Hikvision DS-K2704XP Access Controller

Product's Documents

Below are documents related to this product, you can read online or download:
User Manual Installation Instruction
  • Hikvision Access Controller Quick Start Guide - (English) Download
Specification
  • Hikvision DS-K2704XP Access Controller Datasheet 0.52MB - (English) Download
DS-K2704XP photo

Hikvision DS-K27XX Series Access Controller User Manual

This is the main product document for model DS-K2704XP.

The file format is pdf, 85 pages, you can download this manual here .

background
DS-K27XX Series Access Controller
User Manual
background
Legal Informaon
About this Document
This Document includes instrucons for using and managing the Product. Pictures, charts,
images and all other
informaon hereinaer are for descripon and explanaon only.
The
informaon contained in the Document is subject to change, without noce, due to
rmware updates or other reasons. Please nd the latest version of the Document at the
Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision
Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no
warranes, express or implied.
Please use the Document with the guidance and assistance of professionals trained in
supporng the Product.
About this Product
This product can only enjoy the aer-sales service support in the country or region where the
purchase is made.
If the product you choose is a video product, please scan the following QR code to obtain the
"Iniaves on the Use of Video Products", and read it carefully.
Acknowledgment of Intellectual Property Rights
Hikvision owns the copyrights and/or patents related to the technology embodied in the
Products described in this Document, which may include licenses obtained from third pares.
Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part
of this Document may be excerpted, copied, translated, or modied in whole or in part by any
means without
wrien permission.
and other Hikvision's trademarks and logos are the properes of Hikvision in
various
jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
LEGAL DISCLAIMER
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR
DS-K27XX Series Access Controller User Manual
i
background
IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.
IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE
LATTER PREVAILS.
Data
Protecon
To protect data, the development of Hikvision Products incorporates privacy by design
principles. For example, for Products with facial
recognion features, biometrics data is stored in
your Products with encrypon method; for ngerprint Products, only ngerprint template will be
saved, which is impossible to reconstruct a
ngerprint image.
As a data controller/processor, you may process personal data, including collecon, storage, use,
processing, disclosure,
deleon, etc. You are advised to pay aenon to and comply with
applicable laws and regulaons related to the protecon of personal data, including without
limitaon, conducng security controls to safeguard personal data, such as, implemenng
reasonable administrave and physical security controls, conduct periodic reviews and the
assessments of the
eecveness of your security controls.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
DS-K27XX Series Access Controller User Manual
ii
background
Available Model
Product Name Model
Access Controller DS-K2701X Series Access Controller
DS-K2702X Series Access Controller
DS-K2702WX-E1 Series Access Controller
DS-K2704X Series Access Controller
DS-K2708X Series Access Controller
Access Module DS-K2M002X Access Module
DS-K27XX Series Access Controller User Manual
iii
background
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the users authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the
instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television
recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the
separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC
Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired
operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-K27XX Series Access Controller User Manual
iv
background
under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated
collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include
leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the
baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two
condions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence.
L'exploitaon est autorisée aux deux condions suivantes :
1. l'appareil ne doit pas produire de brouillage, et
2.
l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est suscepble d'en compromere le fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmier by Industry Canada. To reduce
potenal radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communicaon.
Conformément à la réglementaon d'Industrie Canada, le présent émeeur radio peut fonconner
avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émeeur par
Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intenon des
autres ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une
communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
DS-K27XX Series Access Controller User Manual
v
background
Cet équipement doit être installé et ulisé à une distance minimale de 20 cm entre le radiateur et
votre corps.
DS-K27XX Series Access Controller User Manual
vi
background
Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The
precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
All the electronic operaon should be strictly compliance with the electrical safety regulaons,
re prevenon regulaons and other related regulaons in your local region.
Please use the power adapter, which is provided by normal company. The power consumpon
cannot be less than the required value.
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or
re hazard.
Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
When the product is installed on wall or ceiling, the device shall be
rmly xed.
If smoke, odors or noise rise from the device, turn
o the power at once and unplug the power
cable, and then please contact the service center.
Do not ingest baery, Chemical Burn Hazard.
This product contains a
coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used
baeries away from children. If the baery compartment does not close
securely, stop using the product and keep it away from children. If you think baeries might have
been swallowed or placed inside any part of the body, seek immediate medical
aenon.
If the product does not work properly, please contact your dealer or the nearest service center.
Never
aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
DS-K27XX Series Access Controller User Manual
vii
background
Cauons:
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
The device cover for indoor use shall be kept from rain and moisture.
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the
same me.
Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
Please keep all wrappers
aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to addional costs.
Improper use or replacement of the
baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the
baery manufacturer.
DS-K27XX Series Access Controller User Manual
viii
background
Contents
Chapter 1 Features ..................................................................................................................... 1
Chapter 2 Appearance ................................................................................................................ 2
2.1 Appearance and Interfaces of 1-Door/2-Door/4-Door/8-Door Access Controller ................. 2
2.2 Access Module Appearance ................................................................................................... 6
2.3 Indicator Descripon ............................................................................................................. 7
Chapter 3 Terminal Wiring .......................................................................................................... 9
3.1 Wiring Descripon ................................................................................................................. 9
3.2 Wiegand Card Reader Wiring ............................................................................................... 12
3.3 RS-485 Card Reader Wiring .................................................................................................. 13
3.4 Door Lock Wiring ................................................................................................................. 14
3.5 Alarm Wiring ........................................................................................................................ 14
3.6 Exit Buon Wiring ................................................................................................................ 14
3.7 Door Contact Wiring ............................................................................................................ 15
3.8 Fire Alarm Module Wiring .................................................................................................... 15
Chapter 4
Installaon ............................................................................................................... 17
4.1 Install Access Controller ....................................................................................................... 17
4.2 Install Access Controller Main Board ................................................................................... 19
Chapter 5
Sengs .................................................................................................................... 23
Chapter 6 Acvaon ................................................................................................................. 24
6.1 Acvate via Web Browser .................................................................................................... 24
6.2
Acvate via SADP ................................................................................................................. 24
Chapter 7 Typical Applicaon ................................................................................................... 27
Chapter 8 Quick Operaon via Web Browser ............................................................................ 28
8.1 Set Security
Queson ........................................................................................................... 28
8.2 Select Language ................................................................................................................... 28
8.3 Time Sengs ........................................................................................................................ 28
DS-K27XX Series Access Controller User Manual
ix
background
Chapter 9 Operaon via Web Browser ...................................................................................... 29
9.1 Login .................................................................................................................................... 29
9.2 Forget Password ................................................................................................................... 29
9.3 Module
Descripon ............................................................................................................. 29
9.4 Access Control Management ............................................................................................... 30
9.4.1 Overview ..................................................................................................................... 30
9.4.2 Search Event ................................................................................................................ 30
9.4.3 Access Point Management .......................................................................................... 31
9.4.4 Permission Management ............................................................................................ 36
9.4.5 Access Control Applicaon .......................................................................................... 39
9.5 Person Management ............................................................................................................ 47
9.5.1 Add Organizaon ........................................................................................................ 47
9.5.2 Add Person .................................................................................................................. 47
9.6 Device Management ............................................................................................................ 50
9.6.1 Search Not Added Device ........................................................................................... 50
9.6.2 Add Access Module ..................................................................................................... 50
9.6.3 Area Management ...................................................................................................... 53
9.7 System and Maintenance ..................................................................................................... 53
9.7.1 View Device
Informaon ............................................................................................. 53
9.7.2 Set Time ...................................................................................................................... 53
9.7.3 Set DST ........................................................................................................................ 54
9.7.4 Change Administrator's Password ............................................................................... 54
9.7.5 Account Security
Sengs ............................................................................................ 55
9.7.6 View Online User ........................................................................................................ 55
9.7.7 View Open Source Soware License on PC Web ........................................................ 55
9.7.8 View Device Arming/Disarming
Informaon .............................................................. 56
9.7.9 Network Sengs ......................................................................................................... 56
9.7.10 Event
Sengs ............................................................................................................ 59
DS-K27XX Series Access Controller User Manual
x
background
9.7.11 Access Conguraon ................................................................................................. 62
9.7.12 Card Sengs ............................................................................................................. 64
9.7.13 Maintenance and Security ........................................................................................ 66
9.7.14
Cercate Management ........................................................................................... 68
Chapter 10 Other Plaorms to Congure .................................................................................. 70
Appendix A. Dimension ............................................................................................................ 71
DS-K27XX Series Access Controller User Manual
xi
background
Chapter 1 Features
The access controller and access module are cascaded by RS-485. The 4-door access controller
can control up to 128 doors, the 2-door access controller can control up to 126 doors, and the 1-
door access controller can control up to 125 doors.
Supports access control applicaon.
Supports management via Web client.
Supports RS-485 to achieve hand-in-hand cascade.
Supports backup
baery charging and discharging.
Note
Only paral models support this funcon.
Uplink supports wired network or Wi-Fi; Downlink supports Wiegand (customizable) and OSDP.
Note
Only paral models support Wi-Fi funcon.
In addion to the convenonal DC 12 V power supply, device can also be powered via POE.
Note
Only paral models support this funcon.
The main board sells separately and supports rail mounng.
DS-K27XX Series Access Controller User Manual
1
background
Chapter 2 Appearance
2.1 Appearance and Interfaces of 1-Door/2-Door/4-Door/8-Door Access
Controller
The appearance and interfaces of 1-door/2-door/4-door/8-door access controller are as follows.
Appearance and Interfaces of 1-Door Access Controller
Figure 2-1 Appearance and Interfaces of 1-Door Access Controller
DS-K27XX Series Access Controller User Manual
2
background
Figure 2-2 Appearance and Interfaces of 1-Door Access Controller Main Board
Appearance and Interfaces of 2-Door Access Controller
Note
Only paral models support Wi-Fi and POE funcon.
PoE model devices need to be aware of the following:
1. The switch specicaon is 30 W.
2. PoE and Wi-Fi
funcon cannot be used at the same me.
3. If the total power of the incoming locks exceeds 10 W, an addional separate power supply is
required for one of the locks.
4. Supports access to up to 4 card readers.
DS-K27XX Series Access Controller User Manual
3
background
Figure 2-3 Appearance and Interfaces of 2-Door Access Controller
Figure 2-4 Appearance and Interfaces of 2-Door Access Controller Main Board
DS-K27XX Series Access Controller User Manual
4
background
Appearance and Interfaces of 4-Door Access Controller
Figure 2-5 Appearance and Interfaces of 4-Door Access Controller
Figure 2-6 Appearance and Interfaces of 4-Door Access Controller Main Board
DS-K27XX Series Access Controller User Manual
5
background
Appearance and Interfaces of 8-Door Access Controller
Figure 2-7 Appearance and Interfaces of 8-Door Access Controller
2.2 Access Module Appearance
View the access module appearance.
DS-K27XX Series Access Controller User Manual
6
background
Figure 2-8 Access Module Appearance
2.3 Indicator
Descripon
The indicator descripon of 1-door/2-door/4-door/8-door access controller and access module is
as follows.
Device Name
Descripon
1-Door Access Controller There are a total of 9 indicators: a power
supply indicator, a working status indicator, a
network indicator, a door status and 5 RS-485
status indicators.
2-Door Access Controller There are a total of 11 indicators: a power
supply indicator, a working status indicator, a
network indicator, a Wi-Fi indicator, 5 RS-485
status indicators and 2 door status indicators.
DS-K27XX Series Access Controller User Manual
7
background
Note
Some models do not support Wi-Fi
indicators.
4-Door Access Controller There are a total of 12 indicators: a power
supply indicator, a working status indicator, a
network indicator, 5 RS-485 status indicators
and 4 door status indicators.
8-Door Access Controller Access Controller: There are a total of 12
indicators: a power supply indicator, a
working status indicator, a network indicator,
5 RS-485 status indicators and 4 door status
indicators.
Access module: There are a total of 6
indicators: a power supply indicator, a
working status indicator, 2
communicaon
status indicators, and 2 door status
indicators.
Access Module There are a total of 6 indicators: a power
supply indicator, a working status indicator, 2
communicaon status indicators, and 2 door
status indicators.
Note
When the working status indicator is red, it means that the device is powered on; When the
working status indicator is ashing green, it means that the device is added to the plaorm. When
the door status indicator is on, it means that the door is open, and the light is o means that the
door is closed. When the other status indicators are on, it means
connecng, and the light o
means that it is not connected.
DS-K27XX Series Access Controller User Manual
8
background
Chapter 3 Terminal Wiring
Terminal Wiring Descripon of the Access Controller.
3.1 Wiring Descripon
The wiring of 1-door/2-door/4-door/8-door access controller are as follows.
Figure 3-1 The Wiring of 1-Door Access Controller
DS-K27XX Series Access Controller User Manual
9
background
Figure 3-2 The Wiring of 2-Door Access Controller
DS-K27XX Series Access Controller User Manual
10
background
Figure 3-3 The Wiring of 4-Door Access Controller
DS-K27XX Series Access Controller User Manual
11
background
Figure 3-4 The Wiring of Access Module
3.2 Wiegand Card Reader Wiring
You can view the Wiegand card reader wiring diagram.
DS-K27XX Series Access Controller User Manual
12
background
Figure 3-5 Wiegand Card Reader Wiring Diagram
Note
You must connect the OK/ERR/BZ, if using access controller to control the LED and buzzer of the
Wiegand card reader.
3.3 RS-485 Card Reader Wiring
You can view the RS-485 card reader wiring diagram.
Figure 3-6 RS-485 Card Reader Wiring Diagram
Note
If the card reader is installed too far away from the access controller, you can use an external
power supply.
It is recommended to use hand-in-hand wiring to connect the RS-485 card reader.
DS-K27XX Series Access Controller User Manual
13
background
3.4 Door Lock Wiring
You can view the door lock wiring diagram.
Figure 3-7 Wiring Diagram of Door Lock
3.5 Alarm Wiring
You can view the alarm wiring diagram.
Figure 3-8 Alarm Wiring
3.6 Exit
Buon Wiring
You can view the exit buon wiring diagram
DS-K27XX Series Access Controller User Manual
14
background
Figure 3-9 Exit Buon Wiring
3.7 Door Contact Wiring
You can view the door contact wiring diagram.
Figure 3-10 Door Contact Wiring
3.8 Fire Alarm Module Wiring
You can view the
re alarm module wiring diagram.
DS-K27XX Series Access Controller User Manual
15
background
Figure 3-11 Fire Alarm Module Wiring
DS-K27XX Series Access Controller User Manual
16
background
Chapter 4 Installaon
4.1 Install Access Controller
The access controller chassis can be wall-mounted.
Steps
Note
Indoor use only.
The minimum bearing weight of the wall or other places should be 3 mes heavier than the
device weight.
Here we take 1-door access controller as example.
1.
Fix 3 SC-KA4X45 screws to the wall, and 3 to 5 mm thread should be reserved on the top of the
screw (to facilitate subsequent hanging of the chassis).
Figure 4-1 Fix Chassis
2.
Open the chassis cover and press the holes on the chassis body with the screws reserved on the
wall. Then aach the chassis from top to boom onto the screws.
DS-K27XX Series Access Controller User Manual
17
background
Figure 4-2 Hang Chassis
3.
Close the chassis cover to complete the installaon.
DS-K27XX Series Access Controller User Manual
18
background
Figure 4-3 Complete Installaon
4.2 Install Access Controller Main Board
The access controller main board can be wall-mounted.
Steps
Note
Indoor use only.
The minimum bearing weight of the wall or other places should be 3 mes heavier than the
device weight.
Here we take 1-door access controller main board as example.
1.
Use 2 SC-KA4X25 screws to secure the rail to the wall.
DS-K27XX Series Access Controller User Manual
19
background
Figure 4-4 Secure Rail
2.
Align the rail groove on the boom of the device with the rail, press the device, and snap the
device to the rail with the tabs on the
boom.
DS-K27XX Series Access Controller User Manual
20
background
Figure 4-5 Fix Device
3.
Installaon completed.
DS-K27XX Series Access Controller User Manual
21
background
Figure 4-6 Complete Installaon
DS-K27XX Series Access Controller User Manual
22
background
Chapter 5 Sengs
Hardware Inializaon
Hold the restore buon for 5s to inialize the hardware.
Fire Relay NO/NC
The posion of the re jumper cap posion and the related NO/NC status are as follows:
Note
This operaon requires disassembling the upper and lower shells of the device, which is
recommended by a professional.
Figure 5-1 Fire Jumper Cap Posion Descripon
Normally Closed Status Normally Open Status
DS-K27XX Series Access Controller User Manual
23
background
Chapter 6 Acvaon
You should acvate the device before the rst login. Aer powering on the device, the system will
switch to Device
Acvaon page.
Acvaon via the device, SADP tool and the client soware are supported.
The default values of the device are as follows:
The default IP address: 192.0.0.64
The default port No.: 8000
The default user name: admin
6.1
Acvate via Web Browser
You can acvate the device via the web browser.
Steps
1.
Enter the device default IP address (192.0.0.64) in the address bar of the web browser, and press
Enter.
Note
Make sure the device IP address and the computer's should be in the same IP segment.
2.
Create a new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
3.
Click Acvate.
4.
Edit the device IP address. You can edit the IP address via the SADP tool, the device, and the
client soware.
6.2
Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
DS-K27XX Series Access Controller User Manual
24
background
Before You Start
Get the SADP soware from the supplied disk or the ocial website hp://
www.hikvision.com/en/ , and install the SADP according to the prompts.
The device and the PC that runs the SADP tool should be within the same subnet.
The following steps show how to acvate a device and modify its IP address. For batch acvaon
and IP addresses modicaon, refer to User Manual of SADP for details.
Steps
1.
Run the SADP soware and search the online devices.
2.
Find and select your device in online device list.
3.
Input new password (admin password) and
conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
4.
Click Acvate to start acvaon.
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
DS-K27XX Series Access Controller User Manual
25
background
2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking Enable DHCP.
3) Input the admin password and click Modify to acvate your IP address modicaon.
DS-K27XX Series Access Controller User Manual
26
background
Chapter 7 Typical Applicaon
The typical applicaon for access controller, access module, lock and plaorm is as follows.
Figure 7-1 Typical Applicaon
1
No RS-485 redundant protecon max. 128 doors.
Note
The DS-K2704X series support up to 128 doors; K2702X series support up to 126 doors;
K2701x series support up to 125 doors.
2 With RS-485 redundant protecon max. 64 doors.
3 Max. 4 doors.
DS-K27XX Series Access Controller User Manual
27
background
Chapter 8 Quick Operaon via Web Browser
8.1 Set Security Queson
If you forget the device acvaon password, you can change the password via security quesons.
Set the security quesons before conguraon.
Click in the top right of the web page to enter the Change Password page. You can click Skip to
skip the step. Or select three quesons to answer and click Next.
8.2 Select Language
You can select a language for the device system.
Click in the top right of the web page to enter the Device Language Sengs page. You can
select a language for the device system from the drop-down list.
By default, the system language is English.
Note
Aer you change the system language, the device will reboot automacally.
8.3 Time Sengs
Click in the top right of the web page to enter the wizard page.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
NTP
You should set the NTP server's IP address, port No., and interval.
Manual
By default, the device
me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's
me.
Server Address/NTP Port/Interval
You can set the server address, NTP port, and interval.
DST
You can view the DST start me, end me and bias me.
DS-K27XX Series Access Controller User Manual
28
background
Chapter 9 Operaon via Web Browser
9.1 Login
You can login via the web browser or the remote conguraon of the client soware.
Note
Make sure the device is acvated. For detailed informaon about acvaon, see Acvaon
Chapter.
It is recommended to log in through the Chrome browser.
Login via Web Browser
Enter the device IP address in the address bar of the web browser and press Enter to enter the
login page.
Enter the device user name and the password. Click Login.
Login via Remote
Conguraon of Client Soware
Download and open the client soware. Aer adding the device, click to enter the Conguraon
page.
9.2 Forget Password
If you forget the password when logging in, you can change the password by security quesons.
On the login page, click Forget Password.
Answer the security quesons.
Click Next, create a new password and conrm it.
9.3 Module
Descripon
You can set Person management, device management, access control, system and maintenance
parameters.
Click on the right side to open the module descripon page and view the descripon of each
module. Click each hyperlink to jump to the corresponding
sengs page.
Conguraon process is as follows:
DS-K27XX Series Access Controller User Manual
29
background
9.4 Access Control Management
9.4.1 Overview
You can select the area and control the door status, view the device status, view the event, view
the person informaon, network status, basic informaon, and device capacity. You can also enter
the page from quick start part.
Login the web browser and enter the Access Control → Overview .
Door Status
Click View More to view and control all doors' status.
/ / /
Set the door status as unlock, closed, remain open, or remain closed.
Quick Start
Click Add Person, Add Device, System Sengs, or System and Maintenance on the upper-right
of the page to quick enter the page to
congure parameters.
Event
You can view the event Employee ID, Name, Card No., Event Type, Time, and Operaon.
You can also click View More to enter the search condions, including the event type, employee
ID, the name, the card No., the start
me, and the end me, and click Search. The results will be
displayed on the right panel.
Device Status
View the other linked devices' status.
Person Informaon
View the person number, card number, ngerprint No.
Network Status
You can view the connected and registered status of wired network, wireless network, ISUP and
cloud service.
Basic
Informaon
You can view the model, serial No. and rmware version.
Device Capacity
You can view the person, card, ngerprint, and event capacity.
9.4.2 Search Event
Click Access Control → Event Search to enter the Search page.
DS-K27XX Series Access Controller User Manual
30
background
Enter the search condions, including the event type, the employee ID, the name, the card No., the
start me, and the end me, and click Search.
Note
The searched name should be up to 32 bits.
The results will be displayed on the right panel.
9.4.3 Access Point Management
Click Access Control → Access Point Management, you can view the doors associated with the
access controller and the card readers associated with the doors.
Hover the mouse over the door or card reader on the right side of the interface, and you can click
to
congure the door parameters and the card reader authencaon parameters.
Set Door Parameters
Set the door parameters.
You can enter the door parameters page from the following 2 methods:
1. Click Access Control → Access Point Management . Hover the mouse on the door and click
to
enter the door parameters page.
2. Click Access Control
Conguraon → Door Parameters .
Click Save to save the sengs aer the conguraon. Click Copy to to copy the door's parameters
to other doors.
DS-K27XX Series Access Controller User Manual
31
background
Figure 9-1 Set Door Parameters
Door Name
You can create a name for the door.
Area
Select an added area or click Add Area to add a new area for the door.
Open
Duraon
Set the door unlocking duraon. If the door is not opened for the set me, the door will be
locked.
Door Open Timeout Alarm
An alarm will be triggered if the door has not been closed within the congured me duraon.
Door Contact Type
You can set the door contact as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Closed.
Exit
Buon Type
You can set the exit buon as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Open.
Extended Open Duraon
The door contact can be enabled with appropriate delay aer person with extended access
needs swipes her/his card.
Door Remain Open
Duraon with First Person
DS-K27XX Series Access Controller User Manual
32
background
Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows
mulple persons access the door or other authencaon acons.
Duress Code
The door can open by inpung the duress code when there is duress. At the same me, the
client can report the duress event.
Super Password
The
specic person can open the door by inpung the super password.
Dismiss Code
When the alarm is triggered, you can enter the dismiss code to dismiss the alarm.
Note
The duress code and the super password should be dierent.
Set Authencaon Parameters
You can enter the authencaon parameters page from the following 2 methods:
1. Click Access Control → Access Point Management . Hover the mouse on the card reader and
click
to enter the authencaon parameters page.
2. Click Access Control Conguraon Authencaon Parameters .
Click Save to save the
sengs aer the conguraon. Click Copy to to copy the card reader's
parameters to other card readers.
Note
The funcons vary according to dierent models. Refers to the actual device for details.
DS-K27XX Series Access Controller User Manual
33
background
Figure 9-2 Set Authencaon Parameters
Card Reader Parameter Conguraon
Card Reader Name
Create a name for the card reader.
DS-K27XX Series Access Controller User Manual
34
background
Card Reader Type/Card Reader Descripon
View the card reader's type and descripon.
Enable Authencaon Device
Enable the authencaon funcon.
Authencaon
Interval
You can set the authencaon interval of the same person when authencang. The same
person can only authencate once in the congured interval. A second authencaon will be
failed.
Alarm of Max. Failed
Aempts
Enable to report alarm when the card reading aempts reach the set value.
Max. Authencaon Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Communicaon with Controller Every
When the access control device cannot connect with the card reader for longer than the set
me, the card reader will turn oine automacally.
Max. Interval When Entering Password
When you entering the password on the card reader, if the interval between pressing two
digits is longer than the set value, the digits you pressed before will be cleared automacally.
OK LED Polarity/Error LED Polarity/Buzzer Polarity
Set OK LED Polarity/Error LED Polarity/Buzzer Polarity of the access control device according
to the card reader parameters. Generally, adopts the default sengs.
Tampering Detecon
Enable the an-tamper detecon for the card reader.
QR Code
Enable the funcon and the card reader can recognize the QR code for authencaon.
Note
The funcon should be supported by the card reader.
Bluetooth Parameter Conguraon
Enable Bluetooth
Enable the bluetooth funcon and the you can use the bluetooth funcon (e.g. opening
door) on the card reader.
Device Name/Transming Power
Edit the card reader's name and its transming power.
Open Door via Bluetooth
DS-K27XX Series Access Controller User Manual
35
background
Enable the funcon and you can open the door via bluetooth through App. You should add
the device to the App before use the funcon.
Authencaon Plan Conguraon
Set the authencaon schedule for the card reader.
Select an authencaon type and drag the me duraon on the me schedule table to draw
the authencaon duraon.
Click Clear and drag a me duraon to delete, or click → Clear All to delete all me
duraons.
Set Smart Parameters
Click Access Control Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
Aer conguring the general parameters, all card readers will take eect.
Click Save to save the sengs aer the conguraon.
Fingerprint Recognion
The device support recognion ngerprint aer the funcon is enabled.
Fingerprint Security Level
Select the ngerprint security level.
The higher is the security level, the lower is the false acceptance rate (FAR).
9.4.4 Permission Management
You can set access permission schedule template, holiday schedule template, and set access
permission.
Congure
Schedule Template
Set Access Schedule Template
Access schedule templates are used to set authorized passing me for people. The device provides
three default access schedule templates: all-day template, workday template, and weekend
template. You can also add custom templates according to actual needs.
Steps
1.
Click Access Control → Permission Management → Access Plan Management → + Add.
DS-K27XX Series Access Controller User Manual
36
background
Figure 9-3 Set Access Schedule Template
2.
Set the template.
Name
Set the template name.
3.
On the weekly schedule template, drag the cursor to draw on the
me bar.
Note
You can set up to 8 access periods per day.
4.
Oponal: Click Clear, and drag on the me bar to delete the corresponding me period.
5.
Oponal: Select Holiday Schedule.
Note
If the holiday schedule and weekly schedule conict, the holiday schedule will be in priority.
1) Click Select Holiday.
2) Select holiday, and set holiday name and date.
3) Click Add.
4) Click and drag on the corresponding
me bar to draw the valid access permission period.
Note
You can set up to 8 access periods per day.
6.
Click Save.
DS-K27XX Series Access Controller User Manual
37
background
Set Holiday Schedule Template
You can set a legal holiday or a specied date as a holiday. The access permission of holiday is
higher than other basic access permission.
Steps
1.
Click Access Control → Permission Management → Holiday Schedule Management → + Add.
Figure 9-4 Set Holiday Schedule Template
2.
Enter holiday name.
3.
Set the start date and end date of holiday.
4.
Click and drag on the corresponding
me bar to draw the valid access permission period.
5.
Oponal: Move the cursor or click Clear to adjust the me period that has been drawn.
6.
Click Save.
Set Access Permission
Access permission can be dened, and it can be convenient to group according to access points
and manage uniformly.
Steps
1.
Click Access Control → Permission Management → Manage Access Permission → +Add.
DS-K27XX Series Access Controller User Manual
38
background
Figure 9-5 Set Access Permission
2.
Enter Access Permission Name.
3.
Select Access Schedule. You can click View on the right side to view the access period of
dierent template.
4.
Click + Add to check the access point, and click Save.
5.
Click Save.
9.4.5 Access Control
Applicaon
Open Door with First Person
The rst person can be set to open the door, that is, aer a specic person (the rst person) uses
credenals (such as cards, ngerprints, and faces) to authencate, other personnel can pass
directly, or use
credenals to pass, which is oen used in scenarios where a large number of
people pass.
Before You Start
The device is added. For more informaon about how to add a device, see Device Management .
Steps
1.
Click Access Control → Access Control Applicaon → Open Door with First Person → +Add.
DS-K27XX Series Access Controller User Manual
39
background
Figure 9-6 Open Door with First Person
2.
Click + Add, and select the access point.
3.
Set the parameters of rst person.
Rule of Opening Door
Remain Open
Aer the rst person is authencated, the door opening status will last for a period of
me, and other personnel can pass without authencaon during this me period. This
funcon is oen used in scenarios where a large number of people pass, such as group
visitors entering tourist aracons. The door-open duraon can be congured.
Authorizaon
The mode is applicable to places with high security requirements. Only aer the person
congured with access permission passes through, other persons can pass through aer
authencang with credenals.
Consecuve Authencaon Times
The number of mes that authencaon is valid during consecuve authencaon periods.
Interval of Consecuve Authencaon
The interval between which the same person can repeat authencaon. Repeated
authencaon by the same person at the congured interval is considered invalid.
First Person Authencaon Time
You can set the start me and eecve me periods of the rst person.
4.
Add the rst person. Click + Add, and select the rst person.
1) Click + Add.
2) Select the
rst person.
DS-K27XX Series Access Controller User Manual
40
background
3) Click OK.
5.
Click OK.
6.
Oponal: Select mulple rst personnel and click Delete to delete related sengs.
Mul-Factor Authencaon Sengs
Only aer authencang according to the mul-factor authencaon rule, can persons in mul-
factor authencaon groups open the door.
Before You Start
The device is added. For more details, see
Device Management .
The access point is added. For more details, see Access Point Management .
The access schedule is set. For more details, see
Permission Management .
Steps
1.
Click Access Control → Access Control
Applicaon Mul-Factor Authencaon.
Figure 9-7 Mul-Factor Authencaon Sengs
2.
Click Group Management.
1) Click +, and enter the group name.
2) Click + Add, select person, and click OK.
DS-K27XX Series Access Controller User Manual
41
background
3) Click OK. The added group will show in the list on the le side of the page. When you select a
group, the informaon about the people in the group will show on the right side of the page.
4) Oponal: Select a group, click + Add, and you can add more group members. Select and click
OK.
3.
Add mul-factor authencaon rule.
1) Click + Add.
2) Set
mul-factor authencaon parameters.
Mul-Factor Authencaon Name
Create the
mul-factor authencaon name.
Access Point
In the drop-down box, select the access point that needs to be applied in the relevant
mul-factor authencaon.
Authencaon Mode
Local Authencaon
Personnel can only open the door aer authencang locally on the device in
accordance with the
authencaon rules.
Local Authencaon + Remotely Opening Door
Personnel can only open the door aer aer authencang locally on the device in
accordance with the authencaon rules and authencang via plaorm remotely.
Local Authencaon + Super Credenal
Personnel can only open the door aer aer authencang locally on the device in
accordance with the
authencaon rules and authencang via super credenal.
Access Schedule
Select the access schedule. Click View to see the template details.
Time Interval of Card Present
Congure the me interval between authencaon for dierent authencang personnel.
Group
Click Link to Organizaon, and select the group. In the added group, you can drag in the
operaon bar to adjust the order, or congure the Number of Persons for Authencaon.
It needs to be authencated according to the order in the list and the Number of Persons
for Authencaon when authencang.
3) Click OK.
4.
Oponal: Select the unnecessary mul-factor authencaon, and click Delete.
5.
Click
to view the access schedule details.
DS-K27XX Series Access Controller User Manual
42
background
Mul-Door Interlocking Sengs
Mul-door interlocking refers to mulple doors forming an interlocking combinaon, in which one
door can only be opened at most at the same
me, and the other doors must be closed.
Before You Start
The device is added. For more details, see
Device Management .
The access point is added. For more details, see
Access Point Management .
Steps
1.
Click Access Control → Access Control
Applicaon Mul-Door Interlocking → + Add.
Figure 9-8 Mul-Door Interlocking Sengs
2.
Create the name.
3.
Click + Add, and select the access points.
4.
Delete unnecessary access points.
-
Select unnecessary access points in the list and click Delete to delete access points in batch.
-
Click to delete the single access point.
5.
Click OK.
6.
You can edit and delete the created
mul-door interlocking.
-
Select the
mul-door interlocking, and click to edit.
-
Select the mul-door interlocking, and click to delete.
-
Select the
mul-door interlocking, and click Delete to delete in batch.
DS-K27XX Series Access Controller User Manual
43
background
An-Passback Sengs
Personnel must follow the set route for one-way passing. If you do not follow this route for
authencaon, the door will not open. If a person does not enter the door aer swiping the card,
the door will not open when swiping the card again, and the same will apply when going out.
Before You Start
The device is added. For more details, see Device Management .
Steps
1.
Click Access Control → Access Control
Applicaon An-Passback.
Figure 9-9 An-Passback Sengs
2.
Add an-passback route.
1) Enter name and click Next.
2) Set card reader order. Click Add and select the card reader.
3) Click
to add another card reader.
4) Repeat substep 3 to add mulple card readers.
5)
Oponal: Click a card reader to replace or remove the card reader.
6) Click Next.
7) Set rst card reader.
Disable
If the passed card reader of last person recorded by the device is not set
an-passback
or the person is a new user, the an-passback is authencated to pass.
If the passed card reader of last person recorded by the device has set
an-passback, it is
necessary to check whether the current card reader is in the sequent an-passback card
reader
aer the last passed card reader, if so, the an-passback is authencated to pass;
if not, the an-passback authencang failed.
Select One Card Reader as First Card Reader
In any case, the personnel swipe the rst card reader and the an-passback will be
authencated to pass.
If the passed card reader of last person recorded by the device has set an-passback, it is
necessary to check whether the current card reader is in the sequent
an-passback card
reader aer the last passed card reader, if so, the an-passback is authencated to pass;
DS-K27XX Series Access Controller User Manual
44
background
If not, the an-passback authencang failed. And the an-passback authencang
failed in any other cases.
Note
If you violated the an-passback rule, you should swipe the card again from the rst card
reader.
Superusers do not follow the above rules.
Up to 64 doors can be applied in
an-passback.
3.
Oponal: Set an-passback parameter.
1) Click An-Passback Parameter.
2) You can enable Forgive
An-Passback, and set the Forgive An-Passback schedule.
Forgiving Mode
Forgive An-Passback Regularly
Set the me of Forgive An-Passback, the system will clear the an-passback at the set
me. Aer clearing, the personnel need to follow the an-passback rules again, starng
from the rst card reader to authencate.
Delay Forgiving An-Passback
Set the me of Forgiving An-Passback. The system starts ming aer the person
swipes the card, and aer the set delay me, the an-passback will be cleared. Aer
clearing, the personnel need to follow the an-passback rules again, starng from the
rst card reader to authencate.
Non An-Passback Period
Aer selecng the eecve me, drag to draw the non an-passback period on the me
bar, and the an-passback will not take eect within the congured me period.
Click Clear, and drag on the me bar to delete related me period.
Click
→ Clear All to delete all me periods.
3) Click Save.
4.
You can edit, delete and view the created
an-passback.
-
Select the an-passback, and click to edit.
-
Select the
an-passback, and click to delete.
-
Select mulple an-passback, and click Delete to delete in batch.
-
Select the
an-passback, and click to view the an-passback route.
Remain Open or Closed
Sengs
Set the me period by week during which the door(s) remains locked/unlocked.
Before You Start
The device is added. For more details, see Device Management .
The access point is added. For more details, see Access Point Management .
DS-K27XX Series Access Controller User Manual
45
background
Steps
1.
Click Access Control → Access Control Applicaon → Remain Open or Closed.
Figure 9-10 Remain Open or Closed Sengs
2.
Click + Add.
3.
Add the access point.
1) Click + Add.
2) Select the access point, and click OK.
3) You can click
to delete single access point or click Delete to delete in batch.
4.
Set weekly schedule template.
1) Draw
me periods of Remain Open or Closed.
-
Click Remain Open or Remain Closed, and drag over the
me bar of the periods that need to
be remain open or closed.
-
Select Remain Open or Remain Closed, click Quick Operaon, and click All-Day Schedule,
Work Schedule, Weekend Schedule and the
me period will be drawn automacally.
1) Oponal: Click Clear, and drag on the me bar to delete the corresponding me period. Click
→ Clear All to delete all me periods.
5.
Click Save.
DS-K27XX Series Access Controller User Manual
46
background
9.5 Person Management
9.5.1 Add Organizaon
Aer you add an organizaon, you can add people to the corresponding organizaon.
Steps
1.
Click Person Management to enter the sengs page.
2.
Click + on the
le side of the page and select the parent organizaon.
3.
Create the organizaon name.
4.
Click Save.
The added
organizaon will be listed in the selected parent organizaon.
5.
Oponal: Edit / Delete
-
Click an organizaon, and then click to edit the organizaon informaon.
Select people and click Delete to delete the informaon in batch.
Click Clear All, and all person informaon will be deleted.
-
Click an organizaon and click to delete that organizaon informaon.
9.5.2 Add Person
Add the person's informaon, including the basic informaon, cercate, authencaon and
sengs.
Add Basic
Informaon
Click Person Management → Add to enter the Add Person page.
Add the person's basic informaon, including the employee ID, the person's name, and person
type.
Note
If you select Visitor as the person type, you can set the visit mes.
Leers are allowed in the employee ID. Up to 32 bits are allowed.
Up to 128 bits are allowed in the name.
Click Add to save the sengs.
Click Save and Congure to save the sengs and connue to add next person.
Set Permission Time
Click Person Management → Add to enter the Add Person page.
Enable Long-Term Eecve User, or set Start Time and End Time and the person can only has the
permission within the
congured me period according to your actual needs.
Click Add to save the sengs.
DS-K27XX Series Access Controller User Manual
47
background
Click Save and Congure to save the sengs and connue to add next person.
Add Card
Click Person Management → Add to enter the Add Person page.
Click Conguraon. If select the Collecon Device as Card Enrollment Staon, you should select
the device model, card type, set buzzing, M1 card encrypon, and sector. Click OK to save.
Note
If select the Collecon Device as Card Enrollment Staon, click Download to download the plug-in
to view the device status. During the installaon, you should close the web page.
If select the Collecon Device as Card Reader, you should select the card reader from the drop-
down list. Click OK to save.
Click Add Card, enter the Card No. and select the Property, and click OK to add the card.
Click Add to save the
sengs.
Click Save and Congure to save the sengs and connue to add next person.
Add Fingerprint
Note
Only devices supporng the ngerprint funcon can add the ngerprint.
Click Person Management → Add to enter the Add Person page.
Click Conguraon. If you selectUSB Fingerprint Recorder, you can click Downloadto download
the plug-in and view the status. Or select Fingerprint and Card Reader and select a card reader
from the drop-down list. Click OK to save.
Note
During the installaon, you should close the web page.
Click Add Fingerprint, and press your nger on the ngerprint module of the device to add your
ngerprint.
Click Add to save the sengs.
Click Save and Congure to save the sengs and connue to add next person.
Note
The plugin for adding card or ngerprint via USB is only available in Windows.
Add PIN
Before conguring PIN, it is necessary to clarify whether the PIN is a device-set personal PIN or a
plaorm-applied personal PIN. If it is a device-set personal PIN, it can be created or edited on the
device or on the web, and cannot be set on other plaorms; If it is a plaorm-applied personal
PIN, it can be created or edited on the
plaorm, and issued to the device before it can be used. It
cannot be set on the device or on the web.
DS-K27XX Series Access Controller User Manual
48
background
Make sure you have already set the PIN mode as Device-Set Personal PIN in Set Password Mode .
Click PIN Mode on the page to go to congure.
Click Person Management → Add to enter the Add Person page.
Set the PIN. Or click Auto Generate to generate a PIN
automacally.
Click Add to save the sengs.
Click Save and Congure to save the sengs and connue to add next person.
Authencaon Sengs
Click Person Management → Add to enter the Add Person page.
Set the authencaon type.
Click Add to save the sengs.
Click Save and Congure to save the sengs and connue to add next person.
Permission Management
Before you start:
You have already add the device. For details, see
Device Management .
You have already complete access point management. For details, see Access Point
Management .
You have already complete the access permission management. For details, see Permission
Management .
Click Person Management → Add to enter the Add Person page.
Set the permission parameters.
Permission Type
By Permission Group
Click Allocate and select an added access permission. The person will contain the checked
access permission. If you have not added the access permission in advance, you can click Add
Access Permission to add. For details, see
Permission Management . Click OK.
By Access Point
Click Allocate and select the access schedule. ClickAdd to add the access points. The person
will contain the permissions of the access point within the access schedule. Click OK.
Extend Door Opening
The person related door will close aer the congured me duraon. You should go to Set Door
Parameters to set the Extended Open Duraon. Click Door Parameters to go to the
conguraon page.
Click Add to save the sengs.
Click Save and Congure to save the sengs and connue to add next person.
Edit/Delete/Search Person
Click Person Management to enter the page.
Select a person and click to edit the person's informaon.
Select a person and click to delete the person informaon.
DS-K27XX Series Access Controller User Manual
49
background
Select mulple person, click Delete can delete person in batch.
Click Clear All to delete all person informaon.
Click or to switch the viewing method.
Enter the person's employee ID and select the
credenal status and click Filter to search. Click
Reset to reset all
condions.
Check Show Sub Organizaon, all persons in the sub organizaons will be displayed.
9.6 Device Management
9.6.1 Search Not Added Device
The system can automacally search for not added access modules that have been connected to
the access controller.
Click Device Management → Search Not Added Device. The searched not added access modules
will be displayed in the list of the page.
Click
in the acon bar to add an access module to the access controller.
9.6.2 Add Access Module
Add access module manually.
Before You Start
Make sure that the area has been added. For more details, see Area Management .
Steps
1.
Click Device Management to enter the
sengs page.
DS-K27XX Series Access Controller User Manual
50
background
Figure 9-11 Add Access Module
2.
Select the dial address of the access module, and set the DIP switch of the access module to be
consistent with the one shown in the picture.
Note
Aer adding or modifying the dialing address of the access module, you need to reboot the
access module to take it eect.
3.
Set the door parameters, and click Next.
Select Door of Access Module
According to the door actually controlled by the access module, select 1 or 2.
Door Name
Create the door name associated with the access module.
Area
Choose the area from the drop-down list. If you have not created an associated area in
advance, click Add Area to create.
Open
Duraon
Set the acon me aer the associated door is unlocked. If the door is not opened within the
set
me, the door will lock automacally. The range can be set from 1 to 255 s.
Door Magnec Sensor Type
DS-K27XX Series Access Controller User Manual
51
background
The door magnec sensor can be controlled as Remain Closed or Remain Open. Under
normal circumstances, it is Remain Closed (except for special needs).
Exit Buon Type
Under normal circumstances, it is Remain Open (except for special needs).
Extended Open Duraon
For the elderly or children with reduced mobility, by set Extended Open Duraon, the door
magnec sensor opening me aer swiping card can be appropriately delayed.
4.
Set the card reader parameters associated with the access module.
Select Door of Access Module
According to the door actually controlled by the access module, select 1 or 2.
Select Card Reader
Select Enter or Exit according to the actual card reader
locaon.
Card Reader Name
Create the card reader name.
Card Reader Descripon
View the card reader descripon. Read Only
QR Code
If the card reader supports the QR code authencaon funcon, this funcon can be
enabled, then on the card reader, it can be carried out through the QR code authencaon.
Enable Bluetooth
If the card reader supports the Open Door via Bluetooth funcon, this funcon can be
enabled, then on the card reader, the door can be opened via bluetooth.
Authencaon Plan Conguraon
Set the authencaon plan of dierent authencaon type. You can set dierent
authencaon type in dierent me periods.
Select the
authencaon type (you can select more than one), and draw the required me
period in the me bar below, during which you can perform the selected authencaon type.
Click Clear and select the
me period that has been drawn in the me bar to clear the plan.
Click → Clear All to clear all me periods.
5.
Click OK.
6.
Oponal: Other Operaons
Icon
Descripon
You can edit the access module.
You can delete the access module.
You can restart the access module.
You can restore the access module to the factory sengs.
DS-K27XX Series Access Controller User Manual
52
background
You can upgrade the access module. Select a local upgrade package to upgrade.
9.6.3 Area Management
Aer you create an area, you can add access control points to the area to manage them in a
paron.
Steps
1.
Click Device Management → Area Management.
2.
Click + on the le side of the page, select a parent area, and create the area name.
3.
Click Save.
The added area will be listed in the selected parent area.
4.
Oponal: Edit / Delete
-
Select the area and click
to edit the informaon.
Select mulple personnel, and click Delete to delete the informaon of person in batch.
Click Clear All to delete informaon of all personnel.
-
Select the area, and click
to delete the informaon of area.
9.7 System and Maintenance
9.7.1 View Device Informaon
View the device name, language, model, serial No., version, number of channels, IO input, IO
output, RS-485, alarm output, and device capacity, etc.
Click System and Maintenance → System
Conguraon → System → System Sengs → Basic
Informaon to enter the conguraon page.
You can the device name, language, model, serial No., version, number of channels, IO input, IO
output, RS-485, alarm output, and device capacity, etc.
9.7.2 Set Time
Set the device's me zone, synchronizaon mode, server address, NTP port, and interval.
Click System and Maintenance → System
Conguraon → System → System Sengs → Time
Sengs .
DS-K27XX Series Access Controller User Manual
53
background
Figure 9-12 Time Sengs
Click Save to save the sengs aer the conguraon.
Time Zone
Select the device located me zone from the drop-down list.
Time Synchronizaon Mode
NTP
You should set the NTP server's IP address, port No., and interval.
Manual
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's me.
Server IP Address/NTP Port/Interval
You can set the server IP address, NTP port, and interval.
9.7.3 Set DST
Steps
1.
Click System and Maintenance → System
Conguraon → System → System Sengs → Time
Sengs .
2.
Enable DST.
3.
Set the DST start
me, end me and bias me.
4.
Click Save to save the sengs.
9.7.4 Change Administrator's Password
Steps
1.
Click System and Maintenance → System
Conguraon → System → User Management .
2.
Click .
DS-K27XX Series Access Controller User Manual
54
background
3.
Enter the old password and create a new password.
4.
Conrm the new password.
5.
Click Save.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
9.7.5 Account Security Sengs
You can change the security quesons and answers, or the email address for the device. Aer
change the sengs, once you forgot the device password, you should answer the new quesons or
use the new email address to reset the device password.
Steps
1.
Click System and Maintenance → System
Conguraon → System → User Management
Account Security Sengs .
2.
Change the security
quesons or email address according your actual needs.
3.
Enter the device password and click OK to conrm changing.
9.7.6 View Online User
You can view online users.
Click System and Maintenance → System Conguraon → System → User Management
Online Users .
You can view online users'
informaon including name, type, IP Address and operaon me. Click
Refresh to refresh the page.
9.7.7 View Open Source
Soware License on PC Web
On the main page of the device PC Web, click → Open Source Soware Statement , to view the
device license.
DS-K27XX Series Access Controller User Manual
55
background
9.7.8 View Device Arming/Disarming Informaon
View device arming type and arming IP address.
Go to System and Maintenance → System
Conguraon → System → User Management
Arming/Disarming Informaon .
You can view the device arming/disarming informaon. Click Refresh to refresh the page.
9.7.9 Network Sengs
Set Basic Network Parameters
Click System and Maintenance → System Conguraon → Network → Network Sengs
TCP/IP .
Set the parameters and click Save to save the
sengs.
NIC Type
Select a NIC type from the drop-down list.
DHCP
If uncheck the funcon, you should set the IPv4 address, IPv4 subnet mask, IPv4 default
gateway, Mac address, and MTU.
If you check the
funcon, the system will allocate the IPv4 address, IPv4 subnet mask, the IPv4
default gateway
automacally.
DNS Server
Set the preferred DNS server and the Alternate DNS server according to your actual need.
Set Wi-Fi Parameters
Set the Wi-Fi parameters for device wireless connecon.
Steps
Note
The funcon should be supported by the device.
1.
Click System and Maintenance → System Conguraon → Network → Network Sengs → Wi-
Fi .
2.
Check Wi-Fi.
3.
Select a Wi-Fi
-
Click of a Wi-Fi in the list and enter the Wi-Fi password.
DS-K27XX Series Access Controller User Manual
56
background
-
Click Add and enter a Wi-Fi's name, password, and encrypon type. Click Connect. When the
Wi-Fi is connected, click OK.
4.
Oponal: Set the WLAN parameters.
1) Set the IP address, subnet mask, and default gateway. Or enable DHCP and the system will
allocate the IP address, subnet mask, and default gateway automacally.
5.
Click Save.
Set Port Parameters
Set the HTTP, HTTPS, HTTP Listening, RTSP and Server port parameters.
Click System and Maintenance → System Conguraon → Network → Network Service
HTTP(S) .
HTTP
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is
modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.
HTTPS
Set the HTTPS for accessing the browser. Cercate is required when accessing.
HTTP Listening
The device can send alarm informaon to the event alarm IP address or domain name via HTTP
protocol/HTTPS protocol. Edit the event alarm IP address or domain name, URL, port, and
protocol.
Note
The event alarm IP address or domain name should support the HTTP protocol/HTTPS protocol
to receive the alarm informaon.
Click System and Maintenance → System Conguraon → Network → Network Service
WebSocket(s) .
View WebSocket and WebSockets port.
Set ISUP Parameters
Set the ISUP parameters for accessing device via ISUP protocol.
Steps
Note
The funcon should be supported by the device.
1.
Click System and Maintenance → System Conguraon → Network → Device Access → ISUP .
DS-K27XX Series Access Controller User Manual
57
background
Figure 9-13 Set ISUP Parameters
2.
Check Enable.
3.
View the ISUP version, set server IP address, port, device ID,
encrypon key and view the ISUP
status.
4.
Oponal: Click More to set the network connecon priority.
1) Enable WLAN or Wired Network according to your actual needs.
1) Hold and drag
to adjust the access priority.
5.
Set the ISUP listening parameters, including ISUP alarm center IP address/domain name, ISUP
alarm center URL, and ISUP alarm center port.
6.
Click Save.
Plaorm
Access
Plaorm access provides you an opon to manage the devices via plaorm.
DS-K27XX Series Access Controller User Manual
58
background
Steps
1.
Click System and Maintenance → System Conguraon → Network → Device Access → Hik-
Connect to enter the sengs page.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the
device, receive alarm nocaon and so on.
2.
Check Enable to enable the funcon.
3.
Oponal: Check Custom, and you can set the server address by yourself.
4.
Enter the vericaon code.
5.
Oponal: View the register status. Click Refresh to refresh the status.
6.
Oponal: Click More to set the network connecon priority.
1) Enable WLAN or Wired Network according to your actual needs.
1) Hold and drag
to adjust the access priority.
7.
Click View to view device QR code. Scan the QR code to bind the account.
Note
8 to 32 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use a
combinaon of no less than 8 leers or numbers.
8.
Click Save to enable the sengs.
9.
Oponal: Click Refresh to refresh the binding status.
10.
Click Save.
9.7.10 Event
Sengs
Set the event linkage and the alarm output paramters.
Event Linkage
Set linked acons for events.
Steps
1.
Click System and Maintenance → System Conguraon → Event → Event Detecon → Linkage
Sengs to enter the page.
DS-K27XX Series Access Controller User Manual
59
background
Figure 9-14 Event Linkage
2.
Click
3.
Set event source.
-
If you choose Linkage Type as Event Linkage, you need to select event types from the drop-
down list.
-
If you choose Linkage Type as Card Linkage, you need to enter the card No. and select the
card reader.
-
If you choose Linkage Type as Link Employee ID, you need to enter the employee ID and
select the card reader.
4.
Set linked acon.
Linked Access Controller Buzzing
Enable Linked Access Controller Buzzing and select Start Buzzing or Stop Buzzing for the
target event.
Card Reader Linkage
Enable Card Reader Linkage and click Add can check the card reader that will buzz. Click
Save.
Set the card reader's buzzing
acon.
Click to delete single card reader. Check the card readers and click Delete to delete in
batch. Click Batch
Congure to congure all card readers in the list.
Door Linkage
Enable Door Linkage and click Add can check the card reader that will buzz. Click Save.
DS-K27XX Series Access Controller User Manual
60
background
Set the access point's acon.
Click to delete single card reader. Check the card readers and click Delete to delete in
batch.
Linked Alarm Output
If the Linkage Type in the Event Source is Card Linkage, when enable Linked Alarm Output,
you can set Triggering Times Conguraon, Triggering Times (Enable), and Triggering Times
(Disable).
If set Triggering Times (Enable) as 3, and Triggering Times (Disable) as 3, you can present the
card that
congured in the Event Source for 3 me to stop alarm when the following alarm
output in the list is in open status. If the alarm output is in the disabled status, you can
present the card for 3 mes to trigger alarm.
Set the alarm output. Click Add and check the alarm outputs in the list and click Save.
Click
to set the alarm duraon. Click Save.
Note
Aer the conguraon is completed, the conguraon of the same output linked to other
acons will also be changed.
Connuous Alarm
The alarm output device will connuously in the alarm status.
Custom Alarm Duraon
You should set the custom duraon. The alarm output device will be in the alarm status for
the congured me duraon.
Note
Range: from 0 to 5999s.
5.
Click Save.
Alarm
Sengs
Set the device's alarm output parameters.
Click System and Maintenance → System
Conguraon → Event → Alarm Sengs → Alarm
Output .
Select an access point from the list on the
le. Select a alarm output device No. Create a name for
the alarm output device and set the alarm duraon. Click Save.
Connuous Alarm
The alarm output device will connuously in the alarm status.
Custom Alarm Duraon
DS-K27XX Series Access Controller User Manual
61
background
You should set the custom duraon. The alarm output device will be in the alarm status for the
congured me duraon.
Note
Range: from 1 to 5999s.
9.7.11 Access Conguraon
You can set RS-485, Wiegand and host parameters.
Set RS-485 Parameters
You can set the RS-485 parameters including the peripheral, address, baud rate, etc.
Click System and Maintenance → System Conguraon → Access Conguraon → RS-485 .
Figure 9-15 Set RS-485 Parameters
Click Save to save the sengs aer the conguraon.
RS-485 Communicaon Backup
The controller and the access module can communicate via redundant wiring mode.
RS-485 Protocol
Select the RS-485 protocol from the drop-down list.
RS-485 Communicaon Mode
Redundant Wiring
DS-K27XX Series Access Controller User Manual
62
background
When the access controller connects to the terminal (RS-485A/RS-485B/RS-485C/RS-485D) of
the access module, RS-485A and RS-485B are a pair using redundancy wiring, and RS-485C
and RS-485D are another pair. When one of the channels is disconnected, the access
controller can communicate with another channel. No more than 32 access module(s) can be
connected to the access controller.
Single Wiring
RS-485A to RS-485D are communicaon terminals of the access module. The RS-485E
terminal on the access controller can be connected to RS-485A to RS-485D terminals via
single wiring for data transmission. No more than 62 access module(s) can be connected to
the access controller.
No.
Select the RS-485 No.
Baud Rate
The baud rate when the devices are
communicang via the RS-485 protocol.
Serial Port Name
View the serial port name.
Set Wiegand Parameters
You can set the Wiegand transmission direcon.
Steps
Note
Some device models do not support this funcon. Refer to the actual products when conguraon.
1.
Click System and Maintenance → System Conguraon → Access Conguraon → Wiegand
Sengs .
2.
Select a access point from the list on the le.
3.
Set Wiegand parameters.
No.
Select Wiegand No. for parameters sengs.
Wiegand
select to enable the card reader's Wiegand funcon.
Wiegand Direcon
By default, the direcon is Input.
Wiegand Mode
Select the Wiegand mode and the card reader can communicate with the controller by
Wiegand 26/34 or other protocol.
DS-K27XX Series Access Controller User Manual
63
background
Click Auto Recognize, enter card No. to recognize the Wiegand mode. Enter the Card No., and
click Start to Recognize. Present the card on the related card reader. The system will show the
Wiegand mode. Click OK.
If select Custom, you should set custom Wiegand parameters. Click Custom Wiegand
Sengs, and set the name, parity type, total length and Wiegand rule. Click OK.
Wiegand Mapping Card Reader
Select the Wiegand card reader related door and card reader
direcon.
4.
Click Save to save the sengs.
Note
If you change the peripheral, and aer you save the device parameters, the device will reboot
automacally.
Door Magnec Contact Sengs
Set the opening and closing door status of the door magnec contact to match the actual wiring
method.
Before You Start
The access controller has connected to the door magnec contact.
Steps
1.
Click System and Maintenance → Maintenance → Device Access → Host Parameter to enter
the
sengs page.
2.
Select the door magnec contact status.
Barrier Open Status (Default)
The door
magnec contact is in open status in default. Access controller is connected to the
door magnet contact through NO.
Door Closed Status
The door magnec contact is in closed status in default. Access controller is connected to the
door magnet contact through NC.
9.7.12 Card
Sengs
Set Card Security
Click System and Maintenance → System Conguraon → Card Sengs → Card Type to enter the
sengs page.
Set the parameters and click Save.
Enable NFC Card
DS-K27XX Series Access Controller User Manual
64
background
In order to prevent the mobile phone from geng the data of the access control, you can
enable NFC card to increase the security level of the data.
Enable M1 Card
Enable M1 card and authencang by presenng M1 card is available.
M1 Card Encrypon
Sector
M1 card
encrypon can improve the security level of authencaon.
Enable the funcon and set the encrypon sector. By default, Sector 13 is encrypted. It is
recommended to encrypt sector 13.
Enable EM Card
Enable EM card and authencang by presenng EM card is available.
Note
If the peripheral card reader supports presenng EM card, the funcon is also supported to
enable/disable the EM card funcon.
Enable DESFire Card
The device can read the data from DESFire card when enabling the DESFire card funcon.
DESFire Card Read Content
The device can read the DESFire card content.
Enable FeliCa Card
The device can read the data from FeliCa card when enabling the FeliCa card funcon.
Set Card No.
Authencaon Parameters
Set the card reading content when authencate via card on the device.
Go to System and Maintenance → System Conguraon → Card Sengs → Card No. Auth.
Sengs .
Select a card authencaon mode and set the reversed card No. and click Save.
Full Card No.
All card No. will be read.
3 bytes
The device will read card via Wiegand 26 protocol (read 3 bytes).
4 bytes
The device will read card via Wiegand 34 protocol (read 4 bytes).
Enable Reversed Card No.
The read card No. will be in reverse sequence
aer enabling the funcon.
DS-K27XX Series Access Controller User Manual
65
background
9.7.13 Maintenance and Security
Set Privacy Parameters
Set the event storage type, picture upload and storage parameters, and the picture clearing
parameters.
Go to System and Maintenance → System Conguraon → Security → Privacy Sengs
Select a method to delete the event. You can select from Delete Old Events Periodically, Delete
Old Events by Specied Time, or Overwring. Click Save aer conguraon.
Delete Old Events Periodically
Drag the block or enter number to set the period for event deleng. All events will be deleted
according to the
congured me duraon.
Delete Old Events by Specied Time
Set a me and all events will be deleted on the congured me.
Overwring
The earliest 5% events will be deleted when the system detects the stored events has been over
95% of the full space.
Set Password Mode
Before conguring passwords, it is necessary to clarify whether the password is a device-set
personal PIN or a plaorm-applied personal PIN. If it is a device-set personal PIN, it can be created
or edited on the device or on the web, and cannot be set on other
plaorms; If it is a plaorm-
applied personal PIN, it can be created or edited on the plaorm, and issued to the device before it
can be used. It cannot be set on the device or on the web.
Steps
1.
Click System and Maintenance → System
Conguraon → Security → PIN Mode
Device-Set Personal PIN
It can be created or edited on the device or on the web, and cannot be set on other
plaorms.
Plaorm-Applied Personal PIN
It can be created or edited on the plaorm, and issued to the device before it can be used. It
cannot be set on the device or on the web.
2.
Click Save.
DS-K27XX Series Access Controller User Manual
66
background
Upgrade and Maintenance
Reboot device, restore device parameters, and upgrade device version.
Reboot Device
Click System and Maintenance → Maintenance → Restart .
Click Restart to reboot the device.
Upgrade
Click System and Maintenance → Maintenance → Upgrade .
Select an upgrade type from the drop-down list. Click and select the upgrade le from your
local PC. Click Upgrade to start upgrading.
If the device has been connected to Hik-Connect and network, when there is a new
installaon
package in Hik-Connect, you can click Upgrade aer Online Update to upgrade the device system.
Note
Do not power o during the upgrading.
Sub Device Upgrade
Click System and Maintenance → Maintenance → Upgrade .
Set Upgrade
Sengs as RS-485 Card Reader, and select a card reader.
Select an upgrade type from the drop-down list. Click and select the upgrade le from your
local PC. Click Upgrade to start upgrading.
Restore Parameters
Click System and Maintenance → Maintenance → Backup and Reset .
Restore All
All parameters will be restored to the factory sengs. You should acvate the device before
usage.
Restore
The device will restore to the default
sengs, except for the device IP address and the user
informaon.
Import and Export Parameters
Click
System and Maintenance → Maintenance → Backup and Reset .
Export
Click Export to export the device parameters.
Note
You can import the exported device parameters to another device.
DS-K27XX Series Access Controller User Manual
67
background
Import
Click and select the le to import. Click Import to start import conguraon le.
Device Debugging
You can set device debugging parameters.
Steps
1.
Click System and Maintenance → Maintenance → Device Debugging .
2.
You can set the following parameters.
Enable SSH
To raise network security, disable SSH service. The
conguraon is only used to debug the
device for the professionals.
Print Log
You can click Export to export log.
Capture Network Packet
You can set the Capture Packet Duraon, Capture Packet Size, and click Start to capture.
Log Query
You can search and view the device logs.
Go to System and Maintenance → Maintenance → Log .
Set the major and minor type of the log type. Set the start me and end me for searching, and
click Search.
The results will be displayed below, which including the No.,
me, the major type the minor type,
the channel No., the local/remote user
informaon, the remote host IP, etc.
9.7.14
Cercate Management
It helps to manage the server/client cercates and CA cercate.
Note
The funcon is only supported by certain device models.
Create and Import HTTPS Cercate
Steps
1.
Go to Maintenance and Security → Security
Cercate Management .
2.
In the HTTPS Cercate area, click Create Cercate Request.
DS-K27XX Series Access Controller User Manual
68
background
3.
Input cercate informaon and click Save.
Click View and the created cercate will be displayed.
The cercate will be saved automacally.
4.
Download the cercate and save it to an asking le in the local computer.
5.
Send the asking
le to a cercaon authority for signature.
6.
Import the signed
cercate.
1) In the Import Key area, select a cercate from the local, and click Import.
2) In the Import Communicaon Cercate area, select a cercate from the local, and click
Import.
Create and Import SYSLOG Cercate
Steps
1.
Go to Maintenance and Security → Security Cercate Management .
2.
In the SYSLOG
Cercate area, click Create Cercate Request.
3.
Input cercate informaon and click Save.
Click View and the created cercate will be displayed.
The cercate will be saved automacally.
4.
Download the cercate and save it to an asking le in the local computer.
5.
Send the asking
le to a cercaon authority for signature.
6.
Import the signed cercate.
1) In the Import Key area, select a cercate from the local, and click Import.
2) In the Import Communicaon Cercate area, select a cercate from the local, and click
Import.
Import CA
Cercate
Before You Start
Prepare a CA
cercate in advance.
Steps
1.
Go to Maintenance and Security → Security Cercate Management .
2.
Create an ID in the CA Cercate ID area.
Note
The input cercate ID cannot be the same as the exisng ones.
3.
Upload a cercate le from the local.
4.
Click Import.
DS-K27XX Series Access Controller User Manual
69
background
Chapter 10 Other Plaorms to Congure
You can also congure the device via HikCentral Access Control. For details, see the plaorms' user
manual.
HikCentral Access Control (HCAC)
Click/tap the link to view the HCAC's user manual.
hp://enpinfodata.hikvision.com/analysisQR/showQR/f2f6cf42
DS-K27XX Series Access Controller User Manual
70
background
Appendix A. Dimension
Dimension of 1-Door/2-Door/4-Door Access Controller
Dimension of 8-Door Access Controller
DS-K27XX Series Access Controller User Manual
71
background
Dimension of Access Controller Main Board
DS-K27XX Series Access Controller User Manual
72
background
UD35243B

Specifications

Hikvision DS-K2704XP Questions and Answers
