MICROWAVE OVEN
INSTRUCTION MANUAL
Model:
Read these instrucons carefully before using your
microwave oven, and maintain its upkeep. If you
follow the instrucons, your oven will provide you
with many years of good service.
KEEP THESE INSTRUCTIONS IN A SAFE PLACE
FMO22ABTBKC
2
Farberware is a registered trademark of Farberware Licensing Company, LLC
Manufactured and sold pursuant to a license from Farberware Licensing Company, LLC
© 2019 Farberware Licensing Company, LLC. All rights reserved.
3
Tables of Contents
PRECAUTIONS ���������������������������������������������������������������������������������������������������������������������������������� 4
SPECIFICATIONS ����������������������������������������������������������������������������� ������������������������������������������������� 4
SAFETY ��������������������������������������������������������������������������������������������������������������������������������������������� 5
GROUNDING ������������������������������������������������������������������������������������������������������������������������������������ 6
UTENSILS ����������������������������������������������������������������������������������������������������������������������������������������� 8
SETTING UP YOUR OVEN ��������������������������������������������������������������������������������������������������������������� 10
CONTROL PANEL ���������������������������������������������������������������������������������������������������������������������������� 12
OPERATION ������������������������������������������������������������������������������������������������������������������������������������ 13
MAINTENANCE ������������������������������������������������������������������������������������������������������������������������������ 19
WARRANTY INFORMATION ����������������������������������������������������������������������������������������������������������� 20
4
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open door operation can result in
harmful exposure to microwave energy.
It is important not to tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow food or cleaner residue to
accumulate on the sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close properly
and that there is no damage to the:
(1) DOOR (bent)
(2) HINGES AND LATCHES (broken or loosened)
(3) DOOR SEALS AND SEALING SURFACES (Do not use if the door seal or sealing surfaces are
damaged.)
(d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel.
SPECIFICATIONS
Model: FMO22ABTBKC
Rated Voltage: 120V~60Hz
Rated Input Power (Microwave): 1700W
Rated Output Power (Microwave): 1200W
Oven Capacity: 2.2 cubic feet
Turntable Diameter: Ø16.5 inches
External Dimensions: 24.4 x 19.6 x 13.6 inches
Net Weight: 43.4 lbs
WARNING:
This product can expose you to chemicals
including Phthalates or other chemicals which are know to
the State of California to cause cancer birth defects and
other reproductive harm.
For more information, visit www.P65Warnings.ca.gov
n
,
5
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed, including the following:
WARNING - To reduce the risk of burns, electric shock, re, injury to persons or exposure to
excessive microwave energy:
1. Read all instructions before using the appliance.
2. Read and follow the specific: "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY" found on page 4.
3. This appliance must be grounded. Connect only to properly grounded outlet. See "GROUNDING
INSTRUCTIONS" found on page 6.
4. Install or locate this appliance only in accordance with the provided installation instructions.
5. Some products such as whole eggs and sealed containers - for example, closed glass jars - are able to
explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in the manual. Do not use corrosive
chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook or dry
food. It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary when used by children.
8. Do not operate this appliance if it has a damaged cord or plug, if it is not working properly, or if it has
been damaged or dropped.
9. This appliance should be serviced only by qualified service personnel. Contact nearest authorized
service facility for examination, repair, or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this product near water - for example, near a kitchen
sink, in a wet basement, near a swimming pool, or similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that comes together on closing the door, use only mild,
nonabrasive soaps, or detergent applied with a sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible
materials are placed inside the oven to facilitate cooking.
b. Remove wire twist-ties from paper or plastic bag before placing bag in oven.
c. If material inside of the oven ignites, keep oven door closed, turn oven off, and disconnect the
power cord, or shut off power at the fuse or circuit breaker panel.
d. Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils, or
food in the cavity when not in use.
17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or boiling when the container is removed from the
microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN THE CONTAINER
IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID.
6
To reduce the risk of injury to persons:
1. Do not overheat the liquid.
2. Stir the liquid both before and halfway through heating it.
3. Do not use straight-sided containers with narrow necks.
4. After heating, allow the container to stand in the microwave oven for a short time before removing
the container.
5. Use extreme care when inserting a spoon or other utensil into the container.
SAVE THESE INSTRUCTIONS
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord
having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly
installed and grounded.
WARNING – Improper use of the grounding can result in a risk of electric shock. Consult a qualied
electrician or serviceman if the grounding instructions are not completely understood, or if doubt exists
as to whether the appliance is properly grounded. If it is necessary to use an extension cord, use only a
3-wire extension cord that has a 3-blade grounded plug, and 3-slot receptacle that will accept the plug
on the appliance. The marked rating of the extension cord shall be equal to or greater than the electrical
rating of the appliance.
DANGER – Electric Shock Hazard
Touching some of the internal components can cause serious personal injury or death. Do not disassemble
this appliance.
WARNING – Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is
properly installed and grounded.
1. A short power-supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised in
their use.
3. If a long cord or extension cord is used:
a. The marked electrical rating of the cord set or extension cord should be at least as great
as the electrical rating of the appliance.
b. The extension cord must be a grounding-type 3-wire cord.
c. The longer cord should be arranged so that it will not drape over the counter top or
tabletop where it can be pulled on by children or tripped over unintentionally.
7
RADIO INTERFERENCE
1. Operation of the microwave oven may cause interference to your radio, TV or similar equipment.
2. When there is interference, it may be reduced or eliminated by taking the following measures:
3. Clean door and sealing surface of the oven.
a. Reorient the receiving antenna of radio or television.
b. Relocate the microwave oven with respect to the receiver.
c. Move the microwave oven away from the receiver.
d. Plug the microwave oven into a different outlet so that microwave oven and receiver are
on different branch circuits.
SAFETY
1. The oven must be on a leveled surface.
2. The turntable and turntable roller rest must be in the oven during cooking. Place the cookware
gently on the turntable and handle it carefully to avoid possible breakage.
3. Incorrect use of browning dish may cause the turntable to break.
4. Use only the specified bag size when using Direct Access Popcorn.
5. The oven has several built-in safety switches to ensure that the power remains off when the door is
open. Do not tamper with these switches.
6. Do not operate the microwave oven empty. Operating the oven with no food or food that is
extremely low in moisture can cause fire, charring or sparking.
7. Do not cook bacon directly on the turntable. Excessive local heating of the turntable may cause
the turntable to break.
8. Do not heat baby bottles or baby food in the microwave oven. Uneven heating may occur and
could cause physical injury.
9. Do not heat narrow-necked containers, such as syrup bottles.
10. Do not attempt to deep-fry in your microwave oven.
11. Do not attempt home canning in this microwave oven, as it is impossible to be sure all contents of
the jar have reached boiling temperature.
12. Do not use this microwave oven for commercial purpose. This microwave oven is made for
household use only.
13. To prevent delayed eruptive boiling of hot liquids and beverages or scalding yourself, stir liquid
before placing the container in the oven and again halfway through cooking time. Let stand in the
oven for a short time and stir again before removing the container.
14. Use care when cooking food in the microwave oven to avoid burning due to excessive cooking.
15. When the appliance is operated in the combination mode, children should only use the oven
under adult supervision due to the temperatures generated.
16. Failure to maintain the oven in a clean condition could lead to deterioration that could adversely
affect the life of the appliance and possibly result in a hazardous situation.
8
UTENSILS
! CAUTION – Personal Injury Hazard
Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches
should be pierced before cooking.
See the instructions on "Materials you can use in microwave oven or to be avoided in
microwave oven."
There may be certain non-metallic utensils that are not safe to use for microwaving. If in
doubt, you can test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in
question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed utensils Metal shields the food from microwave energy. Metal
trim may cause arcing.
Metal twist ties May cause arcing and could cause a in the oven.
Paper bags May cause fire in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood Wood will dry out when used in the microwave oven and may
split or crack.
MATERIALS TO AVOID IN MICROWAVE OVEN
9
Utensils Remarks
Browning dish Follow manufacturer* instructions. The bottom of browning dish must be at
least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the
turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use
cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer* instructions. Do not close with metal tie. Make slits
to allow steam to escape.
Paper plates and cups Use for short term cooking/warming only. Do not leave oven unattended
while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for
a short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Microwave-safe only. Follow the manufacturer* instructions. Should be
labeled "Microwave Safe ". Some plastic containers soften, as the food
inside gets hot. "Boiling bags " and tightly closed plastic bags should be slit,
pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture.
Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
MATERIALS YOU CAN USE IN MICROWAVE OVEN
10
SETTING UP OUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following
accessories.
Glass tray (turntable)
Turntable ring assembly
Instruction manual
Turntable Installation
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
A
G
Hub (underside)
E D C B
F
a. Never place the glass tray upside down. The glass tray
should never be restricted.
b. Both glass tray and turntable ring assembly must always be
used during cooking.
c. All food and containers of food are always placed on the
glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or breaks,
contact your nearest authorized service center.
Glass tray
Turntable shaft
Turntable ring assembly
11
Countertop Installation
Remove all packing material and accessories. Examine the oven for any damage such as dents or broken
door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.
1. Select a level surface that provides enough open space for the intake and/or outlet vents. A minimum
clearance of 3.0 inches (7.5cm) is required between the oven and any adjacent walls. One side must
be open.
a. Leave a minimum clearance of 12 inches (30cm) above the oven.
b. Do not remove the legs from the bottom of the oven.
c. Blocking the intake and/or outlet openings can damage the oven.
d. Place the oven as far away from radios and TV as possible. Operation of microwave oven may
cause interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as
the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If installed
near or over a heat source, the oven could be damaged and the warranty would be void.
3.0 inch(7.5cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
12
CONTROL PANEL
2. Auto Menu (
3.
4. Time Defrost
6. Number pads (0-9).
10. Power Level (10 Power Levels Availabale)
8. START/+30SEC (Begin cooking time or add
time to cooking.)
9. Memory
7. Clock
12.
Kitchen Timer
11. Express Cook (Number Pad 1-6)
5. Cook Time
13. STOP/CANCEL (Before cooking starts
press to clear all previous settings. During
cooking, press once to stop oven and press twice
to stop oven and clear all settings.)
1. Smart Sensor Cook (Dinner Plate ,
Frozen Vegetable)
Fresh Vegetable,
(1)
(5)
(3)
(4)
(6)
(7)
(8)
(13)
(9)
(12)
(10)
(11)
Weight Defrost
(2)
Popcorn izza Reheat
,
Frozen E ntree
Beverag e, S oup)
,Potato,P
,
13
OPERATION
1. CLOCK SETTING
When the microwave oven is plugged into an outlet, "00:00" will display.
(1) Press "Clock", "00:00" will appear in teh display. The first figure will flash ":" and another "0"
will be lit.
(2) Press the number pads and enter the current time. For example, time is 10:12 now, please
press "1, 0, 1, 2" in turn.
(3) Press "Clock" to finish clock setting. ":" will flash and the clock will be illuminated.
(4) If the numbers input are not within the range of 1:00-12:59, the setting will be invalid until
valid numbers are input.
NOTE:
A. In the process of clock setting, if the "STOP/Cancel" button is pressed or if there is no
operation within 1 minute, the oven will go back to the former setting automatically.
B. If the clock needs to be reset, please repeat step 1 to step 3.
2. KITCHEN TIMER
(1) Press "Kitchen Timer" once, the screen will display "00:00" and "Timer".
(2) Press the number pads and enter the timer time. The maximum cooking time is 99 minutes and
99 seconds.
(3) Press "START/+30SEC" to confirm setting. The timer indicator will flash and the timer will
count down.
(4) When the timer finishes, the oven will beep 3 times and "End" will appear on the display. The
time of day will display by opening the door or pressing "STOP/CANCEL".
A. The kitchen timer is different and won't interfere with the 12-hour system on your
microwave.
B. Kitchen timer and cooking (including microwave, defrosting, Auto menu) are independent,
cooking cannot be set while running the Kitchen Timer.
Kitchen timer amount cannot be increased by pressing "START/+30SEC".
Pressing STOP/CANCEL will cancel the kitchen timer countdown.
NOTE:
C.
D.
14
3. MICROWAVE COOK
(1) Press "Cook Time" once, the screen will display "00:00" and "Cook".
(2) Press number pads to input the cooking time; the maximum cooking time is 99 minutes and 99
seconds.
(3) Press "Power Level" once, the screen will display "PL10". The default power is 100% power.
Press "Power Level" several times or number pads 0-9 to adjust the power level. See the
POWER LEVEL table below.
(4) Press "START/+30SEC" to start cooking.
Example: to cook the food with 50% microwave power for 15 minutes.
A. Press "Cook Time" once, the screen displays "00:00".
B. Press "1", "5", "0", "0" in order.
C. Press "Power Level" once, then press "5" to select 50% microwave power.
D. Press "START/+30SEC" to start cooking.
A. In the process of setting, if the "STOP/Cancel" button is pressed or if there is no operation
within minute, the oven will go back to the former setting automatically.1
B. You can skip the step of "c" and cook at 100% microwave power.
4. POWER LEVEL
10 Power levels are available
Level
10 9 8 7 6 5 4 3 2 1
Power
100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
Display
PL10 PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1
NOTE:
(1) In waiting state, instant cooking at 100% power level with 30 seconds' cooking time can
be started by pressing " " E ach pres s on the s ame button
cooking time by 30 s econds. The maximum cooking time is 99 minutes
(2) In waiting state, press numerical buttons to set the cooking time, then press
" " to start cooking at 100% power level.
" " button.
Note: during microwave cooking and time defrost , time
will increase
S TAR T 0 S ec.
and 99 s econds.
S TAR T/ 30 S ec
can be added by press ing
S TAR T/ 0 S ec
.
.
/+3
+
+3
5. Speedy Cooking
15
(1) In waiting state, press "Dinner Plate", "Fresh Vegetable" or "Frozen Vegetable",
the screen will display "SC".
(2) Press " " to start cooking.
S TART/ 0 S ec
sensor " "S C will flas h in the
dis play.
(3) The sens or will s ound once when the s teaming is emanated.The s urplus time will
di sp
l
ay
.
Menu
.
+3
u
to
(1) Press " " once,
(2)Press numerical buttons to input weight to be defrosted. Input the weight ranged between
0.3~6.3lbs.
If the weight input is not within 0.3~6.3lbs, the input will be invalid.
(3) Press " " to s tart defros ting and the cooking time remained
displayed.
"lbs "
light.
Weight Defrost
screen will dis play "0.0", and
will be
S TAR T/ S ec
.
+
6. Weight Defrost Function
7. Time Defrost Function
8.A
9.Sensor Cook
(1) Press " " once, screen will display "00:00".
(2) Press number pads to input defrosting time.
(3) Press "
" to s tart defros ting. The remained cooking time
displayed.
Time Defrost
S TAR T/+30 S ec
will be
.
(1) In waiting state, press " Popcorn" , " Pizza R eheat" , " Frozen E ntree" ,
" Beverag e" ,
" S oup" ,
or " Potato" to choose the
auto menu.
(2) Press the same pad repeatedly to choose the weight of the food.
(3) Press " " to start cooking.
S TAR T/ 0 S ec
.
+3
30
16
FRESH
VEGETABLE
4-16 OZ
SC
PIZZA
1（sl ice） 1
2
2
REHEAT
3 3
BAKED
POTATO
1( 8.00 OZ)
1
2 2
3 3
4 4
DINNER
PLATE
8- 16 OZ
SC
BEVERAGE
1
OZ)
1
2
SOUP
1 1
2
2
3
3
4 4
FROZEN
VEGETABLE
4-16 OZ
SC
Frozen
Entree
10.00 O
10.0 O
20.00 O
20.0
O
POPCORN
1.75 OZ
1.75 OZ
3．00 OZ
3．
0 OZ
3．30 OZ
3．3 OZ
Weight Menu Display
cup
(about8.8
cups
2
Menu Chart
Z
ZZ
Z
17
10. MEMORY FUNCTION
(1) Press "Memory" to choose up to 3 cooking programs. 1, 2, or 3 will display.
(2) If the program has been set, press "START/+30SEC" to use it. If not, continue to set the
program. A maximum of two microwave stages can be set for each procedure.
(3) After finishing the setting, press "Memory" to save the procedure and turn back to the standby
modes. Press "START/+30SEC" to save and operate the setting.
EXAMPLE: To set the following program as the second memory, that is memory 2, and cook the
food with 80% microwave power for 3 minutes and 20 seconds. Follow these steps:
A. In standby mode, press "Memory" twice, "2" displays.
B. Press "Cook Time", then input number pads "3", "2", "0" to choose the cooking time.
C. Press "Power Level" once, then press number button "8", "PL8" displays.
D. Press "Memory" to save the current setting. The oven beeps once then turns back to
standby mode. If "START/+30SEC" is pressed, the cooking program can be saved as
memory 2 and operated.
E. If the electricity is not cut off, the program will be saved permanently. If it is, the
program will need to be reset.
F. To run the saved program, in standby mode, press "Memory" twice, "2" displays and press
"START/+30SEC" to run the saved cooking program.
NOTE: Auto cook and defrosting cannot be set in memory function.
At most, 2 stages can be set for cooking. In multi-stage cooking, if one stage is defrosting, then
defrosting shall be placed at the first stage automatically.
NOTE: Auto menu cannot be used in multi-stage cooking.
Example: if you want to cook with 80% microwave power for 5 minutes + 60% microwave power
for 10 minutes. The cooking steps are as follows:
(1) Press "Cook Time" once, then press "5", "0", "0" to set 5 minutes.
(2) Press "Power Level" once, then press
(3)
number button "8" to set 80% microwave power.
(4)
Press "Cook Time" once, then press "1", "0", "0", "0" to set 10 minutes.
(5)
Press "Power Level" once,
then press number button "6" to set 60% microwave power.
Press "START/+30SEC" to start cooking.
(1) In the microwave cooking mode, press "Clock" and the current time of day will be displayed
for three seconds then return to the previous mode.
(2) In the microwave cooking mode, press "Power Level" and the current microwave power will be
displayed for 3 seconds then return to the previous mode.
11. MULTI-STAGE COOKING
12. INQUIRING FUNCTION
18
To lock the microwave so that it cannot be operated by children or other inintended users:
(1) In standby mode, press "STOP/Cancel" for 3 seconds. There will be a long "beep" denoting the
child-lock mode and the screen will display " "
(2) To unlock press "STOP/Cancel" for 3 seconds, there will be a long "beep" and " " will
disappear in the display.
16. CHILD LOCK FUNCTION
18. OTHER SPECIFICATIONS
13. English/French Mode
Door
Text English mode French mode
End
door
End Fin
Prte
14. Silence Mode
The default mode is OFF Mode , and the buzzer will ring under special
circumstances. In waiting state, open the door and then press"2" for 3
seconds to enter to Silence Mode. The buzzer will ring under no circumstance.
(1)
( ) When the cooking is finish, the screen will display "End"
The maximum cooking time is 99 minutes and 99 seconds.
2 or "Fin" .Opening the door or
pres s ing
When the cooking is over, the buzzer will sound 5 " beep" to alert user the cooking is
finis hed
17. COOKING END REMINDING FUNCTION
15 . DOOR LOCK FUNCTION
Note:The “kitchen Timer” function is not affected by door lock function.
START/
If the oven in no working state over 5 minutes, it will activate the door lock function.
You cannot press" " to start cooking unless you open door and
then close door.
+30Sec
"STOP/Cancel"
can make the oven enter waiting state.
The default language mode is E nglish Mode. In waiting state,
switch language mode.There are 2 k ds of language mode
open the door and then
press "1" for 3 seconds to
you can choose.
in
19
MAINTENANCE
Troubleshooting
Check your problem by using the chart below and try the solutions for each problem. If the microwave
oven still does not work properly, call the customer service number 877-648-5973.
Trouble Possible Cause Possible Remedy
Oven will not start
a. Electrical cord for oven is not plugged in.
b. Door is open.
c. Wrong operation is set.
a. Plug into the outlet.
b. Close the door and try again.
c. Check instructions.
Arcing or sparking
a. Materials to be avoided in microwave
oven were used.
b. The oven is operated when empty.
c. Spilled food remains in the cavity.
a. Use microwave-safe cookware only.
b. Do not operate with oven empty.
c. Clean cavity with wet towel.
Unevenly cooked
foods
a. Materials to be avoided in microwave
oven were used.
b. Food is not defrosted completely.
c. Cooking time, power level is not suitable.
d. Food is not turned or stirred.
a. Use microwave-safe cookware only.
b. Completely defrost food.
c. Use correct cooking time, power level.
d. Turn or stir food.
Overcooked foods Cooking time, power level is not suitable. Use correct cooking time, power level.
Undercooked foods
a. Materials to be avoided in microwave
oven were used.
b. Food is not defrosted completely.
c. Oven ventilation ports are restricted.
d. Cooking time, power level is not suitable.
a. Use microwave-safe cookware only.
b. Completely defrost food.
c. Check to see that oven ventilation ports
are not restricted.
d. Use correct cooking time, power level.
Improper Defrosting
a. Materials to be avoided in microwave
oven were used.
b. Cooking time, power level is not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe cookware only.
b. Use correct cooking time, power level.
c. Turn or stir food.
Sensor cooked foods
not properly cooked
a. Cover or lid on food not vented.
b. Door opened before sensor-detected
cooking time appears in display.
a. Cover or lid over food must contain vent
b. Do not open door to stir or turn food
hole for escaping steam.
before sensor-detected cooking time
appears in display.
20
ONE YEAR LIMITED WARRANTY
This warranty applies to products purchased and used in the U.S. and Canada.
This is the only expressed warranty for this product and is in lieu of any other warranty or
condition.
This product is warranted to be free from defects in material and workmanship for a
period of one (1) year from the date of original purchase. This warranty is valid for the
original retail purchaser or gift recipient from the date of initial retail purchase and is not
transferable.
Keep your original sales receipt as proof of purchase is required to make a warranty
claim.
IMPORTANT: This warranty does not cover damages resulting from use not in conformity
with the printed directions, accident, misuse or abuse, alternation, the affixing of any
attachments not provided with the product, loss of parts, or subjecting the appliance
to any but the specified voltage. (Read directions carefully.) This warranty is void if the
product is used for other than single-family household use or subjected to any voltage and
waveform other than as specified on the rating label (e.g., 120V ~ 60 Hz).
Englewood Marketing LLC excludes all claims for special, incidental, and consequential
damages caused by breach of express or implied warranty. All liability is limited to the
amount of the purchase price. Every implied warranty, including any statutory warranty
or condition of merchantability or fitness for a particular purpose, is disclaimed except to
the extent prohibited by law, in which case such warranty or condition is limited to the
duration of this written warranty. This warranty gives you specific legal rights. You may
have other legal rights that vary depending on where you live. Some states or provinces
do not allow limitations on implied warranties or special, incidental, or consequential
damages, so the foregoing limitations may not apply to you.
To make a warranty claim or if service is required, please call our CUSTOMER SERVICE
NUMBER.
For faster service, please have the model, type, and series numbers ready for the operator
to assist you.
Customer Service Number
Englewood Marketing LLC
In the US 877-648-5973
Email: [email protected]
