MULTI-PURPOSE STORAGE KIT
MODEL NO’S: APHKIT1 4PC, APHKIT2 10PC, APH01
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Carefully choose location to minimise the risk of injury.
8 DO NOT overload.
9 Beawareofexistingplumbingandelectricalcablesbeforexingtothewall.
2. INTRODUCTION
APHKIT1: 4-piece multipurpose steel hook storage kit. Contains wall mountable hook rail with predrilled mounting holes and 3 x multipurpose
hooks. Ideal for use in a garage, shed or around the home as a space saving tool. Powder coated to prevent oxidisation. PVC Wrapped to avoid
damage to tools and equipment. Easy to install and easy to relocate. 1 x dual utility hook, 1 x double prong hook and 1 x large J hook. Each
hook holds up to 20kg. Overall maximum load 110kg. Overall width of hook rail is 610mm. Fixings not included.
APHKIT2: 10-piece ultimate multipurpose steel hook storage kit. Contains 3 x wall mountable hook rails and 7 x multipurpose hooks. Ideal for
use in a garage, shed or around the home as a space saving tool. Powder coated to prevent oxidisation. PVC Wrapped to avoid damage to tools
and equipment. Easy to install and easy to relocate. 1 x Double S hook, 2 x single hooks, 2 x double prong hooks and 2 x large J hooks. Each
hook holds up to 20kg. Overall maximum load on single hook rail 110kg. Overall width of single hook rail is 610mm. Fixings not included.
APH01: Wall mountable steel hook storage base rail. For use in conjunction with multipurpose hooks, ideal for use in a garage, shed or around
the home as a space saving tool. With predrilled mounting holes for easy installation and relocation. Fixings not included. Overall maximum load
of single base rail 110kg. Dimensions (W x D x H) 610 x 18 x 100mm.
3. SPECIFICATION
APHKIT1 dimensions (W x D x H):
Hook rail ....................................................610 x 18 x 100mm
Dual utility hook ........................................ 80 x 265 x 115mm
Double prong hook ......................................75 x 220 x 90mm
Large J hook .............................................77 x 182 x 230mm
Fixing hole diameter .................................................... 4.7mm
4. INSTALLATION
4.1. Mark out a horizontal line using a spirit level at the desired height, on the wall.
4.2. Makesuretherailisthecorrectwayup,refertog.1.
4.3. Place the bottom of the rail along the marked line.
4.4. Mark the positions of the holes to be drilled. Drill the holes after making a risk assessment
of the drilling operation and positioning of the rail.
4.5. Fasten the rail into position.
NOTE: When fastening into any surface ensure that appropriate fasteners are used.
4.6. Repeat process for other rail (if applicable.)
4.7. Fit hooks as applicable by hanging over the top edge and pull hook down to locate into
bottom edge.
NOTE: Ensure the white pads are located in the bottom of each hook before they are
tted.
4.8. Remove hooks by lifting upwards.
5. MAINTENANCE
5.1. Use a damp, soapy cloth to clean. DO NOT use solvents.
Refer to
instruction
manual
Wear eye
protection
(during
assembly)
APHKIT Issue:1 12/01/21
Original Language Version
© Jack Sealey Limited
APHKIT2 dimensions (W x D x H):
Hook rails (x3) ...........................................610 x 18 x 100mm
Double S hook ..........................................220 x 40 x 195mm
Double prong hook (x2)...............................75 x 220 x 90mm
Large J hook (x2) ...................................... 77 x 182 x 230mm
Single hook (x2) .............................................40 x 140 x 90m
Fixing hole diameter .................................................... 4.7mm
g.1
.
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
APHKIT Issue:1 12/01/21
