FOLDING AXLE STANDS (PAIR) 2TONNE CAPACITY
PER STAND
MODEL NO: AS2000F.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
AS2000F.V2 Issue 7 (1,4) 19/01/22
Original Language Version
© Jack Sealey Limited
Refer to
Instructions
1. SAFETY
WARNING!
DO NOT OVERLOAD AXLE STANDS BEYOND RATED CAPACITY. OVERLOADING CAN CAUSE DAMAGE TO, OR FAILURE OF,
THE AXLE STANDS. POSITION LOAD ON CENTRE OF CRUTCH/SADDLE ONLY. ALWAYS USE STANDS IN PAIRS ON HARD
LEVEL SURFACE CAPABLE OF SUSTAINING THE LOAD. USE OF STANDS ON OTHER THAN HARD LEVEL SURFACES CAN
RESULT IN LOAD INSTABILITY AND POSSIBLE LOSS OF LOAD. DO NOT USE ON TARMACADAM. FAILURE TO FOLLOW
THESE INSTRUCTIONS MAY RESULT IN DAMAGE TO AXLE STANDS, LOSS OF LOAD RESULTING IN PROPERTY DAMAGE,
SERIOUS PERSONAL INJURY OR LOSS OF LIFE.
▲ DANGER! GREAT CARE MUST BE TAKEN TO ENSURE YOU LOWER THE VEHICLE (OR OTHER LOAD)
SLOWLY AND CAREFULLY ONTO THE CENTRES OF THE CRUTCH/SADDLE OF THE AXLE STANDS.
9 Use only as specified by the manufacturer.
9 Ensure the load does not exceed the maximum capacity as marked on the axle stand, per pair.
9 Use no more than a single pair of stands either on the front, rear or one side of the vehicle. Use in pairs.
9 No alterations or modifications shall be made to this product.
9 Use on a hard, level surface, e.g. concrete. DO NOT use on uneven ground or tarmacadam.
9 Securely chock wheels in contact with the ground. Before jacking and placing the stands, apply vehicle
handbrake (put automatics in ‘Park’).
9 Make sure that each stand is securely located under a strong point on the vehicle; consult the vehicle manufacturer’s handbook for
guidance. Ensure that height adjust locking mechanism is fully located before applying any load to the axle stand.
9 Ensure that the load is located centrally on the saddle, and that the weight is directed through the vertical axis of the stand.
9 Exercise extra care when using with a three wheeled vehicle or a trailer. Refer to vehicle manufacturer’s instructions.
9 Once vehicle is supported, ensure that the vehicle and stands are stable before starting work. Ensure that it is not possible for the
vehicle to move before commencing any work.
9 Inspect stands before each use. DO NOT use if they show signs of damage. DO NOT use if it is suspected that they have been
overloaded.
9 Before commencing any work or going beneath the vehicle, undertake a risk assessment. Ensure that a responsible person is aware of
the work about to be undertaken.
9 Replace any labels on the axle stand should they become unreadable. This applies in particular to any warning or operation instruction
labels. If replacement labels are required, contact your Sealey stockist.
8 DO NOT use axle stands on the highway, or anywhere else if it is deemed to be unsafe.
8 DO NOT push or twist the vehicle/load whilst it is supported on stands.
8 DO NOT mix components between stands. Use only as supplied.
8 DO NOT allow children or animals in the vicinity of a vehicle supported on axle stands.
8 DO NOT leave a vehicle on axle stands in an area that could be considered a hazard to others or property.
9 FOLLOW STEPS 1, 2, AND 3 TO CORRECTLY PLACE VEHICLE / LOAD ONTO AXLE STANDS.
Fit pin through
both the stand
collar and the
centre tube
2. INTRODUCTION
Folding design saves space and makes these axle stands ideal for occasional use. Welded steel construction for increased strength and
safety. Folding design for space efcient storage. Fitted with double-locking safety pin. Sold in pairs.
3. SPECIFICATION
Model No: ..........................................................AS2000F.V2
Capacity Each: ..........................................2tonne (2,000 kg)
Capacity Pair: ............................................4tonne (4,000 kg)
Minimum Working Height: .......................................... 278mm
Maximum Working Height ..........................................366mm
4. OPERATION
4.1. Familiarise yourself with the product. Check that the stands are in good order and condition and that no damaged has been
sustained during transit. Familiarise yourself with the folding mechanism (g. 1.1) and the extending legs (g.1.2). Insert the centre
column (g.1.3) in the stand collar (g.1.4), adjust to height required and insert the locking pin (g.1.5). Ensure the maximum load
does not exceed 4 tonnes per pair of axle stands, (2 tonnes for each stand).
4.2. Refer to vehicle owners hand book for correct jacking procedure. Check to ensure that manufacturers recommended jacking points
are in good condition.
4.3. Ensure the vehicle brake is on (or in parked mode) and wheels are chocked.
4.4. Ensure the stand legs are fully extended and adjust height of stand to correspond with the raised vehicle.
4.5. Check that the locking pin is correctly pushed all the way through the stand collar, centre column and out of the other side, insert
safety pin, then position stands under vehicle at points specied by vehicle manufacturer.
4.6. Carefully and slowly lower the load onto stands. Ensure the load bearing points sit in the center of the stand saddle and check that
the stands are stable and not leaning. Also ensure that there are no objects or persons that could impede the safe lowering of the
vehicle onto the stands.
4.7. After use, hold the centre column (g.1.3) rmly when removing the locking pin (g.1.5). Failure to do so will allow the center column
to fall freely through the main center tube which could be dangerous.
WARNING! Ensure you follow all instructions carefully. Failure to note these warnings may cause damage, serious injury or loss of
life.
5. MAINTENANCE
5.1. Before each use check to ensure stands and stand welds are not cracked, and that there are no missing and/or damaged parts.
WARNING! Any stand that appears to be damaged in any way must be removed from service immediately.
5.2. Ensure the locking pin, folding arms and mechanism are in good order and condition.
5.3. Due to the potential hazards associated with these stands, do not misuse, or make any modication to the stands or components.
5.4. It is the responsibility of the stands owner to ensure the operator has read these instructions, and that the operator is familiar with
the stands use and limitations.
Original Language Version
© Jack Sealey Limited
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
g.1
