3 YEAR LIMITED WARRANTY
Sunbeam Products, Inc. or if in Canada, Sunbeam Corporation (Canada) Limited (collectively “Sunbeam”) warrants that
for a period of three years from the date of purchase, this product will be free from defects in material and workmanship.
Sunbeam, at its option, will repair or replace this product or any component of the product found to be defective during
the warranty period. Replacement will be made with a new or remanufactured product or component. If the product is
no longer available, replacement may be made with a similar product of equal or greater value. This is your exclusive
warranty. Do NOT attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void
this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. Sunbeam dealers, service
centers, or retail stores selling Sunbeam products do not have the right to alter, modify or any way change the terms
and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or
misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly, repair
or alteration by anyone other than Sunbeam or an authorized Sunbeam service center. Further, the warranty does not
cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on Sunbeam’s Liability?
Sunbeam shall not be liable for any incidental or consequential damages caused by the breach of any express, implied
or statutory warranty or condition. Except to the extent prohibited by applicable law, any implied warranty or condition
of merchantability or fitness for a particular purpose is limited in duration to the duration of the above warranty.
Sunbeam disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise. Sunbeam
shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use the
product including incidental, special, consequential or similar damages or loss of profits, or for any breach of contract,
fundamental or otherwise, or for any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or
limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
If you have any questions regarding this warranty or would like to obtain warranty service, please call
1-800-546-5637 and a convenient service center address will be provided to you.
In Canada
If you have any questions regarding this warranty or would like to obtain warranty service, please call
1-800-546-5637 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. located in Boca Raton, Florida 33431. In Canada,
this warranty is offered by Sunbeam Corporation (Canada) Limited doing business as Jarden Consumer Solutions,
located at 20 B Hereford Street, Brampton, Ontario L6Y 0M1. If you have any other problem or claim in connection
with this product, please write our Consumer Service Department. PLEASE DO NOT RETURN THIS PRODUCT TO
ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
AER1 FILTER SERIES
®
WARRANTY INFORMATION
TROUBLESHOOTING
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Owner’s Guide
HAP9243, HAP9415, HAP9423
195965 HAP9243_HAP9415_HAP9423-UA_18EM1 Printed In China
CSH-LD0318-HOL186832
Aer1
®
Allergen Remover Filter(s)
Air Purifier with Optional Ionizer
© 2018 Sunbeam Products, Inc. All Rights Reserved.
Distributed by Sunbeam Products, Inc., Boca Raton, Florida 33431.
LEARNING MORE
For a wealth of information about your air purifier and other Holmes
®
products, visit our website at
www.holmesproducts.com or call 1-800-546-5637. For inquiries regarding recycling and proper disposal of this
product, please contact your local waste management facility.
Congratulations! Your new air purifier is equipped with the Aer1
®
Allergen Remover
Filter.
Filter Type Technology Consumer Benefit
Total Air
99% HEPA-Type technology.
Infused with baking soda.
Ideal for dust reduction.
Delivers 30% better air quality.
Odor Eliminator
10 times the odor fighting power.
Contains baking soda, carbon and
zeolite for odor control.
Ideal for eliminating odors from
pets, tobacco smoke and cooking
fumes.
Allergen Remover
99.97% True HEPA technology.
Removes up to 99.97% of particles
as small as 0.3 microns passing
through the filter such as pollen,
dust, mold and dander.
Ideal for allergy sufferers.
Allergen Performance Plus
99.99% True HEPA technology.
Helps remove up to 99.99% of par-
ticles as small as 0.3 microns passing
through the filter such as pollen, dust,
mold and dander.
Ideal for allergy sufferers.
Smoke Grabber
HEPA-type filtration.
Triple layer protection specially
formulated with Baking Soda,
Carbon and Zeolite.
Removes up to 99% of smoke and
pollutants as small as 0.3 microns
from air passing through the filters.
Ideal for reducing smoke and odors
from smoke and VOC's.
TROUBLESHOOTING
Problem Solution
• Unit will not operate.
4 Check if unit is properly plugged in and outlet is energized.
4 Make sure unit is turned ON.
4 Make sure filters are properly installed and front grill is seated correctly.
• Decreased air flow.
4 Make sure nothing is blocking air inlet and filtered air outlets.
4 Check condition of the filters and replace if necessary.
4 Check filters to remove any plastic wrapping/packaging.
• Excessive Noise.
4 Make sure parts are firmly positioned in place.
4 Open the air inlet grill, and make sure that any plastic packaging was
removed from the filters, if applicable.
THIS UNIT
COMES
WITH
HAP9243_HAP9415_HAP9423-UA_18EM1.indd 1 5/4/18 11:28 AM
IMPORTANT SAFEGUARDS
FEATURES
VISIPURE
®
VIEWING WINDOW
Your Holmes
®
Air Purifier includes Aer1
®
Allergen
Remover Filter(s), specially designed to deliver cleaner
air! The Aer1
®
Allergen Remover filter(s) last 12 months.
See back panel for other filter options.
The Visipure
®
Filter Viewing Window is a lens which
allows you to get a clear view of the dirt being collected
in the filter and see if the filter needs replacement. The
Filter Reminder Dial helps you keep track of when to
change the filter.
BEFORE USE
1. Carefully unpack your Air Purifier. Select a firm level
place where there are no obstructions to the air inlet
or filtered air outlet.
2. Remove the air inlet grill and check if the filter is
covered by a plastic bag. If it is, remove plastic bag
before use and place filters into unit. Reinstall the air
inlet grill.
3. This unit is equipped with a filter that lasts 12
months. Please set the Filter Change Reminder to 12
months from date of purchase. If you have a 4
month filter, set the wheel from 4 months from date
of purchase. This will serve as a reference for when
filter replacement is needed.
NOTE: DO NOT POINT FILTERED AIR OUTLET TOWARDS WALL.
OPERATING INSTRUCTIONS
1. Plug into a 120V AC electrical outlet.
2. Select the desired operating speed; HI (3), MEDIUM
(2), LOW (1), by turning Speed Control Switch to the
appropriate setting. For optimum air filtration, it is
recommended to operate the air purifier continuously.
Its rugged motor has been designed to give many
years of use.
3. To release negative ions into the filtered air, press the
ionizer button ( ) to ON and the button will
illuminate in blue.
NOTE: The ionizer will not work unless the unit is
running.
CLEANING/MAINTENANCE INSTRUCTIONS
1. Turn the air purifier off and unplug it before
cleaning.
2. The outside of the air purifier can be cleaned with a
soft, clean damp cloth.
3. The air inlet grill (reference Fig. 1) can be removed
and washed in warm soapy water (not dishwasher
safe). Dry before replacing in the unit.
4. The filtered air outlet can be cleaned of dust with a
small, soft brush.
5. If you wish to clean the inside filter chamber of the air
purifier, please only use a dry, soft cloth to wipe it down.
POWER CORD INSTRUCTIONS
• The length of cord used on this appliance was
selected to reduce tangling or tripping hazards.
• If a longer cord is necessary, an approved extension
cord may be used. The electrical rating of the
extension cord must be equal to or greater than the
electrical rating of the air purifier (see rating label
marked on bottom of the product).
• Care must be taken to arrange the extension cord so
that it will not drape over the countertop or tabletop
where it can be pulled on by children or accidentally
tripped over.
GET TO KNOW YOUR AIR PURIFIER
This unit is compatible with all Aer1
®
Filters. This allows
you to choose the filter that is just right for you. Below is
information on each filter:
TOTAL AIR - Advanced Dust Eliminating Technology
ODOR ELIMINATOR - 10x the odor fighting power
ALLERGEN REMOVER - 99.97% True HEPA technology
improves air quality for allergy sufferers
ALLERGEN PERFORMANCE PLUS - 99.99% True HEPA
technology improves air quality for allergy sufferers.
SMOKE GRABBER - 99% effective at removing smoke
from the air steam (*as small as 0.3 microns from air
passing through the filter)
IONIZER
This appliance has an optional ionizer feature which,
when turned on, releases negative ions into outgoing
filtered air to help the air purification process.
What Are Ions?
Ions are tiny particles that carry a positive or negative
charge. They exist naturally around us: in the air, water,
and ground. Both positive and negative ions are colorless,
odorless, and harmless.
How Does The Ionizer Work?
Negative ions help air purification by attaching
themselves to very small airborne particles in the room.
These particles take on a negative charge and may join
with positively charged particles such as dust, pollen,
smoke, and pet dander to form larger particles. These
larger particles are then more easily captured by the
filter system.
Important Notes:
Your ionizer may produce an occasional popping or
cracking sound. This is normal and occurs when a small
buildup of ions is discharged.
After extended use, you may notice dust around the grills
or front panel. This is caused by negative ions exiting the
air outlet, evidence of the ionizer’s air cleaning
effectiveness. You can remove the dust with a soft brush
or clean, damp cloth.
Larger particles may be attracted to positively charged
surfaces throughout the home, like walls or floors.
• This may occur more frequently when the filter is
nearing the end of its usable product life and is
unable to capture as many charged particles.
• Excessive amounts of pet dander, dust, or smoke may
decrease the life expectancy of the filter and
interfere with the ionization process.
To help prevent particles from attracting to surfaces
throughout your home:
• You may want to run the ionizer less often.
• Check the condition of the filter(s) more frequently.
CAUTION: The ionizer in this appliance produces less
ozone than the UL established limits of 50ppb. However,
in high concentrations, ozone can be harmful to birds and
small pets. To prevent ozone buildup, we suggest using
the ionizer in well ventilated areas with the air purifier
fan on.
HIGH, MEDIUM AND LOW SPEED
SETTINGS
For optimum air filtration, operate your Holmes
®
air
purifier continuously on the MEDIUM (2) setting. Its
rugged motor has been designed to give many years of
use. For quieter operation (such as in a bedroom), select
the LOW (1) setting. When high levels of air pollution are
present, select the HIGH (3) setting to quickly circulate
and filter the air in the room.
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and injury to persons. These precautions include:
1. Read all instructions before using the appliance.
2. To reduce the risk of fire or electric shock, plug the
appliance directly into a 120V AC electrical outlet.
3. If the Filter is covered by a bag when shipped,
remove plastic bag before use.
4. Keep the cord out of heavy traffic areas. To avoid
fire hazard, NEVER put the cord under rugs, near
heat registers, radiators, stoves, or heaters.
5. DO NOT immerse the appliance in water or other
liquids. Do not use near water.
6. Close supervision is necessary when any appliance is
used by or near children, or disabled persons.
7. Always unplug the air purifier before moving or
cleaning the unit, opening the grill, changing the
filter and whenever the unit is not in use. To
disconnect the unit, be sure to pull the plug and not
the cord.
8. NEVER drop or insert any objects into the openings of
the unit.
9. DO NOT operate any appliance with a damaged cord
or plug. If the motor fan fails to operate or the unit
has been dropped or damaged in any manner, return
appliance to manufacturer for examination and/or
repair.
10. Use appliance only for intended household use as
described in this manual. Any other use not
recommended by the manufacturer may cause fire,
electric shock, or injury to persons. The use of
attachments not recommended or sold by Jarden
Consumer Solutions may cause injuries.
11. DO NOT use outdoors.
12. NEVER place on a soft surface such as a bed or sofa
as this could cause the unit to tip over and block the
air inlet or outlet grills.
13.
Keep unit away from heated surfaces and open flames.
14. DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so may cause
injuries and void your warranty. The inside of the unit
contains no user serviceable parts. All servicing should
be performed by Jarden Consumer Solutions or an
authorized Jarden Consumer Solutions Center.
15. DO NOT place anything on top of unit.
16. Always turn the appliance off before unplugging it.
17.
The ionizer in this appliance produces less ozone than
the UL established limits of 50ppb (parts per billion).
However, in high concentrations, ozone can be harmful
to birds and small pets. To prevent ozone buildup, we
suggest using the ionizer in well ventilated areas with
the fan on.
18. This appliance should only be used in a room with
temperatures between 40° F and 110° F.
19. To reduce the risk of fire or electric shock, DO NOT
use this appliance with any solid-state speed control
device.
SAVE SAFETY
INSTRUCTIONS
FEATURES - OPERATIONS
CLEANING/MAINTENANCE
FILTER REPLACEMENT
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in a
polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician to
install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
WARNING: Do not allow moisture to come in
contact with the main housing of the air purifier.
6. NEVER use detergents, gasoline, glass purifier,
furniture polish, paint thinner, or other household
solvents to clean any part of the appliance.
FILTER REPLACEMENT INSTRUCTIONS
IMPORTANT:
• DO NOT attempt to wash and re-use the Aer1
®
Filters.
• If the filters are enclosed in plastic bags, remove
them before use.
NOTE:
Every few weeks, check the condition of filter(s). The
Visipure
TM
Filter Viewing Window is a lens which allows
you to get a clear view of the dirt being collected in the
filter. The Filter Reminder Dial also helps you keep track
of when to change the filters. Filter life will vary,
depending on air quality and usage (see below). Under
normal conditions of continuous use, the Aer1
®
Total Air,
Odor and Smoke Filters will last 4 months while the
Allergen and Allergen Performance Plus Filters will last 12
months.
After approximately 12 months of operation, check the
condition of the filter through the Visipure
®
Filter Viewing
Window and use Filter Reminder Dial to keep track on how
long a filter has been in use.
• Filters with a 4 month filter life: Wash the foam pre-
filter and replace the Aer1
®
filter(s) after 4 months
of operation.
• Filters with a 12 month filter life: After 4 months of
operation, it is recommended to wash the foam
pre-filter and check the condition of your filter(s)
through the Visipure
®
Filter Viewing Window. The
filters must be replaced after 12 months of operation.
To replace your filter(s):
1. Turn off and unplug the air purifier.
2. Open the air inlet grill and examine the black foam
prefilter. Remove any dust or lint and wash in warm
soapy water. Rinse, air dry and place back into grill inlet.
3. Remove the used Aer1
®
filter(s) from the unit by
pulling it gently towards you and discard it. DO NOT
attempt to clean the Aer1
®
filters.
4. Install the new Aer1
®
filter(s) into the unit.
5. Align the clip(s) on the
side of Aer1
®
filter(s)
with rails on the inside of
the purifier unit. Gently
slide the filter(s) onto the
rail. (Fig. 2)
6. Replace air inlet grill.
7. Turn the Filter Reminder Dial to select the current
month you are replacing the new filter(s). This will
serve as reference for when filter replacement is
needed.
Filters can be purchased at a retailer near you, online at www.holmesproducts.com.
Air Purifier
Model Number
Filter Quantity
Needed
Compatible with all
filter models below
Filter
Description
HAP9243/HAP9415 1
HAPF30AT
HAPF30AO
HAPF30AS
HAPF300AH
HAPF300AP (D filter)
aer1
®
Total Air Filter
aer1
®
Odor Filter
aer1
®
Smoke Grabber Filter
aer1
®
Allergen Remover Filter
aer1
®
Allergen Performance Plus
"D" Filter
HAP9423 2
Fig. 2
Fig. 1
A. Control Panel
B. Speed Control
Switch
C. Visipure
®
Filter
Viewing Window
D. Filter Reminder Dial
E. Ionizer Button
F. Filtered Air Outlet
G. Aer1
®
Filter(s)
H. Washable Foam
Pre-Filter
I. Air Inlet Grill
E
B
F
C
D
I
H
G
A
G
H
I
C
D
A
F
F
G
H
I
A
C
D
HAP9243_HAP9415_HAP9423-UA_18EM1.indd 2 5/4/18 11:28 AM
IMPORTANT SAFEGUARDS
FEATURES
VISIPURE
®
VIEWING WINDOW
Your Holmes
®
Air Purifier includes Aer1
®
Allergen
Remover Filter(s), specially designed to deliver cleaner
air! The Aer1
®
Allergen Remover filter(s) last 12 months.
See back panel for other filter options.
The Visipure
®
Filter Viewing Window is a lens which
allows you to get a clear view of the dirt being collected
in the filter and see if the filter needs replacement. The
Filter Reminder Dial helps you keep track of when to
change the filter.
BEFORE USE
1. Carefully unpack your Air Purifier. Select a firm level
place where there are no obstructions to the air inlet
or filtered air outlet.
2. Remove the air inlet grill and check if the filter is
covered by a plastic bag. If it is, remove plastic bag
before use and place filters into unit. Reinstall the air
inlet grill.
3. This unit is equipped with a filter that lasts 12
months. Please set the Filter Change Reminder to 12
months from date of purchase. If you have a 4
month filter, set the wheel from 4 months from date
of purchase. This will serve as a reference for when
filter replacement is needed.
NOTE: DO NOT POINT FILTERED AIR OUTLET TOWARDS WALL.
OPERATING INSTRUCTIONS
1. Plug into a 120V AC electrical outlet.
2. Select the desired operating speed; HI (3), MEDIUM
(2), LOW (1), by turning Speed Control Switch to the
appropriate setting. For optimum air filtration, it is
recommended to operate the air purifier continuously.
Its rugged motor has been designed to give many
years of use.
3. To release negative ions into the filtered air, press the
ionizer button ( ) to ON and the button will
illuminate in blue.
NOTE: The ionizer will not work unless the unit is
running.
CLEANING/MAINTENANCE INSTRUCTIONS
1. Turn the air purifier off and unplug it before
cleaning.
2. The outside of the air purifier can be cleaned with a
soft, clean damp cloth.
3. The air inlet grill (reference Fig. 1) can be removed
and washed in warm soapy water (not dishwasher
safe). Dry before replacing in the unit.
4. The filtered air outlet can be cleaned of dust with a
small, soft brush.
5. If you wish to clean the inside filter chamber of the air
purifier, please only use a dry, soft cloth to wipe it down.
POWER CORD INSTRUCTIONS
• The length of cord used on this appliance was
selected to reduce tangling or tripping hazards.
• If a longer cord is necessary, an approved extension
cord may be used. The electrical rating of the
extension cord must be equal to or greater than the
electrical rating of the air purifier (see rating label
marked on bottom of the product).
• Care must be taken to arrange the extension cord so
that it will not drape over the countertop or tabletop
where it can be pulled on by children or accidentally
tripped over.
GET TO KNOW YOUR AIR PURIFIER
This unit is compatible with all Aer1
®
Filters. This allows
you to choose the filter that is just right for you. Below is
information on each filter:
TOTAL AIR - Advanced Dust Eliminating Technology
ODOR ELIMINATOR - 10x the odor fighting power
ALLERGEN REMOVER - 99.97% True HEPA technology
improves air quality for allergy sufferers
ALLERGEN PERFORMANCE PLUS - 99.99% True HEPA
technology improves air quality for allergy sufferers.
SMOKE GRABBER - 99% effective at removing smoke
from the air steam (*as small as 0.3 microns from air
passing through the filter)
IONIZER
This appliance has an optional ionizer feature which,
when turned on, releases negative ions into outgoing
filtered air to help the air purification process.
What Are Ions?
Ions are tiny particles that carry a positive or negative
charge. They exist naturally around us: in the air, water,
and ground. Both positive and negative ions are colorless,
odorless, and harmless.
How Does The Ionizer Work?
Negative ions help air purification by attaching
themselves to very small airborne particles in the room.
These particles take on a negative charge and may join
with positively charged particles such as dust, pollen,
smoke, and pet dander to form larger particles. These
larger particles are then more easily captured by the
filter system.
Important Notes:
Your ionizer may produce an occasional popping or
cracking sound. This is normal and occurs when a small
buildup of ions is discharged.
After extended use, you may notice dust around the grills
or front panel. This is caused by negative ions exiting the
air outlet, evidence of the ionizer’s air cleaning
effectiveness. You can remove the dust with a soft brush
or clean, damp cloth.
Larger particles may be attracted to positively charged
surfaces throughout the home, like walls or floors.
• This may occur more frequently when the filter is
nearing the end of its usable product life and is
unable to capture as many charged particles.
• Excessive amounts of pet dander, dust, or smoke may
decrease the life expectancy of the filter and
interfere with the ionization process.
To help prevent particles from attracting to surfaces
throughout your home:
• You may want to run the ionizer less often.
• Check the condition of the filter(s) more frequently.
CAUTION: The ionizer in this appliance produces less
ozone than the UL established limits of 50ppb. However,
in high concentrations, ozone can be harmful to birds and
small pets. To prevent ozone buildup, we suggest using
the ionizer in well ventilated areas with the air purifier
fan on.
HIGH, MEDIUM AND LOW SPEED
SETTINGS
For optimum air filtration, operate your Holmes
®
air
purifier continuously on the MEDIUM (2) setting. Its
rugged motor has been designed to give many years of
use. For quieter operation (such as in a bedroom), select
the LOW (1) setting. When high levels of air pollution are
present, select the HIGH (3) setting to quickly circulate
and filter the air in the room.
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and injury to persons. These precautions include:
1. Read all instructions before using the appliance.
2. To reduce the risk of fire or electric shock, plug the
appliance directly into a 120V AC electrical outlet.
3. If the Filter is covered by a bag when shipped,
remove plastic bag before use.
4. Keep the cord out of heavy traffic areas. To avoid
fire hazard, NEVER put the cord under rugs, near
heat registers, radiators, stoves, or heaters.
5. DO NOT immerse the appliance in water or other
liquids. Do not use near water.
6. Close supervision is necessary when any appliance is
used by or near children, or disabled persons.
7. Always unplug the air purifier before moving or
cleaning the unit, opening the grill, changing the
filter and whenever the unit is not in use. To
disconnect the unit, be sure to pull the plug and not
the cord.
8. NEVER drop or insert any objects into the openings of
the unit.
9. DO NOT operate any appliance with a damaged cord
or plug. If the motor fan fails to operate or the unit
has been dropped or damaged in any manner, return
appliance to manufacturer for examination and/or
repair.
10. Use appliance only for intended household use as
described in this manual. Any other use not
recommended by the manufacturer may cause fire,
electric shock, or injury to persons. The use of
attachments not recommended or sold by Jarden
Consumer Solutions may cause injuries.
11. DO NOT use outdoors.
12. NEVER place on a soft surface such as a bed or sofa
as this could cause the unit to tip over and block the
air inlet or outlet grills.
13.
Keep unit away from heated surfaces and open flames.
14. DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so may cause
injuries and void your warranty. The inside of the unit
contains no user serviceable parts. All servicing should
be performed by Jarden Consumer Solutions or an
authorized Jarden Consumer Solutions Center.
15. DO NOT place anything on top of unit.
16. Always turn the appliance off before unplugging it.
17.
The ionizer in this appliance produces less ozone than
the UL established limits of 50ppb (parts per billion).
However, in high concentrations, ozone can be harmful
to birds and small pets. To prevent ozone buildup, we
suggest using the ionizer in well ventilated areas with
the fan on.
18. This appliance should only be used in a room with
temperatures between 40° F and 110° F.
19. To reduce the risk of fire or electric shock, DO NOT
use this appliance with any solid-state speed control
device.
SAVE SAFETY
INSTRUCTIONS
FEATURES - OPERATIONS
CLEANING/MAINTENANCE
FILTER REPLACEMENT
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in a
polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician to
install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
WARNING: Do not allow moisture to come in
contact with the main housing of the air purifier.
6. NEVER use detergents, gasoline, glass purifier,
furniture polish, paint thinner, or other household
solvents to clean any part of the appliance.
FILTER REPLACEMENT INSTRUCTIONS
IMPORTANT:
• DO NOT attempt to wash and re-use the Aer1
®
Filters.
• If the filters are enclosed in plastic bags, remove
them before use.
NOTE:
Every few weeks, check the condition of filter(s). The
Visipure
TM
Filter Viewing Window is a lens which allows
you to get a clear view of the dirt being collected in the
filter. The Filter Reminder Dial also helps you keep track
of when to change the filters. Filter life will vary,
depending on air quality and usage (see below). Under
normal conditions of continuous use, the Aer1
®
Total Air,
Odor and Smoke Filters will last 4 months while the
Allergen and Allergen Performance Plus Filters will last 12
months.
After approximately 12 months of operation, check the
condition of the filter through the Visipure
®
Filter Viewing
Window and use Filter Reminder Dial to keep track on how
long a filter has been in use.
• Filters with a 4 month filter life: Wash the foam pre-
filter and replace the Aer1
®
filter(s) after 4 months
of operation.
• Filters with a 12 month filter life: After 4 months of
operation, it is recommended to wash the foam
pre-filter and check the condition of your filter(s)
through the Visipure
®
Filter Viewing Window. The
filters must be replaced after 12 months of operation.
To replace your filter(s):
1. Turn off and unplug the air purifier.
2. Open the air inlet grill and examine the black foam
prefilter. Remove any dust or lint and wash in warm
soapy water. Rinse, air dry and place back into grill inlet.
3. Remove the used Aer1
®
filter(s) from the unit by
pulling it gently towards you and discard it. DO NOT
attempt to clean the Aer1
®
filters.
4. Install the new Aer1
®
filter(s) into the unit.
5. Align the clip(s) on the
side of Aer1
®
filter(s)
with rails on the inside of
the purifier unit. Gently
slide the filter(s) onto the
rail. (Fig. 2)
6. Replace air inlet grill.
7. Turn the Filter Reminder Dial to select the current
month you are replacing the new filter(s). This will
serve as reference for when filter replacement is
needed.
Filters can be purchased at a retailer near you, online at www.holmesproducts.com.
Air Purifier
Model Number
Filter Quantity
Needed
Compatible with all
filter models below
Filter
Description
HAP9243/HAP9415 1
HAPF30AT
HAPF30AO
HAPF30AS
HAPF300AH
HAPF300AP (D filter)
aer1
®
Total Air Filter
aer1
®
Odor Filter
aer1
®
Smoke Grabber Filter
aer1
®
Allergen Remover Filter
aer1
®
Allergen Performance Plus
"D" Filter
HAP9423 2
Fig. 2
Fig. 1
A. Control Panel
B. Speed Control
Switch
C. Visipure
®
Filter
Viewing Window
D. Filter Reminder Dial
E. Ionizer Button
F. Filtered Air Outlet
G. Aer1
®
Filter(s)
H. Washable Foam
Pre-Filter
I. Air Inlet Grill
E
B
F
C
D
I
H
G
A
G
H
I
C
D
A
F
F
G
H
I
A
C
D
HAP9243_HAP9415_HAP9423-UA_18EM1.indd 2 5/4/18 11:28 AM
IMPORTANT SAFEGUARDS
FEATURES
VISIPURE
®
VIEWING WINDOW
Your Holmes
®
Air Purifier includes Aer1
®
Allergen
Remover Filter(s), specially designed to deliver cleaner
air! The Aer1
®
Allergen Remover filter(s) last 12 months.
See back panel for other filter options.
The Visipure
®
Filter Viewing Window is a lens which
allows you to get a clear view of the dirt being collected
in the filter and see if the filter needs replacement. The
Filter Reminder Dial helps you keep track of when to
change the filter.
BEFORE USE
1. Carefully unpack your Air Purifier. Select a firm level
place where there are no obstructions to the air inlet
or filtered air outlet.
2. Remove the air inlet grill and check if the filter is
covered by a plastic bag. If it is, remove plastic bag
before use and place filters into unit. Reinstall the air
inlet grill.
3. This unit is equipped with a filter that lasts 12
months. Please set the Filter Change Reminder to 12
months from date of purchase. If you have a 4
month filter, set the wheel from 4 months from date
of purchase. This will serve as a reference for when
filter replacement is needed.
NOTE: DO NOT POINT FILTERED AIR OUTLET TOWARDS WALL.
OPERATING INSTRUCTIONS
1. Plug into a 120V AC electrical outlet.
2. Select the desired operating speed; HI (3), MEDIUM
(2), LOW (1), by turning Speed Control Switch to the
appropriate setting. For optimum air filtration, it is
recommended to operate the air purifier continuously.
Its rugged motor has been designed to give many
years of use.
3. To release negative ions into the filtered air, press the
ionizer button ( ) to ON and the button will
illuminate in blue.
NOTE: The ionizer will not work unless the unit is
running.
CLEANING/MAINTENANCE INSTRUCTIONS
1. Turn the air purifier off and unplug it before
cleaning.
2. The outside of the air purifier can be cleaned with a
soft, clean damp cloth.
3. The air inlet grill (reference Fig. 1) can be removed
and washed in warm soapy water (not dishwasher
safe). Dry before replacing in the unit.
4. The filtered air outlet can be cleaned of dust with a
small, soft brush.
5. If you wish to clean the inside filter chamber of the air
purifier, please only use a dry, soft cloth to wipe it down.
POWER CORD INSTRUCTIONS
• The length of cord used on this appliance was
selected to reduce tangling or tripping hazards.
• If a longer cord is necessary, an approved extension
cord may be used. The electrical rating of the
extension cord must be equal to or greater than the
electrical rating of the air purifier (see rating label
marked on bottom of the product).
• Care must be taken to arrange the extension cord so
that it will not drape over the countertop or tabletop
where it can be pulled on by children or accidentally
tripped over.
GET TO KNOW YOUR AIR PURIFIER
This unit is compatible with all Aer1
®
Filters. This allows
you to choose the filter that is just right for you. Below is
information on each filter:
TOTAL AIR - Advanced Dust Eliminating Technology
ODOR ELIMINATOR - 10x the odor fighting power
ALLERGEN REMOVER - 99.97% True HEPA technology
improves air quality for allergy sufferers
ALLERGEN PERFORMANCE PLUS - 99.99% True HEPA
technology improves air quality for allergy sufferers.
SMOKE GRABBER - 99% effective at removing smoke
from the air steam (*as small as 0.3 microns from air
passing through the filter)
IONIZER
This appliance has an optional ionizer feature which,
when turned on, releases negative ions into outgoing
filtered air to help the air purification process.
What Are Ions?
Ions are tiny particles that carry a positive or negative
charge. They exist naturally around us: in the air, water,
and ground. Both positive and negative ions are colorless,
odorless, and harmless.
How Does The Ionizer Work?
Negative ions help air purification by attaching
themselves to very small airborne particles in the room.
These particles take on a negative charge and may join
with positively charged particles such as dust, pollen,
smoke, and pet dander to form larger particles. These
larger particles are then more easily captured by the
filter system.
Important Notes:
Your ionizer may produce an occasional popping or
cracking sound. This is normal and occurs when a small
buildup of ions is discharged.
After extended use, you may notice dust around the grills
or front panel. This is caused by negative ions exiting the
air outlet, evidence of the ionizer’s air cleaning
effectiveness. You can remove the dust with a soft brush
or clean, damp cloth.
Larger particles may be attracted to positively charged
surfaces throughout the home, like walls or floors.
• This may occur more frequently when the filter is
nearing the end of its usable product life and is
unable to capture as many charged particles.
• Excessive amounts of pet dander, dust, or smoke may
decrease the life expectancy of the filter and
interfere with the ionization process.
To help prevent particles from attracting to surfaces
throughout your home:
• You may want to run the ionizer less often.
• Check the condition of the filter(s) more frequently.
CAUTION: The ionizer in this appliance produces less
ozone than the UL established limits of 50ppb. However,
in high concentrations, ozone can be harmful to birds and
small pets. To prevent ozone buildup, we suggest using
the ionizer in well ventilated areas with the air purifier
fan on.
HIGH, MEDIUM AND LOW SPEED
SETTINGS
For optimum air filtration, operate your Holmes
®
air
purifier continuously on the MEDIUM (2) setting. Its
rugged motor has been designed to give many years of
use. For quieter operation (such as in a bedroom), select
the LOW (1) setting. When high levels of air pollution are
present, select the HIGH (3) setting to quickly circulate
and filter the air in the room.
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and injury to persons. These precautions include:
1. Read all instructions before using the appliance.
2. To reduce the risk of fire or electric shock, plug the
appliance directly into a 120V AC electrical outlet.
3. If the Filter is covered by a bag when shipped,
remove plastic bag before use.
4. Keep the cord out of heavy traffic areas. To avoid
fire hazard, NEVER put the cord under rugs, near
heat registers, radiators, stoves, or heaters.
5. DO NOT immerse the appliance in water or other
liquids. Do not use near water.
6. Close supervision is necessary when any appliance is
used by or near children, or disabled persons.
7. Always unplug the air purifier before moving or
cleaning the unit, opening the grill, changing the
filter and whenever the unit is not in use. To
disconnect the unit, be sure to pull the plug and not
the cord.
8. NEVER drop or insert any objects into the openings of
the unit.
9. DO NOT operate any appliance with a damaged cord
or plug. If the motor fan fails to operate or the unit
has been dropped or damaged in any manner, return
appliance to manufacturer for examination and/or
repair.
10. Use appliance only for intended household use as
described in this manual. Any other use not
recommended by the manufacturer may cause fire,
electric shock, or injury to persons. The use of
attachments not recommended or sold by Jarden
Consumer Solutions may cause injuries.
11. DO NOT use outdoors.
12. NEVER place on a soft surface such as a bed or sofa
as this could cause the unit to tip over and block the
air inlet or outlet grills.
13.
Keep unit away from heated surfaces and open flames.
14. DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so may cause
injuries and void your warranty. The inside of the unit
contains no user serviceable parts. All servicing should
be performed by Jarden Consumer Solutions or an
authorized Jarden Consumer Solutions Center.
15. DO NOT place anything on top of unit.
16. Always turn the appliance off before unplugging it.
17.
The ionizer in this appliance produces less ozone than
the UL established limits of 50ppb (parts per billion).
However, in high concentrations, ozone can be harmful
to birds and small pets. To prevent ozone buildup, we
suggest using the ionizer in well ventilated areas with
the fan on.
18. This appliance should only be used in a room with
temperatures between 40° F and 110° F.
19. To reduce the risk of fire or electric shock, DO NOT
use this appliance with any solid-state speed control
device.
SAVE SAFETY
INSTRUCTIONS
FEATURES - OPERATIONS
CLEANING/MAINTENANCE
FILTER REPLACEMENT
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in a
polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician to
install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
WARNING: Do not allow moisture to come in
contact with the main housing of the air purifier.
6. NEVER use detergents, gasoline, glass purifier,
furniture polish, paint thinner, or other household
solvents to clean any part of the appliance.
FILTER REPLACEMENT INSTRUCTIONS
IMPORTANT:
• DO NOT attempt to wash and re-use the Aer1
®
Filters.
• If the filters are enclosed in plastic bags, remove
them before use.
NOTE:
Every few weeks, check the condition of filter(s). The
Visipure
TM
Filter Viewing Window is a lens which allows
you to get a clear view of the dirt being collected in the
filter. The Filter Reminder Dial also helps you keep track
of when to change the filters. Filter life will vary,
depending on air quality and usage (see below). Under
normal conditions of continuous use, the Aer1
®
Total Air,
Odor and Smoke Filters will last 4 months while the
Allergen and Allergen Performance Plus Filters will last 12
months.
After approximately 12 months of operation, check the
condition of the filter through the Visipure
®
Filter Viewing
Window and use Filter Reminder Dial to keep track on how
long a filter has been in use.
• Filters with a 4 month filter life: Wash the foam pre-
filter and replace the Aer1
®
filter(s) after 4 months
of operation.
• Filters with a 12 month filter life: After 4 months of
operation, it is recommended to wash the foam
pre-filter and check the condition of your filter(s)
through the Visipure
®
Filter Viewing Window. The
filters must be replaced after 12 months of operation.
To replace your filter(s):
1. Turn off and unplug the air purifier.
2. Open the air inlet grill and examine the black foam
prefilter. Remove any dust or lint and wash in warm
soapy water. Rinse, air dry and place back into grill inlet.
3. Remove the used Aer1
®
filter(s) from the unit by
pulling it gently towards you and discard it. DO NOT
attempt to clean the Aer1
®
filters.
4. Install the new Aer1
®
filter(s) into the unit.
5. Align the clip(s) on the
side of Aer1
®
filter(s)
with rails on the inside of
the purifier unit. Gently
slide the filter(s) onto the
rail. (Fig. 2)
6. Replace air inlet grill.
7. Turn the Filter Reminder Dial to select the current
month you are replacing the new filter(s). This will
serve as reference for when filter replacement is
needed.
Filters can be purchased at a retailer near you, online at www.holmesproducts.com.
Air Purifier
Model Number
Filter Quantity
Needed
Compatible with all
filter models below
Filter
Description
HAP9243/HAP9415 1
HAPF30AT
HAPF30AO
HAPF30AS
HAPF300AH
HAPF300AP (D filter)
aer1
®
Total Air Filter
aer1
®
Odor Filter
aer1
®
Smoke Grabber Filter
aer1
®
Allergen Remover Filter
aer1
®
Allergen Performance Plus
"D" Filter
HAP9423 2
Fig. 2
Fig. 1
A. Control Panel
B. Speed Control
Switch
C. Visipure
®
Filter
Viewing Window
D. Filter Reminder Dial
E. Ionizer Button
F. Filtered Air Outlet
G. Aer1
®
Filter(s)
H. Washable Foam
Pre-Filter
I. Air Inlet Grill
E
B
F
C
D
I
H
G
A
G
H
I
C
D
A
F
F
G
H
I
A
C
D
HAP9243_HAP9415_HAP9423-UA_18EM1.indd 2 5/4/18 11:28 AM
IMPORTANT SAFEGUARDS
FEATURES
VISIPURE
®
VIEWING WINDOW
Your Holmes
®
Air Purifier includes Aer1
®
Allergen
Remover Filter(s), specially designed to deliver cleaner
air! The Aer1
®
Allergen Remover filter(s) last 12 months.
See back panel for other filter options.
The Visipure
®
Filter Viewing Window is a lens which
allows you to get a clear view of the dirt being collected
in the filter and see if the filter needs replacement. The
Filter Reminder Dial helps you keep track of when to
change the filter.
BEFORE USE
1. Carefully unpack your Air Purifier. Select a firm level
place where there are no obstructions to the air inlet
or filtered air outlet.
2. Remove the air inlet grill and check if the filter is
covered by a plastic bag. If it is, remove plastic bag
before use and place filters into unit. Reinstall the air
inlet grill.
3. This unit is equipped with a filter that lasts 12
months. Please set the Filter Change Reminder to 12
months from date of purchase. If you have a 4
month filter, set the wheel from 4 months from date
of purchase. This will serve as a reference for when
filter replacement is needed.
NOTE: DO NOT POINT FILTERED AIR OUTLET TOWARDS WALL.
OPERATING INSTRUCTIONS
1. Plug into a 120V AC electrical outlet.
2. Select the desired operating speed; HI (3), MEDIUM
(2), LOW (1), by turning Speed Control Switch to the
appropriate setting. For optimum air filtration, it is
recommended to operate the air purifier continuously.
Its rugged motor has been designed to give many
years of use.
3. To release negative ions into the filtered air, press the
ionizer button ( ) to ON and the button will
illuminate in blue.
NOTE: The ionizer will not work unless the unit is
running.
CLEANING/MAINTENANCE INSTRUCTIONS
1. Turn the air purifier off and unplug it before
cleaning.
2. The outside of the air purifier can be cleaned with a
soft, clean damp cloth.
3. The air inlet grill (reference Fig. 1) can be removed
and washed in warm soapy water (not dishwasher
safe). Dry before replacing in the unit.
4. The filtered air outlet can be cleaned of dust with a
small, soft brush.
5. If you wish to clean the inside filter chamber of the air
purifier, please only use a dry, soft cloth to wipe it down.
POWER CORD INSTRUCTIONS
• The length of cord used on this appliance was
selected to reduce tangling or tripping hazards.
• If a longer cord is necessary, an approved extension
cord may be used. The electrical rating of the
extension cord must be equal to or greater than the
electrical rating of the air purifier (see rating label
marked on bottom of the product).
• Care must be taken to arrange the extension cord so
that it will not drape over the countertop or tabletop
where it can be pulled on by children or accidentally
tripped over.
GET TO KNOW YOUR AIR PURIFIER
This unit is compatible with all Aer1
®
Filters. This allows
you to choose the filter that is just right for you. Below is
information on each filter:
TOTAL AIR - Advanced Dust Eliminating Technology
ODOR ELIMINATOR - 10x the odor fighting power
ALLERGEN REMOVER - 99.97% True HEPA technology
improves air quality for allergy sufferers
ALLERGEN PERFORMANCE PLUS - 99.99% True HEPA
technology improves air quality for allergy sufferers.
SMOKE GRABBER - 99% effective at removing smoke
from the air steam (*as small as 0.3 microns from air
passing through the filter)
IONIZER
This appliance has an optional ionizer feature which,
when turned on, releases negative ions into outgoing
filtered air to help the air purification process.
What Are Ions?
Ions are tiny particles that carry a positive or negative
charge. They exist naturally around us: in the air, water,
and ground. Both positive and negative ions are colorless,
odorless, and harmless.
How Does The Ionizer Work?
Negative ions help air purification by attaching
themselves to very small airborne particles in the room.
These particles take on a negative charge and may join
with positively charged particles such as dust, pollen,
smoke, and pet dander to form larger particles. These
larger particles are then more easily captured by the
filter system.
Important Notes:
Your ionizer may produce an occasional popping or
cracking sound. This is normal and occurs when a small
buildup of ions is discharged.
After extended use, you may notice dust around the grills
or front panel. This is caused by negative ions exiting the
air outlet, evidence of the ionizer’s air cleaning
effectiveness. You can remove the dust with a soft brush
or clean, damp cloth.
Larger particles may be attracted to positively charged
surfaces throughout the home, like walls or floors.
• This may occur more frequently when the filter is
nearing the end of its usable product life and is
unable to capture as many charged particles.
• Excessive amounts of pet dander, dust, or smoke may
decrease the life expectancy of the filter and
interfere with the ionization process.
To help prevent particles from attracting to surfaces
throughout your home:
• You may want to run the ionizer less often.
• Check the condition of the filter(s) more frequently.
CAUTION: The ionizer in this appliance produces less
ozone than the UL established limits of 50ppb. However,
in high concentrations, ozone can be harmful to birds and
small pets. To prevent ozone buildup, we suggest using
the ionizer in well ventilated areas with the air purifier
fan on.
HIGH, MEDIUM AND LOW SPEED
SETTINGS
For optimum air filtration, operate your Holmes
®
air
purifier continuously on the MEDIUM (2) setting. Its
rugged motor has been designed to give many years of
use. For quieter operation (such as in a bedroom), select
the LOW (1) setting. When high levels of air pollution are
present, select the HIGH (3) setting to quickly circulate
and filter the air in the room.
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and injury to persons. These precautions include:
1. Read all instructions before using the appliance.
2. To reduce the risk of fire or electric shock, plug the
appliance directly into a 120V AC electrical outlet.
3. If the Filter is covered by a bag when shipped,
remove plastic bag before use.
4. Keep the cord out of heavy traffic areas. To avoid
fire hazard, NEVER put the cord under rugs, near
heat registers, radiators, stoves, or heaters.
5. DO NOT immerse the appliance in water or other
liquids. Do not use near water.
6. Close supervision is necessary when any appliance is
used by or near children, or disabled persons.
7. Always unplug the air purifier before moving or
cleaning the unit, opening the grill, changing the
filter and whenever the unit is not in use. To
disconnect the unit, be sure to pull the plug and not
the cord.
8. NEVER drop or insert any objects into the openings of
the unit.
9. DO NOT operate any appliance with a damaged cord
or plug. If the motor fan fails to operate or the unit
has been dropped or damaged in any manner, return
appliance to manufacturer for examination and/or
repair.
10. Use appliance only for intended household use as
described in this manual. Any other use not
recommended by the manufacturer may cause fire,
electric shock, or injury to persons. The use of
attachments not recommended or sold by Jarden
Consumer Solutions may cause injuries.
11. DO NOT use outdoors.
12. NEVER place on a soft surface such as a bed or sofa
as this could cause the unit to tip over and block the
air inlet or outlet grills.
13.
Keep unit away from heated surfaces and open flames.
14. DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so may cause
injuries and void your warranty. The inside of the unit
contains no user serviceable parts. All servicing should
be performed by Jarden Consumer Solutions or an
authorized Jarden Consumer Solutions Center.
15. DO NOT place anything on top of unit.
16. Always turn the appliance off before unplugging it.
17.
The ionizer in this appliance produces less ozone than
the UL established limits of 50ppb (parts per billion).
However, in high concentrations, ozone can be harmful
to birds and small pets. To prevent ozone buildup, we
suggest using the ionizer in well ventilated areas with
the fan on.
18. This appliance should only be used in a room with
temperatures between 40° F and 110° F.
19. To reduce the risk of fire or electric shock, DO NOT
use this appliance with any solid-state speed control
device.
SAVE SAFETY
INSTRUCTIONS
FEATURES - OPERATIONS
CLEANING/MAINTENANCE
FILTER REPLACEMENT
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in a
polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician to
install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
WARNING: Do not allow moisture to come in
contact with the main housing of the air purifier.
6. NEVER use detergents, gasoline, glass purifier,
furniture polish, paint thinner, or other household
solvents to clean any part of the appliance.
FILTER REPLACEMENT INSTRUCTIONS
IMPORTANT:
• DO NOT attempt to wash and re-use the Aer1
®
Filters.
• If the filters are enclosed in plastic bags, remove
them before use.
NOTE:
Every few weeks, check the condition of filter(s). The
Visipure
TM
Filter Viewing Window is a lens which allows
you to get a clear view of the dirt being collected in the
filter. The Filter Reminder Dial also helps you keep track
of when to change the filters. Filter life will vary,
depending on air quality and usage (see below). Under
normal conditions of continuous use, the Aer1
®
Total Air,
Odor and Smoke Filters will last 4 months while the
Allergen and Allergen Performance Plus Filters will last 12
months.
After approximately 12 months of operation, check the
condition of the filter through the Visipure
®
Filter Viewing
Window and use Filter Reminder Dial to keep track on how
long a filter has been in use.
• Filters with a 4 month filter life: Wash the foam pre-
filter and replace the Aer1
®
filter(s) after 4 months
of operation.
• Filters with a 12 month filter life: After 4 months of
operation, it is recommended to wash the foam
pre-filter and check the condition of your filter(s)
through the Visipure
®
Filter Viewing Window. The
filters must be replaced after 12 months of operation.
To replace your filter(s):
1. Turn off and unplug the air purifier.
2. Open the air inlet grill and examine the black foam
prefilter. Remove any dust or lint and wash in warm
soapy water. Rinse, air dry and place back into grill inlet.
3. Remove the used Aer1
®
filter(s) from the unit by
pulling it gently towards you and discard it. DO NOT
attempt to clean the Aer1
®
filters.
4. Install the new Aer1
®
filter(s) into the unit.
5. Align the clip(s) on the
side of Aer1
®
filter(s)
with rails on the inside of
the purifier unit. Gently
slide the filter(s) onto the
rail. (Fig. 2)
6. Replace air inlet grill.
7. Turn the Filter Reminder Dial to select the current
month you are replacing the new filter(s). This will
serve as reference for when filter replacement is
needed.
Filters can be purchased at a retailer near you, online at www.holmesproducts.com.
Air Purifier
Model Number
Filter Quantity
Needed
Compatible with all
filter models below
Filter
Description
HAP9243/HAP9415 1
HAPF30AT
HAPF30AO
HAPF30AS
HAPF300AH
HAPF300AP (D filter)
aer1
®
Total Air Filter
aer1
®
Odor Filter
aer1
®
Smoke Grabber Filter
aer1
®
Allergen Remover Filter
aer1
®
Allergen Performance Plus
"D" Filter
HAP9423 2
Fig. 2
Fig. 1
A. Control Panel
B. Speed Control
Switch
C. Visipure
®
Filter
Viewing Window
D. Filter Reminder Dial
E. Ionizer Button
F. Filtered Air Outlet
G. Aer1
®
Filter(s)
H. Washable Foam
Pre-Filter
I. Air Inlet Grill
E
B
F
C
D
I
H
G
A
G
H
I
C
D
A
F
F
G
H
I
A
C
D
HAP9243_HAP9415_HAP9423-UA_18EM1.indd 2 5/4/18 11:28 AM
3 YEAR LIMITED WARRANTY
Sunbeam Products, Inc. or if in Canada, Sunbeam Corporation (Canada) Limited (collectively “Sunbeam”) warrants that
for a period of three years from the date of purchase, this product will be free from defects in material and workmanship.
Sunbeam, at its option, will repair or replace this product or any component of the product found to be defective during
the warranty period. Replacement will be made with a new or remanufactured product or component. If the product is
no longer available, replacement may be made with a similar product of equal or greater value. This is your exclusive
warranty. Do NOT attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void
this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. Sunbeam dealers, service
centers, or retail stores selling Sunbeam products do not have the right to alter, modify or any way change the terms
and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or
misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly, repair
or alteration by anyone other than Sunbeam or an authorized Sunbeam service center. Further, the warranty does not
cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on Sunbeam’s Liability?
Sunbeam shall not be liable for any incidental or consequential damages caused by the breach of any express, implied
or statutory warranty or condition. Except to the extent prohibited by applicable law, any implied warranty or condition
of merchantability or fitness for a particular purpose is limited in duration to the duration of the above warranty.
Sunbeam disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise. Sunbeam
shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use the
product including incidental, special, consequential or similar damages or loss of profits, or for any breach of contract,
fundamental or otherwise, or for any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or
limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
If you have any questions regarding this warranty or would like to obtain warranty service, please call
1-800-546-5637 and a convenient service center address will be provided to you.
In Canada
If you have any questions regarding this warranty or would like to obtain warranty service, please call
1-800-546-5637 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. located in Boca Raton, Florida 33431. In Canada,
this warranty is offered by Sunbeam Corporation (Canada) Limited doing business as Jarden Consumer Solutions,
located at 20 B Hereford Street, Brampton, Ontario L6Y 0M1. If you have any other problem or claim in connection
with this product, please write our Consumer Service Department. PLEASE DO NOT RETURN THIS PRODUCT TO
ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
AER1 FILTER SERIES
®
WARRANTY INFORMATION
TROUBLESHOOTING
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Owner’s Guide
HAP9243, HAP9415, HAP9423
195965 HAP9243_HAP9415_HAP9423-UA_18EM1 Printed In China
CSH-LD0318-HOL186832
Aer1
®
Allergen Remover Filter(s)
Air Purifier with Optional Ionizer
© 2018 Sunbeam Products, Inc. All Rights Reserved.
Distributed by Sunbeam Products, Inc., Boca Raton, Florida 33431.
LEARNING MORE
For a wealth of information about your air purifier and other Holmes
®
products, visit our website at
www.holmesproducts.com or call 1-800-546-5637. For inquiries regarding recycling and proper disposal of this
product, please contact your local waste management facility.
Congratulations! Your new air purifier is equipped with the Aer1
®
Allergen Remover
Filter.
Filter Type Technology Consumer Benefit
Total Air
99% HEPA-Type technology.
Infused with baking soda.
Ideal for dust reduction.
Delivers 30% better air quality.
Odor Eliminator
10 times the odor fighting power.
Contains baking soda, carbon and
zeolite for odor control.
Ideal for eliminating odors from
pets, tobacco smoke and cooking
fumes.
Allergen Remover
99.97% True HEPA technology.
Removes up to 99.97% of particles
as small as 0.3 microns passing
through the filter such as pollen,
dust, mold and dander.
Ideal for allergy sufferers.
Allergen Performance Plus
99.99% True HEPA technology.
Helps remove up to 99.99% of par-
ticles as small as 0.3 microns passing
through the filter such as pollen, dust,
mold and dander.
Ideal for allergy sufferers.
Smoke Grabber
HEPA-type filtration.
Triple layer protection specially
formulated with Baking Soda,
Carbon and Zeolite.
Removes up to 99% of smoke and
pollutants as small as 0.3 microns
from air passing through the filters.
Ideal for reducing smoke and odors
from smoke and VOC's.
TROUBLESHOOTING
Problem Solution
• Unit will not operate.
4 Check if unit is properly plugged in and outlet is energized.
4 Make sure unit is turned ON.
4 Make sure filters are properly installed and front grill is seated correctly.
• Decreased air flow.
4 Make sure nothing is blocking air inlet and filtered air outlets.
4 Check condition of the filters and replace if necessary.
4 Check filters to remove any plastic wrapping/packaging.
• Excessive Noise.
4 Make sure parts are firmly positioned in place.
4 Open the air inlet grill, and make sure that any plastic packaging was
removed from the filters, if applicable.
THIS UNIT
COMES
WITH
HAP9243_HAP9415_HAP9423-UA_18EM1.indd 1 5/4/18 11:28 AM
3 YEAR LIMITED WARRANTY
Sunbeam Products, Inc. or if in Canada, Sunbeam Corporation (Canada) Limited (collectively “Sunbeam”) warrants that
for a period of three years from the date of purchase, this product will be free from defects in material and workmanship.
Sunbeam, at its option, will repair or replace this product or any component of the product found to be defective during
the warranty period. Replacement will be made with a new or remanufactured product or component. If the product is
no longer available, replacement may be made with a similar product of equal or greater value. This is your exclusive
warranty. Do NOT attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void
this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. Sunbeam dealers, service
centers, or retail stores selling Sunbeam products do not have the right to alter, modify or any way change the terms
and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or
misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly, repair
or alteration by anyone other than Sunbeam or an authorized Sunbeam service center. Further, the warranty does not
cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on Sunbeam’s Liability?
Sunbeam shall not be liable for any incidental or consequential damages caused by the breach of any express, implied
or statutory warranty or condition. Except to the extent prohibited by applicable law, any implied warranty or condition
of merchantability or fitness for a particular purpose is limited in duration to the duration of the above warranty.
Sunbeam disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise. Sunbeam
shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use the
product including incidental, special, consequential or similar damages or loss of profits, or for any breach of contract,
fundamental or otherwise, or for any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or
limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
If you have any questions regarding this warranty or would like to obtain warranty service, please call
1-800-546-5637 and a convenient service center address will be provided to you.
In Canada
If you have any questions regarding this warranty or would like to obtain warranty service, please call
1-800-546-5637 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. located in Boca Raton, Florida 33431. In Canada,
this warranty is offered by Sunbeam Corporation (Canada) Limited doing business as Jarden Consumer Solutions,
located at 20 B Hereford Street, Brampton, Ontario L6Y 0M1. If you have any other problem or claim in connection
with this product, please write our Consumer Service Department. PLEASE DO NOT RETURN THIS PRODUCT TO
ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
AER1 FILTER SERIES
®
WARRANTY INFORMATION
TROUBLESHOOTING
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Owner’s Guide
HAP9243, HAP9415, HAP9423
195965 HAP9243_HAP9415_HAP9423-UA_18EM1 Printed In China
CSH-LD0318-HOL186832
Aer1
®
Allergen Remover Filter(s)
Air Purifier with Optional Ionizer
© 2018 Sunbeam Products, Inc. All Rights Reserved.
Distributed by Sunbeam Products, Inc., Boca Raton, Florida 33431.
LEARNING MORE
For a wealth of information about your air purifier and other Holmes
®
products, visit our website at
www.holmesproducts.com or call 1-800-546-5637. For inquiries regarding recycling and proper disposal of this
product, please contact your local waste management facility.
Congratulations! Your new air purifier is equipped with the Aer1
®
Allergen Remover
Filter.
Filter Type Technology Consumer Benefit
Total Air
99% HEPA-Type technology.
Infused with baking soda.
Ideal for dust reduction.
Delivers 30% better air quality.
Odor Eliminator
10 times the odor fighting power.
Contains baking soda, carbon and
zeolite for odor control.
Ideal for eliminating odors from
pets, tobacco smoke and cooking
fumes.
Allergen Remover
99.97% True HEPA technology.
Removes up to 99.97% of particles
as small as 0.3 microns passing
through the filter such as pollen,
dust, mold and dander.
Ideal for allergy sufferers.
Allergen Performance Plus
99.99% True HEPA technology.
Helps remove up to 99.99% of par-
ticles as small as 0.3 microns passing
through the filter such as pollen, dust,
mold and dander.
Ideal for allergy sufferers.
Smoke Grabber
HEPA-type filtration.
Triple layer protection specially
formulated with Baking Soda,
Carbon and Zeolite.
Removes up to 99% of smoke and
pollutants as small as 0.3 microns
from air passing through the filters.
Ideal for reducing smoke and odors
from smoke and VOC's.
TROUBLESHOOTING
Problem Solution
• Unit will not operate.
4 Check if unit is properly plugged in and outlet is energized.
4 Make sure unit is turned ON.
4 Make sure filters are properly installed and front grill is seated correctly.
• Decreased air flow.
4 Make sure nothing is blocking air inlet and filtered air outlets.
4 Check condition of the filters and replace if necessary.
4 Check filters to remove any plastic wrapping/packaging.
• Excessive Noise.
4 Make sure parts are firmly positioned in place.
4 Open the air inlet grill, and make sure that any plastic packaging was
removed from the filters, if applicable.
THIS UNIT
COMES
WITH
HAP9243_HAP9415_HAP9423-UA_18EM1.indd 1 5/4/18 11:28 AM
3 YEAR LIMITED WARRANTY
Sunbeam Products, Inc. or if in Canada, Sunbeam Corporation (Canada) Limited (collectively “Sunbeam”) warrants that
for a period of three years from the date of purchase, this product will be free from defects in material and workmanship.
Sunbeam, at its option, will repair or replace this product or any component of the product found to be defective during
the warranty period. Replacement will be made with a new or remanufactured product or component. If the product is
no longer available, replacement may be made with a similar product of equal or greater value. This is your exclusive
warranty. Do NOT attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void
this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. Sunbeam dealers, service
centers, or retail stores selling Sunbeam products do not have the right to alter, modify or any way change the terms
and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or
misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly, repair
or alteration by anyone other than Sunbeam or an authorized Sunbeam service center. Further, the warranty does not
cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on Sunbeam’s Liability?
Sunbeam shall not be liable for any incidental or consequential damages caused by the breach of any express, implied
or statutory warranty or condition. Except to the extent prohibited by applicable law, any implied warranty or condition
of merchantability or fitness for a particular purpose is limited in duration to the duration of the above warranty.
Sunbeam disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise. Sunbeam
shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use the
product including incidental, special, consequential or similar damages or loss of profits, or for any breach of contract,
fundamental or otherwise, or for any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or
limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
If you have any questions regarding this warranty or would like to obtain warranty service, please call
1-800-546-5637 and a convenient service center address will be provided to you.
In Canada
If you have any questions regarding this warranty or would like to obtain warranty service, please call
1-800-546-5637 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. located in Boca Raton, Florida 33431. In Canada,
this warranty is offered by Sunbeam Corporation (Canada) Limited doing business as Jarden Consumer Solutions,
located at 20 B Hereford Street, Brampton, Ontario L6Y 0M1. If you have any other problem or claim in connection
with this product, please write our Consumer Service Department. PLEASE DO NOT RETURN THIS PRODUCT TO
ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
AER1 FILTER SERIES
®
WARRANTY INFORMATION
TROUBLESHOOTING
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Owner’s Guide
HAP9243, HAP9415, HAP9423
195965 HAP9243_HAP9415_HAP9423-UA_18EM1 Printed In China
CSH-LD0318-HOL186832
Aer1
®
Allergen Remover Filter(s)
Air Purifier with Optional Ionizer
© 2018 Sunbeam Products, Inc. All Rights Reserved.
Distributed by Sunbeam Products, Inc., Boca Raton, Florida 33431.
LEARNING MORE
For a wealth of information about your air purifier and other Holmes
®
products, visit our website at
www.holmesproducts.com or call 1-800-546-5637. For inquiries regarding recycling and proper disposal of this
product, please contact your local waste management facility.
Congratulations! Your new air purifier is equipped with the Aer1
®
Allergen Remover
Filter.
Filter Type Technology Consumer Benefit
Total Air
99% HEPA-Type technology.
Infused with baking soda.
Ideal for dust reduction.
Delivers 30% better air quality.
Odor Eliminator
10 times the odor fighting power.
Contains baking soda, carbon and
zeolite for odor control.
Ideal for eliminating odors from
pets, tobacco smoke and cooking
fumes.
Allergen Remover
99.97% True HEPA technology.
Removes up to 99.97% of particles
as small as 0.3 microns passing
through the filter such as pollen,
dust, mold and dander.
Ideal for allergy sufferers.
Allergen Performance Plus
99.99% True HEPA technology.
Helps remove up to 99.99% of par-
ticles as small as 0.3 microns passing
through the filter such as pollen, dust,
mold and dander.
Ideal for allergy sufferers.
Smoke Grabber
HEPA-type filtration.
Triple layer protection specially
formulated with Baking Soda,
Carbon and Zeolite.
Removes up to 99% of smoke and
pollutants as small as 0.3 microns
from air passing through the filters.
Ideal for reducing smoke and odors
from smoke and VOC's.
TROUBLESHOOTING
Problem Solution
• Unit will not operate.
4 Check if unit is properly plugged in and outlet is energized.
4 Make sure unit is turned ON.
4 Make sure filters are properly installed and front grill is seated correctly.
• Decreased air flow.
4 Make sure nothing is blocking air inlet and filtered air outlets.
4 Check condition of the filters and replace if necessary.
4 Check filters to remove any plastic wrapping/packaging.
• Excessive Noise.
4 Make sure parts are firmly positioned in place.
4 Open the air inlet grill, and make sure that any plastic packaging was
removed from the filters, if applicable.
THIS UNIT
COMES
WITH
HAP9243_HAP9415_HAP9423-UA_18EM1.indd 1 5/4/18 11:28 AM
