Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
CAR3000C Issue: 1 04/01/18
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear safety
footwear
INSTRUCTIONS FOR:
CAR RAMPS 1.5TONNE CAPACITY PER RAMP
3 TONNE CAPACITY PER PAIR
MODEL NO: CAR3000C
1. SAFETY
9 Always use on a clean, level surface; preferably a surface with some friction.
9 Have a second person watching the ramps as the vehicle is driven on to warn of any unwanted movement.
9 When in place, apply the vehicle handbrake and leave in gear or ‘park’, if an automatic.
9 Always place chocks behind the rear wheels of the vehicle.
9 DO NOT exceed the rated capacity of the ramps (1500kg each, 3000kg per pair).
8 DO NOT use this product for any purpose other than that for which it is designed.I
8 DO NOT use the ramps if they are in any way damaged.N
2. INTRODUCTION
Manufactured from durable polypropylene. Suitable for professional or serious DIY applications.
3. SPECIFICATION
Model No: ............................................................CAR3000C
Capacity Pair: .............................................................. 3tonne
Ramp Height: ............................................................. 160mm
Maximum Tyre Width:................................................. 260mm
Overall Dimensions (L x W x H): .............900 x 300 x 215mm
4. OPERATION
Apply section 1 safety instructions
4.1. Push the ramps as far as possible under the front wheels.
4.2. With a second person guiding, carefully drive the front wheels up onto the ramps. Take particular care if driving a rear wheel drive
vehicle, which would tend to push the ramps forward.
4.3. Be prepared for the possibility of the vehicle stalling and rolling back.
4.4. When the vehicle is safely housed on the ramps, immobilise and place chocks under the rear wheels.
4.5. To dismount from the ramps, check that the area beneath the vehicle is clear and bring down very slowly using the foot brake.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
