Sealey AK4567D Retractable Oil Hose Reel 10m User Manual

oil hose reel retractable 10mtr

model no: aK4567D

thank you for purchasing a sealey product. manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. saFetY

 WarNiNG! Ensure health & safety, local authority, and general workshop practice regulations are strictly adhered to when using this

equipment.

9  Familiariseyourselfwithproductapplicationandlimitations,aswellasthespecicpotentialhazardspeculiartothisproduct.

9  Maintainthehosereelingoodcondition(useanauthorisedserviceagent).

9  Replaceorrepairdamagedparts.Use genuine parts only. Non authorised parts will invalidate the warranty.

9  UseonlylubricantsuptoSAE150viscosityandantifreezeliquids.

9  Ensuresafetyeyeprotectionandprotectiveclothingarewornwhenusingthisproduct.

9  Removeillttingclothing.Removetieswatchesrings,otherloosejewelleryandcontainand/ortiebacklonghair.

9  Keeptheworkareaclean,unclutteredandensurethereisadequatelighting.

9  Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnonslipshoes.

9  Keepchildrenandunauthorisedpersonsawayfromtheworkingarea.

9  Afteruse,drainanyuidsfromtheequipmentbeforestorage.

9  Disposeofwasteliquidsinaccordancewithlocalauthorityregulations.

9  Disconnectairpressurefromequipmentwhennotinuse.

8 Do Not exceedthemaximumworkingpressureof2000psi.

8 Do Not leavethehoseontheground,retractwhennotinuse.

8 Do Not pointattachmentsatpeopleoranimals.

8 Do Not usetheequipmentnearopenames.

8 Do Not smokewhilstusingthisequipment.

8 Do Not usewithcorrosiveuids.

8 Do Notdismantle,tamperwithoradaptthereelforanypurposeotherthanforwhichitisdesigned.

8 Do Not usetheunitifithasbeendroppedormishandled,checktheunittoensurethereisnodamage.

9  Keeptheequipmentcleanandstoreinasafedry,childprooflocation.

 WarNiNG! Do Notdismantlethehosereelcasing.Todosomayresultindamagetotheapplianceand/orpersonalinjuryandwill

 invalidatethewarranty.

 WarNiNG! Do Notallowuncontrolleddischargeofuidsthuspollutingtheenvironment.Allliquidsmustbedisposedofaccordingto

 localauthorityregulations.

2. iNtroDuctioN

ForusewithAK4560Dpumpstation.Heavy-dutysteelandpowdercoatingfinishforcorrosionresistance.Fourrollerfairleadallowssmooth

runningofhosewhatevertheangleofhoseormountingpositionofreel.Multipositionratchetlockwithfullyenclosedspring.Includes1.5mtr

connectionhoseforconnectingreeltopump.

3. speciFicatioN

model no:................................................................AK4567d

Hoseinlet/outlet:.......................................................1/2”BSP

Hose length:..................................................................10mtr

Hosesize(ID):.................................................................1/2”

max.pressure:...........................................................2000psi

Weight:...................................................................... 18.14kg

4. mouNtiNG

4.1.  Mountthereeltoawallorbenchusingappropriatexings(notsupplied).

4.2.  Connectthe1.5mtrhosefromthecentrereelconnectiontotheAK4560D

 pumpstation.

4.3.  Connectadispensinggun/metertotheoutletconnection.

4.4.

4.5.

4.6.

4.7.

Refer to

instruction

manual

Wear

eye

protection

Wear

protective

gloves

Wear

protective

clothing

AK4567D|Issue:2(H,F)16/04/18

Original Language Version

sealey Group, Kempson Way, suffolk business park, bury st edmunds, suffolk. ip32 7ar

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

eNviroNmeNt protectioN

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

accordingtolocalregulations.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior

notice.

important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

AK4567D|Issue:2(H,F)16/04/18

5. operatioN

5.1.  Pullthehoseatasteadypace,aclickingnoisefromtheratchetwillbeheard,whenthehoseisatthedesiredlength,gentlyrelease

the pressureandthehosewilllockintoposition.

5.2.  Toretractthehose,pullthehoseoutashortdistanceandreleasethehosewillnowrewind.

 WarNiNG! Do Notletgoofthehose,guideitbackuntilitisfullyretracted.Failuretodothismaydamagethegunormetering

 deviceontheendofthehose.

6. maiNteNaNce

 WarNiNG!Beforeattemptingmaintenanceorinspectionventanypressureremaininginthehoseandemptyhoseofoiletc.

6.1.  Toensurereliableoperation,inspect,cleanhoseandcasingregularly.Do Notsprayorwettheproductbutcleanwithadampcloth.

8 Do Notusesolventsordetergentsasthesemaycausepermanentdamage.

6.2.  Thehosereeldoesnotrequirespecialmaintenanceasitislubricatedforlife.Iftheproductneedsattention,consultyournearest

 authorisedserviceagent.

 WarNiNG! Do Not attempt to loosen or remove any part of the product. replacement of the supply hose should be carried

out by skilled personnel only, contact your nearest authorised service agent.

6.3.  Storeinacool,dry,childproofplace.
