Sealey AK39902 Lazy Tongs Riveter User Manual

LAZY TONGS RIVETER

MODEL NO: AK39902.V3

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

 WARNING! Ensure health & safety, local authority, and general workshop practice regulations are adhered to when using

this equipment.

9  Familiariseyourselfwithapplicationandlimitations,aswellasthespecicpotentialhazardspeculiartotheriveter.

9  Replaceorrepairdamagedparts.Usegenuinepartsonly.Nonauthorisedpartsmaybedangerousandwillinvalidatethewarranty.

9  Keeptherivetercleanforbestandsafestperformance.

9  Locateriveterinanadequateworkingareaforitsfunction,keepareaclean&tidyandfreefromunrelatedmaterialsandensurethere

is adequate lighting.

9 Keep children and unauthorised persons away from the working area.

9  Removeillttingclothing.Removeties,watches,rings,andotherloosejewellery,andcontainand/ortiebacklonghair.

 WARNING!Alwayswearapprovedeyeorfaceprotectionwhenoperatingtheriveter.

9  Keepngers,handsandbodyclearofallworkingpartsandDO NOT placeanyitemswithintheriveterlattice.

9 Familiarise yourself with the push action to ensure you DO NOT accidentally wrench your wrist when pushing sharply.

9  Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnonslipshoes.

9  Securenonstableworkpiecewithaclamp,viceorotheradequateholdingdevice.

9  Ensurethatallusedrivetendsaredisposedofinasafemanner.

8 DO NOTgettheriveterwetoruseinwetlocations.

8 DO NOTusetheriveterforanypurposeotherthanforwhichitisdesigned.

8 DO NOToperatetheriveterwhenyouaretired,undertheinuenceofalcohol,drugsorintoxicatingmedication.

8 DO NOTallowuntrainedpersonstooperatetheriveter.

8 DO NOToperatetheriveterifanypartsaredamagedormissingasthismaycausefailureorpossiblepersonalinjury.

2. INTRODUCTION

AluminiumheadwithsteeljawcaseandChromeMolybdenumjawsforaluminium,steelandstainlesssteelrivets.Suitableforrepetitiveriveting

tasks.Suppliedwithvenozzles.

3. SPECIFICATION

Model No.: .........................................................AK39902.V3

Nozzles: ................................................................................

.3.2mm(1/8”),4mm(5/32”),4.8mm(3/16”),6mm,6.4mm(1/4”)

Length: .......................................................................800mm

RivetTypes: ...........................................................................

............Aluminium - Yes, Stainless Steel-Yes, Structural - No

4. OPERATION

4.1. NOZZLES

4.1.1. Selecttheappropriatenozzle.

4.1.2. Toremovenozzleathead,usesuitablewrench.Ensurethereplacementnozzleiscompletelyscrewedinandlightly  

tighten with wrench.

4.2. TO OPERATE

4.2.1. Holdtheheadandpullthehandlesothatthelatticeiscompletelyextended.

 WARNING!Ensureyourngersareclearofmovingparts.Insertrivetshaftallthewayintothenozzle.

4.2.2. Insertrivetheadcompletelyintothepreparedworkpiecehole.

4.2.3. Holdtheriveterrmlyandpushonthehandletocompletelyclosethelatticewhichwillxtherivetinplaceandcuttheshaft.Should

 rivetingnotbeachievedonthersttrythenre-extendthelatticeandpushoncemore.

4.2.4. Oncecompleted,pullthehandletoextendthelatticeagaintoejecttheshaftendfromthenozzle.Safelydiscardofshaftends.

AK39902.V3Issue2(2)14/12/21

Original Language Version

Refer to

instructions

g.1

Wear eye

protection

Crushingof

hands

5. MAINTENANCE

5.1. Keeptheriveterclean.

5.2. Uselightmachineoiltooccasionallylubricatethelatticepivotpins.

5.3. Whennotinuse,storetheriveterinasafe,dry,childprooflocation.

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

according to local regulations.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior

notice. Pleasenotethatotherversionsofthisproductareavailable.Ifyourequiredocumentationforalternativeversions,pleaseemailorcall

ourtechnicalteamontechnical@sealey.co.ukor01284757505.

Important: No Liability is accepted for incorrect use of this product.

Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.

Partssupportisavailableforthisproduct.

www.sealey.co.uk,emailsales@sealey.co.ukortelephone01284757500

Original Language Version

AK39902.V3Issue2(2)14/12/21
