PART NAMES AND LOCATIONS
IN ACCESSORY BAG: USER MANUAL, WARRANTY CARD
As the manufacturer holds the authority to redesign or modify its products without notice:
Any modifications or upgrades of our products will result in this Cooler varying slightly
from this manual but the functionality will remain the same to that as set out within this
manual.
No
Description
1
Glass door
2 Thermostat
3 Wire shelves
4 Leveling feet
1
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Follow these basic precautions to reduce the risk of fire,
electrical shock hazards or injury when operating the
Cooler:
• This product has been designed for using in a normal domestic environment. It is
not intended for commercial use which will avoid warranty, such as supermarket,
food shop, pharmacy, commercial kitchen & etc.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
• It is critical to use this appliance safely. Read all instructions before operating
the Cooler and do not attempt to repair or modify this unit in any way as it can
cause harm or void the warranty.
• Please ensure all persons using this appliance are also informed and comply
with the details set out within this manual and the product Terms and
Conditions.
• When unpacking the appliance for the first time, keep all cardboard and plastic
packaging out of reach from children.
• Report any notable defects with the appliance to CHiQ or retailer as soon as it is
noted. Failure to do so can result in a non-warranty claim. Keep all packaging
materials in a safe location until the unit has been installed properly.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard. It is
recommended the power cord is situated in a safe location when operating or
transporting the appliance to prevent any damage that may cause electrical
shock or fire hazards.
• DANGER or WARNING:
This unit is not designed for outdoor installation.
This appliance is intended to be used in household and similar applications such
as
– staff kitchen areas in shops, offices, and other working environments.
– farmhouses and by clients in hotels, motels, and other residential type
environments.
– bed and breakfast type environments.
– catering and similar non-retail applications.
Service of this unit
2
The installation or any service of the appliance is recommended by a qualified
technician or service company.
Ventilation Hazards
Never clean the Cooler or Cooler parts with flammable fluids, or store gasoline
or any other flammable vapors and liquids in the vicinity of this or any other
Cooler as the gas and/or vapour can cause a fire hazard, explosion or
inhalation.
Electrical Connection
Make certain, when installing or moving the unit that the power outlet has been
connected to, has been fitted by a qualified electrician and the ground wire has
been connected properly to meet the Australian Electrical Standards.
R600a WARNINGS
3
NOTE: This model uses R600a flammable refrigerant in its sealed system.
The following must be observed for your safety:
R600a Refrigerant Warning
• This appliance contains 0.018kg R600a refrigerant which is
environmentally friendly, but flammable. It does not damage the ozone
layer, nor does it increase the greenhouse effect.
• During transportation and installation, ensure that the tubing of the
refrigerant circuit is not damaged.
• Leaking refrigerant can ignite and may damage the eyes.
• In the event any damage does occur, avoid exposure to open fires and
any device which creates a spark. Disconnect the appliance from the
mains power.
• Thoroughly ventilate the room in which the appliance is located for
several minutes.
• Notify Customer Service for necessary action and advice.
• The room for installing the appliance must be at least 1 cubic meter per
8 grams of refrigerant. The refrigerant quantity contained in this
appliance is listed above in grams; it is also noted on the Rating Plate of
the appliance.
* Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Warning: Risk of fire/flammable materials
It is hazardous for anyone other than an Authorized Service Person to carry out
servicing or repairs to this appliance. In Queensland the authorized person must
hold a Gas Work Authorization for hydrocarbon refrigerants, before carrying out
servicing or repairs which involve the removal of covers.
1. Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
2. Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
3. Do not damage the refrigerant circuit.
4. Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
5. Do not store explosive substances such as aerosol cans with flammable propellant in
the appliance.
6. WARNING: When positioning the appliance, ensure the supply cord is not trapped or
damaged.
7. WARNING: Do not locate multiple portable socket-outlets or portable power supplies
at the rear of the appliance.
Do not drag or lift the refrigerator directly from its top frame when moving the refrigerator, to avoid
damaging the top frame.
Disposal
4
The environment and personal safety must be considered when disposing of this
appliance. Please ensure the appliance is taken to a recycle center for safe recycling. DO
NOT dispose of the appliance in land fill as the insulation and refrigerant gas contained
in these appliances are flammable.
INSTALLATION INSTRUCTIONS
Before Using the refrigerator
• Remove the exterior and interior packing.
• Before connecting the Cooler to a power source, let the unit stand upright for
approximately 4 hours to mitigate the possibility of a malfunction in the cooling
system from improper handling during transportation.
• Clean the interior surface with warm water using a soft cloth.
Installing the refrigerator
Dimensions in mm:
W
D
H
A
B
C(°)
E
F
470
439
496
790
883
130±5
50
50
• Place the refrigerator on a concrete, tile floor or waterproof floor is
recommended. The fridge will produce defrost water or condensation moisture;
it might cause water damage in some extreme circumstances.
• This appliance is designed to be free standing only, and should not be recessed or
built in.
• There are no wheels on the bottom of the unit, please lift it up when move the
appliance. Don’t push or pull it when it sits on the flooring which might be
damaged or scratched.
• Allow at least 5cm of space between the back and sides of the Cooler to allow
proper air ventilation. Insufficient space will result in cooling and working life issue
and voiding warranty.
• Place the Cooler on a leveled/even floor surface that is strong enough to support the
weight of the Cooler when it is fully loaded to prevent vibrations.
• Place the Cooler on a concrete, tile floor or waterproof floor is recommended.
5
The fridge will produce defrost water or condensation moisture; it might cause
water damage in some extreme circumstances.
• The bottom feet can be adjusted to level the appliance properly. Adjust the two
feet to keep the Cooler leveled or elevated.
• Situate the Cooler away from direct sunlight and sources of direct heat (stove, heater,
radiator, etc.). Direct sunlight may also affect the acrylic coating and heat sources
may cause an increase in power consumption.
• This unit is not designed for outside installation.
• Avoid situating the Cooler in moist OR pest infestation areas.
• Plug the Cooler into dedicated, properly installed-grounded wall outlet. Do not under
any circumstances cut or remove the third (ground) prong from the power cord. Any
questions concerning power and/or grounding should be directed toward a certified
electrician or an authorized service center.
• After plugging the appliance into a wall outlet, turn the unit on and allow the unit to
cool down for 4-6 hours before placing food in the Cooler.
• Do not place heavy items on the top of this appliance.
ENERGY SAVING TIPS
• Allow hot foods to cool to room temperature before placing in the Cooler. Overloading
the Cooler forces the compressor to work harder. Foods that freeze too slowly may
lose quality, or spoil.
• Be sure to wrap foods properly, and wipe containers dry before placing them in the
Cooler. This cuts down on frost build-up inside the Cooler.
• Organize and label food to reduce door openings and extended searches. Remove as
many items as needed at one time and close the door as soon as possible.
OPERATING INSTRUCTIONS
Temperature setting
6
• The temperature of the appliance can be adjusted by turning the thermostat dial.
The thermostat can be set between 1 and 7.
• 1 is the warmest setting.
• 7 is the coldest setting.
• Set the dial to OFF to turn off the cooling function.
• Under the normal operating condition (in spring and autumn), it is recommended to
set the temperature at 4.
• In summer when the ambient temperature is high, it is recommended to set
temperature at 3-4, to guarantee the Beverage Cooler
• temperatures and reduce the refrigerator’s continuous running time; and in winter
when the ambient temperature is low, it is recommended to set temperature at 5-6 to
avoid frequent start/stop of the Beverage Cooler.
• Notes: The temperatures may vary with respect to settings due to compressor cycles
and outside conditions.
Please note the appliance is using sensitive thermostat, it will keep more stable
temperature inside the unit. In order to do so, the compressor might cut in and
out more often which is normal operation of the unit.
GENERAL CARE AND MAINTENANCE
Defrosting your cooler
• There is slight frosting on the surface of the evaporator during the use of the product.
The beverage cooler defrosts during the cut in and cut off time of the temperature
controller. After defrosting, the water will be collected in the water pan through the
water pipe inside the box, and the heat generated during the operation of the
compressor will evaporate the water in the water pan.
7
Cleaning the cooler
• Upon installation of your new appliance, it is recommended that it be cleaned
thoroughly and properly maintained thereafter.
• Turn off the Cooler and then unplug the unit from the wall outlet.
• Remove all food content before washing the inside with a damp cloth soaked in
lukewarm water and dishwasher liquid. Don’t use any chemical detergent which
might damage coating or inner liner of the cooler.
• Be sure to keep the door gasket (seal) clean to keep the unit running efficiently as
improper cleaning can cause the seal to dislodge and tear.
• Dry the interior and exterior with a soft cloth.
Vacation Time
• Turn off the Cooler first and then unplug the unit from the power point.
• Remove all food.
• Clean the Cooler.
• Leave the lid open slightly to avoid possible formation of condensation, mold, or
odors.
• Use extreme caution in the case of children. The unit should not be accessible to
child’s play.
• Short vacations: Leave the Cooler operating during vacations of less than three
weeks.
• Long vacations: If the appliance will not be used for several months, remove all food
and unplug the power cord. Clean and dry the interior thoroughly. To prevent odour
and mold growth, leave the door open slightly.
Repositioning and Relocating the Cooler
• Unplug the power cord from the wall outlet.
• Remove all the food and drinks.
• Securely tape down all loose items inside your Cooler.
• Tape the doors to be closed securely.
• It is recommended that the Cooler stays in the upright position during transportation.
But if it is laid down for transport purposes, please lift it up immediately after the job
is done. Please wait for at least 24 hours before putting in the power.
TROUBLESHOOTING GUIDE
PROBLEM SOLUTION
PROBLEM SOLUTION
8
The cooler does not operate.
• Make sure that the cooler is plugged in and that the plug is pushed
completely into the outlet.
• Check the house fuse/circuit breaker box and replace the fuse or reset the
circuit breaker.
• If a power failure occurs, the cooler turns off. Wait until the power is
restored, then turn it on again.
The cooler door does not
close completely.
• Adjust the shelf properly.
• Clean the door gaskets.
• Level the cooler with the leveling feet.
The cooler is not cold
enough.
Make sure that the door is closed properly.
• Allow time for new beverages to cool, then check again.
• Set the control to a colder setting.
The cooler makes unusual.
noises or vibrates.
• Level the cooler with the leveling feet.
• Move the cooler out from the wall.
• This is normal.
Moisture is building up in
the interior of the cooler.
• Make sure that the door is closed properly.
• Move the cooler to a dryer location.
The cooler turns on and off
frequently.
• Make sure that your cooler is in a room that is 50–85 °F (10–29.4 °C) or
place your cooler in a cooler
location.
•Make sure that the door is closed properly.
•Clean the door gaskets.
•Set the control to a colder setting.
For any enquiries, please call the CHiQ Cusotmer care on: 1300 796 688
