CM-080A-BU
WARRANTY
Safety Precautions .............................................................................
FAQs ...................................................................................................
Product Description ...................................................................................
Operating Instructions...............................................................................
Maintenance.........................................................................................
Storage...................................................................................................
Disposal................................................................................................
Troubleshooting..........................................................................................
Specifications........................................................................................
Package includes.....................................................................................
Warranty...............................................................................................
1
2
4
5
8
8
9
8
10
10
10
1. Those with any of the following conditions or persons who are
receiving medical treatment should consult the doctor before using the
product:
(1) Using pacemaker or other medical devices which are susceptible to
electrical interference;
(2) Suffering from malignant tumors;
(3) Suffering from cardiac diseases;
(4) Having serious peripheral neuropathy dysfunction or sensory
disturbance caused by diabetes;
(5) Being unsuitable to do the massage because of traumas on the
body;
2. Keep it out of the reach of infants, children, and people without the
ability to use it independently.
3. Don’t use another power adapter but the original one.
4. Don’t scratch, damage, process, excessively band, pull or twist the
power cord of power adapter. Otherwise, it may cause fire or electric
shock.
5. It is not allowed to use when the power adapter dysfunctions or the
plug is loose.
Thigh chamber compress and then release. There will be a brief rest
period and then the cycle will begin again. This will repeat until the
session time runs out.
Q1: How does this product massage?
Q2: How many massage modes, and what's the difference?
A1: There are 3 air chambers in each wrap, they will be inflated and
deflated to simulate kneading and stroking of tissues like human hands.
It can relax our muscles, increase circulation and relieve pain.
A2: There are 3 massage modes.
Mode1: Sequence Mode
Foot & Lower Calf chamber compress and then release → Upper Calf &
Mode 2: Circulation Mode
Foot & Lower Calf chamber compress and hold pressure → Upper
Calf & Thigh chamber compress and hold pressure → all 4 chambers
release at the same time. There will be a brief rest period and then the
cycle will begin again. This will repeat until the session time runs out.
Mode 3: Combination Mode
Mode 1 and mode 2 runs alternately in this mode until the session time
runs out.
Q3: What should I do if I feel the massage strength is too light or too
tight?
A3: There are 3 levels of massage strength selectable via the controller,
please select the intensity which is fit for you. You can also adjust the
strength by changing the tightness of Velcro on the wraps.
Q4: How long should I use it?
A4: It is recommended to use it once or twice a day, no more than 30
minutes at a time. But you can use it longer if you feel too tired and
want it massage longer to work on the soreness.
Q5: Why does not it work when I press the power button?
A5: Please ensure both 2 air hoses are inserted into the controller,
otherwise,it will not work.
Q6: Why does the controller get hot?
A6: As we suggested, you can use it 20 minutes per time normally.
If it keeps working too long, the controller will get hot, it’s a normal
phenomenon.
Q7: Why does the controller make sound?
A7: The sound comes from the working air pump in the controller,
providing air continuously to the airbags in the wraps, it’s normal
phenomenon.
Q8: What should I do if I feel the temperature is too hot?
A8: Please use the lower temperature or turn it off. We suggest you
wear trousers if necessary.
HEAT
Display Screen：display current setting
Current Mode
（SEQUENCE / CIRCULATION / COMBINATION）
Current Intensity
（MIN/MID/MAX）
Current Heating Level
（MIN/MID/MAX）
1
1
2
3
2
3
Air Hoses Connect Port
Power Port
Q9: What should I do if I have thicker legs?
A9: For bigger legs, please use the extensions included to expand the
size of wraps.
Massage Sleeve
Air Hose
Foot Air Chamber
Calf Air Chamber
Thigh Air Chamber
Velcros
UP
Please read safety precautions carefully before using the product.
In order to get better massage, please use it according to the instruction
1.Check the tags for Left / Right Leg and the central line, then wear the
wraps properly.
2.Fix the velcros, adjust the position and tightness, don’t wrap too tight.
Use the extensions for bigger calves, and cut the stitches for bigger
feet.(see details in FAQS A9)
3. Insert BOTH two air hoses into the controller correctly and completely,
then connect well the adapter to the outlet and controller.
4. Press the Power button to start.
It will begin with Mode 1 / Min air presssure intensity / Heat off by default.
5.Press Mode button to change the massage mode. 3 modes available,
see the difference in FAQS A2.
HEAT
HEAT HEAT HEAT
