GUIDANCE ON
THE SAFE USE OF HAMMERS
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
1. GENERAL SAFETY
Perform a risk assessment before using the hammer. Ensure the area is clean and well lit. Always wear appropriate clothing, eye
protection and footwear when using a hammer. Additional PPE may be required depending on the task at hand. DO NOT use this
product if you are tired or under the inuence of drugs, alcohol or medication.
2. HAMMER TYPE
Always select a suitable hammer, of the appropriate type, size and weight, for the job concerned. See table below.
TYPE OF HAMMER DESCRIPTION USE
Claw hammer Has a curved claw on one end for prying and a
at face on the other end for striking.
Used for general carpentry tasks such as nailing,
pulling nails, and prying.
Ball-pein hammer Has a round, domed face on one end and a ball-
shaped pein on the other end.
Used for forging metal, shaping sheet metal, and
riveting.
Deadblow hammer Has a solid metal head that is lled with lead or
another heavy material.
Used for striking without damaging the surface being
struck.
Framing hammer Has a long handle and a large, heavy head. Used for framing walls and other construction tasks.
Mallet Has a large, smooth head made of wood, rubber,
or plastic.
Used for tasks that require a soft strike, such as
driving chisels or shaping wood.
Sledgehammer Has a very large, heavy head. Used for demolition and other heavy-duty tasks.
Tapered pin hammer Has a tapered, pointed head. Used for driving tapered pins and other small objects.
3. WEAR SAFETY GOGGLES
Always wear safety goggles when using a hammer. This is especially important when hammering hard materials and in circumstances
where materials are likely to chip and y.
4. STRIKING TOOLS
When striking chisels, punches, wedges, or other tools, the striking-face of the hammer should be larger than the head of the tool being
struck. For example, a 12mm cold chisel-head requires at least a 25mm hammer face.
5. MASONRY NAILS
Masonry nails, which are hardened, should only be struck with a lump or clubhammer. It is essential that safety goggles are worn when
driving these nails.
6. STRIKING TECHNIQUE
Always strike squarely and avoid glancing blows. Never strike with the side cheek of a hammer head and never strike a material which
is harder than the hammer head. Never strike two hammer head faces together.
7. INSPECT BEFORE USE
Never use a hammer with a loose or damaged handle and discard any hammer if the head shows any sign of excessive wear,
mushrooming, chipping, dents, etc. Never attempt to refurbish hammer faces. Attention is drawn to the use of light hammers with
elongated heads, such as the welder’s chipping hammer, since, whilst handle tests and assembly are appropriate to the mass of the
tool, the mode of use can be particularly prone to loosening of handles.
8. STORAGE - WOODEN HAMMERS ONLY
Always store wooden handled hammers at ambient temperatures. DO NOT store in a heated warehouse or storage place as this is a
signicant cause of loose hammer heads, due to the drying out of the wooden handles.
9. INSPECT REGULARLY
Inspect hammers regularly to ensure they are t for purpose. If in doubt, seek specialist advise or contact the manufacturer.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL
REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR
THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR
FUTURE USE.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
