HIGH FLOW SYPHON PUMP WITH
SEGMENTED SUCTION PIPE
MODEL NO: TP782
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! DO NOT operate using ammable liquids in a conned space, the area should have adequate ventilation.
9 If pumping ammable liquids, avoid proximity to naked ames or welding operations.
9 Wear appropriate protective clothing when pumping solvents.
9 We particularly recommend eye/face and hand protection, available from your authorised Sealey stockist.
9 Keep children away from areas where solvents are being used.
9 Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this equipment.
9 Ensure any spillages are dealt with immediately. Failure to do so could lead to injury.
8 DO NOT use this pump for HOT WATER.
2. INTRODUCTION
Easy-to-use polyethylene manual pump with self-priming feature. Equipped with vent cap to stop discharge after use, and 120mm exible
corrugated discharge hose. Segmented suction pipe for height adjustment and easy storage. Suitable for water, oils and non-aggressive
chemicals. For use with various drums heights from 420mm, 530mm up to 850mm/205L. Delivers approximately 21L/min. transferring liquids
quickly and easily.
3. ASSEMBLY
3.1. Thread Suction Pipe B into Connector under the Pipe A and Pipe C into B with Connector (g.1).
4. OPERATION
4.1. Ref g 2: Place the suction pipe into supply container opening.
4.2. Place the outlet of the discharge hose into receiving container
opening.
4.3. Grip handle, pressing down repeatedly until liquid begins to ow.
4.4. Liquid will continue owing through discharge hose as long as the
level of contents of the supply container is higher than that of the
receiving container.
4.5. If siphon action stops because the level in the supply container
is very low, grip handle, pressing down repeatedly or raise the
supply container so it is above receiving container.
4.6. To stop siphon ow at any time, unscrew the air vent cap at the top
of the grip. To start ow, close the air vent cap and repeat step 4.3.
TP782 Issue 1 04/10/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
Wear protective
gloves
Fig.2
Fig.1
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
