ASSEMBLY INSTRUCTIONS:
Please read the cooler manual carefully and assemble according to following steps.
1. Please make sure all parts are accounted for before beginning assembly.
2. Place main basin up-side down on clean soft surface
3. Attach the 4 legs (part 10) to basin using the 12 M6*16 Bolts (part 9).
4. Screw each caster (parts 11 &13) into the legs.
5. Turn over entire assembly right side-up. Press caster brake lever to lock casters (part 11).
6. Attach bottle-cap catcher (part 8) to main basin by 2pcs bolts (part 5).
7. Attach bottle opener (part6) to main basin using 2 each M6*16 Bolts tighten with the M6 Allen wrench.
8. Attach 2 each lid handles (part 1) to cooler lid (part 2) with 2 each M5*35 Bolts (part 3) tighten.
9. Clean inside of cooler completely with soft dry towel. Place cooler lid (part 2) on top of main basin
(part 7) your cooler is now ready for use.
Item
Description
Qty
1
2
3
4
5
6
7
8
9
10
11
12
13
Lid Handle
Lid
M5*35 Bolts
Handle
M6*16 Bolts
Bottle Opener
Basin
Bottle-cap Catcher
M6*16 Bolts
Legs
Casters with Lock
M6 Allen Wrench
Casters without Lock
2
1
2
2
4
1
1
1
12
4
2
1
2
