Axis Q1614~EOL Q1614 Network Camera 0550-001 User Manual

USERMANUAL

AXISQ1614NetworkCamera

AboutthisDocument

ThismanualisintendedforadministratorsandusersoftheAXISQ1614

FixedDomeNetworkCamera,andisapplicabletormware5.4and

later.Itincludesinstructionsforusingandmanagingtheproducton

yournetwork.Previousexperienceofnetworkingwillbeofusewhen

usingthisproduct.SomeknowledgeofUNIXorLinux-basedsystems

mayalsobebenecial,fordevelopingshellscriptsandapplications.

LaterversionsofthisdocumentwillbepostedtotheAxiswebsite,

asrequired.Seealsotheproduct’sonlinehelp,availableviathe

web-basedinterface.

LegalConsiderations

Videoandaudiosurveillancecanberegulatedbylawsthatvaryfrom

countrytocountry.Checkthelawsinyourlocalregionbeforeusing

thisproductforsurveillancepurposes.

Thisproductincludesone(1)H.264decoderlicenseandone(1)AAC

decoderlicense.Topurchasefurtherlicenses,contactyourreseller.

Liability

Everycarehasbeentakeninthepreparationofthisdocument.Please

informyourlocalAxisofceofanyinaccuraciesoromissions.Axis

CommunicationsABcannotbeheldresponsibleforanytechnicalor

typographicalerrorsandreservestherighttomakechangestothe

productandmanualswithoutpriornotice.AxisCommunicationsAB

makesnowarrantyofanykindwithregardtothematerialcontained

withinthisdocument,including,butnotlimitedto,theimplied

warrantiesofmerchantabilityandtnessforaparticularpurpose.Axis

CommunicationsABshallnotbeliablenorresponsibleforincidentalor

consequentialdamagesinconnectionwiththefurnishing,performance

oruseofthismaterial.Thisproductisonlytobeusedforitsintended

purpose.

IntellectualPropertyRights

AxisABhasintellectualpropertyrightsrelatingtotechnologyembodied

intheproductdescribedinthisdocument.Inparticular,andwithout

limitation,theseintellectualpropertyrightsmayincludeoneormore

ofthepatentslistedatwww.axis.com/patent.htmandoneormore

additionalpatentsorpendingpatentapplicationsintheUSandother

countries.

Thisproductcontainslicensedthird-partysoftware.Seethemenuitem

“About”intheproduct’suserinterfaceformoreinformation.

ThisproductcontainssourcecodecopyrightAppleComputer,

Inc.,underthetermsofApplePublicSourceLicense2.0(see

www.opensource.apple.com/apsl).Thesourcecodeisavailablefrom

https://developer.apple.com/bonjour/

EquipmentModications

Thisequipmentmustbeinstalledandusedinstrictaccordancewiththe

instructionsgivenintheuserdocumentation.Thisequipmentcontains

nouser-serviceablecomponents.Unauthorizedequipmentchangesor

modicationswillinvalidateallapplicableregulatorycertications

andapprovals.

TrademarkAcknowledgments

AXISCOMMUNICATIONS,AXIS,ETRAX,ARTPECandVAPIXare

registeredtrademarksortrademarkapplicationsofAxisABinvarious

jurisdictions.Allothercompanynamesandproductsaretrademarksor

registeredtrademarksoftheirrespectivecompanies.

Apple,Boa,Apache,Bonjour,Ethernet,InternetExplorer,Linux,

Microsoft,Mozilla,Real,SMPTE,QuickTime,UNIX,Windows,Windows

VistaandWWWareregisteredtrademarksoftherespectiveholders.

JavaandallJava-basedtrademarksandlogosaretrademarksor

registeredtrademarksofOracleand/oritsafliates.UPnP

isa

certicationmarkoftheUPnP

ImplementersCorporation.

SD,SDHCandSDXCaretrademarksorregisteredtrademarksofSD-3C,

LLCintheUnitedStates,othercountriesorboth.Also,miniSD,microSD,

miniSDHC,microSDHC,microSDXCarealltrademarksorregistered

trademarksofSD-3C,LLCintheUnitedStates,othercountriesorboth.

RegulatoryInformation

Europe

ThisproductcomplieswiththeapplicableCEmarkingdirectives

andharmonizedstandards:

•ElectromagneticCompatibility(EMC)Directive2004/108/EC.See

ElectromagneticCompatibility(EMC),onpage2.

•LowVoltage(LVD)Directive2006/95/EC.SeeSafety,onpage2.

•RestrictionsofHazardousSubstances(RoHS)Directive2011/65/EU.

SeeDisposalandRecycling,onpage2.

Acopyoftheoriginaldeclarationofconformitymaybeobtainedfrom

AxisCommunicationsAB.SeeContactInformation,onpage3.

ElectromagneticCompatibility(EMC)

Thisequipmenthasbeendesignedandtestedtofulllapplicable

standardsfor:

•Radiofrequencyemissionwheninstalledaccordingtothe

instructionsandusedinitsintendedenvironment.

•Immunitytoelectricalandelectromagneticphenomenawhen

installedaccordingtotheinstructionsandusedinitsintended

environment.

USA

Thisequipmenthasbeentestedusingashieldednetworkcable(STP)

andfoundtocomplywiththelimitsforaClassBdigitaldevice,

pursuanttopart15oftheFCCRules.Theselimitsaredesigned

toprovidereasonableprotectionagainstharmfulinterferenceina

residentialinstallation.Thisequipmentgenerates,usesandcanradiate

radiofrequencyenergyand,ifnotinstalledandusedinaccordance

withtheinstructions,maycauseharmfulinterferencetoradio

communications.However,thereisnoguaranteethatinterference

willnotoccurinaparticularinstallation.Ifthisequipmentdoes

causeharmfulinterferencetoradioortelevisionreception,which

canbedeterminedbyturningtheequipmentoffandon,theuseris

encouragedtotrytocorrecttheinterferencebyoneormoreofthe

followingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfrom

thattowhichthereceiverisconnected.

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Canada

ThisClassBdigitalapparatuscomplieswithCanadianICES-003.

CetappareilnumériquedelaclasseBestconfomeàlanorme

NMB-003duCanada.

Europe

ThisdigitalequipmentfulllstherequirementsforRFemission

accordingtotheClassBlimitofEN55022.

Thisproductfulllstherequirementsforimmunityaccording

toEN61000-6-1residential,commercialandlight-industrial

environments.

Thisproductfulllstherequirementsforimmunityaccordingto

EN61000-6-2industrialenvironments.

Thisproductfulllstherequirementsforimmunityaccordingto

EN55024ofceandcommercialenvironments

Australia/NewZealand

ThisdigitalequipmentfulllstherequirementsforRFemission

accordingtotheClassBlimitofAS/NZSCISPR22.

Japan

この装置は、クラスB情報技術装置です。この装置は、家庭

環境で使用することを目的としていますが、この装置がラジ

オやテレビジョン受信機に近接して使用されると、受信障

害を引き起こすことがあります。取扱説明書に従って正し

い取り扱いをして下さい。

Korea

이기기는가정용(B급)전자파적합기기로서주로가정에

서사용하는것을목적으로하며,모든지역에서사용

할수있습니다.

Safety

ThisproductcomplieswithIEC/EN/UL60950-1,SafetyofInformation

TechnologyEquipment.

Thepowersupplyusedwiththisproductshallfullltherequirements

forSafetyExtraLowVoltage(SELV)andLimitedPowerSource(LPS)

accordingtoIEC/EN/UL60950-1.

DisposalandRecycling

Whenthisproducthasreachedtheendofitsusefullife,disposeof

itaccordingtolocalrawsandregulations.Forinformationabout

yournearestdesignatedcollectionpoint,contactyourlocalauthority

responsibleforwastedisposal.Inaccordancewithlocallegislation,

penaltiesmaybeapplicableforincorrectdisposalofthiswaste.

Europe

Thissymbolmeansthattheproductshallnotbedisposedof

togetherwithhouseholdorcommercialwaste.Directive2012/19/EU

onwasteelectricalandelectronicequipment(WEEE)isapplicablein

theEuropeanUnionmemberstates.Topreventpotentialharmto

humanhealthandtheenvironment,theproductmustbedisposed

ofinanapprovedandenvironmentallysaferecyclingprocess.For

informationaboutyournearestdesignatedcollectionpoint,contact

yourlocalauthorityresponsibleforwastedisposal.Businessesshould

contacttheproductsupplierforinformationabouthowtodispose

ofthisproductcorrectly.

ThisproductcomplieswiththerequirementsofDirective2011/65/EU

ontherestrictionoftheuseofcertainhazardoussubstancesin

electricalandelectronicequipment(RoHS).

China

Thisproductcomplieswiththerequirementsofthelegislative

actAdministrationontheControlofPollutionCausedbyElectronic

InformationProducts(ACPEIP).

ContactInformation

AxisCommunicationsAB

Emdalavägen14

22369Lund

Sweden

Tel:+46462721800

Fax:+4646136130

www.axis.com

Support

Shouldyourequireanytechnicalassistance,pleasecontactyourAxis

reseller.Ifyourquestionscannotbeansweredimmediately,your

resellerwillforwardyourqueriesthroughtheappropriatechannelsto

ensurearapidresponse.IfyouareconnectedtotheInternet,youcan:

•downloaduserdocumentationandsoftwareupdates

•ndanswerstoresolvedproblemsintheFAQdatabase.Search

byproduct,category,orphrase

•reportproblemstoAxissupportstaffbyloggingintoyourprivate

supportarea

•chatwithAxissupportstaff(selectedcountriesonly)

•visitAxisSupportatwww.axis.com/techsup/

LearnMore!

VisitAxislearningcenterwww.axis.com/academy/forusefultrainings,

webinars,tutorialsandguides.

AXISQ1614NetworkCamera

TableofContents

HardwareOverview..........................................6

ConnectorsandButtons..........................................6

LEDIndicators..................................................8

StatusLEDBehaviorforFocusAssistant.............................8

BuzzerSignalforFocusAssistant...................................9

StatusLEDBehaviorandBuzzerSignalforLevellingAssistant...........9

Replacingthelens...............................................9

AccessingtheProduct.......................................11

AccessfromaBrowser...........................................11

AccessfromtheInternet..........................................11

SettheRootPassword...........................................12

TheLiveViewPage..............................................13

MediaStreams.............................................16

HowtoStreamH.264............................................16

MJPEG........................................................16

AXISMediaControl(AMC)........................................16

AlternativeMethodsofAccessingtheVideoStream....................17

AccessingAudioStreams.........................................18

SettingUptheProduct......................................19

BasicSetup....................................................19

FocusAdjustment...............................................19

VideoandAudio............................................20

VideoStream...................................................20

StreamProles.................................................22

CameraSettings................................................22

ViewArea.....................................................25

Overlay........................................................25

PrivacyMask...................................................27

Focus.........................................................27

AudioSettings..................................................27

AudioClips....................................................29

LiveViewCong............................................30

PTZ(PanTiltZoom).........................................33

PresetPositions.................................................33

GuardTour.....................................................34

Advanced......................................................34

InstallingaPTZdriver............................................34

ControlQueue..................................................35

Detectors..................................................36

CameraTampering..............................................36

MotionDetection...............................................36

AudioDetection................................................38

Applications...............................................39

ApplicationLicenses.............................................39

InstallApplication...............................................39

ApplicationConsiderations........................................39

Events....................................................41

SettingUpanActionRule........................................42

Recipients.....................................................43

Schedules......................................................44

Recurrences....................................................44

Recordings.................................................46

RecordingList..................................................46

ContinuousRecording............................................46

Languages.................................................47

SystemOptions.............................................48

Security.......................................................48

Date&Time....................................................50

Network.......................................................51

Storage.......................................................56

I/OPorts.......................................................57

AXISQ1614NetworkCamera

TableofContents

Maintenance...................................................57

Support.......................................................58

Advanced......................................................59

ResettoFactoryDefaultSettings...................................59

Troubleshooting............................................61

CheckingtheFirmware...........................................61

UpgradingtheFirmware..........................................61

Symptoms,PossibleCausesandRemedialActions.....................62

TechnicalSpecications......................................66

..............................................................66

Connectors....................................................68

PerformanceConsiderations.......................................70

AXISQ1614NetworkCamera

HardwareOverview

StatusLEDindicator

Zoompuller

Focuspuller

I/Oconnector

Irisconnector

Powerconnector

PowerLEDindicator

NetworkLEDindicator

RS485/RS422connector

10.

Networkconnector(PoE)

11.

Controlbutton(1)

12.

Functionbutton(2)

13.

microSDCardslot

14.

Audioin

15.

Audioout

ConnectorsandButtons

Fortechnicalspecications,seepage66.

AXISQ1614NetworkCamera

HardwareOverview

NetworkConnector

RJ45Ethernetconnector.SupportsPoweroverEthernet(PoE).

NOTICE NOTICE

NOTICE

Theproductshallbeconnectedusingashieldednetworkcable(STP)oranopticalbercable.Allcablesconnectingthe

producttothenetworkshallbeintendedfortheirspecicuse.Makesurethatthenetworkdevicesareinstalledin

accordancewiththemanufacturer’sinstructions.Forinformationaboutregulatoryrequirements,seeElectromagnetic

Compatibility(EMC),onpage2.

I/OConnector

Usewithexternaldevicesincombinationwith,forexample,tamperingalarms,motiondetection,eventtriggering,timelapserecording

andalarmnotications.Inadditiontothe0VDCreferencepointandpower(DCoutput),theI/Oconnectorprovidestheinterfaceto:

•Digitaloutput–ForconnectingexternaldevicessuchasrelaysandLEDs.Connecteddevicescanbeactivatedbythe

VAPIX®ApplicationProgrammingInterface,outputbuttonsontheLiveViewpageorbyanActionRule.Theoutputwill

showasactive(shownunderSystemOptions>Ports&Devices)ifthealarmdeviceisactivated.

•Digitalinput–Analarminputforconnectingdevicesthatcantogglebetweenanopenandclosedcircuit,forexample:

PIRs,door/windowcontacts,glassbreakdetectors,etc.Whenasignalisreceivedthestatechangesandtheinputbecomes

active(shownunderSystemOptions>Ports&Devices).

PowerConnector

2-pinterminalblockforpowerinput.UseaSafetyExtraLowVoltage(SELV)compliantlimitedpowersource(LPS)witheitherarated

outputpowerlimitedto≤100Woraratedoutputcurrentlimitedto≤5A.

AudioConnector

TheAxisproducthasthefollowingaudioconnectors:

•Audioin(pink)–3.5mminputforamonomicrophone,oraline-inmonosignal(leftchannelisusedfromastereosignal).

•Audioout(green)–3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoran

activespeakerwithabuilt-inamplier.Astereoconnectormustbeusedforaudioout.

RS485/RS422Connector

TwoterminalblocksforRS485/RS422serialinterfaceusedtocontrolauxiliaryequipmentsuchasPTZdevices.

SDCardSlot

AmicroSDcard(notincluded)canbeusedforlocalrecordingwithremovablestorage.Formoreinformation,seeTechnical

Specications,onpage66.

NOTICE NOTICE

NOTICE

Topreventcorruptionofrecordings,theSDcardshouldbeunmountedbeforeremoval.Tounmount,gotoSetup>System

Options>Storage>SDCardandclickUnmount.

ControlButton

Thecontrolbuttonisusedfor:

•Resettingtheproducttofactorydefaultsettings.Seepage59.

•ConnectingtoanAXISVideoHostingSystemservice.Seepage52.Toconnect,pressandholdthebuttonforabout1

seconduntiltheStatusLEDashesgreen.

•ConnectingtoAXISInternetDynamicDNSService.Seepage52.Toconnect,pressandholdthebuttonforabout3seconds.

AXISQ1614NetworkCamera

HardwareOverview

FunctionButton

Thefunctionbuttonhasmultiplefunctions:

•Levellingassistant–Thisfunctionhelpstoensurethecameraislevel.Pressthebuttonforabout3secondstostartthe

levellingassistantandpressagaintostopthelevelingassistant.ThestatusLED(seepage9)andbuzzersignal(seepage

9)assistlevellingofthecamera.Thecameraislevelwhenthebuzzerbeepscontinuously.

•Focusassistant–ThisfunctionisusedforenablingtheFocusAssistant.Toenablethefocusassistant,pressandvery

quicklyreleasethebutton.Pressagaintostopthefocusassistant.Formoreinformation,seetheInstallationGuide.

LEDIndicators

LED

Color

Indication

Green

Steadyforconnectiontoa100MBit/snetwork.Flashesfornetworkactivity.

Amber

Steadyforconnectiontoa10MBit/snetwork.Flashesfornetworkactivity.

Network

UnlitNonetworkconnection.

GreenSteadygreenfornormaloperation.

Amber

Steadyduringstartupandwhenrestoringsettings.

Status

Red

Slowashforfailedupgrade.

Green

Normaloperation. Power

Amber

Flashesgreen/amberduringrmwareupgrade.

Note

•TheStatusLEDcanbeconguredtobeunlitduringnormaloperation.Tocongure,gotoSetup>SystemOptions>Ports

&Devices>LED.Seetheonlinehelpformoreinformation.

•TheStatusLEDcanbeconguredtoashwhileaneventisactive.

•TheStatusLEDcanbeconguredtoashforidentifyingtheunit.GotoSetup>SystemOptions>Maintenance.

•ThePowerLEDcanbeconguredtobeunlitduringnormaloperation.Tocongure,gotoSetup>SystemOptions>Ports

&Devices>LED.Seetheonlinehelpformoreinformation.

•TheNetworkLEDcanbedisabledsothatitdoesnotashwhenthereisnetworktrafc.Tocongure,gotoSetup>System

Options>Ports&Devices>LED.Seetheonlinehelpformoreinformation.

StatusLEDBehaviorforFocusAssistant

Color

Indication

Green

FocusAssistantisenabled

Thelensisoptimallyadjusted

AmberThecamerahasbeenmoved,oranobjecthasbeeninsertedinfrontofthelens.Exitandrestartthe

FocusAssistant.

Thelensislessoptimallyadjusted.

RedThecamerahasbeenmoved,oranobjecthasbeeninsertedinfrontofthelens.Exitandrestartthe

FocusAssistant.

Thelensispoorlyadjusted.

AXISQ1614NetworkCamera

HardwareOverview

BuzzerSignalforFocusAssistant

BuzzerLens

Fastinterval

Optimallyadjusted

MediumintervalLessoptimallyadjusted

Slowinterval

Poorlyadjusted

StatusLEDBehaviorandBuzzerSignalforLevellingAssistant

ForinformationontheFunctionbuttonusedforlevellingthecamera,seeConnectorsandButtons.

Color

Buzzer

Cameraposition

Fixedgreen

Continuousbeep

Level

FlashinggreenFastintervalAlmostlevel

FlashingorangeMediumintervalNotlevel

Flashingred

Slowinterval

Farfromlevel

Replacingthelens

ItispossibletouseoptionallensesfortheAxisproduct.

Toreplacethelens:

1.Disconnecttheiriscable.

2.Unscrewthestandardlens.

3.Attachandscrewonthenewlens.

Note

ThereisnoneedtorestarttheAxisproductafterchangingthelens.However,theproductmustberestartedifyouare

interchangingbetweenaP-iris,DC-Irisorxed/manualirislens.Inordertosetthefocusandpositionthelens,theAxis

productmustbeconnectedtothenetwork.

Tochangetheirisconguration:

1.GotoSetup>VideoandAudio>CameraSettings.Iriscongurationshowsthecurrentcongurediristype.

2.ClickEdit.

3.Selecttheinstalledirislensfromthedrop-downlistandclickOK.

AXISQ1614NetworkCamera

HardwareOverview

Note

ForP-irislensesnotlistedinthedrop-downlist,downloadtheiriscongurationlefromwww.axis.com

Touploadandusethedownloadedcongurationle,clicktheUploadtab.ClickBrowseandselectthecongurationle.

ClickUpload.TheinstalledirislensshouldnowbeincludedintheIrisSelectiondrop-downlist,selectitandpressOK.If

youselectaDCiriscongurationleforaP-irislens,anerrormessagewillappearbelowtheiriscongurationtypeinthe

CameraSettingspage.ForcustomDCIrislenses,selectGenericDCIrisoption.

AXISQ1614NetworkCamera

AccessingtheProduct

ToinstalltheAxisproduct,refertotheInstallationGuidesuppliedwiththeproduct.

Theproductcanbeusedwithmostoperatingsystemsandbrowsers.TherecommendedbrowsersareInternetExplorerwithWindows,

SafariwithMacintoshandFirefoxwithotheroperatingsystems.SeeTechnicalSpecications,onpage66.

ToviewstreamingvideoinInternetExplorer,allowinstallationofAXISMediaControl(AMC)whenprompted.

Note

•QuickTime

isalsosupportedforviewingH.264streamsandforaudio.

•Ifyourcomputerrestrictstheuseofadditionalsoftwarecomponents,theproductcanbeconguredtouseaJavaapplet

forviewingMotionJPEG.

AccessfromaBrowser

1.Startabrowser(InternetExplorer,Firefox,Safari).

2.EntertheIPaddressorhostnameoftheAxisproductinthebrowser’sLocation/Addresseld.Toaccesstheproductfroma

Macintoshcomputer(MacOSX),clickontheBonjourtabandselecttheproductfromthedrop-downlist.

IfyoudonotknowtheIPaddress,useAXISIPUtilitytolocatetheproductonthenetwork.Forinformationabouthowto

discoverandassignanIPaddress,seetheInstallationandManagementSoftwareCDorthedocumentAssignanIPAddress

andAccesstheVideoStreamonAxisSupportwebatwww.axis.com/techsup

3.Enteryourusernameandpassword.Ifthisisthersttimetheproductisaccessed,therootpasswordmustrstbe

congured.Forinstructions,seeSettheRootPassword,onpage12.

4.Theproduct’sLiveViewpageopensinyourbrowser.

Note

ThecontrolsandlayoutoftheLiveViewpagemayhavebeencustomizedtomeetspecicinstallationrequirementsand

userpreferences.Consequently,someoftheexamplesandfunctionsfeaturedheremaydifferfromthosedisplayedin

yourownLiveViewpage.

AccessfromtheInternet

Onceconnected,theAxisproductisaccessibleonyourlocalnetwork(LAN).ToaccesstheproductfromtheInternetyoumust

congureyournetworkroutertoallowincomingdatatrafctotheproduct.Todothis,enabletheNAT-traversalfeature,which

willattempttoautomaticallyconguretheroutertoallowaccesstotheproduct.ThisisenabledfromSetup>SystemOptions>

Network>TCP/IPAdvanced.

AXISQ1614NetworkCamera

AccessingtheProduct

Formoreinformation,seeNATtraversal(portmapping)forIPv4,onpage53.SeealsoAXISInternetDynamicDNSService

atwww.axiscam.net

ForTechnicalnotesonthisandothertopics,visittheAxisSupportwebatwww.axis.com/techsup

SettheRootPassword

ToaccesstheAxisproduct,youmustsetthepasswordforthedefaultadministratoruserroot.ThisisdoneintheCongureRoot

Passworddialog,whichopenswhentheproductisaccessedforthersttime.

Topreventnetworkeavesdropping,therootpasswordcanbesetviaanencryptedHTTPSconnection,whichrequiresanHTTPS

certicate.HTTPS(HypertextTransferProtocoloverSSL)isaprotocolusedtoencrypttrafcbetweenwebbrowsersandservers.The

HTTPScerticateensuresencryptedexchangeofinformation.SeeHTTPS,onpage48.

Thedefaultadministratorusernamerootispermanentandcannotbedeleted.Ifthepasswordforrootislost,theproductmustbe

resettothefactorydefaultsettings.SeeResettoFactoryDefaultSettings,onpage59.

TosetthepasswordviaastandardHTTPconnection,enteritdirectlyinthedialog.

TosetthepasswordviaanencryptedHTTPSconnection,followthesesteps:

1.ClickUseHTTPS.

Atemporarycerticate(validforoneyear)iscreated,enablingencryptionofalltrafctoandfromtheproduct,andthe

passwordcannowbesetsecurely.

2.Enterapasswordandthenre-enterittoconrmthespelling.

3.ClickOK.Thepasswordhasnowbeencongured.

PTZMode

PTZmodeissetthersttimetheAxisproductisaccessedandcanonlybechangedbyresettingtheproducttofactorydefault.

DigitalPTZisthedefaultmodeandshouldbeusedwhenapan/tiltmotorisnotused.

Ifthecameraismountedtoapan/tiltmotor,selectUploadablePTZdriver.ForinformationabouthowtouploadaPTZdriver,

seeInstallingaPTZdriver,onpage34.

CongureCaptureMode

CapturemodedenesthemaximumresolutionandmaximumframerateavailableintheAxisproduct.Thecapturemodesettingalso

affectsthecamera’sangleofview.

Selectthedesiredcapturemodefromthedrop-downlistandclickOK.

SeealsoCaptureMode,onpage22.

SetPowerLineFrequency

PowerlinefrequencyissetthersttimetheAxisproductisaccessedandcanonlybechangedfromPlainCong(seepage59)

orbyresettingtheproducttofactorydefault.

Selectthepowerlinefrequency(50Hzor60Hz)usedatthelocationoftheAxisproduct.Selectingthewrongfrequencymaycause

imageickeriftheproductisusedinuorescentlightenvironments.

Note

Powerlinefrequencyvariesdependingongeographicregion.TheAmericasusuallyuse60Hz,whereasmostotherpartsof

theworlduse50Hz.Localvariationscouldapply.Alwayscheckwiththelocalauthorities.

AXISQ1614NetworkCamera

AccessingtheProduct

TheLiveViewPage

ThecontrolsandlayoutoftheLiveViewpagemayhavebeencustomizedtomeetspecicinstallationrequirementsanduser

preferences.Consequently,someoftheexamplesandfunctionsfeaturedheremaydifferfromthosedisplayedinyourownLiveView

page.Thefollowingprovidesanoverviewofeachavailablecontrol.

ControlsontheLiveViewPage

ClickViewsizetoscaletheimagedownto800pixelswideortofullscale.OnlyavailableinMJPEG.

ClickWDRontoenableWDRinintensebacklightconditions.Readmoreaboutwidedynamicrangeonpage23.

ClickLightnderModetoenablethismode.ReadmoreaboutLightnderonpage23.

SelectastreamprolefortheLiveViewpagefromtheStreamProledrop-downlist.Forinformationabouthow

tocongurestreamproles,seepage22.

ClickPulsetoactivatetheproduct’soutputportforadenedperiodoftime.Forinformationabouthowtoenable

andcongureoutputbuttons,seepage31.

ClicktheActive/Inactivebuttonstomanuallyactivateandinactivetheproduct’soutputport.Forinformation

abouthowtoenableandcongureoutputbuttons,seepage31.

TheManualTriggerbuttonisusedtotriggeranactionrulefromtheLiveViewpage.Forinformationabouthowto

congureandenablethebutton,seeManualTrigger,onpage13.

ClickSnapshottosaveasnapshotofthevideoimage.Right-clickthevideoimagetosaveitinJPEGformatonyour

computer.ThisbuttonisprimarilyintendedforusewhentheAXISMediaControlviewertoolbarisnotavailable.

EnablethisbuttonfromLiveViewCong>ActionButtons.

TheAudioclipdrop-downlistallowsyoutoplayanaudioclipfromtheLiveViewpage.Selecttheaudio

clipandclickthePlaybutton.

ManualTrigger

TheManualTriggerisusedtotriggeranactionrulefromtheLiveViewpage.Themanualtriggercanforexamplebeusedto

validateactionsduringproductinstallationandconguration.

Tocongurethemanualtrigger:

1.GotoSetup>Events.

2.ClickAddtoaddanewactionrule.

3.FromtheTriggerdrop-downlist,selectInputSignal.

4.Fromtheseconddrop-downlist,selectManualTrigger.

5.Selectthedesiredactionandconguretheothersettingsasrequired.

Formoreinformationaboutactionrules,seeEvents,onpage41.

AXISQ1614NetworkCamera

AccessingtheProduct

ToshowthemanualtriggerbuttonsintheLiveViewpage:

1.GotoSetup>LiveViewLayout.

2.UnderActionButtons,selectShowmanualtriggerbutton.

AXISMediaControlviewertoolbar

TheAXISMediaControlviewertoolbarisavailableinInternetExploreronly.SeeAXISMediaControl(AMC),onpage16formore

information.Thetoolbardisplaysthefollowingbuttons:

ThePlaybuttonconnectstotheAxisproductandstartsplayingamediastream.

TheStopbuttonstopsthemediastream.

TheSnapshotbuttontakesasnapshotofthevideoimage.Thelocationwheretheimageissavedcanbespecied

intheAMCControlPanel.

ClicktheViewFullScreenbuttonandthevideoimagewilllltheentirescreen.PressESC(Escape)onthecomputer

keyboardtocancelfullscreenview.

TheRecordbuttonisusedtorecordthecurrentvideostream.Thelocationwheretherecordingissavedcanbespeciedin

theAMCControlPanel.EnablethisbuttonfromLiveViewCong>ViewerSettings.

AMCAudioControls

AMCaudiobuttonscontrolthespeakersandmicrophoneconnectedtotheclientcomputer.Thebuttonsareonlyvisiblewhen

audioisenabled.

Speakerbutton—Clicktoturnthespeakersonoroff.

Microphonebutton–Clicktomuteorunmutethemicrophone.InSimplex-speakeronlymode,theMicrophoneandTalk

buttonsmustbothbeactivetosendaudiototheAxisproduct.Clickeitherbuttontostopaudiotransmission.

Usetheslidertocontrolthevolumeofthespeakersandthemicrophone.

Half-duplexmode

TheTalk/Listenbuttonisusedtoswitchbetweensendingandreceivingaudio.Thebuttoncanbecongured

fromtheAudiotabintheAMCControlpanel:

•Push-To-Talkmode:Clickandholdthebuttontotalk/send.Releasethebuttontolisten.

•Togglemode:Clickoncetoswitchbetweentalkingandlistening.

Simplex–speakeronlymode

Tosendaudio,theTalkandMicrophonebuttonsmustbothbeactive.Clickeitherbuttontostopaudio

transmission.

PTZControls

TheLiveViewpagealsodisplaysPan/Tilt/Zoom(PTZ)controls.Theadministratorcanenable/disablecontrolsforspeciedusersunder

SystemOptions>Security>Users.

Note

ThesecontrolsareavailableifdigitalPTZisenabledintheselectedviewareaorifaPTZdriverhasbeenuploaded.Formore

informationonviewareas,seeViewArea,onpage25.Formoreinformationonhowtouploadadriver,seeInstallingaPTZ

driver,onpage34.ToswitchbetweenthetwooptionsseePTZMode,onpage12.

AXISQ1614NetworkCamera

AccessingtheProduct

WiththePTZControlQueueenabledthetimeeachuserisincontrolofthePTZsettingsislimited.Clickthebuttonstorequestor

releasecontrolofthePTZcontrols.ThePTZControlQueueissetupunderPTZ>ControlQueue.

ClicktheEmulatejoystickmodebuttonandclickintheimagetomovethecameraviewinthedirectionofthe

mousepointer.

ClicktheCentermodebuttonandclickintheimagetocenterthecameraviewonthatposition.Thecentermode

buttoncouldalsobeusedtozoominonaspecicarea.Clickintheimageanddragtodrawarectanglesurrounding

theareatobemagnied.Tozoomout,rotatethemousewheel.

ClicktheCtrlpanelbuttontoopenthePTZcontrolpanelwhichprovidesadditionalPTZcontrols.

User-denedbuttonscanalsoappearintheControlpanel.SeeControls,onpage34.

SelectaPTZpresetpositiontosteerthecameraviewtothesavedposition.SeePresetPositions,

onpage33.

ClickingZoomouttooverviewimagewillsetthecameratotheminimumzoomposition.Inthisposition,thecamera

cannotpanortilt.

ThePTZcontrolscanbedisabledunderPTZ>Advanced>Controls,seeControls,onpage34.

AXISQ1614NetworkCamera

MediaStreams

TheAxisproductprovidesseveralaudioandvideostreamformats.Yourrequirementsandthepropertiesofyournetworkwill

determinethetypeyouuse.

TheLiveViewpageintheproductprovidesaccesstoH.264andMotionJPEGvideostreams,audiostreamsandtothelistofavailable

streamproles.Otherapplicationsandclientscanaccessvideoandaudiostreamsdirectly,withoutgoingviatheLiveViewpage.

HowtoStreamH.264

ThevideocompressionstandardH.264makesgooduseofbandwidth,andcanprovidehighqualityvideostreamsatlessthan1Mbit/s.

Decidingwhichcombinationofprotocolsandmethodstousedependsonyourviewingrequirements,andonthepropertiesof

yournetwork.TheavailableoptionsinAXISMediaControlare:

UnicastRTP

Thisunicastmethod(RTPoverUDP)isused

forliveunicastvideo,especiallywhenitis

importanttoalwayshaveanup-to-datevideo

stream,evenifsomeimagesaredropped.

RTPoverRTSP

Thisunicastmethod(RTPtunneledoverRTSP)

isusefulasitisrelativelysimpletocongure

rewallstoallowRTSPtrafc.

RTPoverRTSPoverHTTP

Thisunicastmethodcanbeusedtotraverse

rewalls.Firewallsarecommonlyconguredto

allowtheHTTPprotocol,thusallowingRTPto

betunneled.

Unicastingisusedforvideo-on-demand

transmissionsothatthereisnovideotrafc

onthenetworkuntilaclientconnectsand

requeststhestream.

Notethatthereareamaximumof20

simultaneousunicastconnections.

MulticastRTP

Thismethod(RTPoverUDP)shouldbeusedforlivemulticastvideo.Thevideostreamisalways

up-to-date,evenifsomeimagesaredropped.

Multicastingprovidesthemostefcientusageofbandwidthwhentherearelargenumbersof

clientsviewingsimultaneously.Amulticastcannothowever,passanetworkrouterunlessthe

routerisconguredtoallowthis.ItisnotpossibletomulticastovertheInternet,forexample.

Notealsothatallmulticastviewerscountasoneunicastviewerinthemaximumtotalof20

simultaneousconnections.

AXISMediaControlnegotiateswiththeAxisproducttodeterminethetransportprotocoltouse.Theorderofpriority,listedinthe

AMCControlPanel,canbechangedandtheoptionsdisabled,tosuitspecicrequirements.

Note

H.264islicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Installingadditionalunlicensed

copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

MJPEG

ThisformatusesstandardJPEGstillimagesforthevideostream.Theseimagesarethendisplayedandupdatedataratesufcient

tocreateastreamthatshowsconstantlyupdatedmotion.

TheMotionJPEGstreamusesconsiderableamountsofbandwidth,butprovidesexcellentimagequalityandaccesstoeveryimage

containedinthestream.TherecommendedmethodofaccessingMotionJPEGlivevideofromtheAxisproductistousetheAXIS

MediaControlinInternetExplorerinWindows.

AXISMediaControl(AMC)

AXISMediaControl(AMC)inInternetExplorerinWindowsistherecommendedmethodofaccessinglivevideofromtheAxisproduct.

AXISQ1614NetworkCamera

MediaStreams

TheAMCControlPanelcanbeusedtocongurevariousvideoandaudiosettings.PleaseseetheAXISMediaControlUser’s

Manualformoreinformation.

TheAMCControlPanelisautomaticallyinstalledonrstuse,afterwhichitcanbecongured.OpentheAMCControlPanelfrom:

•WindowsControlPanel(fromtheStartmenu)

•Alternatively,right-clickthevideoimageinInternetExplorerandclickSettings.

AlternativeMethodsofAccessingtheVideoStream

YoucanalsoaccessvideoandimagesfromtheAxisproductinthefollowingways:

•MotionJPEGserverpush(ifsupportedbytheclient,Firefox,forexample).ThisoptionmaintainsanopenHTTPconnection

tothebrowserandsendsdataasandwhenrequired,foraslongasrequired.

•StillJPEGimagesinabrowser.Enterthepathhttp://<ip>/axis-cgi/jpg/image.cgi

•WindowsMediaPlayer.ThisrequiresAXISMediaControlandtheH.264decodertobeinstalled.Thefollowingpaths

canbeused:

-UnicastviaRTP:axrtpu://<ip>/axis-media/media.amp

-UnicastviaRTSP:axrtsp://<ip>/axis-media/media.amp

-UnicastviaRTSP,tunneledviaHTTP:axrtsphttp://<ip>/axis-media/media.amp

-Multicast:axrtpm://<ip>/axis-media/media.amp

•QuickTime

.Thefollowingpathscanbeused:

-rtsp://<ip>/axis-media/media.amp

-rtsp://<ip>/axis-media/media.3gp

AXISQ1614NetworkCamera

MediaStreams

Note

•<ip>=IPaddess

•TheAxisproductsupportsQuickTime6.5.1andlater.

•QuickTimeaddslatencytothevideostream.

•ItmaybepossibletouseotherplayerstoviewtheH.264streamusingthepathsabove,althoughAxisdoesnotguarantee

this.

AccessingAudioStreams

TheLiveViewpageprovidesaccesstoaudiothroughAXISMediaControl;inadditionaudiocanbeaccessedinthefollowingways:

•VAPIX®ApplicationProgrammingInterface(API)Formoreinformation,visitwww.axis.com/developer

•WindowsMediaPlayersupportssimplexaudio.Thefollowingpathscanbeused:

-UnicastviaRTP:axrtpu://<ip>/axis-media/media.amp

-UnicastviaRTSP:axrtsp://<ip>/axis-media/media.amp

-UnicastviaRTSP,tunneledviaHTTP:axrtsphttp://<ip>/axis-media/media.amp

-Multicast:axrtpm://<ip>/axis-media/media.amp

•QuickTime

supportsG.711andAACaudioencoding.Thefollowingpathscanbeused:

-rtsp://<ip>/axis-media/media.amp

-rtsp://<ip>/axis-media/media.3gp

•TheJavaappletsupportssimplexaudiowithG.711encoding.

AXISQ1614NetworkCamera

SettingUptheProduct

TheAxisproductcanbeconguredbyuserswithadministratororoperatorrights.Toopentheproduct’sSetuppages,clickSetupin

thetopright-handcorneroftheLiveViewpage.

•Administratorshaveunrestrictedaccesstoallsettings.

•OperatorshaveaccesstoallsettingsexceptSystemOptions

Seealsotheonlinehelp

BasicSetup

BasicSetupprovidesshortcutstothesettingsthatshouldbemadebeforeusingtheAxisproduct:

1.Users.Seepage48.

2.TCP/IP.Seepage51.

3.Date&Time.Seepage50.

4.VideoStream.Seepage20.

5.Focus.Seepage27

6.AudioSettings.Seepage27.

TheBasicSetupmenucanbedisabledfromSystemOptions>Security>Users.

FocusAdjustment

ThefocuscanbeadjustedunderBasicSetup>Focus.Followtheon-screeninstructionstoadjustthefocus.Forfurtherinformation

aboutfocus,refertotheproduct’sInstallationGuide.

AXISQ1614NetworkCamera

VideoandAudio

Thevideoandaudiosettingscanbeusedtooptimizevideoandaudioquality.Youcancongurethefollowing:

•Videostreamsettings.Seepage20.

•Streamproles.Seepage22.

•Camerasettings.Seepage22.

•Viewarea.Seepage25.

•Overlayimage.Seepage25.

•Privacymask.Seepage27.

•Focus.Seepage27.

•Audiosettings.Seepage27.

•Audioclips.Seepage29.

VideoStream

YoucandenethefollowingvideostreamsettingsfromVideo&Audio>VideoStream:

•Image.Seepage21.

•Audio.Seepage27.

•H.264.Seepage21.

•MJPEG.Seepage21.

AXISQ1614NetworkCamera

VideoandAudio

PixelCounter

Thepixelcountershowsthenumberofpixelsinanareaoftheimage.Thepixelcounterisusefulinsituationswherethereisa

requirementthattheimageisacertainsize,forexampleinfacerecognition.

Thepixelcountercanbeaccessedfrom:

•Video&Audio>VideoStream.UnderPreview,clickOpenandselecttheShowpixelcounteroptiontoenablethe

rectangleintheimage.Usethemousetomoveandresizetherectangle,orenterthenumberofpixelsintheWidth

andHeighteldsandclickApply.

•Video&Audio>Focus.SelecttheShowpixelcounteroptiontoenabletherectangleintheimage.Usethemouseto

moveandresizetherectangle,orenterthenumberofpixelsintheWidthandHeighteldsandclickApply.

•TheLiveViewpageinInternetExplorerinWindows.Right-clickintheimageandselectPixelcounter.Usethemouse

tomoveandresizetherectangle.


ThedefaultimagesettingscanbeconguredunderVideo&Audio>VideoStream.SelecttheImagetab.

Thefollowingsettingsareavailable:

•Resolution.Selectthedefaultresolution.

•Compression.Thecompressionlevelaffectstheimagequality,bandwidthandlesizeofsavedimages;thelowerthe

compression,thehighertheimagequalitywithhigherbandwidthrequirementsandlargerlesizes.

•Rotateimage.Ifrequired,theimagecanberotated.

•Mirror.Ifrequired,theimagecanbemirrored.

•Maximumframerate.Toavoidbandwidthproblems,theframerateallowedtoeachviewercanbeLimitedtoaxed

amount.Alternatively,theframeratecanbesetasUnlimited,whichmeanstheAxisproductalwaysdeliversthehighest

frameratepossibleunderthecurrentconditions.

•Overlaysettings.SeeOverlay,onpage25.

ClickSavetoapplythenewsettings.

H.264

H.264,alsoknownasMPEG-4Part10/AVC,isavideocompressionstandardthatprovideshighqualityvideostreamsatlowbitrates.

AnH.264videostreamconsistsofdifferenttypesofframessuchasI-framesandP-frames.AnI-frameisacompleteimagewhereas

P-framesonlycontainthedifferencesfrompreviousframes.

TheGOVlengthisthenumberofframesbetweentwoconsecutiveI-frames.IncreasingtheGOVlengthmaysaveconsiderablyon

bandwidthrequirementsinsomecases,butmayalsohaveanadverseaffectonimagequality.

ThebitratecanbesetasVariableBitRate(VBR)orConstantBitRate(CBR).VBRadjuststhebitrateaccordingtotheimage

complexity,usingupmorebandwidthforincreasedactivityintheimage,andlessforlowerimageactivity.CBRallowsyoutoseta

xedTargetbitratethatconsumesapredictableamountofbandwidth.Asthebitratewouldusuallyneedtoincreaseforincreased

imageactivity,butinthiscasecannot,framerateandimagequalityareaffectednegatively.Topartlycompensateforthis,itis

possibletoprioritizeeitherframerateorimagequality.Notsettingaprioritymeansthatframerateandimagequalityareequally

affected.Youmustsaveyoursettingsbeforetheycantakeeffect.

Thecurrentbitratecanbesettoappearastextoverlay.Todothis,selecttheIncludetextcheckboxoptionunderOverlay

Settingsandenterthemodier#bintheeld.

MJPEG

Sometimestheimagesizeislargeduetolowlightorcomplexscenery.Adjustingthemaximumframesizehelpstocontrolthe

bandwidthandstorageusedbytheMotionJPEGvideostreaminthesesituations.SettingtheframesizetotheDefaultsetting

AXISQ1614NetworkCamera

VideoandAudio

providesconsistentlygoodimagequalityattheexpenseofincreasedbandwidthandstorageusageinlowlight.Limitingtheframe

sizeoptimizesbandwidthandstorageusage,butmaygivepoorimagequality.Topreventincreasedbandwidthandstorageusage,

themaximumframesizeshouldbesettoanoptimalvalue.

StreamProles

Astreamproleisasetofpredenedstreamsettingsincludingresolution,compression,framerateandoverlaysettings.Stream

prolescanbeused:

•Whensettinguprecordingusingactionrules.SeeEvents,onpage41.

•Whensettingupcontinuousrecording.SeeContinuousRecording,onpage46.

•IntheLiveViewpage–selectthestreamprolefromtheStreamproledrop-downlist.

Forquicksetup,useoneofthepredenedstreamproles.Eachpredenedprolehasadescriptivename,indicatingitspurpose.If

required,thepredenedstreamprolescanbemodiedandnewcustomizedstreamprolescanbecreated.

Tocreateanewproleormodifyanexistingprole,gotoSetup>Video&Audio>StreamProles.

ToselectadefaultstreamprolefortheLiveViewpage,gotoSetup>LiveViewCong.

CameraSettings

TheVideo&Audio>CameraSettingspageprovidesaccesstoadvancedimagesettingsfortheAxisproduct.

CaptureMode

CapturemodedenesthemaximumresolutionandmaximumframerateavailableintheAxisproduct.Acapturemodewithalarge

maximumresolutionhasareducedmaximumframerateandviceversa.

Thecapturemodesettingalsoaffectsthecamera’sangleofviewastheeffectivesizeoftheimagesensordiffersbetweencapture

modes.

Capturemodeissetthersttimetheproductisaccessed.SelectthedesiredcapturemodeandclickOK.

Changingcapturemodewhentheproducthasbeenconguredisnotrecommendedasmostothersettingswillbeeitherremoved

orreset,forexample:

1.GotoSetup>Video&Audio>CameraSettings.

2.Selectthenewcapturemode.

3.ClickSave.

4.Reviewandrecongureallsettings,forexample:

-Viewarea

-Streamproles

-PTZsettingsincludingpresetpositionsandguardtours

-Gatekeeper

-Motiondetectionwindows

-Privacymasks

-Imageoverlays

-Exposurezones

AXISQ1614NetworkCamera

VideoandAudio

-Whitebalancewindows

-Actionrules

-Settingsinuploadedapplications

ImageAppearance

IncreasingtheColorlevelincreasesthecolorsaturation.Thevalue100givesmaximumcolorsaturation.Thevalue0givesa

blackandwhiteimage.

TheimageBrightnesscanbeadjustedintherange0–100,whereahighervalueproducesabrighterimage.

IncreasingtheSharpnesscanincreasebandwidthusage.Asharperimagemightincreaseimagenoiseespeciallyinlowlight

conditions.Alowersettingreducesimagenoise,butthewholeimagewillappearlesssharp.

TheContrastchangestherelativedifferencebetweenlightanddark.Itcanbeadjustedusingtheslidebar.

WhiteBalance

Whitebalanceisusedtomakecolorsintheimageappearthesameregardlessofthecolortemperatureofthelightsource.TheAxis

productcanbesettoautomaticallyidentifythelightsourceandcompensateforitscolor.Alternatively,selectthetypeoflight

sourcefromthedrop-downlist.Foradescriptionofeachavailablesetting,seetheonlinehelp

ThewhitebalancewindowisenabledfortheAutomaticandAutomaticoutdooroptionsthatappearintheWhitebalancedrop-down

list.Selectoneoftheoptionsfromthedrop-downlisttosetthewhitebalancewindowproperties.SelectAutomatictousethe

defaultsettingsfortheAutomaticandAutomaticoutdooroptions(intheWhitebalancedrop-downlist).SelectCustomtomanually

setareferencewindowforwhitebalanceintheviewarea.

WideDynamicRange

Widedynamicrange(WDR-DynamicCapture)canimprovetheexposurewhenthereisaconsiderablecontrastbetweenlightand

darkareasintheimage.EnableWDRinintensebacklightconditions.DisableWDRinlowlightconditionsforoptimalexposure.

Important

UseWDRincombinationwithautomaticexposurecontrol.Otherexposuresettingscouldgiveundesirableresults.

UsetheHighlightsrecoveryslidertoimprovetheimageappearancebydecreasingbrightnessinthebrightpartsoftheimage.

UsetheShadowsrecoveryslidertoimprovetheimageappearancebyincreasingbrightnessinthedarkpartsoftheimage.

LightnderMode

SelecttheLightnderModeoptionfromthedrop-downlistfromCameraSettings>WideDynamicRange.Thismodeenables

heightenedvisibilityintheproduct,andbetterimagequalityinlowlightconditionssuchasinparkinglots,citysurveillance

andconstructionsites.

ExposureSettings

Conguretheexposuresettingstosuittheimagequalityrequirementsinrelationtolighting,framerateandbandwidth

considerations.

Exposurevalue-Clickinthebartone-tunetheexposure.

Exposurecontrol-Thesesettingsisusedtoadapttotheamountoflightused.Automaticisthedefaultsettingscanbeusedinmost

situations.Theshutterspeedisautomaticallysettoproduceoptimumimagequality.Flicker-free50or60Hzisusedtoremove

ickerwhichcanbecausedbyuorescentandotherlightsources.TheHoldcurrentoptionlocksthecurrentexposuresettings.

EnableBacklightcompensation-Enablethisoptionifabrightspotoflight,forexamplealightbulb,causesotherareasin

theimagetoappeartoodark.

AXISQ1614NetworkCamera

VideoandAudio

Exposurezones-Thissettingsdetermineswhichpartoftheimageisusedtocalculatetheexposure.Formostsituations,theAuto

settingcanbeused.Forparticularrequirement,selectapredenedarea.

Shutter&Gain

Theshutterandgainsettingsaffecttheamountofmotionblurandnoiseintheimage.Toadapttodifferentlighting,available

storagespaceandbandwidth,itisoftennecessarytoprioritizeeitherlowmotionblurorlownoise.TheAxisproductallows

usingdifferentprioritizationinnormallightandinlowlight.

Shutterspeedisrelatedtotheamountoftimetheshutterisopenedandismeasuredinseconds(s).Aslowshutterspeedallows

morelighttoreachthesensorandcanhelpproduceabrighterimageinlowlightsituations.Ontheotherhand,aslowshutter

speedcancausemovingobjectstoappearblurry.

SetShutterto

•Autotosettheshutterspeedautomatically.Ifrequired,useMaxshuttertolimittheshutterspeedtopreventtheframe

ratefrombeingreduced.Forexample,toget30fps,setMaxshutterto1/30.

•Fixedtouseaxedshutterspeed.

Gain,measuredindecibel(dB),istheamountofamplicationappliedtotheimage.Ahighgainmayprovideabetterimageinlow

lightsituationsbutwillincreasetheamountofimagenoise.

SetGainto

•Autotosetthegainautomatically.Ifrequired,useMaxgaintolimittheappliedgain.

•Fixedtouseaxedgain.

WhenShutterandGainarebothsettoAuto,itispossibletosetthePrioritybetweenlowmotionblurandlownoisemanuallyandto

useadifferentPriorityinNormalLightandinLowLight.

Example

Consideranareawherepeopleorvehiclesmoveduringtheday,butwherethereshouldbenomovementsduringnight.Tobeableto,

forexample,recognizefacesorlicenseplates,movethenormallightpriorityslidertowardlowmotionblur.Atnighttime,motion

detectionismoreimportantthanidentication.Motionblurisacceptableandsincelowlightcancausealotofnoise,move

thelowlightpriorityslidertowardlownoise.

Example

Ifstoragespaceorbandwidthislimited,tryusingalowergain.Thiswillreduceimagenoiseandproducesmallerimageles.

Irisconguration

Iriscongurationshowsthecurrentcongurediristype.Donotchangetheiriscongurationunlessthelenshasbeenchanged,

seeReplacingthelens,onpage9.

Irisadjustment

SelectEnableautomaticirisadjustmenttoautomaticallycompensateforchanginglightconditions.Thisoptionisnotavailable

ifaxedirisisused.

UsetheIrisadjustmentslidertosetthepreferredF-value.Thescalerepresentstheamounttheirisisopen.Ifsetto0,theiris

isopenedasmuchaspossible.Ifsetto100,theirisisclosedasmuchaspossible.TheactualF-valueisshownbelowthe

slider.Ifautomaticirisadjustmentisenabled,theiriswillstayatthispositionaslongaslightconditionsarefavorable.Iflight

conditionschange,theiriswilladjustitselftothebestirissettings.Ifautomaticirisadjustmentisdisabled,theiriswilllockon

thesetpositionregardlessoflightconditions

AXISQ1614NetworkCamera

VideoandAudio

Day/Night

TheIRcutlterpreventsinfrared(IR)lightfromreachingtheimagesensor.Inpoorlightingconditions,forexampleatnight,orwhen

usinganexternalIRlamp,settheIRcutltertoOff.Thisincreaseslightsensitivityandallowstheproductto“see”infraredlight.The

imageisshowninblackandwhitewhentheIRcutlterisoff.

IfusingautomaticExposurecontrol,settheIRcutltertoAutotoautomaticallyswitchbetweenOnandOffaccordingtothe

lightingconditions.

TheDay/Nightshiftlevelbarhelpsdeterminewhenthecamerawillshiftfromdaymodetonightmode.Normally,thecamera

automaticallychangesmodefromdaytonightwhenverydark(level100intheslider).BysettingDay/Nightshiftleveltoa

lowervalue,thecamerawillchangetonightmodeearlier.

ViewArea

Note

ThisfeatureisavailableonlyifdigitalPTZwasselectedwhenconguringtheproductforthersttimeorafterresetting

tofactorydefault.

Aviewareaisacroppedpartofthefullview.TheviewareaistreatedasavideosourceinLiveViewandhasitsownvideo

streamandPTZsettings.

Whensettingupaviewareaitisrecommendedthatthevideostreamresolutionisthesamesizeasorsmallerthantheviewarea

size.Settingthevideostreamresolutionlargerthantheviewareasizeimpliesdigitallyscaledupvideoaftersensorcapture,

requiringmorebandwidthwithoutaddingimageinformation.

Toenable,gotoVideo&Audio>CameraSettingsandselectEnableViewArea.

Toconguretheviewarea:

1.GotoVideo&Audio>ViewArea.

2.SelectanAspectratioandaVideostreamresolution.

3.Usethemousetomoveandresizetheviewarea.

4.SelectEnablePTZtoenabledigitalPTZfortheviewarea.

5.ClickSavetosavethesettings.

Note

ThePTZfunctionalityisusefulduringinstallationoftheAxisproduct.Useaviewareatocropoutaspecicpartofthe

fullview.

Overlay

Overlaysareusedtoprovideextrainformation,forexampleforforensicvideoanalysisorduringproductinstallationand

conguration.Overlaysaresuperimposedoverthevideostream.

Anoverlaytextcandisplaythecurrentdateandtime,oratextstring.Whenusingatextstring,modierscanbeusedtodisplay

informationsuchasthecurrentbitrateorthecurrentframerate.Forinformationaboutavailablemodiers,seeFileNaming&

Date/TimeFormatsintheonlinehelp.

Itisalsopossibletodisplaytextwhenanactionruleistriggered,seeUsingOverlayTextinanActionRule.

Toenableoverlays:

1.GotoVideo&Audio>VideoStreamandselecttheImagetab.

2.Toincludeanoverlayimage,selectIncludeoverlayimageatthecoordinates.Theoverlayimagemustrstbeuploadedto

theAxisproduct,seeOverlayImage.

AXISQ1614NetworkCamera

VideoandAudio

3.Toincludedateandtime,selectIncludedateandIncludetime.

4.Toincludeatextstring,selectIncludetextandenterthetextintheeld.Modierscanbeused,seeFileNaming&

Date/TimeFormatsintheonlinehelp

5.Denetextoverlaycharacteristicsintherelevantelds.

6.ClickSave.

Tomodifythedateandtimeformat,gotoSystemOptions>Date&Time.SeeDate&Time,onpage50.

OverlayImage

Anoverlayimageisastaticimagesuperimposedoverthevideostream.Theimage,forexamplecompanylogo,isusedtoprovide

extrainformationortomaskapartoftheimage.

Sinceitisstatic,thepositionandsizeofanoverlayimagewillremainthesameregardlessofresolutionandPan/Tilt/Zoom

movements.Tosetupadynamicmask,whichwillalwaysmaskthespeciedpartofmonitoredarea,seePrivacyMask,onpage27

Touseanoverlayimage,theimagemustrstbeuploadedtotheAxisproduct:

1.GotoVideo&Audio>OverlayImage.

2.ClickBrowseandbrowsetothele.

3.ClickUpload.

4.SelecttheimagetousefromtheUseoverlayimagelist.

5.ClickSave.

Todisplaytheoverlayimage:

1.GotoVideo&Audio>VideoStreamandselecttheImagetab.

2.UnderOverlaySettings,selectIncludeoverlayimageatthecoordinatesandentertheXandYcoordinates.

3.ClickSave.

Forinformationaboutsupportedimageformats,seetheonlinehelp

UsingOverlayTextinanActionRule

Actionrules,seepage41,candisplayanoverlaytextwhentheruleistriggered.Thetextcanbeusedtoprovideinformationfor

forensicvideoanalysis,notifysurveillanceoperatorsorvalidatetriggersandactionsduringproductinstallationandconguration.

Todisplayoverlaytextwhenanactionruleistriggered,themodier#Dshouldbeusedasdescribedbelow.Whentheruleis

triggered,#Dwillbereplacedbythetextspeciedintheactionrule.

Startbyenablingoverlaytextinthevideostream:

1.GotoVideo&Audio>VideoStreamandselecttheImagetab.

2.UnderOverlaySettings,selectIncludetext.

3.Enterthemodier#Dand,optionally,additionaltextwhichwillbedisplayedalsowhentheactionruleisnotactive.

Createtheactionrule:

1.GotoEvents>ActionRules

2.ClickAddtocreateanewrule.

3.SelectaTriggerand,optionally,aScheduleandAdditionalconditions.Seetheonlinehelpfordetails.

AXISQ1614NetworkCamera

VideoandAudio

4.FromtheActionslist,selectOverlayText

5.EnterthetexttodisplayintheTexteld.Thisisthetextthat#Dwillbereplacedby.

6.SpecifytheDuration.Thetextcanbedisplayedwhiletheruleisactiveorforaxednumberofseconds.

Example

Todisplaythetext“Motiondetected”whenmotionisdetected,enter#DintheIncludetexteldandenter“Motiondetected”in

theTexteldwhensettinguptheactionrule.

PrivacyMask

Aprivacymaskisanareaofsolidcolorthatprohibitsusersfromviewingpartsofthemonitoredarea.Privacymaskscannotbe

bypassedviatheVAPIX®ApplicationProgrammingInterface(API).

ThePrivacyMaskList(Video&Audio>PrivacyMask)showsallthemasksthatarecurrentlyconguredintheAxisproductand

indicatesiftheyareenabled.

Youcanaddanewmask,re-sizethemaskwiththemouse,chooseacolorforthemask,andgivethemaskaname.

Formoreinformation,seetheonlinehelp

Important

Addingmanyprivacymasksmayaffecttheproduct’sperformance.

Focus

YoucanfocustheAxisproductunderVideo&Audio>Focus.Formostapplications,theadjustmentsontheBasictabaresufcient.

Ifrequired,additionaladjustmentscanbemadeontheAdvancedtab.Beforefocusing,alwaysclickOpeniristoopentheiristoits

maximum.Thisgivesthesmallestdepthofeldandthusbestconditionsforcorrectfocusing.ClickEnableiriswhennishedfocusing.

Basic

Followtheon-screeninstructionsontheBasictabtoadjustzoomandfocus.Thepixelcounterisusedtodeterminethenumberof

pixelsinanareaoftheimage,forexampletoensurethattheimagesizefulllsspecicrequirements.Topositionthepixelcounter,

clickonthetextanddragthewindowtothedesiredposition.

Note

•Thebackfocus(step2)shouldonlyberesetifthecamerahasbeenfocusedpreviously.

•Setfocusaspreciselyaspossibleusingthefocuspulleronthelens(step3)beforestartingtheautomaticne-tuning(step4).

•Ifthecameraisplacedsothatitisdifculttolookattheimageandmovethepullersatthesametime,youcanusethe

FocusAssistanttofocusthecamera;forinstructions,seetheInstallationGuidesuppliedwiththeproduct.

Advanced

Thetoolsonthispagecanbeusedtondtheoptimalfocusposition.Alwaysopentheirisbeforefocusingandenableitwhennished

focusing.FocusismeasuredinthepartoftheimagecoveredbytheFocuswindow.Usethemousetomoveandresizethewindow

andthenclickFine-tunefocusautomatically.Ifneeded,clickintheFocuspositionbaroronthearrowsattheendsofthebar,to

furtheradjustthefocus.Thebuttons<and>movethefocuspositiononestepineitherdirection.Thebuttons<<and>>movethe

focuspositionmultiplestepsineitherdirection.Clickingonthebarsetsfocustothatposition.Ifthecameraisnotfocusedafter

completingtheaboveinstructions,trytheFullrangefocusscan.Thescan,whichcantakeseveralminutes,transformsthefocus

positionbartoagraphwherepeaksindicatethebestfocuspositions.Clickinthegraphtosetfocustothedesiredposition.

AudioSettings

TheaudiofunctionalityforeachvideostreamisenabledunderVideo&Audio>VideoStream>Audio.

AXISQ1614NetworkCamera

VideoandAudio

AudioModes

TheAxisproductsupportsthefollowingaudiomodes:

Fullduplex-Simultaneoustwo-wayaudioallowingtheAxisproducttotransmitandreceiveaudioatthesametime.Thereisno

echocancellation;iffeedbackloopsappear,trymovingthemicrophoneorthespeaker.

Half-duplex-AudiocanbetransmittedtoandfromtheAxisproductbutonlyinonedirectionatatime.Totransmitaudiousingthe

LiveViewpage,usetheTalkandListenbuttons,seeAMCAudioControls,onpage14.

Simplex—speakeronly-AudioistransmittedfromaclienttotheAxisproductandcanbeplayedbyaspeakerconnected

totheproduct.TotransmitaudiousingtheLiveViewpage,theTalkandMicrophonebuttonsmustbothbeactive,seeAMC

AudioControls,onpage14.

Simplex—microphoneonly-AudiocapturedbytheproductmicrophoneistransmittedfromtheAxisproducttooneormoreclients.

Tosettheaudiomode,gotoVideo&Audio>AudioSettingsandselectthedesiredmodefromtheAudiomodedrop-downlist.

AudioInput

AnexternalmicrophoneoralinesourcecanbeconnectedtotheAudio-inconnector.ConguretheaudioinputsettingsunderVideo

&Audio>AudioSettings.

Note

Theinternalmicrophoneisusedbydefault;theexternalmicrophoneisusedwhenconnected.Itispossibletodisablethe

internalmicrophonebyconnectingaplugtothemicinput.

Note

IfusingLineinamonocontactmustbeused.Signalontipandgroundonsleeve.

SelectMicrophonetouseanexternalmicrophoneorLinetouseaLineindevice,e.g.anaudiomixerformultiplemicrophones

oramicrophonewithabuilt-inamplier,asaudiosource.

TheMicrophonepoweroptionprovidesDCpowerforanexternalmicrophone.Microphonepowershouldonlybeusedwith

microphonesthathavenobatteryandwhenusingtheinternalmicrophone.Thissettingshouldnotbeenabledwhenusingadynamic

orbatterypoweredmicrophone.Microphonepowerwillnotharmthemicrophone;ifyouareuncertain,tryswitchingitoffandon.

Touseaprofessionalmicrophonerequiring48Vphantompower,youneedanexternalpowersupplyandabalanced-unbalanced

converter(audiotransformer)inbetween.

UsetheInputgaintocontrolthevolume(dBFullScale)oftheaudioinput.Ifthesoundistoolow,chooseahigherdB,toamplify

thesound.Ifthesoundistoohigh,choosealowerdB.TheLevelbargivesavisualrepresentationoftheaudiosignallevelindB

relativetothefull-scaleinputlevel.

•Green—thesignalisatagoodlevel.

•Yellow—thesignalisbecomingdistorted.

•Red—thesignalisdistorted.

UsetheEncodingoptiontoselectdigitalaudioencodingformat.

•AACrequiresalicenseforbothencodinganddecoding.AACistheleastcomplicatedandmostwidelyusedcodec.If

achievingthebestpossibleaudioqualityisapriority,AACistherecommendedcodectouse.AnAAClicenseisincluded

intheAxisproduct.

•G711isanunlicensedstandardcodecthatisusefulwhenintegratingaudiointoaVoIPsystem

•G726isanunlicensedspeechcodecthatismostcommonlyusedwithinthesecurityindustry.

TheSampleratedenesthenumberoftimespersecondthesoundissampled.Ahighersampleratewillprovidebetteraudio

quality,butalsorequiresagreaterbandwidth.

AXISQ1614NetworkCamera

VideoandAudio

SettherequiredBitratedependingontheselectedencoding.Ahigherbitratewillgivebetteraudioquality.Alowerbitrate

mayhavelatencyordelay,butwillrequirelessbandwidth.

Formoreinformationaboutthesesettings,pleaseseetheonlinehelp

AudioOutput

AnexternalspeakercanbeconnectedtotheAudio-outconnector(abuilt-inamplierisrequiredforthis).Theoutputcanbe

connectedtoanotheramplierwithspeakers.Astereoconnectormustbeusedfortheaudioout.

ConguretheaudiooutputsettingsunderVideo&Audio>AudioSettings.

Outputgain-Controlthevolume(dBFullScale)ofthelineaudiooutput.Ifthesoundistoolow,chooseahigherdB.Ifthe

soundistoohigh,choosealowerdB.

AudioClips

AnaudioclipisasoundlethatcanbeplayedwheneventsoccurordirectlyfromtheLiveViewpage.Theaudioclipmustrstbe

uploadedtotheAxisproductorrecordedbyamicrophoneconnectedtotheproduct.

Toadd,download,modifyorremoveaudioclips,gotoVideo&Audio>AudioClips.Formoreinformationseetheonlinehelp.

ToconguretheAxisproducttoplayaudioclipswhenaneventoccurs,anactionrulemustbesetup.Formoreinformation,see

Events,onpage41.

Note

Audioclipscannotbeusediftheproduct’saudiofunctionalityisenabled.TheaudiofunctionalityisenabledontheAudio

tabunderVideo&Audio>VideoStream.

AXISQ1614NetworkCamera

LiveViewCong

YoucancustomizetheLiveViewpageandalterittosuityourrequirements.Itispossibletodenethefollowingfeaturesof

theLiveViewpage.

•StreamProle.Seepage22.

•DefaultViewerforBrowser.Seepage30.

•ViewerSettings.Seepage31.

•ActionButtons.ThesearethebuttonsdescribedinControlsontheLiveViewPage,onpage13.

•UserDenedLinks.Seepage31.

•OutputButtons.Seepage31.

DefaultViewerforBrowsers

FromLiveViewCong>DefaultViewerselectthedefaultmethodforviewingvideoimagesinyourbrowser.Theproductattempts

toshowthevideoimagesintheselectedvideoformatandviewer.Ifthisisnotpossible,theproductoverridesthesettingsand

selectsthebestavailablecombination.

AXISQ1614NetworkCamera

LiveViewCong

BrowserViewerDescription

AMC

RecommendedviewerinInternetExplorer(H.264/MotionJPEG).

QuickTime

H.264.

Javaapplet

AslowerimagingalternativetoAMC(MotionJPEG).Requiresoneofthe

followinginstalledontheclient:

•JVM(J2SE)1.4.2orhigher.

•JRE(J2SE)5.0orhigher.

WindowsInternetExplorer

StillimageDisplaysstillimagesonly.ClicktheRefreshbuttoninyourbrowsertoviewa

newimage.

ServerPush

Recommendedviewerforotherbrowsers(MotionJPEG).

QuickTime

H.264.

Javaapplet

AslowerimagingalternativetoServerPush(MotionJPEGonly).

Otherbrowsers

StillimageDisplaysstillimagesonly.ClicktheRefreshbuttoninyourbrowsertoviewa

newimage.

Formoreinformation,pleaseseetheonlinehelp.

ViewerSettings

Tocongureoptionsfortheviewer,gotoLiveViewCong>ViewerSettings.

•SelectShowviewertoolbartodisplaytheAXISMediaControl(AMC)ortheQuickTimeviewertoolbarunderthevideo

imageinyourbrowser.

•H.264decoderinstallation.TheadministratorcandisableinstallationoftheH.264decoderincludedwithAXISMedia

Control.Thisisusedtopreventinstallationofunlicensedcopies.Furtherdecoderlicensescanbepurchasedfromyour

Axisreseller.

•SelectShowcrosshairinPTZjoystickmodetoenableacrossthatwillindicatethecenteroftheimageinPTZjoystick

mode.

•SelectUsePTZjoystickmodeasdefaulttoenablejoystickmode.Themodecanbechangedtemporarilyfromthe

PTZcontrolpanel.

•SelectEnablerecordingbuttontoenablerecordingfromtheLiveViewpage.Thisbuttonisavailablewhenusingthe

AMCviewer.TherecordingsaresavedtothelocationspeciedintheAMCControlPanel.SeeAXISMediaControl

(AMC),onpage16.

UserDenedLinks

Todisplayuser-denedlinksintheLiveViewpage,selecttheShowcustomlinkoption,givethelinkanameandthenentertheURL

tolinkto.Whendeningaweblinkdonotremovethe'http://'fromtheURLaddress.Customlinkscanbeusedtorunscriptsor

activateexternaldevicesconnectedtotheproduct,ortheycanlinktoawebpage.Customlinksdenedascgilinkswillrunthe

scriptinthebackground,inahiddenframe.Deningthelinkasaweblinkwillopenthelinkinanewwindow.

OutputButtons

ExternalI/OdevicesconnectedtotheAxisproduct’soutputportscanbecontrolleddirectlyfromtheLiveViewpage.

TodisplayoutputbuttonsintheLiveViewpage:

1.GotoSetup>LiveViewCong.

2.UnderOutputButtons,selectthetypeofcontroltouse:

AXISQ1614NetworkCamera

LiveViewCong

-Pulseactivatestheoutputforadenedperiodoftime.Thepulsetimecanbesetfrom1/100secondto60

seconds.

-Active/Inactivedisplaystwobuttons,oneoreachaction.

Toconguretheactiveandinactivestates,gotoSystemOptions>Ports&Devices>I/OPortsandsettheport’sNormalstate.

FormoreinformationaboutI/Oports,seeI/OPorts,onpage57.

AXISQ1614NetworkCamera

PTZ(PanTiltZoom)

ThePTZmenuisavailableifdigitalPTZ(pan,tiltandzoom)isenabledintheselectedviewareaorifaPTZdriverhasbeenuploaded.

Formoreinformationonviewareas,seeViewArea,onpage25.Formoreinformationonhowtouploadadriver,seeInstallinga

PTZdriver,onpage34.ToswitchbetweenthetwooptionsseePTZMode,onpage12

PresetPositions

Apresetpositionisapredenedviewthatcanbeusedtoquicklysteerthecameratoaspeciclocation.Presetpositionscan

beaccessedinseveralways:

•ByselectingthepresetfromtheSourcedrop-downlistintheLiveViewPage.

•Whensettingupactionrules.Seepage41.

•WhensettingupGuardTour.Seepage34.

Toaddapresetposition:

1.GotoPTZ>PresetPositions.

2.Usethepan,tiltandzoomcontrolstosteerthecameraviewtothedesiredposition.

3.EnteradescriptivenameintheCurrentpositioneld.

4.ClickAdd.Thecamera’spositionandfocussettingsaresavedasapresetposition.

TheentireviewareaistreatedastheHomepositionwhichisreadilyaccessiblebyclickingtheHomebuttonontheLiveView

pageandinthePresetPositionssetupwindow.

TheproductcanbeconguredtoreturntotheHomepositionwhenthePTZfunctionalityhasbeeninactiveforaspeciedlengthof

time.EnterthelengthoftimeintheReturntooverviewaftereldandclickSave.Setthetimetozerotopreventtheproductfrom

automaticallyreturningtotheHomeposition.

Toincludethepresetpositionnameintheoverlaytext,gotoVideo&Audio,selectIncludeoverlaytextandenterthemodier#Pin

theeld.Formoreinformationaboutmodiers,seeFileNaming&Date/TimeFormatsintheonlinehelp

AXISQ1614NetworkCamera

PTZ(PanTiltZoom)

GuardTour

Aguardtourdisplaysthevideostreamfromdifferentpresetpositions,one-by-one,inapredeterminedorderoratrandomandfor

congurabletimeperiods.Theenabledguardtourwillkeeprunningaftertheuserhasloggedofforclosedthebrowser.

Toaddaguardtour:

1.GotoPTZ>GuardTourandclickAdd.

2.Enteradescriptivename.

3.Specifythepauselengthbetweenruns.

4.SelectanavailablepresetpositionandclickApply.

5.SpecifytheViewTimeinsecondsorminutes.

6.SpecifytheViewOrderorselecttheRandomvieworderoption.

7.ClickSave.

Tomodifyorremoveguardtours,gotoPTZ>GuardTour,selecttheguardtourintheGuardTourListandclickModify/Remove.

Formoreinformationseetheonlinehelp

Advanced

DeviceSettings

TheDeviceSettingswindowdisplaysdriverspecicsettings.Theappearanceofthiswindowcanvarydependingonthedriver

installed.Optionsthatcanbeconguredinclude:

•DriverSpecicSettingsfromVideoSource

•MechanicalLimitsforMovingVideoSource

•LightControlVideoSource

•ExtendedDriverSpecicSettingsforVideoSource

FordownloadandinstallationinformationaboutPTZdriversforyourAxisproductpleasevisitwww.axis.com/techsup/

Controls

PanelShortcutCommandButtonscanbeconguredtoprovidedirectaccesstocommandsissuedviatheVAPIX®Application

ProgrammingInterface.ThebuttonswillbedisplayedinthePTZcontrolpanel,whichisavailableintheLiveViewpagethrough

theCtrlpanelbutton,seepage14.

DeselecttheoptionsunderEnable/Disablecontrolstodisablethepan,tilt,zoomandfocuscontrols.

InstallingaPTZdriver

ThisAxisproductsupportsseveralPTZdevices.Pleaseseewww.axis.comforacompletelistofsupporteddevices,andtoobtainthe

correctdriver.ToinstallaPTZdeviceyouneedtoinstallthePTZdriver.

ToinstallthePTZdrivergotoPTZ>DriverSelection.Browsetondthedriver(e.g.driver.ptz)andUpload.Ifthedriverwas

successfullyuploaded,itappearsintheSelectdrivertousedrop-downlist.Fromthisdrop-downlist,selectthedrivertoinstall

orremove,andclickSave.

SelectActivatePTZtoenablePTZ.TheaddressoftheconnecteddeviceappearsagainstDeviceID.ChoosetheDevicetypefromthe

drop-downlist.Tondwhichdevicetypetouse,consultthedocumentationsuppliedbythePTZdriver.

AXISQ1614NetworkCamera

PTZ(PanTiltZoom)

TocompletetheinstallationgotoSystemOptions>Ports&Devices>COMPort(seeCOMPort)andverifythesettings.

ControlQueue

TheadministratorcansetupaqueueforPTZcontrollersfromPTZ>ControlQueue.Oncesetup,thePTZControlQueuebuttons

appearintheLiveViewpageofferingoneviewerexclusivecontrolforalimitedperiodoftime.Otheruserswillbeplacedinqueue.

Auserwhobelongstoagroup(seeUsers,onpage48)withahigherPTZprioritycangobeforeotherusersinthequeueand

takecontroloftheproduct.Theorderofpriorityisasfollows:

1.Administrator—AnadministratortakesoverPTZcontrolregardlessofwhoisrstinqueue.Theadministratorwillbe

removedfromthequeue60secondsafterthelastPTZcontrolcommand.

2.Event—TheAxisproductcanbeconguredtogotoapresetpositionwhentriggeredbyanalarm(seeEvents,onpage41).

Theeventwillimmediatelybeplacedrstinthequeueexceptwhenanadministratorisincontrol.

3.Operator—Sameasadministratorbutwithlowerpriority

4.GuardTour—Aguardtour(seepage34)hasPTZcontrolforanindeniteperiodoftime.Itmaybeoverriddenbyan

operator,eventoradministrator.Theguardtourwillresumewhenhigherprioritygroupsleavethequeue.

5.Viewer—Multipleviewersmustwaitfortheirturn.Theviewerhas60secondsPTZcontrolbeforecontrolispassed

ontothenextviewerinqueue.

Note

•TheadministratorcanenableanddisablePTZcontrolsforselectedusers.

•Toidentifydifferentusersintheviewergroup,cookiesmustbeenabledontheclient.

AXISQ1614NetworkCamera

Detectors

CameraTampering

CameraTamperingcangenerateanalarmwheneverthecameraisrepositioned,orwhenthelensiscovered,sprayedorseverely

defocused.Tosendanalarm,forexampleanemail,anactionrulemustbesetup.

Toconguretampering:

1.GotoDetectors>CameraTampering.

2.SettheMinimumduration,thatis,thetimethatmustelapsebeforeanalarmisgenerated.Thiscanhelpprevent

falsealarmsforknownconditionsthataffecttheimage.

3.SelectAlarmfordarkimagesifanalarmshouldbegeneratediflightsaredimmedorturnedoff,orifthelensissprayed,

covered,orrenderedseverelyoutoffocus.

4.ClickSave.

Toconguretheproducttosendanalarmwhentamperingoccurs:

1.GotoEvents>ActionRules.

2.ClickAddtosetupanewactionrule.

3.EnteraNamefortheactionrule.

4.UnderCondition,selectDetectorsfromtheTriggerlist.

5.SelectTamperingfromthelistofdetectors.

6.Optionally,selectascheduleandsetadditionalconditions.

7.Selecttheaction.Tosendanemail,selectSendNoticationandselectaRecipientfromthelistofdenedrecipients.

Note

TheWhiletheruleisactiveoptionunderDurationcannotbeusedwithcameratampering,sincecameratamperingdoesnot

haveadurationandonceithasbeentriggereditwillnotautomaticallyreturntoitsuntriggeredstate.

Formoreinformationonactionsrules,seeEvents,onpage41.

ShockDetection

EnableShockDetectionfromtheDetectorsmenu.Shockdetectionisused,forexample,togenerateanalarmiftheproductishit

byanobject.

UsetheShocksensitivityslidertoadjustthesensitivitylevelatwhichtheproductshouldsendanalarmuponbeinghit.Low

sensitivityvalueimpliesthattheproductwillgenerateanalarmonlyifthehitispowerful.

MotionDetection

Motiondetectionisusedtogenerateanalarmwhenevermovementstartsorstopsinthecameraview.

Motiondetectionisconguredbydeningupto10IncludeandExcludewindows:

•Includewindows—deneareaswheremotionshouldbedetected

•Excludewindows—deneareaswithinanIncludewindowthatshouldbeignored(areasoutsideIncludewindows

areautomaticallyignored).

Forinstructions,seeSetUpMotionDetectionWindows,onpage37.

AXISQ1614NetworkCamera

Detectors

Tocontrolthenumberofmotiondetectionalarms,theparametersObjectSize,HistoryandSensitivitycanbeadjusted.See

MotionDetectionParameters,onpage37.

Oncemotiondetectionwindowsarecongured,theAxisproductcanbeconguredtoperformactionswhenmotionisdetected.

Possibleactionsincludeuploadingimagesandstartrecording.Formoreinformation,seeSettingUpanActionRule,onpage42.

Note

•Usingthemotiondetectionfeaturemaydecreasetheproduct’soverallperformance.

•ThepositionoftheMotionDetectionWindowisrelativetotheorientationoftheCamera.Changingtheorientationofthe

camerawillalsochangethepositionoftheMotionDetectionWindow.

SetUpMotionDetectionWindows

TosetupamotiondetectionIncludeWindow,followtheseinstructions:

1.GotoDetectors>MotionDetection.

2.SelecttheCongureIncludedWindowsoptionandclickNew.Selectthenewwindowinthelistofwindowsand

enteradescriptivename.

3.Adjustthesize(dragthebottomright-handcorner)andtheposition(clickonthetextatthetopanddragtothedesired

position)ofthewindow.

4.AdjusttheObjectSize,HistoryandSensitivityprolesliders(seeMotionDetectionParametersfordetails).Anydetected

motionwithinanactivewindowisindicatedbyredpeaksintheActivitywindow.

5.ClickSave.

Toexcludepartsoftheincludewindow,selecttheCongureExcludedWindowsandpositiontheexcludewindowwithinthe

includewindow.

Todeleteanincludeorexcludewindow,selectthewindowinthelistofwindowsandclickDel.

MotionDetectionParameters

Theparameterscontrollingmotiondetectionaredescribedinthetablebelow:

Parameter

ObjectSize

History

Sensitivity

Description

Objectsizerelativetowindow

size.

Objectmemorylength.

Differenceinluminance

betweenbackgroundand

object.

AXISQ1614NetworkCamera

Detectors

Highlevel(100%)

Onlyverylargeobjectstrigger

motiondetection.

Anobjectthatappearsin

thewindowtriggersmotion

detectionforalongtime

beforeitisconsideredas

non-moving.

Ordinarycoloredobjectson

ordinarybackgroundstrigger

motiondetection.

Mediumlevel(50%)

Alargedifferenceinluminance

isrequiredtotriggermotion

detection.

Lowlevel(0%)

Evenverysmallobjectstrigger

motiondetection.

Anobjectthatappearsin

thewindowtriggersmotion

detectiononlyforaveryshort

timebeforeitisconsideredas

non-moving.

Onlyverybrightobjectson

adarkbackgroundtrigger

motiondetection.

Recommendedvalues

5–15%60–90%75–95%

Defaultvalues

15%90%90%

Note

•Totriggeronsmallobjectsormovements,useseveralsmallmotiondetectionwindowsratherthanonelargewindow

andselectalowobjectsize.

•Toavoidtriggeringonsmallobjects,selectahighobjectsize.

•Whilemonitoringanareawheremovingobjectsarenotexpected,selectahighhistorylevel.Thiswillcausemotion

detectiontotriggeraslongastheobjectispresentinthewindow.

•Toonlydetectashinglight,selectalowsensitivity.Inothercaseshighsensitivityisrecommended.

AudioDetection

TheAxisproductcanbeconguredtogenerateanalarmwhenaudiorisesaboveorfallsbelowthethresholdvalue.Thethreshold

valuecanbesetintherange0–100where0isthemostsensitiveand100theleastsensitive.

1.GotoDetectors>AudioDetection.

2.SettheaudioalarmlevelandclickSave.

3.GotoEvents>ActionRulesandsetupanactionrule,seeSettingUpanActionRule,onpage42.

DetectedaudioisindicatedbycoloredpeaksintheActivityindicator.Aneventistriggeredwhendetectedaudiorisesaboveorfalls

belowthethresholdvalue,whichisrepresentedbythebar.

AXISQ1614NetworkCamera

Applications

ThirdpartyapplicationscanbeuploadedtoandinstalledontheAxisproduct.Applicationsaddfunctionalitytotheproduct,for

examplevideoanalyticsandintelligentvideocapabilitiessuchasrecognition,tracking,detectionandcounting.Forinformation

aboutavailableapplications,downloads,trialsandlicenses,gotowww.axis.com/applications

Note

•Itisrecommendedtorunoneapplicationatatime.

•Avoidrunningapplicationswhenthebuilt-inmotiondetectionisactive.

ApplicationLicenses

Someapplicationsneedalicensetorun.Licensescanbeinstalledintwoways:

•Automaticinstallation—requiresaccesstotheInternet

•Manualinstallation—obtainthelicensekeyfromtheapplicationvendoranduploadthekeytotheAxisproduct

Torequestalicense,theAxisproductserialnumber(S/N)isrequired.Theserialnumbercanbefoundontheproductlabelandunder

SystemOptions>Support>SystemOverview.

InstallApplication

Toinstallandstartanapplication:

1.GotoSetup>Applications.

2.UnderUploadApplication,clickBrowse.LocatetheapplicationleandclickUploadPackage.

3.Installthelicense(ifapplicable).Forinstructions,seethedocumentationprovidedbytheapplicationvendor.

4.Starttheapplication.GotopageApplications,selecttheapplicationinthelistofinstalledapplicationsandclickStart.

5.Conguretheapplication.Forinstructions,seethedocumentationprovidedbytheapplicationvendor.

Note

•Applicationscanbeuploadedbyproductadministrators.

•ApplicationsandlicensescanbeinstalledonmultipleproductsatthesametimeusingAXISCameraManagement,version

3.10andlater.

Togeneratealoglefortheapplication,gotoApplications.SelecttheapplicationandclickLog.

ApplicationConsiderations

Ifanapplicationisupgraded,applicationsettings,includingthelicense,willberemoved.Thelicensemustbereinstalledand

theapplicationrecongured.

IftheAxisproduct’srmwareisupgraded,installedapplicationsandtheirsettingswillremainunchanged,althoughthisisnot

guaranteedbyAxisCommunicationsAB.Notethattheapplicationmustbesupportedbythenewrmware.Forinformationabout

rmwareupgrades,seeUpgradingtheFirmware.

IftheAxisproductisrestarted,runningapplicationswillrestartautomatically.

IftheAxisproductisrestored,installedapplicationsremainunchangedbutmustberestarted.Tostarttheapplication,goto

Setup>Applications.SelecttheapplicationinthelistofinstalledapplicationsandclickStart.Forinformationaboutrestoring

theAxisproduct,seeMaintenance.

AXISQ1614NetworkCamera

Applications

IftheAxisproductisresettofactorydefault,installedapplicationsandtheirsettingsareremoved.Forinformationaboutfactory

default,seeResettoFactoryDefaultSettings.

AXISQ1614NetworkCamera

Events

TheAxisproductcanbeconguredtoperformactionswhendifferenteventsoccur,forexample,startarecordingwhenmotionis

detected.ThesetofconditionsthatdeneshowandwhentheactionistriggerediscalledanActionRule.

Availableactionruletriggersandconditionsinclude:

•Applications–Useinstalledapplicationstotriggertherule.SeeApplications,onpage39.

•Detectors

-AudioDetection–Triggertherulewhenaudioisdetected.SeeAudioDetection,onpage38.

-Day/NightMode–Triggertherulewhentheproductswitchesbetweendaymode(IRcutlteron)andnight

mode(IRcutlteroff).Thiscanforexamplebeusedtocontrolanexternalinfrared(IR)lightconnected

toanoutputport.

-LiveStreamAccessed–Triggertherulewhenanystreamisaccessedandduringedgestorageplayback.

Thiscanforexamplebeusedtosendnotications.

-MotionDetection–Triggertherulewhenmotionisdetected.SeeMotionDetection,onpage36.

-ShockDetected–TriggertherulewhentheAxisproductdetectsithasbeentiltedorhit.SeeShockDetection,

onpage36.

-Tampering–Triggertherulewhentamperingisdetected.SeeCameraTampering,onpage36.

•Hardware

-Network–Triggertheruleifnetworkconnectionislostorrestored.Thiscanforexamplebeusedtostart

recordingtotheSDcard.

-Temperature–Triggertheruleifthetemperaturefallsoutsideorinsidetheoperatingrangeoftheproduct.This

canforexamplebeusedtosendmaintenancenotications.

•InputSignal

-DigitalInputPort–TriggertherulewhenanI/Oportreceivesasignalfromaconnecteddevice.SeeI/OPorts,

onpage57.

-ManualTrigger–TriggertheruleusingtheManualTriggerbuttonintheLiveViewpage.SeeControlson

theLiveViewPage,onpage13.Thiscanforexamplebeusedtovalidateactionsduringproductinstallation

andconguration.

-VirtualInputs–canbeusedbyaVMS(VideoManagementSystem)totriggeractions.Virtualinputscan,for

example,beconnectedtobuttonsintheVMSuserinterface.

•PTZ

-Moving–TriggertherulewhenthecameraviewmovesduetoaPTZoperation.Thiscanforexamplebeused

asanadditionalconditiontopreventanactionruletriggeredbymotiondetectiontorecordvideowhilethe

cameraviewmovesduetoaPTZoperation.

-PresetReached–Triggertherulewhenthecamerastopsatapresetposition.Thiscanbeforexamplebeused

withtheSendImagesactiontouploadimagesfromthepresetposition.

•Storage

-Disruption–Triggertheruleifstorageproblemsaredetected,forexampleifthestoragedeviceisunavailable,

removed,full,lockedorifotherreadorwriteproblemsoccur.Thiscanforexamplebeusedtosendmaintenance

notications.

AXISQ1614NetworkCamera

Events

-Recording–TriggerstherulewhentheAxisproductrecordstothestoragedevice.Therecordingstatustrigger

canbeusedtonotifytheoperator,forexamplebyashingLEDlights,iftheproducthasstartedorstoppedto

recordtothestoragedevice.Notethat,thistriggercanbeusedonlyforedgestoragerecordingstatus.

•System

-SystemReady–Triggertherulewhentheproducthasbeenstartedandallservicesarerunning.Thiscanfor

examplebeusedtosendanoticationwhentheproductrestarts.

•Time

-Recurrence–Triggertheruleperiodically.SeeRecurrences,onpage44.Thiscanforexamplebeusedtoupload

animageevery5minutes.

-UseSchedule–Triggertheruleaccordingtotheselectedschedule.SeeSchedules,onpage44.

Availableactionsinclude:

•Day/NightVisionMode–Setdaymode(IRcutlteron)ornightmode(IRcutlteroff).

•OutputPort–ActivateanI/Oporttocontrolanexternaldevice.

•OverlayText–Displayanoverlaytext.SeeUsingOverlayTextinanActionRule,onpage26.

•PlayAudioClip–SeeAudioClips,onpage29.

•PTZControl

-PresetPosition–Gotoapresetposition.

-GuardTour–Startaguardtour.SeeGuardTour,onpage34.

•RecordVideo–Recordvideotoaselectedstorage.

•SendImages–Sendimagestoarecipient.

•SendNotications–Sendanoticationmessagetoarecipient.

•SendSNMPTrap–SendanSNMPtrapmessagetotheoperator.MakesurethatSNMPisenabledandcongured

underSystemOptions>Network>SNMP.

•SendVideoClip–Sendavideocliptoarecipient.

•StatusLED–FlashtheLEDindicator.Thiscanforexamplebeusedtovalidatetriggerssuchasmotiondetectionduring

productinstallationandconguration.

•WDRMode–TheWDRModeorLightnderModecanbeturnedonwhentheactionruleistriggered.Thisactionmay

beusedtochangebetweenthesemodesautomatically.

SettingUpanActionRule

Anactionruledenestheconditionsthatmustbemetfortheproducttoperformanaction,forexamplerecordvideoorsendan

emailnotication.Ifmultipleconditionsaredened,allofthemmustbemettotriggertheaction.

Thefollowingexampledescribeshowtosetupanactionruletorecordvideotoanetworkshareifthereismovementinthe

camera’seldofview.

Setupmotiondetectionandaddanetworkshare:

1.GotoDetectors>MotionDetectionandcongureamotiondetectionwindow.Seepage37

2.GotoSystemOptions>Storageandsetupthenetworkshare.Seepage56.

Setuptheactionrule:

AXISQ1614NetworkCamera

Events

1.GotoEvents>ActionRulesandclickAdd.

2.SelectEnableruleandenteradescriptivenamefortherule.

3.SelectDetectorsfromtheTriggerdrop-downlist.

4.SelectMotionDetectionfromthedrop-downlist.Selectthemotiondetectionwindowtouse.

5.Optionally,selectaScheduleandAdditionalconditions.Seebelow.

6.UnderActions,selectRecordVideofromtheTypedrop-downlist.

7.SelectaStreamproleandconguretheDurationsettingsasdescribedbelow.

8.SelectNetworkSharefromtheStoragedrop-downlist.

Toaddadditionalcriteria,selecttheAdditionalconditionsoptionandaddadditionaltriggers.Topreventanactionfrombeing

triggeredrepeatedly,aWaitatleasttimecanbeset.Enterthetimeinhours,minutesandseconds,duringwhichthetrigger

shouldbeignoredbeforetheactionrulecanbeactivatedagain.

TherecordingDurationofsomeactionscanbesettoincludetimeimmediatelybeforeandaftertheevent.SelectPre-triggertime

and/orPost-triggertimeandenterthenumberofseconds.WhenWhiletheruleisactiveisenabledandtheactionistriggered

againduringthepost-triggertime,therecordingtimewillbeextendedwithanotherpost-triggertimeperiod.

Formoreinformation,seetheonlinehelp

Recipients

Recipientsreceivemedialesandnoticationmessages.Thefollowingrecipientsareavailable:

RecipientUsewithaction

SendImages

SendNotication

SendVideoClip

FTP

SendImages

SendVideoClip

HTTP

SendImages

SendNotication

SendVideoClip

HTTPSSendImages

SendNotication

SendVideoClip

NetworkShare

SendImages

SendVideoClip

TCPSendNotication

1.Someemailprovidershavesecurityltersthatpreventusersfromreceivingorviewinglargeamountofattachments,fromreceivingscheduled

emailsandsimilar.Checktheemailprovider’ssecuritypolicytoavoiddeliveryproblemsandlockedemailaccounts.

2.Anetworksharecanalsobeusedasastoragedeviceforrecordedvideo.GoSystemOptions>Storagetocongureanetworksharebefore

settingupacontinuousrecordingoranactionruletorecordvideo.SeeStorage,onpage56formoreinformationaboutstoragedevices.

Toaddarecipient:

AXISQ1614NetworkCamera

Events

1.GotoEvents>RecipientsandclickAdd.

2.Enteradescriptivename.

3.SelectarecipientType.

4.Entertheinformationneededfortherecipienttype.

5.ClickTesttotesttheconnectiontotherecipient.

6.ClickOK.

SettingUpanEmailRecipient

Emailrecipientscanbeconguredbyselectingoneofthelistedemailproviders,orbyspecifyingtheSMTPserver,portand

authenticationusedby,forexample,acorporateemailserver.

Note

Someemailprovidershavesecurityltersthatpreventusersfromreceivingorviewinglargeamountofattachments,from

receivingscheduledemailsandsimilar.Checktheemailprovider’ssecuritypolicytoavoiddeliveryproblemsandlocked

emailaccounts.

Tosetupanemailrecipientusingoneofthelistedproviders:

1.GotoEvents>RecipientsandclickAdd.

2.EnteraNameandselectEmailfromtheTypelist.

3.EntertheemailaddressestosendemailstointheToeld.Usecommastoseparatemultipleaddresses.

4.SelecttheemailproviderfromtheProviderlist.

5.EntertheuserIDandpasswordfortheemailaccount.

6.ClickTesttosendatestemail.

Tosetupanemailrecipientusingforexampleacorporateemailserver,followtheinstructionsabovebutselectUserdenedas

Provider.EntertheemailaddresstoappearassenderintheFromeld.SelectAdvancedsettingsandspecifytheSMTPserver

address,portandauthenticationmethod.Optionally,selectUseencryptiontosendemailsoveranencryptedconnection.Theserver

certicatecanbevalidatedusingthecerticatesavailableintheAxisproduct.Forinformationonhowtouploadcerticates,

seeCerticates,onpage49.

Schedules

Schedulescanbeusedasactionruletriggersorasadditionalconditions,forexampletorecordvideoifmotionisdetectedoutside

ofcehours.Useoneofthepredenedschedulesorcreateanewscheduleasdescribedbelow.

Tocreateanewschedule:

1.GotoEvents>SchedulesandclickAdd.

2.Enteradescriptivenameandtheinformationneededforadaily,weekly,monthlyoryearlyschedule.

3.ClickOK.

Tousethescheduleinanactionrule,selecttheschedulefromtheScheduledrop-downlistintheActionRuleSetuppage.

Recurrences

Recurrencesareusedtotriggeractionrulesrepeatedly,forexampleevery5minutesoreveryhour.

AXISQ1614NetworkCamera

Events

Tosetuparecurrence:

1.GotoEvents>RecurrencesandclickAdd.

2.Enteradescriptivenameandrecurrencepattern.

3.ClickOK.

Tousetherecurrenceinanactionrule,rstselectTimefromtheTriggerdrop-downlistintheActionRuleSetuppageandthen

selecttherecurrencefromtheseconddrop-downlist.

Tomodifyorremoverecurrences,selecttherecurrenceintheRecurrencesListandclickModifyorRemove.

AXISQ1614NetworkCamera

Recordings

TheAxisproductcanbeconguredtorecordvideocontinuouslyoraccordingtoanactionrule:

•Tostartacontinuousrecording,seepage46.

•Tosetupactionrules,seepage42.

•Toaccessrecordings,seeRecordingList,onpage46.

•Tocongurecameracontrolledstorage,seeStorage,onpage56.

RecordingList

RecordedvideosarelistedontheRecordings>Listpage.Thelistshowseachrecording’sstartdateandtime,durationandthe

eventthattriggeredtherecording.

Toplayordownloadarecording,followthesesteps:

1.GotoRecordings>List.

2.Usetheltertonarrowthelistofrecordings.EnterthedesiredltercriteriaandclickFilter.Someltersmaytake

alongtimetocomplete.

3.Selecttherecording.

4.ClickPlaytoplaytherecording,orclickDownloadtodownloadtherecording.

Multiplerecordingscanbedownloadedatthesametime.SelecttherecordingsandclickDownload.Thedownloadedleisaziple

containingaminimumofthreeles,ofwhichtheMatroska(mkv)lesaretheactualrecordings.Therecordingsaretime-stamped

withthedateandtimetheyweredownloaded(thatis,notthedatetherecordingsweremade).

Note

ToplayrecordingsinWindowsMediaPlayer,AXISMatroskaFileSplittermustbeinstalled.AXISMatroskaFileSplitter

canbedownloadedfromwww.axis.com/techsup/software

Fordetailedrecordingandvideoinformation,selectarecordingandclickProperties.

Toremovearecording,selecttherecordingandclickRemove.

ContinuousRecording

TheAxisproductcanbeconguredtocontinuouslysavevideotoastoragedevice.SeeStorage,onpage56formoreinformation

aboutstoragedevices.Topreventthediskfrombecomingfull,itisrecommendedtocongurethedisktoautomaticallyremoveold

recordings.Ifanewstreamproleisselectedwhilearecordingisongoing,therecordingwillbestoppedandsavedintherecording

listandanewrecordingwiththenewstreamprolewillstart.Allpreviouscontinuousrecordingswillremainintherecordinglist

untiltheyareremovedmanuallyorthroughautomaticremovalofoldrecordings.

Tostartacontinuousrecording,followthesesteps:

1.GotoRecordings>Continuous.

2.SelectEnabled.

3.SelecttypeofstoragedevicefromtheDisklist.

4.SelectaStreamproletouseforcontinuousrecordings.

5.ClickSavetosaveandstarttherecording.

AXISQ1614NetworkCamera

Languages

MultiplelanguagescanbeinstalledintheAxisproduct.Allwebpagesincludingtheonlinehelpwillbedisplayedintheselected

language.Toswitchlanguages,gotoSetup>Languagesandrstuploadthenewlanguagele.Browseandlocatetheleandclick

theUploadLanguagebutton.SelectthenewlanguagefromthelistandclickSave.

Note

•Resettingtheproducttofactorydefaultsettingswilleraseanyuploadedlanguageleandresettheproductlanguageto

English.

•ClickingtheRestorebuttonontheMaintenancepagewillnotaffectthelanguage.

•Armwareupgradewillnotaffectthelanguageused.Howeverifyouhaveuploadedanewlanguagetotheproductand

laterupgradethermware,itmayhappenthatthetranslationnolongermatchestheproduct'swebpages.Inthiscase,

uploadanupdatedlanguagele.

•Alanguagealreadyinstalledintheproductwillbereplacedwhenacurrentoralaterversionofthelanguageleisuploaded.

AXISQ1614NetworkCamera

SystemOptions

Security

Users

UseraccesscontrolisenabledbydefaultandcanbeconguredunderSystemOptions>Security>Users.Anadministratorcan

setupotherusersbygivingthemusernamesandpasswords.Itisalsopossibletoallowanonymousviewerlogin,whichmeans

thatanybodymayaccesstheLiveViewpage.

Theuserlistdisplaysauthorizedusersandusergroups(accesslevels):

Viewer-AccesstotheLiveViewpage

Operator-AccesstotheLiveViewpageandtoallsettingsexceptSystemOptions

Administrator-Unrestrictedaccesstoallsettings;canadd,modifyandremoveotherusers.

UnderHTTP/RTSPPasswordSettings,selectthetypeofpasswordtoallow.Youmayneedtoallowunencryptedpasswordsifthere

areviewingclientsthatdonotsupportencryption,orifyouupgradedthermwareandexistingclientssupportencryptionbutneed

tologinagainandbeconguredtousethisfunctionality.

UnderUserSettings,selecttheEnableanonymousviewerloginoptiontoallowanonymoususersaccesstotheLiveViewpage.

SelecttheEnableanonymousPTZcontrollogintoallowanonymoususersaccesstothePTZcontrols.

DeselecttheEnableBasicSetupoptiontohidetheBasicSetupmenu.BasicSetupprovidesquickaccesstosettingsthatshouldbe

madebeforeusingtheAxisproduct.

ONVIF

ONVIF(OpenNetworkVideoInterfaceForum)isaglobalinterfacestandardthatmakesiteasierforendusers,integrators,consultants,

andmanufacturerstotakeadvantageofthepossibilitiesofferedbynetworkvideotechnology.ONVIFenablesinteroperablitybetween

differentvendorproducts,increasedexibility,reducedcostandfuture-proofsystems.

BycreatingauseryouautomaticallyenableONVIFcommunication.UsetheusernameandpasswordwithallONVIFcommunication

withtheproduct.Formoreinformationseewww.onvif.org

IPAddressFilter

IPaddresslteringisenabledontheSystemOptions>Security>IPAddressFilterpage.Onceenabled,thelistedIPaddressare

allowedordeniedaccesstotheAxisproduct.SelectAlloworDenyfromthelistandclickApplytoenableIPaddressltering.

Theadministratorcanaddupto256IPaddressentriestothelist(asingleentrycancontainmultipleIPaddresses).

HTTPS

HTTPS(HyperTextTransferProtocoloverSecureSocketLayer,orHTTPoverSSL)isawebprotocolprovidingencryptedbrowsing.

HTTPScanalsobeusedbyusersandclientstoverifythatthecorrectdeviceisbeingaccessed.Thesecuritylevelprovidedby

HTTPSisconsideredadequateformostcommercialexchanges.

TheAxisproductcanbeconguredtorequireHTTPSwhenusersfromdifferentusergroups(administrator,operator,viewer)connect.

TouseHTTPS,anHTTPScerticatemustrstbeinstalled.GotoSystemOptions>Security>Certicatestoinstallandmanage

certicates.SeeCerticates,onpage49.

ToenableHTTPSontheAxisproduct:

1.GotoSystemOptions>Security>HTTPS

AXISQ1614NetworkCamera

SystemOptions

2.SelectanHTTPScerticatefromthelistofinstalledcerticates.

3.Optionally,clickCiphersandselecttheencryptionalgorithmstouseforSSL.

4.SettheHTTPSConnectionPolicyforthedifferentusergroups.

5.ClickSavetoenablethesettings.

ToaccesstheAxisproductviathedesiredprotocol,enterhttps://orhttp://intheaddresseldinabrowser.

TheHTTPSportcanbechangedontheSystemOptions>Network>TCP/IP>Advancedpage.

IEEE802.1X

IEEE802.1Xisastandardforport-basedNetworkAdmissionControlprovidingsecureauthenticationofwiredandwirelessnetwork

devices.IEEE802.1XisbasedonEAP(ExtensibleAuthenticationProtocol).

ToaccessanetworkprotectedbyIEEE802.1X,devicesmustbeauthenticated.Theauthenticationisperformedbyanauthentication

server,typicallyaRADIUSserver,examplesofwhichareFreeRADIUSandMicrosoftInternetAuthenticationService.

InAxisimplementation,theAxisproductandtheauthenticationserveridentifythemselveswithdigitalcerticatesusingEAP-TLS

(ExtensibleAuthenticationProtocol-TransportLayerSecurity).ThecerticatesareprovidedbyaCerticationAuthority(CA).

Youneed:

•aCAcerticatetoauthenticatetheauthenticationserver.

•aCA-signedclientcerticatetoauthenticatetheAxisproduct.

Tocreateandinstallcerticates,gotoSystemOptions>Security>Certicates.SeeCerticates,onpage49.ManyCAcerticates

arepreinstalled.

ToallowtheproducttoaccessanetworkprotectedbyIEEE802.1X:

1.GotoSystemOptions>Security>IEEE802.1X.

2.SelectaCACerticateandaClientCerticatefromthelistsofinstalledcerticates.

3.UnderSettings,selecttheEAPOLversionandprovidetheEAPidentityassociatedwiththeclientcerticate.

4.ChecktheboxtoenableIEEE802.1XandclickSave.

Note

Forauthenticationtoworkproperly,thedateandtimesettingsintheAxisproductshouldbesynchronizedwithanNTP

server.SeeDate&Time,onpage50.

Certicates

Certicatesareusedtoauthenticatedevicesonanetwork.Typicalapplicationsincludeencryptedwebbrowsing(HTTPS),network

protectionviaIEEE802.1Xandsecureuploadofimagesandnoticationmessagesforexampleviaemail.Twotypesofcerticates

canbeusedwiththeAxisproduct:

Server/Clientcerticates-ToauthenticatetheAxisproduct.

CAcerticates-Toauthenticatepeercerticates,forexamplethecerticateofanauthenticationserverincasetheAxisproductis

connectedtoanIEEE802.1Xprotectednetwork.

Note

Installedcerticates,exceptpreinstalledCAcerticates,willbedeletediftheproductisresettofactorydefault.Preinstalled

CAcerticatesthathavebeendeletedwillbereinstalled.

AServer/Clientcerticatecanbeself-signedorissuedbyaCerticateAuthority(CA).Aself-signedcerticateofferslimited

protectionandcanbeusedbeforeaCA-issuedcerticatehasbeenobtained.

AXISQ1614NetworkCamera

SystemOptions

Toinstallaself-signedcerticate:

1.GotoSetup>SystemOptions>Security>Certicates.

2.ClickCreateself-signedcerticateandprovidetherequestedinformation.

TocreateandinstallaCA-signedcerticate:

1.Createaself-signedcerticateasdescribedabove.

2.GotoSetup>SystemOptions>Security>Certicates.

3.ClickCreatecerticatesigningrequestandprovidetherequestedinformation.

4.CopythePEM-formattedrequestandsendtotheCAofyourchoice.

5.Whenthesignedcerticateisreturned,clickInstallcerticateanduploadthecerticate.

Server/ClientcerticatescanbeinstalledasCerticatefromsigningrequestorasCerticateandprivatekey.SelectCerticate

andprivatekeyiftheprivatekeyistobeuploadasaseparateleorifthecerticateisinPKCS#12format.

TheAxisproductisshippedwithseveralpreinstalledCAcerticates.Ifrequired,additionalCAcerticatescanbeinstalled:

1.GotoSetup>SystemOptions>Security>Certicates.

2.ClickInstallcerticateanduploadthecerticate.

AudioSupport

SelectEnableaudiosupporttoallowclientstoretrieveaudiostreamsfromtheAxisproduct.Forinformationonhowtocongure

audiosettings,seeAudioSettings,onpage27.

Note

DeselectingthisoptionwilldisableaudiogloballyintheAxisproduct,forconguredeventsandproleswithaudioaswell.

Date&Time

TheAxisproduct’sdateandtimesettingsareconguredunderSystemOptions>Date&Time.

CurrentServerTimedisplaysthecurrentdateandtime(24hclock).Thetimecanbedisplayedin12hclockinthetextoverlay(see

below).

Tochangethedateandtimesettings,selectthepreferredTimemodeunderNewServerTime:

•Synchronizewithcomputertime–Setsdateandtimeaccordingtothecomputer’sclock.Withthisoption,dateand

timearesetonceandwillnotbeupdatedautomatically.

•SynchronizewithNTPServer–ObtainsdateandtimefromanNTPserver.Withthisoption,dateandtimesettingsare

updatedcontinuously.ForinformationonNTPsettings,seeNTPConguration,onpage53.

IfusingahostnamefortheNTPserver,aDNSservermustbecongured.SeeDNSConguration,onpage52.

•Setmanually–Allowsyoutomanuallysetdateandtime.

IfusinganNTPserver,selectyourTimezonefromthedrop-downlist.Ifrequired,checkAutomaticallyadjustfordaylightsaving

timechanges.

TheDate&TimeFormatUsedinImagesisthedateandtimeformatdisplayedasatextoverlayinthevideostream.Usethe

predenedformatsorseeFileNaming&Date/TimeFormatsintheonlinehelp

forinformationonhowtocreatecustomdateand

timeformats.Toincludedateandtimeintheoverlaytext,gotoVideo&AudioandselectIncludedateandIncludetime.

AXISQ1614NetworkCamera

SystemOptions

Network

BasicTCP/IPSettings

TheAxisproductsupportsIPversion4andIPversion6.Bothversionscanbeenabledsimultaneously,andatleastoneversion

mustalwaysbeenabled.

IPv4AddressConguration

Bydefault,theAxisproductissettouseIPv4(IPversion4)andtoobtaintheIPaddressautomaticallyviaDHCP.TheIPv4settingsare

conguredunderSystemOptions>Network>TCP/IP>Basic.

DHCP(DynamicHostCongurationProtocol)allowsnetworkadministratorstocentrallymanageandautomatetheassignmentof

IPaddresses.DHCPshouldonlybeenabledifusingdynamicIPaddressnotication,oriftheDHCPcanupdateaDNSserver.Itis

thenpossibletoaccesstheAxisproductbyname(hostname).

IfDHCPisenabledandtheproductcannotbeaccessed,runAXISIPUtilitytosearchthenetworkforconnectedAxisproducts,orreset

theproducttothefactorydefaultsettings(seepage59)andthenperformtheinstallationagain.

TouseastaticIPaddress,checkUsethefollowingIPaddressandspecifytheIPaddress,subnetmaskanddefaultrouter.

IPv6AddressConguration

IfIPv6(IPversion6)isenabled,theAxisproductwillreceiveanIPaddressaccordingtothecongurationinthenetworkrouter.

ToenableIPv6,gotoSystemOptions>Network>TCP/IP>Basic.OthersettingsforIPv6shouldbeconguredinthenetworkrouter.

ARP/Ping

Theproduct’sIPaddresscanbeassignedusingARPandPing.Forinstructions,seeAssignIPAddressUsingARP/Ping,onpage51.

TheARP/Pingserviceisenabledbydefaultbutisautomaticallydisabledtwominutesaftertheproductisstarted,orassoonasanIP

addressisassigned.Tore-assignIPaddressusingARP/Ping,theproductmustberestartedtoenableARP/Pingforanadditional

twominutes.

Todisabletheservice,gotoSystemOptions>Network>TCP/IP>BasicandcleartheoptionEnableARP/PingsettingofIPaddress.

Pingingtheproductisstillpossiblewhentheserviceisdisabled.

AssignIPAddressUsingARP/Ping

Theproduct'sIPaddresscanbeassignedusingARP/Ping.Thecommandmustbeissuedwithin2minutesofconnectingpower.

1.AcquireafreestaticIPaddressonthesamenetworksegmentasthecomputer.

2.Locatetheserialnumber(S/N)ontheproductlabel.

3.Openacommandpromptandenterthefollowingcommands:

Linux/Unixsyntax

arp-s<IPaddress><serialnumber>temp

ping-l408<IPaddress>

Linux/Unixexample

arp-s192.168.0.12500:40:8c:18:10:00temp

ping-l408192.168.0.125

Windowssyntax(thismayrequirethatyourunthecommandpromptasanadministrator)

arp-s<IPaddress><serialnumber>

AXISQ1614NetworkCamera

SystemOptions

ping-l408-t<IPaddress>

Windowsexample(thismayrequirethatyourunthecommandpromptasanadministrator)

arp-s192.168.0.12500-40-8c-18-10-00

ping-l408-t192.168.0.125

4.Checkthatthenetworkcableisconnectedandthenrestarttheproductbydisconnectingandreconnectingpower.

5.ClosethecommandpromptwhentheproductrespondswithReplyfrom192.168.0.125:...orsimilar.

6.Openabrowserandtypehttp://<IPaddress>intheLocation/Addresseld.

ForothermethodsofassigningtheIPaddress,seetheInstallationandManagementSoftwareCDorthedocumentAssignanIP

AddressandAccesstheVideoStreamonAxisSupportwebatwww.axis.com/techsup

Note

•ToopenacommandpromptinWindows,opentheStartmenuandtypecmdintheRun/Searcheld.

•TousetheARPcommandinWindows7/WindowsVista,right-clickthecommandprompticonandselectRunas

administrator.

•ToopenacommandpromptinMacOSX,opentheTerminalutilityfromApplication>Utilities.

AXISVideoHostingSystem(AVHS)

AVHSusedinconjunctionwithanAVHSservice,provideseasyandsecureInternetaccesstoliveandrecordedvideoaccessiblefrom

anylocation.FormoreinformationandhelptondalocalAVHSServiceProvidergotowww.axis.com/hosting

TheAVHSsettingsareconguredunderSystemOptions>Network>TCPIP>Basic.ThepossibilitytoconnecttoanAVHSservice

isenabledbydefault.Todisable,cleartheEnableAVHSbox.

One-clickenabled-Presstheproduct’scontrolbutton(seeHardwareOverview,onpage6)toconnecttoanAVHSserviceoverthe

Internet.Onceregistered,AlwayswillbeenabledandtheAxisproductstaysconnectedtotheAVHSservice.Iftheproductisnot

registeredwithin24hoursfromwhenthebuttonispressed,theproductwilldisconnectfromtheAVHSservice.

Always-TheAxisproductwillconstantlyattempttoconnecttotheAVHSserviceovertheInternet.Onceregisteredtheproductwill

stayconnectedtotheservice.Thisoptioncanbeusedwhentheproductisalreadyinstalledanditisnotconvenienttousethe

one-clickinstallation.

AXISInternetDynamicDNSService

AXISInternetDynamicDNSServiceassignsahostnameforeasyaccesstotheproduct.Formoreinformation,seewww.axiscam.net

ToregistertheAxisproductwithAXISInternetDynamicDNSService,gotoSystemOptions>Network>TCP/IP>Basic.Under

Services,clicktheAXISInternetDynamicDNSServiceSettingsbutton(requiresaccesstotheInternet).Thedomainnamecurrently

registeredatAXISInternetDynamicDNSservicefortheproductcanatanytimeberemoved.

Note

AXISInternetDynamicDNSServicerequiresIPv4.

AdvancedTCP/IPSettings

DNSConguration

DNS(DomainNameService)providesthetranslationofhostnamestoIPaddresses.TheDNSsettingsareconguredunderSystem

Options>Network>TCP/IP>Advanced.

SelectObtainDNSserveraddressviaDHCPtousetheDNSsettingsprovidedbytheDHCPserver.

Tomakemanualsettings,selectUsethefollowingDNSserveraddressandspecifythefollowing:

AXISQ1614NetworkCamera

SystemOptions

Domainname-Enterthedomain(s)tosearchforthehostnameusedbytheAxisproduct.Multipledomainscanbeseparatedby

semicolons.Thehostnameisalwaystherstpartofafullyqualieddomainname,forexample,myserveristhehostnameinthe

fullyqualieddomainnamemyserver.mycompany.comwheremycompany.comisthedomainname.

Primary/SecondaryDNSserver-EntertheIPaddressesoftheprimaryandsecondaryDNSservers.ThesecondaryDNSserveris

optionalandwillbeusediftheprimaryisunavailable.

NTPConguration

NTP(NetworkTimeProtocol)isusedtosynchronizetheclocktimesofdevicesinanetwork.TheNTPsettingsareconguredunder

SystemOptions>Network>TCP/IP>Advanced.

SelectObtainNTPserveraddressviaDHCPtousetheNTPsettingsprovidedbytheDHCPserver.

Tomakemanualsettings,selectUsethefollowingNTPserveraddressandenterthehostnameorIPaddressoftheNTPserver.

HostNameConguration

TheAxisproductcanbeaccessedusingahostnameinsteadofanIPaddress.ThehostnameisusuallythesameastheassignedDNS

name.ThehostnameisconguredunderSystemOptions>Network>TCP/IP>Advanced.

SelectObtainhostnameviaIPv4DHCPtousehostnameprovidedbytheDHCPserverrunningonIPv4.

SelectUsethehostnametosetthehostnamemanually.

SelectEnabledynamicDNSupdatestodynamicallyupdatelocalDNSserverswhenevertheAxisproduct’sIPaddresschanges.

Formoreinformation,seetheonlinehelp

Link-LocalIPv4Address

Link-LocalAddressisenabledbydefaultandassignstheAxisproductanadditionalIPaddresswhichcanbeusedtoaccess

theproductfromotherhostsonthesamesegmentonthelocalnetwork.TheproductcanhaveaLink-LocalIPandastatic

orDHCP-suppliedIPaddressatthesametime.

ThisfunctioncanbedisabledunderSystemOptions>Network>TCP/IP>Advanced.

HTTP

TheHTTPportusedbytheAxisproductcanbechangedunderSystemOptions>Network>TCP/IP>Advanced.Inadditiontothe

defaultsetting,whichis80,anyportintherange1024–65535canbeused.

HTTPS

TheHTTPSportusedbytheAxisproductcanbechangedunderSystemOptions>Network>TCP/IP>Advanced.Inadditionto

thedefaultsetting,whichis443,anyportintherange1024–65535canbeused.

ToenableHTTPS,gotoSystemOptions>Security>HTTPS.Formoreinformation,seeHTTPS,onpage48.

NATtraversal(portmapping)forIPv4

Anetworkrouterallowsdevicesonaprivatenetwork(LAN)toshareasingleconnectiontotheInternet.Thisisdonebyforwarding

networktrafcfromtheprivatenetworktothe“outside”,thatis,theInternet.Securityontheprivatenetwork(LAN)isincreased

sincemostroutersarepre-conguredtostopattemptstoaccesstheprivatenetwork(LAN)fromthepublicnetwork(Internet).

UseNATtraversalwhentheAxisproductislocatedonanintranet(LAN)andyouwishtomakeitavailablefromtheother

(WAN)sideofaNATrouter.WithNATtraversalproperlycongured,allHTTPtrafctoanexternalHTTPportintheNATrouter

isforwardedtotheproduct.

NATtraversalisconguredunderSystemOptions>Network>TCP/IP>Advanced.

AXISQ1614NetworkCamera

SystemOptions

Note

•ForNATtraversaltowork,thismustbesupportedbytherouter.TheroutermustalsosupportUPnP

•Therouterhasmanydifferentnames:“NATrouter”,“Networkrouter”,“InternetGateway”,”Broadbandrouter”,“Broadband

sharingdevice”or“Homerewall”buttheessentialpurposeofthedeviceisthesame.

Enable/Disable-Whenenabled,theAxisproductattemptstocongureportmappinginaNATrouteronyournetwork,usingUPnP

NotethatUPnP

mustbeenabledintheproduct(seeSystemOptions>Network>UPnP).

UsemanuallyselectedNATrouter-SelectthisoptiontomanuallyselectaNATrouterandentertheIPaddressfortherouterin

theeld.Ifnorouterisspecied,theproductautomaticallysearchesforNATroutersonyournetwork.Ifmorethanonerouteris

found,thedefaultrouterisselected.

AlternativeHTTPport-SelectthisoptiontomanuallydeneanexternalHTTPport.Entertheportnumberintheeld.Ifnoportis

enteredhere,aportnumberisautomaticallyselectedwhenNATtraversalisenabled.

Note

•AnalternativeHTTPportcanbeusedorbeactiveevenifNATtraversalisdisabled.ThisisusefulifyourNATrouterdoesnot

supportUPnPandyouneedtomanuallycongureportforwardingintheNATrouter.

•Ifyouattempttomanuallyenteraportthatisalreadyinuse,anotheravailableportisautomaticallyselected.

•Whentheportisselectedautomaticallyitisdisplayedinthiseld.Tochangethis,enteranewportnumberandclickSave.

FTP

TheFTPserverrunningintheAxisproductenablesuploadofnewrmware,userapplications,etc.TheFTPservercanbedisabled

underSystemOptions>Network>TCP/IP>Advanced.

Note

ThisFTPserverhasnothingtodowiththeproduct’sabilitytotransferimagesviaFTPtootherlocationsandservers.

RTSP

TheRTSPserverrunningintheAxisproductallowsaconnectingclienttostartanH.264stream.TheRTSPportnumbercanbe

changedunderSystemOptions>Network>TCP/IP>Advanced.Thedefaultportis554.

Note

H.264videostreamswillnotbeavailableiftheRTSPserverisdisabled.

SOCKS

SOCKSisanetworkingproxyprotocol.TheAxisproductcanbeconguredtouseaSOCKSservertoreachnetworksontheother

sideofarewallorproxyserver.ThisfunctionalityisusefuliftheAxisproductislocatedonalocalnetworkbehindarewall,and

notications,uploads,alarms,etcneedtobesenttoadestinationoutsidethelocalnetwork(forexampletheInternet).

SOCKSisconguredunderSystemOptions>Network>SOCKS.Formoreinformation,seetheonlinehelp.

QoS(QualityofService)

QoS(QualityofService)guaranteesacertainlevelofaspeciedresourcetoselectedtrafconanetwork.AQoS-awarenetwork

prioritizesnetworktrafcandprovidesagreaternetworkreliabilitybycontrollingtheamountofbandwidthanapplicationmayuse.

TheQoSsettingsareconguredunderSystemOptions>Network>QoS.UsingDSCP(DifferentiatedServicesCodepoint)values,the

Axisproductcanmarkthefollowingtypesoftrafc:livevideo,liveaudio,event/alarmtrafcandmanagementtrafc.

Note

LiveaudioDSCPwillbeequaltolivevideoDSCPifH.264overRTSPisused.

AXISQ1614NetworkCamera

SystemOptions

SNMP

TheSimpleNetworkManagementProtocol(SNMP)allowsremotemanagementofnetworkdevices.AnSNMPcommunityisthe

groupofdevicesandmanagementstationrunningSNMP.Communitynamesareusedtoidentifygroups.

TheAxisproductcanbeconguredtosupportSNMPontheSystemOptions>Network>SNMPpage.

Dependingonthelevelofsecurityrequired,selecttheversiononSNMPtouse.

SNMPv1/v2providesthelowestlevelofsecurity.Thecommunitynamecanbespeciedasapasswordforreadorread/write

accesstoallsupportedSNMPdevices.ThedefaultpasswordfortheReadcommunityispublicandthedefaultpasswordforthe

Writecommunityiswrite.

Note

IfHTTPSisenabled,SNMPv1andSNMPv2cshouldbedisabled.

TrapsforSNMPv1/v2areusedbytheAxisproducttosendmessagestoamanagementsystemonimportanteventsandstatus

changes.CheckEnabletrapsandentertheIPaddresswherethetrapmessageshouldbesentandtheTrapcommunitythat

shouldreceivethemessage.

Thefollowingtrapsareavailable:

•Coldstart

•Warmstart

•Linkup

•Authenticationfailed

SNMPv3providesencryptionandsecurepasswords.TousetrapswithSNMPv3,anSNMPv3managementapplicationisrequired.

TouseSNMPv3,HTTPSmustbeenabled,seeHTTPS,onpage48.ToenableSNMPv3,checktheboxandprovidetheinitialuser

password.

Note

Theinitialpasswordcanonlybesetonce.Ifthepasswordislost,theAxisproductmustberesettofactorydefault,see

ResettoFactoryDefaultSettings,onpage59.

UPnP

TheAxisproductincludessupportforUPnP

.UPnP

isenabledbydefaultandtheproductisautomaticallydetectedbyoperating

systemsandclientsthatsupportthisprotocol.

UPnP

canbedisabledunderSystemOptions>Network>UPnP

RTP/H.264

TheRTPportrangeandmulticastsettingsareconguredunderSystemOptions>Network>RTP.

TheRTPportrangedenestherangeofportsfromwhichthevideo/audioportsareautomaticallyselected.Formulticaststreams,

onlycertainIPaddressesandportnumbersshouldbeused.

SelectAlwaysMulticastVideoand/orAlwaysMulticastAudiotostartmulticaststreamingwithoutopeninganRTSPsession.

Bonjour

TheAxisproductincludessupportforBonjour.Bonjourisenabledbydefaultandtheproductisautomaticallydetectedbyoperating

systemsandclientsthatsupportthisprotocol.

BonjourcanbedisabledunderSystemOptions>Network>Bonjour.

AXISQ1614NetworkCamera

SystemOptions

Storage

SDCard

TheAxisproductsupportsSDcardswithupto64GBofstorage.Forbestrecordingperformance,useanSDHCorSDXCcard

withspeedclass10.

NOTICE NOTICE

NOTICE

Topreventcorruptionofrecordings,theSDcardshouldalwaysbeunmountedbeforeitisejected.

TheAxisproductsupportsSDcardswiththefollowinglesystems:

•ext4—recommendedduetoitsresilienceagainstdatalossifthecardisejectedorifthereisabruptpowerloss.Toaccess

datastoredonthecardfromtheWindowsoperatingsystem,athird-partyext4driverorapplicationisrequired.

•vFAT—mostSDcardsarepre-formattedwithvFATwhenpurchased.

Ifrequired,theSDcardcanbemanuallyformattedtothedesiredlesystem.ToformattheSDcard:

1.InserttheSDcardintheSDcardslot.

2.GotoSystemOptions>StorageandclickSDCard.

3.ClickFormatandselectthedesiredlesystem.

ToautomaticallyformatanSDcardtoext4lesystem,selectAutoformattooption.TheAxisproductwillchecktheinsertedSDcard

toverifyifitslesystemisext4,ifnottheproductwillautomaticallyformattheSDcardintoext4lesystem.

Itisrecommendedthat,Autoformatbeenabledtoext4inorderfortheneworinsertedSDcardtoautomaticallybeformattedtoext4

asitisamorereliablelesystem.

Note

Duringformattinganypreviousdatastoredonthediskwillbelost.

Mountingisdoneautomaticallywhenthecardisinsertedorwhentheproductisstarted.Amanualmountisonlyrequiredifthe

cardhasbeenunmountedandnotejectedandre-inserted.

TounmounttheSDcard:

1.GotoSystemOptions>StorageandclickSDCard.

2.ClickUnmount.

3.Thecardcannowberemoved.

TheSDcardismanagedontheSystemOptions>Storagepage.ClickSDCardtoopenStorageManagement.

Ifthecard’sstatusshowsasfailed,clickCheckdisktoseeiftheproblemcanbefoundandthentryRepair.Thisoptionisonly

availableforSDcardswithext4.ForSDcardswithvFAT,useacardreaderorcomputertotroubleshootthecard.

Toavoidllingthecard,itisrecommendedtoremoverecordingscontinuously.UnderRecordingSettings,selectRemoverecordings

olderthanandselectthenumberofdaysorweeks.

Tostopwritingtothecardandprotectrecordingsfrombeingremoved,selectLockunderRecordingSettings.

NetworkShare

NetworkshareallowsyoutoaddnetworkstoragesuchasaNAS(NetworkAttachedStorage)oranyserverthatusesCIFS(Common

InternetFileSystem)andusethemforstorageofrecordings.

Toaddanetworkshare:

1.GotoSystemOptions>Storage.

AXISQ1614NetworkCamera

SystemOptions

2.ClickNetworkShare.

3.EntertheIPaddress,DNSorBonjournametothehostserverintheHosteld.

4.EnterthenameoftheshareintheShareeld.Subfolderscannotbeused.

5.Ifrequired,selectThesharerequiresloginandentertheusernameandpassword.

6.ClickConnect.

ToclearallrecordingsanddatafromtheAxisproduct’sfolderonthedesignatedshare,clickClearunderStorageTools.

Toavoidllingtheshare,itisrecommendedtoremoverecordingscontinuously.UnderRecordingSettings,selectRemoverecordings

olderthanandselectthenumberofdaysorweeks.

Tostopwritingtotheshareandprotectrecordingsfrombeingremoved,selectLockunderRecordingSettings.

I/OPorts

TheAxisproductprovidestwocongurableinputandoutputportsforconnectionofexternaldevices.Forinformationabout

howtoconnectexternaldevices,seeConnectors,onpage68.

TheI/OportsareconguredunderSystemOptions>Ports&Devices>I/OPorts.Selecttheportdirection(InputorOutput).The

portscanbegivendescriptivenamesandtheirNormalstatescanbeconguredasOpencircuitorGroundedcircuit.

I/OPorts

TheAxisproductprovidestwocongurableinputandoutputportsforconnectionofexternaldevices.Forinformationabout

howtoconnectexternaldevices,seeConnectors,onpage68.

COMPort

TheAxisproducthasoneRS-485/RS-422serialport.Theportsupportsthefollowingmodes:

•GenericHTTPallowstheAxisproducttoreceivedataandsendcommandsviaHTTP.

•PanTiltZoomisusedtocontrolaPTZdevice.ThePTZdevicerequiresadriver.SeeInstallingaPTZdriverformore

information.Driverscanbedownloadedfromwww.axis.com

•GenericTCP/IPallowstheAxisproducttoreceivedataandsendcommandsviaTCP/IP.Daisychainserver-AllowsDaisy

chainclientstocommunicatewiththeAxisproduct.

SelectthedesiredPortTypefromthedrop-downlist.FormoreinformationonSerialPortSettingsandDaisyChainPortSettings

seetheonlinehelp

PortStatus

ThelistontheSystemOptions>Ports&Devices>PortStatuspageshowsthestatusoftheproduct’sinputandoutputports.

Accelerometer

Thelevelingassistantthathelpstolevelthecameraisenabledbydefault.Todisableit,de-selecttheEnablelevelingassistantoption

fromSystemOptions>Ports&Devices>AccelerometerandclickSave.Toenablelevelingassistant,clickReset.

Maintenance

TheAxisproductprovidesseveralmaintenancefunctions.TheseareavailableunderSystemOptions>Maintenance.

ClickRestarttoperformacorrectrestartiftheAxisproductisnotbehavingasexpected.Thiswillnotaffectanyofthecurrent

settings.

AXISQ1614NetworkCamera

SystemOptions

ClickRestoretoresetmostsettingstothefactorydefaultvalues.Thefollowingsettingsarenotaffected:

•thebootprotocol(DHCPorstatic)

•thestaticIPaddress

•thedefaultrouter

•thesubnetmask

•thesystemtime

•theIEEE802.1Xsettings

•thefocusposition

•uploadedapplicationsarekeptbutmustberestarted

ClickDefaulttoresetallsettings,includingtheIPaddress,tothefactorydefaultvalues.Thisbuttonshouldbeusedwithcaution.The

Axisproductcanalsoberesettofactorydefaultusingthecontrolbutton,seeResettoFactoryDefaultSettings,onpage59.

ToidentifytheproductortesttheStatusLED,clickFlashLEDunderIdentifyandspecifythedurationinseconds,minutesorhours.

Thiscanbeusefulforidentifyingtheproductamongotherproductsinstalledinthesamelocation.

Forinformationaboutrmwareupgrade,seeUpgradingtheFirmware,onpage61.

Support

SupportOverview

TheSystemOptions>Support>SupportOverviewpageprovidesinformationontroubleshootingandcontactinformation,

shouldyourequiretechnicalassistance.

SeealsoTroubleshooting,onpage61.

SystemOverview

TogetanoverviewoftheAxisproduct’sstatusandsettings,gotoSystemOptions>Support>SystemOverview.Informationthat

canbefoundhereincludesrmwareversion,IPaddress,networkandsecuritysettings,eventsettings,imagesettingsandrecentlog

items.ManyofthecaptionsarelinkstotheproperSetuppage.

Logs&Reports

TheSystemOptions>Support>Logs&Reportspagegenerateslogsandreportsusefulforsystemanalysisandtroubleshooting.If

contactingAxisSupport,pleaseprovideavalidServerReportwithyourquery.

SystemLog-Providesinformationaboutsystemevents.

AccessLog-Listsallfailedattemptstoaccesstheproduct.TheAccessLogcanalsobeconguredtolistallconnectionstothe

product(seebelow).

ServerReport-Providesinformationabouttheproductstatusinapop-upwindow.TheAccessLogisautomaticallyincluded

intheServerReport.

Youcanviewordownloadtheserverreport.Downloadingtheserverreportcreatesa.ziplethatcontainsacompleteserverreport

textleinUTF–8format.SelecttheIncludesnapshotwithdefaultimagesettingsoptiontoincludeasnapshotoftheproduct’s

LiveViewthatalsoshowsthesettingsspeciedunderVideoStream>Image>ImageAppearance.Theserverreport.zipleshould

alwaysbeincludedwhencontactingsupport.

ParameterList-Showstheproduct'sparametersandtheircurrentsettings.Thismayproveusefulwhentroubleshootingor

whencontactingAxisSupport.

AXISQ1614NetworkCamera

SystemOptions

ConnectionList-Listsallclientsthatarecurrentlyaccessingmediastreams.

CrashReport-Generatesanarchivewithdebugginginformation.Thereporttakesseveralminutestogenerate.

TheloglevelsfortheSystemLogandtheAccessLogaresetunderSystemOptions>Support>Logs&Reports>Conguration.

TheAccessLogcanbeconguredtolistallconnectionstotheproduct(selectCritical,Warnings&Info).

Advanced

Scripting

Scriptingallowsexperienceduserstocustomizeandusetheirownscripts.

NOTICE NOTICE

NOTICE

ImproperusemaycauseunexpectedbehaviorandlossofcontactwiththeAxisproduct.

Axisstronglyrecommendsthatyoudonotusethisfunctionunlessyouunderstandtheconsequences.AxisSupportdoesnotprovide

assistanceforproblemswithcustomizedscripts.

ToopentheScriptEditor,gotoSystemOptions>Advanced>Scripting.Ifascriptcausesproblems,resettheproducttoits

factorydefaultsettings,seepage59.

Formoreinformation,seewww.axis.com/developer

FileUpload

Files,forexamplewebpagesandimages,canbeuploadedtotheAxisproductandusedascustomsettings.Touploadale,go

toSystemOptions>Advanced>FileUpload.

Uploadedlesareaccessedthroughhttp://<ipaddress>/local/<user>/<filename>where<user>isthe

selectedusergroup(viewer,operatororadministrator)fortheuploadedle.

PlainCong

PlainCongisforadvanceduserswithexperienceofAxisproductconguration.Mostparameterscanbesetandmodiedfromthis

page.Helpisavailablefromthestandardhelppages.

ToopenPlainCong,gotoSystemOptions>Advanced>PlainCong.AxisSupportdoesnotprovideassistance.

ResettoFactoryDefaultSettings

Important

Resettofactorydefaultshouldbeusedwithcaution.Aresettofactorydefaultwillresetallsettings,includingtheIP

address,tothefactorydefaultvalues.

Note

TheinstallationandmanagementsoftwaretoolsareavailableontheCDsuppliedwiththeproductandfromthesupport

pagesonwww.axis.com/techsup

Toresettheproducttothefactorydefaultsettings:

1.Disconnectpowerfromtheproduct.

2.Pressandholdthecontrolbuttonandreconnectpower.SeeHardwareOverview,onpage6.

3.Keepthecontrolbuttonpressedforabout15–30secondsuntilthestatusLEDindicatorashesamber.

AXISQ1614NetworkCamera

SystemOptions

4.Releasethecontrolbutton.TheprocessiscompletewhenthestatusLEDindicatorturnsgreen.Theproducthasbeenreset

tothefactorydefaultsettings.IfnoDHCPserverisavailableonthenetwork,thedefaultIPaddressis192.168.0.90

5.Usingtheinstallationandmanagementsoftwaretools,assignanIPaddress,setthepassword,andaccessthevideostream.

6.Refocustheproduct.

Itisalsopossibletoresetparameterstofactorydefaultviathewebinterface.GotoSetup>SystemOptions>Maintenance.

AXISQ1614NetworkCamera

Troubleshooting

CheckingtheFirmware

Firmwareissoftwarethatdeterminesthefunctionalityofnetworkdevices.Oneofyourrstactionswhentroubleshootingaproblem

shouldbetocheckthecurrentrmwareversion.Thelatestversionmaycontainacorrectionthatxesyourparticularproblem.The

currentrmwareversionintheAxisproductisdisplayedinthepageSetup>BasicSetupandinSetup>About.

UpgradingtheFirmware

WhenyouupgradetheAxisproductwiththelatestrmwarefromAxiswebsite,theproductreceivesthelatestfunctionalityavailable.

Alwaysreadtheupgradeinstructionsandreleasenotesavailablewitheachnewrelease,beforeupgradingthermware.

Toupgrade,followtheseinstructions:

1.Savethermwareletoyourcomputer.ThelatestversionofthermwareisavailablefreeofchargefromAxiswebsite

atwww.axis.com/techsup

2.GotoSetup>SystemOptions>Maintenanceintheproduct’swebpages.

3.UnderUpgradeServer,clickBrowseandlocatetheleonyourcomputer.ClickUpgrade.

Afterstartingtheupgradeprocess,alwayswaitatleast5–10minutesbeforerestartingtheproduct,evenifyoususpectthe

upgradehasfailed.

AXISCameraManagementcanbeusedformultipleupgrades.Seewww.axis.comformoreinformation.

Note

•Yourdealerreservestherighttochargeforanyrepairattributabletofaultyupgradebytheuser.

•Preconguredandcustomizedsettingsaresavedwhenthermwareisupgraded(providingthefeaturesareavailableinthe

newrmware)althoughthisisnotguaranteedbyAxisCommunicationsAB.

EmergencyRecoveryProcedure

Ifpowerornetworkconnectionislostduringtheupgrade,theprocessfailsandtheproductbecomesunresponsive.FlashingredStatus

indicatorindicatesafailedupgrade.Torecovertheproduct,followthestepsbelow.Theserialnumberisfoundontheproduct’slabel.

AXISQ1614NetworkCamera

Troubleshooting

1.InUNIX/Linux,typethefollowingfromthecommandline:

arp-s<IPaddress><serialnumber>temp

ping-l408<IPaddress>

InWindows,typethefollowingfromacommand/DOSprompt(thismayrequirethatyourunthecommandpromptas

anadministrator):

arp-s<IPaddress><serialnumber>

ping-l408-t<IPaddress>

2.Iftheproductdoesnotreplyin30seconds,restartitandwaitforareply.PressCTRL+CtostopPing.

3.Openabrowserandtypeintheproduct’sIPaddress.Inthepagethatopens,usetheBrowsebuttontoselecttheupgrade

letouse.ThenclickLoadtorestarttheupgradeprocess.

4.Aftertheupgradeiscomplete(1–10minutes),theproductautomaticallyrestartsandshowsasteadygreenonthe

Statusindicator.

5.Reinstalltheproduct,referringtotheInstallationGuide.

Iftheemergencyrecoveryproceduredoesnotgettheproductupandrunningagain,contactAxissupportatwww.axis.com/techsup/

Symptoms,PossibleCausesandRemedialActions

ProblemssettingtheIPaddress

WhenusingARP/Ping

Trytheinstallationagain.TheIPaddressmustbesetwithintwominutesafterpowerhasbeen

appliedtotheproduct.EnsurethePinglengthissetto408.Forinstructions,seeAssignIPAddress

UsingARP/Ping,onpage51.

Theproductislocatedona

differentsubnet

IftheIPaddressintendedfortheproductandtheIPaddressofthecomputerusedtoaccessthe

productarelocatedondifferentsubnets,youwillnotbeabletosettheIPaddress.Contactyour

networkadministratortoobtainanIPaddress.

TheIPaddressisbeingused

byanotherdevice

DisconnecttheAxisproductfromthenetwork.RunthePingcommand(inaCommand/DOS

window,typepingandtheIPaddressoftheproduct):

•Ifyoureceive:Replyfrom<IPaddress>:bytes=32;time=10...

thismeansthattheIPaddressmayalreadybeinusebyanotherdeviceonthenetwork.

ObtainanewIPaddressfromthenetworkadministratorandreinstalltheproduct.

•Ifyoureceive:Requesttimedout,thismeansthattheIPaddressisavailable

forusewiththeAxisproduct.Checkallcablingandreinstalltheproduct.

PossibleIPaddressconict

withanotherdeviceonthe

samesubnet.

ThestaticIPaddressintheAxisproductisusedbeforetheDHCPserversetsadynamicaddress.

ThismeansthatifthesamedefaultstaticIPaddressisalsousedbyanotherdevice,theremay

beproblemsaccessingtheproduct.

Theproductcannotbeaccessedfromabrowser

Cannotlogin

WhenHTTPSisenabled,ensurethatthecorrectprotocol(HTTPorHTTPS)isusedwhenattempting

tologin.Youmayneedtomanuallytypehttporhttpsinthebrowser’saddresseld.

Ifthepasswordfortheuserrootislost,theproductmustberesettothefactorydefaultsettings.

SeeResettoFactoryDefaultSettings,onpage59.

AXISQ1614NetworkCamera

Troubleshooting

TheIPaddresshasbeen

changedbyDHCP

IPaddressesobtainedfromaDHCPserveraredynamicandmaychange.IftheIPaddresshas

beenchanged,useAXISIPUtilityorAXISCameraManagementtolocatetheproductonthe

network.Identifytheproductusingitsmodelorserialnumber,orbytheDNSname(ifthename

hasbeencongured).

Ifrequired,astaticIPaddresscanbeassignedmanually.Forinstructions,seetheInstallationand

ManagementSoftwareCDorthedocumentAssignanIPAddressandAccesstheVideoStreamon

AxisSupportwebatwww.axis.com/techsup.

Certicateerrorwhenusing

IEEE802.1X

Forauthenticationtoworkproperly,thedateandtimesettingsintheAxisproductshouldbe

synchronizedwithanNTPserver.SeeDate&Time,onpage50.

Theproductisaccessiblelocallybutnotexternally

RoutercongurationTocongureyourroutertoallowincomingdatatrafctotheAxisproduct,enabletheNAT-traversal

featurewhichwillattempttoautomaticallyconguretheroutertoallowaccesstotheAxis

product,seeNATtraversal(portmapping)forIPv4,onpage53.TheroutermustsupportUPnP

Firewallprotection

ChecktheInternetrewallwithyournetworkadministrator.

Defaultroutersrequired

CheckifyouneedtoconguretheroutersettingsfromSystemOptions>Network>TCP/IP>

Basic.

ProblemswithstreamingH.264

ProblemswithAXISMedia

Control(InternetExplorer

only)

ToenabletheupdatingofvideoimagesinInternetExplorer,setthebrowsertoallowActiveX

controls.Also,makesurethatAXISMediaControlisinstalledonyourcomputer.

NoH.264displayedinthe

client

CheckthattherelevantH.264connectionmethodsandcorrectinterfaceareenabledintheAMC

ControlPanel(streamingtab).SeeAXISMediaControl(AMC),onpage16.

IntheAMCControlPanel,selecttheH.264tabandclickSettodefaultH.264decoder.

CheckthatRTSPisenabledunderSystemOptions>Network>TCP/IP>Advanced.

MulticastH.264only

accessiblebylocalclients

Checkifyourroutersupportsmulticasting,oriftheroutersettingsbetweentheclientandthe

productneedtobecongured.TheTTL(TimeToLive)valuemayneedtobeincreased.

NomulticastH.264

displayedintheclient

CheckwithyournetworkadministratorthatthemulticastaddressesusedbytheAxisproduct

arevalidforyournetwork.

Checkwithyournetworkadministratortoseeifthereisarewallpreventingviewing.

Installationofadditional

ActiveXcomponent

restrictedorprohibited

ConguretheAxisproducttouseaJavaappletforupdatingvideoimagesinyourbrowser.Goto

Setup>LiveViewCongandselectJavaappletunderDefaultviewer.

PoorrenderingofH.264

images

Ensurethatyourgraphicscardisusingthelatestdriver.Thelatestdriverscanusuallybe

downloadedfromthemanufacturer’swebsite.

Colorsaturationisdifferent

inH.264andMotionJPEG

Modifythesettingsforyourgraphicsadapter.Refertotheadapter’sdocumentationformore

information.

AXISQ1614NetworkCamera

Troubleshooting

Lowerframeratethan

expected

SeePerformanceConsiderations,onpage70.

Reducethenumberofapplicationsrunningontheclientcomputer.

Limitthenumberofsimultaneousviewers.

Checkwiththenetworkadministratorthatthereisenoughbandwidthavailable.

CheckintheAMCControlPanel(H.264tag)thatvideoprocessingisNOTsettoDecodeonly

keyframes.

Lowertheimageresolution.

SetaCaptureModethatprioritizesframerate.Changingthecapturemodetoprioritizeframerate

willlowerthemaximumresolution.SeeCaptureMode,onpage22.

Themaximumframespersecondisdependentontheutilityfrequency(60/50Hz)oftheAxis

product.SeeTechnicalSpecications,onpage66.

StatusandNetworkindicatorLEDsareashingredrapidly

Hardwarefailure

ContactyourAxisreseller.

Videoandimageproblems,general

Imageunsatisfactory

CheckthevideostreamandcamerasettingsunderSetup>Video&Audio>VideoStreamand

Setup>Video&Audio>CameraSettings.

MotionDetectiontriggersunexpectedly

Changesinluminance

Motiondetectionisbasedonchangesinluminanceintheimage.Thismeansthatifthereare

suddenchangesinthelighting,motiondetectionmaytriggermistakenly.Lowerthesensitivity

settingtoavoidproblemswithluminance.

Noaudio

Incorrectsetup

Checkthesoundcardinthecomputer.Ensurethatmuteisnotselectedandthatthevolume

settingsarecorrect.

CheckthatEnableaudiosupportisselectedunderSetup>SystemOptions>Security>Audio

Support.

CheckthatthecorrectAudioInputsourceisselectedunderSetup>Video&Audio>Audio

Settings.

Pooraudioquality

Stuttering

Reducethenumberoflistenersandviewers.Decreaseimageresolutionandcompression.

Unsynchronizedaudioand

videousingH.264

Synchronizetheproduct’sdateandtimesettingswithanNTPserver.GotoSetup>System

Options>Date&Time.

Distortedaudio

CheckthatthecorrectAudioInputsourceisselectedunderSetup>Video&Audio>Audio

Settings.

FeedbackloopsFeedbackloopsmightappearinfull-duplexmode.Trymovingthemicrophoneorthespeaker,or

usehalf-duplexmodeinstead.

AXISQ1614NetworkCamera

Troubleshooting

Storageanddiskmanagementproblems

Storagedisruption

Astoragedisruptionalarmissentifastoragedeviceisunavailable,removed,full,lockedorifother

readorwriteproblemsoccur.Toidentifythesourceoftheproblem,checktheSystemLogunder

SystemOptions>Support>Logs&Reports.Dependingontheproblem,itmightbenecessaryto

re-mountthestoragedevice.

Forinformationonhowtosetupastoragedisruptionalarm,seeEvents,onpage41.

Videocannotberecorded

CheckthattheSDcardisnotwriteprotected(thatis,readonly).

SDcardcannotbemountedReformattheSDcardandthenclickMount.

AXISQ1614NetworkCamera

TechnicalSpecications

Function/group

Item

Specications

Models

AXISQ1614:720presolution,indoor

Imagesensor

ProgressivescanRGBCMOS1/3”

Lens

P-iris,IRcorrected,varifocal,CS-mount,supportforDC-Irislens,megapixelresolution

2.8-8mm,F1.2

Horizontalangleofview100°-34°

Verticalangleofview:75°-26°

Diagonalangleofview:135°-43°

DayandnightAutomaticallyremovableinfrared-cutlter

Minimum

illumination

Color:0.05lux,F1.2,B/W:0.008lux,F1.2inCapturemodeD1and720p25/30fps

Color:0.1lux,F1.2,B/W:0.02lux,F1.2inCapturemode720p50/60fps

Color:0.4lux,F1.2,B/W0.06lux,F1.2withdynamiccapture

Camera

Shuttertime

25/30fpsmode:1/29500-2;1/231-1/44withdynamiccaptureenabled

50/60fpsmode:1/43500-2

ExtendedD1mode:1/29500-2

Video

compression

H.264(MPEG-4Part10/AVC)

H.264BaselineandMainProle

MotionJPEG

Resolutions

25/30fpsmode:1280x960*to160x90

50/60fpsmode:1280x720to160x90

ExtendedD1mode:768x576to160x90

*1400x1050(1.4MP)scaledresolutionavailableviaVAPIX®

FramerateLightndermode:Upto60fpsin60Hzcapturemode,upto50fpsin50Hzcapturemode

WDR:30fpsin60Hzcapturemode,25fpsin50Hzcapturemode

Videostreaming

Multiple,individuallycongurablestreamsinH.264andMotionJPEG

ControllableframerateandbandwidthVBR/CBRH.264

Imagesettings

Compression,color,brightness,sharpness,contrast,whitebalance,exposurecontrol,

exposurezones,backlightcompensation,netuningofbehavioratlowlight

WDR:Upto120dB(0.4-400,000lux)dependingonscene,shadowandhighlightrecovery

Textandimageoverlay

Privacymask

Mirroringofimages

Rotation:0°,90°,180°,270°,Auto

CorridorFormat™

Video

Users20simultaneoususers

Unlimitednumbersofusersusingmulticast(H.264)

AXISQ1614NetworkCamera

TechnicalSpecications

Function/group

Item

Specications

AudiostreamingTwo-way,fullduplex

Audio

compression

AACLC8/16/32kHz,8-128kbit/s

G.711PCM8kHz64kbit/s

G.726ADPCM8kHz32kbit/sor24kbit/s

Congurablebitrate

Audioinput

AudioInput:3.5mmjackfor:mic/linein.Max80mVppformicrophone/Max6.2Vpp

forlinesignal

Impedance:Min1kΏ,Mic-poweractivated;Min4kΏline

Tip:BalancedMicrophoneHot(+)In/UnbalancedMicrophoneIn/LineIn

Ring:BalancedMicrophoneCold(-)In

Sleeve:Ground

Powertoexternalelectretmicrophone:1.3V-3.0V(DC)

SNR:>40dB

Optional12Vphantompower

Audiooutput3.5mmjackforlineout.Max2.8Vpp

Impedance:Max100Ώ,normal<1Ώ

SNR:>40dB

Audio

Builtin

microphone

specication

Sensitivity:-36dB±2dB(0db=1V/Pa,1kHz)

Maxinput(SPL):100dB

SecurityPasswordprotection,IPaddressltering,IEEE802.1X*networkaccesscontrol,HTTPS**

encryption,digestauthentication,useraccesslog.

*ThisproductincludessoftwaredevelopedbytheOpenSSLProjectforuseintheOpenSSL

Toolkit

Network

Supported

protocols

IPv4/v6,HTTP,HTTPS*,SSL/TLS*,QoSLayer3DiffServ,FTP,SMTP,Bonjour,UPnP™,

SNMPv1/v2c/v3(MIB-II),DNS,DynDNS,NTP,RTSP,RTP,TCP,UDP,IGMP,RTCP,ICMP,

DHCP,ARP,SOCKS,CIFS/SMB.

*ThisproductincludessoftwaredevelopedbytheOpenSSLProjectforuseintheOpenSSL

Toolkit.

Application

Programming

Interface

OpenAPIforsoftwareintegration,includingVAPIX®andAXISCameraApplication

Platform;specicationsatwww.axis.com

AXISVideoHostingSystem(AVHS)withOne-ClickCameraConnectionONVIFProleS;

specicationatwww.onvif.org

IntelligentvideoVideomotiondetection,activetamperingalarm

SupportforAXISCameraApplicationPlatformenablinginstallationofadditional

applications

EventtriggersIntelligentvideo,edgestorageevents,videomotiondetection,activetamperingalarm,

audiodetection,temperature,externalinput,AXISCameraApplicationPlatform

EventactionsFileuploadviaFTP,HTTP,networkshareandemail

Noticationviaemail,HTTPandTCP

Externaloutputactivation

Videoandaudiorecordingtoedgestorage

Pre-andpost-alarmvideobuffering

Videobuffer

48MBpre-andpostalarm

Videoaccessfrom

webbrowser

Cameraliveview

Videorecordingtole(ASF)

CustomizableHTMLpages

WindowsVista,XP,Windows7,andServer2008

DirectX9corhigher

Forotheroperatingsystemsandbrowersseewww.axis.com/techsup

System

Integration

AXISQ1614NetworkCamera

TechnicalSpecications

Function/group

Item

Specications

Built-inaidsin

software

Focusassistant,levellingassistant,remotebackfocus,pixelcounter

Casing

Camera:Metal(zinc)

ToolsTorxscrewdriverT20

Memory256MBRAM,128MBFlash

Batterybacked-upreal-timeclock

Power

8-28VDCorPoweroverEthernet(PoE)IEEE802.3af/IEEE802.3atType1Class3,

max.10.8W

Connectors

RJ4510BASE-T/100BASE-TXPoE

RS485/422

DCinput

Terminalblockfor1alarminputand1output

3.5mmjackformicin(max80mVpp)orlinemonoinput(max6.2Vpp)

3.5mmjackforlinemonooutput(max2.8Vpp)toactivespeaker

Edgestorage

SD/SDHC/SDXCmemorycardslot(cardnotincluded)

Memorycardupto64GB

Supportforrecordingtonetworkshare(NetworkAttachedStorageorleserver)

Operating

conditions

0°Cto50°C(32°Fto122°F),humidity20-85%RH(non-condensing)

Approvals

EN55022ClassB,EN61000-3-2,EN61000-3-3,EN55024,EN61000-6-1,EN

61000-6-2

FCCPart15SubpartBClassAandB

ICES-003ClassB

VCCIClassB,C-tickAS/NZSCISPR22ClassB

KCCKN22ClassB,KN24

IEC/EN/UL60950-1

Weight

925g(2lb)

Dimensions

58.5x82x87mm(2.3x3.2x3.4in)

Included

accessories

Stand,connectorkit,1AllenkeyResitorx20,InstallationGuide,Installationand

ManagementSoftwareCD,Windowsdecoder1-userlicense

Video

management

software(not

included)

AXISCameraCompanion(included),AXISCameraStationandvideomanagement

softwarefromAxis’ApplicationDevelopmentPartners(notincluded).See

www.axis.com/products/video/software

General

Optional

accessories

AXIST90AIlluminators

AXIST8414InstallationDisplay

AXISPoweroverEthernetMidspan1-port

AXISCameraStationandvideomanagementsoftwarefromAxis’Application

DevelopmentPartners

Connectors

I/Oconnector

4–pinterminalblockfor:

•Auxiliarypower(DCoutput)

•DigitalInput

•DigitalOutput

•0VDC(-)

AXISQ1614NetworkCamera

TechnicalSpecications

FunctionPinNotes

Specications

0VDC(-)

DCoutput

Canbeusedtopowerauxiliaryequipment.

Note:Thispincanonlybeusedaspowerout.

12VDC

Maxload=50mA

Digitalinput–Connecttopin1toactivate,orleaveoating

(unconnected)todeactivate.

0tomax30VDC Congurable

(InputorOutput)

3–4

Digitaloutput–Connectedtopin1whenactivated,oating

(unconnected)whendeactivated.Ifusedwithaninductive

load,e.g.arelay,adiodemustbeconnectedinparallelwith

theload,forprotectionagainstvoltagetransients.

0tomax30VDC,opendrain,

100mA

12 V max 50 mA

I/Oconguredasinput

I/Oconguredasoutput

AudioConnector

3.5mmaudioconnectors

(stereo)

123

AudioInput

AudioOutput

1Tip

BalancedMicrophoneHot(+)In/Unbalance

MicrophoneIn/LineIn

2Ring

BalancedMicrophoneCold(-)In

Lineout(mono)

3SleeveGroundGround

AXISQ1614NetworkCamera

TechnicalSpecications

RS-485/422Connector

Two2-pinterminalblocksforRS485/RS422serialinterface.Theserial

portcanbeconguredtosupport:

•Two-wireRS485halfduplex

•Four-wireRS485fullduplex

•Two-wireRS422simplex

•Four-wireRS422fullduplexpointtopointcommunication

1 2

RX/TX TX

RS-485/422

FunctionPinNotes

RS485BaltRS485/422RX(B)

RS485AaltRS485/422RX(A)

RXpairforallmodes(combinedRX/TXfor2-wireRS485)

RS485/RS422TX(B)

RS485/RS422TX(A)

TXpairforRS422and4-wireRS485

Important

Therecommendedmaximumcablelengthis30m(98.4ft).

PerformanceConsiderations

Whensettingsupyoursystem,itisimportanttoconsiderhowvarioussettingsandsituationswillaffectperformance.Somefactors

affecttheamountofbandwidth(thebitrate)required,otherscanaffecttheframerate,andsomeaffectboth.Iftheloadonthe

CPUreachesitsmaximum,thiswillalsoaffecttheframerate.

Thefollowingfactorsareamongthemostimportanttoconsider:

•Highimageresolutionand/orlowercompressionlevelsresultinimagescontainingmoredata.Bandwidthaffected.

•AccessbylargenumbersofMotionJPEGand/orunicastH.264clients.Bandwidthaffected.

•Simultaneousviewingofdifferentstreams(resolution,compression)bydifferentclients.Effectonframerateand

bandwidth.

•AccessingMotionJPEGandH.264videostreamssimultaneously.Framerateandbandwidthaffected.

•Heavyusageofeventsettingsaffecttheproduct’sCPUload.Framerateaffected.

•Heavynetworkutilizationduetopoorinfrastructure.Bandwidthaffected.

•Viewingonpoorlyperformingclientcomputerslowersperceivedperformance.Framerateaffected.

UserManualVer.M3.2

AXISQ1614NetworkCamera

Date:December2013

PartNo.55118

Axis Q1614~EOL Q1614 Network Camera 0550-001

Product's Documents

Axis Q1614 User Manual

Specifications

Axis Q1614~EOL Questions and Answers
