Before using the appliance carefully read Health and Safety guide.
APPLIANCE
PRODUCT DESCRIPTION
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.whirlpool.eu/register
You can download the Safety Instructions and
the Use and Care Guide, by visiting our website
docs.whirlpool.eu and following the Instructions on
the back of this booklet.
1. Upper rack
2. Foldable ๎ aps
3. Upper rack height adjuster
4. Upper spray arm
5. Lower rack
6. Cutlery basket
7. Lower spray arm
8. Filter Assembly
9. Salt reservoir
10. Detergent and Rinse Aid dispensers
11. Rating plate
12. Control panel
0000 000 00000
Service:
1
2
3
4
5
6
7
9
8
1011
12
12345678910
11
1. ON-OFF/Reset button with indicator light
2. Program selection button
3. Salt re๎ ll indicator light
4. Rinse Aid re๎ ll indicator light
5. Program number and delay time indicator
6. Tablet indicator light
DAILY REFERENCE
GUIDE
CONTROL PANEL
7. Display
8. Multizone indicator lights
9. Multizone button
10. Delay button
11. START/Pause button with indicator light / Tab
