MODEL:
Electronic Window Air Conditioner
Thank you very much for purchasing our air conditioner.Please read this owner`s manual carefully before
using your air conditioner.
15,000 BTU
18,000 BTU
25,000 BTU
TABLEOFCONTENTS
4
3
5
6
4
7
6
10
10
14
Annual Maintenance
13
14
14
AIR CONDITIONER SAFETY
2
INSTALLATION REQUIREMENTS
3
Tools and Parts
Electrical Requirements
Location Requirements
INSTALLATION INSTRUCTIONS
Unpack the Air Conditioner
Prepare Air Conditioner for Installation
Window Air Conditioner Installation
Completer Installation
Starting Your Air Conditioner
AIR CONDITIONER USE
Using the Remote Control
Changing Air Direction
Exhaust Air Vent
NormalSounds
AIR CONDITIONER CARE
15
15
Cleaning the Front Panel
15
Repairing Paint Damage
15
TROUBLESHOOTING
16
11
Cleaning the Air Filter
15
2
AIR CONDITIONER SAFETY
You can be killed or seriouslyinjuredif you dont immediately '
You
can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard istell you how to reduce the chance of injuryand tell you what can , ,
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol .
This symbol alerts you to potential hazards that can kill or hurt you and others .
All safety messages will follow the safety alert symbol and either the wordDANGERorWARNING "" "."
These words mean :
follow instructions .
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
To reducetherisk offireelectricalshock orinjurywhenusingyourairconditionerfollowthesebasicprecautions , , :
SAVETHESEINSTRUCTIONS
Unplug air conditioner before servicing .
Use two or more people to move and install air conditioner.
Plug intoa groundedprong outlet 3 .
Do notremovegroundprong .
Do not use an adapter.
Do not use an extension cord .
You safety and the safety of others are very important.
Before throwing the device, it is necessary to pull back the battery cells and get rid of them safety for recycling reasons.
When you need to disposal of the unit consult our dealer. If pipes are removed incorrectly, refrigerant may blow out and
please recycle or dispose of the packaging material for product in an environmentally responsible manner.
Never store or ship the air conditioner upside down or sideways to avoid damage to the compressor .
The wiring diagram is sho
wn at nameplate on the air conditioner.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
DISPOSING OF THE UNIT
come into contact with your skin, causing injury. Releasing refrigerant into the atmosphere also damages the environments.
Do not use means to accelerate the defrosting process
or to clean, other than those recommended by the
manufacturer.
The appliance shall be stored in a room without
continuously operating ignition sources(for example:
open flames, an operating gas appliance or an
operating electric heater.
Do not pierce or bum refrigerant tubing. Be aware that
refrigerants may not contain an odor.
Keep ventilation openings clear of obstruction.
The maximum refrigerant charg
e amount is shown at
nameplate on the air conditioner.
Do not drill holes in the unit.
When handling, installing, and operating the appliance,
care should be taken to avoid damage to the
refrigerant tubing.
Maintenance, cleaning, and service should only be
performed by technicians properly trained and qualified
in the use of flammable refrigerants.
Dispose of air conditioner in accordance with Federal
and Local Regulations. Flammable refrigerants require
special disposal procedures. Contact your local authorities
for the environmentally safe disposal of your air conditioner.
The appliance shall be stored so as to prevent mechanical
damage from occurring.
Wiring requirement
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
WARNING
fire, or electrical shock.
Recommended Grounding Method
To contact a qualified .electrical installer
It is the customer’s responsibility:
To assure that the electrical installation is
adequate and conforms to the Nation Electrical
Code,ANSI/NFPA 70-last edition,and all local
codes and ordinances.
Copies of the standards listed may be obtained from:
Nation Fire Protection Association
1 Batterymarch Park
Quincy,Ma 02169-7471
www.nfpa.org
This
conditioner is equipped with a power supply cord with a
three-prong grounding plug. The cord must be plugged
into a mating, grounded three-prong outlet, grounded in
acco
rdance with all local codes and ordinances. If a
mating outlet is not available, it is the customer's
responsibility to have a properly grounded three-prong
outlet installed by a qualified electrical installer.
air conditioner must be grounded. This air
208/230 V (187.2 V min. to 253 V max.)
18 A time-delay fuse or circuit breaker for
NOTE:
Your air conditioner’s device may differ from the one shown.
To test your power supply cord:
1.Plug power supply cord into a grounded 3prong outlet.
2.Press RESET (on some devices, a green light will turn on).
3.Press TEST (listen for click; Reset button will trip, and on
some devices, a green light will turn off).
4.Press and release RESET (listen for click; Reset button will
latch, and on some devices, a green light will turn on). The
power supply cord is ready for operation.
NOTE:
■The Reset button must be pushed in for proper operation.
■The power supply cord must be replaced if it fails to trip when
the test button is pressed or fails to reset.
■Do not use the power supply cord as an off/on switch. The
power supply cord is designed as a protective device.
■A damaged power supply cord must be replaced with a new
power supply cord obtained from the product manufacturer
and must not be repaired.
■The power supply cord contains no user serviceable parts.
Opening the tamper-resistant case voids all warranty and
performance claims.
A.Test button
B.Reset button
TEST
RESET
A
B
This room air conditioner is equipped with a power supply cord
required by UL. This power supply cord contains state-of-the-art
electronics that sense leakage current. If the cord is crushed, the
electronics detect leakage current and power will be
disconnected in a fraction of a second.
Power Supply Cord
Electrical Requirements
INSTALLATION REQUIREMENTS
15K cooling only
18K cooling only
25K cooling only
12K cooling and heating
115 V (103.5 V min. to 126.5 V max.)
15 A time-delay fuse or circuit breaker for
208/230 V (187.2 V min. to 253 V max.)
15 A time-delay fuse or circuit breaker for
208/230 V (187.2 V min. to 253 V max.)
20 A time-delay fuse or circuit breaker for
3
4
Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools needed
■ Phillips screwdriver
■ Scissors
■ Level
■ Tape measure
■ Cordless drill and bit
■ Pencil
1 /8"
Partssupplied
Check that all parts are included in parts package.
A Adhesive seal .
B Foam seal.
H.
Angle Brackets (2)
I.. Lock frame
(for Vinyl-Clad windows)(2)
M.
" screws (10)
N. " Long Flat Head
A
B
C
D
H
E
G
1 4
⁄
J. Sash lock
G. EVA Foam(2)
T. Remote control
S.
Air conditioner
C Side curtains (2).
D Top channel and.
K. foam sesl(2) EPDM
Bolt and Locknut (2)
3⁄4
O. " Long Bolt
and Locknut
(4)
1⁄2
P. Washer(2)
Q. Left and Right Suppert
Brackets (2)
I
J
PE foam seal
Q
F. Baffle (2)
F
P
R
E. PE foam seal
3 4 ⁄
L.
" screws (8)
NOTE:
The is not provide
for
12K cooling and heating
The is only provide for 12K cooling and heating
F. Baffle (2)、G. EVA Foam(2)
R. Lock frame
R. Lock frame
Remove packaging materials
■
Remove and dispose of/recycle packaging materials.
Remove tape and glue residue from surfaces before turning
on the air conditioner. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
Unpack the Air Conditioner
■ Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your air conditioner.
■
■
Handle the air conditioner gently.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
air conditioner .
Failure to do so can result in back or other injury .
Remove top rail from the packaging material.
S
T
5
Location Requirements
■
■
■
■
■
■
■
■
■
■
Window Installation
If AC is Blocked by Storm Window
Before You Begin
Window opening measurements:
IMPORTANT: Observe all governing codes and ordinances.
Check the location where air conditioner will be installed. Proper
installation is your responsibility. Make sure you have everything
necessary for correct installation.
The location should provide:
■
Do not use an extension cord.
The appliance shall be installed in accordance with
national wiring regulations.
Add wood as shown, or remove storm window before air.
conditioner is installed.
If storm window frame must remain, be sure the drain holes
or slots are not caulked or painted shut. Accumulated rain
water or condensation must be allowed to drain out.
■Free movement of air in room to be cooled.
■A large enough opening for the air conditioner.
NOTE: Cabinet louvers must not be obstructed. Air must be able
to pass freely through the cabinet louvers.
IMPORTANT:
IMPORT
ANT:
These instructions are for a standard double-hung
window. You will need to modify them for other
types of windows.
The air conditioner can be installed without the
side curtain panels if needed to fit in a narrow
window. See the window opening dimensions.
All supporting parts must be secured to firm
wood, masonry or metal.
The electrical outlet must be within reach of the
power cord.
Follow the dimensions in the table and
illustration for your model.
A
(With side curtain panels)
B
ModelsA B
12K BTU
15K BTU
24K BTU
25K BTU
17(432mm) min "
19 1 min /10" (485mm)
18 1 (470mm) min /2"
27- 41 " " (686mm) (1041mm)
32 2 5- 4 /" " (823mm) 4(1118mm)
29 3/5- 42 1 " /10" (752mm) (1069mm)
Read these instructions completely and carefully.
Save these instructions for local inspector’s use.
Observe all governing
codes and ordinances.
Note to Installer:
Be sure to leave these
instructions with the
Consumer.
Note to Consumer:Keep these instructions for future
reference.
Skill level:Installation of this appliance requires basic
mechanical skills.
Completion time:
Approximately 1 hour.
We recommend that two people install this product.
Proper installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the Warranty.
You MUST use all supplied parts and use proper
installation procedures as described in these
instructions when installing this air conditioner.
18K BTU
ACabinet louvers.
12K model is not the Cabinet louver
A
Board
thickness
as required,
for proper
pitch to rear,
along entire
sill. Fasten
with nails or
screws.
Storm window
frame or other
obstruction.
sash
1-1/2"min
(38 mm)
1、Locate the two Front Panel screws and remove.
These screws will be needed to re-install the Front
Panel later.
2、Push metal cabinet side inward to release plastic tabs
on each side of Front Panel.
3、Remove Front Panel from unit.
4、Remove shipping screws from top of unit and also on
both sides by the base if installed.
5、carefully remove the air conditioner from cabinet.
Install Top Angle Rail and Side Retainers
6、Add two foam inserts to holes in top of cabinet where
shipping screws were removed from.
1. Remove adhesive strip coating from foam gasket.Attach adhesive side of gasket to bottom of top angle rail.
Insert 4 screws from inside of cabinet and secure to top angle rail.
2. From inside of cabinet insert 3 screws to attach each side baffle as shown. Attach side baffles
with flat side against cabinet and angled edge toward rear of cabinet.
Remove Air Conditioner from Cabinet
NOTE: Remove any packaging material from cabinet exterior.
6
INSTALLATION INSTRUCTIONS
Prepare Air Conditioner for Installation
12K model do not need
to attach the two screws
1/4" screws
12K model do not need
to attach the two sbaffle
7
C
B
A
3/4″ long
HEX-HEAD
SCREW
Assemble Window Filler Panels
1. Place cabinet on floor, a bench, or a table.
2. Slide "I" section at end of window filler panel into side retainer on each side of the cabinet.
3. On each side of cabinet, insert top and bottom legs of window filler panel frame into channel in the top
and bottom angle rails.
4.Insert a locking screw and flat washer into hole on top leg of each window filler panel Do not
totally tighten. Allow leg to slide freely. Screws will be tightened after Section .
Place Cabinet in Window
1. Open window and mark the center of window
inner sill as shown .
2.Place cabi
net in window with cabinet bracket
securely seated over edge of inner sill as shown
in . Bring window down temporarily behind top angle
rail to hold cabinet in place.
4.For wooden window:
Fasten cabinet to window
inner sill with two 3/4" long hex head screws into
holes (You may wish to pre-drill pilot holes)
5.For Vinyl-Clad window: Place two safety locks
into the holes located in the bottom of the cabinet
and drive two 3/4" pan-head Phillips locking screws
through the safety locks into the cabinet as shown.
3. Shift cabinet left or right as needed to line up
center of cabinet on center line marked on inner
sill.
A. 3/4" screws
B. Safety Lock (Only for Vinly-Clad Window)
C. Bottom Rail Foam Seal
6. Remove protective s
trip from adhesive side of
Bottom Rail Foam Seal Apply Seal over screws
fastening bottom rail to window inner sill.
Window filler
panel
Side retainer
Top window filler
panel leg
Bottom window
filler panel leg
window
inner sill
cabinet
window outer sill
Angle of cabinet
bracket
securely seated
on
edge of inner sill.
Bracket
Window Air Conditioner Installation
Install Support Bracket
3.
Insert 1/2" long bolts through appropriate holes in
cabinet bottom given the sill width distance. Thread
the bolts into the slots of the support brackets. Tighten
lock washer nuts onto bolts.
1. Hold each support bracket flush against outside
of sill and tight to bottom of cabinet. Mark brackets
at top level of sill. Mark cabinet bottom at distance
of sill width. Remove support brackets.
MARK
MARK
" Long Bolt
and Locknut
(4)
1⁄2
2. Attach sill angle brackets to support brackets at
marked positions with flat head bolts and nuts.
Hand tighten only at this point.
RIGHT
LEFT
Angle Brackets
" Long Flat Head
Bolt and Locknut
3⁄4
" Long Bolt
and Locknut
1⁄2
4.
Adjust height of sill angle bracket so that bracket
rests securely on edge of sill, and so that cabinet
has the correct downward tilt for proper water
drainage. Tighten nuts securely.
3°
This lock frame is only provide for 12K
NOTE:
Extend Window Filler Panels and attach to top angle rail
1. Carefully raise window to expose filler panel locking screws on top angle rail. Loosen screws so filler
panels slide easily.
2. Close window behind top angle rail.
3. Attach the top angle rail to window frame: Use a drill bit to drill one hole through the hole in the
middle of top angle rail into the window frame, and drive one 3/4" locking screw through
the hole in the middle of top angle rail into the window frame as shown.
Side Louvers
Window
Sash
Sill
Angle Bracket
Window
Sill
about 3°
8
1/4"screws
A. Lower window sash
B Adhesive seal.
A
B
5Place the frame lock between the base and the
sill with 1/4" (6,5mm) screw as shown
.cabinet
Attach Window Filler Panels to Window Frame
Install Window Sash Seal and Safety Lock
Attach the EVA Foam
1.
Insert foam seal behind the top of the lower window
sash and against the glass of the upper window.
2.
Attach right angle safety lock to top window sash
as shown .
safety lock
3. If necessary, trim weather seals to needed length,
peel off protective backing, and use to plug any gaps.
A
B
C
AWindow sash .
B.Hole in side curtain
C.
3/4" screw
3/4" screw
2.Use a 1drill bit to drill a starter hole through the /8"(3mm)
hole in the top rail.
1.Pull the left-hand curtain out until it fits into the window channel.
3.Insert one of the 3/4"(20mm) screws through the left-hand
curtain and into the window sash.
In order to minimize air leaks and ensure optimal
insulation, it is necessary to install the EVA Foam on
the Curtain housing.
After the unit is installed to the window, measure
the inner width of the side curtain as shown.
1. Put one EVA Foam on the Curtain housing.
9
Measure the inner width
of the side curtain
2. Remark a line on the EVA Foam according to less 1/8
(3mm) than the measured width in, then cut the EVA
Foam along the line.
3. Remove the backing from the EVA Foam.
Attach one EVA Foam on the Curtain housing
adhesiveCurtain housing
, the side
with should facing the .
The EVA Foam is not need to attach for Models:
12K cooling and heating
B
A
A.Curtain housing
B. EVA Foam
B
A
NOTE:
A.Top of lower window sash
BFoam seal.
A
B
10
CompleteInstallation
AIR CONDITIONER USE
Operating your air conditioner properly helps you to obtain the
best possible results.
This section explains proper air conditioner operation.
IMPORTANT:
■
If you turn off the air conditioner, wait at leastminutes 3
before turning it back on. This prevents the air conditioner
from blowing a fuse or tripping a circuit breaker.
■
■
Air conditioner in the Cool mode operation the better limits:
Outdoor side 64.4~109.4°F (18~43 °C), ≤80%RH; indoor side
62.6~89.6°F (17~32°C), ≤80%RH.
Air conditioner in the Heat mode operation the better limits:
Outdoor side 19.4~75.2°F (-7~24 °C), ≤80%RH; indoor side
32~80.6°F (0~27°C), ≤80%RH.
NOTE: In the event of a power failure, your air conditioner will
operate at the previous settings when the power is restored.
1.Plug into a grounded 3 prong outlet.
2.Press RESET on the power supply cord. See "Electrical
Requi
rements".
Electrical ShockHazard
Plug intoa groundedprongoutlet 3 .
Do notremove ground prong .
Do notuse an adapter .
Do notuse an extensioncord .
Failure tofollow these instructionscan resultin death ,
fireor electrical shock, .
WARNING
Install Air Conditioner into Cabinet and Install Front Panel to Unit
1.
.
.
4.
s
.
Lift air conditioner and carefully slide into cabinet.
2CAUTION: Do not push on controls OR finned coils.
3 Be sure air conditioner is firmly seated towards rear of cabinet.
Reconnect electronics plug if present. Position vent control lever so that it will thread into its channel
in the front panel.Hook front panel top tabs into sloton cabinet top, and rotate front pan
el down so that
side tabs snap into place on cabinet. Insert 4 previously removed screws through front panel and into
air conditioner.
5 Insert air conditioner filter. Reinstall the front grille by hooking bottom tabs into slots on Front Panel
bottom, then rotating grille up to snap into place.
Vent control
correct location
11
Starting Your Air Conditioner
1.Press the power button to turn on the air conditioner.
■Dry - Dries the room. The air conditioner automatically
selects the temperature. Fan runs on Low speed only.
Fan Speed
NOTE: TheFan Speed button will operate only when the Cool,
Fan or Power Saver mode has been selected.
1.Press FAN SPEED until you see the indicator light glow for
the desired setting.
2.Choose High, MedLow.,
■High -for maximum cooling
■Med -for normal cooling
■Low -forquieter cooling
NOTE:
NOTE: When the air conditioner is turned on for the first time
after itis plugged in, the display will show the current set
temperature and will run in the ECO control .
2.Select mode. See "Mode".
3.Select fan speed. See "Fan Speed".
4.Set temperature. See "Temperature".
Mode
ON/OFF
1.Press MODE repeatedly until you see the indicator light glow
for the desired setting.
2.Choose Fan, Dry, Cool, Eco, or Heat.
■
■
■
■
Cool -
Eco -
Heat - Heats the room.
NOTE: Heat is available for heating models.
Cools the room.
FAN SPEED to select High, Med, Low.
In ECO mode,the Fan will ran at low
■
speed when compressor turn off.
■
ON/OFF
ON/OFF
TimerSleepFilterTimerSleepFilter
FAN FAN
MODE
LowMed
High
LowMed
High
FAN FAN
LowMed
High
LowMed
High
Dry
Fan
Cool
Eco
Dry
Fan
Cool
Eco
MODE
Heat
MODE
Dry
Fan
Cool
Eco
Dry
Fan
Cool
Eco
MODE
Heat
CONNECTCONNECT
NOTE:
NOTE:
Dry mode should not be used to cool the room.
Select ECO mode to initiate this function. The
fan will continue to run after the compressor shuts off
for 2 minutes(4 minutes for the first time)，so the fan
will shuts off for 10 minutes .The fan then cycles
run for 2 minutes and 10 minutes off intervals
until the room temperature is above the set
temperature, at which time the compressor turns
back on and Cooling resumes.
Fan - Only the fan runs. Press FAN SPEED to select High,
Med or Low.
■
■
Temperature
Press the plus UP button to raise the temperature. Each (∧)
time you press or hold the plus button, the UP (∧)
temperature will go up 1°F (1°C) until it reaches 86°F (30°C).
Press the minus DOWN button to lower the temperature. Each (
∨)
time you press or hold the button, the temperature DOWN (∨)
will go down 1°F (1°C) until it reaches 61°F (16°C).
Tochange the temperature display fromF toC ° °:
Press both the MODE and buttons at the sameDOWN (
∨)
t ime for 5 seconds to switch the display from °F to °C.
After cleaning and replace the filter, press the POWER
button for resetting and the FILTER light will go off.
Cools the room and save energy.
12
Filt re
Sleep
1. The LED light on for Timer、Sleep、Filter. control panel
The function introduction See “using the remote control”.
2.
Timer
WIFI
WIFI control is available for connected models with this
logo on control panel.
CONNECTCONNECT
1. Press the CONNECT button for 5s,the LED start to falsh.
2. After the WIFI module connecting the router,the LED
keeps on.Or the LED keeps off.
Timer Sleep FilterTimer Sleep Filter
NOTE: . WIFI control is a vailable for WIFI control models
13
Using the Remote Control
NOTE: Remote control may differ in appearance.
Power
Press POWER to turn on/off air conditioner.
Mo ed
Press MODE to select Cool, ECO .Fan, Dry, , Heat
Fan Speed
Press FAN to select High, Med, Low.
NOTE:
Sleep Control
NOTES:
■
■
1. Press MODE to select Cool, Dry or ECO
2. Press FAN to select High, Med or Low.
3. Press the up or down arrow button to set the temperature.
4. Press SLEEP. After 10 seconds, the lights on the control
panel display will dim.
.
NOTE: The mode and temperature may be adjusted during
Sleep control. Fan speed is automatically set to LOW.
In Dry mode Fan speed cannot be set.,
■
NOTE:
One CR2025 battery (included) powers
the remote control. Replace battery
remote control starts to lose power.
Disposal of battery old batteries must be removed and
disposed of in accordance with current legislation as they
are harmful to the environment.
■
Please ensure the correct direction
for polarity of the cell same as the
in dicator on the bracket.
A
A. Bracket
When the first use,please remove the insulated
plastic patch.
after 6 months of use, or when the
■
■
■
5. To turn off Sleep control, press SLEEP again. or wait 8 hours
for the air conditioner to turn off automatically.
NOTE: The air conditioner will return to previous settings after
Sleep control is turned off.
Temperature
DIMMER
Press the DIMMER button to turn off the control panel display.
■
When in DIMMER mode, new control inputs will return display
NOTE:
to normal.
In the Cooling mode,Dry mode, ECO mode,
temperature will increase by 4°F(2°C)at most, during 2hours,
and continues running at that temperature until auto shut off.
the set
In Heating mode, the set temperature will decrease by 4°F(2°C)
at most, during 2hours, and continues running at that
temperature until auto shut off.
■ Press the plus UP button to raise the temperature. Each (∧)
time you press or hold the plus button, the UP (
∧)
temperature will go up 1°F (1°C) until it reaches 86°F (30°C).
■ Press the minus DOWN button to lower the temperature. Each (∨)
time you press or hold the button, the temperature DOWN (∨)
will go down 1°F (1°C) until it reaches 61°F (16°C).
14
To set timer for a 1 – 24 hour delay on – off operation:
Timer
2. Press up or down arrow button to change the delay time from
1 hour to 24 hours.
3. Press TIMER on remote control again for TIMER
confirmation and TIMER indicator light on the air
conditioner control will be on.
4. To cancel the TIMER, press the TIMER on remote and
the TIMER indicator light will be off.
1. Press TIMER on remote control, LED display on the air
conditioner control panel will flash.
When the light is on, it will remain on for 180
hours or until you press Clean Filter button.
NOTE:
1. When the Filter indicator light is lit, remove, clean
and replace the air filter. See “Cleaning the Air Filter”.
2. Press
Power button on the machine, or FILTER
button on remote
to reset the filter, after cleaning
and replacing the air filter.
Filter
Changing Air Direction
Use the Vertical Level Vane to direct the air right or left. Use the whole cartridge to direct air up, down or straight ahead.
A.Vertical Level Vane
B. Cartridge
A
B
Exhaust Air Vent
■Pull out the exhaust air vent control to Open the exhaust air
vent and draw stale or smoky air from the room.
■Push in the exhaust air vent control to close the exhaust air
vent for maximum continuous cooling.
NOTE: The exhaust air vent control will function only when the
Fan Speed control is operating.
Normal Sounds
When your air conditioner is operating normally, you may hear
sounds such as:
■Droplets of water hitting the condenser, causing a pinging or
clicking sound. The water droplets help cool the condenser.
■Air movement from the fan.
■Clicks from the thermostat cycle.
■Vibrations or noise due to poor wall or window construction.
■A high-pitched hum or pulsating noise caused by the modern
high-efficiency compressor cycling on and off.
A.Exhaust air vent control
A
15
AIR CONDITIONER CARE
Your new air conditioner is designed to give you many years of dependable service. This section tells you how to clean and care for your
air conditioner properly. Call your local authorized dealer for an annual checkup. Remember the cost of this service call is your
responsibility.
Cleaning the Air Filter
The air filter is removable for easy cleaning. A clean filter helps
remove dust, lint, and other particles from the air and is important
for best cooling and operating ef ficiency. Check the filter every
2 weeks to see whether it needs cleaning.
NOTE: Do not operate the air conditioner without the filter in
place.
1.Turn off the air conditioner.
2.Open the front panel. Grasp the filter by the center and
pull up and out.
3.Use a vacuum cleaner to clean the air filter Ifthe air filter is .
very dirty, wash it in warm water with a mild detergent. Do not
wash the air filter in the dishwasher or use any chemical
cleaners. Air dry the filter completely before replacing to
ensure maximum efficiency.
4.Replace the air filter back into the air conditioner, and colse
the front panel.
Cleaning the Front Panel
1.Turn off the air conditioner.
2.Clean the front panel with a soft, damp cloth.
3.Air dry the front panel completely.
Repairing Paint Damage
Check onceor twice a year for paint damage. This is very
important, especially in areas near oceans or where rust is a
problem. If needed, touch up with a good grade enamel paint.
Annual Maintenance
Your air conditioner needs annual maintenance to help ensure
steady, top performance throughout the year. Call your local
authorized dealer to schedule an annual checkup. The expense
of anannual inspection is your responsibility.
16
TRLESHOOTINGOUB
Beforecalling for servicetry the sugge , stions below to see whether you can solve your problem without outside help.
Air conditioner willnotoperate
■
The power supply cord is unplugged. Plug into grounded
3prong outlet. See "Electrical Requirements”.
■The power supply cord has tripped (Reset button has
popped out). Pressandrelease RESET (listen for click; Reset
button will latch and on some devices, a green light will turn
on) to resume operation.
■A householdfuse has blownor circuit breaker has ,
tripped. Replace the fuse or reset the circuit breaker. If the
problem continues, call an electrician. See "Electrical
Requirements”.
■The Power button has not been pressed. Press the Power
button.
■The local power has failed. Wait for power to be restored.
Air conditioner blows fuses or trips circuit breakers
■Too many appliances are being used on the same circuit.
Unplug or relocate appliances that share the same circuit.
■Timedelay fuse or circuit breaker of the wrong capacity -
is being used. Replace with a time-delay fuse or circuit
breaker of the correct capacity. See "Electrical
Requirements”.
■An extension cord is being used. Do not use an extension
cord with this or any other appliance.
■You are trying to restart the air conditioner too soon after
turning off the air conditioner. Wait at least minutes after 3
turning off the air conditioner before trying to restart the air
conditioner.
Air conditioner power supply cord trips Reset button (
pops out)
■Disturbances in your electrical current can trip (Reset
button will pop out) the power supply cord.
release RESET (listen for click; Reset button will latch and on
some devices, a green light will turn on) to resume operation.
■Electrical overloading, overheating, cord pinching or
aging can trip (Reset button will pop out) the power
supply cord.
RESET (listen for click; Reset button will latch and on some
devices, a green light will turn on) to resume operation.
NOTE: A damaged power supply cord must be replaced with a
new power supply cord obtained from the product manufacturer
and must not be repaired.
Air conditioner seems to run too much
■The current air conditioner replaced an older model. The
use ofmore efficient components may cause the air
conditioner to run longer than an older model, but the total
energy consumption will be less. Newer air conditioners do
not emit the "blast” of cold air you may be accustomed to
from older air conditioners, but this is not an indication of
lesser cooling capacity or efficiency. Refer to the efficiency
rating (EER) and capacity rating (in Btu/h) marked on the air
conditioner.
■The air conditioner is in a heavily occupied room, or heat-
producing appliances are in use in the room. Use exhaust
vent fans while cooking or bathing and try not to use heat-
producing appliances during the hottest part of the day. A
higher capacity air conditioner may be required, depending
on the sizeof the room being cooled.
Air conditioner cycles on and off too much or does not
cool
■The air conditioner is not properly sized for your room.
Check the cooling capabilities of your room air conditioner.
Room air conditionersare not designed to cool multiple
rooms.
■The filter is dirty or obstructed by debris. Clean the filter.
■The inside evaporator and outside condenser coils are
dirty or obstructed by debris. See Annual Maintenance.
■There is excessive heat or moisture (open container
cooking, showers, etc.) in the room. Use a fan to exhaust
heat or moisture from the room. Try not to use heat-
producing appliances during the hottest part of the day.
■The louvers are blocked. Install the air conditioner in a
location where the louvers are free from curtains, blinds,
furniture, etc.
Electrical ShockHazard
Plug intoa groundedprongoutlet 3 .
Do notremove ground prong .
Do notuse an adapter .
Do notuse an extensioncord .
Failure tofollow these instructionscan resultin death ,
fireor electrical shock, .
WARNING
After correcting the problem, press and release
Press and
17
■The temperature of the room you are trying to cool is
extremely hot. Allow extra time for the air conditioner to cool
off a very hot room.
■Windows or doors to the outside are open. Close all
windows and doors.
■The Temp control is not at a cool enough setting. Adjust
the Temp control to a cooler setting by pressing the minus
button to reduce the temperature. Set the Fan Speed control
to the highest setting.
Water drips from cabinet into your house
■The air conditioner is not properly leveled. The air
conditioner should slope slightly downward toward the
outside. Level the air conditioner to provide a downward
slope toward the outside to ensure proper drainage. See the
Installation Instructions.
NOTE: Do not drill a hole in the bottom of the metal base and
condensate pan.
For any questions or Technical Support,
Please Call Customer Service: 1-844-801-8880
