PARTICULATE FILTER P3R - PACK OF 2
MODEL NO: 9007
1. INTRODUCTION
AP3R Particulate filter provides protection against solid particles and water based aerosols. Suitable for
use with the Sealey 9000 half face mask. Conforms to EN 143:2000. Maximum filtration levels 30 x OEL
Type Examination Ref.: UE/557/2021/1437
Notified Body: Centralny Instytut Ochrony Pracy – Panstwowy Instytut Badawczy (CIOP-
PIB) (notified body number 1437)
2. FILTER PROTECTION
T-B lters of class P2 (P3) when completed with an appropriate two-lter face part (half mask, mask) protect the respiratory system
against non-toxic and moderately toxic (P3 - toxic) solid aerosols or water-based aerosols (dust, smoke) and liquid aerosols (mists),
provided that the concentration of the dispersed phase of the aerosol does not exceed the value of 12 x NDS (P3 - 50 x NDS) when
completed with a half mask, and 16.5 x NDS (P3 – 1000 x NDS) when completed with a mask. The P2 (P3) lter with carbon eece
additionally protects against odours and unpleasant odours as well as the irritating eects of aerosols and organic vapours. This makes
it possible to use protective equipment equipped with T-B P2 (P3) R-A lters in an atmosphere contaminated with organic substances,
provided that their concentration does not exceed the MRL value.
P2 - Penetration: < 3%, P3 - Penetration: < 0.05%
P2 - Breathing resistance (47.5 l/min.): < 160 Pa, P3 - Breathing resistance (47.5 l/min.): < 260 Pa
MARKS MEANING CLASS GAS FILTERS PARTICULATE FILTERS
A Filter against organic gases and vapours with a
boiling point > 65⁰C
1 Gas concentration
1000 ppm (0.1%)
Penetration 20%
AX Filter against lter against organic gases and
vapours with a boiling point < 65⁰C
2 Gas concentration
5000 ppm (0.5%)
Penetration 6%
B Filter against inorganic gases and vapors
excluding carbon monoxide
3 Gas concentration
10000 ppm (1%)
Penetration 0.05%
E Filter against sulfur dioxide and other acid gases
K Filter against ammonia and organic vapours
derived from ammonia
MARKS
P Filter against particulate (dust and aerosols) T-B, T-BL, T-BM – lter type
P2 and P3 – lter class according to EN 43:2000/A1:2006
A- lter containing carbon eece
R – reusable lter
VENTUM – lter manufacturer
R Filter reusable
NR Filter non reusable
D Filter passes the optional Dolomite clogging test
2.1. P2 and P3 grade T-B lters are manufactured with three types of bayonet connectors. To distinguish
the type of connector, the lters have appropriate extensions in the name, namely:
2.1.1. VENT ESKA T-B P2 (P3) R and T-B P2 (P3) R-A lters have a bayonet connector that allows them to
be mounted with half masks: SECURA 2000, Advantage 200, 300, 400 and masks: Advantage 1000, 3000 or MAG-2
2.1.2. VENT ELKA T-BL P2 (P3) R and T-BL A P2 (P3) R lters have a bayonet connector that allows them to be mounted with half masks or
masks with BLS connectors
2.1.3. The VENT EMKA T-BM P2 (P3) R and T-BM A P2 (P3) R lters have a bayonet connector that allows them to be mounted with half
masks or masks with a bayonet connector, such as those from 3M
The use of T-B lters with other facepieces requires checking the compatibility of their bayonet connector with the lter connector.
2.2. Respirators and masks should be adjusted to the user’s face before use in accordance with the instructions for use of the protective
equipment in question.
2.3. Assess whether the lters meet the requirements for existing hazards
2.4. Respirators and masks with T-B lters of class P2 (P3) do not protect against carbon monoxide. Do not use half masks and masks with
lters in the area of res.
2.5. Half masks and masks with T-B lters of class P2 (P3) should not be used where oxygen deciency (below 19% vol.) may occur, e.g. in
manholes, ducts, unventilated rooms with small cubic capacity.
NOTE: If it is necessary to replace the lters, replace both lters in use with new ones at the same time. It is forbidden to replace one
lter and leave the lter previously used in the equipment.
9007 Issue 1 01/05/24
Original Language Version
© Jack Sealey Limited
REFER TO INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE
AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
P2 APPLICATION EXAMPLES THREAT TYPE
1 - Sanding softwoods (except beech and oak)
2 - Mechanical rust removal (sanding), plaster and plastic sanding
3 - Mechanical processing of steel: cutting, machining, grinding
4 - Powder coating (except paints containing lead chromate)
5 - Mining and processing of hard coal and lignite, granite, marble, sandstone, dolomite
6 - Mining and processing of metal ores (except zinc and lead)
7 - Iron Casting & Casting Machining
8 - Mechanical machining of aluminium and aluminium alloys
9 - Sanding wood with copper-containing water
10 - Mechanical Paint Stripping
11 - Powder coating with paints containing lead chromate
12 - TIG/MIG/MAG/ welding, oxy-fuel cutting, brazing, brazing
13 - Agriculture - articial fertilizers (preparation, pouring, spreading).
1 - Fine particles and dust
2 - Particles and ne particles
3 - Metallic dusts, particles
4 - Dust, ne particles
5 - Dust, ne particles
6 - Dust, ne particles, mists
7 - Dust, ne particles, mists
8 - Dust, ne particles
9 - Particles, ne particles, mists
10 - Dust, ne particles
11 - Dust, ne particles
12 - Fumes
13 - Fine particles, dusts
P3 APPLICATION EXAMPLES THREAT TYPE
1 - Sanding softwoods (except beech and oak)
2 - Dusts that cause pneumoconiosis - especially silicosis dusts containing free silica
(SiO2): quartz, chalcedony, tridinite, cristobalite, opal, quartz glass, cement, coal,
lignite, talc, mineral wool, soil, grindstones.
3 - Chemical, glass, optical, electronic, foundry, construction, etc.
4 - Agriculture - articial fertilizers (preparation, pouring, spreading).
5 - Asbestos dusts are classied as extremely harmful dusts.
6 - Hardwood sanding
7 - Mechanical rust removal (sanding), plaster and plastic sanding.
8 - Welding: TIG/MIG/MAG/ welding, gas welding, oxy-fuel cutting, soldering, brazing
9 - Machining: cutting, machining, grinding
1 - Fine particles and dust
2 - Dust and ne particles
3 - Dust and ne particles
4 - Dust, ne particles
5 - Dust, ne particles
6 - Dust, ne particles
7 - Particles and ne particles
8 - Fine metallic particles and fumes, ozone
9 - Metallic dusts, Particles
NOTE: Italics in the application examples mean that it is sucient to use P1 lters Filters with carbon eece (letter A in the name)
additionally protect against odours and unpleasant odours as well as the irritating eects of aerosols and organic vapours. Half masks
and masks equipped with this type of lters eectively reduce the negative eects associated with exhaust emissions. This makes
it possible to use protective equipment equipped with carbon eece lters in an atmosphere contaminated with organic substances,
provided that their concentration does not exceed the MRL value. Individual protective equipment with lters with carbon eece can
be used, for example, in electric welding, in the operation of trains powered by internal combustion engines, in the pharmaceutical
industry, in breweries, in tanneries, in forensics, during service and maintenance works and other work in the atmosphere where
unpleasant odours and odours may occur, e.g. removing waste from septic tanks and manholes, cleaning garbage cans. The use of a
carbon layer in the lters slightly increases the breathing resistance, but signicantly expands their protective parameters.
3. STORAGE & CLEANING
Filters should be stored in the factory packaging (plastic bag, cardboard) in dry rooms, under the conditions indicated on the pictogram.
In case of damage or deterioration, replace the lter. DO NOT clean or maintain. The replacement of the lters must be determined
through the implementation of a respiratory protection program which ensures that they are replaced before the end of their service life.
4. OBSOLESCENCE
Filters stored in accordance with the recommendations retain their functional (protective) properties for 36 months from the date of
manufacture.
5. FILTER DISPOSAL
Once lters have been used, they must be disposed of according to the current national legislation.
EU | Sealey EU Ltd, Farney Street, Carrickmacross, Co. Monaghan, A81 PK68 Ireland
UK | Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
REGISTER YOUR
PURCHASE HERE
This document has been drawn up according to Regulation (EU) 2016/425 as amended to apply to GB for Personal Protective
Equipment. The declaration of conformity can be accessed at www.sealey.co.uk.
