Installation Diagram
FE-CDRC-4
Parts List
A 2X Rectangle Stand
B 2X Round Stand
C 2X Rectangle Bottom Tray
D 2X Round Bottom Tray
E 2X Rectangle Water Pan
F 2X Round Water Pan
G 2X Rectangle Cover
H 2X Round Cover
I 6X Fuel Holder
J 2X 1/1 Rectangle Food Pan
K 6X 1/3 Rectangle Food Pan
L 2X 1/1 Round Food Pan
1
2
3
Fix the round stand（B) with screws so that the chafer will be more stable for supporting
the food.
Fix the round bottom tray (D) and the legs of the round stand (B) with screws. Then place
the fuel holder (I)on the round bottom tray (D).
Place the round water pan ( F）in the rack (B）. Fill some water into the round water pan
(F). Now place the 1/1 round food pan (L) according to your food quantity in the round
water pan (F). Then put the round cover (H) on.
B
D
B
I
F
B
L
H
1
2
3
Unfold the two struts of the rectangle stand (A) as shown and put the stand up.
Fix the rectangle bottom tray (C) and the legs of the rectangle stand (A) with screws. Then
place the fuel holder (2xI)on the rectangle bottom tray (C).
Place the rectangle water pan ( E）in the rectangle stand (A）. Fill some water into the
rectangle water pan (E). Now place the 1/3 rectangle food pan(3xK) or the 1/1 rectangle
food pan (2xJ) according to your food quantity in the rectangle water pan (E). Then put
the rectangle cover(G) on.
or
G
A
C
I I
K
K
K
E
A
J
J
A
A
Separate the food pan and the water
pan.
Step 4
Put on gloves (package included) to
prevent scratches.
Step 1
Tips for seperating FESTA ESSENTIAL stainless steel pans
Step 2
Hold the corners of the food pan and
the water pan with both hands, and
break them apart.
Step 3
4
Pry open the four corners with a screwdriver
which in the package,the more places you
pry to get more air in, the easier it is to pry
open.
