3 DRAWER MID-BOXES WITH BALL BEARING
SLIDES
MODEL NO: AP223, AP225, AP226, AP223B,
AP225B, AP226B
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
8 DO NOT open more than one draw at a time.
9 Close lid, lock draws before moving.
8 DO NOT stand on the tool boxes.
8 DO NOT mount the tool box on a truck bed or any other moving object.
9 Apply brakes on swivel casters when not moving unit.
8 DO NOT pull the tool box when moving, only push to move.
8 DO NOT stand inside the draws.
2. INTRODUCTION
Manufactured from double skin side walls for extra strength and nished in a smooth, hi-gloss triple baked enamel. Resists scratches,
oil, dirt and most solvents. Mid-boxes feature 35mm ball-bearing slides and recessed carry handles. Each drawer face has full length
pulls with chrome style trims. All chests are supplied with tumbler type security locks and two numbered keys.
3. OPERATION
3.1. TOPCHEST
3.1.1. To lock the tool box. Make sure all draws are closed, close lid,
turn key anti-clockwise.
3.1.2. To unlock the tool box. Turn key clockwise and pull open draw.
3.2. MID-BOX / ROLLCAB
3.2.1. To lock the tool box. Make sure all draws are closed, turn key
anti-clockwise.
3.2.2. To unlock the tool box. Turn key clockwise and pull open draw.
8 DO NOT slam the draws shut as damage may occur to the lock
bar tabs or lock pockets.
3.3. TO REMOVE DRAWS
3.3.1. Empty draw and pull out until it stops.
3.3.2. Release the black retaining clips by pushing the righthand side
clip up and the left hand side down simultaneously, and pulling
the draw out g.1.
3.3.3. To re-install draws, place draw onto slides and push in.
3.4. CASTORS AND SIDE HANDLE
3.4.1. Roll cabinet is supplied with heavy duty castors, including two
swivel castors. Fix as shown in g.2.
3.4.2. The side handle must be xed on the same side as the swivel
castors, by inserting handle through slots in side of cabinet and
xing in place with the four set screws provided.
AP223, AP225, AP226, AP223B, AP225B, AP226B Issue 2 16/11/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions
g.1
g.2
Castor
Bottom
4. MAINTENANCE
4.1. Lubricate the top and bottom channels of the drawer slides at least
twice a year.
4.2. If the lock bar tabs or pockets get damaged remove draws and with
pliers or a screwdriver g.3.
g.3
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 24 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
