A feeling of security is one universal human need.
And beyond physical, bodily security, people need
to know that their environment, investments, and
belongings are safe as well. Security systems are
installed in homes and businesses every day to
create that sense of security.
Compared to conventional sensor-based alarm
systems, a surveillance system that utilizes
cameras has several advantages:
• the ability to watch events in real-time,
• obtaining key data around those events,
• and providing solid and accurate evidence for law
enforcement.
Empowered by deep learning algorithms, AcuSense technology
distinguishes people and vehicles from other moving objects.
AcuSense series products are your perfect choices for an
accessible and intelligent security system!
Accurate Alarm for
Human and Vehicle
Search Targets Quickly
by Type
Visual and
Auditory Warning
A surveillance camera
would usually “see”
many events, ranging
from people crossing
a perimeter to animals
that accidentally enter.
Accurate Alarm for
Human and Vehicle
AcuSense
Products
Without the “brain” that Deep Learning provides, any
insignificant movement will trigger an alarm
.
Conventional Surveillance
products
VCAs
As a result, security personnel waste time, energy and
resources responding to them.
AcuSense devices recognize whether the alarm was
triggered by a person, a vehicle, or another object
based on the deep-learning algorithm.*
Alarm Zone
Human
Alarm Triggered
Vehicle
Alarm Triggered
Intrusion Alarm Triggered
Products
How can AcuSense products help
when you want to level up your
protection for your property?
This traditional approach to perimeter
protection only sends alarm signals.
Without a camera for visual reference,
they only create extra effort.
Accuracy of sensors can also be
sensitive to temperature changes (for
example, a PIR sensor) or other sudden
changes in surroundings.
As an result, you’ll get an alarm only
when people or vehicles intrusions are
identified, depending on the event type
you choose to focus on.
Alarm Sensors
Video Content Analyses
There are plenty of clips that are about
irrelevant objects – animals, leaves,
light and shadow, etc.
You’ll still need to browse through all
event files within a period to find the
one that captures your target.
Video clips are already sorted into the
“Human Files” and “Vehicle Files.” Just
simply click one of these categories and
use time or location to quickly locate the
clip that you want.
AcuSense Technology
Human Files Vehicle Files 1 2 n... ...
Laboratory data shows that AcuSense technology can
correctly identify up to 90% of the “ Others” category. This
parameter may vary due to different installation environments.
*
Search Targets Quickly by Type
Visual
Intrusion
Alarm
Categorizes Alarms
as Human, Vehicle,
or Other
Real-Time reaction and
Deterrence
Yes Yes Yes
Conventional
Surveillance Products
Yes Yes No
Maybe;
External siren or light
Alarm Sensors No Yes No
Maybe;
External siren or light
Built-in Visual
and Auditory
Warning
Products
Intrusion Alarm Triggered
For most security events, you will search for video clips that captured human or
vehicle activities. With AcuSense devices, this gets easier.
Explore The Many Application Scenarios
For Burglar Alarm Service
Traditional sensor-based or VCA-based burglar alarm services may be
distracted with alarms triggered by insignificant objects, for example, a cat,
a dog, or a beam of light. With an advanced algorithm, AcuSense devices can
easily distinguish human and vehicle targets among other objects, and sends
an alarm when and only when such intrusion events occur. Other events will
also be stored, but will not be flagged for attention.
For Playback and Video Search
Searching for a specific clip from an ocean of footage is time-consuming.
With AcuSense devices, clips or files that are already classified as people or
vehicles become much easier to locate after an event.
“Being able to focus on human and vehicle-
triggered alarms without the distraction of
animal or rain-triggered ones greatly improves
work eciency.”
Restricted areas or dangerous areas usually have
signage to warn people of danger. People ignore
these signs from time to time, resulting in serious
consequences, trespassing in high-security zones, or
enduring unfortunate incidents.
With an AcuSense camera, you can customize an audio
message to be sent when the camera detects someone
attempting to enter the area.
The human voice is a much more powerful warning
compared to just a written sign. Trespassers are also
more likely to turn back when they see a camera
monitoring the area.
Security monitoring is never an easy task, especially when you’re
responsible for watching over multiple locations at the same time.
Improve Alarm Accuracy and Search Eciency
Alarm Receiving Center / Monitoring Center
Customizable Visual and Auditory Warning
Restricted Areas
"It's great that I can use my security camera to verbally warn
anyone who approaches the area."
Factories and warehouses store high-value raw materials
or commodities. Security here is crucial. However, there is
usually only limited manpower to perform such tasks.
Replace Security Patrols with Camera Monitoring
Using AcuSense products can greatly improve perimeter
monitoring efficiency and ensure that limited human
resources can be deployed only where most needed.
Accurate Trespassing Alarm for Human Targets
Factories and warehouses mostly deal with human
intrusion events, which might turn into burglary or
vandalism.
The security team can set their AcuSense devices to send
alerts only upon the detection of a human intrusion. Wild
animals crossing the line will no longer trigger the alarm.
“I instantly get alerts and can check with my
phone when someone walks into my yard.”
"Now I get notified when people are entering the premises,
not when a cat runs into the area."
Accurate Trespass Alarm, 24 Hours a Day
Factories
Residences
Whether you choose to keep an eye on the house yourself or hire a professional
service provider to look after your home, there’re two functions you will surely
want to have:
Prompt Notification via Smartphone
Whether events will be taken care of by you or someone else, it’s also good to
have the first-hand information. You’ll get a notification on the App or via SMS
when the alarm is triggered. Then check out the live video from your phone.
Light and Sound Intruder Deterrence
Knowing what the suspect looks like is important, especially for providing
evidence to police. However, property losses have already occurred at that time.
It would be even better if there were means that can provide on-site deterrence
and prevent any loss at all. Now you can!
AcuSense Network Camera can be set to react to intrusion events with a flashing
light and customizable siren, alerting any would-be intruder that they are being
monitored and have already been spotted.
Intrusion Detection and Deterrence for Home Security
AcuSense Products
AcuSense Cameras
Appearance
Model DS-2CD2086G2-I(U) DS-2CD2386G2-I(U) DS-2CD2T86G2-2I/4I DS-2CD2686G2-IZS DS-2CD2786G2-IZS DS-2CD2146G1-I(S) DS-2CD2126G1-I(S) DS-2CD2346G1-I
Key
Features
2.8 / 4 / 6 mm fixed lens available 2.8~12 mm motorized VF lens 2.8 / 4 / 6 mm fixed lens available
IP67 (-I models), IP66 (-IU models) IP67 IP66, IK10 IP67, IK10 IP67
4K 4K 4K 4K 4K 4 MP 4 MP2 MP
Appearance
Model DS-2CD2326G1-I DS-2CD2T46G1-2I/4I DS-2CD2T26G1-2I/4I DS-2CD2646G1-IZ(S) DS-2CD2626G1-IZ(S) DS-2CD2746G1-IZ(S) DS-2CD2726G1-IZ(S)
Key
Features
2.8 / 4 / 6 mm fixed lens available 2.8~12 mm motorized VF lens
IP67 IP67, IK10
2 MP 2 MP 2 MP 2 MP4 MP 4 MP 4 MP
* *
*
-U: built-in microphone
Powered by
120
dB
AcuSense NVRs
DS-7732NXI-I4(/16P)/4S
• Up to 8-ch IP cameras for access.
• False alarm reduction for 4-ch behavior (line crossing and intrusion) detection
for 2 MP, 3 MP, 4 MP, and 8 MP network camera
• Support quick target search
• H.265/H.265+/H.264/H.264+/MPEG4 supported decoding formats
• 80 Mbps/256 Mbps for incoming/outgoing bandwidth
• 12-ch 1080p decoding
• HDMI, VGA and CVBS output
• Optional 8 PoE ports, with /8P model
• 1U chassis
• Up to 16-ch IP cameras for access.
• False alarm reduction for 4-ch behavior (line crossing and intrusion) detection
for 2 MP, 3 MP, 4 MP, and 8 MP network camera
• Support quick target search
• H.265/H.265+/H.264/H.264+/MPEG4 supported decoding formats
• 256 Mbps/200 Mbps for incoming/outgoing bandwidth
• 12-ch 1080p decoding
• 2 HDMI, 1 VGA and 1 CVBS output
• eSATA by default
• Optional 16 PoE ports, with /16P model
• 1.5U chassis
• Up to 16-ch IP cameras for access.
• False alarm reduction for 4-ch behavior (line crossing and intrusion) detection for
2 MP, 3 MP, 4 MP, and 8 MP network camera
• Support quick target search
• H.265/H.265+/H.264/H.264+/MPEG4 supported decoding formats
• 160 Mbps/256 Mbps for incoming/outgoing bandwidth
• 12-ch 1080p decoding
• HDMI, VGA and CVBS output
• Optional 16 PoE ports, with /16P model
• 1U chassis
• Up to 32-ch IP cameras for access.
• False alarm reduction for 4-ch behavior (line crossing and intrusion) detection for
2 MP, 3 MP, 4 MP, and 8 MP network camera
• Support quick target search
• H.265/H.265+/H.264/H.264+/MPEG4 supported decoding formats
• 256 Mbps/200 Mbps for incoming/outgoing bandwidth
• 12-ch 1080p decoding
• 2 HDMI, 1 VGA and 1 CVBS output
• Optional 16 PoE ports, with /16P model
• 1.5U chassis
AcuSense Camera with Strobe Light and Audio Alarm
DS-7608NXI-I2(/8P)/4S DS-7616NXI-I2(/16P)/4S
DS-7716NXI-I4(/16P)/4S
Powered by
120
dB
Appearance
Model DS-2CD2346G1-I/SL DS-2CD2326G1-I/SL DS-2CD2T46G1-4I/SL DS-2CD2T26G1-4I/SL
Key Features
2.8 / 4 / 6 mm fixed lens available
/ IP66
4 MP 4 MP2 MP 2 MP
Indoor Model Indoor Model
Continued on Back
Headquarters
No.555 Qianmo Road, Binjiang District,
Hangzhou 310051, China
T +86-571-8807-5998
AcuSense DVRs
• Deep learning-based facial detection or behavior analysis
• 1-ch human face capture or 4-ch false alarm reduction
• 5 MP @ 12 fps (CH1: supports 8 MP @ 8fps)
• Maximum 8 IP Camera Inputs (up to 8 MP)
iDS-7204HUHI-M1(2)/S
4-Channel AcuSense Face Detection DVR
• Deep learning-based facial detection or behavior analysis
• 1-ch human face capture or 2-ch false alarm reduction
• 4 MP Lite @ 15 fps / 1080p @ 15fps
• Maximum 6 IP Camera Inputs (up to 6 MP)
iDS-7204HQHI-M1/S
4-Channel AcuSense Face Detection DVR
• Deep learning-based behavior analysis or face picture comparison
• 1-ch human face capture and facial comparison alarm or 4-ch false alarm reduction
• Face picture library up to 80 MB capacity, up to 16 face picture libraries
• 5 MP @ 12 fps(CH1:supports 8 MP @ 8 fps)
• Maximum 8 IP camera inputs (up to 8 MP)
iDS-7204HUHI-M1(2)/FA
4-Channel AcuSense Facial Recognition DVR
• Deep learning-based facial detection or behavior analysis
• 1-ch human face capture or 4-ch false alarm reduction
• 4 MP Lite @ 15 fps / 1080p @ 15fps
• Maximum 24 IP Camera Inputs (up to 6 MP)
iDS-7216HQHI-M1(2)/S
16-Channel AcuSense Face Detection DVR
• Deep learning-based behavior analysis or face picture comparison
• 1-ch human face capture and facial comparison alarm or 2-ch false alarm reduction
• Face picture library up to 80 MB capacity, up to 16 face picture libraries
• 4 MP Lite @ 15 fps / 1080p @ 15fps
• Maximum 6 IP camera inputs (up to 6 MP)
iDS-7204HQHI-M1/FA
4-Channel AcuSense Facial Recognition DVR
• Deep learning-based behavior analysis or face picture comparison
• 1-ch human face capture and facial comparison alarm or 4-ch false alarm reduction
• Face picture library up to 80 MB capacity, up to 16 face picture libraries
• 4 MP Lite @ 15 fps / 1080p @ 15fps
• Maximum 24 IP camera inputs (up to 6 MP)
iDS-7216HQHI-M1/ FA
16-Channel AcuSense Facial Recognition DVR
• Deep learning-based facial detection or behavior analysis
• 1-ch human face capture or 4-ch false alarm reduction
• 8 MP @ 8fps / 5 MP @ 12 fps
• Maximum 16 IP Camera Inputs (up to 8 MP)
iDS-7208HUHI-M1(2)/S
8-Channel AcuSense Face Detection DVR
• Deep learning-based facial detection or behavior analysis
• 1-ch human face capture or 4-ch false alarm reduction
• 4 MP Lite @ 15 fps / 1080p @ 15fps
• Maximum 12 IP Camera Inputs (up to 6 MP)
iDS-7208HQHI-M1(2)/S
8-Channel AcuSense Face Detection DVR
• Deep learning-based behavior analysis or face picture comparison
• 1-ch human face capture and facial comparison alarm or 4-ch false alarm reduction
• Face picture library up to 80 MB capacity, up to 16 face picture libraries
• 8 MP @ 8 fps / 5 MP @ 12 fps
• Maximum 16 IP camera inputs (up to 8 MP)
iDS-7208HUHI-M1(2)/FA
8-Channel AcuSense Facial Recognition DVR
• Deep learning-based behavior analysis or face picture comparison
• 1-ch human face capture and facial comparison alarm or 4-ch false alarm reduction
• Face picture library up to 80 MB capacity, up to 16 face picture libraries
• 4 MP Lite @ 15 fps / 1080p @ 15fps
• Maximum 12 IP camera inputs (up to 6 MP)
iDS-7208HQHI-M1/ FA
8-Channel AcuSense Facial Recognition DVR
For more information, please
visit our AcuSense page.
HDTVI / AHD / CVI / CVBS / IP Video Inputs
