Rollibot COOL410 ROLLICOOL Alexa-Enabled Portable Air Conditioner

Product's Documents

Below are documents related to this product, you can read online or download:
Main documentSpecificationQuestions and answersRelateds Products
COOL410 photo

User Manual

This is the main product document for model COOL410.

The file format is pdf, 24 pages, you can download this manual here .

background
Portable Air Conditioner
10,000 BTU
COOL 410
COOLING
Advanced Remote Technology-
Turn it on and o from anywhere!
Model No.
Rollibot.com
A
P
P
C
O
N
T
R
O
L
R32
E
F
F
I
C
I
E
N
T
R
E
F
R
I
G
E
R
A
N
T
USER MANUAL
In order to continue serving our customers and providing the best products, our product information including our user
manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials.
background
www.rollibot.com
Customer Service: 1-844-585-6295
background
Dear Rollibot RolliCool Owner,
Welcome to the new age of cool!
The RolliCool 410 is an air conditioner that uses the latest technology to improve your
quality of life. We’ve designed this unit to be fully portable and easy to use in your
home. It features multiple modes to keep you comfortably cool on hot days and dry
during humid nights.
The RolliCool 410 is designed for indoor use and can be used in dierent sized spaces.
Casters make it easy to move the unit from room to room so you can stay comfortable
anywhere.
All of the unit’s features are available through the RolliCool app. After pairing your unit
with your smartphone, you’ll be able to stay comfortable however you like!
Thank you for being a part of the Rollibot family!
— The RolliBot Team
background
4
RolliBot RolliCOOL 410 Portable AC User Manual
Contents
Section 1. Information & Safety Warnings ...................................................................................................... 5
1.1 – Introduction .............................................................................................................................................5
1.2 – Safety Warnings .......................................................................................................................................5
1.3 – FCC Information .......................................................................................................................................6
1.4 – Disposal at End-of-Life...........................................................................................................................6
Section 2. RolliCool Parts ........................................................................................................................................7
2.1 – Box Contents ............................................................................................................................................. 7
2.2 – Components Overview .........................................................................................................................7
2.3 – Control Panel .............................................................................................................................................8
2.4 – Remote Overview ...................................................................................................................................10
2.5 - Tips for Optimal Use ................................................................................................................................11
Section 3. Setting Up the Unit ..............................................................................................................................12
Section 4. Wireless Setup ........................................................................................................................................ 15
4.1 – App Installation ........................................................................................................................................ 15
4.2 – App Installation ........................................................................................................................................ 16
4.3 – Amazon Alexa Setup .............................................................................................................................17
Section 5. How to Use the RolliCool ..................................................................................................................18
5.1 – Timer ...........................................................................................................................................................18
5.2 – Fan Mode ................................................................................................................................................... 18
5.3 – Cool Mode .................................................................................................................................................. 18
5.4 – Dehumidify Mode ...................................................................................................................................19
5.5 – Sleep Mode ............................................................................................................................................... 19
5.6 – Automatic Defrost ................................................................................................................................... 19
5. 7 – Overload Protection ..............................................................................................................................19
Section 6. Maintenance ...........................................................................................................................................20
6.1 – How to Clean the Filters ........................................................................................................................20
6.2 – How to Drain the Unit ............................................................................................................................ 20
Section 7. Storage .....................................................................................................................................................21
Section 8. Troubleshooting .................................................................................................................................... 21
Section 9. Warranty .................................................................................................................................................. 22
9.1 – Violation ...................................................................................................................................................... 22
9.2 – Information ................................................................................................................................................ 23
background
5
RolliBot RolliCOOL 410 Portable AC User Manual
Section 1. Information & Safety Warnings
1.1 – Introduction
This user manual will guide you through the functions and usage of your RolliCool 410 Portable
AC unit. It is important that you follow all instructions and pay attention to all notes that appear
throughout this manual. Consult this manual before you attempt to use your RolliCool. If you
have questions not answered by this manual or are in need of repair or non-routine service,
contact customer service at 1-844-585-6295. Before contacting customer service, please have
your purchase information ready as this may be needed during the call. This information may be
recorded below.
Date of Purchase:
Place of Purchase:
1.2 – Safety Warnings
When reading this manual, note these icons:
• Notes with this icon MUST be read, understood, and obeyed to prevent injury or damage , etc.
• Notes with this icon include relevant information.
Overall Usage
• Do not insert objects into the product.
• The product is not a toy. Do not leave children unsupervised around the product.
• The product is designed for indoor use only.
• Keep the product upright at all times.
• Do not use the product near any of the following places:
• Near anything ammable
• Direct sunlight
• Damp areas
• Dusty areas
• Do not use wax, thinner, or solvents when cleaning the air conditioner.
• Clean your lters once or more every couple of weeks.
• Do not place any obstacles in front of the air inlet or outlet.
• Do not pull on the power cords or cables.
• In the event that the product is malfunctioning, shut the power o immediately.
• Switch o the product before cleaning.
• Only use parts you have received from RolliBot
R
or that have been included in the
original packaging.
• Do not use the product for any purpose other than described in this user manual.
Installation Warnings
• Do not install the product in a sloped setting.
• Do not install the product in direct sunlight.
• Do not install the product in places with open ames or ammable gas.
• Do not use extension cords etc. Only plug the product into a grounded wall outlet.
• Avoid installing the product in damp areas.
• Make sure to drain the product with the included drainage pipe.
background
6
RolliBot RolliCOOL 410 Portable AC User Manual
1.3 – FCC Information
DECLARATION OF CONFORMITY:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC RELATED INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmenttoanoutletonacircuitdierentfromthattowhichthe
receiver is connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modications to this equipment. Such modications could void the user’s authority to operate
the equipment.
1.4 – Disposal at End-of-Life
This product must not be disposed of by incineration, landlling, or mixing it with household
trash. Improper disposal of the battery contained within this product may result in the battery
heating up, rupturing, or igniting which may cause serious injury. The refrigerants contained
inside the RolliCool present chemical risks to the environment. The recommended disposal for
any RolliCool 410 Portable AC unit at its end-of-life is to dispose of the entire unit by contacting
your local recycling company. Local regulations and laws pertaining to the recycling and
disposalofanyRolliCoolunitand/orproductscontainingthemwillvaryaccordingtoyour
country, state, and local governments. You must check laws and regulations corresponding to
where you live in order to dispose of your RolliCool unit properly. It is the user’s responsibility to
dispose of their equipment properly in accordance with local regulations and laws.
For additional information about where you should drop o your RolliCool unit, please contact
your local or regional waste management oce, your household waste disposal service, or your
point-of-sale.
background
7
RolliBot RolliCOOL 410 Portable AC User Manual
Section 2. RolliCool Parts
2.1 – Box Contents
• 1xRolliCool410PortableA/CUnit
• 1x Remote Control
• 1x Drainage Tube
• 1x Window Kits
• 1x Exhaust Hose Outer Connector
• 1x Exhaust Hose Inner Connector
• 1x Exhaust Hose
RolliCool 410 Portable A/C Unit
1
2
4
3
1
Control Panel
Casters
4
3
Front Housing
Open Air Vents (non-oscillating)
5
5
2
Closed Air Vents (non-oscillating)
2.2 – Components Overview
High
Low
Timer Power
Sleep
Fan
Down
Up
Cool
Dry
C/ F
High
Low
Timer Power
Sleep
Fan
Down
Up
Cool
Dry
C/ F
Draining Tube
Exhaust HoseExhaust Hose Inner Connector
Window Kits
A
B
High
Low
Timer Power
Sleep
Fan
Down
Up
Cool
Dry
C/ F
High
Low
Timer Power
Sleep
Fan
Down
Up
Cool
Dry
C/ F
High
Low
Timer Power
Sleep
Fan
Down
Up
Cool
Dry
C/ F
High
Low
Timer Power
Sleep
Fan
Down
Up
Cool
Dry
C/ F
Exhaust Hose Outer Connector
Remote Control
background
8
RolliBot RolliCOOL 410 Portable AC User Manual
2.3 – Control Panel
The 410 features an LED control panel which turns on when the unit turns on and includes on-
screen buttons.
Buttons & Parts (Top View)
LOCK
SLEEP
TIMER
DOWN
SPEED
MODE
POWER
1 32 4 5 6 7 8 9
1
Lock Button: Long press to turn on or o the child lock function.
2
Sleep Button:
Press to turn on or o sleep mode (Sleep mode can only be used in Cool Mode).
3
Timer Button: Press to turn timer mode on or o.
4
Up Button: Press to raise the temperature or adjust timer duration.
5
Display: This section will light up to show temperature and other information.
6
Down Button: Press to lower temperature or adjust timer duration.
7
Speed: Press to cycle through 2 fan speeds (High or Low).
8
Mode Button: Press to cycle between cool, dehumidify, and fan modes.
9
Power Button: Press to turn the unit on or o.
6
7
8
9
11
6
Rear Filter
7
Upper Drainage Opening
8
Lower Drainage Opening
9
Handle
10
Air Vent
11
Power Cord
10
background
9
RolliBot RolliCOOL 410 Portable AC User Manual
Display Icons
Sleep Mode: This icon will light up when sleep mode is open.
Lock Function: This icon will light up when the child lock function is on.
WIFI: This icon will blink during the unit is connecting to the cell phone via wi or
Bluetooth, then it will light up when the unit is connected the cell phone successfully.
High: This icon will light up when the speed is high.
Low: This icon will light up when the speed is low.
Timer Mode: This icon will light up when the timer has been programmed.
Fan Mode: This icon will light up when the unit is in fan mode.
Cool Mode: This icon will light up when the unit is in cool mode.
Dehumidify Mode: This icon will light up when the unit is in dehumidify mode.
• Schedulingcanbedoneand/oradjustedviathecontrolpanelortheapp.SeeSection 4 for information about the app.
• ThecontrolpaneldisplaysFahrenheittemperatureasdefault,anditcanbechangedtodisplayCelsiustemperiatureif
need.
background
10
RolliBot RolliCOOL 410 Portable AC User Manual
2.4 – Remote Overview
1
UP Button: Press to raise temperature or adjust timer
duration.
2
High: Press to switch fan speed to high.
3
Down Button: Press to lower temperature or adjust timer
duration.
4
Low: Press to switch fan speed to low.
5
Sleep Mode: Press to turn on or o sleep mode (Sleep
mode can only be used in Cool Mode).
6
Timer: Press to turn timer mode on or o.
7
Power Button: Press to turn the unit on or o.
8
°C/°F Button: Press to switch between Celsius and
Fahrenheit.
9
Fan Mode: Press to switch to fan mode.
10
Dehumidify Mode: Press to switch to dehumidify mode.
11
Cool Mode: Press to switch to cool mode.
• Avoidpressingtworemotebuttonssimultaneouslyasthismaycausemalfunctions.
• Avoidusingtheremoteinareaswithextremetemperatureuctuations.
• Iftheremotewillnotbeusedforextendedperiodsoftime,removethebattery.
• Theremotecontrol’srangeisapproximately23ft.Useitwithinthisrange.
• UseonlytwoAAAbatterieswiththeincludedremote.Donotmixoldandnewbatteriesorbatteriesfromdierentbrands.
High
Low
Timer Power
Sleep
Fan
Down
Up
Cool
Dry
C/ F
7
8
9
10
11
1
2
3
4
5
6
background
11
RolliBot RolliCOOL 410 Portable AC User Manual
2.5 - Tips for Optimal Use
Follow these recommendations to get the most out of your RolliCool performance:
1. Close windows and doors in the room to be cooled.
Always close the doors and windows while using the AC.
(Close shutters and drapes for better cooling performance.)
2. Closeorpartiallyclosewindowcurtainsand/orblindstopreventdirectsunlightfrom
entering the room.
(Direct sunlight hitting the AC unit may cause the unit’s temperature sensor to misread the
actual temperature in the room. This may cause the unit to keep running, even if the room
has been adequately cooled.)
3. Make sure the AC unit is standing on a at, level surface.
4. DonotcovertheACunitorblocktheairintake/outlets.
DO NOT COVER
Never obstruct the air outlet
or intake grilles.
DO NOT COVER
Never obstruct the
air outlet or intake
grilles.
Upper Drain Opening
For use with continuous
draining in dehumidify
mode and in cool mode in
high-humidity area.
(Drain pan not included.)
5. Do not use in rooms with excessive humidity (e.g., bathrooms, laundries).
6. Regularly inspect air lters and clean when necessary.
7. Remove/minimizesourcesofexcessiveheatfromtheroom.
8. Always connect the upper drainage tube when using cool or dehumidify modes.
9. Always connect the exhaust hose to the window kit for proper ventilation.
10. Keep the exhaust hose as short and free of curves as possible.
11. Do not use outdoors.
background
12
RolliBot RolliCOOL 410 Portable AC User Manual
Section 3. Setting Up the Unit
• Beforeusingtheunit,keepituprightforatleasttwohours.
• Donotuseextensioncordsetc.Onlyplugtheunitintoagroundedwalloutlet.
• Donotusetheunitinbathroomsorotherexcessivelyhumidenvironments.
• Afterinstallation,placetheunitonarm,levelsurfaceinanareawithatleast19.6in.offreespacearoundittoallowfor
proper air circulation.
Installation – Part 1 of 4: Prepare the Unit
Step 1. Keep the unit upright for at least 2 hours.
Step 2. Select the perfect placement for the unit that includes:
• unobstructedaccesstoawindow
• unobstructeddirectaccesstoapoweroutlet
• at,levelsurface
• atleast11.8”fromwallsorotherobstructions
• adequatespaceforwaterrunowhenusingtheupperdrainagehole(requiredfor
cool and dehumidify modes)
Step 3. Test the unit’s placement:
• verifytheACunithasdirect,unobstructedaccesstoagroundedoutlet(donotusean
extension cord)
• carefullyunfurltheexhausthoseandadjustitslengthtoreachthewindow
Keep the exhaust hose as short and free of curves as possible. Make sure the exhaust hose remains unobstructed and free of
sharp bends and bends.
Forbestresults,addweatherstrippingtoyourwindowtoimproveholdonthewindowkitandreducecooledairloss.
Installation – Part 2 of 4: Water Drain
Do not skip this step. To avoid unit failure, you must connect the
upper drain hose when using cool and/or dehumidify mode or
operating in humid environments.
Step 1. Locate the upper drainage hole on the back
of the unit. Set a large container close to the drainage
hole for water runo.
Step 2. Remove the cap from the upper drainage
hole.
Step 3. Place one end of the draining tube in the
container and connect the other end to the unit’s
upper drainage hole.
• Ifthedrainingtubeistoostiand/orcannotbeattached,trysoakingtheendinhotwatertosoftenitrst.
• Foroptimalexperience,usealargecontainerforwaterdrainage.Containershouldnotexceedheightoftheupperdrainage
hole.
background
13
RolliBot RolliCOOL 410 Portable AC User Manual
Installation – Part 3 of 4: Exhaust Hose
Do not skip this step. You must attach the exhaust hose to the window kit for proper ventilation.
Make sure that the unit is placed in a at position and that air vents are not blocked or obstructed.
Step 1. Insert the connectors into both ends of the exhaust hose. Rotate the connectors
clockwise to tighten.
Inner Connector
Outer Connector
B
B
B
A
A
A
C
C
C
B
A
A
C
Step 2. Slide the exhaust hose onto the air vent on the back of the unit. Make sure to use the
inner connector.
Keep the exhaust hose as short and free of curves as possible. Make sure it is free from sharp bends and kinks, as this may
inhibit airow and/or damage the unit.
Installation – Part 4 of 4: Window Kit
Window Kit Parts
Sections
These sections thread into one another and
should be placed within a window gap.
Screw Fastener
These parts are used to secure the sections
together and can be loosened or tightened
when adjusting the sections according to
window height.
Screw Head
Screw Base
Washer
A
A
B
B
background
14
RolliBot RolliCOOL 410 Portable AC User Manual
Installation
Step 1. Separate one screw fastener and thread the screw base into one end of Section B (
1
).
Step 2. Thread Section A onto the end of Section B (
2
), and use the screw head and washer to
secure the sections together (
3
).
Step 3. Install the assembled window kit into the gap between the window and the frame. Close
the window to secure it. It needs to hold the windows kit rmly in place, and secure the window
kit with duct tape if required. It is recommended that the gap between the adapter and the
sides of the window should be sealed o for maximum eciency.
Screw Head
Screw Head
A
B
B
Screw Base
Washer
Sliding Window Hung Window
Window Kit
Slide Window Hung Window
Window Kit
background
15
RolliBot RolliCOOL 410 Portable AC User Manual
Step 4. Carefully unfurl the exhaust hose to reach the window. Ax the outer connector of the
hose to the window kit’s air outlet.
11.8 in.
11.8 in.
• Makesuretheexhausthoseremainsunobstructedandfreefromsharpbendsandkinks,asthismayinhibitairowand/
or damage the unit.
• Forsmallerwindows,thewindowkitcanbecutforabettertusingahacksaworsomeotherlargecuttingtool.Donot
use hand scissors, kitchen knives or other small cutting utensils.
• Makesuretheexhausthoseisnotbentorkinkedasthismayinhibitairowand/ordamagetheunit.
• Makesurethattheunitisplacedinaatpositionandtheairoutletisnotblocked
• Makesuretheunitisplacedatleast11.8in.(30cm)awayfromthewall.
Section 4. Wireless Setup
The RolliCool app can be used to control most features on the AC unit. The app is compatible
with most Android and iOS smartphones. Additionally, the unit can also be paired with Alexa
and other products from the Amazon Echo Family.
You must have the RolliCool app on your smartphone to use Alexa with the RolliCool.
4.1 – App Installation
Step1. UseyoursmartphonetosearchthePlayorAppStoreforthe“RolliCool”application.
Step2. Download and install the app according to your operating system.
background
16
RolliBot RolliCOOL 410 Portable AC User Manual
4.2 – App Installation
When pairing to the app, your mobile device and the AC unit must be on the same Wi-Fi
network.
• Bluetooth®isenabledandwillstayenabledaslongastheRolliCoolisturnedon.
• ForinstructionsonhowtoturnonBluetooth®,consultmaterialsforyoursmartphone.
• AswithmostBluetooth®devices,itisrecommendedtokeeptheconnecteddeviceswithin32ft.fromeachother.The
connection may be terminated or fail to work properly if the connected devices are too far apart.
Step 1. Turn on the AC unit, then turn on your smartphone’s Bluetooth. Open the Rollicool app.
Step 2. Register for an account. Then sign in with your Rollicool account details on the
app (g. 1) to log in. If you already have a Rollibot account, simply log in.
Step 3. Tapthe“AddDevice”
icon at the lower left corner to go next step.
Step 4. Tap the access mode Bluetooth (g.2). Enter access details as needed.
Step 5. Selectanearbydevicetopair.The“WIFI”lightshouldstartblinking;afterwhich,the
app should begin pairing.
Step 6. After connecting successfully, the “WIFI“ light will stay on, and the app can be used to
set cooling schedules, change cooling modes and more (g. 3).
Yourdevicemayhadadierentmodelnamebydefault.Tochangethedevicename,tap“More”intheuppercornerthen
select“Renamedevice”toenteranewnameforyourCOOL410.Do not use “AC”, “A/C”, “A-C”, or similar iterations, as
this will interfere with some Alexa features.
• Afterpowereddownforanextendedtime,theRolliCoolappmaynotautomaticallysyncwithyourRolliCoolonceyouturn
theunitbackon.Waitafewminutes,thenrestarttheACunit.Followthepairingstepstopairyoursmartphonewiththe
unit again.
• Afterpairingsuccessfully,ifyoucan’tcontrolthedeviceimmeduitely,youmayhaveanetworkdelayproblem.Simplywait
a moment and try again to use the app to control the device.
Fig. 1 Fig. 2
Fig. 3
background
17
RolliBot RolliCOOL 410 Portable AC User Manual
4.3 – Amazon Alexa Setup
Step 1. Search “RolliCool“ in the Amazon Alexa app home screen (g. 4).
Step 2. Select the RolliCool app and tap “ENABLE“ (g. 5).
Step 3. LogintoyourRolliCoolaccountandtap”LinkNow”.Followanyadditionalin-app
instructions as needed (g. 6).
Fig. 4
Fig. 5 Fig. 6
Search for RolliCool in the Skill page.
ChangethenameofyourRolliCool410beforepairingwithAlexa;otherwise,Alexawon’tbeabletoidentifythedefaultname
(RolliCool-smart-12517).Do not use “AC”, “A/C”, “A-C”, or similar iterations, as this will interfere with some Alexa
features.Mostfeaturescanbeusedbypressingthebuttonsontheunit’scontrolpanel,throughAlexavoicecommands,or
via the Rollicool app.
List of Alexa Commands:
1.“Turnon<devicename>”:PowersontheRolliCool410.
2.“Turno<devicename>”:PowersotheRolliCool410.
3.“Settemperatureto<degree>”:SetsRolliCooltemperaturetospeciednumber.
•MakesureAmazonAlexaappandRolliCoolareconnectedtothesamewi-;otherwise,Alexamaynotbeabletodiscover
your AC unit.
•Makesureyou’reconnectingtoastablewi-network.Ifyourwi-isunstable,Alexamaydisconnectand/orworkcorrectly
with your RolliCool.
•YoumusthavetheRolliCoolapponyoursmartphonetouseAlexawiththeRolliCool.
background
18
RolliBot RolliCOOL 410 Portable AC User Manual
Section 5. How to Use the RolliCool
The COOL410 features a number of ways to keep comfortable. Most features can be used by
pressing the buttons on the unit’s control panel or via the app.
• Inmostcases,theappcanbeusedasanalternativecontrolmethod.
• Youmustattachthedrainagetubetotheupperdrainingopeningwhenusingcoolordehumidifymodes.SeeSection 3
for more information.
•Youmustconnecttheexhausttubetothewindowforproperventilation.SeeSection 3 for more information.
5.1 – Timer
With this mode, the unit will automatically turn on or o and regulate temperature according to
the selected times.
• TurningonthetimermodewhentheunitisOFFwillsetthenumberofhoursbeforetheunitwillturnon(seebelow).
• TurningonthetimermodewhentheunitisONwillsetthenumberofhourstheunitwillturno(seebelow).
• Aftersettingthetimer,theACunitwillentertimermode.Whileinthismode,theunitwilloperateaccordingtothe
selectedtimerduration.Pressingthetimerbuttonagainwillturntimermodeoandcancelanydurationsetting.
To Set a Turn On Time
1. When the unit is OFF, press the timer button on the control panel or remote.
2. Use the up and down buttons to select the time the AC unit will turn on. For example,
selecting“03”willprompttheunittoturnonin3hours.
3. After the selection is complete, the “03“ number will ash for ~5s and the display’s Timing
light will turn on, indicating the Timer function is set successfully.
When a schedule is active, the unit will not turn on if the chosen temperature is higher than the indoor temperature.
To Set a Shut off Time
1. When the unit is ON, press the timer button on the control panel or remote.
2. Use the up and down buttons to select the time the AC unit will turn o. For example,
selecting“03”willprompttheunittoturnoin3hours.
3. After the selection is complete, the “03“ number will ash for ~5s and the display’s Timing
light will turn on, indicating the Timer function is set successfully.
5.2 – Fan Mode
With this mode, the unit will turn on and begin using the fan to promote air circulation.
1. Press the power button on the control panel or remote.
2. Press the mode button on the control panel or remote until the display’s FAN light turns on.
3. Use the speed button to switch between fan speeds.
5.3 – Cool Mode
With this mode, the unit will turn on and regulate temperature as selected.
1. Press the power button on the control panel or remote.
background
19
RolliBot RolliCOOL 410 Portable AC User Manual
2. Press the mode button on the control panel or remote until the display’s COOL light turns on.
3. Use the up and down buttons to set the desired temperature 62~86°F (16~30°C).
4. Use the speed button to switch between fan speeds.
In cool mode, the unit will not turn on if the chosen temperature is higher than the indoor temperature.
You must attach the drainage tube to the upper draining opening when using cool mode.
5.4 – Dehumidify Mode
With this mode, the unit will turn on and begin removing moisture from the air.
1. Connect the drainage tube to the upper drainage opening. Set a container near the unit to
collect the water (if needed). Then place the other end of the drainage tube in the container.
2. Press the power button on the control panel.
3. Press the mode button on the control panel or remote until the display’s DEHUM light turns
on.
You must attach the drainage tube to the upper draining opening when using dehumidify mode.
In dehumidify mode, the fan speed is automatically set to low and cannot be adjusted.
5.5 – Sleep Mode
When Sleep Mode is activated, the unit will gradually increase the temperature by up to 4˚F
over the rst two hours. Once the initial 2-hour period has elapsed, the temperature will remain
constant until Sleep Mode is turned o or until a maximum of 12 hours has passed.
1. Press the power button on the control panel or remote.
2. Press the sleep button on the remote to turn this mode on.
In sleep mode, the fan speed is automatically set to auto and cannot be adjusted.
5.6 – Automatic Defrost
At low room temperatures, frost may buildup at the evaporator during operation. The unit will
automatically start defrosting and the POWER LED blinking.The defrost control sequence is as
follows:
A. When the unit operates in the cooling operation, drying operation, the ambient temperature
sensor senses the evaporator coil temperature is below 30°F, after the compressor will stop
operating for 10 minutes or the coil temperature up to 44°F, the unit restart to cool operating
mode.
B. When the unit operates in the drying operation, once the coil temperature sensor senses
the temperature of the evaporator is below 104°F and the dierential temperature between
coil temperature and room temperature is below 66°F after the compressor operation for
20minutes, the unit starts defrosting for 5 minutes and the power indicator blinking.
5. 7 – Overload Protection
In the event of a powerloss,to protect the compressor there is a 3-minute delay until the
compressor restarts.
background
20
RolliBot RolliCOOL 410 Portable AC User Manual
Section 6. Maintenance
Proper maintenance will help improve your RolliCool’s
performance. Periodically, the RolliCool will need its lters
cleaned. For optimal performance, the lters should be
cleaned at least twice a month.
• Ifanytypeofnon-routinemaintenanceisneeded,suchasanymaintenance
notdescribedinSection6ofthis manual,please
contactcustomerserviceoracertiedHVACprofessionalastheunitcontainsrefrigerant.
• Wipetheexteriorcleanwithnon-abrasivecloth.Ifneeded,clothcanbedampenedwithwater.
• Donotuseharshchemicalstocleanasthesemaydamagetheunit.
6.1 – How to Clean the Filters
•
PleasemakesureyourACunitiscompletelypoweredobeforeperforminganytypeofmaintenance.
• Donotscrapetheairlter.
• Ahandvacuummaybeusedtocleanthelter.
• Reinstallthelteraftercleaning.DonotusetheRolliCoolwithoutthelter.
• Ifwaterhasbeenusedtocleanthelter,ensureitiscompletelydriedbeforereinstalling.DoNOTdrythelterindirect
sunlightoradryingappliance.Allowtheltertoairdry.
Cleaning the Filters
1. Reach under the notches and remove the two rear lters.
Soak both lters in lukewarm water or use a vacuum to
clean the lters. Mild detergents may be used.
2. After the lters have completely dried, reinstall the two
rear lters.
6.2 – How to Drain the Unit
In most cases, the AC unit will not require draining. In the
event that draining is necessary, the unit will sound an alarm
(~10s Beep sound) and the display’s “FL“ light will turn on to
indicate the water reservoir inside is full.
• PleasemakesureyourACunitiscompletelypoweredobeforeperforminganytypeofmaintenance.
• Ifrelocatingtheunitbeforedraining,moveitcarefullysoasnottospillthewaterinsidethereservoir.
• Makesurethedrainagepipehasadequatespaceunderneathfordraining.Ifusingthelowerdrainageopening,ensure
thereisasuitableareaforwaterruno.Ifusingtheupperdrainageopening,fetchacontainerforwaterrunobefore
connecting the tube.
• Keepthedrainagecoverandthewaterplugonatalltimeswhennotdrainingtheunit.
• Whendrainingtheunit,donotallowthepowercordtocomeincontactwithwater.
• Duringdrainage,theunitmaybetiltedslightbackwardstopromotefasterdrainage.
• Keepinmindtheunitmayholdmorewaterthanexpected.Donotuseasmallcontainertodrain.OrdraintheRolliCool410
outdoors.
background
21
RolliBot RolliCOOL 410 Portable AC User Manual
Using the Lower Drainage Openings
1. Turn o and unplug the unit. If necessary, carefully move it to a suitable location for drainage.
2. Set a container near the unit for water run o, then place the end of the draining tube in the
container.
3. Remove the cap from the lower drainage opening and connect the draining tube to the unit
via the opening.
Ifthedrainingtubeistoostiand/orcannotbeattached,trysoakingtheendinhotwatertosoftenitrst.
4. Allow the water to drain.
Afterdrainingiscomplete,itisrecommendedtoturntheunitonandrunitinFanModeatthelowestspeedforatleasttwo
hours in order to ensure the unit dries inside.
5. Detach the tube and reinstall the cap.
Section 7. Storage
Store your RolliCool 410 in a dry, indoor environment. Properly storing your RolliCool will help
improve performance and battery life expectancy.
Step 1. Turn the AC unit o.
Step 2. Remove the exhaust hose and window kit as needed for storage with the unit.
Step 3. Drain the unit of any water and ensure all parts are completely dry.
Step 4. Turn the unit on and run it in fan mode at the lowest speed for at least two hours in
order to ensure the inner reservoir is dried inside.
Step 5. Turn o the unit and install the power cord’s plug into its xture on the back of the unit.
Step 6. Remove the remote batteries and store them separately.
• Alwaysturntheunitobeforetransportingorstoring.
• Covertheunittoprotectitfromdust.Donotstoreinadustyenvironment.Aswithallelectronicdevices,dustmaycause
damage over time.
• Storetheunitindoorsatadryandstabletemperature.Donotstoreinanunheatedgarage,shed,orotherlocationswith
extreme temperature uctuations.
Section 8. Troubleshooting
Problem Possible Cause(s) Solution(s)
The unit does
not power on.
There is no electricity.
Turn it on after connecting it to a socket
with electricity.
The overow indicator is on. Drain the water inside.
The system is protected
Wait 3 minutes until the temperature is
lowered then restart the unit.
The cooling
eect is weak.
There is direct sunlight.
Cover any direct sunlight coming
through the windows.
Doorsorwindowsareopen;there
arealotofpeople;orthereare
other sources of heat nearby.
Close doors and windows.
The lter is dirty. Clean or replace the lter.
The air inlet or outlet is blocked. Clear obstructions.
background
22
RolliBot RolliCOOL 410 Portable AC User Manual
Problem Possible Cause(s) Solution(s)
Excessive noise
The unit is not placed on a at
surface.
Place the unit on a at and stable surface.
Leaking while
moving
Water reservoir is full.
Drain the water reservoir before moving
(see Section 6.2 How to Drain the Unit).
The drainage plug may be cracked. Check the drain stop plug for cracks
Display not on
Power plug and socket contact
bad or power cord disconnect, no
power.
Check the power plug, power cord or
socket and connect it again.
There is unusual
sound
It is normal to have a slightly
stronger vibration sound in the rst
few minutes after power-up.
Will disappear after few minutes.
Water beads on
the surface
In areas of relatively high humidity,
air outlet, control panel, and other
parts may produce condensation.
It is a normal phenomenon.
Long-term cooling operation in
open spaces with windows open.
Closing windows, doors, etc. may resolve
excessive condensation.
Low fan speed may also lead to
increased condensation.
Increase the fan speed.
The opening angle of the louvers
(adjustable vents) is too small.
Increase the angle of the louvers
(adjustable vents) or set it to Oscillate
mode.
When the RolliCool encounters errors, the display may show certain error codes. Refer to the
table below.
Code Possible Cause Solution(s)
E0
Communication faults between
main PCB and display PCB.
Check the wire harness of the display PCB for
damage.
E1
Ambient temperature sensor
failure.
Check connection or replace it. To clean or replace
the temperature sensor.
E2 Coil temperature sensor failures.
Check connection or replace it. To clean or replace
the temperature sensor
Ft Condensate water high level alarm. Empty the drain pan by removal the rubber plug.
If none of the above information resolves your issue, please visit our website at www.rollibot.
com or contact customer service at 1-844-585-6295.
Section 9. Warranty
9.1 – Violation
The RolliCool 410 Portable AC Unit cannot be repaired or serviced within its warranty period if
any of the following has occurred:
The warranty has expired
Damageoccurredduringorinrelationtonon-routineand/orunauthorizeddisassembly
Failuretoprovideavalidproofofpurchasewhenrequestingserviceorrepair
Damage occurred as a result of natural disaster etc.
background
23
RolliBot RolliCOOL 410 Portable AC User Manual
Damageoccurredduetounexpectedfactorsorman-madereasons(includingmis-operation,uidfoundinanyopenings,
improperinsertionorpulling,hauling,bumping,impropervoltageinputandothers).
9.2 – Information
One-Year Limited Hardware Warranty
YourRolliCool410PortableACUnit(“Product”)includesaOne-YearLimitedHardwareWarranty
(“Warranty”).TheWarrantycoversproductdefectsinmaterialsandworkmanshipundernormal
use. This Warranty is limited to residents of the United States and Canada only and is available
only to original purchasers. This Warranty gives you specic legal rights, and you may also have
other rights which vary from state to state.
ThisWarrantystartsonthedateofyourpurchaseandlastsforoneyear(the“WarrantyPeriod”).
The Warranty Period is not extended if the Product is repaired or replaced. We may change the
availability of this limited warranty at our discretion, but any changes will not be retroactive.
WarrantyservicesareprovidedbyRollibotWarrantyPro(“WP”).Ifahardwaredefectarisesand
a valid claim is received within the Warranty Period, at its option and to the extent permitted by
law, WP will: (1) repair the hardware defect by using new or refurbished parts that are equivalent
to new in performance and reliability, or (2) exchange the Product with a product that is new
or refurbished which is substantially equivalent to the original product. This Warranty is for one
replacement only of like-items and does not cover items out of production if the product is no
longer made or stocked. This Warranty is not assignable or transferable. The original purchaser
may call WP’s toll-free number at 1-844-585-6295 for a service request.
When a product or part is exchanged, any replacement item becomes your property, and
the replaced item becomes WP’s property. This warranty only covers technical hardware
defectiveness during the warranty period and under normal use conditions. WP does not
warrant the uninterrupted or error-free operation of this Product.
ThisWarrantydoesnotcoveranydamagedueto:(a)transportation;(b)storage;(c)improper
use;(d)failuretofollowtheproductinstructionsortoperformanypreventivemaintenance;(e)
modications;(f)unauthorizedrepair;(g)normalwearandtear;or(h)externalcausessuchas
accidents, abuse, or other actions or events beyond our reasonable control.
Important: Do not disassemble the Product. Disassembling the Product will void this Warranty.
Only WP or a party expressly authorized by WP should perform service on this Product.
DISCLAIMER OF WARRANTY: THE REMEDIES DESCRIBED ABOVE ARE YOUR SOLE AND EXCLUSIVE
REMEDIES AND OUR ENTIRE LIABILITY FOR ANY BREACH OF THIS LIMITED WARRANTY. OUR
LIABILITY SHALL UNDER NO CIRCUMSTANCES EXCEED THE ACTUAL AMOUNT PAID BY YOU FOR
THE DEFECTIVE PRODUCT, NOR SHALL WE UNDER ANY CIRCUMSTANCES BE LIABLE FOR ANY
CONSEQUENTIAL, INCIDENTAL, SPECIAL, OR PUNITIVE DAMAGES OR LOSSES, WHETHER DIRECT
OR INDIRECT.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO
YOU.
THE DURATION AND REMEDIES OF ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION
THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
LIMITED TO THE DURATION OF THIS EXPRESS LIMITED WARRANT
background
Copyright © 2023. Rollibot, LLC. All Rights Reserved

Specifications

Indexed Terms: Portable Air Conditioner

Rollibot COOL410 Questions and Answers

Find answers or ask new question.
See other models: BL800 BL618 BL100
Questions and Answers
