USER’S GUIDE
Version: FM12-202009RM
AIR CURTAINS
Slimline Models: FM-1209T, FM-1210T, FM-1212T
STOP and Read! Test before installing
1. Do NOT plug in power cord to power source, use a screw driver to rotate
the fan wheels.
2. If the fan doesn’t rotate smoothly, pull the side cover off, and pull the
front bars. Remove the side panel screws and the motor’s shaft screw to
remove the fan wheel.
3. Reseat the fan wheel bearings and align the motor to fix the issues.
4. Plug in 120V power source (some old air curtains might use 240V, verify
the power voltage if not sure); press the switch to H or L to test it. If the
air curtain works normally, refer to section 3 through 7 to install the air
curtain. Refer to section 10 for technical support.
5. If the fan wheel is broken, contact Awoco (refer to section 10) to get the
fan wheel replacement.
6. After installation, if the air curtain doesn’t run, first step is to check the
magnetic switch. Refer to section 7 for troubleshooting.
PLEASE READ AND SAVE THESE INSTRUCTIONS.
Strongly recommend to test the unit before installation for any
defective or damage during shipment.
