X +
0 +
Y
2
0
M
HZ
X + 0 + Y
2
0M
HZ
”
X + 0 + Y
2
TWEETER TYPE: Pure-titanium dome with EOS™ waveguide
DESIGN GOAL: Bring the thrill of live performance and movie sound to
the homeenvironment by calling on JBL’s professional engineering leadership.
CROSSOVER NETWORK: Straight-Line Signal Path™ (SSP)
ENCLOSURE DESIGN: Sealed
PROFESSIONAL REFERENCE: Studio Monitor
OWNER’S GUIDE
WOOFER TYPE:
Cast-aluminum basket with HeatScape™ motor structure
PRODUCT LINE:
STUDIO SERIES
JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
©2000 JBL, Incorporated. JBL is a registered trademark
of JBL, Incorporated.
Part No.
qi0424
TWEETER TYPE: Pure-titanium dome with EOS™ waveguide
DESIGN GOAL: Bring the thrill of live performance and movie sound to
the home environment bycalling on JBL’s professional engineering leadership.
CROSSOVER NETWORK: Straight-Line Signal Path™ (SSP)
WOOFER TYPE:
Cast-aluminum basket with HeatScape™ motor structure
ENCLOSURE DESIGN: Sealed
PROFESSIONAL REFERENCE: Studio Monitor
OWNER’S GUIDE
PRO SOUND
COMES HOME
™
PRODUCT LINE:
STUDIO SERIES
MODEL
S36
NUMBER:
MODEL
S36
NUMBER:
THANK YOU FOR CHOOSING JBL
For more than 50 years, JBL
has been involved in every
aspect of music and film
recording and reproduction,
from live performances to the
recordings you play in your
home, car or office.
We’re confident that the JBL
loudspeakers you have
chosen will provide every
note of enjoyment that you
expected – and that when you
think about purchasing
additional audio equipment
for your home, car or
office, you will once again
choose JBL.
Please take a moment to
complete the enclosed
profile card. It enables us
to keep you posted on our
latest advancements, and
helps us to better understand
our customers and build
products that meet their
needs and expectations.
JBL Consumer Products
SPECIFICATIONS
S36
Description: 3-Way 6" horizontal/vertical mirror-image
wall-mount/bookshelf loudspeakers
Maximum Recommended
Amplifier Power*: 150W
Nominal Impedance: 8 Ohms
Sensitivity (2.83V/1m):
90dB
Frequency Response (–3dB):
60Hz – 20kHz
Crossover Frequencies: 650Hz, 3000Hz
High-Frequency Transducer: 1" Pure-titanium dome, with rubber surround,
shielded; Elliptical Oblate Spheroidal™ (EOS)
waveguide
Midrange Transducer: 4" PolyPlas™ (polymer-coated cellulose fiber)
cone, rubber surround, shielded; Linear Field
Proximity™ (LFP) bezel
Low-Frequency Transducer
: 6" PolyPlas™ (polymer-coated cellulose fiber)
cone, rubber surround, SFG™, magnetic shorting
rings, high-temp oversized Kapton
®
voice coil,
HeatScape™ motor structure, cast-aluminum
baskets, shielded
Baffles: Low diffraction, IsoPower™
Enclosure: Sealed
Network: Straight-Line Signal Path™ (SSP)
Terminals: All-metal, gold-plated 5-way binding posts
Dimensions (H x W x D): 10-1/4" x 14-5/8" x 5"
260mm x 371mm x 127mm
Weight: 11 lb/5kg
*The maximum recommended amplifier power rating will ensure proper system headroom to allow
for occasional peaks. We do not recommend sustained operation at these maximum power levels.
Occasional refinements may be made to existing products without notice but will always meet or
exceed original specifications unless otherwise stated.
