User Guide
LIMITED WARRANTY STATEMENT
1. WHAT THIS WARRANTY COVERS:
LG offers you a limited warranty that the enclosed subscriber unit and
its enclosed accessories will be free from defects in material and
workmanship, according to the following terms and conditions:
(1) The limited warranty for the product extends for ONE (1) year
beginning on the date of purchase of the product.
(2) The limited warranty extends only to the original purchaser of the
product and is not assignable or transferable to any subsequent
purchaser/end user.
(3) This limited warranty is good only to the original purchaser of
the product during the warranty period as long as it is in the U.S.,
including Alaska, Hawaii, U.S. Territories, and all Canadian
Provinces.
(4) The external housing and cosmetic parts shall be free of defects
at the time of shipment and, therefore, shall not be covered under
these limited warranty terms.
(5) Upon request from LG, the consumer must provide information
to prove the date of purchase.
(6) The customer shall bear the cost of shipping the product to the
Customer Service Department of LG. LG shall bear the cost of
shipping the product back to the consumer after the completion
of service under this limited warranty.
2. WHAT THIS WARRANTY DOES NOT COVER:
(1) Defects or damage resulting from use of the product in other than
its normal and customary manner.
(2) Defects or damage from abnormal use, abnormal conditions,
improper storage, exposure to moisture or dampness,
unauthorized modifications, unauthorized connections,
unauthorized repair, misuse, neglect, abuse, accident, alteration,
improper installation, or other acts which are not the fault of LG,
including damage caused by shipping, blown fuses, or spills of
food or liquid.
(3) Breakage or damage to antennas unless caused directly by defects
in material or workmanship.
(4) Alleged defects or malfunctions of the product if the Customer
Service Department at LG was not notified by the consumer
during the applicable limited warranty period.
(5) Products which have had the serial number removed or made
illegible.
(6) This limited warranty is in lieu of all other warranties, express or
implied either in fact or by operations of law, statutory or
otherwise, including, but not limited to any implied warranty of
marketability or fitness for a particular use.
(7) Damage resulting from use of non-LG approved accessories.
(8) All plastic surfaces and all other externally exposed parts that are
scratched or damaged due to normal customer use.
(9) Products operated outside published maximum ratings.
(10) Products used or obtained in a rental program.
(11) Consumables (such as fuses).
3. STATE LAW RIGHTS:
No other express warranty is applicable to this product. THE
DURATION OF ANY IMPLIED WARRANTIES, INCLUDING
THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED
TO THE DURATION OF THE EXPRESS WARRANTY HEREIN.
LG INFOCOMM INC. SHALL NOT BE LIABLE FOR THE LOSS
OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS OR
ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL,
ARISING OUT OF THE USE OF, OR INABILITY TO USE, THIS
PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY, INCLUDING THE IMPLIED
WARRANTY OF MARKETABILITY APPLICABLE TO THIS
PRODUCT.
Some states do not allow the exclusive of limitation of incidental or
consequential damages or limitations on how long an implied
warranty lasts; so these limitations or exclusions may not apply to
you. This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
4. HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please call the following telephone
number from anywhere in the continental United States:
Tel. 1-800-793-8896
www.lgeservice.com
Please call or write for the location of the LGE authorized service
center nearest you and for the procedures for obtaining warranty claims.
Electronics Service
201 JAMES RECORD ROAD, HUNTSVILLE, AL 35824
10 Driver Safety Tips
Your wireless phone gives you the powerful ability to
communicate by voice almost anywhere, anytime. An
important responsibility accompanies the benefits of wireless
phones, one that every user must uphold.
When operating a car, driving is your first responsibility. When
using your wireless phone behind the wheel of a car, practice
good common sense and remember the following tips:
1. Get to know your wireless phone and its features such as
speed dial and redial. Carefully read your instruction manual
and learn to take advantage of valuable features most phones
offer, including automatic redial and memory. Also, work to
memorize the phone keypad so you can use the speed dial
function without taking your attention off the road.
2. When available, use a hands-free device. A number of
hands-free wireless phone accessories are readily available
today. Whether you choose an installed mounted device for
your wireless phone or a speaker phone accessory, take
advantage of these devices if available to you.
3. Position your wireless phone within easy reach. Make sure
you place your wireless phone within easy reach and where
you can reach it without removing your eyes from the road.
If you get an incoming call at an inconvenient time, if
possible, let your voice mail answer it for you.
4. Suspend conversations during hazardous driving conditions
or situations. Let the person you are speaking with know you
are driving; if necessary, suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet, snow and ice can
be hazardous, but so is heavy traffic. As a driver, your first
responsibility is to pay attention to the road.
5. Do not take notes or look up phone numbers while driving.
If you are reading an address book or business card, or
writing a to do list while driving a car, you are not watching
where you are going. It’s common sense. Don’t get caught in
a dangerous situation because you are reading or writing and
not paying attention to the road or nearby vehicles.
6. Dial sensibly and assess the traffic; if possible, place calls
when you are not moving or before pulling into traffic. Try
to plan your calls before you begin your trip or attempt to
coincide your calls with times you may be stopped at a stop
sign, red light or otherwise stationary. But if you need to dial
while driving, follow this simple tip--dial only a few
numbers, check the road and your mirrors, then continue.
7. Do not engage in stressful or emotional conversations that
may be distracting. Stressful or emotional conversations and
driving do not mix--they are distracting and even dangerous
when you are behind the wheel of a car. Make people you
are talking with aware you are driving and if necessary,
suspend conversations which have the potential to divert
your attention from the road.
8. Use your wireless phone to call for help. Your wireless
phone is one of the greatest tools you can own to protect
yourself and your family in dangerous situations--with your
phone at your side, help is only three numbers away. Dial
911 or other local emergency number in the case of fire,
traffic accident, road hazard or medical emergency.
Remember, it is a free call on your wireless phone!
9. Use your wireless phone to help others in emergencies. Your
wireless phone provides you a perfect opportunity to be a
“Good Samaritan” in your community. If you see an auto
accident, crime in progress or other serious emergency where
lives are in danger, call 911 or other local emergency
number, as you would want others to do for you.
10. Call roadside assistance or a special wireless non-
emergency assistance number when necessary. Certain
situations you encounter while driving may require attention,
but are not urgent enough to merit a call for emergency
services. But you still can use your wireless phone to lend a
hand. If you see a broken-down vehicle posing no serious
hazard, a broken traffic signal, a minor traffic accident where
no one appears injured or a vehicle you know to be stolen,
call roadside assistance or other special non-emergency
wireless numbers.
The wireless industry reminds you to use your phone safely
when driving.
For more information, please call to 888-901-SAFE, or visit our
website www.wow-com.com
Provided by the Cellular Telecommunications Industry
Association
1
THIS MODEL PHONE MEETS THE
GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population.
The guidelines are based on
standards that were developed by independent
scientific organizations through periodic and thorough
evaluation of scientific studies. The standards include a
substantial safety margin designed to assure the safety
of all persons, regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by the FCC is
1.6W/kg. * Tests for SAR are conducted using standard
operating positions specified by the FCC with the phone
transmitting at its highest certified power level in all tested
frequency bands. Although SAR is determined at the
highest certified power level, the actual SAR level of the
phone while operating can be well below the maximum
value.
Because the phone is designed to operate at
multiple power levels to use only the power required to
reach the network, in general, the closer you are to a
wireless base station antenna, the lower the power
output
.
2
Before a phone model is available for sale to the public, it
must be tested and certified to the FCC that it does not
exceed the limit established by the government-adopted
requirement for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the
body) as required by the FCC for each model. The highest
SAR value for this model phone when tested for use at the
ear is 1.28 mW/g and when worn on the body, as
described in this user guide, is 0.83 mW/g. (Body-worn
measurements differ among phone models, depending
upon available accessories and FCC requirements). While
there may be differences between SAR levels of various
phones and at various positions, they all meet the
government requirement for safe exposure.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF emission guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID
BEJTM520.
Additional information on Specific Absorption Rates (SAR)
can be found on the Cellular Telecommunications Industry
Association (CTIA) website at http://www.wow-com.com.
3
* In the United States and Canada, the SAR limit for
mobile phones used by the public is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give
additional protection for the public and to account for any
variations in measurements.
4
SUBJECT
The VX1 phone has been designed to operate on the
latest digital mobile communication technology, Code
Division Multiple Access (CDMA). This CDMA digital
technology has greatly enhanced voice clarity and can
provide a variety of advanced features. Currently,
CDMA mobile communication technology has been
commercially used in Cellular and Personal
Communication Service (PCS).
The difference between them is operating frequency
spectrum. Cellular uses 800Mhz and PCS
uses
1.9Ghz. The VX1 operates on both frequencies, this is
called a dual-mode phone. Also, the VX1 works on
Advanced Mobile Phone Service (AMPS). We call it a tri-
mode phone. If one of the Cellular, PCS or AMPS base
stations is located nearby,
call fail rate of a tri-mode
phone is less than a dual-mode phone or a single-mode
phone.
CDMA technology adopts DSSS (Direct Sequence
Spread Spectrum). DSSS enables the phone to keep
communication from being crossed and to use one
frequency channel by multiple users in the same
specific area, resulting in a 10 fold increase in capacity
when compared with the analog mode currently used.
Soft/Softer Handoff, Hard Handoff, and Dynamic RF
power Control technologies are combined into this
phone to reduce call interruptions.
5
The Cellular and PCS CDMA networks consist of
MSO (Mobile Switching Office), BSC (Base Station
Controller), BTS (Base station Transmission System),
and MS (Mobile Station). The following table lists
some major CDMA Standards.
TSB -74: Protocol between an IS-95A system and
ANSI J-STD-008
1xRTT system receives subscribers in wireless
section twice as much as IS-95. Its battery life is twice
as long as IS-95. High-speed data transmission is
also possible.
CDMA Standard
Basic air interface
Network
Service
Performance
Designator
TIA/EIA/IS-95-A
ANSI J-STD-008
TIA/EIA/IS-634
TIA/EIA/IS/651
TIA/EIA/IS-41-C
TIA/EIA/IS-124
TIA/EIA/IS-96-B
TIA/EIA/IS-99
TIA/EIA/IS-637
TIA/EIA/IS-657
TIA/EIA/IS-97
TIA/EIA/IS-98
ANSI J-STD-018
ANSI J-STD-019
TIA/EIA/IS-125
Description
Protocol between MS and BTS for Cellular & AMPS
Protocol between MS and BTS for PCS
MAS-BS
PCSC-RS
Intersystem operations
Nom-signaling data comm.
Speech CODEC
Assign data and fax
Short message service
Packet data
Cellular base station
Cellular mobile station
PCS personal station
PCS base station
Speech CODEC
6
Introduction
Highlights
Congratulations! Your new mobile phone will change
the way you communicate and is a compact, lightweight
personal communication system with added features
for the person on the go. Our advanced digital mobile
communication technology features the following:
Large, easy-to-read, 8-line, backlight LCD with
status icons.
Paging, messaging, voice mail, and caller ID.
18-key keypad.
Long battery standby and talk time.
Menu-driven interface with prompt for easy
operation and configuration.
Any key answer, auto answer, auto retry, and one
touch dialing and speed dialing with 199 memory
locations.
Bilingual (English and Spanish menu languages
are available).
Optional accessories. (see pages 119~121)
Important Information
This user guide provides important information on the
use and operation of your VX1 phone. Please read all
the information carefully prior to using the phone for best
performance and to prevent any damage to or misuse of
the phone. Any unapproved change or modification will
void your warranty.
Check Accessories
Your mobile phone comes with the following accessories,
a one-slot desktop charger and a rechargeable battery.
Please verify your accessories are included.
7
Before You Start
Safety Instructions
WARNING! To reduce the possibility of electric shock, do not
expose your phone to high humidity areas, such as the
bathroom, swimming pool, etc.
IMPORTANT! Please read the SAFETY AND GENERAL
INFORMATION on page 123 before using your phone.
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of the
United States, with its action in Report and Order FCC 96-
326, adopted an updated safety standard for human
exposure to radio frequency (RF) electromagnetic energy
emitted by FCC regulated transmitters. Those guidelines are
consistent with the safety standard previously set by both U.S.
and international standards bodies.
The design of this phone complies with the FCC guidelines
and these international standards.
CAUTION
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or result in
violation of FCC regulations.
Do not use the phone with a damaged antenna. If the
damaged antenna comes into contact with the skin, a minor
burn may result. Contact your local dealer for a replacement
antenna.
8
9
Body-worn Operation
This device was tested for typical body-worn operations with
the back of the phone kept inch (2 ) from the body. To
comply with FCC RF exposure requirements, a minimum
separation distance of inches (2 ) must be maintained
between the user’s body and the back of the phone, including
the antenna, whether extended or retracted. Third-party belt-
clips, holsters, and similar accessories containing metallic
components should not be used. Body-worn accessories that
cannot maintain inch (2 ) separation distance between the
user’s body and the back of the phone, and have not been
tested for typical body-worn operations may not comply with
FCC RF exposure limits and should be avoided.
Vehicle Mounted External Antenna
(optional, if available)
A minimum separation distance of 8 inches (20 ) must be
maintained between the user/bystander and the vehicle
mounted external antenna to satisfy FCC RF exposure
requirements.
For more information about RF exposure, visit the FCC
website at www.fcc.gov
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of
FCC rules. Operation is subject to the following two
conditions: (1) This device and its accessories may not
cause harmful interference, and (2) this device and its
accessories must accept any interference received,
including interference that cause undesired operation.
Cautions for Battery
Do not disassemble.
Do not short-circuit.
Do not expose to high temperature : 60 C (140 F)
Do not incinerate.
Battery Disposal
Please dispose of your battery properly or bring to
your local wireless carrier for recycling.
Do not dispose in fire or with hazardous or flammable
materials.
Adapter (CHARGER) Cautions
Using the wrong battery charger could damage your
phone and void your warranty.
The charger or adapter is intended for indoor use
only.
Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as the
bathroom.
10
Contents
Introduction 6
Highlights 6
Important Information 7
Check Accessories 7
Before You Start 8
FCC RF Exposure Information 8
Chapter 1. Getting Started 14
Cautions 14
Using the Battery Pack 15
Phone Components 19
Phone Overview 20
Onscreen Icons 22
Entering Information Using T9 Text Input 23
Chapter 2. Basic Functions 28
Turning the Phone On and Off 28
Making a Call 29
Correcting Dialing Mistakes 30
Receiving Calls 30
Using Manner & Lock Mode 31
Call Waiting 32
Mute 32
Redialing Calls 33
Adjusting the Volume 33
Power Save Mode 34
11
12
Signal Strength 34
Caller ID Display 35
Speed Dialing 36
Caller ID 36
Phone Book Features 37
Chapter 3. Menu Features 46
General Guidelines to MENU Access and
Settings 46
Sound 47
Display 53
Features 57
System 62
Security 65
Chapter 4. PIM Features 69
Phone Book 69
Call History 73
Scheduler 76
Wake Up 82
Game 83
Calculator 91
Chapter 5. Message Features 92
SMS 94
Voice 94
Send Message 95
13
Inbox 100
Outbox 103
Erase Msgs 105
Setting 106
Chapter 6. Functions Used During a Call 108
Mute 108
Memo 108
Key Tone 108
Voice Privacy 109
Chapter 7. MiniBrowser 110
Overview 112
Accessing the MiniBrowser 113
Chapter 8. Accessories 119
Chapter 9. Appendix 122
Chapter 10. Safety Guidelines 123
Safety Information 123
FDA Consumer Update 127
14
Chapter 1. Getting Started
Cautions
Using the
phone near receiving
equipment (i.e., TV
or radio) may cause interference.
Keep your phone in a safe place when not in use.
Only use the batteries, antennas and chargers
provided by LG. Using unauthorized accessories
could void your warranty.
Only authorized personnel should service the phone
and its accessories. Faulty installation or service
may result in accidents and consequently void the
warranty.
Do not hold the antenna while the phone is in use.
Do not use the phone in designated no cellular phone
use areas.
Do not expose the phone to high temperature or
humidity.
Avoid getting your phone wet. If the phone gets wet,
turn the power off immediately and remove the
battery. If the phone is non-functional, return it to
the dealer for service.
Avoid shock or impact on the phone.
15
Get t ing St art ed
Using the Battery Pack
Charge the battery fully before the initial use of
the phone.
The phone comes with a rechargeable battery. Keep
the battery charged while not in use in order to
maximize talk and standby time when using the phone.
Installing the Battery
To install the battery, insert the bottom of the battery
into the opening on the back of the phone. Then, push
the battery down until the latch clicks.
Removing the Battery
Turn the power off. (If power is on, a loss of stored numbers
and messages may occur.)
By lifting removal button the battery will become detached.
16
Battery Charge Level
The battery charge level is shown at the top right of the
LCD screen.
When the battery charge level becomes low, the low
battery sensor will alert you in three ways: sounding
an audible tone, blinking the battery icon outline,
and displaying
LOW BATTERY WARNING!
If the
battery charge level becomes exceedingly low, the
phone will automatically switch off and any function
in progress will not be saved.
17
Get t ing St art ed
Using the Desktop Charger
The Desktop charger has a slot for recharging batteries.
The slot accommodates phone and battery for charging.
Warning! Use only the Desktop charger provided with
the phone. Using an unauthorized charger may cause
damage to your phone or battery.
1. Plug the charger into a wall outlet.
The phone must be charged from a 110 V power
source only.
2. Insert the phone with an installed battery or a
battery into the slot of the charger.
Red light indicates the battery is being charged.
Green light indicates the battery is fully charged.
Charge time will vary depending upon battery level.
Maximum charge time for a fully discharged battery
will not exceed 3 hours.
18
Caring for the Battery
1. To recharge the battery, you do not need to wait
until the
battery is completely
discharged.
2. U
se only LG batteries and chargers specific to
your model of phone.
LG’s chargers are designed
to maximize the battery life.
3. Do not disassemble or short-circuit the battery.
4. Keep the metal contacts of the battery clean.
5. Replace the battery when it no longer provides
acceptable performance. The battery may be recharged
several hundred times before it needs replacing.
6. Recharge the battery if it has not been used for a long
time to maximize battery life.
7. Do not expose the battery charger to direct sunlight or
use it in areas of high humidity, such as the bathroom.
8. Do not leave the battery in hot or cold places, this may
deteriorate battery performance.
9. Your battery life may vary by location, use patterns,
etc.
10. Long backlight settings, searching for service,
MiniBrowser, data connectivity and synchronization
all may affect battery life, talk and standby time.
19
Get t ing St art ed
Phone components
The following shows key components of your mobile
phone.
15. Antenna
16. Earpiece
2. LCD Screen
7. Soft Key 2
5. Navigation Key
17. Microphone
8. Side Keys
14. Headset Jack
6. Cellcase
13. Message Key
9. Alphanumeric
Keypad
11. Manner
mode Key
1. Lamp
7. Soft Key 1
4. END/PWR
3. SEND
10. CLR
11. Manner
mode Key
12. Lock mode Key
Caller LCD
20
Phone Overview
1.
Lamp The red light shows when you turn the power
on and when you have incoming calls and messages.
2. LCD screen Displays messages and indicator icons.
3. SEND Allows a user to place or answer calls.
4. END/PWR Used to turn power on/off and to end a
call. Using this key, you can return to the main menu
display screen.
5. Navigation Key This Navigation key allows quick
access to text and voice mail notification
messages. Calendar, Outgoing Call list,
Name search.
6. Cellcase Open the cellcase to answer an incoming
call and close to end the call.
7. Soft Keys
- Soft Key 1
Used to display the function setting menu.
- Soft Key 2
Press this key once in a menu, to go back one level.
8. Side Keys Enables you to adjust key beep volume
(in standby mode) and earpiece volume (during a
call).
When your phone rings press either side key to
mute the ringer or vibration for that call only.
21
Get t ing St art ed
9. Alphanumeric keypad Enables you to enter
numbers and characters and to choose menu items.
10.
Clear Key Press to delete a single space or character.
Press and hold to delete entire words.
11. Manner Mode Key
- In standby mode, set the manner mode by pressing
and holding the key about 3 seconds.
12. Lock Mode Key
- In standby mode, set the lock function by pressing
and holding the key about 3 seconds.
13. Message Key
14. Headset Jack
15. Antenna
16. Earpiece
17. Microphone
22
Onscreen Icons
The phone screen displays several onscreen icons
which appear when the phone is powered on.
Displays the strength of the signal received
by the phone and current signal strength is
indicated by the number of bars displayed on
the screen.
No service
The phone is not receiving a system signal.
In use
A call is in progress.
No icon indicates the phone is in standby mode
.
Digital indicator
Digital service is available.
Analog indicator
Analog service is available.
Indicates that a text message or voice mail
has been received.
Roaming
The phone is outside of its home service area.
In Vibration mode
In Alarm mode
Charge level
Indicates battery charge level.
D
23
Get t ing St art ed
Entering Information Using T9 Text
Input
You can edit the Banner, Scheduler, Short Message and
Phone Book using T9 Text Input.
Key Functions
Soft Key 2
: Press to scroll and select a mode through
menus.
- You can scroll through the modes using Soft Key 2
in the following order : Abc 123 Symbol
Help T9En
- SHIFT Key ( ): Used to change the letter case.
~
(Type Text)
:
In T9 mode, press one key per
letter to enter text.
~
(Type Numbers)
: In 123
(Numbers)
mode,
press once to enter numbers.
(Next)
:
In T9 mode, press to display other matching
words.
(Punctuation)
:
In T9 mode, press to insert punctuation
in a word and complete a sentence.
(Space)
: Press to complete a word or insert a space.
(Clear)
: Press to delete a single space or character.
Press and hold to delete entire words.
24
Input mode
T9 Text Input provides five modes for entering text,
numbers, special characters, and punctuation.
T9En
(
T9
)
Mode
Type text using one keystroke per letter. The default is
T9 mode.
ABC
(
Multi-tap
)
Mode
Use ABC mode to add words to the T9 database.
123
(
Numbers
)
Mode
Type numbers using one keystroke per number.
To change to 123 mode in a text entry field, press Soft
Key 2 until 123 mode is displayed.
SYMBOL Mode
Insert special characters and punctuation.
You may use any of the 33 special characters.
When
the cursor is located where you want the special
character, switch to SYMBOL mode. Press Navigation
Key to cycle through and select from the following
characters
:
25
Get t ing St art ed
T9Help Mode
Display T9 Help Text.
Changing Letter Case
There are three options for selecting letter cases:
Initial Cap
(
T9En/Abc
)
Only the first letter is capitalized.
Caps Lock
(
T9EN/ABC
)
Press to change letter case to Caps Lock.
All subsequent letters are capitalized.
Lowercase
(
T9en/abc
)
Press again to change letter case to lowercase.
Examples Using T9 Text Input
Typing In T9 Mode
To type a new message, follow these steps:
1. Press:
Soft Key 2 to change letter case to
T9En mode.
2. Press: .
3. Press: to complete the word and add a space.
4. Press: .
5. Display: Call the office.
26
Using the NEXT Key
After you have finished typing a word, if the word displayed
is not the word you want, press to display additional
choices.
For example, follow these steps :
1. Press: .
2. Display: Good
3. Press: .
4. Display: Home, Gone, Hood......
Adding Words to the T9 Database
If a word is not in the T9 database, add it by using ABC
(Multi-tap) mode text entry. The word is automatically
added to the T9 database when you return to T9 mode.
For example, follow these steps:
1. Press: Soft Key 2 to change letter case to ABC
(multi-tap) mode.
2. Press: .
3. Display: Imt
4. Press: Soft Key 2 to change letter case to T9
mode and then the word Imt will be added to the T9
database
5. Press: to erase the existing word.
6. Press: .
7. Display: got
8. Press: .
9. Display: Imt
27
Get t ing St art ed
Examples Using ABC
(
Multi-tap
)
Text Input
Typing In ABC (Multi-tap) Mode
To type a new message, follow these steps:
1. Press:
Soft Key 2
to change letter case to
ABC mode
2. Press: to change to ABC Caps Lock mode
3. Press: .
4. Display: LG
28
Chapter 2. Basic Functions
Turning the Phone On and Off
Turning the Phone On
1. Install a charged battery pack or connect the
phone to an external power source such as the
cigarette lighter adapter or car kit.
2. Press for a few seconds until the red light
in the middle of the phone flashes.
Fully extend the antenna for the best performance.
Like any other radio device, avoid any unnecessary
contact with the antenna while your phone is on.
Turning the Phone Off
1. Press and hold until display
screen turns off, then release the
key.
2. Protect the antenna by pushing it
back into the phone, if extended.
29
Basic Funct ions
Making a Call
When you make a call, follow these simple steps:
1. Make sure the phone is turned on.
If not, press .
2.
Enter the phone number, with area code (if needed).
3. Press .
If the phone is locked, enter the lock code.
Call Failed indicates that the call did not go
through.
4. Press to the call.
5.
This phone has been restricted If this message
displays on your screen, then outgoing calls are in
restricted mode. You can only dial phone numbers
saved in Emergency or Phone Book list.
If you want to turn off this function, take the
following step.
Menu (Press four times) Security
Restrict Enter Lock Code No Ok
6. When one - touch is enabled, type in the phone
book entry number and hold the last digit until
the call is made.
Phone number and entry name appear on the display
when you type in the entry number and hold the last
digit.
30
Correcting Dialing Mistakes
If you make mistakes while dialing a number, press
once to erase the last digit entered or hold
down for at least two seconds to delete all
digits, or simply press Soft Key 2 Back to exit the
dialing state.
Receiving Calls
1. When the phone rings, open the
cellcase or if the cellcase is open,
press any key (except ,
or ) to answer.
If you press the or Side Keys (
,
)
while the phone is ringing, the ringing or vibration
is muted for that call.
2. Press , or twice to end the call.
Using Manner & Lock Mode
Manner Mode (Quick)
Use Manner Mode in a public place.
1. In standby mode, activate Manner
Mode quickly by pressing the ,
. (for 3 seconds) instead of using
the Menu function.
When Manner Mode is set, -Manner Mode- ( )
is displayed on the LCD screen.
When Manner Mode is set, Key tone does not
sound and Vibration is selected as the ringer.
To cancel Manner Mode, press , again until
Normal Mode Entered! is displayed.
Lock Mode (Quick)
Use to prevent others from using your
phone.
1. In standby mode, to activate the
Lock Mode quickly, press the
(for 3 seconds).
Lock mode Setting! will be displayed.
To cancel the Lock Mode, Press Soft Key 1 Unlock,
then enter your password (4 digits).
The lock code (password) is commonly the last 4
digits of your phone number.
31
Basic Funct ions
32
Call Waiting
Your cellular service may offer a call waiting function.
While a call is in progress, you may hear two beeps
indicating another incoming call. When call waiting is
enabled, you may put the active call on hold while
you answer the other incoming call. Check with your
cellular service provider for information about this
function.
1. Press to receive a waiting call.
2. Press again to switch between calls.
Mute
The mute function prevents the other
party from hearing your voice, but
allows you to hear the other party.
1. Press Soft Key 1 Menu and
during a call.
2. To cancel Mute, press Soft Key 1 Menu and
again.
33
Basic Funct ions
Redialing Calls
1. Press to redial the last number in call history.
You can also redial any of the last 30 numbers
you have dialed. The last 30 numbers are
stored in the call history list. (See the Call
History List on page 73.)
Adjusting the Volume
The volume keys on the left side (Side Keys) of the
phone can be used to adjust the earpiece, ringer,
and key beep volumes. The upper key is used to
increase and the lower key is used to decrease the
volume.
You may adjust the earpiece volume during a call.
The ringer volume can be adjusted through the
Menu feature.
If you adjust the ringer volume to minimum or set
the lamp in ringer type, the LCD displays
-Ringer
Off- and you will not hear the ringer sound.
The key beep volume is adjusted through Menu
feature.
34
Power Save Mode
When the phone is in an area without service for about
15 minutes, it stops searching for service and enters
into Power Save Mode. When your phone activates
this feature, Power Save is displayed on the screen.
The phone automatically checks for service periodically
or you can check manually by pressing any key.
Signal Strength
The call quality depends on the signal strength in your
area. The current signal strength is displayed on the
screen as the number of bars next to the signal
strength icon: The more bars, the better the signal
strength. If the signal quality is poor, move to an open
area. If you are in a building, the reception may be
better near a window. For maximum reception, make
sure that the antenna is fully extended.
Caller ID Display
The small LCD on the outside of the
phone displays information such as:
Date and Time.
Caller ID (caller’s information[name and/or number])
Number of missed calls.
Number of new messages.
No service status and Power Save Mode.
Wake up and scheduler message.
The phone will display most recent information until
the cellcase is opened, then the information will
appear on the main display.
35
Basic Funct ions
Speed Dialing
(see Making a call from
Phone Book on page 41.)
Speed dialing is a convenient feature, which allows
you to make phone calls quickly and easily. Your
phone recalls the phone number from your personal
directory, displays it briefly and then dials it.
1. Enter memory location number 001 to 199 .
2. Press .
Caller ID
Caller ID lets you know who is calling by displaying
the number of the person calling when your phone
rings. If the caller’s name and number are already
stored in your phone book, the corresponding name
appears with the number.
You should check with your service provider to
ensure they offer this feature.
36
Phone Book Features
You can store up to 199 entries in your phone book
with easy access to your most frequently dialed phone
numbers.
Personal Phone Book Memory
The phone has 199 personal phone book memory
locations where you can store up to 5 phone numbers
with 32 digit capacity for each phone number.
Saving Numbers in Your Personal Phone Book
Memory locations 1 through 9 should be used for one-
touch dialing for your most frequently used phone
numbers.
1. Input the phone number that you
want to save (up to 32 digits).
2. Press Soft Key 1Option, the sub-
menu appears.
3. Select Save on the sub-menu.
4.
The phone will prompt you for the
memory location where the number
will be saved. Press Soft Key 1Next
to automatically store the number in
the first available memory location.
37
Basic Funct ions
38
You also have the option to enter a specific three-
digit memory location number.
5. Select your desired label types
Home, Office, Mobile, Pager,
Data /Fax and E-mail using .
6.
Enter a name for the phone number
(up to 16 characters). If you do not
want to enter a name, go to the next
step.
7. You may select the desired ID ring
type, secret and .
8. Press Soft Key 1 Save.
A confirmation prompt Saved! Thanks!
displays on the phone.
Retrieving Numbers
Retrieving by Name Search
1. Press Soft Key 2 PIM.
2. Press Find Name.
3.
Enter the character(s) that you want
to search for (such as the few letters
of the name.)
4. Press Soft Key 1 Find.
5. You will see a list of matches.
6. Press Soft Key 1 View to see
specifics in that memory location,
or press to place the call.
39
Basic Funct ions
Retrieving Phone Numbers Using Memory Location
Number.
From the initial display, press Soft Key 2 PIM and
then select Find Entry. Enter the location number to
be retrieved.
To search for stored phone numbers, from the initial
display enter a specific number(s) and a list containing
that number(s) appears. If you want to make a call,
select the number you want by using , then press
.
How do I add phone numbers, names, and e-mail
address on a previously saved number in my
Personal Phone Book (See pages 69 ~72)
40
41
Basic Funct ions
Making a call from Your Phone Book
You can place a call from any memory location either
by using speed dialing or by entering the phone number
and pressing .
One-Touch Speed Dialing: This feature enables you
to store your nine most frequently used numbers in
your phone book in memory locations (1 through 9)
For locations 1 through 9, you can use one-touch
dialing (if enabled, see One-Touch on page 60)
by pressing and holding the corresponding key to
the memory location to be dialed.
OR
Press a digit, then press .
42
Two-Touch Speed Dialing : This feature enables
you to dial numbers in your
phone book through two
keys (for locations 10 to 99.)
1) Press the first digit.
2) Press and hold the key of the second digit.
OR
1) Press the first and second digit, then press .
Three-Touch Speed Dialing: This feature enables
you to dial numbers in your phone book by pressing
three keys (for locations 100 to 199.)
1) Press the first and second digits.
2) Press and hold the key of the third digit.
OR
1) Press the first, second, and third digits, then press
.
Dialing from a Memory List
1) From a memory list, press the scroll keys to go to
the memory location you want.
2) Press .
Dialing from a Memory Location
While viewing a memory location, press to call.
Advanced Phone Book Features
1. Pause Feature: When you call automated systems
(such as voice mail or credit billing numbers), you
often have to enter a series of numbers. Instead of
entering these numbers by hand, you can store the
numbers in your phone book separated by special
characters(eg. , )called pauses.
There are two different pauses that you can use
when storing a number
:
Hard Pause (H)
The phone will stop dialing until you press Soft
Key 1
Resume
to advance to the next number
.
Time Pause (T)
The phone will wait two seconds before sending
the next string of digits
.
2. Storing a number with pauses
1) Enter the phone number.
2) Press Soft Key 1 Option.
3) Select one of the following:
Press Hard Pause.
Press Time Pause.
4) Enter additional number(s) (e.g., pin number or
credit card number).
T
H
43
Basic Funct ions
44
5)
Press Soft Key 1 Option and press Soft Key 1 Ok,
the sub-menu will appear. Select Save on the sub-
menu to save this number with pauses.
6)
The phone will prompt you for the memory location
where the number will be saved. Press Soft Key 1
Next to automatically store the number in the first
available memory location. You also have the
option to enter a specific three-digit memory
location number.
7) Select your desired label type Home, Office,
Mobile, Pager, Data / Fax or E-mail using .
8) Enter a name for the phone number (up to 16
characters.) If you do not want to enter a name, go
to the next step.
Press Soft Key 1 Save. A confirmation message
Saved! Thanks! displays on the phone.
3.
Prepending a Stored Number Prepend can be used
if you are out of your home system area and need to
add the area code to an existing phone book number.
When a phone book entry or message callback
number shows up on the display, you can add to the
beginning of the original number. However, you
cannot edit the original number during Prepend.
1) Recall a number in memory.
2) Enter the prepend digits and the phone number.
3) Press .
4. Dynamic Search
Number Dynamic Search
Compares entered numbers against the entries in
the phone book and then displays a matching list
in descending order. You can then call a number
from the list.
Name Dynamic Search
Compares entered letters against the entries in the
phone book and then displays a matching list in
descending order. You can then call a number from
the list.
45
Basic Funct ions
46
Chapter 3. Menu Features
General Guidelines to MENU Access
and Settings
1. Press Soft Key 1 Menu. Four menu items will
appear on the display screen.
2.
Press to go through the list of menu features.
3. Press the corresponding number to the menu
item that you want to select. Then the sub-menu
list will appear on the screen.
4. Press the appropriate key to select the sub-menu
you want to access.
5. Select preferred settings, using the . Press
Soft Key 2 Back to go one step backward while
accessing menu or selecting settings.
6. Press Soft Key 1 Ok to save the settings or Soft
Key 2 Back to cancel without saving.
47
SOUND
(
Menu
)
Ring Sound
(
Menu
)
To select a Ring Sound.
1. Press Soft Key 1 Menu.
2. Press Ring Sound.
3. Press or until you find the
sound you desire.
4. Then press Soft Key 1 Ok to save
the ring sound.
The beep or bell may cause a serious injury to the
eardrum, so the phone increases the volume
incrementally.
Menu Feat ures
48
Ring Type
(
Menu
)
To select a Ring Type.
1. Press Soft Key 1 Menu.
2. Press Ring Type.
3. Select one of six ring types
Ring,
Vibrate, Vib1+Ring, Vib2 +Ring,
Vib3+Ring
and Lamp with
or .
The number after Vib means the number of vibrations.
4. Then press Soft Key 1 Ok to save the ring type.
Ring & Vib Vol.
(
Menu
)
To select a Ring & Vib Vol.
1. Press Soft Key 1 Menu.
2. Press Ring & Vib Vol.
3.
Adjust the volume of the ringer or
level of the vibrate with
or .
4. Then press Soft Key 1 Ok to save
the ring volume or vibrate level.
49
Key Tone
(
Menu
)
To set Key Tone length and touch tone
playback speed.
1. Press Soft Key 1 Menu.
2. Press Key Tone.
3. Set Normal/Long with or
and then press Soft Key 1 Ok.
Normal
Sends out a tone for a
fixed period of time even if you keep
the key pressed.
Long Sends out a continuous tone for as
long as you keep the key pressed.
Use the side key volume buttons on the side keys of
the phone. The upper button increases the volume and
the lower button decreases the volume.
Dual-Tone Multi Frequency (DTMF) Signaling by
the simultaneous transmission of two tones, one
from a group of low frequencies and another from a
group of high frequencies. Each group of
frequencies consists of four frequencies. Setting Key
Beep length to long will extend the DTMF tone.
Press Menu, then press Key Tone Using
then select Long. Press Soft Key 1 Ok.
Menu Feat ures
50
Key Volume
(
Menu
)
To adjust the key beep volume.
1. Press Soft Key 1Menu.
2. Press Key Volume.
3. Adjust the key volume with
or .
4. Then press Soft Key 1 Ok to save
the key volume.
Ear Volume
(
Menu
)
To adjust the earpiece volume during
a call, press the .
1. Press Soft Key 1Menu.
2. Press Ear Volume.
3. Adjust the earpiece volume with
or .
4. Then press Soft Key 1 Ok to save
the earpiece volume.
51
Escalating Vol.
(
Menu
)
In order to protect your ears, when
the cellcase is open, you may choose
to escalate the ring volume from the
minimum to maximum. It alerts you in
a low volume. But if the cellcase is
closed, it rings according to the ring
volume regardless of the setting of
Escalating Volume.
1. Press Soft Key 1 Menu.
2. Press Escalating Vol.
3. Set Off/On with or and then press Soft
Key 1 Ok.
Menu Feat ures
52
Alerts
(
Menu
)
Any of the four Alert options could be
turned on or off.
1. Press Soft Key 1 Menu.
2. Press Alerts.
Check each option and turn it off if not desired.
1) Fade
(
Menu
)
Sets an alert to inform you when you have lost
a call or services.
2) Minute
(
Menu
)
Alerts you 10 seconds before the end of every
minute during a call.
3) Service
(
Menu
)
If on, alerts you when service changes.
When you enter a service area, the phone displays
Entering Service Area message.
When you leave a service area, the phone displays
Leaving Service Area message.
4) Call Connect
(
Menu
)
Alert tone notifies the user when the call is
connected.
3. Choose among the options and press Soft Key
1 Ok.
4. Set Off/On with or and then press Soft
Key 1 Ok.
53
DISPLAY
(
Menu
Press one time
)
Backlight
(
Menu
Press one time,
)
Choose the settings of the LCD and
keypad backlight.
1. Press Soft Key 1 Menu.
2. Press one time.
3.
Press
Backlight.
4.
Choose an option and press Soft
Key 1 Ok.
10 seconds turns the backlight
off 10 seconds after the last key was pressed.
30 seconds turns the backlight off 30 seconds
after the last key was pressed.
On when Cellcase open means that the
backlight is always on while cellcase is open.
Always on means that the backlight is always
on.
Always off means that the backlight is never
on.
Menu Feat ures
54
Contrast
(
Menu
Press one time,
)
Using the Navigation Key, select the
contrast setting using the scale of
lightest to darkest.
1. Press Soft Key 1 Menu.
2. Press one time.
3.
Press
Contrast.
4. Adjust the contrast with or
.
5. Then press Soft Key 1 Ok to save the contrast
setting.
Banner
(
Menu
Press one time,
)
Enter the string of characters you want
to be displayed (up to 16 characters.)
1. Press Soft Key 1
Menu
.
2. Press one time.
3. Press Banner.
4. Enter a Banner name and then
press Soft Key 1
Save
.
55
Theme
(
Menu
Press one time,
)
You can set up the screen displayed
on the LCD screen in the standby
mode. (Default Analog Clock)
1. Press Soft Key 1 Menu.
2. Press one time.
3.
Press
Theme.
4.
Used to choose the theme between
Default and Analog Clock and
then press Soft Key 1 Ok.
Language
(
Menu
Press one time,
)
Set the Bilingual feature according to
your preference,
choose between
English and Spanish.
1. Press Soft Key 1 Menu.
2. Press one time.
3. Press Language.
4. Set English/Spanish with or
and then press Soft Key 1 Ok.
Menu Feat ures
56
Version
(
Menu
Press one time,
)
View the software and PRL version.
1. Press Soft Key 1 Menu.
2. Press one time.
3.
Press
Version.
4. Press Soft Key 1
Ok.
My Phone #
(
Menu
Press one time,
)
The number will be displayed on the
screen.
1. Press Soft Key 1 Menu.
2. Press one time.
3. Press My Phone #.
4. Press Soft Key 1
Ok
.
57
FEATURES
(
Menu
Press two times
)
Data Setting
(
Menu
Press two times,
)
Data/Fax
(
Press Menu two times, ,
)
In Data/Fax setting, you can use your
phone to transmit data and faxes.
Wireless data communication services
refer to utilization of subscriber
terminals for access to internet with
personal computer or laptops at 19.2
Kbps or at maximum of 230.4 Kbps.
Speed of connection depends on
carrier’s network and other variables.
Contact communication information
specifications must match network.
1. Press Soft Key 1
Menu
.
2. Press two times.
3. Press
Data Setting and then Data/Fax.
4. Press Soft Key 1
Ok
.
Data In: This setting enables the subscriber
terminal to receive data calls.
Fax In: This setting enables the subscriber
terminal to receive fax transmittals.
Data Connection Kit-Your wireless connection to the
Internet and other dial-up networking functions. This
Kit allows you to connect your PC or PDA to your
LG wireless phone, freeing you from having to locate
a telephone outlet. You can send or receive an e-mail,
a fax, or access the Internet anytime, anywhere.
Menu Feat ures
58
Data Baud
(
Menu Press two times, ,
)
This setting enables the subscriber
terminal to set the data baud.
1. Press Soft Key 1
Menu
.
2. Press two times.
3. Press Data Setting and press
Date Baud.
4. Select an option, press Soft Key 1
Ok
.
Data Baud set 19,200/115,200 /230,400
Data Baud needs to be set properly based on
carrier’s network. Contact carrier for the maximum
available speed.
When using 1X HSPD data service by means of a
RS-232C data cable, data baud shall be set to 115,200.
(230,400 shall not be supported). When using 1X
HSPD data service by means of USB data cable, you
may get better data speed if the data baud is set to
230,400 rather than 115,200.
59
Auto Answer
(
Menu
Press two times,
)
Select the ring type before the phone
automatically answers a call. This
feature is used only with the car kit.
1. Press Soft Key 1 Menu.
2. Press two times and press
Auto Answer.
3.
Select an option and press Soft Key
1 Ok.
Off
after 1 ring (or melody for 5 seconds)
after 3 rings (or melody for 10 seconds)
When you have an incoming call, the phone
automatically responds after 1 ring/ 3 rings.
Auto Answer works only when the cellcase is open.
Menu Feat ures
60
Auto Retry
(
Menu
Press two times,
)
Set the length of time the phone waits
before automatically redialing a
number when the attempted call fails.
1. Press Soft Key 1 Menu.
2. Press two times and press
Auto Retry.
3.
Select an option and press Soft Key
1 Ok.
Off/ every 10 seconds/every 30 seconds/every
60 seconds
One-Touch
(
Menu
Press two times,
)
Enable/Disable one-touch dialing.
1. Press Soft Key 1 Menu.
2. Press two times.
3. Press One-Touch.
4.
Select Enable or Disable and press
Soft Key 1 Ok.
Voice Privacy
(
Menu
Press two times,
)
Set the voice privacy feature for CDMA
calls as Enhanced or Standard. CDMA
offers inherent voice privacy. Check
with your service provider for availability
of the enhanced voice privacy mode.
1. Press Soft Key 1 Menu.
2. Press two times.
3. Press Voice Privacy.
4.
Select Enhanced or Standard and press Soft Key
1 Ok.
Audio AGC
(
Menu
Press two times,
)
Enable / Disable the function of Audio
AGC(Auto Gain Control) system.
This feature provides a better audio
experience by enabling the Audio
AGC system to control the dynamic
range and volume of the sending and
receiving voice across different levels
of speaker and environments.
1. Press Soft Key 1 Menu.
2. Press two times.
3. Press Audio AGC.
4. Selcet Off or On and press Soft Key 1 Ok.
61
Menu Feat ures
62
SYSTEM
(
Menu
Press three times
)
System Sel
(
Menu
Press three times,
)
This function enables set up of the user’s
mobile phone producer’s management
environment. Leave this setting at the
default unless you want to alter the
system selection. (As instructed by your
service provider.)
1. Press Soft Key 1 Menu.
2. Press three times and press
System Sel.
3. Select an option and press Soft Key 1 Ok.
Home is B (Automatic_B, Automatic_A, Home
only) is displays.
Set NAM
(
Menu
Press three times,
)
Select the phone’s NAM (Number
Assignment Module) if the phone is
registered with multiple service
providers.
1. Press Soft Key 1 Menu.
2. Press three times, and press
Set NAM.
3.
Select NAM#1 or NAM#2 and press
Soft Key 1 Ok.
Auto NAM
(
Menu
Press three times,
)
Allows the phone to automatically
switch between programmed telephone
numbers corresponding to the service
provider area.
1. Press Soft Key 1 Menu.
2. Press three times and press
Auto NAM.
3.
Select Off or On and press Soft Key
1 Ok.
Force Call
(
Menu
Press three times,
)
Allows the phone to make an analog
call. You have 30 seconds to place the
call. This feature is typically used for
data applications.
1. Press Soft Key 1 Menu.
2. Press three times and press
Force Call.
3. Press Soft Key 1 Ok.
63
Menu Feat ures
64
Serving Sys
(
Menu
Press three times,
)
You can identify the channel number
of System which is served and SID
Number.
This information is only for technical
support.
1. Press Soft Key 1 Menu.
2. Press three times and
press
Serving Sys.
3. Press Soft Key 1 Ok.
TTY Mode
(
Menu
Press three times,
)
Users can attach a TTY device and
communicate with parties also using a
TTY device. A phone with TTY support
is able to translate typed characters to
voice. Voice can also be translated
into characters and then displayed on
the TTY.
1. Press Soft Key 1 Menu.
2. Press three times and press
TTY Mode.
3. Select an option and press Soft Key 1 Ok.
TTY users must have a TTY / TDD device.
SECURITY
( Menu
Press four times
)
Lock Mode
(
Menu
Press four times,
)
Keeps your phone from unauthorized
use. Once the phone is locked, it is in
restricted mode, until the lock code is
entered. This will allow you to receive
phone calls and still make emergency
calls. The lock code is commonly the
last 4 digits of your phone. If you
need to modify the lock code, you
may modify it using the New Lock
code within the Security menu.
1. Press Soft Key 1 Menu.
2. Press four times and press
Lock Mode.
3. Enter the four-digit Lock code.
4. Select an option and press Soft Key 1 Ok.
Never means that the phone is never locked
(Lock mode can be used). When locked, you
can receive incoming calls or make only
emergency calls.
On power up means the phone is locked when
it is turned on.
Always means that the phone is always locked.
65
Menu Feat ures
66
Restrict
(
Menu
Press four times,
)
To change your restrict.
1. Press Soft Key 1 Menu.
2. Press four times and press
Restrict.
3. Enter the four-digit lock code.
4. Select Yes or No with or
and then press Soft Key 1 Ok.
If you set it to Yes you can only
place calls to emergency numbers
and phone numbers stored in the memory locations.
You can still receive calls in the restrict mode.
Clear Call
(
Menu
Press four times,
)
Allows you to delete all the telephone
numbers saved in the Call History.
1. Press Soft Key 1 Menu.
2.
Press
four times and press
Clear Call
.
3. Enter the four-digit lock code.
4. Use to select Yes.
5. Press Soft Key 1 Ok.
Clear Data
(
Menu
Press four times
)
Deletes all information saved in memory
locations (001-199), schedule, and
wake up. Be careful since any deleted
information is not recoverable.
1. Press Soft Key 1 Menu.
2.
Press four times and press
Clear Data.
3. Enter the four-digit lock code.
4. Using the then select Yes.
5. Press Soft Key 1 Ok.
Emergency #
(
Menu
Press four times,
)
You can call these numbers, and 911,
even when the phone is locked or
restricted.
To enter 3 emergency numbers.
1. Press Soft Key 1 Menu.
2. Press four times and press
Emergency
#
.
3. Enter the four-digit lock code.
4. Use to select Edit.
5. Enter an Emergency number.
6. Press Soft Key 1 Save.
7. Press .
67
Menu Feat ures
68
New Lock Code
(
Menu
Press four times,
)
New Lock Code allows you to enter
a new four-digit lock code number.
This is the same number as the pin
code.
1. Press Soft Key 1 Menu.
2. Press four times and press
New Lock Code.
3. Then enter the four-digit lock code.
4. For confirmation, it will ask you to enter the new
lock code again.
69
PIM Feat ures
Chapter 4. PIM Features
PHONE BOOK
(
PIM
)
Find Entry
(
PIM
)
To find phone numbers you have stored
in the Phone Book.
1. Press Soft Key 2 PIM .
2. Press Find Entry.
3.
The display prompts you to enter the
entry number on the display screen.
4. If you press Soft Key 1 Ok without
entering an entry, you will view a
list of all entries in your phone book.
At any entry, you may move to another entry by
pressing the Up/Down( )key.
If you press Soft
Key 1
Option
, you can save or erase.
70
Find Name
(
PIM
,
)
To search for a phone number by
name.
1. Press Soft Key 2 PIM.
2. Press Find Name.
3
.
Enter the letter(s) that you want to
search for (at least three letters are
required for a quick search). Then
press Soft Key 1 Find. A list of
matching names is displayed. If the
name is found, the name will be displayed and if
the name is not found, the message Entry Empty!
will appear. Following the above message, if the
saved content is not found, the Not Found message
appears on the screen.
On the Find Name menu, you can change mode by
pressing
Soft Key 2.
(Abc -> 123 -> Symbol -> Help
-> T9En )
71
PIM Feat ures
Add Entry
(
PIM
,
)
You can save phone numbers, pager
numbers and so on, up to 199 entries .
1. Press Soft Key 2 PIM.
2. Press Add Entry.
3.
Enter the phone number, then press
Soft Key 1 Next.
4.
Select the memory location number.
5. Press Soft Key 1 Next.
6.
Select the desired phone number type using
.
7. Enter Name.
To enter an Email address, select E-mail from
label, press to move to the available E-mail
addresses.
8. You may select the desired ID ring type ,
secret / using .
Phone Type
Home Phone Number Entry
Office Phone Number Entry
Mobile Phone Number Entry
Pager Number Entry
Data/Fax Number Entry
E-Mail Address entry
72
Find Email
(
PIM
,
)
1. Press Soft Key 2 PIM.
2. Press Find Email.
3.
Enter the E-mail address you want
to search for and press Soft Key 1
Find. If the E-mail address is found,
the E-mail address will be displayed
and if the E-mail address is not
found, the message Entry Empty!
will appear. Following the above
message, if the saved content is not
found, the message Not Found appears on the screen.
Select the item you want to view using .
4. After selecting the E-mail address to edit from the
E-mail list, press Soft Key 1 View and the phone
book entry will be displayed.
5.
After selecting the E-mail label, press to move
to an available entry where you can edit or delete.
6.
To save, press Soft Key 1 Save or press Soft Key 1
Option and Select Save Entry on the sub-menu.
To delete an E-mail address: Move to the Phone
book from either Find Email or Find Entry. After
selecting the E-mail label, press to move to
the memory location, press and hold to
delete the E-mail address and press Soft Key 1
Save to confirm.
73
PIM Feat ures
CALL HISTORY
(
PIM
Press one time
)
Allows you to view the 30 most recent phone calls.
Once you exceed the (total) 30-number storage limit,
the oldest call history record is overwritten. These
calls are divided into 3 types of calls.
Outgoing
(
PIM
Press one time,
)
Allows you to view list of all outgoing
calls.
Maximum 10 numbers are possible.
1. Press Soft Key 2 PIM.
2.
Select CALL HISTORY,
Outgoing.
3. You may place a call by pressing .
Incoming
(
PIM
Press one time,
)
Allows you to view list of all incoming
calls.
Maximum 10 numbers are possible.
1. Press Soft Key 2 PIM.
2. Select CALL HISTORY, Incoming.
3. You may place a call by pressing .
74
Missed
(
PIM
Press one time,
)
Allows you to view list of all missed
calls.
Maximum 10 numbers are possible.
1. Press Soft Key 2 PIM.
2.
Select CALL HISTORY,
Missed.
3. You may place a call by pressing .
Works only in digital area and if it is not restricted.
Recent Call History List
Allows you to view the 30 most recently dialed phone
numbers. Speed dialing a number in the Call History
List is available.
1. Press Soft Key 2 PIM.
2. Example: Select Outgoing
3. Press , or to scroll through the last
calls and scroll to the number you want to call.
4. Press to place a call. Or to see the details of
the call choose View from the Soft Key 1 Option.
Press Soft Key 1 Save to save the number in a
memory location. (If you need further information
please refer to pages 37~38)
Press number key to prepend in view status. You
can make an addition, if needed, to the beginning
of original number and press
.
5. To erase the call from the list, choose Erase from
the Soft Key 1 Option.
75
PIM Feat ures
Call Info
(
PIM
Press one time,
)
1. Last Call
(
PIM
Press one time, ,
)
Displays the duration of the last call
made.
2. Home Calls
(
PIM
Press one time, ,
)
Keeps a running count of the time spent
making calls in your service area since
the last reset. To reset the counter,
press Soft Key 1 Option, select Zero
using and then Soft Key 1 Select.
3. Roam Calls
(
PIM
Press one time, ,
)
Keeps a running count of the time spent
making calls outside your service area.
To reset the counter, press Soft Key 1
Option, select Zero using and then
Soft Key 1 Select.
4. All Calls
(
PIM
Press one time, ,
)
Keeps a running count of the time spent
making all calls, either inside or outside
your area. Resetting the call time is not
available
.
76
SCHEDULER
(
PIM
Press two times
)
Scheduler Functions
Scheduler keeps your agenda convenient and easy to
access. Simply store your appointments and your
phone alerts you with a reminder of your appointment.
You can also take advantage of the wake-up feature.
If transmitting SMS or connecting UP during a call,
at the preset time, it does not ring. After exiting, it
will ring the reminder.
General Guidelines to Scheduler Access
and Setting
1. The menu will appear when you press Soft Key 2
PIM.
2. Scroll through the menu list by using .
3.
To make a selection, locate the entry on the menu
and press Soft Key 1 Select on left or by pressing
number on the menu.
4.
Move between entries on the menu by using
.
5. Press Soft Key 1 Select to make new entries and
Soft Key 2 Back to exit without making new
entries.
6.
If you want to see the calender, press in standby
mode.
77
PIM Feat ures
How to use buttons
,
Moves cursor to the left.
,
Moves cursor to the right.
Moves to the previous week.
Moves to the next week.
Moves to the previous year.
Moves to the next year.
Moves to the previous month.
Moves to the next month.
Moves to today.
78
Add Event
(
PIM
Press two times,
)
Allows you to input your schedule.
If you input the time and memo, an
alarm rings at the set time.
1. Press Soft Key 2 PIM.
2. Select SCHEDULER, Add
Event.
3. Select the date using your keypad
(refer to p77), then press Soft Key
1 Select.
4.
Enter the time and data of the event
using your keypad.
5. To toggle between AM and PM,
select am/pm using side key s
( ) .
6. Enter a title and press Soft Key 1 Save.
7. Press .
View Daily
(
PIM
Press two times,
)
Allows you to view all events of a
selected date.
1. Press Soft Key 2 PIM.
2. Select SCHEDULER, View
Daily.
3. Select the date using your keypad
(refer to p77), then press Soft Key
1 Select.
4. Select the item and press Soft Key
1 View.
You will see a list of matches.
5. Press Soft Key 1 Option.
You may select either Erase or
Edit.
79
PIM Feat ures
80
View All
(
PIM
Press two times,
)
Allows you to view all stored events.
1. Press Soft Key 2 PIM.
2. Select SCHEDULER, View
All.
All stored entries will appear.
3. Select the item and press Soft Key
1 View.
You will see a list of matches.
4. Press Soft Key 1 Option.
You may select either Erase or Edit.
Erase All
(
PIM
Press two times,
)
Allows you to delete all items stored
in the scheduler.
1. Press Soft Key 2 PIM.
2. Select SCHEDULER, Erase
All.
You are then prompted to Erase
All.
3. To delete information, scroll to Yes
and press Soft Key 1 Ok.
All items in Scheduler will be deleted.
81
PIM Feat ures
Erase Old
(
PIM
Press two times,
)
Erases only the past Scheduler items.
1. Press Soft Key 2 PIM.
2. Select SCHEDULER, Erase
Old.
Y
ou are then prompted to Erase
Old.
3.To delete information, scroll to Yes
and press Soft Key 1 Ok.
Past Scheduler items will be deleted.
82
WAKE UP
(
PIM
Press three times
)
Works only in digital area.
Wake up
(
PIM
Press three times,
)
To change an event alarm time.
1. Press Soft Key 2 PIM.
2. Press three times, then press Wake up.
3. Set time for alarm and press Soft Key 1 Save.
The current time will be displayed on the upper
portion of the screen.
4. You can change the alarm mode using or
.
(Off/ Daily /Once)
5. You can move to the edit window using .
At alarm time, Wake Up will be displayed on
the LCD screen and the alarm will sound.
Am/pm may be selected using the Side key.
Ringing(or vibration, Vib1+Ring, Vib2+Ring,
Vib 3+Ring) will stop when any key is pressed
or cellcase is opened.
Ring volume is controlled according to setting in
reception mode. However, ringing (or vibration,
Vib1+Ring, Vib2+Ring, Vib 3+Ring) will not be
heard when reception mode is in Lamp.
83
PIM Feat ures
GAME
(
PIM
Press four times
)
You can get key information about playing a game
if you press after selecting Black Jack game or
Comanche in menu.
Comanche
(
PIM
Press four times,
)
You control a Comanche helicopter.
Your objective is to destroy the enemy’s
helicopters, tanks, and automobiles. If
you attack ambulances, you lose 5
points for each. You clear each stage
by destroying the building at the end of the stage.
To Play the Game
1. Press Soft Key 2 PIM.
2. Press four times.
3. Choose game Comanche and press Select.
4. For a new game, press
.
5. To start the game, press Soft Key 1 .
84
1. Keypad Configuration - Menu Screen
:
Moves to selected menu's
screen.
: Moves to Score screen.
: Moves to Keypad Confi-
guration screen.
: Resumes the game if paused.
: Moves to the Game Selection screen.
: Ends the game.
2.
When you see the game's logo on
the screen, you can select from stage
1 to stage 10 by using 0 to 9 on the
keypad. After selecting a stage, you
begin gameplay by pressing Soft Key
1 .
85
PIM Feat ures
3. Keypad Configuration - Game Screen
:
Moves Comanche one tile up.
If you push and hold the button,
Comanche keeps moving
upwards.
:
Moves Comanche one tile to the left. If you
push and hold the button, Comanche keeps
moving to the left.
:
Moves Comanche one tile to the right. If you
push and hold the button, Comanche keeps
moving to the right.
:
Fires air-to-air missile.
:
Moves Comanche one tile down. If you push
and hold the button, Comanche keeps moving
downward.
:
Fires air-to-ground missile.
:
Moves Comanche one tile to the left.
:
Moves Comanche one tile to the right.
:
Moves Comanche one tile up.
:
Moves Comanche one tile down.
:
Pauses the game.
86
4. Score input screen
:
@ 1 $ . , ? ! + - * / = ' " ; :
:
A B C 2
:
D E F 3
:
G H I 4
:
J K L 5
:
M N O 6
:
P Q R S 7
:
T U V 8
:
W X Y Z 9
:
0 & ^ | ~ # % ( ) [ ] { } < > _
:
Space
:
Delete
:
Ends the game
:
Switches between lowercase and uppercase
characters
:
Input name completed
87
PIM Feat ures
Black Jack
(
PIM
Press four times,
)
Black Jack is a card game. The one
whose cards add closest to 21 wins
the hand. The player and the dealer
get dealt two cards each. The player
then chooses to receive another card
(Hit) or play what he was dealt (Stay). You can get
as many cards as you want, but the total value of
the cards must not exceed 21. An (Ace) is valued at
1 or 11. J (Jack), Q (Queen) and K (King) are
valued at 10. Two through Ten receive face value. If
your first two cards are composed of an A and one
of 10, J, Q, and K, gets a “Black Jack”. The dealer
shouts out “Black Jack”. If you get Black Jack you
win the hand, unless the dealer also has a Black
Jack.
To play Black Jack
1. Press Soft Key 2 PIM.
2. Press four times.
3. Choose game Black Jack and press Select.
4. For a new game, press .
5. To start the game, press Soft Key 1 .
88
1. Keypad Configurations - Menu Screen
:
Begins a new game.
:
Moves to score screen.
:
Moves to key configurations
screen.
:
Resumes the game if paused.
:
Moves to game selection menu.
:
Ends the game.
2. Key Configurations - Game Logo Screen
:
Pauses the game.
:
Ends the game.
:
Moves to Betting screen.
:
Moves to Game Menu screen.
3. Key Configurations - Betting Screen
:
Decreases bet.
:
Increases bet.
:
Ends the game and moves
to Input Name screen.
:
Pauses the game.
:
Ends the game.
:
Moves to Dealing Screen.
89
PIM Feat ures
4. Keypad Configurations - Dealing Screen
:
Pauses the game.
:
Ends the game.
5. Keypad Configurations - Game Screen
:
HIT
:
STAY
:
DOUBLE (Appears only
when you have two of the
same card; such as 2 k’s)
:
Pauses the game
:
Ends the game
The rest are the same as the keypad configurations
in Comanche.
90
Setting
(
PIM
Press four times,
)
You can set sound volume of the
game and backlight to on or off.
To change your phone’s setting when
you play the game.
1. Press Soft Key 2 PIM.
2. Press four times, then press Setting.
3. Use to choose the setting between Sound
Volume and Backlight.
CALCULATOR
(
PIM
Press five times
)
Calculator
(
PIM
Press five times,
)
Calculate simple mathematical
computations.
(Can enter numbers up to the second
decimal place.)
1. Press and in order.
2. Press five times.
3. Select (multiplication) using keys.
4. Press , in order.
5. Select using Soft Key 1 Answer.
You will see the result of the calculation 250.
Calculation should be 50 characters (for example,
50+14-...).
Valid result is 2.14*E9.
91
PIM Feat ures
92
Chapter 5.Message Features
Text message, page and voice mailbox become
available as soon as the power is on. You can access
the above types of messages using the Message Key
. In addition, you can make a call to the call back
number by pressing during a message check.
The phone can store up to 30 messages (1 Voice
message: 29 text messages) with 245 characters
per message. Users may read and edit messages,
saved in the outbox during transmission and send
them.
However, you should check whether your carrier
provides the above features.
Character limits: The VX1 supports up to 245
characters per message including header information.
Limits to available characters per message may exist;
please check with your service provider for system
capabilities.
The information that is stored in the message is
determined by phone mode and service capability.
You can check types of messages by pressing the
Message Key .
93
Message Feat ures
Types of Menu
Voice:
Shows the number of messages in voice mail.
Send Msg: Sends a message.
Inbox: Shows you the list of the received messages.
Outbox: Informs the status of the saved message.
Erase Msgs: Deletes all stored messages.
Setting: Select alert type for new message(s).
New Message Alert
There are four ways your phone alerts you to new
messages.
1. The phone displays the message on the display
screen.
2. One of four ring types is heard if selected.
3. The red light blinks.
4. The message icon is displayed on the display
screen . In the case of an urgent message,
the icon will flash and it displays as an Urgent
message.
If you receive the same message twice, your phone
deletes the older one and the new one is stored as a
DUPLICATE.
94
SMS
( )
Voice
(
,
)
Allows you to view the new voice
messages recorded in the voice mail
box. Once you exceed the storage limit,
the old messages will be overwritten.
When you have a new text message,
your phone will alert you.
Checking your Voice Mail box
1. Press .
2. Select Voice.
To delete information press Soft Key 1 Option
and then select Erase.
While you are answering another call, if you have a
new message, the call back number will be displayed
on the screen.
Out of Memory Warning
No more messages can be received until enough
memory space becomes available.
At this time, the message NOT ENOUGH MEMORY
will be displayed on the screen and any new
message is not accepted.
95
Message Feat ures
Send Message
(
,
)
Text messages, page messages, and
e-mail transmissions are all available.
If there is a message in the transmission,
it is a text message. When there is no
message in the transmission, it is a page.
To send a message, enter a SMS phone number to
Send To 1. Select Continue in Option menu and
enter a message in the content entering stage. Press
Send in Option to send the message.
To send e-mail, enter recipient
’
s e-mail address.
96
Menu
Send to 1: This feature allows multi-sending of up
to 10 total addresses.
There are five optional menus of Continue, Next
Addr, Prev Addr, Book, and Back.
1. Press .
2. Select Send Msg.
3. After entering the phone number
where the message is to be sent,
press Soft Key 1
Option.
Continue Use to save the
current address.
Next Addr Allows you to enter
the next sending
address.
Prev Addr
Allows you to edit
the previous sending
address.
Book Allows you to refer
to the address in the phone book.
By reading the phone number or e-
mail address, you may save them as
recipient numbers.
Back Goes back to the previous page.
97
Message Feat ures
4. After entering a message to be
sent by selecting Continue, press
Soft Key 1 Option.
Send Use to send the
message.
Save
Use to save the
sending address, call
back number, user
data, call timer.
Back
Goes back to previous
page.
Option Send, CB#, Priority,
Deferred, Validity, and Delivery ACK
are available options.
-
Send With the changed parameters, send
the message.
-
CB
Used to enter the call back number.
-
Priority
Allows you to give the priority to
message. Normal or Urgent.
-
Deferred
Allows you to delay sending the
message until the programmed time
frame.
Delaying time frame is as follows
:
Immediate, After 30 Minutes, After 1
Hour, After 2 Hours, After 12 Hours,
After 1 Day and After 2 Days.
98
-
Validity
Indicates the validity of message
delivery to the Short Message Center
(SMC) without being transmitted to the
sending address for certain periods of
time. Those messages will be deleted
within the programmed time frame.
Validity time frames are as
follows
:
Default, 30 Minutes, 1 Hour, 2 Hours,
12 Hours, 1 Day and 2 Days.
-
Delivery
ACK
Allows you to be certain the message
transmission has gone through.
When all fields are entered, press
to send the message.
If you press without a sending
address, a warning message is
displayed on the screen. When the
message has gone through,
confirming message is displayed on
the display screen. If the message
has not gone through, the No Call
Back phone number received
message will be displayed on the
screen.
Canned Up to 10 frequently used sentences
are displayed. Users may add the
sentences to a message just by
reading canned sentences, not by
entering from the keypad.
Message Feat ures
99
Message Feat ures
-
10 texts : Yes, No, Call me, Need Direct, Where
are you?, Will call later, Busy, On my
way, Will arrive 15 minutes, Thank
you.
5.
If you select Send, it notifies you that
the message was sent successfully.
6.
Then select Soft Key 2 Quit.
7.
This option must be set up by carrier.
100
Inbox
(
,
)
Received text messages, page
messages, and e-mail lists may be
searched, and the contents may be
viewed. Received messages are
sorted in an order of urgent messages,
unread messages and read messages.
To view the list of the received messages.
1. Press .
2. Select Inbox.
Messages are saved in order of URGENT/ NEW/
OLD. For example, if a NEW message is read it
goes into OLD messages.
: URGENT
: NEW
: OLD
3. After selecting the desired message with or
; press Soft Key 1 Option
and select View.
View
You can read the selected
message.
Erase Delete the selected message.
101
Message Feat uresMessage Feat ures
Protect?
Configure Erase Protect on the selected
message. For the Protect configured
message, messages may not be deleted
by Erase Inbox and Erase All functions
of Erase Msgs Menu.
4. Press Soft Key 1 Option after checking the
message.
Reply This function allows you
to reply to this SMS or e-
mail address. If the SMS
has both an originating
address and an e-mail
address, the reply will only be sent to the
e-mail address.
Forward
Forwards a received message to others.
After recipients are entered, the messages
can be forwarded.
Erase
Deletes the selected message from the
Inbox.
102
Save Addr
Stores the callback number, e-mail
address and user data number included
in the received message into your phone
book. When received number information
is displayed, the user can store the
number in the corresponding number list
in the phone book. For an e-mail address,
select the option new entry and old entry.
The new e-mail address may overwrite
an old address entry if necessary. For
new entries, an e-mail address may be
stored with the new memory number.
Protect? Protects a message when deleting all
other messages. There are two options
disable and enable. When you select
Protect?, a lock will be displayed in front
of the protected message.
103
Message Feat ures
Outbox
(
,
)
Up to 30 sent messages can be stored
in the Outbox. Icons indicate if the
messages were successfully sent to the
message center.
Users may view lists and contents of
sent messages in this menu and may also verify if
the transmission was successful or not.
Displays the status of the messages recorded in the
voice mailbox.
1. Press .
2. Select Outbox.
3. After selecting the desired message with or
,
press Soft Key 1 Option . If you select
the sent message ( ) Resend / View / Erase/
Cancel/ Protect? appears on the screen. If you
select the saved message ( ), Send / View/
Erase / Protect? appears on the screen.
Resend Allows you to retransmit the selected
message.
View Shows the message currently saved.
The view menu has three sub-menus
Resend, Open and Erase.
-
Resend
Used to retransmit the selected message.
-
Open
Used to copy the saved message.
-
Erase
Used to delete the recorded message.
104
-
Cancel Used to delete the recorded message.
Erase Delete a selected message in the Outbox.
Cancel Cancels the transmitted message.
Status
:
Send
- Messages saved in Short Message Center
(SMC) have been transmitted.
:
Save - After message editing, it indicates that
messages are only stored in the Outbox
without being transmitted.
:
Fail - Indicates a failed message transmission
.
: Delivery - Message has been delivered.
:
Cancel
- After transmission to message center
has occurred, messages that have not been
delivered may be canceled by transmitting cancel
message.
:
Multi-sending address - Indicates more than one
designated recipient.
:
Pending
-
Transmission is unavailable in analog
mode or in a no service area. Messages are
pending transmission.
Pending messages are
transmitted automatically when digital mode
becomes available.
Erase Msgs
(
,
)
All the voice mailbox messages, text
messages and pages are deleted
when you select Erase Msgs from
the Message Menu screen. Protected
messages are not erased.
Erase Inbox
(
, ,
)
Read messages and all messages are divided and must
be deleted separately. Protected messages are not
deleted
.
Erase Outbox
(
, ,
)
Allows you to delete all messages saved in the
Outbox.
Erase All
(
, ,
)
Allows you to delete all messages in the Outbox and
the Inbox. Protected messages are not deleted.
105
Message Feat ures
106
Setting
(
,
)
Alert, default CB# (call back number),
Auto Save and Auto Delete may be
configured for receiving new messages.
You are alerted in 3 ways when you
receive a new message:
- By displaying a message on the screen.
- By sounding a beep or vibration.
- By the flashing of a lamp.
Alert
(
, ,
)
Allows you to select the alert type for a new message.
Alert types are 2 Alerts, Vibrate, Lamp, and 4 Alerts.
2Min Alert
(
, ,
)
User may select 2-Min Alert for reminder in case a
new message(s) is not opened.
Default CB#
(
, ,
)
By setting this configuration ON, a user may automatically
set his/her phone number as a sender number without
entering phone numbers for message transmission.
Enables its own phone number to be verified on call
back menu.
Auto Save
(
, ,
)
With this feature on, messages are automatically saved
in the Outbox when transmitted.
Auto Delete
(
, ,
)
With this feature on, old messages are automatically
deleted when you exceed storage limit.
107
Message Feat ures
108
Chapter 6. Functions Used During a Call
Mute
(
During a call: MENU
)
Sometimes it may be necessary to
mute a call. To use this function during
a call, press Soft Key 1 Menu and
.
If you need to cancel the mute, press the Soft Key
1Menu and .
Memo
(
During a call: MENU
)
Used to save a phone number the other party tells
you during a call, without writing it down. The phone
number is saved in the Outgoing Call History.
Key Tone
(
During a call:
MENU
)
Set key beep length and touch tone playback speed.
Normal Tone sounds for a fixed duration, no matter
how long you press the key.
Long Tone sounds continuously, as long as you
press the key.
109
Funct ions Used
During a call
Voice Privacy
(
During a call:
MENU
)
Set the privacy feature for CDMA calls as Enhanced
or Standard.
CDMA offers inherent voice privacy. Check with your
service provider for availability of the enhanced voice
privacy mode.
110
Chapter 7. MiniBrowser
The MiniBrowser feature allows you to view internet
content especially designed for the mobile phone
interface. Access and selections within this feature
are service provider dependent.
For specific information on MiniBrowser access
through your phone, contact your service provider.
Browser Start
(
,
Press one time,
)
To start the MiniBrowser.
Browser Msg
(
,
Press one time,
)
If there are any browser alerting messages,
then the list is displayed.
Browser Set (
,
Press one time,
)
1. Prompt (
,
Press one time,
,
)
You can set the function of whether or
not to see the information messages
when you start UP.
Prior to making a MiniBrowser call,
the user is informed that there is a
charge and asks if they still want to launch the
browser. This step is used to prevent accidental
activation of the browser since all subscribers will be
provided with the browser automatically.
Mini Browser
111
Mini Browser
A message is also available to ask the user if they
want to exit the browser, after they press . Users
can disable this extra step (or enable if it is disabled)
through a menu option.
None: You will not see the information messages.
To start: You only see the messages asking
whether or not to start up.
Both: You see the messages asking whether to
start or stop the up.
To end: You see the message asking to stop the
up.
2. Alert Sound
(
,
Press one time, ,
)
There are 3 alert options. Mute, 2 alerts and 4
alerts options are provided in this menu. The user
may select a browser start sound.
112
Overview
The MiniBrowser allows the user to use a variety of
Internet services. Using the MiniBrowser on the phone
allows you to:
Send and receive Internet e-mail.
Browse and search the World Wide Web via web
pages especially designed for wireless phone
customers.
Set bookmarks to directly access your favorite sites.
Retrieve information, such as stock quotes and
flight schedules from the internet.
Quality of Browser
Browsing the web via the phone is not like using your
home computer. Site providers have selected only
the critical aspects of their site to present to wireless
phone users and have removed most graphics.
Billing
Each time you start MiniBrowser, the phone will
connect to the Nationwide Network as necessary, the
phone icon (In Use Icon) will appear on the display
screen, and you will be billed accordingly. Rates will
vary according to your billing plan.
Each time you start the MiniBrowser you will view a
reminder that you will be billed for the connection
time. If you wish to disable this reminder, follow the
steps below:
1. Message Menu Press one time
Browser Set Prompt.
2. Disable the reminder by selecting None using .
Mini Browser
113
Mini Browser
Accessing the MiniBrowser
You can access MiniBrowser by pressing and holding
in the initial screen or by selecting item from Main
Menu screen.
Start MiniBrowser
(
, ,
)
1) A reminder of the charge will appear; press Soft
Key 1 Yes to launch the MiniBrowser if required.
2) After a few seconds, you will see the Home Page.
Ending MiniBrowser Session
You can end a MiniBrowser session by pressing .
If the prompt To end or Both option is set in the
MiniBrowser Setup, you will be prompted whether you
want to end the browser call. (Message Menu
Press one time Browser Set Prompt
.)
Ending browser calls - Users can end a browser session
by pressing .
114
Navigating through the Browser
While using the MiniBrowser, you will find that on-
screen items may be presented in one of the following
ways:
numbered options (some options may not be numbered).
links (embedded in content).
text or numeric input.
simple text.
You can act on the options or the links by using the Soft
Keys. The Soft Keys are just below the display screen.
115
Mini Browser
Navigation keys
S
crolling Up / Down by Item
You can use to scroll through the content if the
current page does not fit on one screen. The currently
selected item is indicated by a cursor on the screen
and will also move the cursor.
Fast Scrolling Up /Down
Press and hold to quickly move the cursor up
and down on the current screen.
Scrolling Up / Down by page
Press Side Keys to move up and down a whole screen
page.
G
o to Home Page
To go back to the Home Page, press and hold .
116
View Browser Menu
Press and hold to use the browser menu when
the MiniBrowser is being used.
Clearing out text/number entered
When entering text or numbers, press to clear
the last number, letter or symbol. And press and hold
to clear the input field completely.
Selecting and activating items using Soft Keys
and/or digits
If the items on a page are numbered, you can use
your keypad (number) Keys or to select an item,
or you can select the items by moving the cursor
and selecting the appropriate Soft Keys.
Soft Keys
To navigate to different screens or select special
functions, use the Soft Keys. Soft Keys are just below
the display screen. Note that the function associated
with the Soft Keys can change for each page and will
depend on each highlighted item.
Soft Key 1
The Soft Key 1 is used primarily for first options or
selecting item but its function may change, depending
on the content displayed.
Soft Key 2
The Soft Key 2 is used primarily for secondary options
or a menu of secondary options.
Entering Text, Numbers, or Symbols
When you are prompted to enter text, the current
text entry method will appear on the Soft Key 2 as
Alpha, Symbol, Number, Word or Smart. (exact
label depends on implementation.)
To change the input mode, use the Soft Key 2.
To create an upper case character, use . And
the current text method will appear on the Soft Key
2 as ALPHA or SMART.
allows user to shift to input case sensitivity.
Initiating aphone call from the MiniBrowser
You can make a phone call from the MiniBrowser, if the
site you are using supports the feature (the phone
number may be highlighted and the Soft Key 1 will
appear as Call).
The browser connection will be terminated when you
initiate the call. After you end the call, your phone
will return to the screen from which you initiated the
call.
Using Bookmarks
You can bookmark many individual pages for easy
access at a later time. Bookmarks save you time by
reducing the number of steps it takes to access a desired
page.
117
Mini Browser
118
To create a Bookmark:
Go to the page that you want to mark. On the browser
menu, select Mark Site or press and hold .
If the page has a title, it will automatically be used for
the name of the bookmark. When the bookmark is
saved you can change the bookmark name if you
choose. Selecting Save will save the name and add the
page to the bottom of your list of bookmarks.
A message will appear confirming that the bookmark
was added to the list. Select Soft Key 1 Ok to return to
the screen that you marked to resume navigation within
the Mini Browser.
This function is dependent upon the html coding of the
page being read and determined by the website.
Finding a Bookmark
From the Home Page or press and hold , then
select the bookmark you want.
Or
From the Home Page, press and hold the number
associated with the bookmark in the bookmark list.
119
Accessories
Chapter 8. Accessories
There are a variety of accessories available for your
mobile phone. You can select these options according
to your personal communication requirements. Consult
your local dealer for availability.
Travel Charger
This charger, model TC-30W, allows you
to charge the battery. It supports standard
U.S. 120 Volt 60 Hz outlets. An orange
light indicates that it is charging, a green
light indicates charging is complete. It
takes 5 hours to charge a completely
discharged battery.
Battery
(LGLi-AATM)
Standard battery and Extended
battery are available.
Desktop Charger
The desktop charger, model
DC-45W
,
allows you to place the phone in the
stand for charging. It can charge a
completely discharged battery in 3
hours.
Standard
battery
Extended
battery
120
Cigarette Lighter Charger
You can operate the phone and trickle
charge the phone’s battery from your
vehicle by using the cigarette lighter
charger, model
CLC-30W
. It takes 5
hours to charge a completely
discharged battery.
Hands-Free Car Kit
(
Portable
)
The hands-free car kit, model
PHF-
32W
, enables you to attach the phone
to the car providing you with hands-
free operation. It will also charge a
completely discharged battery in 5
hours.
Hands-Free Car kit
(
Installed
)
The installed hands-free car kit, model IHF-52W, is
permanently installed in your car, and provides you with
hands-free operation. It will also charge a completely
discharged battery.
121
Acce ssories
Data Cable Kit
Connects your phone to your PC.
(Model KW-
Headset
Connects to your phone, allowing hands-
free operation. Includes earpiece,
microphone, and integrated call answer/
termination button.
(Model Headset 1000)
Hand strap AC Adaptor
Holster
USB Converter Cable
Connects your phone to your PC.
(Model LG-USB 1000
122
Press Soft Key 1Menu . Press to scroll.
Press Soft Key 2 PIM .
Press to scroll.
Press .
Press to scroll.
Menu Tree
Chapter 9. Appendix
SOUND
1. Ring Sound
2. Ring Type
Ring
Vibrate
Vib1 +Ring
Vib2 + Ring
Vib 3+Ring
Lamp
3.
Ring &Vib Vol.
4. Key Tone
Normal
Long
5. Key Volume
6. Ear Volume
7. Escalating Vol
8. Alerts
Fade
Minute
Service
Call Connect
DISPLAY
1. Backlight
10 seconds
Always off
Always on
On when
Cellcase open
30 seconds
2. Contrast
3. Banner
4. Theme
Analog Clock
Default
5. Language
English
Spanish
6. Version
7. My Phone#
FEATURES
1. DataSetting
Data/Fax
Off
Data In
Fax In
Data Baud
2. Auto Answer
Off
after 3 rings
after 1 ring
3. Auto Retry
Off
every
60
seconds
every
30
seconds
every
10
seconds
4. One-Touch
Enable
Disable
5. Voice Privacy
Standard
Enhanced
6. Audio AGC
Off
On
SYSTEM
1. System Sel
Automatic_B
Automatic_A
Home only
2. Set NAM
3. Auto NAM
Off
On
4. Force Call
Use Analog
5. Serving Sys
6. TTY Mode
Disable
Enable
SECURITY
1. Lock Mode
Never
Always
On power up
2. Restrict
3. Clear Call
4. Clear Data
5. Emergency #
6. New Lock Code
4. Call Info
Last Call
Home Calls
Roam Calls
All Calls
SCHEDULER
1. Add Event
2. View Daily
3. View All
4. Erase All
5. Erase Old
WAKEUP
1. Wakeup
GAME
1. Comanche
2. Black Jack
3. Setting
CALCULATOR
1. Calculator
SMS
Voice
Send Msg
Inbox
Outbox
Erase Msgs
1. Erase Inbox
2. Erase Outbox
3. Erase All
Setting
1. Alert
2. 2 Min Alert
3. Default CB#
4. Auto Save
5. Auto Delete
Wireless Web
Browser Start
Browser Msg
Browser Set
1. Prompt
2. Alert Sound
PHONE BOOK
1. Find Entry
2. Find Name
3. Add Entry
4. Find Email
CALL HISTORY
1. Outgoing
2. Incoming
3. Missed
Press .
Press to scroll.
123
Saf et y Guidelines
Chapter 10. Safety Guidelines
Safety Information
Exposure to Radio Frequency Signal
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
European and international agencies have set standards and
recommendations for the protection of public exposure to RF
electromagnetic energy.
International Commission on Non-Ionizing Radiation Protection
(ICNIRP) 1996
Verband Deutscher Elektrotechnik (VDE) DIN-0848
Directives of the European Community, Directorate General V in
Matters of Radio Frequency Electromagnetic Energy
National Radiological Protection Board of the United Kingdom,
GS 11, 1988
American National Standards Institute (ANSI) IEEE C95.1-1992
National Council on Radiation Protection and Measurements
(NCRP), Report 86
Department of Heath and Welfare Canada, Safety Code 6
Those standards were based on comprehensive and periodic
evaluations of the relevant scientific literature. Over 120 scientists,
engineers, and physicians from universities, government health
agencies, and industry reviewed the available body of research to
develop the ANSI Standard (C95.1.)
The design of your phone complies with these standards when used
normally. Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage
the phone and may violate FCC regulations.
124
Efficient Phone Operation
Normal Position
Hold the phone as you would any other telephone with the antenna
pointed up and over your shoulder.
Tips on Efficient Operation:
For your phone to operate most efficiently;
Extend your antenna fully.
Do not touch the antenna unnecessarily when the phone is in use.
Contact with the antenna affects call quality and may cause the
phone to operate at a higher power level than otherwise needed.
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects, including
both installed or portable wireless equipment, in the area over the air
bag or in the air bag deployment area. If in-vehicle wireless equipment
is improperly installed and the air bag inflates, serious injury could
result.
Batteries
Caution: All batteries can cause property damage, injury or burns if a
conductive material, such as jewelry, keys, or beaded chains, touches
exposed terminals. The material may complete an electrical circuit
and become quite hot. To protect against such unwanted current
drain, exercise care in handling any charged battery, particularly when
placing it inside your pocket, purse or other container with metal
objects. Your batteries are packed with a protective battery cover.
When the battery is detached from the phone, please use this cover
for storing your batteries when not in use.
Check the laws and regulations on the use of wireless telephones
in the areas where you drive. Always obey them.
125
Saf et y Guidelines
Also, if using your phone while driving, please:
Give full attention to driving-driving safely is your first responsibility;
Use hands-free operation, if available;
Pull off the road and park before making or answering a call if
driving conditions so require.
Most modem electronic equipment is shielded from RF signals.
However, certain electronic equipment may not be shielded against the
RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6”) inches be maintained between a
handheld wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations are
consistent with the independent research by and recommendations of
Wireless Technology Research.
Persons with pacemakers
Should ALWAYS keep the phone more than six inches from their
pacemaker when the phone is turned ON
Should not carry the phone in a breast pocket
Should use the ear opposite the pacemaker to minimize the
potential for interference
If you have any reason to suspect that interference in taking place,
turn your phone OFF immediately.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids.
In the event of such interference, you may want to consult your
hearing aid manufacturer to discuss alternatives.
126
Other Medical Devices
If you use any personal medical device, consult the manufacturer of
your device to determine if they are adequately shielded from external
RF energy. Your physician may be able to assist you in obtaining this
information. Turn your phone OFF in health care facilities when any
regulations posted in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that could be sensitive
to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer or
its representative regarding your vehicle. You should also consult the
manufacturer of any equipment that has been added to your vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notice so require.
FCC regulations prohibit using your phone while in the air. Switch
OFF your phone before boarding an aircraft.
To avoid interfering with blasting operations, turn your phone OFF
when in a blasting area or in areas posted Turn off two-way radio.
Obey all signals and instructions.
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are not always clearly
marked. They include fueling areas such as gasoline stations; below
deck on boats; fuel or chemical transfer or storage facilities; vehicles
using liquefied petroleum gas (such as propane or butane;) areas
where the air contains chemicals or particles, such as grain, dust, or
metal powders; and any other area where you would normally be
advised to turn off your vehicle engine.
127
Saf et y Guidelines
FDA Consumer Update
The FDA has been receiving inquiries about the safety of mobile
phones, including cellular phones and PCS phones. The following
summarizes what is known—and what remains unknown—about
whether these products can pose a hazard to health, and what can be
done to minimize any potential risk. This information may be used to
respond to questions.
Why the concern?
Mobile phones emit low levels of radiofrequency energy (i.e.,
radiofrequency radiation) in the microwave range while being used.
They also emit very low levels of radiofrequency energy (RF),
considered non-significant, when in the standby mode. It is well
known that high levels of RF can produce biological damage through
heating effects (this is how your microwave oven is able to cook
food). However, it is not known whether, to what extent, or through
what mechanism, lower levels of RF might cause adverse health
effects as well. Although some research has been done to address
these questions, no clear picture of the biological effects of this type
of radiation has emerged to date. Thus, the available science does
not allow us to conclude that mobile phones are absolutely safe, or
that they are unsafe. However, the available scientific evidence does
not demonstrate any adverse health effects associated with the use
of mobile phones.
What kinds of phones are in question?
Questions have been raised about hand-held mobile phones,
especially the kind that have a built-in antenna that is positioned close
to the user’s head during normal telephone conversation. These types
of mobile phones are of concern because of the short distance
between the phone’s antenna—the primary source of the RF—and
the person’s head. The exposure to RF from mobile phones in which
the antenna is located at greater distances from the user (on the
outside of a car, for example) is drastically lower than that from hand-
held phones, because a person’s RF exposure decreases rapidly with
distance from the source. The safety of so-called cordless phones,
which have a base unit connected to the telephone wiring in a house
and which operate at far lower power levels and frequencies, has not
been questioned.
128
How much evidence is there that hand-held mobile phones might be
harmful?
Briefly, there is not enough evidence to know for sure, either way;
however, research efforts are on-going.
The existing scientific evidence is conflicting and many of the studies
that have been done to date have suffered from flaws in their
research methods. Animal experiments investigating the effects of RF
exposures characteristic of mobile phones have yielded conflicting
results. A few animal studies, however, have suggested that low
levels of RF could accelerate the development of cancer in laboratory
animals. In one study, mice genetically altered to be predisposed to
developing one type of cancer developed more than twice as many
such cancers when they were exposed to RF energy compared to
controls. There is much uncertainty among scientists about whether
results obtained from animal studies apply to the use of mobile
phones. First, it is uncertain how to apply the results obtained in rats
and mice to humans. Second, many of the studies that showed
increased tumor development used animals that had already been
treated with cancer-causing chemicals, and other studies exposed the
animals to the RF virtually continuously—up to 22 hours per day.
For the past five years in the United States, the mobile phone
industry has supported research into the safety of mobile phones.
This research has resulted in two findings in particular that merit
additional study:
In a hospital-based, case-control study, researchers looked for an
association between mobile phone use and either glioma (a type of
brain cancer) or acoustic neuroma (a benign tumor of the nerve
sheath). No statistically significant association was found between
mobile phone use and acoustic neuroma. There was also no
association between mobile phone use and gliomas when all types
of types of gliomas were considered together. It should be noted that
the average length of mobile phone exposure in this study was less
than three years.
129
Saf et y Guidelines
When 20 types of glioma were considered separately, however, an
association was found between mobile phone use and one rare type
of glioma, neuroepithelliomatous tumors. It is possible with multiple
comparisons of the same sample that this association occurred by
chance. Moreover, the risk did not increase with how often the
mobile phone was used, or the length of the calls. In fact, the risk
actually decreased with cumulative hours of mobile phone use. Most
cancer causing agents increase risk with increased exposure. An on-
going study of brain cancers by the National Cancer Institute is
expected to bear on the accuracy and repeatability of these results.
1. Researchers conducted a large battery of laboratory tests to
assess the effects of exposure to mobile phone RF on genetic
material. These included tests for several kinds of abnormalities,
including mutations, chromosomal aberrations, DNA strand breaks,
and structural changes in the genetic material of blood cells called
lymphocytes. None of the tests showed any effect of the RF except
for the micronucleus assay, which detects structural effects on the
genetic material. The cells in this assay showed changes after
exposure to simulated cell phone radiation, but only after 24 hours of
exposure. It is possible that exposing the test cells to radiation for this
long resulted in heating. Since this assay is known to be sensitive to
heating, heat alone could have caused the abnormalities to occur.
The data already in the literature on the response of the micronucleus
assay to RF are conflicting. Thus, follow-up research is necessary.
2. FDA is currently working with government, industry, and academic
groups to ensure the proper follow-up to these industry-funded
research findings. Collaboration with the Cellular Telecommunications
Industry Association (CTIA) in particular is expected to lead to FDA
providing research recommendations and scientific oversight of new
CTIA-funded research based on such recommendations.
130
Two other studies of interest have been reported recently in the
literature:
Two groups of 18 people were exposed to simulated mobile phone
signals under laboratory conditions while they performed cognitive
function tests. There were no changes in the subjects’ ability to recall
words, numbers, or pictures, or in their spatial memory, but they were
able to make choices more quickly in one visual test when they were
exposed to simulated mobile phone signals. This was the only change
noted among more than 20 variables compared.
3. In a study of 209 brain tumor cases and 425 matched controls,
there was no increased risk of brain tumors associated with mobile
phone use. When tumors did exist in certain locations, however, they
were more likely to be on the side of the head where the mobile
phone was used. Because this occurred in only a small number of
cases, the increased likelihood was too small to be statistically
significant.
4. In summary, we do not have enough information at this point to
assure the public that there are, or are not, any low incident health
problems associated with use of mobile phones. FDA continues to
work with all parties, including other federal agencies and industry, to
assure that research is undertaken to provide the necessary answers
to the outstanding questions about the safety of mobile phones.
What is known about cases of human cancer that have been reported
in users of hand-held mobile phones?
Some people who have used mobile phones have been diagnosed
with brain cancer. But it is important to understand that this type of
cancer also occurs among people who have not used mobile phones.
In fact, brain cancer occurs in the U.S. population at a rate of about 6
new cases per 100,000 people each year. At that rate, assuming 80
million users of mobile phones (a number increasing at a rate of about
1 million per month), about 4800 cases of brain cancer would be
expected each year among those 80 million people, whether or not
they used their phones. Thus it is not possible to tell whether any
individual’s cancer arose because of the phone, or whether it would
have happened anyway. A key question is whether the risk of getting
a particular form of cancer is greater among people who use mobile
phones than among the rest of the population.
131
Saf et y Guidelines
One way to answer that question is to compare the usage of mobile
phones among people with brain cancer with the use of mobile phones
among appropriately matched people without brain cancer. This is
called a case-control study. The current case-control study of brain
cancers by the National Cancer Institute, as well as the follow-up
research to be sponsored by industry, will begin to generate this type
of information.
What is FDA’s role concerning the safety of mobile phones?
Under the law, FDA does not review the safety of radiation-emitting
consumer products such as mobile phones before marketing, as it
does with new drugs or medical devices. However, the agency has
authority to take action if mobile phones are shown to emit radiation at
a level that is hazardous to the user. In such a case, FDA could require
the manufacturers of mobile phones to notify users of the health
hazard and to repair, replace, or recall the phones so that the hazard
no longer exists.
Although the existing scientific data do not justify FDA regulatory
actions at this time, FDA has urged the mobile phone industry to take a
number of steps to assure public safety. The agency has
recommended that the industry support needed research into possible
biological effects of RF of the type emitted by mobile phones, design
mobile phones in a way that minimizes any RF exposure to the user
that is not necessary for device function, and cooperate in providing
mobile phone users with the best possible information on what is
known about possible effects of mobile phone use on human health.
At the same time, FDA belongs to an interagency working group of
the federal agencies that have responsibility for different aspects of
mobile phone safety to ensure a coordinated effort at the federal
level. These agencies are:
National Institute for Occupational Safety and Health
Environmental Protection Agency
Federal Communications Commission
Occupational Health and Safety Administration
National Telecommunications and Information Administration
The National Institutes of Health also participates in this group.
In the absence of conclusive information about any possible risk,
what can concerned individuals do?
132
If there is a risk from these products—and at this point we do not
know that there is—it is probably very small. But if people are
concerned about avoiding even potential risks, there are simple steps
they can take to do so. For example, time is a key factor in how much
exposure a person receives. Those persons who spend long periods
of time on their hand-held mobile phones could consider holding
lengthy conversations on conventional phones and reserving the
hand-held models for shorter conversations or for situations when
other types of phones are not available.
People who must conduct extended conversations in their cars every
day could switch to a type of mobile phone that places more distance
between their bodies and the source of the RF, since the exposure
level drops off dramatically with distance. For example, they could
switch to a mobile phone in which the antenna is located outside the
vehicle, a hand-held phone with a built-in antenna connected to a
different antenna mounted on the outside of the car or built into a
separate package, or a headset with a remote antenna to a mobile
phone carried at the waist.
Again, the scientific data do not demonstrate that mobile phones are
harmful. But if people are concerned about the radiofrequency energy
from these products, taking the simple precautions outlined above can
reduce any possible risk.
Where can I find additional information?
For additional information, see the following websites:
Federal Communications Commission (FCC) RF Safety Program
(select Information on Human Exposure to RF Fields from Cellular
and PCS Radio Transmitters): http://www.fcc.gov/oet/rfsafety
World Health Organization (WHO) International Commission on Non-
Ionizing Radiation Protection (select Q’s & A’s):http://www.who.int/emf
United Kingdom, National Radiological Protection Board:
http://www.nrpb.org.uk
Cellular Telecommunications Industry Association (CTIA) : http://
www.wow-com.com
U.S. Food and Drug Administration (FAD) Center for Devices and
Radiological Health : http://www.fda.gov/cdrh/consumer/
Licensed by QUALCOMM Incorporated under one or more of the following Patents;
U.S. Patent No. 4,901,307 U.S. Patent No. 5,056,109 U.S. Patent No. 5,099,204
U.S. Patent No. 5,101,501 U.S. Patent No. 5,103,459 U.S. Patent No. 5,107,225
U.S. Patent No. 5,109,390
Product manufactured or sold in U.S.; “This product is covered by U.S. Pat.
5,818,437, U.S. Pat. 5,953,541, U.S. Pat. 6,011,554 and other patents pending.”
