Lippert # 2021123784 / FACT11CA-PS
Lippert # 2022007394 / FACT11CA-PS-OEM
Furrion Standard Air Distribution Box with
Manual Control
TM
Cool, Calm and Collected
Designed for RV campers and travel trailers with a roof thickness
of 3-6” and roof opening of 14”, the Furrion air distribution box,
(ADB) with manual control is compatible with the Furrion Chill air
conditioning system.
Easy Installation
Three fan speeds Detachable filter
Features
• Temperature control
• Compatible with ducted and non-ducted systems
• Use with a rooftop AC system
• Compatible with optional heat strip
• For 3-6” roof thickness and 14” roof opening
• Two-way airflow
Furrion Standard Air Distribution Box with Manual Control (FACT11CA-PS)
17¼"
(438mm)
1½"
(39mm)
7½" (191mm)
17¼" (438mm)
3⅜" (87mm)
⅝" (15mm)
Ver. 3.0
Furrion® and the Furrion logo are trademarks licensed for use by Furrion Ltd. and registered in the U.S. and other countries. © 2007-2022 Furrion Ltd.
Customer Service & Technical Support: Email: [email protected] Tel : (888) 354 5792 www.furrion.com
Specifications
Mechanical Control
Fast Cool
Indoor Sound Pressure Level
Operating Temperature Range
Voltage
Frequency for AC
Compatible with
8 positions
√
60dB
0°F to 122°F / -17°C to 50°C
AC 115V
60Hz (AC)
Rooftop AC Unit
Heat Strip
* Note: “√”=Equipped
Dimensions and Weight
Product Dimension (WxHxD)
Packaging Dimension (LxWxH)
Net Weight (lbs/kg)
Gross Weight (lbs/kg)
17¼ x 4⅜ x 17¼"
(438 x 112 x 438mm)
18¼ x 5⅜ x 18"
(463 x 138 x 458mm)
5.3lbs/2.4kg
6.6lbs/3.0kg
