ONYX BOOX Note 4 quick start guide 2 MB, PDF

This is the main product document for model NOTE 4.

The file format is pdf, 20 pages, you can download this manual here .

background
E‑bookreader
ONYXBOOX
Quickstartguide
NOTE4
background
background
2
Thank you for choosing our product. We would like to
remindyouthatthedevice requirescarefulhandlingin
accordancewithoperatingrules.
Newsoftwareversionsmaychangethedevice'sfunctions
andtheirnumber.In thesecases,the information,con‑
tained in this manual, may become outdated. New
versionsofusermanualswillbeavailableontheweb‑page
http://onyxboox.com/
background
3
Completeset:
ONYXBOOXdevice;
Covercase;
USBcable;
Quickstartguide;
Warrantycard.
Thepurposeandfunctionalityofthedevice
Themainpurposeofthedeviceisoperatingandstoring
differenttypesoftextandgraphicfiles.Also,connectionto
the Internet is possible. Video files, however, cannot be
playedback.
background
4
1.VIEWANDCONTROL
1.1.Front
POWERbutton
Powerbutton
Pressandholdforabout2‑3seconds,ifthee‑readerisoff,this
turns it on. A longer press for 15‑20 seconds reboots the
device. A short press turns the device into a standby
(sleeping)mode.
background
5
1.2.Bottom
USB‑Cjack
Microphone
USB‑Cjack
ConnectsthedevicetoacomputerusingtheenclosedUSB
cabletosharedataortochargethee‑reader.
Microphone
Recordsaudionotes.
Speakers
Playsounds.
Speaker Speaker
background
6
2.GETTINGSTARTED
2.1.Howtoturnonthedevice?
a)PressandholdthePowerbuttonforabout3seconds.
Thedevicewillstartloading.
b)Releasethepowerbutton.
c)Waitforthedevicetoload.
2.2.Howtochargethebatteryofthedevice?
PlugtheUSBcableintothejackofthedeviceandconnectit
toaUSBportonaPC.
FullchargetimedependsonthevoltageofthePC.
2.3.HowtoconnectthedevicetoaPC?
a)TurnontheBOOX.
b)ConnecttheBOOXtoaUSBportofaPCusingtheUSB
cable.
c)Afterthedeviceisdetected,anactionsselectionmenu
willappearonthecomputerscreen.
d)Choose“Openthedevicetoviewfiles”.
e)Nowyouhaveaccesstofilesintheinternalmemory.
background
7
NOTE1.Thedeviceshouldnotbeoperatedwhen
connectedtothePC.
NOTE2.Beforeturningoffthedevice,disconnectitfrom
thePC.
NOTE3.RecommendedversionsofWindowsare7and
higher.
NOTE4.MacOSrequirestheAndroidFileTransfer
application.
2.4.Howtoturnoffthedevice?
a)PressandholdthePowerbuttonforabout2seconds.
b)Themenuwith“Poweroff”and“Restart”willappear.
Choose“Poweroff”.
background
8
3.MAINPAGE
Themainpageallowstheusertogetquickaccesstoe‑
books, files, installed applications and settings. The
descriptionofvirtualbuttonsandindicatorsisgivenbelow.
8
9
10
1
2
3
5
6 7
4
1. Time / 2. Lighting indicator / 3. Screen mode switcher / 4
Bluetoothconnectionindicator/5.Networkconnectionindicator/
6.Chargeindicator/7.Batterycharge/8.Booknumberindicator/
9.Appearance/10.Informationtype
background
3.1.TheLibrary
The library displays e‑book‑format files in sorted view.
Groupingandsearchbyauthors,genre,seriesarepossible
only forformats containingthis information(fb2, epub,
mobi,pdf).Forotherfiles,thefilenameisshownasthe
titleand thedocumenttype isshownas theseries and
author(txt,docetc.).
Thankstothisfeatureyoudon'thavetospendtimesorting
booksintofoldersandrenamingfiles.
3.2.The“Nowreading”section
Thissectionappearswhenabookisopenedforthefirst
time. It contains the cover of the last book that was
opened.Additionalinformationcanbefoundontheright:
Thenumberofapagebeingreadandthetotalnumberof
pagesinthebook;
Readingprogressscale;
Dateandtimeofthelastopening;
Booktitle(iftherearenotitlesinmetadata,thefilename
isdisplayed);
Name of the author or authors (if this information is
containedinmetadata).
Atthetoprightthereisanindicatorofthebookcurrently
beingreadaswellasthethreepreviousbooks.
Toaccessapreviouslyreadbook,swipefromtherightto
theleftonthe“Nowreading”field.Theindicatorwillshow
whichofthefourrecentlyreadbooksisdisplayedatthe
moment.
9
background
4.WORKWITHBOOKSANDFILES
4.1.Gettingstartedwiththelibrary
The first time you open the library, you must scan the
internal memory. This will help the system extract
metadata,addbookstothecatalogueandsortthem.To
launchthisprocedure,presstheSCANLIBRARYbutton.
Eachtimeyourecordordeletebooksfromthememoryof
thedeviceitisnecessarytolaunchthescanmanuallyto
refreshthelibrary.
4.2.Sortingandfiltering
Inthe library,booksaregroupedbyauthors,series and
titles (for each group the number of items in it is dis‑
played).Withinthesegroupstheitemsaresortedalpha‑
betically(intheseriesbooksaresortedbytheirnumbersin
theseries),forauthorsandseriesthenumberofbooksis
indicated. The items beginning with digits or without a
namearelocatedattheendofthelist.
Onthemainpageofthelibraryitispossibletosetthefilter
bylanguage,genre,text,dateofthebook’spublicationand
dateoffilecreation.
Aftersettingthefilterinthegroups“Authors”,“Series”,
“Titles” books will be displayed by their corresponding
filterparameters.
10
background
The“Text”filterallowstheusertosortbooksbyapartof
thetitle,thenameoftheauthororbyapartoftheseries
name.Forthisfilteringitisnecessarytoenteratleasttwo
letters.Iftheenteredtextiscontainedinthenameofthe
element(titleofabookorofseries,nameoftheauthor),
this element and all the elements related to it will be
selected.Forexample,ifthesearchedtextiscontainedin
thenameoftheseries,thissameserieswillbeshownin
the“Series”groupafterfiltering,inthe“Authors”group–
authors from this series, in the “Titles” group – all the
books from this series, even though the names of the
authorsandthebooktitlesdonotcontaintheenteredtext.
The“Clearall”optionclearsallthefilterparameters.If
youwanttoclearonlyoneofthefilters,gotothecorre‑
spondingfilterandchoose“Clear”orerasethetextinthe
“Text”filter.
4.3.Workingwithlistsandbooks
A short tap on a list opens it and shows its content.To
returntoaleveluponthelist,touchthearrowintheupper
partofthelist.
Ashorttaponabookopensthepagewiththedescription
ofthebook.Hereyoucanreadthedetailsofthebook:title,
author,genreandannotations.Butthesedetailsappear
only if they are contained in the file metadata.
Unfortunately, not all the e‑book files contain them or
containthementirely.Inthiscasethecorrespondingfields
willbeempty.
11
background
12
Alongtaponabookcallsthefollowingmenu:
Read‑chooseareadingapp;
Properties–thebookinformation;
Delete–deletingthebookfromthedevice.Ifthebookis
inthearchive,allofthearchivewithallthefilesinitwillbe
deleted.
Togotothemainpageofthelibrarypressthe“Arrowtothe
left”iconinthetoptray.
4.4.Thelibraryviewsetup
You can change the view of the library by touching the
‘’eye”iconandchoosingoneoftwovariants
Onecolumn
Twocolumns
4.5.Choosingthetypeofdisplayedinformation
Touchingthe“Informationtypes”icon(threedots)callsthe
followingmenu:
OpenFile–Thefilemanager(storage)displayingfolders.
Favorites–Auser’slistoffavoritebooks.
RecentFiles–Thelistofrecentlyopenedbooks.
Sort–Orderingbooks.Thisoptionisonlyavailableinthe
filemanager.
background
13
4.6.Thefilemanager
Tolaunchthefilemanagerofthelibrary,pressthe“Infor‑
mationtype”icon(threedots)andchoose“Openfile”.In
thefilemanageronlythosefilesaredisplayedwhichcan
beopenedwithoneofthereadingprograms.
NOTE: A folder containing thousands of files may not
displaytheentirelistoffilesbutonlyitsbeginning.
Intheupperlinethecurrentpathisshown.The“Arrow’
iconontherightservestogoalevelupinthecatalogue.
Attention! The Library, the file manager, Favorites and
Recentfiles aresingle‑leveltypesofdisplayinginforma‑
tion.MultiplepressesoftheArrowiconinthefilemanager
willleadtotherootdirectoryofthefilesystem.Togoto
thelibrary,usethe“Informationtypes”icon(threedots)
andthenchoosethe“Library”option.
Filesandfolderscanbesorted(Menu–ort)byname,by
dateandbysize.
Ashorttaponafileopensit.
Alongtaponafilecallsupthefollowingmenu:
Read‑chooseareadingapp;
Properties–thebookinformation;
Delete–deletingthebookfilefromthedevice. Ifthe
bookisinthearchive,theentirearchivewithallthefilesin
itwillbedeleted.
background
14
4.7.RecentFiles
To go to the list of recently opened books, touch the
“Informationtypes”icon(threedots)onthemainpageof
thelibraryandchoose“Recentfiles”.
Thesizeofthislistislimitedto256books.
Theviewandtheactionsherearesimilartothoseinthefile
managerexceptdisplayingfolders.
Togotothelibrary,tothefilemanagerorto“Favorites”use
the“Informationtypes”icon(threedots).
4.8.Favorites
Togotothelistoffavoritebooks,touchthe“Information
types” icon (three dots) on the home page and choose
“Favorites”.
Theviewandtheactionsherearesimilartothoseinthefile
managerexceptdisplayingfolders.
To add a book to the Favorites, you need to open the
“Properties”windowsthenpressthe“Star”iconinthetop
right.Thestarwillbecomedark.
Todeletethebookfromthefavoritelistpressbrieflythe
bookicon–the“Properties”windowwillopen.Pressthe
“Star”iconinthetopright.Thestarwillbecomelight.You
canalsocompletelyclearthelistoffavoritesbypressing
the “Information types” icon (three dots) and choosing
“Remove all”. The files themselves in this case are not
deletedandremaininstorage.
Files”listusethe“Informationtypes”icon(threedots).
background
Attention!Whenretrievingthecontextmenubypressing
the book pictogram for several seconds, the option
“Delete”willbecomeavailable.Choosingthisactionwill
deletethebooknotonlyfromthe“Favorites”listbutfrom
storageaswell.
TogototheLibrary,tothefilemanagerortothe“Recent
Files”listusethe“Informationtypes”icon(threedots).
5.GENERALPRINCIPLESOFTHEWORK
WITHREADINGPROGRAMS
Thereadingprogramspre‑installedinthee‑readerserve
forreadingthefollowingfilesTXT,HTML,RTF,FB2,FB2.zip,
DOC,MOBI,CHM,EPUB,PDF,DJVUandothers.
Toturnpagessimplytouchthesensorscreen.
Thereadingprogramallowsyoutoaddbookmarks.Inthe
AlReaderXapp bring upthe menuand then choosethe
option“AddBookmark”.IntheNeoReaderprogramitis
enoughtogotoadesiredpageandbrieflypresstheupper
rightcornerofthescreen.Itwillchange.Clickingtheicon
againwilldeletethebookmarkandtheiconwillreturnto
itsoriginalstate.Themenuinbothprogramswillallowyou
toseepreviouslyaddedbookmarksandtogotoacorre‑
spondingpage.
Youcanopensettingswithashorttouchtothecenterof
thescreen
15
background
16
6.WORKINGWITHPROGRAMS
Android is an open‑source operating system specially
developed for mobile devices. The Android OS is con‑
stantly being improved because it occupies one of the
leadingpositionsontheworldmarket.
OntheInternettherearemanydevelopersocietieswho
createprogramsandapplicationsfortheAndroidoperat‑
ingsystem.MostofthemarewrittenintheJavaprogram‑
minglanguage.Installationfilesfortheseappsarefilesin
.apkformat.
ONYXBOOXNOTE4runsontheAndroidOSversion11.
6.1.Installingapps
Besidesastandardpackageofbasicapplicationsandthe
pre‑installedsoftware,youcaninstalladditionalsoftware
ifyouwish.
Toinstallappsbyyourselfitisnecessary:
a) To write an installation file (in .apk format) into the
internalmemoryofthedevice;
b) To find this file in the File manager or in a different
similarprogram;
c)Openthefileandconfirmtheinstallation.
6.2.Deletingapps
Todeleteaninstalledapp,dothefollowing:
a)Gotothemainpage;
b)Choose“Settings”;
c)Openthe“Application”section;
d)Then“Manageapps”;
e)Findandchoosetheappinthelist;
f)Press“delete”andconfirmthedeletion.
background
NOTE1:Theappsincluded in theoperatingsystemare
impossibletoremove.
NOTE2:Beforeinstallingathird‑partyapp,makesurethat
itisdesignedforthisversionofAndroidandadaptedfor
deviceswithEInkscreens.
17
7.WARNINGSANDSAFETYCONDITIONS
7.1.Anewbatteryachievesitsmaximumcapacityafter2‑
3cyclesofrecharging.
7.2.Toavoidimportantdataloss,westronglyrecommend
you to save them periodically on alternative data
storages.Itisespeciallyimportanttosavedatabefore
updatingthedevice.Ourcompanydoesnotbearany
responsibilityforyourdatapreservation.
7.3.Please,donotdismantlethedeviceonyourown.
7.4. Avoid twisting and bending the device and other
deformationsofthecasing.
7.5.Avoidhittingthedeviceagainsthardsurfaces.
7.6. Avoid placing excessive pressure on the screen or
hittingit.
7.7.Donotallowwatertogetintoorontoyourdevice.Do
notuseitclosetoopenwatersources.
7.8.AvoidusingtheBOOXinthefollowingconditions:
Lowtemperature;
Hightemperature;
Intensemagneticfield;
Highhumidity;
Highdustcontent;
Directsunlight.
background
18
NOTE:Therangeoftemperatureandhumidityisindicated
intheProductspecificationsofthismanual.
7.9. Do not use concentrated detergents. To clean the
device,useadrycottoncloth.
7.10.Donotreplacepartsofthedevice.
7.11.Usebatteries,poweradaptorsandotheraccessories
recommendedbythemanufacturer.Usingthird‑party
accessoriesmaybedangerousandcaninvalidatethe
warranty.
7.12.Whenrecyclingoutdatedproducts,followtherules
andlawsoftheterritoryofusage.
7.13.Ifanyproblemsoccurwiththedevice,getintouch
withanearestservicecenter.Informationabouthow
to contact service centers can be found on the
warrantycard.
7.14.Themanufacturerreservestherighttomakechanges
tothedevicewithoutnotifyingtheconsumers.
background
9.PRODUCTSPECIFICATIONS
Display
Frontlight
MOONLight2
Processor
8‑core,2GHz
RAM
ROM
64GB
Wirelessintarfaces
Wi‑FiIEEE802.11ac
Bluetooth5.0
Wiredinterface
USBType‑С
Operatingsystem
Android11
Supportedfileformats
Battery
3700mAh
Recommendedpower
adaptor
ACinput:100–240V,50/60GHz
DСoutput:5V–3A
Size
Weight
Operatingtemperature/
acceptablehumidity
0°С‑50°С/0%‑90%
Durability
2years
Warrantyperiod
1year
СЕ/ЕАС
Detailedinformationisavailableonthewebpage
http://onyxboox.com/
EInkMobiusCarta,10.3"touchcapacitive,resolution
1404x1872,16shadesofgrey,withtheSNOWField
function
4GB
249х176.5х5.5mm
385gr
Note:Sincepartoftheflashmemoryvolumeisoccupiedbythesystem
software,theportionavailabletotheuser,islessthanthetotalsize
ofthememorychip.
Standardsconformity
TXT,HTML,RTF,FB2,FB2.zip,FB3,DOC,DOCX,PRC,
MOBI,CHM,PDB,EPUB,JPG,PNG,GIF,BMP,PDF,DjVu,
CBR,CBZ,MP3,WAV
Audio
Speakers,Microphone
Sensors
Hallsensor,fingerprintrecognitionsensor

Specifications

ONYX BOOX NOTE 4 Questions and Answers

Find answers or ask new question.
See other models: MIRA LIVINGSTONE 2 KON-TIKI 3 GALILEO FAUST 5
Questions and Answers
