Installation Instr uction
ITEM
DESCRIPTION/PART NO.
QUANTITY
ITEM
DESCRIPTION/PART NO.
QUANTITY
7
8
9
HOME button
unaccessible.
HOME button
accessible.
M
A
anti-theft box
1
B
1
pole
C
base
1
D 4
rubber pad
E
1
decorative cover
F
ST6.3x55
2
G
concrete anchor
2
key
H
2
M5x6
4I
M8x20
4
J
4mm Allen key
1
K
5mm Allen key
1
L
button
1
M
1
D
K
PSPADLKPRO6
40mm
(1.6")
60mm
(2.4")
ø 10mm
(ø 3/8")
3b-1
ø 4.5 mm
(ø 3/16")
40mm
(1.6")
55mm
(2.2")
F
F
G
3b-2
Put the mount directly
on the countertop.
B
E
C
J
L
6
5
3a
2
For iPad Pro
4
I
For the wooden
counter top installation
X
For the concrete or solid brick
installation
