afet¥ Preca
[]
I
iMPORTANT SAFETY iNSTRUCTiONS FOR THE OPERATION OF YOUR CLOTHES WASHER
tI, WAI-i|_i|I_II_: TO REDUCE THE
RISK OF FIRE, EXPLOSION,
ELECTRIC SHOCK, OR PERSONAL
INJURY WHEN USING YOUR
WASHER, FOLLOW BASIC SAFETY
PRECAUTIONS INCLUDING THE
FOLLOWING:
1. READ ALL INSTRUCTIONS
CAREFULLY BEFORE USING THE
WASHER. RETAIN ALL INSTRUCTIONS
FOR FUTURE REFERENCE.
2. PROPERLY INSTALL AND LOCATE in
accordance with the Installation
Instructions.
MUST BE PROPERLY GROUNDED- See
installation instructions.
SHOULD ANYONE get an ELECTRIC
SHOCK from the washer, disconnect
electrical power. DO NOT OPERATE
until it has been repaired by a qualified
service technician.
INSTALL OR STORE where it will NOT
be exposed to temperatures below
freezing or exposed to the weather.
CONNECT to a properly rated,
protected, and sized power supply
circuit. See Electrical Requirements.
CONNECT to adequate plumbing and
drain facilities.
HAVE A QUALIFIED SERVICE
TECHNICIAN install your washer.
3. TO PREVENT INJURY TO CHILDREN:
DO NOT ALLOW children to play
inside, on, or with the washer.
CLOSE SUPERVISION of children is
necessary when using washer.
WHEN CHILDREN are mature enough,
instruct them in the safe, correct use of
the washer.
KEEP ALL LAUNDRY AIDS out of the
reach of children, preferably in a locked
cabinet. USE laundry aids only as
directed by manufacturer, observing all
warnings on container labels.
DESTROY THE CARTON AND PLASTIC
BAGS after unpacking the washer.
Cartons covered with rugs, bedspreads,
or plastic sheet can create a chamber
with inadequate ventilation.
REMOVE THE DOOR to the washing
compartment before the washer is
removed from service or discarded.
4. DO NOT REACH INTO the washer if the
tub or agitator is moving. The washer is
equipped with a safety switch for your
protection. If action does not stop when
the washer lid is opened during the Spin
Cycle, disconnect the electrical power to
the washer. Do not operate the washer
until it has been repaired by a qualified
service technician.
5. DO NOT TAMPER with the Operating
Controls.
6. TO PREVENT PERSONAL INJURY and
damage to the washer, DO NOT repair
or replace any part of the washer or
attempt any servicing. SERVICING
should be referred to a qualified service
technician.
7. DO NOT WASH FIBERGLASS
ARTICLES unless recommended by
manufacturer.
10. DO NOT ADD gasoline, dry-
cleaning solvents, or other flammable
or explosive substances to the wash
water. These substances give off
vapors that could ignite or explode.
11. DO NOT WASH ARTICLES which
have been previously cleaned,
washed, soaked, or spotted with
gasoline, dry-cleaning solvents, oil,
waxes, chemical solvents, alcohol,
turpentine, or other flammable or
explosive materials. These substances
will be retained in articles, and articles
which still contain these flammable or
explosive substances give off vapors
that could ignite or explode.
12. OBSERVE THESE PRECAUTIONS
WHEN USING CLEANING FLUIDS,
SPOT OR STAIN REMOVERS, ETC.
Products should be labeled
"NONFLAMMABLE". Use according to
MANUFACTURER'S DIRECTIONS in a
well VENTILATED AREA or outdoors.
Thoroughly RINSE ARTICLES by hand
before placing them in the washer.
Some of these products - rust
removers, for example - will damage
components and the finish of the
washer.
FIRE HAZARD
13. KEEP AREA around and under-
neath washer free from the accumu-
lation of combustible materials, such
as lint, paper, rags, gasoline, and all
other flammable vapors and liquids.
14. HYDROGEN GAS IS EXPLOSIVE
and under certain conditions,
hydrogen gas may be produced in a
hot water system that has not been
used for two weeks or more. If the hot
water system has not been used for
such a period, BEFORE USING THE
WASHER, turn on all hot water faucets
and let the water flow from each
faucet for several minutes. This will
release any accumulated hydrogen
gas. As this gas is flammable, DO NOT
SMOKE or use an open flame during
this procedure.
15. Recent studies have shown that if
vegetable oil contaminated materials
are incompletely washed, a carry-over
and buildup of the oil may contribute
to a chemical reaction (spontaneous
combustion) that could cause a load
to catch fire by itself. This would be
more likely to happen if the load was
left in the dryer after tumbling
stopped or if items were folded and
stacked while warm.
8. FLAME RETARDANT FINISHES -
improper laundering could remove
them. FOLLOW garment manufacturer's
instructions carefully.
9. WHEN MOVING, have the washer
checked and properly installed by a
qualified service technician.
SAVE THESE INSTRUCTIONS
PRINTED IN U.S.A.
Part No. 35-5971
Washer Operating Instructions
10.1 Iogram Washer MODELNUMBER
Models: 220-240 Volt/50 Hertz
AAV1200AGW/AAV1200ARW
I it-J
IIWARNING: To reduce the risk of
fire, explosion, electric shock, or
personal injury, read the IMPORTANT
SAFETY INSTRUCTIONS before
operating your washer.
READ THESE OPERATING
INSTRUCTIONS CAREFULLY BEFORE
YOU USE THE WASHER AND RETAIN
FOR FUTURE REFERENCE.
Before operating your washer, be sure
that all installation requirements are
met. SEE INSTALLATION
INSTRUCTIONS.
TO OPERATE:
Water fill hoses should be attached and
faucets fully opened. Be sure washer
drain hose is in drain.
1. LOAD BLEACH DISPENSER, if
desired (maximum one cup).
& CAUTION: Never pour chlorine
bleach directly onto clothes.
2. MEASURE DETERGENT, place in
washer basket.
3, LOAD CLOTHES loosely in washer.
Maximum load is to top of agitator
vanes.
4. SELECT WATER LEVEL. Determine
the selected setting based on clothes
load size (see tableL Selection should
provide sufficient water to permit
clothes to circulate during agitation.
It may become necessary, due to
bulky fabrics, to adjust the water
level after agitation begins. To adjust
for a higher water level, turn control
to RESET position and then back to
desired setting. To decrease rinse
water level, turn the control to a
lower setting after wash agitation
has started.
WATER LEVEL SETTING LOAD SIZE
SUPER 3/4 - Full
MEDIUM 1/2 - 3/4 Full
SMALL 1/4- 1/2 Full
REMEMBER: Items must circulate freely for best results,
SELECT CYCLE. To set Cycle Timer,
push the Timer Knob IN (off position)
and turn it to the right (clockwise)
until the pointer is at the
recommended starting point in the
"wash" segment in either the
COTTONS, WRINKLE-FREE
CLOTHES OR THE DELICATES
CYCLE. See washing guide for
recommended cycles. CLOSE LID.
COTTONS CYCLE:
Provides normal agitation and
normal spin speeds for regular wash
cycles to wash cottons and heavily
soiled items.
12-14 Min. Hot Wash Cold Rinse
4-10Min. Warm Wash Cold Rinse
WRINKLE-FREE CLOTHES CYCLE:
Provides normal agitation speed for
first six minutes, a pause, then slow
agitation for remainder of wash
cycle to protect permanent press
fabrics. Spin speed will be normal
to reduce water retention.
8-10 Min. Warm Wash Cold Rinse
2-6 Min. Cold Wash Cold Rinse
6.
7.
DELICATES CYCLE:
Provides slow agitation speed and
slow spin speed for delicates and
double knit fabrics.
8-10Min. Warm Wash Cold Rinse
2-6 Min. Cold Wash Cold Rinse
PULL TIMER KNOB OUT TO START.
You may stop the washer at any time
by simply pushing the Timer Knob
IN. Therefore, it is possible to obtain a
non-agitated soak for as long as you
wish, or to shorten, skip or repeat
any part of a cycle. The Timer Knob
must be pushed IN (off position)
when you change the setting.
NOTE: Do not attempt to turn the
Timer Knob counterclockwise since
damage to the timer will result.
LAUNDRY AIDS:
FABRIC SOFTENERS. Add in the
amount recommended by the
manufacturer. Most should be added
at the start of "Rinse" when the tub
is filling with water. DO NOT POUR
DIRECTLY ONTO CLOTHES.
