1
Operation Guide 5449/5523
MA1610-EA
© 2014 CASIO COMPUTER CO., LTD.
x Be sure to keep all user documentation handy for future reference.
x Your watch may differ somewhat from the one shown in the illustration.
To change the day setting
Note
x The day setting uses a
31-day month. Make
adjustments for months of
shorter lengths.
x Avoid changing the day
setting between the hours
of 9 p.m. and 1 a.m.
Otherwise, the day setting
may not change correctly at
midnight.
Pull the Crown out to Click 1.
Rotate the Crown towards you to set the
day.
Push the Crown back in.
To adjust the day of the week and time
When the second hand is at 12o’clock, pull
the
Crown out to Click 2.
Rotate the Crown to advance the hour and
minute hand settings, which will also change
as the day of the week setting.
Note
x Take care that you set the
correct AM or PM time.
x When changing the time,
move the minute hand four
or five minutes past your
final setting, and then back
it up to the setting you want.
Rotate the Crown to change the time setting.
Push the Crown back in on a time signal to
resume timekeeping.
Crown Operations
Crown
Loosen
Some water-resistant models (100 meters, 200 meters)
have a screw-in crown. When you need to perform a crown
operation, rotate it towards you to unscrew it. Then pull the
crown out. Avoid applying undue force when pulling. The watch
loses its water resistance while the crown is unscrewed. After
performing a crown operation, fully screw the crown back in.
If your watch has a rotary bezel...
Start
Elapsed time
Current
You can rotate the bezel to align its
▼
mark with the
minute hand. Then you will be able to tell how much
time has elapsed since aligning the
▼
mark.
Specifications
Module No.
Accuracy at normal
temperature (per month)
Battery type Battery life
5449 ±20 seconds SR920SW Approx. 3 years
5523 ±20 seconds SR927SW Approx. 3 years
Specifications are subject to change without notice.
Module 5449
Click 1
Day
Day of the week
Click 2
Crown
Module 5523
Click 1
Day
Day of the week
Click 2
Crown
