AIR CONDITIONER
Read this owner’s manual thoroughly before operating the appliance
and keep it handy for reference at all times.
OWNER’S MANUAL
TYPE : PORTABLE AIR CONDITIONER (INVERTER)
LP1419IVSM
LP1022FVSM
TABLE OF CONTENTS
SAFETY INSTRUCTIONS ..............................................................3
IMPORTANT SAFETY INSTRUCTIONS ..........................................................4
PRODUCT OVERVIEW ..................................................................8
Key Parts and Components ..............................................................................8
INSTALLATION ...............................................................................9
Electrical Data ...................................................................................................9
Before Installation the Air Conditioner ............................................................. 10
Wireless Remote Control ................................................................................10
PREPARING FOR INSTALLATION .................................................................11
SELECTION OF INSTALLATION LOCATION .................................................11
WINDOW VENT PANEL AND EXTENSIONS .................................................12
INSTALLATION (VERTICAL) ..........................................................................13
INSTALLATION (HORIZONTAL) ..................................................................... 15
OPERATION .................................................................................17
Control Panel and Remote Control .................................................................17
Removing Condensation Buildup .................................................................... 18
SMART FUNCTIONS ....................................................................19
LG ThinQ Application ......................................................................................19
Smart Diagnosis .............................................................................................. 20
MAINTENANCE ............................................................................ 22
Emptying the Water Collection Tank ...............................................................22
Cleaning the Case...........................................................................................22
Cleaning the Air Filter ...................................................................................... 22
TROUBLESHOOTING .................................................................. 23
Before Calling for Service ...............................................................................23
Normal Sounds You May Hear ........................................................................ 23
WARRANTY ..................................................................................27
3
EN
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on
your appliance. Always read and follow all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or injure you
and others.
All safety messages will follow the safety alert symbol and either the
word WARNING or CAUTION.
These words mean:
WARNING
You may be killed or seriously injured if you do not follow instructions.
CAUTION
You may be injured or cause damage to the product if you do not follow
instructions.
All safety messages will tell you what the potential hazard is, tell you
how to reduce the chance of injury, and tell you what may happen if the
instructions are not followed.
The following symbols are displayed on units.
This symbol indicates that this appliance uses a flammable
refrigerant. If the refrigerant is leaked and exposure to an
external ignition source, there is a risk of fire.
This symbol indicates that the Operation Manual should be read
carefully.
This symbol indicates that a service personnel should be
handling this equipment with reference to the Installation Manual.
This symbol indicates that information is available such as the
Operating Manual or Installation Manual.
4
EN
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of explosion, fire, death, electric shock, scalding or
injury to persons when using this product, follow basic precautions,
including the following:
INSTALLATION
• Before use, the appliance must be properly installed as described in this manual.
• Contact the authorized service technician for repair or maintenance of this unit.
• Contact the installer for installation of this unit.
• The air conditioner is not intended for use by young children or invalids without supervision.
• Young children should be supervised to ensure that they do not play with the air conditioner.
• Installation work must be performed in accordance with the National Electric Code by qualified and
authorized personnel only.
• Connect to a properly rated, protected, and sized power circuit to avoid electrical overload.
• Always plug into a grounded outlet.
• Do not under any circumstances, cut or remove the third (ground) prong from the power cord.
• When installing or moving the appliance, be careful not to pinch, crush, or damage the power cord.
• Plug in the power plug properly.
• Do not modify or extend the power cord.
• Do not start/stop operation by plugging/unplugging the power cord.
• If the cord/plug is damaged, have it replaced by an authorized service person using authorized
replacement parts.
• Use a dedicated circuit.
• Do not disassemble or modify the product.
• Adhere to all industry recommended safety procedures including the use of long-sleeved gloves
and safety glasses.
• Disconnect the power cord or circuit breaker before installing or servicing the appliance.
• Keep packaging materials out of the reach of children. These materials can pose a suffocation risk
to children.
• Store and install the product where it will not be exposed to temperatures below freezing or
exposed to outdoor weather conditions.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
• Do not install the unit in potentially explosive atmospheres.
5
EN
OPERATION
• Use this appliance only for its intended purpose.
• Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or
has missing or broken parts, including a damaged cord or plug.
• Repair or immediately replace all power cords that have become frayed or otherwise damaged. Do
not use a cord that shows cracks or abrasion damage along its length or at either end.
• Do not run cord under carpets or mats where it could be stepped on and damaged.
• Keep the cord out from under heavy objects like tables or chairs.
• Do not place the power cord near a heat source.
• Do not use an adaptor or plug the product into a shared outlet.
• Do not tamper with controls.
• If you detect a strange sound, a chemical or burning smell, or smoke coming from the appliance,
unplug it immediately, and contact the LG Electronics Customer Information Center.
• Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull
straight out from the outlet.
• Do not grasp the power cord or touch the appliance controls with wet hands.
• If water enters the product, turn off the power at the main circuit, then unplug the product and call for service.
• If the product has been submerged, contact the LG Electronics Customer Information Center for
instructions before resuming use.
• Unplug the product when unused for long periods.
• Unplug the product before cleaning.
• In the event of a gas leak (propane gas, etc.) do not operate this or any other appliance. Open a
window or door to ventilate the area immediately.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning the use of the appliance by a person responsible for their safety.
• To clean the interior, contact the LG Electronics Customer Information Center or dealer. Using
harsh detergents may cause corrosion or damage to the unit.
• Do not use solvent-based detergent on the product. Doing so can cause corrosion or damage,
product failure, electrical shock, or fire.
GROUNDING INSTRUCTIONS
• The power cord of this appliance is equipped with a three-prong (grounding) plug. Use this with
a standard three-slot (grounding) wall power outlet to minimize the hazard of electric shock. The
customer should have the wall receptacle and circuit checked by a qualified electrician to make
sure the receptacle is properly grounded. DO NOT CUT OR REMOVE THE THIRD (GROUND)
PRONG FROM THE POWER PLUG.
− Situations when the appliance will be disconnected occasionally; Because of potential safety
hazards, we strongly discourage the use of an adapter plug. However, if you wish to use an
adapter, a TEMPORARY CONNECTION may be made. Use UL-listed adapter, available from
most local hardware stores. The large slot in the adapter must be aligned with the large slot in
the receptacle to assure a proper polarity connection.
• Attaching the adapter ground terminal to the wall receptacle cover screw does not ground the
appliance unless the cover screw is metal, and not insulated, and the wall receptacle is grounded
through the house wiring. The customer should have the circuit checked by a qualified electrician
to make sure the receptacle is properly grounded.
• Disconnect the power cord from the adapter, using one hand on each. Otherwise, the adapter
ground terminal might break. Do not use the appliance with a broken adapter plug.
− Situations when the appliance will be disconnected often; Do not use an adapter plug in these
situations. Unplugging the power cord frequently can lead to an eventual breakage of the ground
terminal. The wall power outlet should be replaced by a three-slot (grounding) outlet instead.
6
EN
CAUTION
To reduce the risk of minor or moderate injury to persons,
malfunction, or damage to the product or property when using this
product, follow basic precautions, including the following:
INSTALLATION
• Take care when installing the product that exhaust or condensation does not damage nearby
property.
• Follow installation instructions exactly to avoid excessive vibration or water leakage.
• Wear gloves and use caution when unpacking and installing the appliance. Screws or sharp edges
can cause injuries.
OPERATION
• This appliance is not intended for use as a precision refrigeration system. Do not use it for special
purposes such as maintaining pets, food, precision machinery, or art objects.
• When installing or moving the appliance, be careful not to pinch, crush, or damage the power cord.
• Make sure the air inlet and outlet are free from obstructions.
• Use a soft cloth to clean the appliance. Do not use waxes, thinners, or harsh detergents.
• Do not step on or place heavy objects on top of the appliance.
• Do not operate the appliance without the filter securely installed.
• Do not drink water drained from the appliance.
• Be sure to ventilate sufficiently when the air conditioner and a heating appliance such as a heater
are used simultaneously.
• Being exposed to direct airflow for an extended period of time could be hazardous to your health.
• Remove the batteries if the remote control is not to be used for an extended period of time.
• Never mix different types of batteries, or old and new batteries for the remote control.
• Stop using the remote control if there is a fluid leak in the battery. If your clothes or skin are
exposed to the leaking battery fluid, wash off with clean water.
• If the leaking battery fluid has been swallowed, rinse the inside of the mouth thoroughly and
consult a doctor.
• Do not recharge or disassemble the batteries.
MAINTENANCE
• Clean the filter every two weeks.
• Never touch the metal parts of the air conditioner when removing the air filter.
• Never use strong cleaning agents or solvents when cleaning the air conditioner or spray water.
Use a smooth cloth.
7
EN
REFRIGERANT (FOR R32 ONLY)
WARNING
• Do not use means to accelerate the defrosting process or to clean, other than those recommended
by the manufacturer.
• The appliance shall be stored in a room without continuously operating ignition sources (for
example: open flames an operating gas appliance or an operating electric heater).
• Do not pierce or burn. Be aware that flammable refrigerants may not contain an odor.
CAUTION
• This unit contains flammable refrigerant and has special safety precautions not normally
associated with older units. Please follow all precautions and advisories.
− Use caution while handling and prevent damage to unit. Do not put any holes into product for
any reason. This can cause damage to product and prevent unit from cooling.
− Maintenance and cleaning of unit should be performed by trained personnel. Failure to properly
clean unit can result in damage to the refrigeration system and or the electrical system.
− Make certain that all the air circulation/ventilation openings are free from obstruction.
− Service should only be performed by technicians properly trained and certified in the use of
flammble refrigerants. Any service performed by unauthorized servicers/individuals will void all
warranties.
− When storing the appliance, do not put in a room with any open flame appliance, such as gas
water heaters or furnaces. Also keep away from electric heaters. Damaged units should be
repaired before storage.
SAVE THESE INSTRUCTIONS
8
EN
PRODUCT OVERVIEW
Key Parts and Components
1
AIR DISCHARGE
The adjustable louvered air discharge opens
automatically when the air conditioner is turned on,
and closes when it is turned off. It can also be set
to oscillate to distribute air more evenly through the
room.
7
8
6
1
4
5
3
2
2
CONTROL PANEL AND DISPLAY
Easy-to-read digital display shows the set
temperature, and indicator lights show the operating
mode. Simple push buttons make changing settings
quick and easy.
3
SWIVELING CASTERS
Swiveling casters allow you to move the air
conditioner easily on most floor surfaces.
4
INTEGRATED HANDLES
Integrated handles provide a convenient grip when
lifting the air conditioner.
5
REMOTE CONTROLLER
The remote controller allows you to adjust the
temperature and operate most functions of the air
conditioner from across the room.
6
BOTTOM DRAIN PORT
Before moving the air conditioner, drain the internal
water in the collection tank completely using the
bottom drain port.
7
AIR FILTER
8
HOSE AND DIFFUSER
Use the diffuser and hose to connect the air
conditioner to the window installation kit to vent
exhaust air outside.
9
EN
INSTALLATION
Electrical Data
Power cord may include a current interrupter
device. TEST and RESET buttons are provided
on the plug case. The device should be tested on
a periodic basis by frist pressing the TEST button
and then the RESET button. If the TEST button
does not trip or if the RESET button will not stay
engaged, discontinue use of the air conditioner
and contact a qualified service technician.
for 120 V
Use Wall Receptacle Power Supply
Standard 120 V, 3-wire
grounding receptacle rated
15 A / 120 VAC / 60 Hz
Use 15 A, time
delay fuse or 15 A,
circuit breaker.
WARNING
• This appliance should be installed in
accordance with the National Electrical Code.
• Use of extension cords could cause serious
injury or death.
− Do not use an extension cord with this
portable air conditioner.
− Do not use surge protectors or multi-outlet
adapters with this portable air conditioner.
• Never push the TEST button during operation.
Doing so can damage the plug.
− Do not remove, modify, or immerse this
plug. If this device trips, the cause should be
corrected before further use.
CAUTION
• The conductors inside this cord are surrounded
by shields, which monitor leakage current.
These shields are not grounded. Periodically
examine the cord for any damage. Do not
use this product in the event the shields
become exposed. Avoid shock hazard. This
unit cannot be user-serviced. Do not open the
tamperresistant sealed portion. All warranties
and performance will be voided. This unit is not
intended to be used as an ON/OFF switch.
10
EN
Before Installation the Air
Conditioner
PREPARING FOR OPERATION
Refer to the Installation Instructions included in this
manual before using the air conditioner. Once the
air conditioner has been properly assembled and
installed:
1
Plug the power cord into its own dedicated
properly grounded outlet. Do not plug other
appliances into the same outlet. Doing so
could overload the outlet and create a fire
hazard.
2
Make sure the air conditioner and cord are
positioned where they do not create a tripping
hazard and will receive adequate ventilation.
Do not place the appliance near furniture or
objects that could block the vent openings.
3
Make sure that any items that could be blown
over or damaged by the airflow from the fan
are out of the airflow path.
IMPORTANT:
• Do not remain in the direct airflow from the air
conditioner for extended periods of time.
• When used at the same time as stoves,
fireplaces, and other combustion devices,
make sure there is a sufficient flow of fresh air
into the room. Do not use in tightly enclosed
spaces with these types of devices.
• This air conditioner is intended for household
use as a consumer comfort appliance. Do not
use it as a precision climate control system,
or for purposes such as cooling precision
equipment, food, pets, plants, artwork, etc.
Such items could be damaged.
• Do not bend the hose downward when window
installation kit is not applied. It may cause
failure of air conditioner or performance
deterioration.
UNPACKING THE AIR CONDITIONER
Remove and store packing materials for reuse.
Remove any shipping tape before using the
air conditioner. If the tape leaves behind any
adhesive, rub a small amount of liquid dish soap
onto it and wipe with a damp cloth. Do NOT use
sharp instruments, alcohol, thinners, or abrasive
cleaners to remove adhesive. They could damage
the finish.
Wireless Remote Control
Inserting Batteries
If the display screen of the remote control begins
to fade, replace the batteries. Insert AAA (1.5 V)
batteries before using the remote control.
1
Remove the cover on the back of the remote
control.
2
With the plus and minus poles facing as
marked, insert two new AAA 1.5V batteries.
NOTE
• Two new batteries are supplied with the air
conditioner for use in the remote control.
• Do not use a rechargeable battery. Make sure
that the battery is new.
• In order to prevent discharge, remove the
battery from the remote control if the air
conditioner is not going to be used for an
extended period of time.
• Keep the remote control away from extremely
hot or humid places.
• To maintain optimal operation of the remote
control, the remote sensor should not be
exposed to direct sunlight.
11
EN
PREPARING FOR INSTALLATION
Basic Installation Materials Supplied
Shape Parts Name Shape Parts Name
Hose
Mounting plate
insulation (2 pcs)
Base mounting plate
(23”, 1 pcs)
Window gap
insulation (1 pcs)
Extension mounting
plate (16”, 1 pcs)
Fixing clips
(2 pcs)
Extension mounting
plate (23”, 1 pcs)
Security brackets
(2 pcs)
Mounting plate screws
(4 pcs)
Bracket screws
(2 pcs)
Adhesive short foam
weather seals (2 pcs)
Installation Tools
Shape Parts Name Shape Parts Name
⊕ Driver
Power drill,
Ø 3mm drill blade
Tape ruler, knife
“No residue”
duct tape
* Installation tools are not included with the product.
SELECTION OF INSTALLATION LOCATION
1
Place the unit on a level floor.
2
For best performance, allow at least 8” of
air space on all sides of the unit for good air
circulation.
3
Place the unit near a window. The hose
and diffuser will be used to connect the air
conditioner to the window installation kit to
vent exhaust air outside.
NOTE
• After installation, the Hose length is
approximately 35.5” or less for best
performance.
8
8
8
12
EN
WINDOW VENT PANEL AND EXTENSIONS
The window installation kit allows you to install the air conditioner in most vertical-sliding windows 23” to 60”
wide, or horizontal-sliding windows from 23” to 60” high.
Panel
Window open
A B C Fig.
(23") (16") (23")
23" a
24"~38" b
39"~45" c
46"~60" d
1
For window openings shorter than 23”, trim
panel A to fit the opening.
2
For longer window openings, assemble and
adjust the panels to fit the window opening.
Use Mounting plate screws (included) to fix the
panels together at the proper length.
Mounting plate
screws
Mounting plate
screws
Panel A (23”) Panel B(16”) Panel C (23”)
2 Extension Panels
1 Window Vent Panel
Window Installation Kit (Includes 1 Window
Vent Panel and 2 Extension Panels)
23”
23”
For an 23” window opening, use the window vent
panel (Panel A) by itself.
24” – 38”
24” – 38”
For window openings from 24” to 38”, use the
window vent panel (Panel A) and an extension
panel (Panel B).
Fig. a Fig. b
39” – 45”
39” – 45”
For window openings from 39” to 45”, use the
window vent panel (Panel A) and an extension
panel (Panel C)..
46” – 60”
46” – 60”
Panel B
Panel B
Panel C
Panel C
For window openings from 46” to 60”, use the
window vent panel (Panel A) and two extension
panels (Panel B and Panel C).
Fig. c Fig. d
13
EN
INSTALLATION (VERTICAL)
1 Inserting Panel Assembly
1
Fit the chassis fixing clips at both ends of
the mounting plate.
2
After adjusting the length of the mounting
plate to the chassis height, insert the clip
into the window sill.
<Small Windows><Small Windows>
• Refer to the <Positioning Vent Hose>
to adjust the hose outlet position.
3
Secure the mounting plate screws in
the mounting holes on both sides of the
mounting plate.
• If the screw fixing holes do not match,
use a power drill to drill the holes (3
mm) in the outer mounting plate in
accordance with the inner screw holes.
2 Connecting Vent Hose
1
Insert the hose into the groove in the
insertion direction.
Inserting directionInserting direction
2
Push the hose in the assembling direction
to assemble with the mounting plate.
Assembling Assembling
directiondirection
14
EN
3 Attaching Foam Weather Seals
1
Cut the mounting plate insulation to the
chassis length and insert it on both sides of
the mounting plate.
2
Move the mounting plate to the end of the
chassis, close the window and secure it
with the security bracket.
CAUTION
• Be sure to install the window fixing
bracket to prevent the window from
opening outside.
3
Cut the window gap insulation to the
window length and insert it into the window
gap.
4 Positioning Vent Hose
For best results, keep the vent hose as short and straight as possible. However, shape the diffuser end
of the vent hose into an inverted U shape just inside the window to allow any rain or condensation to
drain out the window.
8”
8”
15.7”
MinimumMinimum
<Best positioning> <inverted U shape> <Correct Installation Position>
15
EN
INSTALLATION (HORIZONTAL)
1 Attaching Foam Weather Seals
Cut the mounting plate insulation to the chassis length and insert it on both
sides of the mounting plate.
(Attaching the foam weather seals to the panel assembly rather than the
window sash and frame makes for easier cleanup when removing the panel
assembly.)
NOTE
• Take care not to block drain holes in the exterior sill. If necessary, cut slots
in the foam seal to allow any moisture to drain out the window sill drains.
Adhesive short foam
weather seals
Adhesive short foam
weather seals
Mounting plate insulation
Indoor
Interlor
Mounting
plate insulation
Mounting
plate insulation
Indoor
Interlor
2 Inserting Panel Assembly
Insert the panel assembly in the bottom sash channel as in step 2. Use care when installing the
assembly, which will now fit very tightly in the opening.
Close the sash tightly against the top of the panel assembly. For a tighter seal, use “no residue” duct
tape (not included) to seal any gaps around the installed panel assembly.
• If needed, install the included security bracket with a bracket screws.
Bracket screws
Security
brackets
Base mounting
plate
Extension
panel
3 Sealing Gap between Sashes
Measure and cut the included window gap insulation to fit the window opening. Stuff it between the
window sashes to prevent air and insects from getting into the room.
Tip: For a tighter seal, use “no residue” duct tape to seal the gap between the sashes.
16
EN
4 Connecting Vent Hose
Align the tabs on the diffuser end of the vent hose to the slots in the panel assembly opening. Insert the
diffuser and push it in the Lock direction to assemble with the mounting plate.
• If disconnected, reconnect the other end of the vent hose to the product by inserting the vent hose
into the product with the mounting ring facing out. If the hose doesn’t snap into place, rotate it
slightly so the 2 lines at the front align.
Mounting ring
(2) UnLock
lock
(1) Insert
Window gap insulation
5 Positioning Vent Hose
For best results, keep the vent hose as short and straight as possible. However, shape the diffuser end
of the vent hose into an inverted U shape just inside the window to allow any rain or condensation to
drain out the window.
8”
8”
15.7”
MinimumMinimum
<Best positioning> <inverted U shape> <Correct Installation Position>
17
EN
OPERATION
Control Panel and Remote Control
1 2 3 9
4 5
7 6
8
Remote Control
1
2
6
10
3
4
7
5
Auto
Swing
NOTE
• The feature may be changed according to the type of model.
1
Power (t)
Press to turn the air conditioner ON or
OFF.
3
Sleep Mode
This mode keeps operating noise to a minimum
and turns the air conditioner off after a set time.
The timer can be set from 1 to 12 hours. In this
mode, the control panel turns off.
• In the Sleep Mode, the setting temperature
increases by 2 °F after 30 minutes and
additional 2 °F after another 30 minutes for
a more comfortable sleep.
• The setting temperature increases up to
4 °F from the preset temperature.
NOTE
• Press Sleep button of remote controller for
5 seconds, the temperature display can be
switched between degrees Fahrenheit (°F)
and dregrees Celsius (°C).
2
Operation Mode
Press the Mode button to cycle between
3 types of air conditioner operation: Cool /
Fan / Dry.
Cool - This mode is ideal on hot days to
cool and dehumidify the room quickly. Use
the Temp buttons to set the desired
room temperature and use the Fan Speed
button to set the desired fan circulation
speed.
Fan - In this mode the fan circulates air but
the compressor does not run. Use the Fan
Speed button to set fan speed to High,
Medium or Low. In this mode, you cannot
adjust the set temperature.
Dry -
This mode is ideal for rainy and
damp days to dehumidify the room rather
than cooling it significantly. Humidity is
removed from the room by the combination
of compressor operation and the fan speed
fixed at Low. The compressor and fan turn
off once the set temperature is reached.
Fan speed cannot be adjusted in Dry mode.
NOTE
• To set the brightness on the control
panel, press Mode button on the control
panel for 3 seconds.
Brightness : 100% → 50% → Off
3s 3s
4
Fan Speed
Press to set the Fan Speed to Low (F1),
Medium (F2) or High (F3).
5
Auto Swing
This function adjusts the direction of the air flow
vertically. Press Auto Swing button repeatedly
and select the desired direction.
18
EN
6
Delay ON/OFF Timer
Delay ON - When the air conditioner is off,
set it to automatically turn on from 1 to 24
hours later, at its previous mode and fan
settings.
Delay OFF - When the air conditioner is
on, set it to automatically turn off from 1 to
24 hours later.
NOTE
• Each press of the Timer button
advances the timer by 1 hour. After
the last press of the Delay OFF Timer
the display returns to the temperature
setting.
7
Temperature Control
To adjust the desired room temperature in Cool
or Dry mode. The desired room temperature
can be set between 60 °F–86 °F (16 °C–30 °C).
Press or arrows to increase or decrease
temperature setting.
NOTE
• Press and button together on
the control panel for 3 seconds, the
temperature display can be switched
between degrees Fahrenheit (ºF) and
degrees Celsius (ºC).
8
Wi-Fi
Enables connection of the air conditioner to
the home Wi-Fi.
To connect Wi-Fi, press the Fan Speed
button on the control panel for 3 seconds.
9
Clean Filter
The Clean Filter LED lights up to notify you
that the filter needs to be cleaned. After
cleaning the filter, press Sleep button on
the control panel for 3 seconds to turn off
the Clean Filter light.
NOTE
• The filter reset must be done using the
control panel, not the remote control.
• This feature is a reminder to clean the
air filter for more efficient operation.
The LED light turns on after 250 hours
of operation.
10
Clear
Cancel Sleep and Timer settings.
NOTE
• Press the Clear button on remote
controller for 5 seconds, the Smart
Diagnosis function works.
NOTE
• Auto Restart : In case of turning off the air
conditioner due to power failure, your unit will
resume its last operation several minutes after
power is restored.
Removing Condensation
Buildup
Condensation can build up inside the unit when
the Cool and Dry modes are used. The fan can
be set to run for a short period after the product is
turned off to help keep the inside of the appliance
dry. This option is off by default.
Turning Condensation Fan On
1
Turn on the product, set it to Cool mode and
let it run for at least 10 seconds.
2
Press and hold the Auto Swing button for 3
seconds until On appears in the display.
3
The condensation fan is now turned on. When
the appliance is turned off, Co appears in the
display and the fan will continue to run for 10
minutes. The appliance will then shut down as
normal.
Turning Condensation Fan Off
1
When the product is powered ON, press and
hold the Auto Swing button for 3 seconds
until OF appears in the display.
2
The condensation fan is now turned off. The
appliance will shut down immediately when it
is turned off.
NOTE
• Some functions cannot be used while this
option is turned on.
• This option must be set using the control panel,
not the remote control.
19
EN
SMART FUNCTIONS
LG ThinQ Application
This feature is only available on models with
the b or ThinQ logo
The LG ThinQ application allows you to
communicate with the appliance using a
smartphone.
LG ThinQ Application Features
Communicate with the appliance from a
smartphone using the convenient smart features.
Smart Diagnosis
If you experience a problem while using the
appliance,this smart diagnosis feature will help you
diagnose the problem.
Settings
Allows you to set various options on the appliance
and in the application.
NOTE
• If you change your wireless router, internet
service provider, or password, delete the
registered appliance from the LG ThinQ
application and register it again.
• The application is subject to change for
appliance improvement purposes without
notice to users.
• Functions may vary by model.
Before Using LG ThinQ
Application
1
Check the distance between the appliance
and the wireless router (Wi-Fi network).
• If the distance between the appliance and
the wireless router is too far, the signal
strength becomes weak. It may take a long
time to register or installation may fail.
2
Turn off the Mobile data or Cellular Data on
your smartphone.
3
Connect your smartphone to the wireless
router.
NOTE
• To verify the Wi-Fi connection, check that f
icon on the control panel is lit.
• The appliance supports 2.4 GHz Wi-Fi
networks only. To check your network
frequency, contact your Internet service
provider or refer to your wireless router manual.
• LG ThinQ is not responsible for any
network connection problems or any faults,
malfunctions, or errors caused by network
connection.
• If the appliance is having trouble connecting
to the Wi-Fi network, it may be too far from
the router. Purchase a Wi-Fi repeater (range
extender) to improve the Wi-Fi signal strength.
• The Wi-Fi connection may not connect or may
be interrupted because of the home network
environment.
• The network connection may not work properly
depending on the Internet service provider.
• The surrounding wireless environment can
make the wireless network service run slowly.
• The appliance cannot be registered due to
problems with the wireless signal transmission.
Unplug the appliance and wait about a minute
before trying again.
• If the firewall on your wireless router is enabled,
disable the firewall or add an exception to it.
• The wireless network name (SSID) should be
a combination of English letters and numbers.
(Do not use special characters.)
• Smartphone user interface (UI) may vary
depending on the mobile operating system
(OS) and the manufacturer.
• If the security protocol of the router is set
to WEP, you may fail to set up the network.
Please change it to other security protocols
(WPA2 is recommended) and register the
product again.
20
EN
Installing the LG ThinQ
Application
Search for the LG ThinQ application from the
Google Play Store or Apple App Store on a
smartphone. Follow instructions to download and
install the application.
Open Source Software Notice
Information
To obtain the source code under GPL, LGPL,
MPL, and other open source licenses that have
the obligations to disclose source code, that
is contained in this product, and to access all
referred license terms, copyright notices and
other relevant documents please visit https://
opensource.lge.com.
LG Electronics will also provide open source code
to you on CD-ROM for a charge covering the cost
of performing such distribution (such as the cost of
media, shipping, and handling) upon email request
This offer is valid to anyone in receipt of this
information for a period of three years after our last
shipment of this product.
Smart Diagnosis
This feature is only available on models with the
c or d logo.
Use this feature to help you diagnose and solve
problems with your appliance.
NOTE
• For reasons not attributable to LGE’s
negligence, the service may not operate due
to external factors such as, but not limited to,
Wi-Fi unavailability, Wi-Fi disconnection, local
app store policy, or app unavailability.
• The feature may be subject to change without
prior notice and may have a different form
depending on where you are located.
Using LG ThinQ to Diagnose
Issues
If you experience a problem with your Wi-Fi
equipped appliance, it can transmit troubleshooting
data to a smartphone using the LG ThinQ
application.
• Launch the LG ThinQ application and select
the Smart Diagnosis feature in the menu.
Follow the instructions provided in the
LG ThinQ application.
Using Audible Diagnosis to
Diagnose Issues
Follow the instructions below to use the audible
diagnosis method.
• Launch the LG ThinQ application and select
the Smart Diagnosis feature in the menu.
Follow the instructions for audible diagnosis
provided in the LG ThinQ application.
1
Plug the power plug in the outlet properly.
2
Place the mouthpiece of your smartphone
close to the c or d logo.
3
Press and hold the DIAGNOSIS [5 s] button
for 5 seconds or longer while holding the
smartphone mouthpiece to the logo until the
data transfer is complete.
• Keep the smartphone in place until the data
transfer has finished. Time remaining for
data transfer is displayed.
4
After the data transfer is complete, the
diagnosis will be displayed in the application.
NOTE
• For best results, do not move the smartphone
while the tones are being transmitted.
• Be sure to keep ambient noise to a minimum or
the phone may not correctly receive the buzzer
beeps from the indoor unit.
21
EN
FCC Notice
This following notice cover the transmitter module
contained in this product.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses,
and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and the receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
1) This device may not cause harmful
interference and
2) This device must accept any interference
received, including interference that may
cause undesired operation.
Any changes or modifications in construction of
this device which are not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC RF Radiation Exposure
Statement
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be
colocated or operating in conjunction with any
other antenna or transmitter.
This equipment should be installed and operated
with a minimum distance of 20 cm (7.8 inches)
etween the antenna and your body. Users must
follow the specific operating instructions for
satisfying RF exposure compliance.
Wireless LAN Module
Specifications
Frequency
Range
2412 MHz - 2462 MHz
Output
Power
(Max)
< 30 dBm
22
EN
MAINTENANCE
WARNING
• Before cleaning or performing maintenance,
disconnect the power supply and wait until the
fan stops.
Emptying the Water
Collection Tank
When the internal water collection tank is full, the
LED display will show FL and the air conditioner
will turn off until the tank is emptied.
• Unplug the air conditioner, disconnect the
exhaust hose from the back, and move the
air conditioner to a suitable drain location or
outdoors. You may also place a pan under the
drain that will hold up to 2 pints of water.
• Remove the drain cap from the drain outlet.
• Once the water collection tank is drained,
reinstall the drain cap, making sure it is on
securely.
• Place the air conditioner in the desired location,
reconnect the exhaust hose, and plug in the air
conditioner.
NOTE
• If you want to disconnect the hose from the
product, grasp the mounting bracket on the
hose, turn it clockwise or counterclockwise,
and then disconnect it easily.
Cleaning the Case
Wipe the case with a slightly damp cloth, then wipe
dry with a dry cloth or towel.
• To prevent damage to the finish, do not
use gasoline, benzene, thinner, etc., or any
abrasive cleansers to clean the air conditioner;
they may damage the finish.
• Never pour water onto or into the air conditioner.
It could damage internal components and
create a shock and fire hazard.
Cleaning the Air Filter
The air filters should be cleaned every two weeks;
depending on indoor air quality, more frequent
cleaning may be needed. A dirty air filter will
decrease airflow and reduce efficiency.
1
Pull out each air filter by the handle.
2
Use a vacuum cleaner to clean the filter. If the
filters are heavily soiled, they can be washed
in warm water using a mild detergent.
• Do not use harsh cleaners or very hot water.
• Do not wash in a dishwasher.
3
Dry the filter in the shade.
4
Reinsert the filters.
23
EN
TROUBLESHOOTING
Before Calling for Service
The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at
an early stage. If the appliance does not function properly or does not function at all, check the following
before you call for service.
Normal Sounds You May Hear
1
High Pitched Chatter
High efficient inverter compressor may occur high-pitched sound during operation.
2
Sound of Rushing Air
At the front of the unit, you may hear the sound of rushing air being moved by the fan.
3
Gurgle/Hiss
Gurgling or hissing noise may be heard due to refrigerant passing through evaporator during
normal operation.
4
Pinging or Swishing
Droplets of water hitting condenser during normal operation may cause pinging or swishing
sounds..
24
EN
Problem Possible Causes & Corrective Action
Air conditioner does
not start.
The air conditioner is unplugged.
• Make sure the air conditioner plug is pushed completely into the outlet.
The fuse is blown/circuit breaker is tripped.
• Check the house fuse/circuit breaker box and replace the fuse or reset the
breaker.
Power failure.
• If power failure occurs, turn the mode control to off. When power is restored,
wait 3 minutes to restart the air conditioner to prevent tripping of the
compressor overload.
The current interrupter device is tripped.
• Press the RESET button located on the power cord plug. If the RESET
button will not stay engaged, discontinue use of the air conditioner and
contact a qualified service technician.
FL appears in the display.
• The water collection tank is full. Drain the tank and reset your settings.
Air conditioner does
not cool as it should.
Airflow is restricted.
• Make sure there are no curtains, blinds, or furniture blocking the front of the
air conditioner.
The temp control may not be set correctly.
• Set the desired temperature to a level lower than the current temperature.
The air filter is dirty.
• Clean the filter at least every 2 weeks. See the ‘MAINTENANCE’ section.
The room may have been hot.
• When the air conditioner is first turned on, you need to allow time for the
room to cool down.
Cold air is escaping.
• Check for open fumace floor registers and cold air returns.
Cooling coils have iced up.
• See ‘Air conditioner freezing up’ below.
Air conditioner
freezing up.
The cooling coils are iced over.
• Ice may block the air flow and obstruct the air conditioner from properly
cooling the room. Set the mode control at High Fan or High Cool.
25
EN
Problem Possible Causes & Corrective Action
Water collects in
base pan.
Moisture removed from air and drains into base pan.
• This is normal for a short period in areas with little humidity; normal for a
longer period in very humid areas.
Air conditioner turns
on and off rapidly.
Dirty air filter - air restricted.
• Clean air filter.
Outside temperature extremely hot.
• Refer to installation instructions or check with installer.
Noise when unit is
cooling.
Air movement sound.
• This is normal. If too loud, set to lower FAN Setting.
Room too cold.
Set temperature too low.
• Increase set temperature.
Remote sensing
deactivating
prematurely.
Remote control not located within range.
• Place remote control within 20 feet & 120° radius of the front of the unit.
Remote control signal obstructed.
• Remove obstruction.
Can’t connect the LG
ThinQ App. to the air
conditioner.
Air conditioner is turned off.
• Turn the air conditioner on.
Wireless router is turned off.
• Turn the router on.
The air conditioner is
not connecting to the
Wi-Fi.
The Wi-Fi router is too far from the air conditioner.
• Move the router closer to the air conditioner or purchase and install a Wi-Fi
repeater (signal booster).
You do not have permission to use the router or it is incompatible.
• Make sure you are selecting the correct wireless router from the list. The
router must be set to 2.4 GHz.
26
EN
Problem Possible Causes & Corrective Action
Trouble connecting
appliance and
smartphone to Wi-Fi
network.
The password for the Wi-Fi network was entered incorrectly.
• Delete your home Wi-Fi network and begin the registration process again.
Mobile data for your smartphone is turned on.
• Turn off the Mobile data of your smartphone before registering the
appliance.
The wireless network name (SSID) is set incorrectly.
• The wireless network name (SSID) should be a combination of English
letters and numbers. (Do not use special characters.)
The router frequency is not 2.4 GHz.
• Only a 2.4 GHz router frequency is supported. Set the wireless router to
2.4 GHz and connect the appliance to the wireless router. To check the
router frequency, check with your Internet service provider or the router
manufacturer.
The appliance is too far from the router.
• If the appliance is too far from the router, the signal may be weak and the
connection may not be configured correctly. Move the router closer to the
appliance or purchase and install a Wi-Fi repeater.
NOTE
• If you see “CH” in the display, please call 1-800-243-0000.
27
EN
WARRANTY
WHAT THIS WARRANTY COVERS:
LG Electronics U.S.A., Inc. (“LG”) warrants your LG Portable Air Conditioner (“product”) against defect in
materials or workmanship under normal household use, during the warranty period set forth below, LG will,
at its option, repair or replace the product. This limited warranty is valid only to the original retail purchaser
of the product, is not assignable or transferrable to any subsequent purchaser or user, and applies only
when the product is purchased through an LG authorized dealer or distributor and used within the United
States (“U.S.”) including U.S. Territories.
NOTE
• Replacement products and repair parts may be new or factory-remanufactured and are warranted for
the remaining portion of the original unit’s warranty period or ninety (90) days, whichever is longer.
Please retain dated receipt or delivery ticket as evidence of the Date of Purchase for proof of warranty
(you may be required to submit a copy to LG or authorized representative).
WARRANTY PERIOD:
1 year from the Date of Purchase: Any internal/ functional Parts and Labor
HOW SERVICE IS HANDLED: In-Home Service
In-home service will be provided during the warranty period subject to availability within the United States.
In-home service may not be available in all areas. To receive in-home service, the product must be
unobstructed and accessible to service personnel. If during in-home service repair cannot be completed, it
may be necessary to remove, repair and return the product. If in-home service is unavailable, LG may elect,
at our option, to provide for transportation of our choice to and from a LG authorized service center.
THIS LIMITED WARRANTY DOES NOT COVER:
• Service trips to deliver, pick up, or install the product or for instruction on product use.
• Replacing house fuses or resetting of circuit breakers, correction of house wiring or plumbing, or
correction of product installation.
• Damage or failure caused by leaky / broken / frozen water pipes, restricted drain lines, inadequate or
interrupted water supply or inadequate supply of air.
• Damage or failure caused by accidents, pets and vermin, lightning, wind, floods or acts of God.
• Damage or failure resulting from misuse, abuse, improper installation, repair or maintenance. Improper
repair includes use of parts not approved or specified by LG.
• Damage or failure caused by unauthorized modification or alteration to the product.
• Damage or failure caused by incorrect electrical current, voltage, or plumbing codes.
• Cosmetic damage, including scratches, dents, chips or other damage to finish of the product, unless
such damage results from defects in materials or workmanship and is reported to LG within seven (7)
calendar days from the date of delivery.
• Damage or missing items to any display, open box, discounted, or refurbished product.
• Product where the original factory serial numbers have been removed, defaced or changed in any way.
• Repairs when product is used in other than normal and usual household use (e.g. rental, commercial
use, offices, or recreational facilities) or contrary to the instructions outlined in the owner’s manual.
• The removal and reinstallation of the Product if it is installed in an inaccessible location.
28
EN
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING
AND WITHOUT LIMITATION TO, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, THIS
WARRANTY IS LIMITED IN DURATION TO THE TERM PERIOD EXPRESSED ABOVE. REPAIR OR
REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY FOR THE
CUSTOMER. NEITHER THE MANUFACTURER NOR ITS U.S. DISTRIBUTOR SHALL BE LIABLE
FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY
NATURE, INCLUDING AND WITHOUT LIMITATION TO, LOST REVENUES OR PROFITS, OR ANY
OTHER DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on
how long an implied warranty lasts, so the above exclusion or limitation may not apply to you. This warranty
gives you specific legal rights and you may also have other rights that vary from state to state.
HOW TO OBTAIN WARRANTY SERVICE & ADDITIONAL INFORMATION:
Call 1-800-243-0000 or visit our website at www.lg.com.
Mail to: LG Customer Information Center (ATTN: CIC)
201 James Record Road, Huntsville, AL 35824
FOR YOUR RECORDS
Write the model and serial numbers here:
Model No.
Serial No.
• This information is located on a label on the side of the unit.
Dealer’s Name
Date Purchased
• Staple your receipt to this page in the event you need it to prove date of purchase or for warranty
issues.
29
EN
ARBITRATION NOTICE: THIS LIMITED WARRANTY CONTAINS AN ARBITRATION PROVISION
THAT REQUIRES YOU AND LG TO RESOLVE DISPUTES BY BINDING ARBITRATION INSTEAD OF
IN COURT, UNLESS YOU CHOOSE TO OPT OUT. IN ARBITRATION, CLASS ACTIONS AND JURY
TRIALS ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING
DISPUTES” BELOW.
PROCEDURE FOR RESOLVING DISPUTES:
ALL DISPUTES BETWEEN YOU AND LG ARISING OUT OF OR RELATING IN ANY WAY TO THIS
LIMITED WARRANTY OR THE PRODUCT SHALL BE RESOLVED EXCLUSIVELY THROUGH BINDING
ARBITRATION, AND NOT IN A COURT OF GENERAL JURISDICTION. BINDING ARBITRATION
MEANS THAT YOU AND LG ARE EACH WAIVING THE RIGHT TO A JURY TRIAL AND TO BRING OR
PARTICIPATE IN A CLASS ACTION.
Definitions.
For the purposes of this section, references to “LG” mean LG Electronics U.S.A., Inc., its
parents, subsidiaries and affiliates, and each of their officers, directors, employees, agents, beneficiaries,
predecessors in interest, successors, assigns and suppliers; references to “dispute” or “claim” shall
include any dispute, claim or controversy of any kind whatsoever (whether based in contract, tort, statute,
regulation, ordinance, fraud, misrepresentation or any other legal or equitable theory) arising out of or
relating in any way to the sale, condition or performance of the product or this Limited Warranty.
Notice of Dispute.
In the event you intend to commence an arbitration proceeding, you must first notify
LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG
Electronics, USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs,
NJ 07632.
You and LG agree to engage in good faith discussions in an attempt to amicably resolve your claim. The
notice must provide your name, address, and telephone number; identify the product that is the subject of
the claim; and describe the nature of the claim and the relief being sought. If you and LG are unable to
resolve the dispute within 30 days, either party may proceed to file a claim for arbitration.
Agreement to Binding Arbitration and Class Action Waiver.
Upon failure to resolve the dispute
during the 30 day period after sending written notice to LG, you and LG agree to resolve any claims
between us only by binding arbitration on an individual basis, unless you opt out as provided below. Any
dispute between you and LG shall not be combined or consolidated with a dispute involving any other
person’s or entity’s product or claim. More specifically, without limitation of the foregoing, any dispute
between you and LG shall not under any circumstances proceed as part of a class or representative
action. Instead of arbitration, either party may bring an individual action in small claims court, but that
small claims court action may not be brought on a class or representative basis.
Arbitration Rules and Procedures.
To begin arbitration of a claim, either you or LG must make a
written demand for arbitration. The arbitration will be administered by the American Arbitration Association
(“AAA”) and will be conducted before a single arbitrator under the AAA’s Consumer Arbitration Rules that
are in effect at the time the arbitration is initiated (referred to as the “AAA Rules”) and under the
procedures set forth in this section. The AAA Rules are available online at www.adr.org/consumer. Send a
copy of your written demand for arbitration, as well as a copy of this provision, to the AAA in the manner
described in the AAA Rules. You must also send a copy of your written demand to LG at LG Electronics,
USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632. If there is a
conflict between the AAA Rules and the rules set forth in this section, the rules set forth in this section will
govern. This arbitration provision is governed by the Federal Arbitration Act. Judgment may be entered on
the arbitrator’s award in any court of competent jurisdiction. All issues are for the arbitrator to decide,
except that issues relating to the scope and enforceability of the arbitration provision and to the
arbitrability of the dispute are for the court to decide. The arbitrator is bound by the terms of this provision.
Governing Law.
The law of the state of your residence shall govern this Limited Warranty and any
disputes between us except to the extent that such law is preempted by or inconsistent with applicable
federal law.
30
EN
Fees/Costs.
You do not need to pay any fee to begin an arbitration. Upon receipt of your written demand
for arbitration, LG will promptly pay all arbitration filing fees to the AAA unless you seek more than
$25,000 in damages, in which case the payment of these fees will be governed by the AAA Rules. Except
as otherwise provided for herein, LG will pay all AAA filing, administration and arbitrator fees for any
arbitration initiated in accordance with the AAA Rules and this arbitration provision. If you prevail in the
arbitration, LG will pay your attorneys’ fees and expenses as long as they are reasonable, by considering
factors including, but not limited to, the purchase amount and claim amount. Notwithstanding the
foregoing, if applicable law allows for an award of reasonable attorneys’ fees and expenses, an arbitrator
can award them to the same extent that a court would. If the arbitrator finds either the substance of your
claim or the relief sought in the demand is frivolous or brought for an improper purpose (as measured by
the standards set forth in Federal Rule of Civil Procedure 11(b)), then the payment of all arbitration fees
will be governed by the AAA Rules. In such a situation, you agree to reimburse LG for all monies
previously disbursed by it that are otherwise your obligation to pay under the AAA Rules. Except as
otherwise provided for, LG waives any rights it may have to seek attorneys’ fees and expenses from you if
LG prevails in the arbitration.
Hearings and Location.
If your claim is for $25,000 or less, you may choose to have the arbitration
conducted solely on the basis of (1) documents submitted to the arbitrator, (2) through a telephonic
hearing, or (3) by an in-person hearing as established by the AAA Rules. If your claim exceeds $25,000,
the right to a hearing will be determined by the AAA Rules. Any in-person arbitration hearings will be held
at a location within the federal judicial district in which you reside unless we both agree to another
location or we agree to a telephonic arbitration.
Opt Out.
You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can
require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no
later than 30 calendar days from the date of the first consumer purchaser’s purchase of the product by
either: (i) sending an e-mail to [email protected], with the subject line: “Arbitration Opt Out” or (ii) calling
1-800-980-2973. You must include in the opt out e-mail or provide by telephone: (a) your name and
address; (b) the date on which the product was purchased; (c) the product model name or model number;
and (d) the serial number (the serial number can be found (i) on the product; or (ii) online by accessing
https://www.lg.com/us/support/repair-service/schedule-repair-continued and clicking on “Find My Model &
Serial Number”).
You may only opt out of the dispute resolution procedure in the manner described above (that is, by
e-mail or telephone); no other form of notice will be effective to opt out of this dispute resolution
procedure. Opting out of this dispute resolution procedure will not affect the coverage of the Limited
Warranty in any way, and you will continue to enjoy the full benefits of the Limited Warranty. If you keep
this product and do not opt out, then you accept all terms and conditions of the arbitration provision
described above.
LG Electronics Inc.
111 Sylvan Avenue, Englewood Cliffs, NJ 07632.
LG Customer Information Center
1-800-243-0000
Register your product Online!
www.lg.com
