ASSEMBLY INSTRUCTIONS
Before assembling your Headboard, please read through these
ORLANDO HEADBOARD
Page 1 of 5
Orlando Headboard & Bed
Adult Assembly
Step 1
Attach the legs (2) and (3) to headboard panel (1),
using wooden dowels (A) and JCB (B).
Tighten with the Allen wrench (F).
1
2
3
A
B
B
A
Instructions apply for all bed sizes
TWIN > FULL > QUEEN > KING
PARTS LIST HARDWARE
Split Washer - 4 pcs
Flat Washer - 4 pcs
JCB M6 X 25mm (1”) - 4 pcs
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
JCB M6 X 35mm (1 3/8”) - 4 pcs
Spare - 1 pc
B
A
E
D
C
F
HEADBOARD PANEL
1 PC
1
2
3
1 PC
1 PC
LEFT LEG
RIGHT LEG
Allen Wrench - 1pc
Spare - 1pc
ATTENTION! If you receive a damaged or defective item,
please contact Atlantic Furniture at [email protected] 1-800-955-3726 / M-F 9:00-5:00 EST
Wooden Dowel - 4 pcs
Spare - 1 pc
NOTE: WE INCLUDE SPARE HARDWARE IN CASE THE ALLEN WRENCH, JCB, SPLIT, OR FLAT WASHER ARE DAMAGED DURING ASSEMBLY.
READY
ASSEMBLE
TO
Congratulations!
Your Orlando Headboard is now ready to assembe.
instructions carefully and familiarize yourself with the different parts.
To ensure lasting safety, we recommend that you periodically check
that all screws are tight and all parts are secure.
ASSEMBLY INSTRUCTIONS
Before assembling your Headboard, please read through these
ORLANDO BED
READY
ASSEMBLE
TO
Instructions apply for all bed sizes
TWIN > FULL > QUEEN > KING
BED SHOWN WITH OPEN FOOTRAIL
BED SHOWN WITH FLAT PANEL FOOTBOARD BED SHOWN WITH MATCHING FOOTBOARD
Adult Assembly
Page 2 of 5
instructions carefully and familiarize yourself with the different parts.
Orlando Headboard & Bed
01
01
01
02
03
04
05
PARTS LIST
HARDWARE
HARDWARE
HARDWARE
HEADBOARD
FOOTBOARD
LONG RAILS
SLAT KIT
BOX 1
BOX 2
BOX 3
BOX 4
01
04
04
04
05
02
02
03
04
BED SHOWN WITH OPEN FOOTRAIL
Attach the long rails (04) to the headboard (02) using the bed hook as shown below.
Step 1
Adult Assembly
Page 3 of 5
Use the upper set of pins when
using only mattress, use the lower
set of pins if using both box spring
and mattress.
Orlando Headboard & Bed
Step 2
Step 3
Attach the long rail assemblies (04) to the footboard (03) using bed hook as shown below.
04
04
03
Adult Assembly
BED SHOWN WITH OPEN FOOTRAIL
Congratulations!
Your Orlando bed is now ready for use.
Adult Assembly
Phillips head
screwdriver
Customer supplied
BED SHOWN WITH OPEN FOOTRAIL
PLATFORM BED - TALL HEIGHT
TRADITIONAL BED - LOW HEIGHT
Page 4 of 5
05
05
Lastly, lay slat kit (05) onto the bed. For slat kit assembly, follow the assembly instructions included
with slat kit.
To ensure lasting safety, we recommend that you periodically check
that all screws are tight and all parts are secure.
Orlando Headboard & Bed
ASSEMBLY INSTRUCTIONS
Before assembling your Bed, please read through these
ORLANDO HEADBOARD
Adult Assembly
PARTS LIST
01
02
HARDWARE
HEADBOARD
Congratulations!
JCB M6 X 1”
C
Allen Wrench M4
F
Flat Washer
Split Washer
D
E
02
01
C
C
E
E
D
D
Instructions apply for all bed sizes
Twin > Full > Queen > King
Page 5 of 5
attach to metal frame sold separately
Your Orlando Bed is now ready for use.
instructions carefully and familiarize yourself with the different parts.
Attach the headboard assembly (02) to the metal frame using JCB (C), flat washer (D),
and split washer (E) then tighten with Allen wrench, as shown below.
To ensure lasting safety, we recommend that you periodically check
that all screws are tight and all parts are secure.
Orlando Headboard & Bed
Step 1
