GE JGBS66REK6SS 30" Free-standing Gas Range User Manual

Write the model and serial

numbers here:

Model # _________________

Serial # _________________

You can find the rating label on the

front behind the range drawer.

ESPAÑOL

Para consultar una version en

español de este manual de

instrucciones, visite nuestro sitio de

internet GEAppliances.com.

OWNER’S MANUAL

RANGES

Single Oven Gas

49-2000316 Rev. 8 04-22 GEA

SAFETY INFORMATION .......... 3

USING THE RANGE

In Case of a Power Failure ............... 7

Surface Burners ........................ 7

Griddle ................................ 9

Oven Controls ..........................10

Special Features ........................11

Sabbath Mode - OU and CRC .............12

Sabbath Mode - Standard ................13

Cooking Modes .........................14

Oven Racks ............................15

Aluminum Foil and Oven Liners ...........15

Cookware ..............................15

Oven Air Vents .........................15

Cooking Guide .........................16

CARE AND CLEANING

Range – Exterior ........................17

Range – Interior ........................18

Cooktop ...............................19

Door and Drawer .......................21

Oven Light ............................ 22

Oven Door ............................ 23

TROUBLESHOOTING TIPS .......24

LIMITED WARRANTY ............ 26

ACCESSORIES .................... 27

CONSUMER SUPPORT ........... 28

GE is a trademark of the General Electric Company. Manufactured under trademark license.

RGBS400

JGBS60

JGBS61

JGBS66

JGSS61

JGSS66

JGB635

JGB645

2 49-2000316 Rev. 8

THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.

Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.

We take pride in the craftsmanship, innovation and design that goes into every GE Appliances

product, and we think you will too. Among other things, registration of your appliance ensures that we

can deliver important product information and warranty details when you need them.

Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration

card included in the packing material.

49-2000316 Rev. 8 3

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

SAFETY INFORMATION

ANTI-TIP DEVICE

To reduce the risk of tipping the range,

the range must be secured by a properly

installed anti-tip bracket. See installation

instructions shipped with the bracket for

complete details before attempting to

install.

For Free-Standing and Slide-In Ranges

To check if the bracket is installed and

engaged properly, look underneath the

range to see that the rear leveling leg is engaged in the bracket. On

some models, the storage drawer or kick panel can be removed for easy

inspection. If visual inspection is not possible, slide the range forward,

confirm the anti-tip bracket is securely attached to the floor or wall, and

slide the range back so the rear leveling leg is under the anti-tip bracket.

If the range is pulled from the wall for any reason, always repeat this

procedure to verify the range is properly secured by the anti-tip bracket.

Never completely remove the leveling legs or the range will not be secured

to the anti-tip device properly.

WARNING

If the information in this manual is not followed exactly, a fire or

explosion may result, causing property damage, personal injury or death.

- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of

this or any other appliance.

- WHAT TO DO IF YOU SMELL GAS

 ■ Donottrytolightanyappliance.

 ■ Donottouchanyelectricalswitch;donotuseanyphoneinyourbuilding.

 ■ Immediatelycallyourgassupplierfromaneighbor’sphone.Followthegas

supplier’sinstructions.

 ■ Ifyoucannotreachyourgassupplier,callthefiredepartment.

- Installation and service must be performed by a qualified installer, service agency or

the gas supplier.

WARNING

Read all safety instructions before using the product. Failure to follow these instructions may result

in fire, electrical shock, serious injury or death.

Anti-Tip

Bracket

Leveling Leg

Free-Standing and Slide-In Ranges

• A child or adult can tip the range and be killed.

• Install the anti-tip bracket to the wall or floor.

• Engage the range to the anti-tip bracket by sliding the

range back such that the foot is engaged.

• Re-engage the anti-tip bracket if the range is moved.

• Failure to do so can result in death or serious burns

to children or adults.

Tip-Over Hazard

WARNING

4 49-2000316 Rev. 8

SAFETY INFORMATION

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

WARNING

GENERAL SAFETY INSTRUCTIONS

WARNING

NEVER use this appliance

as a space heater to heat or warm the room.

Doing so may result in carbon monoxide

poisoning and overheating of the oven.

■ Usethisapplianceforitsintendedpurposeas

described in this owner’s manual.

■ Haveyourrangeinstalledandproperlygroundedby

a qualified installer in accordance with the provided

installation instructions.

■ Anyadjustmentandserviceshouldbeperformed

only by a qualified gas range installer or service

technician. Do not attempt to repair or replace

any part of your range unless it is specifically

recommended in this manual.

■ Yourrangeisshippedfromthefactorysetforuse

with natural gas. It can be converted for use with

propane gas. If required, these adjustments must be

made by a qualified technician in accordance with

the installation instructions and local codes. The

agency performing this work assumes responsibility

for the conversion.

■ Havetheinstallershowyouthelocationofthe

range gas shut-off valve and how to turn it off if

necessary.

■ Plugyourrangeintoa120-voltgroundedoutlet

only. Do not remove the round grounding prong

from the plug. If in doubt about the grounding of the

home electrical system, it is your responsibility and

obligation to have an ungrounded outlet replaced

with a properly grounded, three prong outlet in

accordance with the National Electrical Code. Do

not use an extension cord with this appliance.

■ Beforeperforminganyservice,unplugtherange

or disconnect the power supply at the household

distribution panel by removing the fuse or switching

off the circuit breaker.

■ Besureallpackingmaterialsareremovedfromthe

range before operating to prevent ignition of these

materials.

■ Avoidscratchingorimpactingglassdoors,

cooktops, or control panels. Doing so may lead

to glass breakage. Do not cook on a product with

broken glass. Shock, fire, or cuts may occur.

■ Donotleavechildrenaloneorunattendedinan

area where an appliance is in use. They should

never be allowed to climb, sit or stand on any part

of the appliance.

■

CAUTION

Do not store items of interest

to children in cabinets above an oven - children

climbing on the oven to reach items could be

seriously injured.

■ Neverblockthevents(airopenings)oftherange.

They provide the air inlets and outlets that are

necessary for the range to operate properly with

correct combustion. Air openings are located at the

rear of the cooktop, at the top and bottom of the

oven door, and at the bottom of the range under the

warming drawer, lower oven drawer or kick panel.

■ Useonlydrypotholders—moistordamppot

holders on hot surfaces may result in burns from

steam. Do not let pot holders touch surface burners,

burner grate, or oven heating element. Do not use a

towel or other bulky cloth in place of pot holders.

■ Donottouchtheheatingelementsortheinterior

surface of the oven. These surfaces may be hot

enough to burn even though they are dark in color.

During and after use, do not touch, or let clothing

or other flammable materials contact any interior

area of the oven; allow sufficient time for cooling

first. Other surfaces of the appliance may become

hotenoughtocauseburns.Potentiallyhotsurfaces

include the burners, grates, oven vent opening,

surfaces near the opening, and crevices around the

oven door.

■ Donotheatunopenedfoodcontainers.Pressure

could build up and the container could burst,

causing an injury.

■ Cookfoodthoroughlytohelpprotectagainst

foodborne illness. Minimum safe food temperature

recommendations can be found at IsItDoneYet.gov

and fsis.usda.gov.Useafoodthermometertotake

food temperatures and check several locations.

■ Donotallowanyonetoclimb,standorhangonthe

oven door, drawer or cooktop. They could damage

the range or tip it over causing severe injury or death.

49-2000316 Rev. 8 5

WARNING

KEEP FLAMMABLE MATERIALS AWAY FROM THE RANGE

Failure to do so may result in fire or personal injury.

■ Donotstoreoruseflammablematerialsinanoven

or near the cooktop, including paper, plastic, pot

holders, linens, wall coverings, curtains, drapes and

gasoline or other flammable vapors and liquids.

■ Neverwearloose-fittingorhanginggarmentswhile

using the appliance. These garments may ignite if

they contact hot surfaces causing severe burns.

■ Donotletcookinggreaseorotherflammable

materials accumulate in or near the range. Grease

in the oven or on the cooktop may ignite.

READ AND SAVE THESE INSTRUCTIONS

WARNING

IN THE EVENT OF A FIRE, TAKE THE FOLLOWING

STEPS TO PREVENT INJURY AND FIRE SPREADING

■ Donotusewaterongreasefires.Neverpickup

a flaming pan. Turn the controls off. Smother a

flaming pan on a surface unit by covering the pan

completely with a well-fitting lid, cookie sheet or flat

tray.Useamulti-purposedrychemicalorfoam-type

fire extinguisher.

■ Ifthereisafireintheovenduringbaking,smother

the fire by closing the oven door and turning the

oven off or by using a multi-purpose dry chemical or

foam-type fire extinguisher.

■ Ifthereisafireintheovenduringself-clean,turn

the oven off and wait for the fire to go out. Do not

force the door open. Introduction of fresh air at self-

clean temperatures may lead to a burst of flame

from the oven. Failure to follow this instruction may

result in severe burns.

WARNING

COOKTOP SAFETY INSTRUCTIONS

WARNING

NEVER Operate the

Top Surface Cooking Section of this

Appliance Unattended.

• Failure to follow this warning

statement could result in fire,

explosion, or burn hazard that could

cause property damage, personal

injury, or death.

• If a fire should occur, keep away from

the appliance and immediately call

your fire department.

DO NOT ATTEMPT TO EXTINGUISH

AN OIL/GREASE FIRE WITH WATER.

■ Neverleavethesurfaceburnersunattendedat

medium or high heat settings. Foods, especially oily

foods, may ignite resulting in fire that could spread

to surrounding cabinets.

■ Neverleaveoilunattendedwhilefrying.Ifallowed

to heat beyond its smoking point, oil may ignite

resulting in fire that may spread to surrounding

cabinets.Useadeepfatthermometerwhenever

possible to monitor oil temperature.

■ Toavoidoilspilloverandfire,usetheminimum

amount of oil when using a shallow pan-frying

and avoid cooking frozen foods with excessive

amounts of ice.

■ Useproperpansizeandavoidpansthatare

unstable or easily tipped. Select cookware that is

matched to the size of the burner. Burner flames

should be adjusted so that they do not extend

beyond the bottom of the pan. Excessive flame may

be hazardous.

■ AlwaysusetheLITEpositionwhenignitingthetop

burners and make sure the burners have ignited.

■ Whenusingglass/ceramiccookware,makesureit

is suitable for cooktop service; others may break

because of sudden change in temperature.

■ Tominimizethepossibilityofburns,ignitionof

flammable materials and spillage, the handle of a

container should be turned toward the center of the

range without extending over nearby burners.

■ Donotuseawokwitharoundmetalsupportring.

The ring may trap heat and block air to the burner

resulting in a carbon monoxide hazard.

■ Donotattempttoliftthecooktop.Doingsomay

damage the gas tubing to the surface burners

resulting in a gas leak and risk of fire.

■ WhendisablingLockControl(onsomemodels),

make sure the surface controls are set to the OFF

position. This will prevent unintended gas flow from

the burners.

■ Donotusealuminumfoiltocoverthegratesor

line any part of the cooktop. Doing so may result

in carbon monoxide poisoning, overheating of the

cooktop surfaces, or a potential fire hazard.

SAFETY INFORMATION

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

6 49-2000316 Rev. 8

WARNING

SELF-CLEANING OVEN SAFETY INSTRUCTIONS

The self-cleaning feature operates the oven at temperatures high enough to burn away food soils in the oven.

Follow these instructions for safe operation.

■ Donottouchovensurfacesduringself-clean

operation. Keep children away from the oven during

self-cleaning. Failure to follow these instructions

may cause burns.

■ Beforeoperatingtheself-cleancycle,removepans,

shiny metal oven racks, and other utensils from the

oven. Only porcelain-coated oven racks may be left

in the oven.

■ Beforeoperatingtheself-cleancycle,wipegrease

and food soils from the oven. Excessive amount

of grease may ignite leading to smoke damage to

your home.

■ Iftheself-cleaningmodemalfunctions,turnthe

oven off and disconnect the power supply. Have it

serviced by a qualified technician.

■ Donotuseovencleaners.Nocommercialoven

cleaner or oven liner protective coating of any kind

should be used in or around any part of the oven.

■ Donotcleanthedoorgasket.Thedoorgasketis

essential for a good seal. Care should be taken not

to rub, damage or move the gasket.

■ IMPORTANT: The health of some birds is

extremely sensitive to the fumes given off during

the self-cleaning cycle of any range. Move birds to

another well-ventilated room.

SAFETY INFORMATION

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

READ AND SAVE THESE INSTRUCTIONS

WARNING

OVEN SAFETY INSTRUCTIONS

WARNING

NEVER cover any slots,

holes, or passages in the oven bottom or

cover an entire rack with materials such as

aluminum foil or oven liners. Doing so blocks

air flow through the oven and may cause

carbon monoxide poisoning. Never place foil

or oven liners on the oven bottom. They can

trap heat causing risk of smoke or fire.

■ Standawayfromtherangewhenopeningtheoven

door. Hot air or steam which escapes can cause

burnstohands,faceand/oreyes.

■ Neverplacecookingutensils,pizzaorbakingstones,

or any type of foil or liner on the oven floor. These

items can trap heat or melt, resulting in damage to

the product and risk of shock, smoke or fire.

■ Placeovenracksindesiredlocationwhileovenis

cool. If rack must be moved while oven is hot, be

careful to avoid touching hot surfaces.

■ Donotleaveitemssuchaspaper,cookingutensils,

or food in the oven when not in use. Items stored in

an oven can ignite.

■ Donotleaveitemsonthecooktopneartheoven

vent. Items may overheat resulting in a risk of fire or

burns.

■ Neverbroilwithdooropen.Open-doorbroilingis

not permitted due to overheating of control knobs.

How to Remove Protective Shipping Film and Packaging Tape

Carefully grasp a corner of the protective shipping film

with your fingers and slowly peel it from the appliance

surface. Do not use any sharp items to remove the film.

Remove all of the film before using the appliance for the

first time.

To assure no damage is done to the finish of the

product, the safest way to remove the adhesive from

packaging tape on new appliances is an application of

a household liquid dishwashing detergent. Apply with a

soft cloth and allow to soak.

NOTE: The adhesive must be removed from all parts. It

cannot be removed if it is baked on.

Consider recycling options for your appliance packaging

material.

PROPER DISPOSAL OF YOUR APPLIANCE

Dispose of or recycle your appliance in accordance with Federal and Local Regulations. Contact your local

authorities for the environmentally safe disposal or recycling of your appliance.

49-2000316 Rev. 8 7

In Case of a Power Failure

USING THE RANGE: InCaseofaPowerFailure/SurfaceBurners

Surface Burners

In the event of a power failure, the oven is inoperable and no attempt should be made to operate it. However, the

surfaceburnersmaybelitwithamatch.Usingextremecaution,holdalitmatchneartheportsbeneaththesurface

burner cap, then slowly turn the knob to the LITE position. Once lit, surface burners will continue to operate normally.

Lighting a Surface Burner

WARNING

Burners should be operated only

when covered by cookware. Burner flames not

covered by cookware present a risk of fire or

clothing ignition. Never let flames extend beyond the

sides of the cookware. Failure to comply may result

in serious injury.

Make sure all burners are in their correct locations and

fully assembled before attempting to operate any burner.

Selectaburnerandfinditscontrolknob.Pushtheknob

in and turn it to the LITE position.

You will hear a clicking

noise—thesoundofthe

electric spark igniting the

burner. When one burner is

turned to LITE, all burners

will spark. Sparking will

continue as long as the knob

remains at LITE. Once gas

is ignited, turn the knob to

adjust the flame size.

Using the Surface Burners

NOTES:

■ Donotoperatetheburnerforanextendedperiodof

time without cookware on the grate. The finish on the

grate may discolor or chip without cookware to absorb

the heat.

■ Donotattempttodisassembleanyburnerwhileanother

burner is on. Damage to the product may occur.

■ Besuretheburnersandgratesarecoolbeforeyou

place your hand, a pot holder or cleaning materials

on them.

Your rangetop offers convenience, cleanability and

flexibility for a wide range of cooking applications.

The smallest burner is the simmer burner. A simmer

burner turned down to LO provides precise cooking

performance for foods such as delicate sauces that

require low heat for a long cooking time.

Selecting a Flame Size

Watch the flame, not the knob, as you adjust heat. When

rapid heating is desired, the flame size should match the

size of the cookware you are using. Flames larger than

the bottom of the cookware will not heat faster and may

be hazardous.

These flames are too large for the pot

Pushthecontrolknobinand

turn it to the LITE position.

Types of Surface Burners

Round Burner

Usethisburnerforgeneralcookingpurposes.

Size cookware appropriately to the flames.

Oval Burner (on some models)

Usethisburnertocookonthegriddle.

8 49-2000316 Rev. 8

USING THE RANGE: Surface Burners

Surface Burners (Cont.)

Stove Top Grills

Do not use an after-market stove top grill on your

gas surface burners. A stove top grill will cause

incomplete combustion resulting in carbon monoxide

levels above allowable standards. This could be

hazardous to your health.

Using a Wok

Useonlyaflat-bottomedwokwithadiameterof14inches

or less. Make sure the wok bottom sits flat on the grate.

Donotuseawoksupportring.Placingtheringoverthe

burner or grate may cause the burner to work improperly,

resulting in carbon monoxide levels above allowable

standards. This could be hazardous to your health.

Useaflat-bottomedwok.

Do not use stove top grills

Top-of-Range Cookware

Aluminum: Medium-weight cookware is recommended

because it heats quickly and evenly. Most foods brown

evenlyinanaluminumskillet.Usesaucepanswithtight-

fitting lids when cooking with minimum amounts of water.

Stainless Steel: This metal alone has poor heating

properties and is usually combined with copper,

aluminum or other metals for improved heat distribution.

Combination metal skillets usually work satisfactorily if

they are used with medium heat or as the manufacturer

recommends.

Cast-Iron: If heated slowly, most skillets will give

satisfactory results.

Enamelware:Undersomeconditions,theenamel

of some cookware may melt. Follow the cookware

manufacturer’s recommendations for cooking methods.

Glass:Therearetwotypesofglasscookware—those

for oven use only and those for top-of-range cooking

(saucepans,coffeeandteapots).Glassconductsheat

very slowly.

Heatproof Glass Ceramic: Can be used for either

surface or oven cooking. It conducts heat very slowly and

cools very slowly. Check the cookware manufacturer’s

directions to be sure it can be used on gas ranges.

49-2000316 Rev. 8 9

USING THE RANGE: Griddle

Griddle (on some models)

Using Your Nonstick Aluminum Griddle (on some models)

Your griddle provides an extra-large cooking surface for

meats, pancakes, and other foods usually prepared in

a skillet. Before first use, rinse with hot water and dry

thoroughly.

Griddle Precautions:

■ Donotuseoilonthegriddleforextendedlengthsof

time.Permanentstainingand/orcrazelinesonthe

surface could result.

■ Do not overheat the griddle. Leaving the griddle

burner on at Hi for an extended amount of time

without food can damage the nonstick coating.

■ Useonlyplastic,nylon,woodenutensils,or

SilverStone

kitchen tools to prevent marring of the

coating.

■ Neveruseknivesorcutfoodonthegriddle.

■ Donotusemetalutensilswithsharppointsorrough,

sharp edges which might damage the griddle surface.

■ Storecarefullytopreventscratching.

■ Donotplacethegriddleinamicrowaveoven.

■ Ifsomethinghasspilledunderthegriddle,itshouldbe

cleaned up as soon as possible to prevent “baked on”

food soil.

■ Donotallowgreasetoaccumulateunderthegriddle

as it can be a fire hazard. Clean under the griddle with

hot, soapy water as soon as it is cool.

■ Donotcleanyourgriddleinthedishwasher.

■ Donotcleanthegriddleintheself-cleaningoven.

Doing so will damage the nonstick coating. For

instructions on how to clean the griddle, see the

Cleaning the Cooktop section of this manual.

WARNING

Fire Hazard

■ Use care when cooking greasy foods. Spilled grease may result in fire.

■ Never place any items on the griddle when it is not in use. Heat from surrounding burners can heat

the griddle and may result in fire.

■ Place and remove the griddle only when griddle is cool and all surface burners are turned OFF.

Nonstick Aluminum Griddle

Replacethecentergrate(ifpresent)withthe

Nonstick Aluminum Griddle

Type of Food Cook Setting

Bacon Med

Breakfast Sausage Links Med

Fried Eggs Lo

Hamburgers Med-Hi

HotSandwiches(suchasGrilledCheese) Med

Pancakes Med-Lo

Warming Tortillas Med-Lo

Positioning Your Griddle

Thenonstickaluminumgriddle(onsomemodels)canonlybeusedoverthecenterburneroftherangetop.To

positionthegriddle,removethecentergrate(ifpresent),andreplaceitwiththegriddle.Donotturnonthecenter

burner until you are certain the griddle has been positioned correctly.

Preheating Your Griddle

If your center burner is a single oval burner, preheat your griddle for 2-5 minutes on Hi before placing food on the

griddle.Ifyourcenterburnerisadualovalburner,preheatyourgriddlefor5-10minutesonHibeforeplacingfoodon

the griddle. Once the griddle is preheated, turn the heat down to the cook setting outlined in the table corresponding

to your griddle. To determine the type of burner you have, see the Types of Surface Burners section.

10 49-2000316 Rev. 8

USING THE RANGE: Oven Controls

Non Convection

1. Convection Bake (on some models):

Convection cooking uses increased air circulation

to improve performance when baking on multiple

racks. See the Cooking Modes section for more

information.

2. Traditional Cooking Modes: Your oven has

the following traditional cooking modes: Bake, Broil

Hi and Broil Lo. See the Cooking Modes section for

more information.

3. Clean (on some models): There are two

cleaning modes: Self Clean and Steam Clean.

See the Cleaning the Oven section for important

information about using these modes.

4. Start: Must be pressed to start any cooking,

cleaning or timed function.

5. Cancel/Off: Cancels ALL oven operations except

the clock and timer.

6. Cook Time: Counts down cooking time and turns

off the oven when the cooking time is complete.

Programthedesiredcookingmodeandtemperature

and press Start. Then, press the Cook Time pad

and use the number pads to program a cooking

time in hours and minutes. Then, press Start again.

This can only be used with Traditional Bake and

Convection Bake.

Convection

2 3

1 7 8

5 6 9

Oven Controls

4 78

35 6 9

11 10

49-2000316 Rev. 8 11

7. Clock: Sets the oven clock time and clock display

(onsomemodels).Tosettheclockdisplay(on/off),

press the Set Clockpad(onsomemodels)once.If

your model does not have a Set Clock pad, see the

Special Features section for instructions on how to

adjust the clock display. To set the clock time, press

both the + and - pads and hold for 3 seconds or

press the Set Clock pad until the display is flashing.

Usethe+ and -padstoadjusttheclock.Press

Start to save the time.

8. Timer: Worksasacountdowntimer.Pressthe

Timer pad and the + and - pads to program the

timeinhoursandminutes.PresstheStart pad.

The oven will continue to operate when the timer

countdown is complete. To turn the timer off, press

the Timer pad.

9. Delay Time: Delays when the oven will turn on.

Usethistosetatimewhenyouwanttheovento

start.PresstheDelay Time pad, and use the + and

- pads to program the time of day for the oven to

turn on. Then press the desired cooking mode pad,

use the + and - pads to adjust the temperature, then

press Start. After Start has been pressed, a cook

time may also be programmed if desired. Once the

Delay Time has been programmed, the start time

set for the oven will be displayed until that time is

reached.Then,eitherthecooktime(ifprogrammed)

or the temperature will be displayed. Delay Time

can only be used with Traditional Bake, Convection

Bake,andtheCleanmodes(onsomemodels).

NOTE: When using the delay time feature, foods

thatspoileasily—suchasmilk,eggs,fish,stuffings,

poultry,andpork—shouldnotbeallowedtosit

atroomtemperatureformorethan1hourbefore

or after cooking, as this may promote the growth

of harmful bacteria. Be sure that the oven light is

off, because heat from the bulb will speed harmful

bacteria growth.

10. Oven Light (on some models): Turns the

oven light on or off.

11. Lock Controls (on some models): Locks

out the control so that pressing the pads does not

activatethecontrols.Pressandboththe+ and -

pads and hold for 3 seconds to lock or unlock the

control. Cancel/Off is always active, even when the

control is locked.

12. Automatic Oven: Light turns on when Cook

Time or Delay Time and Bake are selected.

USING THE RANGE:OvenControls/SpecialFeatures

Oven Controls (Cont.)

There are several different special features on your range. To change the settings of these special features:

■ PresstheBake and Broil pads at the same time and hold for three seconds.

■ “SF”willappearinthedisplay.

■ Forinstructionsonhowtoselectdifferentfeatures,refertothesectionbelowthatcorrespondstothespecial

feature of interest.

■ Whenthechangehasbeenmade,presstheStart key to save the change and exit the special features menu.

Adjust the Oven Temperature

This feature allows the oven baking temperature to be

adjustedupto35ºFhotterordownto35ºFcooler.Use

this feature if you believe your oven temperature is too

hot or too cold and wish to change it. This adjustment

affects every cooking mode except broil.

After entering the special features menu, press the

Bake pad to enter the temperature adjustment mode. A

numberbetween35and-35willdisplay.Usethe+ or -

padstosetthedesiredtemperatureadjustment.Press

the Start pad to save the temperature adjustment.

12-Hour Auto Shut-Off

12-hourautoshut-offturnsofftheovenafter12hours

ofcontinuousoperation.The12-hourautoshut-offmay

be “on” or “oFF.”. Enter into the special features menu

as outlined above and repeatedly press the Set Clock

pad until the desired setting is displayed. If your model

does not have a Set Clock pad, then repeatedly press

the Cook Time pad until the desired setting is displayed.

PresstheStart pad to save the setting.

Clock Display (on some models)

This feature specifies if the time of day is displayed.

The clock display may be “on” or “oFF.” If your model

has a Set Clock pad, see the Oven Controls section for

instructions on adjusting the display. If your model does

not have a Set Clock pad, enter into the special features

menuasoutlinedabove.PresstheTimer pad to see the

currentsetting.PresstheTimer pad again to change the

setting.PresstheStart pad to save the display setting.

Increment/Decrement Speed

Asetting(i.e.temperature)mayberapidlyadjusted

by pressing and holding the + or - pad. To adjust the

increment/decrementspeed,enterintothespecial

featuresmenuasoutlinedabove.Pressthe+ pad to

increase the speed or press the - pad to decrease the

speed.Settingsvaryfrom1(slowest)to5(fastest).

PresstheStart pad to save the speed setting.

Special Features

12 49-2000316 Rev. 8

IfyourrangedoesnothavetheOUandCRClogoon

theratinglabelaspictured(locationmayvarybymodel)

follow the “Sabbath Mode – Standard” instructions in

thefollowingsection,otherwiseyourrangeoffersanOU

and CRC Sabbath mode that complies with standards

setforthbyOrthodoxUnion,theCentralRabbinical

Congress,andHalachaTech,andis100%certifiedto

the highest halacha standards. In this mode the oven

lights will remain on for the duration of use, oven tones

will be disabled, pads apart from the cancel pad shall

be disabled, Enhanced Sabbath shall exit automatically

based on user selection at the time of entry.

NOTE: Ensure the oven clock is accurate before

entering the mode. For proper Sabbath operation, the

modemustbestartedwithinthe1-hourwindowbefore

sunset.

Setting OU and CRC Sabbath (Default Schedule)

1.PressandholdtheBake and + pads for 3 seconds

until “SAb” is displayed.

2. The default warm duration is 24 Hours, If the default

duration is not desired, press the Timer On/Off pad to

enter the Sabbath Warm Duration Selection menu. Scroll

through the duration options using the + or – pads.

Sabbath Warm has options of 24h, 48h, 72h, 4h, 8h, 12h.

3.PressStartpad.IfStartpadisnotpressedin30

seconds, the unit will exit Sabbath setup.

4. Sabbath Warm cycle shall start, “SAb” shall continue

to be displayed, and the oven will heat to a warming

temperature.

NOTE: For time options less than 24 hours, the unit will

complete the Sabbath Warm function and transition to

Sabbath Idle for the remainder of the 24-hour period.

During Sabbath Idle the oven lights will remain on, oven

tones will remain disabled, oven heating will be disabled,

and the control will display “IdLE”. To account for the

1-hourwindowbeforesunset,theSabbathexitwillbe

extended by one hour.

OU and CRC Sabbath Plus Holiday Schedule

1.PressandholdtheBake and + pads for 3 seconds

until “SAb” is displayed.

2. Scroll through the schedule options using the + or –

pads. Select the desired schedule by pressing Start.

Example - Setting a Sabbath with two days of Holidays

PressandholdtheBake and + pads for 3 seconds

until“SAb”isdisplayed.Pressthe+ key until SHH is

displayed on the control, then press the Start pad.

UnitwillnowenterSabbathWarmanddisplay“SAb”

onthecontrolforthenext25hours.Uponexitingthe

Sabbath Warm the Holiday schedule will be executed

as described in the Holiday chart for the next 48 hours.

UponcompletionoftheHolidayschedulethecontrolwill

return to normal function.

Holiday Schedule

Holiday Cycle Definition

• Holiday Warm: “Hol” shall be displayed, and the oven

will heat to a warming temperature.

• Holiday Bake: “Hol” shall be displayed, Bake LED shall

be on, and the oven will heat to a baking temperature.

Manual Stop Sabbath Mode

PressingtheCancel/Off pad will exit the Sabbath mode

completely and return the range to normal function.

Sabbath Mode Power Outage Note

If a power outage occurs during the use of the Sabbath

mode, the unit will return to Sabbath Warm for the

remainder of the chosen schedule. If the power outage

occurs during the Sabbath Idle mode, the unit will

return to Sabbath Idle for the remainder of the chosen

schedule. This mode does not account for the time

elapsed during the power outage and will resume at the

samepointoftheinitiallossofpower.Thus,OUand

CRC Sabbath exit shall be delayed by the same amount

as the power loss duration.

USING THE RANGE: SabbathMode-OUandCRC

Sabbath Mode

- OU (Orthodox Union) and CRC (Central Rabbinical Congress)

Start Time End Time

Holiday

Bake

Initial Time Entered

(ITE)

ITE + 5 hrs or Midnight

(whicheveroccursfirst)

Holiday

Warm

ITE + 5 hrs or Midnight

(whicheveroccursfirst)

8 AM

Holiday

Bake

8 AM 12Noon

Holiday

Warm

12Noon Initial Time Entered

Menu Options Schedule Details

SAb(default) 24hr+1hrSabbathWarm

SH 24hr+1hrSabbathWarm

24 hr Holiday

SHH 24hr+1hrSabbathWarm

24 hr Holiday

HS 24 hr Holiday

24hr+1hrSabbathWarm

HHS 24 hr Holiday

24 hr Holiday

24hr+1hrSabbathWarm

49-2000316 Rev. 8 13

USING THE RANGE: Sabbath Mode - Standard

Only continuous baking or timed baking is allowed in the Sabbath mode. All tones are disabled in the Sabbath mode;

however the oven light is not disabled, so the light should be removed to ensure it does not come on when the door

is opened. While in standard Sabbath mode, the sensors will detect your actions but will not respond. The heating

elementswillcycleastheydowhilenotinSabbathmode.Pleaseconsultyourlocalrabbiforadditionalguidance

whileusingtherangeduringShabbosand/orholiday.CookingintheSabbathmodeisatwo-stepprocess,firstthe

Sabbath mode must be set and then the bake mode must be set.

Setting the Sabbath Mode

PresstheBake and Broil pads at the same time and

hold for three seconds. “SF” will appear in the display.

PresstheSet Clock pad until “SAb” appears in the

display and then press Start. If your model does not

have a Set Clock pad, then press the Cook Time pad

until “SAb” appears in the display and then press Start. If

“SAb”isnotanoption,tryusingtheSabbathMode-OU

and CRC instructions in the previous section. A single

bracket “]” will appear in the display indicating that the

Sabbath mode is set. Continuous bake or timed bake

can now be set as outlined below.

Start a Continuous Bake

PressBake,ifatemperatureotherthan350Fisdesired

then press the + or - pads to adjust the temperature in

25 degree increments, then press Start. After a delay, a

second bracket “] [” will appear in the display indicating

that the oven is baking.

Adjusting the Temperature

PressBake, then press the + or - pads to adjust the

temperature in 25 degree increments, then press Start.

An oven thermometer can be used if some indication of

temperature setting is desired.

Start a Timed Bake

PressCook Time, then press the + or - pads to adjust

thecooktimeinoneminuteincrements.PressBake,

ifatemperatureotherthan350Fisdesiredthenpress

the + or - pads to adjust the temperature in 25 degree

increments, then press Start. After a delay, a second

bracket “] [” will appear in the display indicating that the

oven is baking. When the cook time expires the display

will change back to a single bracket “]” indicating that the

oven is no longer baking.

Exit the Sabbath Mode

Exiting the Sabbath mode should be done after the

Sabbathisover.PressCancel/Off to end any bake

modethatmayberunning.PressBake and Broil pads

at the same time and hold for three seconds. “SF” will

appearinthedisplay.PresstheSet Clock pad until

“On” appears in the display and then press Start. If your

model does not have a Set Clock pad, then press the

Cook Time pad until “On” appears in the display and

then press Start. The display will change from a single

bracket “]” to the time of day indicating that the Sabbath

mode has been exited.

Sabbath Mode Power Outage Note

If a power outage occurs, the Sabbath mode will not

resume when power is restored.

Sabbath Mode - Standard*

*ThestandardSabbathmodehasnotbeenreviewedorapprovedbyOrthodoxUnionandCentralRabbinicalCongress.

14 49-2000316 Rev. 8

USING THE RANGE: Cooking Modes

Your new oven has a variety of cooking modes to help you get the best results. These modes are described below.

Refer to the Cooking Guide section for recommendations for specific foods. Remember, your new oven may perform

differently than the oven it is replacing.

Bake

The bake mode is for baking and roasting. This mode

uses heat only from the lower burner. When preparing

baked goods such as cakes, cookies and pastries,

always preheat the oven first. To use this mode, press

the Bake pad, use the + and - pads to adjust the

temperature, then press Start.

Broiling Modes

Always broil with the oven door and drawer closed.

Monitorfoodcloselywhilebroiling.Usecautionwhen

broiling on the upper rack positions as placing food

closer to the broil burner increases smoking, spattering,

and the possibility of fats igniting.

Try broiling foods that you would normally grill. Adjust

rack positions to adjust the intensity of the heat to the

food.Placefoodsclosertothebroilburnerwhenaseared

surface and rare interior is desired. Thicker foods and

foods that need to be cooked through should be broiled

on a lower rack position or by using the Broil Lo mode.

Broil Compartment (on some models)

For better searing use the rack position that places

food closest to the broil heater. Move food down for

moredoneness/lesssearing.Takecarenottotouch

the inner door when placing and removing food in broil

compartment.

Broil Hi

The Broil Hi mode uses intense heat from the upper

burnertosearfoods.UseBroilHiforthinnercutsofmeat

and/orwhenyouwouldliketohaveasearedsurfaceand

rare interior. To use this mode press the Broil pad once

and then press Start. It is not necessary to preheat when

using this mode.

Broil Lo

The Broil Lo mode uses less intense heat from the upper

burner to cook food thoroughly while also browning the

surface.UseBroilLoforthickercutsofmeatand/orfoods

that you would like cooked all the way through. To use

this mode press the Broil pad twice and then press Start.

It is not necessary to preheat when using this mode.

Convection Bake (on some models)

The Convection Bake mode is intended for baking

on multiple racks at the same time. This mode uses

air movement from the convection fan to enhance

cooking evenness. Your oven is equipped with Auto

Recipe Conversion, so it is not necessary to adjust the

temperature when using this mode. Always preheat

when using this mode. Baking times may be slightly

longer for multiple racks than what would be expected

for a single rack. To use this mode press the Conv Bake

pad, use the + and - pads to adjust the temperature, and

then press Start. Always preheat when using this mode.

Cooking Modes

Drop-downBroilCompartment(somemodels)

49-2000316 Rev. 8 15

Oven Racks

Cookware

Aluminum Foil and Oven Liners

Recommended rack positions for various types of

foods are provided in the Cooking Guide. Adjusting

rack position is one way to impact cooking results. For

example, if you would prefer darker tops on cakes,

muffins, or cookies, try moving food one rack position

higher. If you find foods are too brown on top try moving

them down next time.

When baking with

multiple pans

and on multiple

racks, ensure

there is sufficient

space between

pans to allow air

flow. This may

improve cooking

eveness.

Removing and Replacing Flat Racks

When placing and removing cookware, pull the rack out

tothebump(stopposition)ontheracksupport.

To remove a rack, pull it toward you until it reaches the

stop position, tilt up the front of the rack and pull it out.

To replace a rack,

place the curved end of

the rack onto the rack

supports. Tilt up the front

of the rack and push

the rack in until it stops.

Then lay the rack flat

and push it in until it is

all the way into the oven.

Racks may become

difficult to slide,

especially after a self-

clean cycle. To improve

sliding conditions, use a

soft cloth or paper towel

to rub vegetable oil on

the left and right edges

oftheracksand/orrack

supports.

NOTE: Remove unused racks when using the oven for

faster preheat, improved efficiency and optimal cooking

performance.

Cookware Guidelines

The material, finish, and size of cookware affect baking

performance.

Dark, coated and dull pans absorb heat more readily

thanlight,shinypans.Pansthatabsorbheatmore

readily can result in a browner, crisper, and thicker crust.

If using dark and coated cookware check food earlier

than minimum cook time. If undesirable results are

obtained with this type of cookware consider reducing

oven temperature by 25°F next time.

Shiny pans can produce more evenly cooked baked

goods such as cakes and cookies.

Glass and ceramic pans heat slowly but retain heat well.

These types of pans work well for dishes such as pies

and custards.

Air insulated pans heat slowly and can reduce bottom

browning.

Keep cookware clean to promote even heating.

Stoneware heats slowly and retains heat well. It is

recommended to preheat this type of cookware if

possible. Additional cook time may be required.

CAUTION

Do not use any type of foil or oven liner to cover the oven bottom. These items can trap heat

or melt, resulting in damage to the product and risk of shock, smoke or fire. Damage from improper use of

these items is not covered by the product warranty.

Foil may be used to catch spills by placing a sheet on a lower rack, several inches below the food. Do not use more

foilthannecessaryandneverentirelycoveranovenrackwithaluminumfoil.Keepfoilatleast1-1/2”fromovenwalls

to prevent poor heat circulation.

The number of rack positions may vary by model.

Replacing racks

Removing racks

Rack stop

position

Oven Air Vents

USING THE RANGE:

OvenRacks/AluminumFoilandOvenLiners/Cookware/OvenAirVents

Neverblockthevents(airopenings)oftherange.They

provide the air inlet and outlet that are necessary for the

range to keep cool and operate properly with correct

combustion.

Air openings are located at the rear of the cooktop, at

the top and bottom of the oven door, and at the bottom

of the range.

Ventappearanceandlocationvary.

16 49-2000316 Rev. 8

USING THE RANGE: Cooking Guide

Cooking Guide

FOOD TYPE

RECOMMENDED

MODE(S)

RECOMMENDED

RACK POSITION(S) ADDITIONAL SUGGESTIONS

Baked Goods

Layer cakes, sheet cakes,

bundt cakes, muffins,

quick breads, biscuits,

scones on a Single Rack

Bake 4 or 5 Useshinycookware.

Layer cakes* on Multiple

Racks

Bake

Convection Bake

3 and 5

Ensure adequate airflow

(seeillustrationbelow).

Chiffon cakes

(angelfood)

Bake 2 Useshinycookware.

Cookies, biscuits, scones

on a Single Rack

Bake 3 or 4 Useshinycookware.

Cookies, biscuits, scones

on Multiple Racks

Convection Bake

Bake

2 Racks - 3 and 5

3 Racks - 2, 4 and 6

Ensure adequate airflow. Switch food location partially

through cooking for more even cooking results.

Beef & Pork

Hamburgers Broil Hi 6 or C

Useabroilpan;movefooddownformoredoneness/less

searing. Watch food closely when broiling.

Center food under burner.

Steaks & Chops Broil Hi 6 or C

Useabroilpan;movefooddownformoredoneness/less

searing. Watch food closely when broiling.

Center food under burner.

Roasts Bake 2 or 3

Leave uncovered, use a low sided pan such as a broil pan.

Preheatingisnotnecessary.

Poultry

Whole chicken Bake 2 or 3 Leave uncovered, use a low sided pan such as a broil pan.

Bone-in chicken breasts,

legs, thighs

Broil Lo

Bake

4 or B

If breaded or coated in sauce avoid Broil Hi modes. Broil skin

side down first. Watch food closely when broiling.

Boneless chicken breasts

Broil Lo

Bake

4 or B

Movefooddownformoredoneness/lesssearingandupfor

greatersearing/browningwhenbroiling.

Whole turkey Bake 1or2 Leave uncovered, use a low sided pan such as a broil pan.

Turkey Breast Bake 2 or 3 Leave uncovered, use a low sided pan such as a broil pan.

Fish Broil Lo

6orC(1/2inchthickorless)

5orB(>1/2inch)

Watch food closely when broiling.

Casseroles Bake 3 or 4

Frozen Convenience Foods

Pizza,potatoproducts,

chicken nuggets, appetizers

on a Single Rack

Bake 4 or 5 Useshinycookware.

Pizza,potatoproducts,

chicken nuggets, appetizers

on Multiple Racks

Bake

Convection Bake

3 and 5

2, 4 and 6

Useshinycookware.

Switch food location partially through cooking for more even

cooking results.

*When baking four cake layers at a time, stagger the

pans as shown to the right so that one pan is not directly

above another.

Cook food thoroughly to help protect against

foodborne illness. Minimum safe food temperature

recommendations for food safety can be found at

IsItDoneYet.gov. Make sure to use a food thermometer

to take food temperatures.

NOTE: Remove unused racks when using the oven for

faster preheat, improved efficiency and optimal cooking

performance.

Front

Placement

Rear

Placement

49-2000316 Rev. 8 17

A child or adult can tip the range and be killed.

Verify the anti-tip bracket has been properly installed

and engaged.

Ensure the anti-tip bracket is re-engaged when the range

is moved.

Do not operate the range without the anti-tip bracket in

place and engaged.

Failure to follow these instructions can result in death or

serious burns to children or adults.

Tip-Over Hazard

WARNING

Range – Exterior

CARE AND CLEANING: Range – Exterior

WARNING

If your range is removed for cleaning, servicing or any reason, be sure the

anti-tip device is reengaged properly when the range is replaced. Failure to

take this precaution could result in tipping of the range and can result in death

or serious burns to children or adults.

Be sure all controls are off and all surfaces are cool before cleaning any part of the range.

Control Lockout

If desired, the touch pads may be deactivated before

cleaning.

See Lock Controls in the Oven Controls section in this

manual.

Clean up splatters with a damp cloth.

You may also use a glass cleaner.

Remove heavier soil with warm, soapy water. Do not use

abrasives of any kind.

Reactivate the touch pads after cleaning.

Control Panel

It’s a good idea to wipe the control panel after each use.

Clean with mild soap and water or vinegar and water,

rinse with clean water and polish dry with a soft cloth.

Do not use abrasive cleansers, strong liquid cleansers,

plastic scouring pads or oven cleaners on the control

panel—theywilldamagethefinish,includingBlack

Stainless Steel.

Oven Exterior

Do not use oven cleaners, abrasive cleansers, strong

liquid cleansers, steel wool, plastic scouring pads, or

cleaning powders on the interior or exterior of the oven.

Clean with a mild soap and water or vinegar and water

solution. Rinse with clean water and dry with a soft cloth.

When cleaning surfaces, make sure that they are at

room temperature and not in direct sunlight.

If stain on the door vent trim is persistent, use a mild

abrasive cleaner and a sponge-scrubber for best results.

Spillage of marinades, fruit juices, tomato sauces and

basting liquids containing acids may cause discoloration

and should be wiped up immediately. Let hot surfaces

cool, then clean and rinse.

Painted Surfaces

Paintedsurfacesincludethesidesoftherangeandthe

door, top of control panel and the drawer front. Clean

these with soap and water or a vinegar and water solution.

Do not use commercial oven cleaners, cleaning

powders, steel wool or harsh abrasives on any painted

surface, including Black Stainless Steel.

Stainless Steel excluding Black Stainless Steel (on some models)

Do not use a steel wool pad; it will scratch the surface.

Cleaners with oxalic acid such as Bar Keepers Friend

Soft Cleanser™ will remove surface rust, tarnish and

smallblemishes.Useonlyaliquidcleanserfreeofgrit

and rub in the direction of the brush lines with a damp,

soft sponge.

To clean the stainless steel surface, use warm sudsy

water or a stainless steel cleaner or polish. Always wipe

the surface in the direction of the grain. Follow the cleaner

instructions for cleaning the stainless steel surface.

To inquire about purchasing cleaning products

including stainless steel appliance cleaner or polish,

see the Accessories and Consumer Support sections

at the end of this manual.

18 49-2000316 Rev. 8

The interior of your new oven can be cleaned manually or by using the Steam Clean or the Self Clean mode.

Spillage of marinades, fruit juices, tomato sauces and basting liquids containing acids may cause discoloration and

should be wiped up immediately. Let hot surfaces cool, then clean and rinse.

Manual Cleaning

Do not use oven cleaners, strong liquid cleansers, steel

wool, or scouring pads on the interior of the oven. For

soils on the oven bottom and other enameled surfaces,

use a gentle abrasive containing oxalic acid, such as

Bar Keepers Friend

, with a non-scratch sponge. Take

care not to apply any abrasive cleaners or sponges to

the door glass, as it will scratch the reflective coating.

The oven interior and door glass may be cleaned using

a soft cloth with a mild soap and water, or vinegar and

water solution. After cleaning, rinse with clean water and

dry with a soft cloth.

CARE AND CLEANING: Range – Interior

Range – Interior

Steam Clean Mode (on some models)

The Steam Clean feature is for cleaning light soil from

your oven at a lower temperature than Self Clean.

To use the Steam Clean feature:

1.Startwiththeovenatroomtemperature.

2. Wipe excess grease and soils from the oven.

3.Pouronecupofwaterontothebottomoftheoven.

4. Close the door.

5.PresstheClean pad, select Steam Clean and

then press Start/Enter.30minuteswillshowand

count down inthe display in the Steam Clean

mode.

If your range has the self clean mode below, slide

the door latch handle to the left as far as it will go. Do

notopenthedoorduringthe30minuteSteamClean

cycle. At the end of the Steam Clean cycle, soak up

the remaining water, and wipe the moisture-softened

soil from the oven walls and door.

Self Clean Mode (on some models)

Read Self-Cleaning Oven Safety Instructions at the

beginning of this manual before using the Self Clean

Mode. Self Clean uses very high temperatures to clean

theoveninterior.Onlyself-clean(black)racksandgrates

may remain in the oven during the self-clean cycle. All

otheritems,includingnickelplated(silver)racks,should

beremoved.Ifnickelplated(silver)racksareleftinthe

oven during a self-clean cycle, the racks will tarnish. If

either type of rack is left in the oven during a self-clean

cycle, the rack may become difficult to slide. See the

Oven Racks section for instructions on how to improve.

IMPORTANT: The health of some birds is extremely

sensitive to the fumes given off during the self-cleaning

cycle of any range. Move birds to another well-

ventilated room.

To use the Self Clean feature:

1.Startwiththeovenatroomtemperature.

2. Wipe excess grease and soils from the oven and

interior door.

3. Remove all items. See Cleaning the Cooktop to

determine if your grates may be self-cleaned and

for important details regarding grate placement.

4. Close the door. Slide the door latch handle to the

left as far as it will go.

5.PresstheClean pad, select Self Clean and then

press Start/Enter. 4 hours will show and count

down in the display in the Self Clean mode.

You cannot open the door during the self-clean cycle.

The door will remain locked after the self-clean cycle

until the oven cools below the unlocking temperature.

At the end of the self-clean cycle, allow the oven to cool

and wipe any ash out of the oven.

Racks

All racks can be washed with warm, soapy water.

Enameled(notshiny)rackscanbeleftinthecavity

during self clean.

Racks may be more difficult to slide, especially after

aself-clean.Putsomevegetableoilonasoftclothor

paper towel and rub onto the left and right edges.

49-2000316 Rev. 8 19

Removal of Surface Burners for Cleaning

Turn all controls OFF. Allow cooktop to cool before

removing grates and burner parts. When removing the

burner caps and heads, remember their size and location.

Replace them in the same location after cleaning.

CAUTION

Do not attempt to remove oval burner

cap from burner head.

Cooktop

CARE AND CLEANING: Cooktop

Round Burner Oval Burner

(on some models)

Round Burner Cap

(Removable)

Electrode

Round

Burner

Head

Cleaning the Surface Burners

Cleaning the Burner Caps

Wash burner caps in hot, soapy water and rinse with

clean water. You may scour with a plastic scouring pad

to remove burned-on food particles. The round burner

caps may also be cleaned in your dishwasher.

Cleaning the Burner Heads

Wash the burner heads routinely, especially after bad

spillovers which could clog the burner openings. Lift

burners off when cool. Wash with hot, soapy water. Rinse

with clean water. For more stubborn stains, use a brush

with plastic bristles.

NOTE: Do not use steel wool or scouring pads to clean

the burner parts as these may clog the openings. Never

wash burner heads in your dishwasher as dishwasher.

Doing so may cause them to discolor.

The ports in the burner heads must be kept clean at all

times for an even, unhampered flame.

Clogged or dirty burner ports or electrodes will not allow

the burner to operate properly.

Replacing Surface Burners

Before replacingtheburnercaps,headsandovalhead/

cap assembly, shake out excess water and allow them to

dry thoroughly.

Replace burner heads in the correct locations according

to size. Ensure each cap is properly seated on the

burner head, as pictured below.

CAUTION

Do not operate the cooktop without

all burner parts and grates in place.

Any spill on or around an electrode must be carefully

cleaned. Avoid hitting the electrode with anything hard or

it could be damaged.

The electrode of the spark igniter is exposed

when the burner head is removed. When one

burner is turned to LITE, all the burners spark.

Do not attempt to disassemble or clean around

any burner while another burner is on.

Electrode

Burner cap is

properly seated.

Burner cap is

NOT properly

seated.

Burner cap is

NOT properly

seated.

Round hole in

burner head must

be kept clear

Oval Burner Cap

(Non-Removable)

Oval

Burner

Head

Electrode

20 49-2000316 Rev. 8

Cooktop (Cont.)

CARE AND CLEANING: Cooktop

Grate Support Bumpers (on some models)

If any of the rubber grate support bumpers in the cooktop

are missing or damaged, replacement parts can be

obtained by visiting geappliances.com

To insert the new bumpers, simply place the cone-

shaped end of the bumper into the hole in the cooktop

and push down while gently twisting the bumper.

Griddles (on some models)

Nonstick Aluminum Griddle: Avoid scraping the griddle

surface with metal utensils. Wash your griddle with dish

soap and hot water. If necessary, scrub with a non-

abrasive plastic pad.

Griddle Precautions:

■ If something has spilled under the griddle, it should

be cleaned up as soon as possible to prevent the spill

from getting baked onto the cooktop.

■ Do not allow grease to accumulate under the griddle

as it can be a fire hazard. Clean under the griddle with

hot, soapy water as soon as it is cool.

■ Do not wash your griddle in the dishwasher.

■ Donotcleanthegriddleintheself-cleaningoven.

Grate Support Bumpers

Burner Grates

Manual Cleaning

Grates should be washed in hot, soapy water and

rinsed with clean water. To soften burned-on food,

place grates in a solution containing ¼-cup of

household ammonia for several hours. Afterward, scrub

grates with a plastic scouring pad soaked in hot, soapy

water. Rinse well and dry.

Self Clean Mode (on some models)

If your grates do not have rubber bumpers on their

bottom surface, they may be cleaned in the oven using

the self-clean cycle. Do not attempt to clean your grates

in the oven if your grates have rubber bumpers. Doing

so will destroy the rubber bumpers and may affect the

function of your surface burners.

Porcelain-coatedgratesmaygraduallydullifcontinually

exposed to self-clean temperatures.

Yourovenisequippedwithnickel-plated(silver)racks,

it is recommended to follow the instructions for placing

grates on the oven bottom. Nickel-plated racks should

not remain in the oven during the self clean cycle. Doing

so will tarnish the racks. If either type of rack is left in

the oven during a self-clean cycle, the rack may become

difficult to slide.

NOTE: When placing or removing grates from the oven,

do not slide the grates on the racks or oven bottom.

Doing so could damage the enamel on the racks or

oven bottom.

To self clean your grates on the oven bottom:

1. Removeallovenracks.

2. Gently place one grate on the center of the oven

bottom with the grate oriented in the upright position.

Stackremaininggrate(s)asshownbelow.Donot

place or stack grates in any other configuration.

Once the grates are placed in the oven, operate the

self-clean cycle per the instruction in the Cleaning the

Oven section.

NOTE:Usecautionwhenremovingthegratesfromthe

oven after the self-clean cycle has ended. The grates

may still be hot.

Once the self-clean cycle is complete, the grates may

carefully be removed. You may notice a white residue on

the grates. Wipe it off with a damp sponge. If white spots

persist,wetthespongewitha50/50solutionofvinegar

and water and wipe the grates again.

When replacing the grates on the cooktop, be sure to

locate them correctly. Grates should fit securely into

the cooktop.

49-2000316 Rev. 8 21

Cleaning the Oven Door

Cleaning the Door Interior

Do not allow excess water to run into any holes or slots

in the door .

Wipe dish soap over any baked-on spatters on the glass.

Useasinglesidedsafetyrazorbladetocleanitoff.Then

wipe over the glass with a soapy cloth to remove any

residue and dry off.

The area outside the gasket can be cleaned with a soap-

filled plastic scouring pad. Do not rub or clean the door

gasket - it has an extremely low resistance to abrasion.

If you notice the gasket becoming worn, frayed or

damaged in any way or if it has become displaced on the

door, you should have it replaced.

Cleaning the Door Exterior

If a stain on the door vent trim is persistent, use a mild

abrasive cleaner and a sponge-scrubber for best results.

Do not use this method on any other surface.

Stainless Steel Surfaces (on some models)

Do not use a steel wool pad; it will scratch the surface.

To clean the stainless steel surface, use warm sudsy

water or a stainless steel cleaner or polish. Always wipe

the surface in the direction of the grain. Follow the cleaner

instructions for cleaning the stainless steel surface.

To inquire about purchasing cleaning products

including stainless steel appliance cleaner or polish,

see the Accessories and Consumer Support sections

at the end of this manual.

Door and Drawer

CARE AND CLEANING: Door and Drawer

Removable Storage Drawer (on some models)

The storage drawer is a good place to store cookware

and bakeware. Do not store plastics or flammable

material in the drawer.

The storage drawer may be removed for cleaning under

the range. Clean the storage drawer with a damp cloth or

sponge. Never use harsh abrasives or scouring pads.

Removing the Storage Drawer:

1. Pulldrawerstraightoutuntilitstops.

2. Tilt the front of the drawer upward and pull the drawer

free of the range.

Replacing the Storage Drawer:

1. Restthedrawerslidesontherangestops.

2. Pushdirectlybackwarduntilthedrawerdropsinto

place.

3. Slide the drawer all the way into the oven.

The storage drawer may be removed

for cleaning under the range.

22 49-2000316 Rev. 8

WARNING

SHOCK OR BURN HAZARD: Before replacing oven light bulb, disconnect the electrical power to the

range at the main fuse or circuit breaker panel. Failure to do so may result in electric shock or burn.

CAUTION

BURN HAZARD: The glass cover and bulb should be removed when cool. Touching hot glass with

bare hands or a damp cloth can cause burns.

CAUTION

Before replacing your oven light bulb, disconnect the electrical power to the range at the main fuse

or circuit breaker panel. Be sure to let the light cover and bulb cool completely.

The oven light bulb is covered with a removable glass cover that is held in place with a bail-shaped

wire. Remove the oven door, if desired, to reach the cover easily. See the Lift-Off Oven Door

section for detailed oven door removal instructions.

Oven Light

CARE AND CLEANING: Oven Light

Replacing the Light Bulb (JGSS66 model only):

1. Disconnectelectricalpowertotherange.

2. Hold the glass cover stable, so it doesn’t fall when

released.

3. Slide near the indent of the cover holder until the

cover is released. Do not remove any screws to

release the glass cover.

4. Replacebulbwitha40-watthouseholdappliance

bulb. Do not touch hot bulb with hand or wet

cloth. Only remove bulb when it is cool.

5. Hold glass cover stable over new bulb.

6. Pullthewirecoverholderneartheindentuntilthe

indent in the wire cover holder is located in the indent

of the glass cover.

7. Connect electrical power to range.

Wire cover holder

Indent

Glasscover(onself

cleanmodelonly)

NOTE: The glass cover should be removed only when

cold. Wearing latex gloves may offer a better grip.

Before replacing the bulb, disconnect electrical power to

the oven at the main fuse or circuit breaker panel. Let

the bulb cool completely before removing it. For your

safety do not touch a hot bulb with a damp cloth. If you

do the bulb may break.

To remove:

Turntheglasscovercounterclockwise1/4turnuntilthe

tabs of the glass cover clear the grooves of the socket

and pull the cover off. Remove the bulb.

To replace:

Putinanew40-wattappliancebulb.Placethetabsof

the glass cover into the grooves of the socket. Turn the

glasscoverclockwise1/4turn.

NOTE:

■ A40-wattappliance

bulb is smaller than

astandard40-watt

household bulb.

■ Reconnect electrical

power to the oven once

the new bulb is installed.

■ For improved lighting

inside the oven,

clean the glass cover

frequently using a wet

cloth. This should be

done when the oven is

completely cool.

Bulb

Socket

Tab

⁄2”

Max

length

Glass cover

49-2000316 Rev. 8 23

Oven Door

The door is very heavy. Be careful when removing and lifting the door. Do not lift door by the handle.

To Remove the Door (JGSS66 model only):

1. Fullyopenthedoor.

2. Pullthehingelocksupandawayfromtherange

frame to the unlocked position.

3. Firmly grasp both sides of the door near the top.

4. Close door until the top of the door is approximately

6” from the range frame.

5. Lift door up and away from the range until both hinge

arms are clear of the slots in the range frame.

To Replace the Door (JGSS66 model only):

1. Firmlygraspbothsidesofthedoornearthetop.

2. With the door at the same angle as the removal

position, rest the notch on the underside of the left

hinge arm on the bottom edge of the left hinge slot.

The notch in the hinge arm must be fully seated into

the bottom of the slot. Repeat for the right side.

3. Fully open the door. If the door will not fully open, the

notches in the bottoms of the hinge arms have not

seated correctly in the bottom edge of the slot. Lift the

door off the range and repeat previous step.

4. Pushthehingelockstowardtherangecavityand

down to the locked position.

5. Close the oven door.

Removal positionPullhingelocksuptounlock

PushhingelocksdowntolockRest notch on bottom edge

of hinge slot

Notch

Bottom

edge of

slot

Hinge arm

CARE AND CLEANING: Oven Door

The door is very heavy. Be careful when removing and lifting the door. Do not lift door by the handle.

Removing the Door:

1. Fullyopentheovendoor.

2. On each hinge, slide the hinge lock up, making sure it

snaps into its fully raised position.

3. Firmly grasp both sides of the door near the handle.

4. Close the door until the top of the door is

approximately 3” from the range frame.

5. Lift door up and away from the range until both hinge

arms are clear of the slots in the range frame.

Replacing the Door:

1. Firmlygraspbothsidesofthedoornearthehandle.

2. With the door at the same angle as the removal

position, rest the notch in the bottom of the left hinge

arm on the bottom edge of the left hinge slot. The

notch in the hinge arm must be fully seated onto the

bottom of the slot. Repeat for the right side.

3. Fully open the door. If the door will not fully open, the

hinge arms are not seated correctly. Lift the door off

the range and repeat Step 2.

4. Pushthehingelocksdowntothelockedposition.

5. Close the oven door.

Pullhingelocksuptounlock

Notch

Pushhingelocksdowntolock

Removal position

24 49-2000316 Rev. 8

Problem

Possible Cause What To Do

My new oven doesn't

cook like my old one.

Is something wrong

with the temperature

settings?

Your new oven has a different cooking system

from your old oven and therefore may cook

differently than your old oven.

For the first few uses, follow your recipe times and

temperatures carefully and use rack positions recommended in

the Cooking Guide. If you still think your new oven is too hot or

too cold, you can adjust the temperature yourself to meet your

specific cooking preference. See the Oven Controls section.

Food does not bake

properly

Oven controls improperly set. See the Cooking Modes section.

Rack position is incorrect or rack is not level. See the Cooking Modes section and Cooking Guide.

Incorrect cookware or cookware of improper

size being used.

See the Cookware section.

Oven temperature needs adjustment. See the Oven Controls section.

Food does not broil

properly

Oven controls improperly set. Make sure you select the appropriate broil mode.

Improper rack position being used. See Cooking Guide for rack location suggestions.

Cookware not suited for broiling. Useapanspecificallydesignedforbroiling.

Aluminum foil on the broil pan has not been

fitted properly or slit to drain grease.

If using aluminum foil on broil pan, wrap tightly and add slits

conforming to those in the pan to allow grease to drain.

Oven temperature

too hot or too cold

Oven temperature needs adjustment. See the Oven Controls section.

Oven and/or display

appears not to work

A fuse in your home may be blown or the circuit

breaker tripped.

Replace the fuse or reset the circuit breaker.

Oven controls improperly set. SeetheUsingtheOvensection.

A single bracket "]" shows in the display. PressBake and Broil pads at the same time and hold for

threeseconds."SF"willappearinhedisplay.PresstheSet

Clock pad or the Cook Time pad until "On" appears in the

display and then press Start. The display will change from a

single bracket "]" to the time of day.

The clock is turned off. See the Oven Controls or Special Features section.

“Crackling” or

“popping” sound

This is the sound of the metal heating and cooling

during both the cooking and cleaning functions.

This is normal.

Why is my range

making a "clicking"

noise when using

my oven?

Your range has been designed to maintain a

tighter control over your oven's temperature.

You may hear your oven's heating elements

"click" on and off more frequently than in older

ovens to achieve better results during baking,

broiling, and self-clean cycles.

This is normal.

Clock and timer do

not work

A fuse in your home may be blown or the circuit

breaker tripped.

Replace the fuse or reset the circuit breaker.

Sometimes the oven

takes longer to

preheat to the same

temperature

Cookware,food,and/ornumberofracksin

oven.

Cookware, food, and racks in the oven will cause

differences in preheat times. Remove excess items to

reduce preheat time.

Oven light does not

work

Light bulb is loose or defective. Tighten or replace bulb. See the Maintenance section for

instructions on how to replace the bulb.

Oven will not self-

clean

The temperature is too high to set a self-clean

operation.

Allow the oven to cool and reset the controls.

Oven controls improperly set. See the Care and Cleaning section.

Excessive smoking

during clean cycle

Excessive soil or grease. Turn the Oven Temperature Knob to OFF. Wait until the

Oven cools below the unlocking temperature. Open the

windows to rid the room of smoke. Wipe up the excess soil

and reset the clean cycle.

Oven not clean after

a clean cycle

Oven controls improperly set. See the Care and Cleaning section.

Oven was heavily soiled. Clean up heavy spillovers before starting the clean cycle.

Heavily soiled ovens may need to self-clean again.

Strong “burning” or

“oily” odor emitting

from the vent

This is normal in a new oven and will disappear

in time.

To speed the process, set a self-clean cycle. See the Care

and Cleaning section. This is temporary.

Troubleshooting Tips ... Before you call for service

Save time and money! Review the charts on the following pages first and you may not need to call for service.

TROUBLESHOOTING TIPS

49-2000316 Rev. 8 25

Troubleshooting Tips ... Before you call for service

TROUBLESHOOTING TIPS

Problem Possible Cause What To Do

Excessive smoking

during broiling

Food too close to burner element. Lower the rack position of the food.

Oven door will not open

when you want to cook.

The oven door is locked because the

temperature inside the oven has not

dropped below the locking temperature.

Allow the oven to cool below the locking temperature.

"LOCK DOOR" flashes

in the display

The self-clean or steam-clean cycle has

been selected but the door is not locked.

Lock the oven door.

“F— and a number

or letter” flash in the

display

You have a function error code. PresstheCancel/Off pad. Allow the oven to cool for one

hour.Puttheovenbackintooperation.Ifthefunctioncode

repeats,disconnectallpowertotheovenforatleast30

seconds and then reconnect power. If the function error code

repeats again, call for service.

Clock flashes due to a

power outage

Poweroutageorsurge Reset the clock. If the oven was in use, you must reset it by

pressing the Cancel/Off pad, setting the clock and resetting

any cooking function.

Lock Controls or

Control Lockout feature

is activated

If LOC ON appears in the display, the range control is locked.

Turn this feature off to use the range. See the Oven Controls

section.

Burners do not light Plugonrangeisnotcompletelyinsertedin

the electrical outlet.

Make sure electrical plug is plugged into a live, properly

grounded outlet.

Gas supply not connected or turned on. See the Installation Instructions that came with your range.

A fuse in your home may be blown or the

circuit breaker tripped.

Replace the fuse or reset the circuit breaker.

Burner parts not replaced correctly. See the Care and Cleaning of the range section.

Burner slots near the electrode, or the

round lighter port on the oval burner, may

be clogged.

Remove the burners and clean them. Check the electrode

area for burned-on food or grease. See the Care and

Cleaning of the range section.

Food residue on electrode Lightly polish flat tip of electrode with nail file or sandpaper

until shiny.

Top burners do not

burn evenly

Improper burner assembly. Make sure the burner caps are seated correctly. See the

Care and Cleaning of the range section.

Burner slots on the side of the burner may

be clogged.

Remove the burners for cleaning. See the Care and Cleaning

of the range section.

Burner flames are very

large or yellow

Improper air to gas ratio. IfrangeisconnectedtoPropanegas,contactthetechnician

who installed your range or made the conversion.

Surface burners light

but bake and broil

burners do not.

Gas to the oven burners may have been

shut off.

The oven gas shut-off is located on the gas regulator near the

gas line attachment to your range. Locate it and flip the lever.

My oven door glass

appears to be "tinted"

or have a "rainbow"

color.

The inner oven glass is coated with a heat

barrier to reflect the heat back into the

oven to prevent heat loss and keep the

outer door cool while baking.

Thisisnormal.Undercertainlightorangles,youmaysee

this tint or rainbow color.

Drawer does not slide

smoothly or drags

The drawer is out of alignment. Fully extend the drawer and push it all the way in. See the

Care and Cleaning of the range section.

Drawer is over-loaded or load is

unbalanced.

Reduce weight or redistribute drawer contents.

Lever is

shown closed.

PULLTOOPEN.

Sealed burner models

26 49-2000316 Rev. 8

Stapleyourreceipthere.Proofoftheoriginalpurchase

date is needed to obtain service under the warranty.

LIMITED WARRANTY

GE Appliances Gas Range Limited Warranty

GEAppliances.com

All warranty service is provided by our Factory Service Centers, or an authorized Customer Care

technician. To schedule

service online, visit us at GEAppliances.com/service,orcallGEAppliancesat800.GE.CARES(800.432.2737).Please

have your serial number and your model number available when calling for service.

Servicing your appliance may require the use of the onboard data port for diagnostics. This gives a GE Appliances factory

service technician the ability to quickly diagnose any issues with your appliance and helps GE Appliances improve its

products by providing GE Appliances with information on your appliance. If you do not want your appliance data to be

sent to GE Appliances, please advise your technician not to submit the data to GE Appliances at the time of service.

What GE Appliances will not cover:

■ Service trips to your home to teach you how to use

the product.

■ Improperinstallation,delivery,ormaintenance.

■ Failureoftheproductifitisabused,misused,

modified, or used for other than the intended purpose

or used commercially.

■ Replacementofhousefusesorresettingofcircuit

breakers.

■ Damagetotheproductcausedbyaccident,fire,

floods, or acts of God.

■ Damagetofinish,suchassurfacerust,tarnish,or

small blemishes not reported within 48 hours of

delivery.

■ Incidentalorconsequentialdamagecausedby

possible defects with this appliance.

■ Damagecausedafterdelivery.

■ Productnotaccessibletoproviderequiredservice.

■ Servicetorepairorreplacelightbulbs,exceptforLED

lamps.

EXCLUSION OF IMPLIED WARRANTIES

Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties,

including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or

the shortest period allowed by law.

This limited warranty is extended to the original purchaser and any succeeding owner for products purchased for

homeusewithintheUSA.IftheproductislocatedinanareawhereservicebyaGEAppliancesAuthorizedServicer

is not available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized

GE Appliances Service location for service. In Alaska, the limited warranty excludes the cost of shipping or service

calls to your home.

Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty

gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your

legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.

Warrantor: GE Appliances, a Haier company

Louisville,KY40225

Extended Warranties:PurchaseaGEAppliancesextendedwarrantyandlearnaboutspecialdiscountsthatare

available while your warranty is still in effect. You can purchase it online anytime at

GEAppliances.com/extended-warranty

orcall800.626.2224duringnormalbusinesshours.GEAppliancesServicewillstillbethereafteryourwarrantyexpires.

For the period of GE Appliances will replace

One year

From the date

of the original

purchase

Any part of the range which fails due to a defect in materials or workmanship. During this

limited one-year warranty, GE Appliances will provide, free of charge, all labor and in-home

service to replace the defective part.

49-2000316 Rev. 8 27

ACCESSORIES

Looking For Something More?

GE Appliances offers a variety of accessories to

improve your cooking and maintenance experiences!

Refer to the Consumer Support page for phone numbers

and website information.

The following products and more are available:

Accessories

Nickel Flat Rack

Reinforced Nickel Flat Rack

Self Clean Flat Rack

Nickel Extension Rack

Self Clean Extension Rack

 BroilerPan(12¾”x1¼”x16½“)

Roasting Rack Accessory

Cooktop Center Grate

Nonstick Aluminum Griddle

Reversible Cast-Iron Griddle

Cleaning Supplies

CitruShine™ Stainless Steel Wipes

 StainlessSteelPolishingCloth

Burnt-On Grease Remover

28 49-2000316 Rev. 8

PrintedinMexico

Consumer Support

CONSUMER SUPPORT

GE Appliances Website

Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day

of the year! You can also shop for more great GE Appliances products and take advantage of all our on-line support

servicesdesignedforyourconvenience.IntheUS:GEAppliances.com

communication and prompt service under the terms of your warranty, should the need arise. You may also mail in

thepre-printedregistrationcardincludedinthepackingmaterial.IntheUS:GEAppliances.com/register

Schedule Service

Expert GE Appliances repair service is only one step away from your door. Get on-line and schedule your service at

yourconvenienceanydayoftheyear.IntheUS:GEAppliances.com/service

orcall800.432.2737duringnormalbusinesshours.

Extended Warranties

PurchaseaGEAppliancesextendedwarrantyandlearnaboutspecialdiscountsthatareavailablewhileyour

warranty is still in effect. You can purchase it on-line anytime. GE Appliances Services will still be there after your

warrantyexpires.IntheUS:GEAppliances.com/extended-warranty

orcall800.626.2224duringnormalbusinesshours.

Remote Connectivity

Forassistancewithwirelessnetworkconnectivity(formodelswithremoteenable),

visit our website at GEAppliances.com/connect orcall800.220.6899intheUS.

Parts and Accessories

Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes

(VISA,MasterCardandDiscovercardsareaccepted).Orderon-linetoday24hourseveryday.

IntheUS:GEApplianceparts.com or by phone at 877.959.8688 during normal business hours.

Instructions contained in this manual cover procedures to be performed by any user. Other servicing

generally should be referred to qualified service personnel. Caution must be exercised, since improper

servicing may cause unsafe operation.

If you are not satisfied with the service you receive from GE Appliances, contact us on our Website with all the

details including your phone number, or write to:

IntheUS:GeneralManager,CustomerRelations|GEAppliances,AppliancePark|Louisville,KY40225

GEAppliances.com/contact

GE JGBS66REK6SS 30" Free-standing Gas Range

Product's Documents

Owner's Manual

Specifications

GE - General Electric JGBS66REK6SS Questions and Answers
