Box Content
Solar Panel Screw Kit
Drill Template Quick Start Guide
Installation
CAUTION: As an alternative charging equipment, the power amount generated by this solar
panel may be affected by its actual surrounding environment, mainly the intensity of sunlight
and the time length of illumination. If the battery camera is running out of power soon, please
bear in mind that this solar panel alone cannot ensure the camera remains in working status.
1
Installation Location
Please install the solar panel in the place with the longest sunshine time throughout the year,
and choose a suitable wall or at surface for installation.
2
Installation Steps
Drill holes and install
expansion bolts.
Tighten the at washer,
spring washer and screw
nut.
Place the drill template onto the surface
you have chosen to install the solar
panel.
When drilling holes for expansion bolts, please make sure that the diameter of the drill head is
10mm to 11mm, and that the hole depth is 45mm to 55mm.
3
Adjust Angle
Loosen the screws on both sides of the panel, adjust the angle of the solar panel to make it
exposed to direct sunlight and then re-tighten the screws on both sides.
2
Tighten the screws on both
sides after adjusting the panel.
• Please do not place the solar panel completely parallel to the ground.
• Recommended angle: 25°-40°, as shown below.
25°-40°
4
Connect Camera
Remove the waterproof endcap on the cable port according to the label, then connect it to the
battery camera.
• Please keep the removed waterproof endcap properly.
• Please do not remove the waterproof endcap on the unused cable port.
• The solar panel cannot be covered, otherwise the photoelectric conversion of solar energy
will be greatly affected.
• Please clean the solar panel regularly to remove dust and other dirt.
For detailed information, please visit www.ezvizlife.com.
