Operating Instructions
Unheated 7 Bar Ladder Towel Rail
For Model: CDBTR7NH
READ THESE INSTRUCTIONS CAREFULLY.
Keep them handy for future reference.
▪ DO NOT use this appliance for any purpose other than its intended use.
▪WARNING: In order to avoid a hazard for young children, this appliance must be installed
so that the bottom rail is at least 300mm above the floor.
SPECIFICATIONS
Height: 800mm
Width: 630mm
Depth: 112mm
Colour: Stainless Steel
Safety Information
Installation
Mounting:
Please note: This towel rail should be installed by a professional.
Please read the safety information on the previous page carefully before mounting.
Check mounting hardware in kit provided
1. 4 x Legs
2. 4 x Grub screws
(Already fitted to legs)
3. 4x Mounting Bush
4. 4 x Long Screws
(For Wall mounting)
5. 4 x Wall Plugs
6. 4 x short screws
7. 1 x Allen Key
Dimensions
1. As shown in the picture, screw the short screw (6) through the
hole of sheet metal of the bracket (1).
2. Use the short screw (6) to fix the bracket onto the metal pad of
the vertical tube.
3. Screw down the short screw (6) by a screwdriver. Note that the
hole of the bracket (1) should towards the floor when the towel
rail is wall mounted.
4. Fix the other three brackets (1) to the vertical tubes by
repeating step 1 to 3.
5. Use a tape measure to measure the distance between the
centres of the four brackets and note them as A,B,C and D.
6. Mark the wall to correspond with the bracket measurements A,
B, C, D.The towel should be installed at least 300mm above floor
level.
7. Drill A, B, C, D holes
Installation cont.
8. Use hammer to knock plastic expander (5) into wall completely.
9. Insert long screw (4) through bush (3), then screw into plastic
expander (5).
10. Install the bracket onto the bush (3).
11. As shown in the picture, screw the grub screw (2) into the hole of
the bracket (1) by hexagonal spanner; fix the bracket (1) onto the
bush (3).
12. Fix the rest three brackets by repeating step11. The installation is
finished. Then wipe the tubs cleanly
Installation cont.
Goldair – New Zealand
Monday – Friday 8am-5pm
Phone +64 (0)9 917 4000
Phone 0800 232 633
Goldair – Australia
Monday – Friday 8am-5pm
Phone +61 (0)3 9336 4423
Phone 1300 465 324
info@cdbgoldair.com.au
SUPPORT AND TECHNICAL ADVICE
CLEANING
The Towel Rail requires regular cleaning to ensure longevity of the product.
Use a damp cloth (not wet) to wipe the exterior of the towel rail to remove dust and dirt
DO NOT USE ANY ABRASIVE OR CORROSIVE CLEANERS.
Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when
used in normal domestic use for a period of two years. In non-domestic use Goldair limits the voluntary warranty
to three months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing
fault during the warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried
out by anyone other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in
relation to the goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act
(1993).
Two Year Warranty
Goldair Two Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date Of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
