1
SmartRack
®
Enclosures
(Series Numbers: AG-039A, AGAC7006, AGAC7761,
AG-0324, AG-00BE, AG-0325, AGAC7454, AG-0534, AG-0535, AG-0536, AG-076F)
Owner’s Manual
Important Safety Instructions 2
Overview 3
Feature Identification 4
Enclosure Installation 5
Preparation 5
Unpacking 5
Placement 6
Leveling 7
Ground Connection 7
Enclosure Configuration 8
Adding or Removing Front and Rear Doors 8
Reversing Front Door 8
Adding or Removing Roof Panel 10
Adding or Removing Side Panels 10
Adjusting Mounting Rails and Cable Management Rails 11
Combining (Baying) Enclosures 12
Equipment Installation 12
Installing or Removing Cage Nuts 13
Specifications 14
Storage and Service 16
Warranty and Product Registration 16
Español 17
Français 33
Русский
49
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2023 Tripp Lite. All rights reserved.
