MONITOR
MAG342CQPV
SEE BEYOND THE GAME. VISUALIZE YOUR VICTORY.
© 2022 Micro-Star Int'l Co.Ltd. MSI is a registered trademark of Micro-Star Int'l Co.Ltd. All rights reserved.
SPECIFICATIONS
Panel Size 34" (86.36 cm)
Panel Resolution 3440 x 1440 (UWQHD)
Refresh Rate 100Hz
Response time 1ms(MPRT)
Panel Type VA
Brightness (nits) 250
Viewing Angle 178°(H)/178°(V)
Aspect Ratio 21:9
Curvature 1500R
Contrast Ratio 3000:1
Active Display Area (mm) 797.184 (H) x 333.72 (V)
Pixel Pitch (H x V) 0.23175(H) x 0.23175 (V)
Surface Treatment Anti-glare
Display Colors 1.07B(8bit+FRC)
DCI-P3 / sRGB 86%/115%
Video ports
1x DP(Supports 3440 x 1440@100Hz as
specified in DisplayPort 1.2a)
1x HDMI(Supports 3440 x 1440@100Hz
as specified in HDMI1.4b)
1x HDMI(Supports 3440 x 1440@100Hz
as specified in HDMI2.0b)
Audio ports 1 x Earphone out
Kensington Lock Yes
VESA Mounting 75 x 75 mm
Power Type External Adaptor 19V 3.42A
Power Input 100~240V, 50~60Hz
DYNAMIC REFRESH RATE
TECHNOLOGY
Adaptive-Sync
DCR 100000000:1
Signal Frequency
58.56 to 148.1KHz(H)
48 to 100Hz(V)
Adjustment (Tilt) -5° ~ 20°
Adjustment (Swivel) -30° ~ 30°
Adjustment (Pivot) -5° ~ 5°
Adjustment (Height) 0 - 90mm
Dimension (W x H x D)
810 x 270 x 510 mm / 31.89 x 10.63 x
20.08 inch
Carton Dimension (W X H X D)
910 x 210 x 485 mm / 35.83 x 8.27 x
19.09 inch
FEATURES
MONITOR
MAG342CQPV
SEE BEYOND THE GAME. VISUALIZE YOUR VICTORY.
© 2022 Micro-Star Int'l Co.Ltd. MSI is a registered trademark of Micro-Star Int'l Co.Ltd. All rights reserved.
Weight (NW / GW)
6.91 kg / 9.36 kg
15.24 lbs / 20.64 lbs
Frameless Design Yes
Console Mode
2K Resolution PS5™ Optimization
* All trademarks and the registered
trademarks are the property of their
respective owners.
Compatibility
PC, Mac, PS5™, PS4™, Xbox, Mobile,
Notebook
* All trademarks and the registered
trademarks are the property of their
respective owners.
Note
Display Port: 3440 x 1440 (Up to 100Hz)
HDMI: 3440 x 1440 (Up to 100Hz)
sRGB and DCI-P3 follow CIE1976
standrard
CONNECTIONS
1. 1x HDMI 2.0
2. 1x HDMI 2.0
3. 1x Display Port 1.2a
4. 1x DC Jack
5. 1x Earphone out
Generated 2022-05-27, check for the latest version www.msi.com/datasheet. The information provided in this document is intended for informational purposes only and is subject to change without notice.
