RCA RCTC4GB 4 Device Universal Remote Control Streaming, User Manual

RCTC4GB

Universal Remote Control

Owner’s Manual

Manual del Propietario (parte posterior)

RCTC4GB US 00 R341U1

Battery Saver

Your remote control saves charge by

automatically turning off if any key is

pressed for more than 15 seconds. This

saves your charge should your remote get

stuck in a place where the keys remain

depressed, such as between sofa cushions.

Before you start using the remote, it’s

a good idea to charge it completely.

To charge the remote:

1. Plug the charging cable into

the charging jack on the back/

bottom of the remote.

2. Plug the other end into a USB

power source. The red charging

indicator illuminates. The green

indicator illuminates when the

remote is fully charged.

Step 1: Charge the remote

Step 2: Program your remote

To use this remote with your streaming player and TV, rst you

need to program it to control your devices. There are three ways

you can program the remote to operate your devices. Try them in

the order listed.

• The Direct Code Entry lets you enter a code from the

accompanying code list for your brand of device.

• The Auto Code Search: Top Brands searches through the

codes for select brands of devices.

• The Auto Code Search: All Brands goes automatically through

all the codes for the device you’re trying to control.

IMPORTANT!

This remote is already programmed to operate most Samsung

TVs, DVD and Blu Ray players, Roku streaming players, and

Comcast cable boxes. Just press the corresponding key—

DVD/B RAY for a DVD or Blu Ray player, TV for a television,

SATELLITE/CABLE for a satellite receiver, or STREAM for a

streaming player.

This remote also supports control of CEC enabled RF devices,

like the Amazon Fire TV Stick, Google Chromecast, and Roku

Stick, via HDMI CEC connection. For this control you don’t

need to program the remote for the RF device, just for the TV.

Consult your TV’s owner’s manual for instructions on enabling

HDMI CEC control.

Direct Code Entry

Direct Code Entry lets you enter a code from the accompanying

code list for your brand of device.

1. Manually turn on the device you want

to control.

3. Press and hold the device key you

want to program for about 2 seconds,

until the POWER key illuminates and

stays on. Then release the key.

2. Find the Code List that came with

the remote. Locate the section for

the type of device you’re trying to

program, and nd your brand in that

section. Circle the codes for your

brand and keep them handy.

4. Enter the rst ve-digit code for your

brand in the code list (the POWER key

ashes after each digit).

NOTES

Test the remote with the device to make sure the device key is

programmed with the correct code for maximum functionality.

If some features don’t work, try a different code in the list.

Remember to enter the code for future reference in the box

provided in the Code Retrieval section of this manual.

If your brand isn’t listed in the code list, use the Auto Code

Search method to program the remote control.

NO, it’s still illuminated: You have either entered a code number

that is not in the code lists or missed a step in the code entry

procedure. Try step 4 again.

5. When you’ve nished entering the

ve-digit code, look at the POWER

key.

Did the POWER key turn off?

YES: You’re done! You’ve

programmed this device key.

Auto Code Search: Top Brands

This search goes automatically through all device codes for the

select brands listed below. If your brand of device is listed, this

search can be quick and easy.

APEX, ELEMENT, EMERSON, HAIER, HISENSE, HITACHI,

INSIGNIA, JVC, LG, MAGNAVOX, MITSUBISHI, OLEVIA,

ONN, PHILIPS, PHILIPS-MAGNAVOX, PIONEER, POLAROID,

PROSCAN, RCA, ROKU TV, SAMSUNG, SANSUI, SANYO,

SCEPTRE, SEIKI, SHARP, SKYWORTH, SONY, SUNBRITE TV,

SYLVANIA, TCL, TOSHIBA, VIZIO, WESTINGHOUSE

STREAM

ALTICE, APPLE TV, ASUS, AT&T, BOXEE, CHANNEL MASTER,

DIGITAL STREAM, D-LINK, IVIEW, LETV, LG, MAGNAVOX,

MICCA, NETGEAR, NVIDIA, ONN, PHILIPS, RCA, ROKU,

SAMSUNG, SHARP, SLING, SONY, TIVO, UNBLOCK TECH,

VANKYO, VIZIO, WD (WESTERN DIGITAL), XBOX, XIAOMI,

XTREAMER

SAT-CBL

ADELPHIA, AMINO, ARRIS, AT&T, BELL, CABLE

ONE, CABLEVISION, CHANNEL MASTER, CHARTER

COMMUNICATIONS, CHARTER DIGITAL, CISCO, COMCAST/

XFINITY, CONSOLIDATED COMMUNICATIONS, COX,

DIRECTV, DISH NETWORK, ENTONE, HOMEWORX, HUMAX,

MEDIACOM, MOTOROLA, OPTIMUM, PACE, SAMSUNG,

SCIENTIFIC ATLANTA, SHAW, SKY NETWORK, SONY,

SPECTRUM, SUDDEN LINK, TIVO, UNIVERSAL, VERIZON

DVD-BLURAY

BLACK WEB, DENON, FUNAI, HITACHI, INSIGNIA, JVC,

LG, MAGNAVOX, MEMOREX, ONKYO, ONN, OPPO,

PANASONIC, PHILIPS, PHILIPS-MAGNAVOX, PIONEER, RCA,

SAMSUNG, SANYO, SHARP, SONY, SYLVANIA, TOSHIBA,

VIZIO

PROJECTOR

3M, BENQ, EPSON, LG, MITSUBISHI, NEC, OPTOMA,

PANASONIC, SONY, VIEWSONIC

VCR

HITACHI, JVC, MAGNAVOX, PHILIPS, RCA, SAMSUNG,

SANSUI, SANYO, SHARP, SONY, YAMAHA

3. Manually turn on the device you want to

control.

1. Press and hold the device key you want

to program for about 2 seconds, until

the POWER key illuminates and stays

on. Then release the key.

2. Enter the ve-digit device code for your

device you want to operate.

11111 TV

22222 VCR

33333 Streaming Player

44444 Satellite Receiver,

Cable Box, Digital TV Converter

55555 DVD / Blu Ray Player

88888 Projector

The POWER key ashes after the rst four digits and turns off

after the fth.

4. Press and hold the device key you want

to program for 2 seconds, until the

POWER key illuminates and stays on.

Then release the key.

5. Point the remote directly at the front panel

of the device you want to control. Press

POWER on the remote.

The remote starts sending the on/off

command for a new code every 2 seconds.

When your device turns off:

Press the key to store the code. You’re

done! You’ve programmed this device key.

If your device turns off but you waited more than 2 seconds:

Press the

key to go backwards through the last few codes.

When your device turns back on again, press

to store that

code.

Testing the Code for Maximum Functionality

1. Try a variety of the device’s functions with the remote. If

some device features don’t work, go to the next step to try a

different code.

2. Repeat the Code Search from step 3.

3. Test the key’s functionality again by attempting to control

a variety of the device’s functions. If the code that has

been stored controls the majority of the device’s functions,

programming is complete. If the code stored does not give

maximum functionality, try another code.

NOTES

Throughout the programming of each key, be sure to keep the

remote pointed at the IR sensor of the device you are currently

programming the remote to control.

Test the remote with the device to make sure the device key is

programmed with the correct code for maximum functionality.

If some features don’t work, try a different code. See the

“Testing the Code for Maximum Functionality” section below

for more information.

Auto Code Search: All Brands

This search goes automatically through all the codes for the device

you’re trying to control. When you nd the one that operates your

device, you can stop the search and store that code.

1. Press and hold the device key you want

to program for about 2 seconds, until

the POWER key illuminates and stays on.

Then release the key.

5. Point the remote directly at the front panel of the device you

want to control. Press

on the remote.

The remote starts sending the on/off command for a new code

every 2 seconds.

When your device turns off:

Press the

key to store the code. You’re done! You’ve

programmed this device key.

If your device turns off but you waited more than 2 seconds:

Press the

key to go backwards through the last few codes.

When your device turns back on again, press

to store that

code.

3. Manually turn on the device you want to

control.

2. Enter the ve-digit device code for your

device you want to operate.

11111 TV

22222 VCR

33333 Streaming Player

44444 Satellite Receiver, Cable

Box, Digital TV Converter

55555 DVD / Blu Ray Player

88888 Projector

The POWER key ashes after the rst four digits and turns off

after the fth.

4. Press and hold the device key you

want to program for about 2 seconds,

until the POWER key illuminates. Then

release the key.

Testing the Code for Maximum Functionality

1. Try a variety of the device’s functions with the remote. If

some device features don’t work, go to the next step to try a

different code.

2. Repeat the search from step 3.

3. Test the key’s functionality again by attempting to control

a variety of the device’s functions. If the code that has

been stored controls the majority of the device’s functions,

programming is complete. If the code stored does not give

maximum functionality, try another code.

NOTES

Throughout the programming of each key, be sure to keep the

remote pointed at the IR sensor of the device you are currently

programming the remote to control.

Test the remote with the device to make sure the device key is

programmed with the correct code for maximum functionality.

If some features don’t work, try a different code. See the

“Testing the Code for Maximum Functionality” section below

for more information.

Tour of the Remote

In most cases, the keys on this remote perform the same functions

as the keys on your original remotes once you’ve programmed this

remote to operate your components. Many keys on this remote have

other functions as well.

Actual model may

vary from illustration

Illuminated POWER key serves as an

indicator light to provide feedback.

Device keys (TV, SATELLITE/CABLE,

STREAM, DVD/B RAY) put the

remote in the right mode to control

your device.

MENU and

access device menu

and information screens.

controls Samsung Hub functionality

on TVs. It may also control similar

functionality on other devices (see your

device manual for information).

EXIT exits remote programming; it

also performs the same functions as on

your original remotes.

puts the remote in guide mode

for satellite receivers or cable boxes,

and accesses the home screen for

streaming players.

Arrow keys and OK act as navigation

and selection keys in device guides

and menu systems.

The INPUT — (dash) key has three

functions: (1) it toggles through all the

video sources connected to your TV;

(2) when the remote is in VCR mode,

this button toggles between VCR and

the TV input; (3) when you’re entering

digital channel numbers directly, this

button lets you separate the main

channel number from the sub-channel

number (like 59.1).

, , , and provide direct access

to Netix, Disney+, Hulu, and YouTube

if supported by your streaming player

or smart TV. These keys also provide

additional functionality on other

components and can execute macro

functions if programmed (see the

Shortcut / Macro Keys section).

Backlight key (

) turns backlighting

on/off.

IMPORTANT

The shortcut keys mimic the functionality of your device’s original

remote — for example, if the original remote that came with your

SmartTV doesn’t have a YouTube key, chances are this remote’s

YouTube key will not automatically give you direct access to

YouTube on your SmartTV. You can, however, set up a macro on

that key to perform this function. See the Shortcut / Macro Keys

section for more information.

Because this remote controls more than one device, you must rst

“tell” the remote which device you wish to operate. That means,

if you wish to operate your TV, you must rst press the TV key to

put the remote in the TV Mode. The remote stays in that device

mode until you press a different device key. For example, if your

remote is in TV Mode and you want to operate the DVD player,

you must press the DVD/B RAY key to change device modes.

Advanced Functions

Shortcut/Macro Keys

The , , , and keys have different functions depending on

the device you’re controlling and whether you press or press and

hold them.

Press

Press & Hold

(2+ seconds)

SmartTV,

Streaming Player

(if supported)

DVD/Bluray,

Satellite/Cable

(if supported)

Netix red key

Macro 1

Disney+ blue key Macro 2

Hulu green key

Macro 3

YouTube yellow key

Macro 4

Setting Up Macros

Macros are multi-step functions you can program to a single

keypress, like accessing a streaming service directly if your

streaming player or TV doesn’t support hot keys.

To set up a macro:

1. Press and hold the device key for the device you want to use

the macro on. (For example, press and hold the TV key to

program a macro for TV.) The POWER key illuminates.

Note: Each macro works for a single device only.

2. Press the App key you want to use to store the macro. The

POWER key blinks and stays illuminated.

3. Press the keys you want in the order you want for the macro.

(For example, to access a streaming service on your TV, press

, then use the arrow keys to highlight the service, and press

OK). Note: Each App key can store a maximum of 14 macro

steps overall.

4. Press the App key again to store the macro. The POWER key

turns off.

To use the macro: Make sure you’re in the right device mode.

Then press and hold the App key storing the macro.

To turn channel lock on:

1. Press and hold the device key you want to use to change

channels for about 2 seconds until the POWER key illuminates.

Then release the device key.

2. Press the CH + key once. The POWER key ashes once and

remains on.

3. Press OK to lock channel commands to this device. The

POWER key ashes twice and turns off.

To turn channel lock off:

1. Press any device key for about 2 seconds until the POWER key

illuminates. Then release device key.

2. Press the CH — key once. The POWER key ashes once and

remains on.

3. Press OK to unlock channel commands. The POWER key

ashes twice and turns off.

TV Volume Lock

TV Volume Lock allows the VOL and keys, when pressed in

SATELLITE/CABLE, STREAM, or DVD/B RAY modes, to go directly

to your TV. TV Volume Lock occurs automatically and allows you to

control the volume without exiting the current mode.

Note: TV Volume Lock does not occur in cases where the

component code has its own volume/mute controls, such as

some satellite receivers.

Code Retrieval

If you used one of the Code Search methods to program your

remote or if you used the Direct Entry method but don’t remember

the code you used, you can retrieve each device’s ve-digit code

and write it down for reference below.

1. Press and hold the device key (TV, SATELLITE/CABLE,

STREAM, DVD/B RAY) whose code you wish to retrieve for

about 2 seconds until the POWER key illuminates and stays

on. Then release device key.

2. Press the MENU key. The POWER key ashes once and

remains illuminated.

3. To retrieve the rst number in the code, press the 1 key on the

remote. The POWER key blinks to show the number that is the

rst digit in the code. For example, if the POWER key blinks 3

times when you press the 1 key, the rst number in the code is

3. Write this number in the corresponding box below.

Repeat for each number in the code—press 2 to see the

second number in the code, 3 for the third, and so on until you

have all 5.

4. Press MENU to exit code retrieval.

TIP: To exit the Code Retrieval Mode at any time, press the

MENU key.

SATELLITE/CABLE CODETV CODE

DVD/B RAY CODESTREAM CODE

Channel Lock

Channel lock automatically sends channel commands, like the

CH and 0–9 number keys, to your satellite receiver, cable box,

or digital TV converter when you’re in TV mode. This can save

you keypresses if you use a device other than your TV to change

channels.

Troubleshooting

Problem: The remote doesn’t perform commands properly.

• Make sure the remote is in the correct mode by pressing the corresponding

device key (TV, SATELLITE/CABLE, STREAM, DVD/B RAY). This tells the remote

which device to operate.

• Make sure device is ready (for example, the DVD player has a disc loaded).

• You may have pressed an invalid key for the mode the remote is in.

• If you’re trying to enter a channel number directly, try pressing the OK key after

entering the channel number as this is a requirement of certain models and

brands.

• Press the OK key after you enter a channel number.

• Remove any obstacles between the remote and the device. Make sure to aim

the remote at the IR sensor on the device.

Problem: The device’s menu does not appear on the TV screen.

• Make sure you have connected the device to your TV properly and selected

the correct input. (See your devices’ Owner’s Manuals for proper connection

procedures.)

• Make sure the remote is in the correct mode by pressing the corresponding

device key (TV, SATELLITE/CABLE, STREAM, DVD/B RAY). This tells the remote

which device to operate.

• Menu access isn’t supported for all brands. You may need to use your original

remote control to access menu functions for some devices.

Problem: The remote’s shortcut/macro keys don’t work as

expected.

• Make sure the remote is in the correct mode by pressing the corresponding

device key (TV, SATELLITE/CABLE, DVD/B RAY, STREAM). This tells the remote

which device to operate.

• The shortcut keys mimic the functionality of your device’s original remote — for

example, if the original remote that came with your SmartTV doesn’t have

a YouTube key, chances are this remote’s YouTube key will not automatically

give you direct access to YouTube on your SmartTV. You can, however, set up

a macro on that key to perform this function. See the Shortcut / Macro Keys

section for more information.

For more information, including instructional videos,

remote programming codes, and customer support, visit

www.RCACodeSupport.com

• The programmed code may only be able to control some of your device

features (for example, only turns a device on and off). To conrm that the device

key is programmed with the correct code for maximum functionality, test the

device. Attempt to control a variety of the device’s functions with the remote. If

some of the features of your devices don’t work, try programming the remote

with a different code in the list using the Direct Code Entry Method, until you

nd the code that allows the remote to control the majority of your device’s

functions. Different codes can provide different levels of functionality.

Problem: The POWER key does not light when you press a key.

• You may have pressed an invalid key for the mode the remote is in.

• Make sure the remote is in the correct mode by pressing the corresponding

device key (TV, SATELLITE/CABLE, STREAM, DVD/B RAY). This tells the remote

which device to operate.

• Make sure the remote is charged. Insert the charging cable into the charging

port on the bottom of the remote. Plug the other end of the cable into a USB

power source, like a computer or USB adapter (not included). The red indicator

on the back of the remote illuminates while the remote is charging. The green

indicator turns on when the remote is fully charged.

Problem: Remote backlighting doesn’t work.

• Press the key to activate backlighting.

• Make sure the remote is charged. Insert the charging cable into the charging

port on the bottom of the remote. Plug the other end of the cable into a

USB power source, like a computer or USB adapter (not included). The red

indicator on the back of the remote illuminates while the remote is charging.

The green indicator turns on when the remote is fully charged.

Problem: The remote will not change channels on device.

• Make sure the remote is in the correct mode by pressing the corresponding

device key (TV, SATELLITE/CABLE, STREAM, DVD/B RAY). This tells the remote

which device to operate.

TO RESET THE REMOTE:

Find the reset port on the back of the

remote, toward the bottom and in the

middle of the back. Unbend a paper clip

and insert it into this hole until you reach

the reset button on the inside of the

remote. Press for 2-3 seconds to reset

the remote. You will need to recharge the

remote and reprogram it to control your devices.

Reset port

Care and Maintenance

• Keep the remote dry. If it gets wet, wipe it dry immediately.

• Use and store the remote only in normal temperature environments.

• Handle the remote gently and carefully. Don’t drop it.

• Keep the remote away from dust and dirt.

• Wipe the remote with a damp cloth occasionally to keep it looking new.

• Modifying or tampering with the remote’s internal devices can cause

malfunction and invalidate its warranty.

Ecology

Your product must be disposed of properly according to local laws and

regulations. Because this product contains a rechargeable battery, the product

must be disposed of separately from the household waste.

Problem: The remote does not operate your device.

• Make sure the remote is in the correct mode by pressing the corresponding

device key (TV, SATELLITE/CABLE, STREAM, DVD/B RAY). This tells the

remote which device to operate.

• Remove any obstacles between the remote and the device. Make sure

you’re aiming the remote at the device’s IR sensor.

• Make sure the remote is charged. Insert the charging cable into the charging

port on the bottom of the remote. Plug the other end of the cable into a

USB power source, like a computer or USB adapter (not included). The red

indicator on the back of the remote illuminates while the remote is charging.

The green indicator turns on when the remote is fully charged.

Problem: The remote can’t be programmed to operate your

device.

• If you are testing the remote while programming it, you may be too far away

from the device or at a wrong angle. There must be an unobstructed path

between the remote and the IR sensor on the device. Move closer and make

sure you point the remote at the device you’re trying to control.

• If you’re using the Direct Entry programming method to enter the codes for

your brand and the unit is still not functioning properly, try one of the automatic

search methods.

• Make sure the remote is charged. Insert the charging cable into the charging

port on the bottom of the remote. Plug the other end of the cable into a USB

power source, like a computer or USB adapter (not included). The red indicator

on the back of the remote illuminates while the remote is charging. The green

indicator turns on when the remote is fully charged.

Voxx Accessories Corporation (the “Company”) warrants to you the original

retail purchaser of this product that should it, under normal use and conditions,

be proven defective in material or workmanship during its lifetime while you

own it, such defect(s) will be repaired or replaced (at the Company’s option)

without charge for parts and repair labor. To obtain repair or replacement within

the terms of the warranty, the product is to be delivered with proof of warranty

coverage (e.g. dated bill of sale), specication of defect(s), transportation

prepaid, to an approved warranty station. For the location of the nearest

warranty station to you, call toll-free to our control ofce: 1-800-645-4994.

This Warranty does not cover product purchased, serviced or used outside

the United States or Canada. This Warranty is not transferable and does

not extend to costs incurred for installation, removal or reinstallation of

the product. This Warranty does not apply if in the Company’s opinion,

the product has been damaged through alteration, improper installation,

mishandling, misuse, neglect, accident, or the simultaneous use of different

battery types (e.g. alkaline, standard or rechargeable). THE EXTENT OF THE

COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR

OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE

COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER

FOR THE PRODUCT.

This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED

WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE SHALL BE LIMITED TO DURATION

OF THIS WARRANTY. IN NO CASE SHALL THE COMPANY BE LIABLE FOR

ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES WHATSOEVER. No

person or representative is authorized to assume for the Company any liability

other than expressed herein in connection with the sale of this product.

Some states/provinces do not allow limitations on how long an implied warranty

lasts or the exclusion or limitation of incidental or consequential damage so the

above limitations or exclusions may not apply to you. This Warranty gives you

specic legal rights and you may also have other rights, which vary from state/

province to state/province.

Limited Lifetime Warranty

FCC Statement:

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including

interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution: Any changes or modications not expressly approved by the party

responsible for compliance could void the user’s authority to operate this

equipment.

ISED Compliance Statement CAN ICES-003(B) / NMB-003(B)
