Model number(s):
RH54FR3FZ146 (B) (S)
For Customer Services & Spare Parts please call 0345 208 8750
or visit us at mda.russellhobbs.com
IMPORTANT:
RETAIN FOR FUTURE REFERENCE
Upright 54cm Wide Freezer
Instruction Manual
- 1 -
Contents
Safety Instructions ………………………………………. 3-5
Electrical Safety ………………………………………. 5
Transportation & Handling ………………………………………. 5
Installing & Switching on your Appliance ………………………………………. 6-7
Before Switching On ………………………………………. 7
Product Overview ………………………………………. 9
Unit & Spare Parts ………………………………………. 9
Usage ………………………………………. 10-11
Temperature Selection ………………………………………. 10
Functions ………………………………………. 11
Door Reversal ………………………………………. 12-14
Energy Saving Advice ………………………………………. 15
Freezer Storage Advice ………………………………………. 15
Power Failure ………………………………………. 16
Food Storage Advice ………………………………………. 17
Maintenance & Cleaning ………………………………………. 18-19
Defrosting ………………………………………. 19
Trouble Shooting ………………………………………. 20-21
Error codes ………………………………………. 22
Connection to the Mains Supply ………………………………………. 23
Guarantee ………………………………………. 24
Technical Specification ………………………………………. 25
Product Fiche ………………………………………. 26
- 2 -
Safety Instructions
Important note: Please read this booklet before installing and switching on this
appliance. The manufacturer assumes no responsibility for incorrect installation
and usage as described in this booklet.
Warning: When positioning the appliance, ensure the supply cord is not
trapped or damaged.
Warning: Do not locate multiple portable socket-outlets or portable power
suppliers at the rear of the appliance.
• This model uses natural refrigerant gas as part of its cooling system. This
gas is known as R600a (Isobutene) and is environmentally friendly but can be
combustible. Care should therefore be taken when handling or transporting the
product to ensure that none of the refrigeration circuit components are
damaged,
• Do not obstruct ventilation openings in the appliance
• The appliance must not be placed or rested on its power cord.
• Do not use mechanical devices or other artificial means to accelerate the
defrosting process, such as a heater or a hair dryer.
• Do not use electrical appliances in the refrigerator compartment of the
appliance.
• If this appliance is to replace an old refrigerator with a lock, the lock must be
removed as a safety measure before storing it or disposing of it. This is to
protect children from locking themselves inside the appliance.
• Old refrigerators and freezers contain insulation gases and refrigerant, they
must be disposed of properly. Contact your local authority or your dealer if
you have any questions. Please ensure that you do not damage the scrap unit
prior to being picked-up by the relevant waste disposal service.
• Do not use adaptors or extension leads when connecting the appliance to the
electrical power supply
- 3 -
• Do not plug in damaged plugs.
• Do not pull, twist or damage the power cable.
• Do not plug-in or un-plug the appliance with wet hands to prevent electrical
shock.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children should not play with the appliance.
• Children aged from 3 to 8 years are allowed to load and unload this appliance.
• This appliance is designed to be used by adults, do not allow children to play
with the appliance or let them hang over the door.
• Do not place explosive or flammable material in your appliance for your own
safety.
• Bottles containing a high percentage of alcohol must be sealed well and placed
vertically in the refrigerator.
• Do not cover the body or the top of the appliance
• Fix down the accessories in the appliance during transportation to prevent
damage to them.
• To avoid contamination of food, please respect the following instructions
• Opening the door for long periods can cause a significant increase of the
temperature in the compartments of the appliance.
• Clean regularly surfaces that can come in contact with food and accessible drainage
systems.
• Store raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
• Two-star frozen-food compartments(if they are presented in the appliance) are
suitable for storing pre-frozen food, storing or making ice-cream and making ice
cubes.
- 4 -
• One-, two- and three -star compartments (if they are presented in the
appliance) are not suitable for the freezing of fresh food.
• If the appliance is left empty for long periods, switch off, defrost, clean,
dry and leave the door open to prevent mount developing within the
appliance.
Electrical Safety
THIS APPLIANCE MUST BE PLUGGED INTO AN EARTHED SOCKET
• Before switching on, make sure that the voltage of your electricity supply is the
same as that indicated on the rating plate. This product is designed to operate
on 220 – 240V AC; 50Hz. Connection to any other power source may damage
the unit.
• This product may be fitted with a non re-wireable plug. If it is necessary to
change the fuse in the plug, the fuse cover must be refitted. If the fuse cover
becomes lost or damaged, the plug must not be used until a suitable
replacement is obtained.
• If the plug has to be changed because it is not suitable for your socket, or
becomes damaged in any way, it should be cut off and an appropriate plug
fitted following the wiring instructions. This should be carried out by a qualified
electrician. The plug removed must be disposed of safely, as insertion into a 13
Amp socket is likely to cause an electrical hazard.
Transportation and Handling
For safe lifting, tilt the appliance backwards by no more than 45 degrees, hold the
base and rear corners of cabinet. Lift the refrigerator carefully. Never use the door
handles for lifting. To move the refrigerator on a flat level surface, tilt it slightly
backwards and push backwards.
This unit is heavy and could cause injury – ensure there are adequate people
present to move the appliance.
- 5 -
Installing and Switching on Your Appliance
• Operating voltage for your appliance is 220-240V at 50Hz.
• Before plugging in the power supply, ensure that the voltage on the rating label
corresponds to the working voltage of your electrical system in your home.
• Insert the plug into an efficient Ground (Earth) connection. If the socket has no
Ground (Earth) contact or the plug does not match, we suggest you call an authorised
electrician for assistance.
• Place your appliance in an area that is not exposed to direct sunlight.
• Your appliance should be placed at least 10cm away from stoves, ovens and other
heating cores.
• This appliance should never be used outdoors or left in the rain.
• When your appliance is placed next to a chest freezer or freezer, there should be at
least 10cms between them to prevent humidity on the outer surface.
• Do not place anything on your appliance and install the unit in a suitable place so that
there is at least 30cm clearance above the appliance.
• If placing your appliance next to kitchen cabinets, leave 5cm between them.
• The rear of the appliance should be at least 6cm away from the back wall.
• The appliance must be used in the vertical position and on a flat surface.
• To level the appliance, use the adjustable feet on the appliance.
• Do not place your appliance on a carpeted surface as this will prevent adequate
ventilation.
• This appliance is not intended to be built-in to worktops or other units, unless
specifically outlined in this instruction manual. All vents must remain clear of
obstruction to ensure safety and performance..
• This appliance should only be placed on a flat, firm surface.
• Choose a dry and well-ventilated space.
• The appliance should be positioned so that the plug is easily accessible.
• Suitable for storage in a garage, outbuilding or shed (can operate in a ambient
temperature up to -15⁰C).
• If you need help or are unsure how to install the unit, please contact Customer
Services on 0345 208 8750 or visit mda.russellhobbs.com.
- 6 -
Before Switching On
• Before using your appliance, add a teaspoon of bicarbonate of soda to warm
water and with a damp cloth wipe down all parts of the new appliance, then
repeat the process with a clean damp cloth and dry. (ensure the appliance is
not connected to the power when performing this task).
• Remove all transport tapes and foam protection pieces . Clean the interior with
a cloth dampened in lukewarm soap and water. Wipe with clean water and
wipe dry.
• There may be an odour when you first switch on the appliance, it will disappear
when the appliance starts to cool.
• Install the plastic distance guide, this is on the condenser pipes (the black pipes)
on the rear of the appliance, by turning it 90° (as shown below) to prevent the
condenser pipes from touching the wall. The distance between the appliance
and back wall must be a minimum of 25mm and a maximum of 75mm.
• When the appliance has been positioned, adjust the feet to ensure the unit is
stable. This is essential to ensure quiet running and proper door opening
/closing.
• Connect to the electrical socket but do not switch the power to the refrigerator
on for at least 3 hours. The coolant within the product needs time to settle after
it has been transported and put in to position, failure to do this will affect the
cooling performance of your appliance.
WARNING! During use, service and disposal of the appliance,
please pay attention to symbol similar to the one shown, which is
located on rear of the appliance (rear panel or compressor) and
with a yellow or orange colour. It’s risk of fire warning symbol.
There are flammable materials in refrigerant pipes and
compressor. Please be far away from fire source during use,
service and disposal.
- 7 -
• Once the appliance has settled, locate the thermostat dial on the product and
set to “-20" position and switch on the power. The compressor will begin to
work. Close the door.
• You may hear faint gurgling or bubbling sounds when the refrigerant is pumped
to the cooling system and through the coils or tubing at the rear of the
appliance. When the compressor is in operation you may hear a slight whirring
sound or pulsating noise. The thermostat controls the operation of the
compressor, and you may hear a slight click as it cycles in and out (this is
normal).
• To save energy, you should minimize the frequency and duration of door
opening.
Vacuum Balancer Fitment Instructions (Optional)
• After closing the doors, a vacuum seal may form that will prevent re-opening of
the doors for around 1 minute. To prevent this, we have included an optional
Vacuum Balancer with your appliance.
• The Vacuum Balancer is a small piece of plastic applied to the bottom of the
freezer by removing the tape attached, and sticking to the lower part of the
freezer as shown below.
- 8 -
Note: The Vacuum
balancer should be
positioned a minimum of
60mm, to a maximum of
100mm from the outside
of the appliance/
Unit Parts & Spare Parts
Before installation, check that all parts detailed in the product overview are
present. If any parts are missing, please contact the Customer Service team on
0345 208 8750 or visit us at mda.russellhobbs.com
Product Overview
1. Temperature control & indicators
2. Freezer flaps (4 star rating)
3. Freezer drawers (4 star rating)
4. Adjustable Feet
5. Ice Cube Tray
6. Vacuum Balancer*
- 9 -
6
*See Vacuum Balancer Fitment instructions on Page 8
The temperature in the appliance is controlled by the temperature control panel
located inside the freezer above the cavity. Press the control buttons to regulate
the temperature inside the freezer.
Plug in the appliance, and the internal lights may not illuminate for 1 minute
whilst start-up tests are performed.
The sequence of the temperature setting is below:
-16 – -18 – -20 – -22 – -24 – SUPER FREEZE
The recommended temperature setting is “-20”.
Once the temperature control has been set, close the door. We recommend that
the door is not opened for a minimum of 4 hours to allow the appliance to reach
the standard operating temperature.
Note: The standard operating temperature for the 4 star freezer compartments
should be between -18°C and -25°C
Allow to stand for a minimum of 3 hours before plugging in to the mains
Usage
1. Temperature Set Button
2. Super Freeze Indicator
3. Alarm Indicator
4. Temperature Indicator
- 10 -
Super Freeze
This function should be used as a rapid cool/freeze setting and is beneficial
when freezing large amounts of food and preventing the loss of nutrients. Set
this function 3 hours before a large amount of food is placed in the freezer. The
temperature control will automatically revert back to its previous setting after a
period of maximum 54 hours.
If required then the temperature can be changed manually by pressing the
“TEMPERATURE SET” button.
Door open warning
If the door of the appliance are open for more than 3 minutes the door open
warning light will flash continuously. Close the door to stop.
Power cut memory
In case of a power failure, when the power is restored the appliance will retain
its settings.
Fault alarm
When the alarm indicator keeps flashing (with the corresponding indicator light
of “-16, -20, -24, or fast freezing” flickering simultaneously), it indicates fault
with the refrigerator. Please contact customer services.
Standby
Set the temperature to -16° and then hold the Temperature Set button until all 3
LED’s start blinking. This will stop normal fridge operation.
To restart the fridge, press and hold the temperature set button. The Door Open
Alarm LED may light up as the appliance is warmer than normal operation. This
will stop once the door is closed and the freezer reaches its operating
temperature.
Usage
- 11 -
Door Reversal
You will need to tilt the appliance backward to access the lower hinge which holds
screws. Do not tilt more than 45 degrees and do not lay the appliance flat on its
side.
For your own safety, a minimum of 2 people should lift or tilt this product.
Tools Required: Cross headed screwdriver, flat headed screwdriver and hexagonal
spanner.
1. Remove the hinge cover and the screws from the hinge bracket, take it off and
remove the door by lifting it up and away.
2. Remove the screw cap covers that are on the top left of the unit and fix them on
to the opposite side.
3. Remove the door bushing & hole cover from the top of freezer door and fix it to
the opposite side.
Screw cap
cover
- 12 -
Door Reversal
4. Tilt the appliance carefully, no more than 45 degrees and remove the adjustable
foot.
5. Take off the bottom hinge by removing the screws and moving the pin.
6. Move the hinge to the opposite side, install and affix feet.
- 13 -
Door Reversal
7. Move the bung on the bottom of the door to the opposite side.
8. Place the door on to the bottom hinge and put the pin of the upper/top hinge
into the top of the door and fix the hinge in to place by screwing it to the top of
the freezer (use a spanner to tighten it if necessary. Ensure the door is aligned
horizontally and vertically so that the seals are closed on all sides before finally
tightening the top hinge.
- 14 -
Energy Saving Advice
• Do not install the appliance close to sources of heat, such as a cooker,
dishwasher or radiator.
• Locate the appliance in a cool well-ventilated room and make sure that the air
vents are clear.
• Try to avoid keeping the doors open for a long time, warm air will enter the
cabinet and may cause a build-up of ice as well as affecting the energy
consumption. Ensure there are no obstructions preventing the doors from
closing properly.
• Ensure that the door seals are clean and there are no tears or splits.
• Do not overload the appliance: the cooling air that circulates to keep the
appliance cold gets blocked and pockets of warm air form.
• Do not put hot food into the freezer – let it cool down first.
Freezer Storage Advice
• Store fresh food in airtight boxes or wrap in bags or foil which are suitable for
freezing.
• Do not allow frozen food into direct contact with food to be frozen.
• Pre-frozen food must be placed in the freezer as quickly as possible after
purchasing.
• To prevent frost damage to fresh vegetables or fruits they must be processed
appropriately before being placed into the freezer compartment.
• You must always follow the storage guidelines printed on all food packaging.
However, below is some suggested maximum storage times at -18°C (4 star
freezer rating) for a variety of foods:
• Fresh meat & poultry – up to 12 months
• Cooked meat – up to 2 months
• Fresh fish – up to 6 months
• Fruit & vegetables – up to 12 months
• Bread & cakes – up to 6 months
- 15 -
Power Failure
If there is a power failure during the storage of frozen foods, keep the door closed.
If the temperature within your freezer should rise, do not refreeze the food
without checking it's condition.
• Ice Cream: Once thawed should be discarded.
• Fruit and Vegetables: If soft should be cooked and used up.
• Bread and Cakes: Can be refrozen without danger.
• Shellfish: Should be refrigerated and used up quickly.
• Cooked Dishes: i.e. casseroles should be refrigerated and used up.
• Large Pieces of Meat: Should be refrigerated and used up quickly
• Small Joints: Should be refrigerated and used up quickly
• Chicken: Should be refrigerated and used up quickly
- 16 -
Refrigerator compartments
Type of food
Freezer drawer(s)/shelf
Foods for long
-term storage.
Bottom drawer/shelf for raw meat, poultry, fish.
Middle drawer/shelf for frozen vegetables, chips.
Top drawer/shelf for ice cream, frozen fruit, frozen
baked goods.
Food Storage Guidelines
- 17 -
Maintenance & Cleaning
Disconnect the appliance from the power supply before cleaning.
Internal Cleaning
• Do not pour water over the appliance.
• The cavity should be cleaned periodically using a solution of bicarbonate of
soda and lukewarm water (5ml to 0.5 litre of water)
• Clean the accessories separately with soap and water. Do not put them in the
dishwasher.
• Do not use abrasive products, detergents or soaps.
• After washing, rinse with clean water and dry carefully.
• When you have finished cleaning reconnect the plug with dry hands.
External Cleaning
• Wash the outer cabinet with warm soapy water. Do NOT use abrasive products.
• There are sharp edges on the underside of the product so care should be taken
when cleaning.
• Once or twice a year dust the rear of the appliance and the compressor at the
back of the appliance, with a brush or vacuum cleaner, as an accumulation of
dust will affect the performance of the appliance and cause increased energy
consumption.
When the appliance is not in use
When the appliance is not in use for long periods, disconnect from the electricity
supply, empty all of the food and clean the inside. Leave the door open to prevent
the build-up of odours.
- 18 -
Maintenance & Cleaning
Defrosting
The refrigerator is a frost free product and will therefore defrost itself automatically.
However in case the refrigerator is not defrosting then the refrigerator can be defrosted
manually.
Note: Care must be taken when performing the following procedure.
• Defrost twice a year or when a frost layer of approximately 7 mm (1/4”) has formed.
• 6 hours before the defrosting process, set the temperature to its coldest setting to
make sure the food is at the lowest temperature before removing the frozen foods. All
food should be wrapped in several layers of newspaper and stored in a cool place (e.g.
fridge or larder).
• Place several layers of new paper or towels underneath and next to the freezer
door/compartment
• Use the manual defrost process detailed in the next steps or switch off the appliance at
the socket outlet and pull out the mains plug.
• To use the manual defrost process (the units has to be plugged in and power on:.
• Press and hold down the “SET” button for 15 seconds. All the indicator lights
illuminated, the refrigerator will stop cooling and will start to defrost by
entering into heat mode. The frost and ice will be defrosted and will eventually
be removed.
• During the defrosting process, you can press and hold the “SET” key for 3
seconds to stop defrosting manually, or wait until the defrosting program has
finished and is exited automatically.
• Avoid frequent defrosting of the refrigerator, do not access the manual
defrosting again within 10 minutes of manually disabling it.
• Remove all drawers, baskets, etc. and leave the door or lid open. Containers of warm
water (not hot) may be placed carefully in the freezer to speed up the defrosting
process.
• Never use hairdryers, electrical heaters or other such electrical appliances for
defrosting.
• When the ice has melted, clean and dry the interior. Wipe up any spillages that may
have occurred.
• Switch the appliance on (if it has been turned off) and replace any frozen food.
Never use sharp metal tools as it may damage the appliance.
Never use an electrical heater, this may cause an electric shock.
- 19 -
Trouble shooting
Problem
Solution
The freezer doesn't work
Check that the appliance is switched on.
Check that there has not been a power cut.
Check that the plug is not
faulty.
Check that the fuse has not blown.
Check that the voltage is correct for the appliance.
Are there any faults with the socket? For this purpose,
try the plug of your appliance by connecting it to a socket
which you are sure is working.
The temperature inside the
appliance is not cold enough
Check that there is not too much food in the appliance.
Check that the thermostat is set to a suitable
temperature.
Check that the appliance is not placed in direct sunlight,
or too near to a heating source.
Check that the ambient temperature is within the
operation limits of the appliance.
Are the doors of the appliance opened frequently? Once
the door is opened, the humidity found in the air in the
room enters the appliance, especially if the humidity
levels in the room are very high. The more frequently the
door is opened in humid conditions the more chance of
the build up of moisture.
The temperature within the
appliance is too cold.
Increase the working temperature by adjusting the
temperature control to a higher temperature
The inner surfaces of the
appliance are wet
Caused by condensation
-
dry the inside of the appliance.
The outer surfaces of the
appliance are wet
Caused by condensation
-
dry the outer of the appliance
carefully.
Excess ice or frost has built up
inside the appliance
Check that the door has not been left open.
Check that the door gasket is clean and undamaged.
- 20 -
Trouble shooting
Problem
Solution
Smell/odour
Check all
the food and drink that is in the freezer is
correctly packaged. If it isn’t then it should be removed
immediately or repackaged.
Check for spillages on each shelf, flap and drawer. You
may need to remove the drawers to check that no
spillages have settled underneath them. As spillages that
have not been cleaned and have been left can cause
smells and unwanted odours.
The doors do not close properly
Ensure there are no obstructions preventing door
closure.
Check the door compartments and shelves are correctly
in place.
Check the door seal is not warped or torn.
Check the appliance is level.
Unusual noises
Check that the appliance is on a flat, level surface and is
stable.
Check the spacing's around the appliance and ensure it is
not touching other items.
Bubbling and gurgling sound:
• This noise is emitted as
the coolant fluid flows through the pipes within the
system. This is normal.
Water flowing sound:
• This is the normal sound of
water flowing into the drain trough during the defrosting
process.
If the appliance is operating noisily (compressor noise):
This is normal. This noise indicates that the compressor is
operating normally.
As the compressor is being
energized, it might run a bit more noisily for a short
period of time.
Buzzer alarm
Is the door open? Open the door, and close it again.
All indicator lights on the display
panel ON
Is the defrosting function enabled? Hold down the SET
key for 3 seconds (for details, refer to the Defrosting
function on page 10)
- 21 -
Error codes
Error code
Solution
When the alarm indicator keeps
flashing (with the corresponding
indicator light of “
-16, -20, -
24, or
fast freezing” flickering
simultaneously)
Indicates fault with the refrigerator. Please contact
customer services.
- 22 -
WARNING- THIS APPLIANCE MUST BE EARTHED
This appliance is designed to operate from a mains supply of AC220V - 240V; 50HZ.
Check that the voltage marked on the product corresponds with your supply voltage.
For UK use only – Plug fitting details (where applicable):
As the colours of the wires in the mains lead of this appliance may not correspond
with the coloured markings identifying the terminals in your plug, proceed as follows:
The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which
is marked with the letter E or by the earth symbol or coloured GREEN or
GREEN/YELLOW.
The BLUE wire is the NEUTRAL and must be connected to
the terminal marked with the letter N or coloured BLACK.
The BROWN wire is the LIVE wire and must be connected
to the terminal marked with the letter L or coloured RED.
Always ensure that the plug cord grip is fastened correctly.
If a 13A (BS1363) fused plug is used it must be fitted with a 13amp fuse conforming
to BS1362 and be BSI or ASTA approved.
Connection to the Mains Supply
- 23 -
Guarantee
This product is guaranteed for 12 months from the date of the original
purchase. If any defect arises due to faulty materials or workmanship you
must contact Product Care with the original proof of purchase so a
replacement or refund can be arranged.
Refund or replacement is at the discretion of Product Care.
The following conditions apply:
• Product Care will require a valid proof of purchase at the point of
replacement or refund.
• The product must be installed and used in accordance with the
instructions contained in this instruction guide and any other
instructions for use which has been supplied.
• It must be used for domestic purposes only and for its intended use.
• This guarantee does not cover wear and tear, damage, misuse or
consumable parts.
This does not affect your statutory rights.
- 24 -
Technical Specification
Model number RH54FR3FZ146 (B) (S)
Rated Voltage 220V – 240V ~ 50Hz
Capacity 175L
External Dimensions(HxWxD) 1455mm x 540mm x 595mm (with
handle)
- 25 -
Product Fiche
Model
RH54FR3FZ146/B/S
Fresh Food Storage Compartment Volume (L)
N/A
Frozen Food Storage Volume (L)
174
Storage Temperature (
°
C) -12 to -26
Energy Consumption (kWh/per year)
266
Energy Consumption (kWh/per year), based on standard test results for 24 hours
Household Appliance Category
8
Energy Rating
F
Defrosting Type
Frost Free
Climate Class
T/SN
This appliance is intended to be used at an ambient temperature between 10
°
c and 43
°
c
Airborne Acoustical Noise (dB)
41
Temperature Rise Time (hr)
7hr
Freezing Capacity (kg/24h)
8kg/24h
Rated voltage (V)
220V – 240V / 50Hz
Rated Current (A)
0.55A
Product Dimensions
CMs (H x W x D) 145.5 x 54.0 x 59.5 (with handle)
Total Storage Volume (L)
175
Net Weight (KG)
54
Class Symbol
Ambient temperature
range (
°
C)
Information
Extended
temperate
SN +10 to +32
Extended temperate: 'this refrigerating appliance is
intended to be used at ambient temperatures ranging
from 10
°
c to 32
°
c;
Temperate N +16 to +32
Temperate: 'this refrigerating appliance is intended to
be used at ambient temperatures ranging from 16
°
c to
32
°
c;
Subtropical ST +16 to + 38
Subtropical: 'this refrigerating appliance is intended to
be used at ambient temperatures ranging from 16
°
c to
38
°
c;
Tropical T +16 to+ 43
Tropical: 'this refrigerating appliance is intended to be
used at ambient temperatures ranging from 16
°
c to
43
°
c;
- 26 -
Notes
This page is intentionally blank.
- 27 -
Made by Product Care Trading Limited under license from Spectrum Brands
(UK) Limited. Product Care Trading Limited, Wigan, WN2 4AY/ PCT (NI) Ltd,
Belfast, BT5 5AD. Russell Hobbs is the registered trademark of Spectrum
Brands (UK) Ltd.
Russell Hobbs Support: call 0345 208 8750 or visit: mda.russellhobbs.com
The ‘wheelie bin’ symbol is known as the 'Crossed-out wheelie bin Symbol'.
When this symbol is marked on a product/batteries, it means that the
product/batteries should not be disposed of with your general household
waste. Only discard electrical/electronic/battery items in separate collection
schemes, which cater for the recovery and recycling of materials contained
within. Your co-operation is vital to ensure the success of these schemes
and for the protection of the environment. For your nearest disposal facility,
visit www.recycle-more.co.uk or ask in store for details.
SEDEX – Connecting businesses and their global suppliers to share ethical
data and enabling improvement in ethical performance. Visit
www.sedex.org.uk for further information.
We reserve the right, due to possible changes to design, to alter the
instruction manual without prior notice.
Revision 1.7
