NEC NP-M352WS REPLACED BY NP-M353WS 3500-Lumen Portable User Manual

Projector

M352WS/M302WS/M332XS

User’s Manual

The M302WS is not distributed in North America.

Model No.

NP-M352WS, NP-M302WS, NP-M332XS

Ver. 1/12/13

•฀DLP฀is฀a฀trademark฀of฀Texas฀Instruments.

•฀Apple,฀Mac,฀Mac฀OS,฀and฀MacBook฀are฀trademarks฀of฀Apple฀Inc.฀registered฀in฀the฀U.S.฀and฀other฀countries.

•฀Microsoft,฀Windows,฀Windows฀Vista,฀Internet฀Explorer,฀.NET฀Framework฀and฀PowerPoint฀are฀either฀a฀registered฀

trademark฀or฀trademark฀of฀Microsoft฀Corporation฀in฀the฀United฀States฀and/or฀other฀countries.

•฀Intel฀and฀Intel฀Core฀are฀trademarks฀of฀Intel฀Corporation฀in฀the฀U.S.฀and/or฀other฀countries.

•฀PowerPC฀is฀a฀registered฀trademark฀of฀the฀International฀Business฀Machines฀Corporation.

•฀MicroSaver฀is฀a฀registered฀trademark฀of฀Kensington฀Computer฀Products฀Group,฀a฀division฀of฀ACCO฀Brands.

•฀Virtual฀Remote฀Tool฀uses฀WinI2C/DDC฀library,฀©฀Nicomsoft฀Ltd.

•฀HDMI,฀the฀HDMI฀Logo฀and฀High-Denition฀Multimedia฀Interface฀are฀trademarks฀or฀registered฀trademarks฀of฀HDMI฀

Licensing฀LLC.

•฀Trademark฀PJLink฀is฀a฀trademark฀applied฀for฀trademark฀rights฀in฀Japan,฀the฀United฀States฀of฀America฀and฀other฀

countries and areas.

•฀Wi-Fi

,฀Wi-Fi฀Alliance

,฀and฀Wi-Fi฀Protected฀Access฀(WPA,฀WPA2)

฀are฀registered฀trademarks฀of฀the฀Wi-Fi฀Alli-

ance.

•฀Blu-ray฀is฀a฀trademark฀of฀Blu-ray฀Disc฀Association

•฀CRESTRON฀and฀ROOMVIEW฀are฀registered฀trademarks฀of฀Crestron฀Electronics,฀Inc.฀in฀the฀United฀States฀and฀other฀

countries.

•฀Other฀product฀and฀company฀names฀mentioned฀in฀this฀user’s฀manual฀may฀be฀the฀trademarks฀or฀registered฀trademarks฀

of฀their฀respective฀holders.

•฀GPL/LGPL฀Software฀Licenses

฀The฀product฀includes฀software฀licensed฀under฀GNU฀General฀Public฀License฀(GPL),฀GNU฀Lesser฀General฀Public฀

License฀(LGPL),฀and฀others.

฀For฀more฀information฀on฀each฀software,฀see฀“readme.pdf”฀inside฀the฀“about฀GPL&LGPL”฀folder฀on฀the฀supplied฀CD-

ROM.

NOTES

(1)฀The฀contents฀of฀this฀user’s฀manual฀may฀not฀be฀reprinted฀in฀part฀or฀whole฀without฀permission.

(2)฀The฀contents฀of฀this฀user’s฀manual฀are฀subject฀to฀change฀without฀notice.

(3)฀Great฀care฀has฀been฀taken฀in฀the฀preparation฀of฀this฀user’s฀manual;฀however,฀should฀you฀notice฀any฀questionable฀

points,฀errors฀or฀omissions,฀please฀contact฀us.

(4)฀Notwithstanding฀article฀(3),฀NEC฀will฀not฀be฀responsible฀for฀any฀claims฀on฀loss฀of฀prot฀or฀other฀matters฀deemed฀

to฀result฀from฀using฀the฀Projector.

Important Information

Safety Cautions

Precautions

Please฀read฀this฀manual฀carefully฀before฀using฀your฀NEC฀projector฀and฀keep฀the฀manual฀handy฀for฀future฀reference.

CAUTION

To฀turn฀off฀main฀power,฀be฀sure฀to฀remove฀the฀plug฀from฀power฀outlet.

The฀power฀outlet฀socket฀should฀be฀installed฀as฀near฀to฀the฀equipment฀as฀possible,฀and฀should฀be฀easily฀

accessible.

CAUTION

TO฀PREVENT฀SHOCK,฀DO฀NOT฀OPEN฀THE฀CABINET.

THERE฀ARE฀HIGH-VOLTAGE฀COMPONENTS฀INSIDE.

REFER฀SERVICING฀TO฀QUALIFIED฀SERVICE฀PERSONNEL.

This฀symbol฀warns฀the฀user฀that฀uninsulated฀voltage฀within฀the฀unit฀may฀be฀sufcient฀to฀cause฀electrical฀

shock.฀Therefore,฀it฀is฀dangerous฀to฀make฀any฀kind฀of฀contact฀with฀any฀part฀inside฀of฀the฀unit.

This฀symbol฀alerts฀the฀user฀that฀important฀information฀concerning฀the฀operation฀and฀maintenance฀of฀this฀

unit฀has฀been฀provided.

The฀information฀should฀be฀read฀carefully฀to฀avoid฀problems.

WARNING:฀TO฀PREVENT฀FIRE฀OR฀SHOCK,฀DO฀NOT฀EXPOSE฀THIS฀UNIT฀TO฀RAIN฀OR฀MOISTURE.

DO฀NOT฀USE฀THIS฀UNIT’S฀PLUG฀WITH฀AN฀EXTENSION฀CORD฀OR฀IN฀AN฀OUTLET฀UNLESS฀ALL฀THE฀PRONGS฀

CAN฀BE฀FULLY฀INSERTED.

DOC Compliance Notice (for Canada only)

This฀Class฀B฀digital฀apparatus฀complies฀with฀Canadian฀ICES-003.

Machine Noise Information Regulation - 3. GPSGV,

The฀highest฀sound฀pressure฀level฀is฀less฀than฀70฀dB฀(A)฀in฀accordance฀with฀EN฀ISO฀7779.

Disposing of your used product

EU-wide฀legislation฀as฀implemented฀in฀each฀Member฀State฀requires฀that฀used฀electrical฀and฀electronic฀prod-

ucts฀carrying฀the฀mark฀(left)฀must฀be฀disposed฀of฀separately฀from฀normal฀household฀waste.฀This฀includes฀

projectors฀and฀their฀electrical฀accessories฀or฀lamps.฀When฀you฀dispose฀of฀such฀products,฀please฀follow฀the฀

guidance฀of฀your฀local฀authority฀and/or฀ask฀the฀shop฀where฀you฀purchased฀the฀product.

After฀collecting฀the฀used฀products,฀they฀are฀reused฀and฀recycled฀in฀a฀proper฀way.฀This฀effort฀will฀help฀us฀

reduce฀the฀wastes฀as฀well฀as฀the฀negative฀impact฀such฀as฀mercury฀contained฀in฀a฀lamp฀to฀the฀human฀health฀

and฀the฀environment฀at฀the฀minimum฀level.

The฀mark฀on฀the฀electrical฀and฀electronic฀products฀only฀applies฀to฀the฀current฀European฀Union฀Member฀

States.

Important Information

WARNING TO CALIFORNIA RESIDENTS:

Handling฀the฀cables฀supplied฀with฀this฀product฀will฀expose฀you฀to฀lead,฀a฀chemical฀known฀to฀the฀State฀of฀California฀

to฀cause฀birth฀defects฀or฀other฀reproductive฀harm.฀WASH฀HANDS฀AFTER฀HANDLING.

RF Interference (for USA only)

WARNING

The฀Federal฀Communications฀Commission฀does฀not฀allow฀any฀modications฀or฀changes฀to฀the฀unit฀EXCEPT฀those฀

specied฀by฀NEC฀Display฀Solutions฀of฀America,฀Inc.฀in฀this฀manual.฀Failure฀to฀comply฀with฀this฀government฀regu-

lation฀could฀void฀your฀right฀to฀operate฀this฀equipment.฀This฀equipment฀has฀been฀tested฀and฀found฀to฀comply฀with฀

the฀limits฀for฀a฀Class฀B฀digital฀device,฀pursuant฀to฀Part฀15฀of฀the฀FCC฀Rules.฀These฀limits฀are฀designed฀to฀provide฀

reasonable฀protection฀against฀harmful฀interference฀in฀a฀residential฀installation.฀This฀equipment฀generates,฀uses,฀and฀

can฀radiate฀radio฀frequency฀energy฀and,฀if฀not฀installed฀and฀used฀in฀accordance฀with฀the฀instructions,฀may฀cause฀

harmful฀interference฀to฀radio฀communications.฀However,฀there฀is฀no฀guarantee฀that฀interference฀will฀not฀occur฀in฀a฀

particular฀installation.

If฀this฀equipment฀does฀cause฀harmful฀interference฀to฀radio฀or฀television฀reception,฀which฀can฀be฀determined฀by฀

turning฀the฀equipment฀off฀and฀on,฀the฀user฀is฀encouraged฀to฀try฀to฀correct฀the฀interference฀by฀one฀or฀more฀of฀the฀

following฀measures:

•฀Reorient฀or฀relocate฀the฀receiving฀antenna.

•฀Increase฀the฀separation฀between฀the฀equipment฀and฀receiver.

•฀Connect฀the฀equipment฀into฀an฀outlet฀on฀a฀circuit฀different฀from฀that฀to฀which฀the฀receiver฀is฀connected.

•฀Consult฀the฀dealer฀or฀an฀experienced฀radio฀/฀TV฀technician฀for฀help.

For฀UK฀only:฀In฀UK,฀a฀BS฀approved฀power฀cord฀with฀moulded฀plug฀has฀a฀Black฀(ve฀Amps)฀fuse฀installed฀for฀use฀with฀

this฀equipment.฀If฀a฀power฀cord฀is฀not฀supplied฀with฀this฀equipment฀please฀contact฀your฀supplier.

Important Safeguards

These฀safety฀instructions฀are฀to฀ensure฀the฀long฀life฀of฀your฀projector฀and฀to฀prevent฀re฀and฀shock.฀Please฀read฀them฀

carefully฀and฀heed฀all฀warnings.

Installation

•฀Do฀not฀place฀the฀projector฀in฀the฀following฀conditions:

- on an unstable cart, stand, or table.

-฀near฀water,฀baths,฀or฀damp฀rooms.

-฀in฀direct฀sunlight,฀near฀heaters,฀or฀heat฀radiating฀appliances.

-฀in฀a฀dusty,฀smoky฀or฀steamy฀environment.฀

-฀on฀a฀sheet฀of฀paper฀or฀cloth,฀rugs฀or฀carpets.

•฀If฀you฀wish฀to฀have฀the฀projector฀installed฀on฀the฀ceiling:

-฀Do฀not฀attempt฀to฀install฀the฀projector฀yourself.

-฀The฀projector฀must฀be฀installed฀by฀qualied฀technicians฀in฀order฀to฀ensure฀proper฀operation฀and฀reduce฀the฀risk฀

of฀bodily฀injury.

-฀In฀addition,฀the฀ceiling฀must฀be฀strong฀enough฀to฀support฀the฀projector฀and฀the฀installation฀must฀be฀in฀accordance฀

with฀any฀local฀building฀codes.

-฀Please฀consult฀your฀dealer฀for฀more฀information.

iii

Important Information

WARNING

•฀Do฀not฀cover฀the฀lens฀with฀the฀lens฀cap฀or฀equivalent฀while฀the฀projector฀is฀on.฀Doing฀so฀can฀lead฀to฀melting฀of฀

the฀cap฀due฀to฀the฀heat฀emitted฀from฀the฀light฀output.

•฀Do฀not฀place฀any฀objects,฀which฀are฀easily฀affected฀by฀heat,฀in฀front฀of฀the฀projector฀lens.฀Doing฀so฀could฀lead฀

to฀the฀object฀melting฀from฀the฀heat฀that฀is฀emitted฀from฀the฀light฀output.

•฀Do฀not฀spray฀ammable฀gas฀to฀get฀rid฀of฀dust฀and฀dirt฀that฀accumulate฀in฀the฀lens.฀Doing฀so฀could฀cause฀a฀

re.

Place the projector in a horizontal position

The฀tilt฀angle฀of฀the฀projector฀should฀not฀exceed฀10฀degrees,฀nor฀should฀the฀projector฀be฀installed฀in฀any฀way฀other฀

than฀the฀desktop฀and฀ceiling฀mount,฀otherwise฀lamp฀life฀could฀decrease฀dramatically.

10˚

Fire and Shock Precautions

•฀Ensure฀that฀there฀is฀sufcient฀ventilation฀and฀that฀vents฀are฀unobstructed฀to฀prevent฀the฀build-up฀of฀heat฀inside฀your฀

projector.฀Allow฀at฀least฀4฀inches฀(10cm)฀of฀space฀between฀your฀projector฀and฀a฀wall.

•฀Do฀not฀try฀to฀touch฀the฀exhaust฀vent฀on฀the฀right฀front฀(when฀seen฀from฀the฀front)฀as฀it฀can฀become฀heated฀while฀the฀

projector฀is฀turned฀on฀and฀immediately฀after฀the฀projector฀is฀turned฀off.฀Parts฀of฀the฀projector฀may฀become฀temporarily฀

heated฀if฀the฀projector฀is฀turned฀off฀with฀the฀POWER฀button฀or฀if฀the฀AC฀power฀supply฀is฀disconnected฀during฀normal฀

projector฀operation.

฀Use฀caution฀when฀picking฀up฀the฀projector.

•฀Prevent฀foreign฀objects฀such฀as฀paper฀clips฀and฀bits฀of฀paper฀from฀falling฀into฀your฀projector.฀Do฀not฀attempt฀to฀retrieve฀

any฀objects฀that฀might฀fall฀into฀your฀projector.฀Do฀not฀insert฀any฀metal฀objects฀such฀as฀a฀wire฀or฀screwdriver฀into฀your฀

projector.฀If฀something฀should฀fall฀into฀your฀projector,฀disconnect฀it฀immediately฀and฀have฀the฀object฀removed฀by฀a฀

qualied฀service฀personnel.

•฀Do฀not฀place฀any฀objects฀on฀top฀of฀the฀projector.

•฀Do฀not฀touch฀the฀power฀plug฀during฀a฀thunderstorm.฀Doing฀so฀can฀cause฀electrical฀shock฀or฀re.

•฀The฀projector฀is฀designed฀to฀operate฀on฀a฀power฀supply฀of฀100-240V฀AC฀50/60฀Hz.฀Ensure฀that฀your฀power฀supply฀

ts฀this฀requirement฀before฀attempting฀to฀use฀your฀projector.

•฀Do฀not฀look฀into฀the฀lens฀while฀the฀projector฀is฀on.฀Serious฀damage฀to฀your฀eyes฀could฀result.

•฀Keep฀any฀items฀such฀as฀magnifying฀glass฀out฀of฀the฀light฀path฀of฀the฀projector.฀The฀light฀being฀projected฀from฀the฀

lens฀is฀extensive,฀therefore฀any฀kind฀of฀abnormal฀objects฀that฀can฀redirect฀light฀coming฀out฀of฀the฀lens,฀can฀cause฀

unpredictable฀outcome฀such฀as฀re฀or฀injury฀to฀the฀eyes.

•฀Do฀not฀place฀any฀objects,฀which฀are฀easily฀affected฀by฀heat,฀in฀front฀of฀a฀projector฀exhaust฀vent.

฀Doing฀so฀could฀lead฀to฀the฀object฀melting฀or฀getting฀your฀hands฀burned฀from฀the฀heat฀that฀is฀emitted฀from฀the฀ex-

haust.

Important Information

•฀Do฀not฀splash฀water฀over฀the฀projector.฀Doing฀so฀can฀cause฀electrical฀shock฀or฀re.฀If฀the฀projector฀gets฀wet,฀turn฀off฀

the฀projector,฀unplug฀the฀power฀cord฀and฀have฀the฀projector฀serviced฀by฀a฀qualied฀service฀personnel.

•฀Handle฀the฀power฀cord฀carefully.฀A฀damaged฀or฀frayed฀power฀cord฀can฀cause฀electric฀shock฀or฀re.

-฀Do฀not฀use฀any฀power฀cord฀other฀than฀the฀one฀supplied฀with฀the฀projector.

-฀Do฀not฀bend฀or฀tug฀the฀power฀cord฀excessively.

-฀Do฀not฀place฀the฀power฀cord฀under฀the฀projector,฀or฀any฀heavy฀object.

-฀Do฀not฀cover฀the฀power฀cord฀with฀other฀soft฀materials฀such฀as฀rugs.

-฀Do฀not฀heat฀the฀power฀cord.

-฀Do฀not฀handle฀the฀power฀plug฀with฀wet฀hands.

•฀Turn฀off฀the฀projector,฀unplug฀the฀power฀cord฀and฀have฀the฀projector฀serviced฀by฀a฀qualied฀service฀personnel฀under฀

the฀following฀conditions:

-฀When฀the฀power฀cord฀or฀plug฀is฀damaged฀or฀frayed.

-฀If฀liquid฀has฀been฀spilled฀into฀the฀projector,฀or฀if฀it฀has฀been฀exposed฀to฀rain฀or฀water.฀

-฀If฀the฀projector฀does฀not฀operate฀normally฀when฀you฀follow฀the฀instructions฀described฀in฀this฀user’s฀manual.

-฀If฀the฀projector฀has฀been฀dropped฀or฀the฀cabinet฀has฀been฀damaged.

-฀If฀the฀projector฀exhibits฀a฀distinct฀change฀in฀performance,฀indicating฀a฀need฀for฀service.

•฀Disconnect฀the฀power฀cord฀and฀any฀other฀cables฀before฀carrying฀the฀projector.

•฀Turn฀off฀the฀projector฀and฀unplug฀the฀power฀cord฀before฀cleaning฀the฀cabinet฀or฀replacing฀the฀lamp.

•฀Turn฀off฀the฀projector฀and฀unplug฀the฀power฀cord฀if฀the฀projector฀is฀not฀to฀be฀used฀for฀an฀extended฀period฀of฀time.

•฀When฀using฀a฀LAN฀cable฀(only฀models฀with฀the฀RJ-45฀LAN฀port):

฀For฀safety,฀do฀not฀connect฀to฀the฀connector฀for฀peripheral฀device฀wiring฀that฀might฀have฀excessive฀voltage.

CAUTION

•฀Do฀not฀use฀the฀tilt-foot฀for฀purposes฀other฀than฀originally฀intended.฀Misuses฀such฀as฀gripping฀the฀tilt-foot฀or฀hang-

ing฀on฀the฀wall฀can฀cause฀damage฀to฀the฀projector.

•฀Do฀not฀send฀the฀projector฀in฀the฀soft฀case฀by฀parcel฀delivery฀service฀or฀cargo฀shipment.฀The฀projector฀inside฀the฀

soft฀case฀could฀be฀damaged.

•฀Select฀[HIGH]฀in฀Fan฀mode฀if฀you฀continue฀to฀use฀the฀projector฀for฀consecutive฀days.฀(From฀the฀menu,฀select฀

[SETUP]฀→฀[OPTIONS(1)]฀→฀[FAN฀MODE]฀→฀[HIGH].)

•฀Do฀not฀turn฀off฀the฀AC฀power฀for฀60฀seconds฀after฀the฀lamp฀is฀turned฀on฀and฀while฀the฀POWER฀indicator฀is฀blink-

ing฀blue.฀Doing฀so฀could฀cause฀premature฀lamp฀failure.

Remote Control Precautions

•฀Handle฀the฀remote฀control฀carefully.

•฀If฀the฀remote฀control฀gets฀wet,฀wipe฀it฀dry฀immediately.

•฀Avoid฀excessive฀heat฀and฀humidity.

•฀Do฀not฀short,฀heat,฀or฀take฀apart฀batteries.

•฀Do฀not฀throw฀batteries฀into฀re.

•฀If฀you฀will฀not฀be฀using฀the฀remote฀control฀for฀a฀long฀time,฀remove฀the฀batteries.

•฀Ensure฀that฀you฀have฀the฀batteries’฀polarity฀(+/−)฀aligned฀correctly.

•฀Do฀not฀use฀new฀and฀old฀batteries฀together,฀or฀use฀different฀types฀of฀batteries฀together.

•฀Dispose฀of฀used฀batteries฀according฀to฀your฀local฀regulations.

Important Information

Note for US Residents

The฀lamp฀in฀this฀product฀contains฀mercury.฀Please฀dispose฀according฀to฀Local,฀State฀or฀Federal฀Laws.

Lamp Replacement

•฀Use฀the฀specied฀lamp฀for฀safety฀and฀performance.

•฀To฀replace฀the฀lamp,฀follow฀all฀instructions฀provided฀on฀page฀

128.

•฀Be฀sure฀to฀replace฀the฀lamp฀when฀the฀message฀[THE LAMP HAS REACHED THE END OF ITS USABLE LIFE.

PLEASE REPLACE THE LAMP.]฀appears.฀If฀you฀continue฀to฀use฀the฀lamp฀after฀the฀lamp฀has฀reached฀the฀end฀of฀

its฀usable฀life,฀the฀lamp฀bulb฀may฀shatter,฀and฀pieces฀of฀glass฀may฀be฀scattered฀in฀the฀lamp฀case.฀Do฀not฀touch฀them฀

as฀the฀pieces฀of฀glass฀may฀cause฀injury.

฀If฀this฀happens,฀contact฀your฀dealer฀for฀lamp฀replacement.

A Lamp Characteristic

The฀projector฀has฀a฀high-pressure฀mercury฀lamp฀as฀a฀light฀source.

A฀lamp฀has฀a฀characteristic฀that฀its฀brightness฀gradually฀decreases฀with฀age.฀Also฀repeatedly฀turning฀the฀lamp฀on฀

and฀off฀will฀increase฀the฀possibility฀of฀its฀lower฀brightness.

The฀actual฀lamp฀life฀may฀vary฀depending฀upon฀the฀individual฀lamp,฀the฀environmental฀conditions฀and฀usage.

CAUTION:

•฀DO฀NOT฀TOUCH฀THE฀LAMP฀immediately฀after฀it฀has฀been฀used.฀It฀will฀be฀extremely฀hot.฀Turn฀the฀projector฀off฀

and฀then฀disconnect฀the฀power฀cord.฀Allow฀at฀least฀one฀hour฀for฀the฀lamp฀to฀cool฀before฀handling.

•฀When฀removing฀the฀lamp฀from฀a฀ceiling-mounted฀projector,฀make฀sure฀that฀no฀one฀is฀under฀the฀projector.฀Glass฀

fragments฀could฀fall฀if฀the฀lamp฀has฀been฀burned฀out.

About High Altitude mode

•฀Set฀[FAN฀MODE]฀to฀[HIGH฀ALTITUDE]฀when฀using฀the฀projector฀at฀altitudes฀approximately฀5500฀feet/1700฀meters฀

or฀higher.

฀Using฀the฀projector฀at฀altitudes฀approximately฀5500฀feet/1700฀meters฀or฀higher฀without฀setting฀to฀[HIGH฀ALTITUDE]฀

can฀cause฀the฀projector฀to฀overheat฀and฀the฀protector฀could฀shut฀down.฀If฀this฀happens,฀wait฀a฀couple฀minutes฀and฀

turn฀on฀the฀projector.

•฀Using฀the฀projector฀at฀altitudes฀less฀than฀approximately฀5500฀feet/1700฀meters฀and฀setting฀to฀[HIGH฀ALTITUDE]฀

can฀cause฀the฀lamp฀to฀overcool,฀causing฀the฀image฀to฀icker.฀Switch฀[FAN฀MODE]฀to฀[AUTO].

•฀Using฀the฀projector฀at฀altitudes฀approximately฀5500฀feet/1700฀meters฀or฀higher฀can฀shorten฀the฀life฀of฀optical฀com-

ponents฀such฀as฀the฀lamp.

About Copyright of original projected pictures:

Please฀note฀that฀using฀this฀projector฀for฀the฀purpose฀of฀commercial฀gain฀or฀the฀attraction฀of฀public฀attention฀in฀a฀venue฀

such฀as฀a฀coffee฀shop฀or฀hotel฀and฀employing฀compression฀or฀expansion฀of฀the฀screen฀image฀with฀the฀following฀func-

tions฀may฀raise฀concern฀about฀the฀infringement฀of฀copyrights฀which฀are฀protected฀by฀copyright฀law.

[ASPECT฀RATIO],฀[KEYSTONE],฀Magnifying฀feature฀and฀other฀similar฀features.

Turkish RoHS information relevant for Turkish market

EEE Yonetmeliğine Uygundur.

Important Information

Power management function

The฀projector฀has฀power฀management฀functions.฀To฀reduce฀power฀consumption,฀the฀power฀management฀functions฀(1฀

and฀2)฀are฀factory฀preset฀as฀shown฀below.฀To฀control฀the฀projector฀from฀an฀external฀device฀via฀a฀LAN฀or฀serial฀cable฀

connection,฀use฀the฀on-screen฀menu฀to฀change฀the฀settings฀for฀1฀and฀2.

1. STANDBY MODE (Factory preset: NORMAL)

To control the projector from an external device, select [NETWORK STANDBY] for [STANDBY MODE].

NOTE:

•When[NORMAL]isselectedfor[STANDBYMODE],thefollowingconnectorsandfunctionswillnotwork:

MONITOROUTconnector,AUDIOOUTconnector,USB-Bport,LANfunctions,MailAlertfunction,DDC/CI(VirtualRemote

Tool)

2. AUTO POWER OFF (Factory preset: 1 hour)

To control the projector from an external device, select [OFF] for [AUTO POWER OFF].

NOTE:

•When[1:00]isselectedfor[AUTOPOWEROFF],youcanenabletheprojectortoautomaticallyturnoffin60minutesifthereis

nosignalreceivedbyanyinputorifnooperationisperformed.

Health precautions to users viewing 3D images

Before฀viewing,฀be฀sure฀to฀read฀health฀care฀precautions฀that฀may฀be฀found฀in฀the฀user’s฀manual฀included฀with฀your฀

LCD฀shutter฀eyeglasses฀or฀your฀3D฀compatible฀content฀such฀as฀DVDs,฀video฀games,฀computer's฀video฀les฀and฀

the฀like.

To฀avoid฀any฀adverse฀symptoms,฀heed฀the฀following:

•฀Do฀not฀use฀LCD฀shutter฀eyeglasses฀for฀viewing฀any฀material฀other฀than฀3D฀images.

•฀Allow฀a฀distance฀of฀2฀m/7฀feet฀or฀greater฀between฀the฀screen฀and฀a฀user.฀Viewing฀3D฀images฀from฀too฀close฀a฀

distance฀can฀strain฀your฀eyes.

•฀Avoid฀viewing฀3D฀images฀for฀a฀prolonged฀period฀of฀time.฀Take฀a฀break฀of฀15฀minutes฀or฀longer฀after฀every฀hour฀

of฀viewing.

•฀If฀you฀or฀any฀member฀of฀your฀family฀has฀a฀history฀of฀light-sensitive฀seizures,฀consult฀a฀doctor฀before฀viewing฀3D฀

images.

•฀While฀viewing฀3D฀images,฀if฀you฀get฀sick฀such฀as฀nausea,฀dizziness,฀queasiness,฀headache,฀eyestrain,฀blurry฀

vision,฀convulsions,฀and฀numbness,฀stop฀viewing฀them.฀If฀symptoms฀still฀persist,฀consult฀a฀doctor.฀

•฀View฀3D฀images฀from฀the฀front฀of฀the฀screen.฀Viewing฀from฀an฀angle฀may฀cause฀fatigue฀or฀eyestrain.฀

vii

Table of Contents

Important Information ............................................................................................i

1. Introduction ...........................................................................................................1

❶฀What’s฀in฀the฀Box? ..........................................................................................................1

❷฀Introduction฀to฀the฀Projector ...........................................................................................2

Congratulations฀on฀Your฀Purchase฀of฀the฀Projector ..................................................2

Features฀you’ll฀enjoy: ................................................................................................2

About฀this฀user’s฀manual ...........................................................................................4

Comparative฀Table฀of฀Main฀Features ........................................................................5

❸฀Part฀Names฀of฀the฀Projector ...........................................................................................6

Front/Top ...................................................................................................................6

Rear ..........................................................................................................................7

Top฀Features .............................................................................................................8

Terminal฀Panel฀Features ...........................................................................................9

❹฀Part฀Names฀of฀the฀Remote฀Control ..............................................................................10

Battery฀Installation ..................................................................................................11

Remote฀Control฀Precautions ...................................................................................11

Operating฀Range฀for฀Wireless฀Remote฀Control .......................................................11

❺฀Operating฀Environment฀for฀Software฀Included฀on฀CD-ROM .........................................12

Operating฀Environment ...........................................................................................13

2. Projecting an Image (Basic Operation) ...............................................15

❶฀Flow฀of฀Projecting฀an฀Image .........................................................................................15

❷฀Connecting฀Your฀Computer/Connecting฀the฀Power฀Cord ..............................................16

❸฀Turning฀on฀the฀Projector ...............................................................................................17

Note฀on฀Startup฀screen฀(Menu฀Language฀Select฀screen) .......................................18

❹฀Selecting฀a฀Source .......................................................................................................19

Selecting฀the฀computer฀or฀video฀source..................................................................19

❺฀Adjusting฀the฀Picture฀Size฀and฀Position ........................................................................20

Adjust฀the฀Tilt฀Foot ..................................................................................................21

Zoom .......................................................................................................................22

Focus ......................................................................................................................23

❻฀Correcting฀Keystone฀Distortion฀Manually .....................................................................24

Adjusting฀with฀buttons฀on฀the฀cabinet .....................................................................24

Adjusting฀with฀the฀remote฀control ............................................................................25

❼฀Optimizing฀Computer฀Signal฀Automatically ..................................................................26

Adjusting฀the฀Image฀Using฀Auto฀Adjust ...................................................................26

❽฀Turning฀Up฀or฀Down฀Volume .........................................................................................26

❾฀Turning฀off฀the฀Projector ...............................................................................................27

❿฀After฀Use.......................................................................................................................28

3. Convenient Features ......................................................................................29

❶฀Turning฀off฀the฀Image฀and฀Sound .................................................................................29

❷฀Freezing฀a฀Picture ........................................................................................................29

❸฀Enlarging฀a฀Picture .......................................................................................................29

❹฀Changing฀Eco฀Mode/Checking฀Energy-Saving฀Effect฀ .................................................31

Using฀Eco฀Mode฀[ECO฀MODE] ...............................................................................31

viii

Table of Contents

Checking฀Energy-Saving฀Effect฀[CARBON฀METER] ..............................................32

❺

Preventing฀the฀Unauthorized฀Use฀of฀the฀Projector฀[SECURITY] .......................................33

❻฀Using฀the฀Computer฀Cable฀(VGA)฀to฀Operate฀the฀Projector฀(Virtual฀Remote฀Tool) ......36

❼

Operating฀Your฀Computer’s฀Mouse฀Functions฀from฀the฀Projector’s฀Remote฀Control฀

via฀the฀USB฀Cable฀(Remote฀Mouse฀Function) .......................................................... 42

❽฀Projecting฀Your฀Computer’s฀Screen฀Image฀from฀the฀Projector฀via฀the฀USB฀Cable฀

(USB฀Display) .........................................................................................................43

❾฀Controlling฀the฀Projector฀by฀Using฀an฀HTTP฀Browser ..................................................45

❿

Controlling฀the฀Projector฀over฀a฀LAN฀(PC฀Control฀Utility฀Pro฀4/Pro฀5) ............................. 52

⓫฀Projecting฀Your฀Computer’s฀Screen฀Image฀from฀the฀Projector฀over฀a฀LAN฀(Image฀

Express฀Utility฀Lite) .................................................................................................56

Starting฀Image฀Express฀Utility฀Lite฀from฀a฀USB฀Memory฀or฀SD฀Card .....................59

Downloading฀Image฀Express฀Utility฀Lite฀via฀the฀HTTP฀server .................................60

⓬฀Projecting฀an฀Image฀from฀an฀Angle฀(Geometric฀Correction฀Tool฀in฀Image฀Express฀

Utility฀Lite) ...............................................................................................................63

What฀you฀can฀do฀with฀GCT .....................................................................................63

Projecting฀an฀Image฀from฀an฀Angle฀(GCT) ..............................................................63

⓭฀Viewing฀3D฀Images .......................................................................................................65

⓮฀Connecting฀Your฀Microphone ........................................................................................69

4. Using the Viewer ..............................................................................................70

❶฀What฀you฀can฀do฀with฀the฀Viewer ..................................................................................70

❷฀Projecting฀images฀stored฀in฀a฀USB฀memory฀device .....................................................72

5. Using On-Screen Menu .................................................................................78

❶฀Using฀the฀Menus ...........................................................................................................78

❷฀Menu฀Elements .............................................................................................................79

❸฀List฀of฀Menu฀Items ........................................................................................................80

❹฀Menu฀Descriptions฀&฀Functions฀[SOURCE] .................................................................83

COMPUTER ...........................................................................................................83

HDMI1฀and฀2 ...........................................................................................................83

VIDEO .....................................................................................................................83

USB-A฀(Viewer) .......................................................................................................83

LAN .........................................................................................................................83

USB-B฀(USB฀Display) .............................................................................................83

❺฀Menu฀Descriptions฀&฀Functions฀[ADJUST] ...................................................................84

[PICTURE] ..............................................................................................................84

[IMAGE฀OPTIONS] .................................................................................................87

❻฀Menu฀Descriptions฀&฀Functions฀[SETUP] .....................................................................92

[GENERAL] .............................................................................................................92

[MENU] ...................................................................................................................95

[INSTALLATION] .....................................................................................................97

[OPTIONS(1)] .........................................................................................................99

[OPTIONS(2)] .......................................................................................................101

[3D] .......................................................................................................................104

Setting฀up฀the฀Projector฀for฀a฀Wired฀LAN฀Connection฀[WIRED฀LAN] ....................106

Setting฀up฀the฀Projector฀for฀a฀Wireless฀LAN฀Connection฀(with฀the฀optional฀USB฀

Wireless฀LAN฀Unit฀equipped)฀[WIRLESS฀LAN] .....................................................107

Table of Contents

❼฀Menu฀Descriptions฀&฀Functions฀[INFO.] .....................................................................109

[USAGE฀TIME] ......................................................................................................109

[SOURCE(1)] ........................................................................................................110

[SOURCE(2)] ........................................................................................................110

[WIRED฀LAN] ........................................................................................................110

[WIRELESS฀LAN] .................................................................................................111

[VERSION(1)] .......................................................................................................111

[VERSION(2)] .......................................................................................................111

[OTHERS] .............................................................................................................112

❽฀Menu฀Descriptions฀&฀Functions฀[RESET] ...................................................................113

Returning฀to฀Factory฀Default฀[RESET] ..................................................................113

6. Installation and Connections ..................................................................114

❶฀Setting฀Up฀the฀Screen฀and฀the฀Projector ....................................................................114

Selecting฀a฀Location..............................................................................................114

Throw฀Distance฀and฀Screen฀Size ..........................................................................116

❷฀Making฀Connections ...................................................................................................117

Connecting฀Your฀Computer ...................................................................................117

Connecting฀an฀External฀Monitor ...........................................................................119

Connecting฀Your฀DVD฀Player฀or฀Other฀AV฀Equipment ...........................................120

Connecting฀Component฀Input ...............................................................................121

Connecting฀HDMI฀Input.........................................................................................122

Connecting฀to฀a฀Wired฀LAN ..................................................................................123

Connecting฀to฀a฀Wireless฀LAN฀(Optional:฀NP02LM฀series) ...................................124

7. Maintenance .....................................................................................................127

❶฀Cleaning฀the฀Lens.......................................................................................................127

❷฀Cleaning฀the฀Cabinet ..................................................................................................127

❸฀Replacing฀the฀Lamp....................................................................................................128

8. Appendix ..............................................................................................................131

❶฀Troubleshooting ..........................................................................................................131

Indicator฀Messages ...............................................................................................131

Common฀Problems฀&฀Solutions ............................................................................132

If฀there฀is฀no฀picture,฀or฀the฀picture฀is฀not฀displayed฀correctly. ...............................133

❷฀Specications .............................................................................................................134

❸฀Cabinet฀Dimensions ...................................................................................................136

Attaching฀the฀Optional฀Cable฀Cover฀(NP05CV) ....................................................137

❹฀Pin฀Assignments฀of฀D-Sub฀COMPUTER฀Input฀Connector .........................................138

❺฀Compatible฀Input฀Signal฀List .......................................................................................139

❻฀PC฀Control฀Codes฀and฀Cable฀Connection ..................................................................140

❼฀Troubleshooting฀Check฀List .........................................................................................141

❽฀TCO฀Certication ........................................................................................................143

❾฀REGISTER฀YOUR฀PROJECTOR!฀(for฀residents฀in฀the฀United฀States,฀Canada,฀and฀

Mexico) .................................................................................................................144

Projector

[M352WS/M302WS/M332XS]

Power cord

(US: 7N080240)

(EU: 7N080027)

Computer cable (VGA)

(7N520089)

Remote control

(7N901051)

Batteries (AAA × 2)

For North America only

Limited warranty

For customers in Europe:

You will ﬁnd our current valid Guar-

antee Policy on our Web Site:

www.nec-display-solutions.com

•฀Important฀Infomation฀

(For North America: 7N8N4361)

(For Other countries than

North America: 7N8N4361 and

7N8N4371)

•฀Quick฀Setup฀Guide฀

(7N8N4381)/(7N8N4391)

NEC Projector CD-ROM

User’s manual (PDF) and the

utility software

(7N952001)

1. Introduction

❶ What’s in the Box?

Make฀sure฀your฀box฀contains฀everything฀listed.฀If฀any฀pieces฀are฀missing,฀contact฀your฀dealer.

Please฀save฀the฀original฀box฀and฀packing฀materials฀if฀you฀ever฀need฀to฀ship฀your฀projector.

Unless฀otherwise฀described฀in฀the฀user’s฀manual,฀the฀drawings฀for฀the฀projector฀cabinet฀show฀examples฀of฀the฀

M352WS.

1. Introduction

❷ Introduction to the Projector

This฀section฀introduces฀you฀to฀your฀new฀projector฀and฀describes฀the฀features฀and฀controls.

Congratulations on Your Purchase of the Projector

This฀projector฀is฀one฀of฀the฀very฀best฀projectors฀available฀today.฀The฀projector฀enables฀you฀to฀project฀precise฀images฀

up฀to฀150฀inches฀for฀short฀throw฀models฀across฀(measured฀diagonally)฀from฀your฀PC฀or฀Mac฀computer฀(desktop฀or฀

notebook),฀VCR,฀DVD฀player,฀or฀document฀camera.

You฀can฀use฀the฀projector฀on฀a฀tabletop฀or฀cart,฀you฀can฀use฀the฀projector฀to฀project฀images฀from฀behind฀the฀screen,฀

and฀the฀projector฀can฀be฀permanently฀mounted฀on฀a฀ceiling*

.฀The฀remote฀control฀can฀be฀used฀wirelessly.

฀Do฀not฀attempt฀to฀mount฀the฀projector฀on฀a฀ceiling฀yourself.

฀The฀projector฀must฀be฀installed฀by฀qualied฀technicians฀in฀order฀to฀ensure฀proper฀operation฀and฀reduce฀the฀risk฀

of฀bodily฀injury.

฀In฀addition,฀the฀ceiling฀must฀be฀strong฀enough฀to฀support฀the฀projector฀and฀the฀installation฀must฀be฀in฀accordance฀

with฀any฀local฀building฀codes.฀Please฀consult฀your฀dealer฀for฀more฀information.

Features you’ll enjoy:

•฀0.2฀W฀(100-130฀V฀AC)/฀0.38฀W฀(200-240฀V฀AC)฀in฀standby฀condition฀with฀energy฀saving฀technology

฀Selecting฀[NORMAL]฀for฀[STANDBY฀MODE]฀from฀the฀menu฀can฀put฀the฀projector฀in฀power-saving฀mode.

฀NORMAL:฀0.2W(100-130V฀AC)/0.38W(200-240V฀AC)

฀NETWORK฀STANDBY:฀2.5W(100-130V฀AC)/2.9W(200-240V฀AC)

•฀Carbon฀Meter฀

฀This฀feature฀will฀show฀energy-saving฀effect฀in฀terms฀of฀CO

฀emission฀reduction฀(kg)฀when฀the฀projector’s฀[ECO฀

MODE]฀is฀set฀to฀[AUTO฀ECO],฀[NORMAL],฀or฀[ECO].

฀The฀amount฀of฀CO

฀emission฀reduction฀will฀be฀displayed฀in฀the฀conrmation฀message฀at฀the฀time฀of฀power-off฀and฀

in฀the฀INFO฀of฀the฀on-screen฀menu.

•฀Lamp฀life฀up฀to฀8000฀hours

฀Using฀in฀Eco฀Mode฀allows฀you฀to฀prolong฀the฀projector’s฀lamp฀life฀up฀to฀8000฀hours฀(up฀to฀3500฀hours฀in฀ECO฀

MODE฀OFF).฀

•฀No฀lter฀replacement฀required

฀Since฀the฀projector฀has฀no฀lters,฀lter฀replacement฀is฀not฀required.

•฀Two฀HDMI฀input฀ports฀provide฀digital฀signal฀

฀The฀two฀HDMI฀inputs฀provide฀HDCP฀compatible฀digital฀signals.฀The฀HDMI฀input฀also฀supports฀audio฀signal.

•฀20฀W฀built-in฀speaker฀for฀an฀integrated฀audio฀solution฀/mic฀input฀supprted

฀Powerful฀20฀watt฀monaural฀speaker฀provides฀volume฀need฀for฀large฀rooms฀a฀dynamic฀or฀condenser฀mic฀can฀be฀

used.

•฀The฀supplied฀remote฀control฀allows฀you฀to฀assign฀a฀CONTROL฀ID฀to฀the฀projector

฀Multiple฀projectors฀can฀be฀operated฀separately฀and฀independently฀with฀the฀same฀single฀remote฀control฀by฀assigning฀

an฀ID฀number฀to฀each฀projector.

•฀USB฀Display฀

฀Using฀a฀commercially฀available฀USB฀cable฀(compatible฀with฀USB฀2.0฀specications)฀to฀connect฀the฀computer฀with฀

the฀projector฀allows฀you฀to฀send฀your฀computer฀screen฀image฀to฀the฀projector฀without฀the฀need฀of฀a฀traditional฀

computer฀cable฀(VGA).

1. Introduction

•฀Integrated฀RJ-45฀connector฀for฀wired฀networking฀capability฀along฀with฀wireless฀networking฀capabilities

฀An฀RJ-45฀connector฀is฀standard.฀An฀optional฀USB฀Wireless฀LAN฀Unit฀is฀required฀for฀wireless฀LAN฀connection.

•฀Software฀programs฀(User฀Supportware)฀contained฀in฀the฀supplied฀CD-ROM

฀The฀supplied฀NEC฀Projector฀includes฀three฀programs:฀Virtual฀Remote฀Tool,฀Image฀Express฀Utility฀Lite฀(for฀Windows/

Mac฀OS),฀PC฀Control฀Utility฀Pro฀4฀(for฀Windows)/5฀(for฀Mac฀OS).฀

฀Image฀Express฀Utility฀Lite฀(for฀Windows)฀can฀be฀started฀from฀a฀commercially฀available฀USB฀memory฀or฀SD฀card฀

without฀the฀need฀of฀installing฀on฀your฀computer.

•฀Audio฀transfer฀capability฀(for฀Windows฀only)

฀Image฀Express฀Utility฀Lite฀allows฀you฀to฀send฀the฀computer’s฀screen฀image฀and฀audio฀to฀the฀projector฀over฀a฀network฀

or฀USB฀connection.

*฀Audio฀transfer฀capability฀is฀available฀only฀when฀the฀computer฀connects฀with฀the฀projector฀in฀peer-to-peer฀net-

work.

•฀AUTO฀POWER฀ON฀and฀AUTO฀POWER฀OFF฀features

฀The฀DIRECT฀POWER฀ON,฀AUTO฀POWER฀ON(COMP.),฀AUTO฀POWER฀OFF,฀and฀OFF฀TIMER฀features฀eliminate฀

the฀need฀to฀always฀use฀the฀POWER฀button฀on฀the฀remote฀control฀or฀projector฀cabinet.

•฀AUTO฀POWER฀OFF฀Function

฀The฀projector฀is฀preset฀at฀the฀factory฀so฀that฀it฀will฀automatically฀turn฀off฀if฀there฀is฀no฀signal฀present฀after฀a฀preset฀

duration.฀If฀you฀do฀not฀need฀this฀preset฀function,฀cancel฀it฀from฀the฀OSD฀menu.฀See฀page฀

102฀for฀more฀informa-

tion.

•฀Preventing฀unauthorized฀use฀of฀the฀projector

฀Enhanced฀smart฀security฀settings฀for฀keyword฀protection,฀cabinet฀control฀panel฀lock,฀security฀slot,฀and฀security฀

chain฀opening฀to฀help฀prevent฀unauthorized฀access,฀adjustments฀and฀theft฀deterrence.

•฀High฀resolution฀up฀to฀WUXGA

฀High฀resolution฀display฀-฀up฀to฀WUXGA฀compatible,฀XGA฀(M332XS)/WXGA฀(M352WS/M302WS)฀native฀resolu-

tion.

•฀3D฀Images฀supported

฀The฀projector฀provides฀3D฀images฀to฀a฀user฀wearing฀commercially฀available฀3D฀eyeglasses.

•฀CRESTRON฀ROOMVIEW฀compatibility

฀The฀projector฀supports฀CRESTRON฀ROOMVIEW,฀allowing฀multiple฀devices฀connected฀in฀the฀network฀to฀be฀man-

aged฀and฀controlled฀from฀a฀computer฀or฀controller.

1. Introduction

About this user’s manual

The฀fastest฀way฀to฀get฀started฀is฀to฀take฀your฀time฀and฀do฀everything฀right฀the฀rst฀time.฀Take฀a฀few฀minutes฀now฀to฀

review฀the฀user’s฀manual.฀This฀may฀save฀you฀time฀later฀on.฀At฀the฀beginning฀of฀each฀section฀of฀the฀manual฀you’ll฀nd฀

an฀overview.฀If฀the฀section฀doesn’t฀apply,฀you฀can฀skip฀it.

1. Introduction

Comparative Table of Main Features

The฀main฀features฀vary฀depending฀on฀the฀model฀as฀follows.

Short-Throw฀Models฀with฀Wide฀PanelShort-Throw฀Model

M352WS M302WS M332XS

Native฀Aspect฀Ratio16:10

Wide

4:3

Standard

Native฀Resolution฀(dots฀×฀

lines*

)฀

WXGA฀(1280฀×฀800)XGA฀(1024฀×฀768)

Screen฀Size฀60"฀-฀150"

Projection฀Distance22–58฀inches/0.57–1.5฀m฀27–70฀inches/0.68–1.8฀m

Light฀output฀*

฀in฀OFF฀for฀

ECO฀MODE฀

3500 lumens 3000 lumens 3300 lumens

Lamp฀Replacement฀Time฀

(average)฀

OFF฀for฀ECO฀MODE/ON฀for฀ECO฀MODE฀(H)

3500/8000 3500/8000 3500/8000

Lamp฀ModelNP30LPNP28LPNP30LP

Lamp฀Wattage฀(AC)270฀W225 W 270฀W

Zoom Using฀the฀[DIGITAL฀ZOOM]฀function฀from฀the฀menu

Focus฀Using฀the฀manual฀focus฀lever

For฀further฀details฀on฀the฀specications,฀see฀pages฀

134 to 135.

*1฀Effective฀pixels฀are฀more฀than฀99.99%.

*2฀This฀is฀the฀light฀output฀value฀(lumens)฀when฀the฀[PRESET]฀mode฀is฀set฀to฀[HIGH-BRIGHT].฀If฀any฀other฀mode฀is฀selected฀as฀the฀

[PRESET]฀mode,฀the฀light฀output฀value฀may฀drop฀slightly.

*3฀Compliance฀with฀ISO21118-2005

TIP:Themodelnameislocatedonthecabinet.

1. Introduction

❸ Part Names of the Projector

Front/Top

Focus Lever

(→ page 23)

[M352WS/M302WS/M332XS]

Remote Sensor

(→ page 11)

Exhaust Vent

Heated air is exhausted from here.

Lens Cap

Adjustable Tilt Foot Lever

(

→ page 21)

Adjustable Tilt Foot

(

→ page 21)

Lens

Security chain opening

Attach an anti-theft device.

The security chain opening accepts

security wires or chains up to 0.18

inch/4.6 mm in diameter.

Controls

(→ page 8)

Port Cover for Optional USB

Wireless LAN Unit

When using the optional USB

Wireless LAN Unit, ﬁrst remove

the cover. (

→ page 125)

Light Sensor

(→ page 93)

1. Introduction

Rear

[M352WS/M302WS/M332XS]

*฀This฀security฀slot฀supports฀the฀MicroSaver฀

฀Security฀System.

AC฀Input

Connect the supplied power cord’s

three-pin plug here, and plug the

other end into an active wall outlet.

(

→ page 16)

Built-in Security Slot (

Terminal Panel (

→ page 9)

Lamp Cover (

→ page 128)

Rear Feet (→ page 21)

Intake฀Vent

(→ page 127)

Monaural฀Speaker฀(20฀W)

Connection for cable cover (Left)

Screw holes

(

→ page 137)

Connection for cable cover (Right)

Screw holes

(

→ page 137)

1. Introduction

Top Features

1, 2

89 11

5610

713

1. ฀(POWER)฀Button฀

฀(→฀page฀17, 27)

2. POWER Indicator

฀(→฀page฀

16, 17, 27, 131)

3. STATUS Indicator

฀(→฀page฀

131)

4.฀LAMP฀Indicator฀

฀(→฀page฀

128, 131)

5.฀ECO฀Button฀

฀(→฀page฀

31)

6. SOURCE Button

฀(→฀page฀

19)

7.฀AUTO฀ADJ.฀Button฀

฀(→฀page฀

26)

8.฀MENU฀Button฀

฀(→฀page฀

78)

9. ▲▼◀▶฀/฀Volume฀Buttons฀◀▶฀/฀Keystone฀Buttons฀

▲▼

฀(→

฀page฀

24, 26, 78)

10.฀ENTER฀Button฀

฀(→฀page฀

78)

11.฀EXIT฀Button฀

฀(→฀page฀

78)

12.฀Wireless฀LAN฀Indicator฀(

)

฀When฀the฀projector฀is฀turned฀on฀with฀the฀optional฀wire-

less฀LAN฀unit฀inserted,฀the฀indicator฀will฀light฀up฀blue.

฀(→฀page฀124)

13. ECO Indicator

฀When฀[ECO฀MODE]฀is฀set฀to฀the฀other฀options฀than฀

[OFF],฀this฀indicator฀will฀light฀up฀green.

฀(→฀page฀

31)

NOTE:

•Allthebuttonsexcept▲▼◀▶willlightwhenpressed.

1. Introduction

Terminal Panel Features

1246

1211 10 35

1.฀COMPUTER฀IN/฀Component฀Input฀Connector฀

(Mini฀D-Sub฀15฀Pin)฀

฀(→฀page฀117, 119, 121)

2.฀COMPUTER฀AUDIO฀IN฀Mini฀Jack฀(Stereo฀Mini)฀

(→฀page฀

117, 119, 121)

3.฀HDMI฀1฀IN฀Connector฀(Type฀A)฀

(→฀page฀

117, 122)

4.฀HDMI฀2฀IN฀Connector฀(Type฀A)฀

(→฀page฀

117, 122)

5.฀USB-B฀Port฀(Type฀B)฀

(→฀page฀

42, 43)

6.฀MONITOR฀OUT฀(COMP.)฀Connector฀(Mini฀D-Sub฀

15฀Pin)฀

(→฀page฀

121)

7.฀AUDIO฀OUT฀Mini฀Jack฀(Stereo฀Mini)฀

฀(→฀page฀

121)

8.฀VIDEO฀IN฀Connector฀(RCA)฀

฀(→฀page฀

120)

9.฀VIDEO฀AUDIO฀IN฀L/MONO,฀R฀(RCA)฀

฀(→฀page฀

120)

10.฀MIC฀Input฀Jack฀(Monaural฀Mini)

฀(→฀page฀

69)

11.฀LAN฀Port฀(RJ-45)฀

฀(→฀page฀

123)

12.฀USB-A฀Port฀(Type฀A)฀

฀(→฀page฀

72)

13.฀3D฀SYNC฀(Mini฀DIN฀4฀Pin)

฀(→฀page฀

65)

14.฀PC฀CONTROL฀[PC฀CONTROL]฀Port฀(D-Sub฀9฀Pin)฀

฀(→฀page฀

140)

฀Use฀this฀port฀to฀connect฀a฀PC฀or฀control฀system.฀This฀

enables฀you฀to฀control฀the฀projector฀using฀serial฀commu-

nication฀protocol.฀If฀you฀are฀writing฀your฀own฀program,฀

typical฀PC฀control฀codes฀are฀on฀page฀140.

1. Introduction

❹ Part Names of the Remote Control

1. Infrared Transmitter

฀(→฀page฀11)

2. POWER ON Button

฀(→฀page฀

17, 27)

3. STANDBY Button

฀(→฀page฀

27)

4.฀SOURCE฀Button

฀(→฀page฀

19)

5,฀6.฀COMP1/COMP2฀Button

฀(→฀page฀

19)฀

฀(COMP2฀button฀does฀not฀work฀in฀

this฀series฀of฀projectors.)

7.฀AUTO฀ADJ.฀Button

฀(→฀page฀

26)

8,฀9.฀HDMI1/HDMI2฀Button฀

฀(→฀page฀

19)

10.฀DisplayPort฀Button฀

฀(This฀button฀does฀not฀work฀in฀this฀

series฀of฀projectors)

฀(→฀page฀

19)

11.฀VIDEO฀Button

฀(→฀page฀

19)

12.฀USB-A฀Button

฀(→฀page฀

19, 72)

13.฀USB-B฀Button฀

฀(→฀page฀

19)

14.฀LAN฀Button฀

฀(→฀page฀

19)

15.฀ID฀SET฀Button

฀(→฀page฀

98)

16.฀Numeric฀Keypad฀Button/

CLEAR Button

฀(→

฀page฀

98)

17. FREEZE Button

฀(→฀page฀

29)

18.฀AV-MUTE฀Button

฀(→฀page฀

29)

19. MENU Button

฀(→฀page฀

78)

20.฀EXIT฀Button฀

฀(→฀page฀

78)

21. ▲▼◀▶ Button

฀(→

฀page฀

78)

22. ENTER Button

฀(→฀page฀

78)

23.฀D-ZOOM฀(+)(–)฀Button

฀(→฀page฀

29)

24.฀MOUSE฀L-CLICK฀Button*

฀(→฀page฀

42)

25.฀MOUSE฀R-CLICK฀Button*

฀(→฀page฀

42)

26. PAGE ▽/△ Button

฀(→

฀page฀

42)

27. ECO Button

฀(→฀page฀

31)

28.฀KEYSTONE฀Button

฀(→฀page฀

24)

29. PICTURE Button

฀(→฀page฀

84, 86)

30.฀VOL.฀(+)(–)฀Button

฀(→฀page฀

26)

31. ASPECT Button

฀(→฀page฀

89)

32.฀FOCUS/ZOOM฀Button

฀The฀ZOOM฀button฀works฀on฀the฀

short-throw฀models฀only.฀The฀

FOCUS฀button฀does฀not฀work฀on฀

this฀series฀of฀projectors.

33. HELP Button

฀(→฀page฀

109)

*฀The฀MOUSE฀L-CLICK฀and฀MOUSE฀R-CLICK฀buttons฀work฀only฀when฀a฀USB฀cable฀is฀connected฀with฀your฀computer.

1. Introduction

Remote Control Precautions

•฀Handle฀the฀remote฀control฀carefully.

•฀If฀the฀remote฀control฀gets฀wet,฀wipe฀it฀dry฀immediately.

•฀Avoid฀excessive฀heat฀and฀humidity.

•฀Do฀not฀short,฀heat,฀or฀take฀apart฀batteries.

•฀Do฀not฀throw฀batteries฀into฀re.

•฀If฀you฀will฀not฀be฀using฀the฀remote฀control฀for฀a฀long฀time,฀remove฀the฀batteries.

•฀Ensure฀that฀you฀have฀the฀batteries’฀polarity฀(+/−)฀aligned฀correctly.

•฀Do฀not฀use฀new฀and฀old฀batteries฀together,฀or฀use฀different฀types฀of฀batteries฀together.

•฀฀Dispose฀of฀used฀batteries฀according฀to฀your฀local฀regulations.

Operating Range for Wireless Remote Control

22 feet/7 m

Remote control

Remote sensor on projector cabinet

Remote control

•฀The฀infrared฀signal฀operates฀by฀line-of-sight฀up฀to฀a฀distance฀of฀about฀22฀feet/7฀m฀and฀within฀a฀60-degree฀angle฀of฀

the฀remote฀sensor฀on฀the฀projector฀cabinet.

•฀The฀projector฀will฀not฀respond฀if฀there฀are฀objects฀between฀the฀remote฀control฀and฀the฀sensor,฀or฀if฀strong฀light฀falls฀

on฀the฀sensor.฀Weak฀batteries฀will฀also฀prevent฀the฀remote฀control฀from฀properly฀operating฀the฀projector.

Press฀rmly฀and฀slide฀the฀battery฀

cover฀off.

Install฀new฀batteries฀(AAA).฀Ensure฀

that฀you฀have฀the฀batteries’฀polarity฀

(+/−)฀aligned฀correctly.

Battery Installation

Slip฀the฀cover฀back฀over฀the฀bat-

teries฀until฀it฀snaps฀into฀place.฀Do฀

not฀mix฀different฀types฀of฀batteries฀

or฀new฀and฀old฀batteries.

OPEN

1. Introduction

❺ Operating Environment for Software Included on CD-ROM

Names฀and฀Features฀of฀Bundled฀Software฀Programs

Name฀of฀software฀programFeatures

Virtual฀Remote฀Tool

(Windows฀only)

This฀is฀a฀software฀program฀used฀to฀control฀the฀power฀ON/OFF฀and฀source฀selec-

tion฀of฀the฀projector฀from฀your฀computer฀by฀using฀the฀supplied฀computer฀cable฀

(VGA)฀and฀others.฀(→฀page฀

36)

Name฀of฀software฀programFeatures

Image฀Express฀Utility฀Lite•฀This฀is฀a฀software฀program฀used฀to฀project฀your฀computer’s฀screen฀or฀sound฀

from฀the฀computer฀over฀the฀USB฀cable฀or฀the฀wired/wireless฀network.฀The฀

computer฀cable฀(VGA)฀is฀not฀required.฀(→฀page฀

56)

•฀This฀software฀program฀can฀be฀used฀to฀control฀the฀power฀ON/OFF฀and฀source฀

selection฀of฀the฀projector฀from฀your฀computer.

•฀The฀Geometric฀Correction฀Tool฀(GCT)฀function฀allows฀you฀to฀correct฀distortion฀

of฀images฀projected฀on฀a฀curved฀wall.฀(→฀page฀63)

Image฀Express฀Utility฀Lite฀for฀

Mac฀OS

•฀This฀is฀a฀software฀program฀used฀to฀project฀your฀computer's฀screen฀over฀the฀

wired/wireless฀network.฀The฀computer฀cable฀(VGA)฀is฀not฀required.฀(→฀page฀

56, 61)฀

•฀This฀software฀program฀can฀be฀used฀to฀control฀the฀power฀ON/OFF฀and฀source฀

selection฀of฀the฀projector฀from฀your฀computer.฀

*฀“Audio฀transmission”,฀“USB฀Display”,฀and฀“GCT”฀functions฀are฀not฀supported฀

by฀Mac.

Name฀of฀software฀programFeatures

PC฀Control฀Utility฀Pro฀4

PC฀Control฀Utility฀Pro฀5฀(for฀Mac฀

OS)

This฀is฀a฀software฀program฀used฀to฀operate฀the฀projector฀from฀the฀computer฀when฀

the฀computer฀and฀the฀projector฀are฀connected฀with฀LAN฀(wired฀or฀wireless)฀or฀

a฀serial฀cable.฀(→฀page฀

52)

NOTE:

•ImageExpressUtilityLitedoesnotsupport"MeetingMode"inImageExpressUtility2.0includedwithourothermodels.

Download service

For฀the฀update฀information฀about฀these฀software฀programs,฀visit฀our฀website:

URL:฀

http://www.nec-display.com/dl/en/index.html

1. Introduction

Operating Environment

The฀following฀is฀the฀operating฀environment฀for฀Image฀Express฀Utility฀Lite.฀For฀the฀operating฀environment฀of฀other฀soft-

ware฀program,฀refer฀to฀the฀help฀function฀of฀each฀software฀program.

[Windows]

Supported฀OSWindows฀8฀(Core฀Edition)

Windows฀8฀Pro

Windows฀8฀Enterprise

Windows฀7฀Home฀Basic

Windows฀7฀Home฀Premium

Windows฀7฀Professional

Windows฀7฀Ultimate

Windows฀7฀Enterprise

Windows฀Vista฀Home฀Basic

Windows฀Vista฀Home฀Premium

Windows฀Vista฀Business

Windows฀Vista฀Ultimate

Windows฀Vista฀Enterprise

Windows฀XP฀Home฀Edition฀(32-bit฀version)฀Service฀Pack฀3฀or฀later

Windows฀XP฀Professional฀(32-bit฀version)฀Service฀Pack฀3฀or฀later

•฀Windows฀power-saving฀function฀is฀not฀supported.

•฀To฀use฀the฀audio฀transfer฀capability,฀Windows฀8/Windows฀7/Windows฀Vista฀

Service฀Pack฀1฀or฀later฀is฀required.

Processor •฀Windows฀8/Windows฀7/Windows฀Vista

Pentium฀M฀1.2฀GHz฀equivalent฀or฀higher฀required

Dual฀core฀1.5฀GHz฀or฀higher฀recommended

•฀Windows฀XP

Pentium฀M฀1.0฀GHz฀equivalent฀or฀higher฀required

Dual฀core฀1.0฀GHz฀or฀higher฀recommended

Memory•฀Windows฀8/Windows฀7/Windows฀Vista

512฀MB฀or฀more฀required

1฀GB฀or฀more฀recommended

•฀Windows฀XP

256฀MB฀or฀more฀required

512฀MB฀or฀more฀recommended

*฀More฀memory฀may฀be฀required฀to฀run฀additional฀applications฀simultane-

ously.

Graphic฀processor฀•฀Windows฀8/Windows฀7/Windows฀Vista

The฀“Graphics”฀score฀3.0฀or฀more฀of฀“Windows฀Experience฀Index”฀recom-

mended.

Network฀environmentTCP/IP-compatible฀wired฀LAN฀or฀wireless฀LAN

*฀Use฀a฀wireless฀LAN฀unit฀complying฀with฀the฀Wi-Fi฀standard.

*฀Audio฀transfer฀capability฀requires฀3฀Mbps฀or฀more฀throughput.

Resolution•฀Windows฀8/Windows฀7/Windows฀Vista฀

SVGA฀(800฀×฀600)฀or฀higher฀required

XGA฀(1024฀×฀768)฀recommended฀

•฀Windows฀XP฀

VGA฀(640฀×฀480)฀or฀higher฀required

XGA฀(1024฀×฀768)฀recommended

1024฀dots฀×฀768฀lines฀-฀1280฀dots฀×฀800฀lines฀recommended฀(M352WS/

M302WS)

Screen฀ColorsHigh฀Color฀(15฀bits,฀16฀bits)

True฀Color฀(24฀bits,฀32฀bits)฀(recommended)

•฀256฀or฀fewer฀colors฀are฀not฀supported.

1. Introduction

[Mac]

Supported฀OSMac฀OS฀X฀v10.6,฀v10.7,฀v10.8

Processor฀(CPU)Intel

฀Core™฀Duo฀processor฀1.5฀GHz฀or฀higher฀required

Intel

฀Core™฀2฀Duo฀processor฀1.6฀GHz฀or฀higher฀recommended

*฀PowerPC

฀is฀not฀supported

Memory512฀MB฀or฀higher฀required

Network฀environmentWired฀or฀wireless฀LAN฀required฀that฀supports฀TCP/IP

*฀The฀following฀LAN฀adapters฀are฀veried฀to฀work฀with฀Image฀Express฀Utility฀

Lite:

•฀Wired฀LAN฀adapter฀built฀into฀Mac

•฀Wireless฀LAN฀adapter฀built฀into฀Mac

•฀Apple฀USB฀Ethernet฀adapter

“Easy฀Connection”฀supports฀only฀wireless฀LAN.

Supported฀ResolutionSVGA฀(800฀×฀600)฀or฀higher฀required

XGA฀(1024฀×฀768)฀recommended

(1024฀×฀768฀–฀1280฀×฀800฀recommended฀for฀M352WS/M302WS)

Supported฀Screen฀Colors16.70฀million฀colors฀required

This฀section฀describes฀how฀to฀turn฀on฀the฀projector฀and฀to฀project฀a฀picture฀onto฀the฀screen.

❶ Flow of Projecting an Image

Step 1

•฀Connecting฀your฀computer฀/฀Connecting฀the฀power฀cord฀(→฀page฀16)

Step 2

•฀Turning฀on฀the฀projector฀(→฀page฀17)

Step 3

•฀Selecting฀a฀source฀(→฀page฀19)

Step 4

•฀Adjusting฀the฀picture฀size฀and฀position฀(→฀page฀20)

•฀Correcting฀keystone฀distortion฀[KEYSTONE]฀(→฀page฀24)

Step 5

•฀Adjusting฀a฀picture฀and฀sound

- Optimizing a computer signal automatically (→ page 26)

- Turning up or down volume (

→ page 26)

Step 6

•฀Making฀a฀presentation

Step 7

•฀Turning฀off฀the฀projector฀(→฀page฀27)

Step 8

•฀After฀use฀(→฀page฀28)

2. Projecting an Image (Basic Operation)

❷ Connecting Your Computer/Connecting the Power Cord

1.฀Connect฀your฀computer฀to฀the฀projector.

This section will show you a basic connection to a computer. For information about other connections, see “6.

Installation฀and฀Connections”฀on฀page฀117.

฀Connect฀the฀computer฀cable฀(VGA)฀between฀the฀projector’s฀COMPUTER฀IN฀connector฀and฀the฀computer’s฀port฀

(mini D-Sub 15 Pin). Turn two thumb screws of both connectors to ﬁx the computer cable (VGA).

2.฀Connect฀the฀supplied฀power฀cord฀to฀the฀projector.

฀First฀connect฀the฀supplied฀power฀cord’s฀three-pin฀plug฀to฀the฀AC฀IN฀of฀the฀projector,฀and฀then฀connect฀the฀other฀

plug of the supplied power cord in the wall outlet.

The projector’s power indicator will light red* (standby mode).

฀See฀the฀Power฀Indicator฀section.(→ page 131)

COMPUTER IN

Make฀sure฀that฀the฀prongs฀are฀fully฀inserted฀into฀

both฀the฀AC฀IN฀and฀the฀wall฀outlet.

To wall outlet

CAUTION:

Parts฀of฀the฀projector฀may฀become฀temporarily฀heated฀if฀the฀projector฀is฀turned฀off฀with฀the฀POWER฀button฀or฀if฀the฀

AC฀power฀supply฀is฀disconnected฀during฀normal฀projector฀operation.

Use฀caution฀when฀picking฀up฀the฀projector.

2. Projecting an Image (Basic Operation)

StandbyBlinkingPower฀On

Steady red light Blinking blue

light

Steady blue

light

❸ Turning on the Projector

1. Remove the lens cap.

2. Press the (POWER) button on the projector cabinet

or the POWER ON button on the remote control.

The POWER indicator will turn to blue and the projector

will become ready to use.

TIP:

•Whenthemessage“Projectorislocked!Enteryourpassword.”

isdisplayed,itmeansthatthe[SECURITY]featureisturnedon.

(→page33)

After you turn on your projector, ensure that the computer

or video source is turned on and that the lens cover is

open.

NOTE:Whennoinputsignalispresent,theno-signalguidanceis

displayed(factorymenusetting).

(→฀page฀131)

Lens cap

2. Projecting an Image (Basic Operation)

Note on Startup screen (Menu Language Select screen)

When฀you฀rst฀turn฀on฀the฀projector,฀you฀will฀get฀the฀Startup฀menu.฀This฀menu฀gives฀you฀the฀opportunity฀to฀select฀one฀

of฀the฀menu฀languages.

To฀select฀a฀menu฀language,฀follow฀these฀steps:

1. Use the ▲, ▼, ◀ or ▶฀button฀to฀select฀one฀of฀the฀lan-

guages฀from฀the฀menu.

2. Press the ENTER button to execute the selection.

After฀this฀has฀been฀done,฀you฀can฀proceed฀to฀the฀menu฀

operation.

If฀you฀want,฀you฀can฀select฀the฀menu฀language฀later.

(→฀[LANGUAGE]฀on฀page฀80 and 94)

NOTE:

•Whenturningoffthepowersupplyandthenbackonbyusingapowerstriporbreaker.

Allowaminimumof1secondbetweenturningoffthemainpowersupplyandturningitbackonagain.

Failingtodosocouldresultinnopowertotheprojector.(Therewillbenostand-byLED)

Shouldthishappen,unplugthepowercordandplugitinagain.Turnonthemainpower.

•Ifoneofthefollowingthingshappens,theprojectorwillnotturnon.

•Iftheinternaltemperatureoftheprojectoristoohigh,theprojectordetectsabnormalhightemperature.Inthisconditionthe

projectorwillnotturnontoprotecttheinternalsystem.Ifthishappens,waitfortheprojector’sinternalcomponentstocool

down.

•Whenthelampreachesitsendofusablelife,theprojectorwillnotturnon.Ifthishappens,replacethelamp.

•IftheSTATUSindicatorlightsorangewiththepowerbuttonpressed,itmeansthatthe[CONTROLPANELLOCK]isturnedon.

Cancelthelockbyturningitoff.(→page97)

•Ifthelampfailstolight,andiftheSTATUSindicatorashesonandoffinacycleofsixtimes,waitafullminuteandthenturnon

thepower.

•WhilethePOWERindicatorisblinkingblueinshortcycles,thepowercannotbeturnedoffbyusingthepowerbutton.

•Immediatelyafterturningontheprojector,screenickermayoccur.Thisisnormal.Wait3to5minutesuntilthelamplightingis

stabilized.

•Whentheprojectoristurnedon,itmaytakesometimebeforethelamplightbecomesbright.

•Ifyouturnontheprojectorimmediatelyafterthelampisturnedofforwhenthetemperatureishigh,thefansrunwithoutdisplay-

inganimageforsometimeandthentheprojectorwilldisplaytheimage.

2. Projecting an Image (Basic Operation)

❹ Selecting a Source

Selecting the computer or video source

NOTE:Turnonthecomputerorvideosourceequipmentconnectedtotheprojector.

Detecting฀the฀Signal฀Automatically

Press฀the฀SOURCE฀button฀once.฀The฀projector฀will฀search฀for฀the฀available฀

input฀source฀and฀display฀it.฀The฀input฀source฀will฀change฀as฀follows:฀

COMPUTER฀→฀HDMI1฀→฀HDMI2฀→฀VIDEO฀→฀USB-A฀→฀LAN฀→฀USB-B฀

→฀COMPUTER฀→ ...

•฀With฀the฀SOURCE฀screen฀displayed,฀you฀can฀press฀the฀SOURCE฀

button฀a฀few฀times฀to฀select฀the฀input฀source.

TIP:Ifnoinputsignalispresent,theinputwillbeskipped.

Using the Remote Control

Press฀any฀one฀of฀the฀COMP1,฀HDMI1,฀HDMI2,฀VIDEO,฀USB-A,฀LAN,฀or฀

USB-B฀buttons.

Selecting Default Source

You฀can฀set฀a฀source฀as฀the฀default฀source฀so฀that฀it฀will฀be฀displayed฀

each฀time฀the฀projector฀is฀turned฀on.

1. Press the MENU button.

The menu will be displayed.

2. Press the

▶฀button฀twice฀to฀select฀[SETUP]฀and฀press฀the฀▼ but-

ton฀or฀the฀ENTER฀button฀to฀select฀[GENERAL].

Press the

▶

฀button฀four฀times฀to฀select฀[OPTIONS(2)].

4. Press the ▼฀button฀ve฀times฀to฀select฀[DEFAULT฀SOURCE฀SE-

LECT]฀and฀press฀the฀ENTER฀button.

The [DEFAULT SOURCE SELECT] screen will be displayed.

(

→ page 102)

5.฀Select฀a฀source฀as฀the฀default฀source,฀and฀press฀the฀ENTER฀but-

ton.

6.฀Press฀the฀EXIT฀button฀a฀few฀times฀to฀close฀the฀menu.

7. Restart the projector.

The source you selected in step 5 will be projected.

TIP:

•WhentheprojectorisinStandbymode,applyingacomputersignalfroma

computerconnectedtotheCOMPUTERINinputwillpowerontheprojector

andsimultaneouslyprojectthecomputer’simage.

([AUTOPOWERON(COMP.)]→page102)

•OnWindows7,acombinationoftheWindowsandPkeysallowsyoutosetup

externaldisplayeasilyandquickly.

2. Projecting an Image (Basic Operation)

❺ Adjusting the Picture Size and Position

Use฀the฀adjustable฀tilt฀foot,฀the฀zoom฀function฀or฀the฀focus฀ring฀to฀adjust฀the฀picture฀size฀and฀position.

In฀this฀chapter฀drawings฀and฀cables฀are฀omitted฀for฀clarity.

Adjusting฀the฀throw฀angle฀(the฀height฀of฀an฀image)

[Tilt฀foot]฀(→฀page฀21)

Adjusting฀the฀left฀and฀right฀tilt฀of฀an฀image

[Rear฀foot]฀(→฀page฀21)

Finely฀adjusting฀the฀size฀of฀an฀image

[Zoom฀lever]฀(→฀page฀22)

Adjusting฀the฀focus

[Focus฀ring]฀(→฀page฀23)

Adjusting฀the฀keystone฀correction฀[KEYSTONE]*฀(→฀page฀24)

*฀Automatic฀Keystone฀Correction฀function฀is฀turned฀on฀at฀the฀time฀of฀shipment.฀To฀perform฀keystone฀correction฀manually,฀see฀“6.฀

Correcting฀Keystone฀Distortion฀Manually”฀on฀page฀

24.

2. Projecting an Image (Basic Operation)

Adjustable Tilt Foot

Adjustable Tilt

Foot Lever

Adjust the Tilt Foot

1.฀฀Lift฀the฀front฀edge฀of฀the฀projector.

CAUTION:

Do฀not฀try฀to฀touch฀the฀exhaust฀vent฀during฀Tilt฀Foot฀adjustment฀as฀

it฀can฀become฀heated฀while฀the฀projector฀is฀turned฀on฀and฀after฀it฀is฀

turned฀off.

2.฀฀Push฀up฀and฀hold฀the฀Adjustable฀Tilt฀Foot฀Lever฀on฀the฀front฀of฀

the฀projector฀to฀extend฀the฀adjustable฀tilt฀foot.

3.฀฀Lower฀the฀front฀of฀the฀projector฀to฀the฀desired฀height.

4.฀฀Release฀the฀Adjustable฀Tilt฀Foot฀Lever฀to฀lock฀the฀Adjustable฀tilt฀

foot.

The tilt foot can be extended up to 2 inches/52 mm.

There is approximately 10 degrees (up) of adjustment for the front of

the projector.

Rotate the rear foot to the desired height in order to square the image

on the projection surface.

CAUTION:

•฀Do฀not฀use฀the฀tilt-foot฀for฀purposes฀other฀than฀originally฀intended.

฀Misuses฀such฀as฀using฀the฀tilt฀foot฀to฀carry฀or฀hang฀(from฀the฀wall฀or฀

ceiling)฀the฀projector฀can฀cause฀damage฀to฀the฀projector.

Adjusting฀the฀left฀and฀right฀tilt฀of฀an฀image฀[Rear฀foot]

•฀Rotate฀the฀rear฀foot.

The rear foot can be extended up to 1 inch/26.5 mm. Rotating the rear

foot allows the projector to be placed horizontally.

NOTE:

•Donotextendtherearfootbeyonditsheightlimit(1inch/26.5mm).Doingso

maycausetherearfoottocomeoutoftheprojector.

•Ifextendingtheleftrearfoot(viewedfromtherear)causestheprotrusionto

interferewiththeoor,extendtherightrearfootby0.5inch/12mmorlonger.

Ifextendingtherightrearfootcausestheprotrusiontointerferewiththeoor,

extendtheleftrearfootby0.3inch/8mm.



Rear feet

Up Down

2. Projecting an Image (Basic Operation)

Zoom

The฀image฀size฀can฀be฀adjusted฀electronically฀from฀the฀menu.฀To฀do฀so,฀follow฀the฀steps฀below.

Adjusting฀with฀the฀ZOOM฀button฀on฀the฀remote฀control

1. Press the ZOOM button.

฀The฀DIGITAL฀ZOOM฀bar฀will฀be฀displayed.

2. Press the ◀ or ▶฀button฀to฀adjust฀the฀image฀size.฀

3.฀Press฀the฀EXIT฀button.

฀The฀DIGITAL฀ZOOM฀bar฀will฀be฀closed.฀

2. Projecting an Image (Basic Operation)

Focus

Use฀the฀FOCUS฀lever฀to฀obtain฀the฀best฀focus.

Focus Lever

2. Projecting an Image (Basic Operation)

❻ Correcting Keystone Distortion Manually

If฀the฀screen฀is฀tilted฀vertically,฀keystone฀distortion฀becomes฀large.฀Automatic฀Keystone฀Correction฀function฀is฀turned฀on฀

at฀the฀time฀of฀shipment.฀To฀correct฀keystone฀distortion฀manually,฀proceed฀with฀the฀following฀steps฀to฀correct฀keystone฀

distortion.

NOTE:

•TheKeystonecorrectioncancauseanimagetobeslightlyblurredbecausethecorrectionismadeelectronically.

•TheKeystonecorrectionrangecanbemadenarrower,dependingonasignaloritsaspectratioselection.

Adjusting with buttons on the cabinet

1. Press the ▲ or ▼฀button฀with฀no฀menus฀displayed.

฀The฀keystone฀bar฀will฀be฀displayed.

2. Use the ▲ or ▼฀to฀correct฀the฀keystone฀distortion.

฀The฀keystone฀bar฀will฀be฀closed฀after฀a฀period฀of฀time.

3. Press the ENTER button.

฀The฀keystone฀bar฀will฀be฀closed.

NOTE:

•Whenthemenuisdisplayed,theaboveoperationisnotavailable.Whenthemenuisdisplayed,presstheMENUbuttontoclose

themenuandstarttheKeystonecorrection.

Fromthemenu,select[SETUP]→[GENERAL]→[KEYSTONE].Thechangescanbesavedwith[KEYSTONESAVE].(→page

92)

•Keystonecontrolisnotavailablewiththe▲or▼buttonwhenthe[USB-B]inputisused.

2. Projecting an Image (Basic Operation)

Adjusting with the remote control

1.฀Press฀the฀KEYSTONE฀button.

The Keystone bar will be displayed.

2. Use the ◀ or ▶฀button฀to฀correct฀the฀keystone฀distortion.

Adjust so that the right and left sides are parallel.

3.฀Press฀the฀EXIT฀button.

The Keystone bar will be closed.

2. Projecting an Image (Basic Operation)

❼ Optimizing Computer Signal Automatically

Adjusting the Image Using Auto Adjust

Optimizing฀a฀computer฀image฀automatically.฀(COMPUTER)

Press฀the฀AUTO฀ADJ.฀button฀to฀optimize฀a฀computer฀image฀automatically.

This฀adjustment฀may฀be฀necessary฀when฀you฀connect฀your฀computer฀for฀the฀rst฀time.

[Poor picture]

[Normal picture]

NOTE:

Somesignalsmaytaketimetodisplayormaynotbedisplayedcorrectly.

•IftheAutoAdjustoperationcannotoptimizethecomputersignal,trytoadjust[HORIZONTAL],[VERTICAL],[CLOCK],and[PHASE]

manually.(→page87,88)

❽ Turning Up or Down Volume

Sound฀level฀from฀the฀speaker฀can฀be฀adjusted.

TIP:Whennomenusappear,the◀and▶buttonsontheprojectorcabinetwork

asavolumecontrol.

NOTE:

•Volumecontrolisnotavailablewiththe◀or▶buttonwhenanimageisenlarged

byusingtheD-ZOOM(+)buttonorwhenthemenuisdisplayed.

•Volumecontrolisnotavailablewiththe◀or▶buttonwhenVIEWERis

used.

TIP:The[BEEP]soundvolumecannotbeadjusted.Toturnoffthe[BEEP]sound,

fromthemenu,select[SETUP]→[OPTIONS(1)]→[BEEP]→[OFF].

Increase฀volume

Decrease volume

2. Projecting an Image (Basic Operation)

❾ Turning off the Projector

To฀turn฀off฀the฀projector:

1. First, press the (POWER) button on the projector

cabinet or the STANDBY button on the remote con-

trol.

The conﬁrmation message will be displayed.

2.฀Secondly,฀press฀the฀ENTER฀button฀or฀press฀the฀

(POWER)฀or฀the฀STANDBY฀button฀again.

฀After฀the฀projector฀turns฀off,฀the฀cooling฀fans฀keep฀operating฀

for a while (Cooling-off time).

The cooling fans stop operating when the projector turns

off and goes into standby mode. When in standby mode,

the POWER indicator will light red and the STATUS indica-

tor will light off when [NORMAL] is selected for [STANDBY

MODE].

Power฀On

Steady blue light

Standby

Steady

red light

CAUTION:

Parts฀of฀the฀projector฀may฀become฀temporarily฀heated฀if฀the฀projector฀is฀turned฀off฀with฀the฀POWER฀button฀or฀if฀the฀

AC฀power฀supply฀is฀disconnected฀during฀normal฀projector฀operation.

Use฀caution฀when฀picking฀up฀the฀projector.

NOTE:

•Whilethepowerindicatorisblinkingblueinshortcycles,thepowercannotbeturnedoff.

•Youcannotturnoffthepowerfor60secondsimmediatelyafterturningitonanddisplayinganimage.

•DonotdisconnecttheACpowersupplytotheprojectorwithin10secondsofmakingadjustmentorsettingchangesandclosing

themenu.Doingsocancauselossofadjustmentsandsettings.

2. Projecting an Image (Basic Operation)

❿ After Use

Preparation:฀Make฀sure฀that฀the฀projector฀is฀turned฀off.

1.฀Unplug฀the฀power฀cord.

2. Disconnect any other cables.

•฀Remove฀the฀USB฀memory฀if฀it฀is฀inserted฀into฀the฀projector.

3.฀Retract฀adjustable฀tilt฀foot฀if฀extended.

4. Reattach the lens cap

① Put the lens cap on the top of the lens.

② Push to cover the lens completely.

CAUTION:

Use฀caution฀when฀putting฀the฀projector฀in฀the฀soft฀case฀immediately฀after฀the฀projector฀has฀been฀operating.฀The฀

projector฀cabinet฀is฀hot.

❶ Turning off the Image and Sound

Press฀the฀AV-MUTE฀button฀to฀turn฀off฀the฀image฀and฀sound฀for฀a฀short฀

period฀of฀time.฀Press฀again฀to฀restore฀the฀image฀and฀sound.

The฀projector’s฀power-saving฀function฀will฀work฀10฀seconds฀after฀the฀im-

age฀is฀turned฀off.

As฀a฀result,฀the฀lamp฀power฀will฀be฀reduced.

NOTE:

•

Eventhoughtheimageisturnedoff,themenustillremainsonthescreen.

•SoundfromtheAUDIOOUTjack(Stereomini)canbeturnedoff.

•Evenwhenthepower-savingfunctionworks,thelamppowermayberestored

toitsoriginalleveltemporarily.

•Torestoretheimage,evenifyoupresstheAV-MUTEbuttonimmediatelyafter

thestartofthepower-savingfunction,thelampbrightnessmaynotberestored

toitsoriginallevel.

❷ Freezing a Picture

Press฀the฀FREEZE฀button฀to฀freeze฀a฀picture.฀Press฀again฀to฀resume฀

motion.

NOTE:

•Theimageisfrozenbuttheoriginalvideoisstillplayingback.

•WithImageExpressUtilityincludingUSBDisplay,pressingtheFREEZEbutton

willeliminatesoundtemporarilyduringdisplayoffreezedimage.

❸ Enlarging a Picture

You฀can฀enlarge฀the฀picture฀up฀to฀four฀times.

NOTE:Themaximummagnicationmaybelessthanfourtimesdependingon

thesignal.

To฀do฀so:

1.฀Press฀the฀D-ZOOM฀(+)฀button฀to฀magnify฀the฀picture.

To move the magniﬁed image, use the ▲,▼,◀ or ▶ button.

3. Convenient Features

2. Press the ▲▼◀▶ button.

The area of the magniﬁed image will be moved

3. Press the D-ZOOM (−) button.

฀Each฀time฀the฀D-ZOOM฀(−)฀button฀is฀pressed,฀the฀image฀is฀reduced.

NOTE:

•Theimagewillbeenlargedorreducedatthecenterofthescreen.

•Displayingthemenuwillcancelthecurrentmagnication.

3. Convenient Features

❹ Changing Eco Mode/Checking Energy-Saving Effect

Using Eco Mode [ECO MODE]

The฀ECO฀MODE฀(NORMAL฀and฀ECO)฀increases฀lamp฀life,฀while฀lowering฀power฀consumption฀and฀cutting฀down฀on฀

emissions.

Four฀brightness฀modes฀of฀the฀lamp฀can฀be฀selected:฀[OFF],฀[AUTO฀ECO],฀[NORMAL]฀and฀[ECO]฀modes.฀

[ECO฀MODE]฀Description

Status฀of฀LAMP฀

indicator

Status฀of฀

ECO฀indi-

cator

[OFF]

The฀lamp฀brightness฀is฀100%.

OffOff

[AUTO฀ECO]

Lamp฀power฀consumption฀will฀be฀controlled฀between฀

[OFF]฀and฀[ECO]฀automatically฀according฀to฀picture฀

level.

NOTE:Abrightgradationmaybelessvisibledependingon

theimage.

Steady฀

Green฀light

Steady฀

Green฀light

[NORMAL]Lamp฀power฀consumption.฀(approx.81%฀brightness฀on฀

M352WS/M332XS฀and฀approx.฀76%฀on฀M302WS)฀The฀

lamp฀life฀will฀extend฀by฀lowering฀the฀lamp฀power.

[ECO]

Lamp฀power฀consumption฀(approx.฀60%฀brightness).฀

The฀lamp฀life฀will฀extend฀longer฀than฀the฀one฀on฀NOR-

MAL฀mode฀by฀controlling฀power฀appropriate฀for฀the฀

lamp.฀The฀maximum฀power฀becomes฀equivalent฀to฀the฀

power฀in฀NORMAL.

To฀turn฀on฀the฀[ECO฀MODE],฀do฀the฀following:฀

1.฀Press฀the฀ECO฀Button฀on฀the฀remote฀control฀to฀display฀[ECO฀MODE]฀screen.

2.฀Press฀the฀ECO฀button฀again฀to฀select฀a฀mode฀you฀wish.฀

•฀Each฀time฀the฀ECO฀button฀is฀pressed,฀the฀choices฀will฀be฀changed:

OFF → AUTO ECO → NORMAL → ECO → OFF

TIP:

•TheleafsymbolatthebottomofthemenushowsthecurrentselectionofECOmode.

NOTE:

•Immediatelyafterthemenuitemisselectedfor[ECOMODE],thescreenmayicker.Thisisnotmalfunction.

•The[ECOMODE]canbechangedbyusingthemenu.

Select[SETUP]→[GENERAL]→[ECOMODE].

•Thelampliferemainingandlamphoursusedcanbecheckedin[USAGETIME].Select[INFO.]→[USAGETIME].

•Theprojectorisalwaysin[NORMAL]for90secondsafterthelampisturnedonandwhilethePOWERindicatorisblinkinggreen.

Thelampconditionwillnotbeaffectedevenwhen[ECOMODE]ischanged.

•Afteralapseof1minutefromwhentheprojectordisplaysno-signalguidance,ablue,blackorlogoscreen,[ECOMODE]will

automaticallyswitchto[ECO].

•Iftheprojectorisoverheatedin[OFF]mode,theremaybeacasewherethe[ECOMODE]automaticallychangesto[NORMAL]

modetoprotecttheprojector.Whentheprojectorisin[NORMAL]mode,thepicturebrightnessdecreases.Whentheprojector

comesbacktonormaltemperature,the[ECOMODE]returnsto[OFF]mode.

Thermometersymbol[

]indicatesthe[ECOMODE]isautomaticallysetto[NORMAL]modebecausetheinternaltemperature

istoohigh.

3. Convenient Features

Checking Energy-Saving Effect [CARBON METER]

This฀feature฀will฀show฀energy-saving฀effect฀in฀terms฀of฀CO

฀emission฀reduction฀(kg)฀when฀the฀projector’s฀[ECO฀MODE]฀

is฀set฀to฀[AUTO฀ECO],฀[NORMAL],฀or฀[ECO].฀This฀feature฀is฀called฀as฀[CARBON฀METER].

There฀are฀two฀messages:฀[TOTAL฀CARBON฀SAVINGS]฀and฀[CARBON฀SAVINGS-SESSION].฀The฀[TOTAL฀CARBON฀

SAVINGS]฀message฀shows฀the฀total฀amount฀of฀CO

฀emission฀reduction฀from฀the฀time฀of฀shipment฀up฀to฀now.฀You฀can฀

check฀the฀information฀on฀[USAGE฀TIME]฀from฀[INFO.]฀of฀the฀menu.฀(→฀page฀

109)

The฀[CARBON฀SAVINGS-SESSION]฀message฀shows฀the฀amount฀of฀CO

฀emission฀reduction฀between฀the฀time฀of฀

changing฀to฀ECO฀MODE฀immediately฀after฀the฀time฀of฀power-on฀and฀the฀time฀of฀power-off.฀The฀[CARBON฀SAVINGS-

SESSION]฀message฀will฀be฀displayed฀in฀the฀[POWER฀OFF/฀ARE฀YOU฀SURE?]฀message฀at฀the฀time฀of฀power-off.

TIP:

•TheformulaasshownbelowisusedtocalculatetheamountofCO

emissionreduction.

AmountofCO

emissionreduction=(PowerconsumptioninOFFforECOMODE−PowerconsumptioninAUTOECO/NORMAL/

ECOforECOMODE)×CO

conversionfactor.*WhentheimageisturnedoffwiththeAV-MUTEbuttonorwiththelenscover

closed,theamountofCO

emmissionreductionwillalsoincrease.

*CalculationforamountofCO

emissionreductionisbasedonanOECDpublication“CO

EmissionsfromFuelCombustion,2008

Edition”.

•The[TOTALCARBONSAVINGS]iscalculatedbasedonsavingsrecordedin15minutesintervals.

•Thisformulawillnotapplytothepowerconsumptionwhichisnotaffectedbywhether[ECOMODE]isturnedonoroff.

3. Convenient Features

❺

Preventing the Unauthorized Use of the Projector [SECURITY]

A฀keyword฀can฀be฀set฀for฀your฀projector฀using฀the฀Menu฀to฀avoid฀operation฀by฀an฀unauthorized฀user.฀When฀a฀keyword฀

is฀set,฀turning฀on฀the฀projector฀will฀display฀the฀Keyword฀input฀screen.฀Unless฀the฀correct฀keyword฀is฀entered,฀the฀pro-

jector฀cannot฀project฀an฀image.฀

•฀The฀[SECURITY]฀setting฀cannot฀be฀cancelled฀by฀using฀the฀[RESET]฀of฀the฀menu.

To฀enable฀the฀Security฀function:

1. Press the MENU button.

The menu will be displayed.

2. Press the

▶฀button฀twice฀to฀select฀[SETUP]฀and฀press฀the฀▼฀button฀or฀the฀ENTER฀button฀to฀select฀[GEN-

ERAL].

3. Press the ▶฀button฀to฀select฀[INSTALLATION].

4. Press the ▼฀button฀three฀times฀to฀select฀[SECURITY]฀and฀press฀the฀ENTER฀button.

The OFF/ON menu will be displayed.

5. Press the

▼฀button฀to฀select฀[ON]฀and฀press฀the฀ENTER฀button.

฀The฀[SECURITY฀KEYWORD]฀screen฀will฀be฀displayed.

6.฀Type฀in฀a฀combination฀of฀the฀four฀▲▼◀▶฀buttons฀and฀press฀the฀ENTER฀button.

NOTE:Akeywordmustbe4to10digitsinlength.

฀The฀[CONFIRM฀KEYWORD]฀screen฀will฀be฀displayed.

3. Convenient Features

7.฀Type฀in฀the฀same฀combination฀of฀▲▼◀▶฀buttons฀and฀press฀the฀ENTER฀button.

The conﬁrmation screen will be displayed.

8.฀Select฀[YES]฀and฀press฀the฀ENTER฀button.

฀The฀SECURITY฀function฀has฀been฀enabled.

To฀turn฀on฀the฀projector฀when฀[SECURITY]฀is฀enabled:

1. Press the POWER button.

฀The฀projector฀will฀be฀turned฀on฀and฀display฀a฀message฀to฀the฀effect฀that฀the฀projector฀is฀locked.

2. Press the MENU button.

3.฀Type฀in฀the฀correct฀keyword฀and฀press฀the฀ENTER฀button.฀The฀projector฀will฀display฀an฀image.

NOTE:Thesecuritydisablemodeismaintaineduntilthemainpoweristurnedofforunpluggingthepowercord.

3. Convenient Features

To฀disable฀the฀SECURITY฀function:

1. Press the MENU button.

The menu will be displayed.

2.฀฀Select฀[SETUP]฀→฀[INSTALLATION]฀→฀[SECURITY]฀and฀press฀the฀ENTER฀button.

The OFF/ON menu will be displayed.

3.฀Select฀[OFF]฀and฀press฀the฀ENTER฀button.

฀The฀SECURITY฀KEYWORD฀screen฀will฀be฀displayed.

4.฀Type฀in฀your฀keyword฀and฀press฀the฀ENTER฀button.

฀When฀the฀correct฀keyword฀is฀entered,฀the฀SECURITY฀function฀will฀be฀disabled.

NOTE:Ifyouforgetyourkeyword,contactyourdealer.Yourdealerwillprovideyouwithyourkeywordinexchangeforyourrequest

code.YourrequestcodeisdisplayedintheKeywordConrmationscreen.Inthisexample[NB52-YGK8-2VD6-K585-JNE6-EYA8]

isarequestcode.

3. Convenient Features

❻ Using the Computer Cable (VGA) to Operate the

Projector (Virtual Remote Tool)

Using฀the฀utility฀software฀“Virtual฀Remote฀Tool”฀included฀on฀the฀companion฀NEC฀Projector฀CD-ROM,฀Virtual฀Remote฀

screen฀(or฀toolbar)฀can฀be฀displayed฀on฀your฀computer฀screen.

This฀will฀help฀you฀perform฀operations฀such฀as฀projector’s฀power฀on฀or฀off฀and฀signal฀selection฀via฀the฀computer฀cable฀

(VGA),฀serial฀cable,฀or฀LAN฀connection.

Control Functions

Power฀On/Off,฀signal฀selection,฀picture฀freeze,฀picture฀mute,฀audio฀mute,฀and฀remote฀control฀operation฀on฀your฀

PC.

Virtual฀Remote฀screenToolbar

This฀section฀provides฀an฀outline฀of฀preparation฀for฀use฀of฀Virtual฀Remote฀Tool.

For฀information฀on฀how฀to฀use฀Virtual฀Remote฀Tool,฀see฀Help฀of฀Virtual฀Remote฀Tool.฀(→฀page฀

41)

Step฀1:฀Install฀Virtual฀Remote฀Tool฀on฀the฀computer.฀(→฀page฀37)

Step฀2:฀Connect฀the฀projector฀to฀the฀computer.฀(→฀page฀39)

Step฀3:฀Start฀Virtual฀Remote฀Tool.฀(→฀page฀40)

TIP:

•VirtualRemoteToolcanbeusedwithaLANandaserialconnection.USBconnectionisnotsupportedbyVirtualRemoteTool.

•ForupdateinformationonVirtualRemoteTool,visitourwebsite:

http://www.nec-display.com/dl/en/index.html

3. Convenient Features

NOTE:

•When[COMPUTER]isselectedfromyoursourceselection,theVirtualRemotescreenorthetoolbarwillbedisplayedaswellas

yourcomputerscreen.

•Usethesuppliedcomputercable(VGA)toconnecttheCOMPUTERINconnectordirectlywiththemonitoroutputconnectorof

thecomputertouseVirtualRemoteTool.

Usingaswitcherorothercablesthanthesuppliedcomputercable(VGA)maycausefailureinsignalcommunication.

VGAcableconnector:

PinNos.12and15arerequiredforDDC/CI.

•VirtualRemoteToolmaynotworkdependingonyourcomputer’sspecicationsandversionofgraphicadaptersordrivers.

•TorunVirtualRemoteToolonWindows8andWindowsXP,“Microsoft.NETFrameworkVersion2.0”isrequired.TheMicrosoft

.NETFrameworkVersion2.0,3.0or3.5isavailablefromMicrosoft’swebpage.Downloadandinstalltheitonyourcomputer.

TIP:

•Theprojector’sCOMPUTERINconnectorsupportsDDC/CI(DisplayDataChannelCommandInterface).DDC/CIisastandard

interfaceforbidirectionalcommunicationbetweendisplay/projectorandcomputer.

Step 1: Install Virtual Remote Tool on the computer

NOTE:

•ToinstallVirtualRemoteTool,theWindowsuseraccountmusthave“Administrator”privilege(Windows8,Windows7,Windows

VistaandWindowsXP).

•ExitallrunningprogramsbeforeinstallingVirtualRemoteTool.Ifanotherprogramisrunning,theinstallationmaynotbecom-

pleted.

1฀Insert฀the฀accompanying฀NEC฀Projector฀CD-ROM฀into฀your฀CD-ROM฀drive.

The menu window will be displayed.

3. Convenient Features

TIP:

Ifthemenuwindowwillnotbedisplayed,trythefollowingprocedure.

ForWindows7

1.฀Click฀“start”฀on฀Windows.

2.฀Click฀“All฀Programs”฀→฀“Accessories”฀→฀“Run”.

3.฀Type฀your฀CD-ROM฀drive฀name฀(example:฀“Q:\”)฀and฀“LAUNCHER.EXE”฀in฀“Name”.฀(example:฀Q:\

LAUNCHER.EXE)

4.฀Click฀“OK”.

The menu window will be displayed.

2฀Click฀“Install฀Virtual฀Remote฀Tool”฀on฀the฀menu฀window.

The installation will start.

When the installation is complete, the Welcome window will be displayed.

3฀Click฀“Next”.

฀“END฀USER฀LICENSE฀AGREEMENT”฀screen฀will฀be฀displayed.

฀Read฀“END฀USER฀LICENSE฀AGREEMENT”฀carefully.

4฀If฀you฀agree,฀click฀“I฀accept฀the฀terms฀in฀the฀license฀agreement”฀and฀then฀click฀“Next”.

•฀Follow฀the฀instructions฀on฀the฀installer฀screens฀to฀complete฀the฀installation.

•฀When฀the฀installation฀is฀complete,฀you฀will฀return฀to฀the฀menu฀window.

3. Convenient Features

TIP:

Uninstalling฀Virtual฀Remote฀Tool

Preparation:

Exit฀Virtual฀Remote฀Tool฀before฀uninstalling.฀To฀uninstall฀Virtual฀Remote฀Tool,฀the฀Windows฀user฀account฀must฀have฀

“Administrator”฀privilege฀(Windows฀8,฀Windows฀7฀and฀Windows฀Vista)฀or฀“Computer฀Administrator”฀privilege฀(Windows฀

XP).

•฀For฀Windows฀7/Windows฀Vista

1฀Click฀“Start”฀and฀then฀“Control฀Panel”.

The Control Panel window will be displayed.

2฀Click฀“Uninstall฀a฀program”฀under฀“Programs”

฀The฀“Programs฀and฀Features”฀window฀will฀be฀displayed.

3฀Select฀Virtual฀Remote฀Tool฀and฀click฀it.

4฀Click฀“Uninstall/Change”฀or฀“Uninstall”.

฀•฀When฀the฀“User฀Account฀Control”฀windows฀is฀displayed,฀click฀“Continue”.

Follow the instructions on the screens to complete the uninstallation.

•฀For฀Windows฀XP

1฀Click฀“Start”฀and฀then฀“Control฀Panel”.

The Control Panel window will be displayed.

2฀Double-click฀“Add฀/฀Remove฀Programs”.

The Add / Remove Programs window will be displayed.

3฀Click฀Virtual฀Remote฀Tool฀from฀the฀list฀and฀then฀click฀“Remove”.

Follow the instructions on the screens to complete the uninstallation.

Step 2: Connect the projector to the computer

1฀Use฀the฀supplied฀computer฀cable฀(VGA)฀to฀connect฀the฀COMPUTER฀IN฀connector฀of฀the฀projector฀directly฀

with฀the฀monitor฀output฀connector฀of฀the฀computer.

2฀Connect฀the฀supplied฀power฀cord฀to฀the฀AC฀IN฀of฀the฀projector฀and฀the฀wall฀outlet.

The projector is in the standby condition.

AC IN

COMPUTER IN

Supplied computer cable (VGA)

To wall outlet

Power cord (supplied)

TIP:

•WhenVirtualRemoteToolstartsforthersttime,“EasySetup”windowwillbedisplayedtonavigateyourconnections.

3. Convenient Features

Step 3: Start Virtual Remote Tool

Start using the shortcut icon

•฀Double-click฀the฀shortcut฀icon฀

฀on฀the฀Windows฀Desktop.

Start from the Start menu

•฀Click฀[Start]฀→฀[All฀Programs]฀or฀[Programs]฀→฀[NEC฀Projector฀User฀Supportware]฀→฀[Virtual฀Remote฀Tool]฀

→฀[Virtual฀Remote฀Tool].

฀When฀Virtual฀Remote฀Tool฀starts฀for฀the฀rst฀time,฀“Easy฀Setup”฀window฀will฀be฀displayed.

Follow the instructions on the screens

฀When฀“Easy฀Setup”฀is฀completed,฀the฀Virtual฀Remote฀Tool฀screen฀will฀be฀displayed.

NOTE:

•When[NORMAL]isselectedfor[STANDBYMODE]fromthemenu,theprojectorcannotbeturnedonviathecomputercable

(VGA)ornetwork(wiredLAN/wirelessLAN)connection.

TIP:

•TheVirtualRemoteToolscreen(orToolbar)canbedisplayedwithoutdisplaying“EasySetup”window.

Todoso,clicktoplaceacheckmarkfor“DonotuseEasySetupnexttime”onthescreenatStep6in“EasySetup”.

3. Convenient Features

Exiting฀Virtual฀Remote฀Tool

1฀Click฀the฀Virtual฀Remote฀Tool฀icon฀

฀on฀the฀Taskbar.

The pop-up menu will be displayed.

2฀Click฀“Exit”.

The Virtual Remote Tool will be closed.

Viewing฀the฀help฀le฀of฀Virtual฀Remote฀Tool

•฀Displaying฀the฀help฀le฀using฀the฀taskbar

1฀Click฀the฀Virtual฀Remote฀Tool฀icon฀

฀on฀the฀taskbar฀when฀Virtual฀Remote฀Tool฀is฀running.

The pop-up menu will be displayed.

2.฀Click฀“Help”.

The Help screen will be displayed.

•฀Displaying฀the฀help฀le฀using฀the฀Start฀Menu.

1.฀Click฀“Start”฀→฀“All฀programs”฀or฀“Programs”฀→฀“NEC฀Projector฀User฀Supportware”฀→฀“Virtual฀Remote฀

Tool”฀→฀and฀then฀“Virtual฀Remote฀Tool฀Help”฀in฀this฀order.

The Help screen will be displayed.

3. Convenient Features

❼

Operating Your Computer’s Mouse Functions from the

Projector’s Remote Control via the USB Cable (Remote Mouse

Function)

The฀built-in฀remote฀mouse฀function฀enables฀you฀to฀operate฀your฀computer’s฀mouse฀functions฀from฀the฀supplied฀remote฀

control฀when฀the฀projector฀is฀connected฀to฀a฀computer฀via฀a฀commercially฀available฀USB฀cable฀(compatible฀with฀USB฀

2.0฀specications).

The฀Remote฀Mouse฀function฀works฀for฀the฀COMPUTER฀input฀while฀the฀computer฀screen฀is฀displayed.

The฀Remote฀Mouse฀function฀will฀not฀work฀while฀you฀freeze฀or฀magnify฀an฀image.

-฀Using฀the฀USB฀cable฀to฀connect฀the฀projector฀and฀the฀computer฀will฀also฀start฀USB฀Display฀function.

AC IN

USB-B

USB cable (not supplied)

To wall outlet

NOTE:

•AUSBcablemustsupporttheUSB2.0Specications.

•Themousefunctioncanbeusedwiththefollowingoperatingsystems:

Windows7,WindowsXP,orWindowsVista

•InSP2orolderversionofWindowsXP,ifthemousecursorwillnotmovecorrectly,dothefollowing:

CleartheEnhancepointerprecisioncheckboxunderneaththemousespeedsliderintheMousePropertiesdialogbox[Pointer

Optionstab].

•Waitatleast5secondsafterdisconnectingtheUSBcablebeforereconnectingitandviceversa.Thecomputermaynotidentify

theUSBcableifitisrepeatedlyconnectedanddisconnectedinrapidintervals.

•ConnecttheprojectortothecomputerwithaUSBcableafterstartingthecomputer.Failuretodosomayfailtostartthecom-

puter.

Operating฀your฀computer’s฀mouse฀from฀the฀remote฀control

You฀can฀operate฀your฀computer’s฀mouse฀from฀the฀remote฀control.

PAGE ▽/△ Button ...........................scrolls the viewing area of the window or to move to the previous or next slide in PowerPoint

on your computer.

▲▼◀▶ Buttons ..............................moves the mouse cursor on your computer.

MOUSE L-CLICK/ENTER Button ......works as the mouse left button.

MOUSE R-CLICK Button ..................works as the mouse right button.

NOTE:

•Whenyouoperatethecomputerusingthe▲▼◀or▶buttonwiththemenudisplayed,boththemenuandthemousepointer

willbeaffected.Closethemenuandperformthemouseoperation.

TIP:YoucanchangethePointerspeedontheMousePropertiesdialogboxontheWindows.Formoreinformation,seetheuser

documentationoronlinehelpsuppliedwithyourcomputer.

3. Convenient Features

❽ Projecting Your Computer’s Screen Image from the

Projector via the USB Cable (USB Display)

Using฀a฀commercially฀available฀USB฀cable฀(compatible฀with฀USB฀2.0฀specications)฀to฀connect฀the฀computer฀with฀the฀

projector฀allows฀you฀to฀send฀your฀computer฀screen฀image฀to฀the฀projector฀for฀displaying.฀Power฀On/Off฀and฀source฀

selection฀of฀the฀projector฀can฀be฀done฀from฀your฀computer฀without฀connecting฀a฀computer฀cable฀(VGA).

NOTE:

•TomakeUSBDISPLAYavailableonWindows8,Windows7,WindowsVistaandWindowsXP,theWindowsuseraccountmust

have“Administrator”privilege.

•USBDisplayusesfunctionsofImageExpressUtilityLitecontainedonNECProjectorCD-ROM(→page56).

StartingUSBDisplay,however,willnotinstallImageExpressUtilityLiteonyourcomputer.ThisisbecauseUSBDisplayexecutes

theprojector’sprogramonly.

•WhenImageExpressUtilityLiteisinstalledtobothyourcomputerandtheprojector,theoneinstalledtoyourcomputeralways

startevenifitisolderversionthantheoneinstalledtotheprojector.

Ifaudiotransfercapabilityandotherfeatureswillnotwork,tryuninstallingImageExpressUtilityLitefromyourcomputer.This

willallowyoutouseallthefeatures.

•USBDisplaywillnotworkin[NORMAL]of[STANDBYMODE].TouseUSBDisplay,select[NETWORKSTANDBY]for[STANDBY

MODE].(→page101)

•WhenUSBDisplayisused,thesoundisoutputfromtheCOMPUTERAUDIOINMiniJack(StereoMini).Imageandsoundmay

notbesynchronized.

1. Start the computer.

2.฀Connect฀the฀projector’s฀power฀cord฀to฀the฀wall฀outlet฀and฀put฀the฀projector฀into฀standby฀condition.

•฀Open฀the฀projector’s฀lens฀cover.

3.฀Use฀the฀USB฀cable฀to฀connect฀the฀computer฀with฀the฀projector.

AC IN

USB-B

USB cable (not supplied)

To wall outlet

Power cord (supplied)

฀The฀message฀“The฀projector฀is฀in฀standby฀mode.฀Connect฀it?”฀will฀be฀displayed฀on฀the฀computer฀screen.

•฀The฀control฀window฀of฀Image฀Express฀Utility฀Lite฀will฀be฀displayed฀on฀the฀top฀of฀the฀screen.

NOTE:Dependingonthecomputersetting,the“AutoPlay”windowmaybedisplayedwhenthe

computerdetectstheconnectiontotheprojector.Ifthishappens,clickthe“StartUSBDisplay”

window.

4.฀Click฀“Yes”.

฀The฀projector฀will฀turn฀on฀and฀the฀message฀“The฀projector฀is฀getting฀ready.฀Please฀wait.”฀will฀be฀displayed฀on฀the฀

computer screen. This message will disappear in a few seconds.

3. Convenient Features

5.฀Operate฀the฀control฀window.

(1) (Source) ..... Selects an input source of the projector.

(2)

(Picture) .... Turns on or off AV-MUTE (Picture mute), and turns on or off FREEZE (Freeze a picture).

(3)

(Sound) ..... Turns on or off AV-MUTE (Sound mute), play the sound and turns up or down the volume.

(4)

(Others) ..... Uses “Update”, “HTTP Server”*, “Settings” and “Information”.

* The HTTP Server cannot be selected when a USB cable is connected.

(5)

(Exit) .......... Exit Image Express Utility Lite. You can also turn off the projector at the same time.

(6)

(Help) ........... Displays the help of Image Express Utility Lite.

(1) (2) (3) (4) (5)(6)

3. Convenient Features

❾ Controlling the Projector by Using an HTTP Browser

Overview

The฀HTTP฀Server฀function฀provides฀settings฀and฀operations฀for:

1.฀Setting฀for฀wired/wireless฀network฀(NETWORK฀SETTINGS)

To use wireless LAN connection, the optional USB Wireless LAN Unit is required. (→ page 124)

To use wired/wireless LAN connection, connect the projector to the computer with a commercially available LAN

cable. (

→ page 123)

2.฀Setting฀Alert฀Mail฀(ALERT฀MAIL)

฀When฀the฀projector฀is฀connected฀to฀a฀wired/wireless฀network,฀lamp฀replace฀time฀or฀error฀messages฀will฀be฀sent฀via฀

e-mail.

3.฀Operating฀the฀projector

Power on/off, selecting input, volume control and picture adjustments are possible.

4.฀Setting฀PJLink฀PASSWORD฀and฀AMX฀BEACON

5.฀Allowing฀Image฀Express฀Utility฀Lite฀to฀be฀downloaded฀and฀copied฀to฀your฀USB฀memory

This฀device฀uses฀“JavaScript”฀and฀“Cookies”฀and฀the฀browser฀should฀be฀set฀to฀accept฀these฀functions.฀The฀setting฀

method฀will฀vary฀depending฀on฀the฀version฀of฀browser.฀Please฀refer฀to฀the฀help฀les฀and฀the฀other฀information฀provided฀

in฀your฀software.

Two฀ways฀of฀access฀to฀the฀HTTP฀server฀function฀are฀available:

•฀Start฀the฀Web฀browser฀on฀the฀computer฀via฀the฀network฀connected฀to฀the฀projector฀and฀enter฀the฀following฀

URL :

฀http://<the฀projector’s฀IP฀address>฀/index.html

•฀Use฀Image฀Express฀Utility฀Lite฀contained฀on฀the฀supplied฀NEC฀Projector฀CD-ROM.

TIP:ThefactorysettingIPaddressis[DHCPON].

NOTE:

•Tousetheprojectorinanetwork,consultwithyournetworkadministratoraboutnetworksettings.

•Thedisplay’sorbutton’sresponsecanbesloweddownoroperationmaynotbeaccepteddependingthesettingsofyournet-

work.

Shouldthishappen,consultyournetworkadministrator.Theprojectormaynotrespondifitsbuttonsarerepeatedlypressedin

rapidintervals.Shouldthishappen,waitamomentandrepeat.Ifyoustillcan’tgetanyresponse,turnoffandbackontheprojec-

tor.

•IfthePROJECTORNETWORKSETTINGSscreendoesnotappearinthewebbrowser,presstheCtrl+F5keystorefreshyourweb

browser(orclearthecache).

Preparation before Use

Connect฀the฀projector฀to฀a฀commercially฀available฀LAN฀cable฀before฀engaging฀in฀browser฀operations.฀(→฀page฀123)

Operation฀with฀a฀browser฀that฀uses฀a฀proxy฀server฀may฀not฀be฀possible฀depending฀on฀the฀type฀of฀proxy฀server฀and฀the฀

setting฀method.฀Although฀the฀type฀of฀proxy฀server฀will฀be฀a฀factor,฀it฀is฀possible฀that฀items฀that฀have฀actually฀been฀set฀

will฀not฀be฀displayed฀depending฀on฀the฀effectiveness฀of฀the฀cache,฀and฀the฀contents฀set฀from฀the฀browser฀may฀not฀be฀

reected฀in฀operation.฀It฀is฀recommended฀that฀a฀proxy฀server฀not฀be฀used฀unless฀it฀is฀unavoidable.

3. Convenient Features

Handling of the Address for Operation via a Browser

Regarding฀the฀actual฀address฀that฀is฀entered฀for฀the฀address฀or฀entered฀to฀the฀URL฀column฀when฀operation฀of฀the฀pro-

jector฀is฀via฀a฀browser,฀the฀host฀name฀can฀be฀used฀as฀it฀is฀when฀the฀host฀name฀corresponding฀to฀the฀IP฀address฀of฀the฀

projector฀has฀been฀registered฀to฀the฀domain฀name฀server฀by฀a฀network฀administrator,฀or฀the฀host฀name฀corresponding฀

to฀the฀IP฀address฀of฀the฀projector฀has฀been฀set฀in฀the฀“HOSTS”฀le฀of฀the฀computer฀being฀used.

Example฀1:฀฀When฀the฀host฀name฀of฀the฀projector฀has฀been฀set฀to฀“pj.nec.co.jp”,฀access฀is฀gained฀to฀the฀network฀

setting฀by฀specifying

฀http://pj.nec.co.jp/index.html

for฀the฀address฀or฀the฀entry฀column฀of฀the฀URL.

Example฀2:฀฀When฀the฀IP฀address฀of฀the฀projector฀is฀“192.168.73.1”,฀access฀is฀gained฀to฀the฀network฀setting฀by฀

specifying

฀http://192.168.73.1/index.html

for฀the฀address฀or฀the฀entry฀column฀of฀the฀URL.

PROJECTOR ADJUSTMENT

POWER:฀This฀controls฀the฀power฀of฀the฀projector.

ON ......................... Power is switched on.

OFF ........................ Power is switched off.

VOLUME:฀This฀controls฀the฀volume฀of฀the฀projector.

▲ ........................... Increases the volume adjustment value.

▼ ........................... Decreases the volume adjustment value.

AV-MUTE:฀This฀controls฀the฀mute฀function฀of฀the฀projector.

PICTURE ON .......... Mutes the video.

PICTURE OFF ......... Cancels the video muting.

SOUND ON ............ Mutes the audio.

SOUND OFF ........... Cancels the audio muting.

ALL ON .................. Mutes each of the video, and audio functions.

ALL OFF ................. Cancels the muting of each of the video, and audio functions.

3. Convenient Features

PICTURE:฀Controls฀the฀video฀adjustment฀of฀the฀projector.

BRIGHTNESS ▲ .... Increases the brightness adjustment value.

BRIGHTNESS ▼ .... Decreases the brightness adjustment value.

CONTRAST ▲ ........ Increases the contrast adjustment value.

CONTRAST ▼ ........ Decreases the contrast adjustment value.

COLOR ▲ .............. Increases the color adjustment value.

COLOR ▼ .............. Decreases the color adjustment value.

HUE ▲ ................... Increases the hue adjustment value.

HUE ▼ ................... Decreases the hue adjustment value.

SHARPNESS ▲ ..... Increases the sharpness adjustment value.

SHARPNESS ▼ ..... Decreases the sharpness adjustment value.

•฀The฀functions฀that฀can฀be฀controlled฀will฀vary฀depending฀on฀the฀signal฀being฀input฀to฀the฀projector.฀(→฀page฀

86)

SOURCE฀SELECT:฀This฀switches฀the฀input฀connector฀of฀the฀projector.

COMPUTER ........... Switches to the COMPUTER IN connector.

HDMI 1 .................. Switches to the HDMI 1 IN connector.

HDMI 2 .................. Switches to the HDMI 2 IN connector.

VIDEO .................... Switches to the VIDEO IN connector.

USB-A .................... Switches to the data on the USB memory device.

LAN ........................ Switches to a LAN signal.

USB-B .................... Switches to the USB-B Port.

PROJECTOR฀STATUS:฀This฀displays฀the฀condition฀of฀the฀projector.

LAMP LIFE REMAINING .....Displays the remaining life of the lamp as a percentage.

LAMP HOURS USED ...........Displays how many hours the lamp has been used.

ERROR STATUS ..................Displays the status of errors occurring within the projector.

LOG฀OFF:฀Logging฀off฀your฀projector฀and฀returning฀to฀the฀authentication฀screen฀(LOGON฀screen).

3. Convenient Features

NETWORK SETTINGS

•฀SETTINGS

WIRED or WIRELESS

SETTINGSet฀for฀wired฀LAN฀or฀for฀wireless฀LAN.

APPLYApply฀your฀settings฀to฀wired฀LAN฀or฀wireless฀LAN.

DHCP฀ONAutomatically฀assign฀IP฀address,฀subnet฀mask,฀and฀gateway฀to฀the฀projector฀from฀your฀

DHCP฀server.

DHCP฀OFFSet฀IP฀address,฀subnet฀mask,฀and฀gateway฀to฀the฀projector฀assigned฀by฀your฀network฀

administrator.

IP฀ADDRESSSet฀your฀IP฀address฀of฀the฀network฀connected฀to฀the฀projector.

SUBNET฀MASKSet฀your฀subnet฀mask฀number฀of฀the฀network฀connected฀to฀the฀projector.

GATEWAYSet฀the฀default฀gateway฀of฀the฀network฀connected฀to฀the฀projector.

AUTO฀DNS฀ONDHCP฀server฀will฀automatically฀assign฀IP฀address฀of฀DNS฀server฀connected฀to฀the฀

projector.

AUTO฀DNS฀OFFSet฀your฀IP฀address฀of฀DNS฀server฀connected฀to฀the฀projector.

Setting for WIRED LAN

ENABLETurn฀on฀wired฀LAN฀connection

DISABLETurn฀off฀wired฀LAN฀connection

Setting฀for฀WIRELESS฀LAN฀(with฀the฀optional฀USB฀Wireless฀LAN฀Unit฀equipped)฀

EASY฀CONNECTIONExecute฀a฀wireless฀LAN฀using฀EASY฀CONNECTION.

SIMPLE฀ACCESS฀POINTSet฀the฀projector฀for฀simple฀access฀point.฀

CHANNELSelect฀a฀channel.฀Available฀channels฀vary฀depending฀on฀the฀country฀and฀region.฀When฀

you฀select฀[INFRASTRUCTURE],฀make฀sure฀that฀the฀projector฀and฀your฀access฀point฀

are฀on฀the฀same฀channel;฀when฀you฀select฀[AD฀HOC],฀make฀sure฀that฀the฀projector฀and฀

your฀computer฀are฀on฀the฀same฀channel.

PROFILE฀1/PROFILE฀2Two฀settings฀can฀be฀set฀for฀wireless฀LAN฀connection.฀Select฀PROFILE฀1฀or฀PROFILE฀

SSID

Enter฀an฀identier฀(SSID)฀for฀wireless฀LAN.฀Communication฀can฀be฀done฀only฀with฀

equipment฀whose฀SSID฀matches฀SSID฀for฀your฀wireless฀LAN.

SITE฀SURVEYDisplays฀a฀list฀of฀available฀SSIDs฀for฀wireless฀LAN฀on฀site.฀Select฀an฀SSID฀which฀you฀

can access.

3. Convenient Features

NETWORK฀TYPESelect฀communication฀method฀when฀using฀wireless฀LAN.

INFRASTRUCTURE:฀Select฀this฀option฀when฀communicating฀with฀one฀or฀more฀equip-

ment฀connected฀to฀the฀wireless฀LAN฀network฀via฀a฀wireless฀access฀point.

AD฀HOC:฀Select฀this฀option฀when฀using฀the฀wireless฀LAN฀to฀directly฀communicate฀with฀

a฀computer฀in฀peer-to-peer฀mode.฀

SECURITY฀TYPE

Turn฀on฀or฀off฀the฀encryption฀mode฀for฀secure฀transmission.฀When฀turn฀on฀the฀encryp-

tion฀mode,฀set฀WEP฀key฀or฀encrypted฀key.

DISABLEWill฀not฀turn฀on฀the฀encryption฀feature.฀Your฀communications฀

may฀be฀monitored฀by฀someone.

WEP฀64฀bitUses฀64-bit฀datalength฀for฀secure฀transmission.

WEP฀128฀bitUses฀128-bit฀datalength฀for฀secure฀transmission.฀This฀option฀will฀

increase฀privacy฀and฀security฀when฀compared฀to฀use฀of฀64-bit฀

datalength฀encryption.

WPA-PSK฀TKIP/

WPA-PSK฀AES/

WPA2-PSK฀TKIP/

WPA2-PSK฀AES/

These฀options฀provide฀stronger฀security฀

than฀WEP.

NOTE:

•TheWEPsettingsmustbethesameascommunicationdevicessuchasPCoraccesspointin

yourwirelessnetwork.

•WhenyouuseWEP,yourimagetransmissionspeedwillslowdown.

•[WPAPSK-TKIP],[WPAPSK-AES],[WPA2PSK-TKIP]and[WPA2PSK-AES]arenotavailable

when[ADHOC]isselectedfrom[NETWORKTYPE].

INDEXSelect฀encryption฀key฀when฀selecting฀[WEP฀64฀bit]฀or฀[WEP฀128฀bit]฀in฀[SECURITY฀

TYPE].฀When฀[WEP฀64bit]฀or฀[WEP฀128bit]฀is฀selected฀for฀[SECURITY฀TYPE],฀the฀WEP฀

key฀is฀xed฀to฀“1”฀and฀cannot฀be฀changed.

KEYWhen฀selecting฀[WEP฀64฀bit]฀or฀[WEP฀128฀bit]฀in฀[SECURITY฀TYPE]:

Enter฀WEP฀key.

Select Characters฀(ASCII)Hexadecimal฀digit฀(HEX)

WEP฀64฀bitUp฀to฀5฀charactersUp฀to฀10฀characters

WEP฀128฀bitUp฀to฀13฀charactersUp฀to฀26฀characters

When฀selecting฀[WPA฀PSK-TKIP],฀[WPA฀PSK-AES],฀[WPA2฀PSK-TKIP]฀or฀[WPA2฀

PSK-AES]:

Enter฀encryption฀key.฀Key฀length฀must฀be฀8฀or฀greater฀and฀63฀or฀less.

3. Convenient Features

•฀NAME

PROJECTOR฀NAMEEnter฀a฀name฀for฀your฀projector฀so฀that฀your฀computer฀can฀identify฀the฀projector.฀A฀

projector฀name฀must฀be฀16฀characters฀or฀less.฀

TIP:฀Projector฀name฀will฀not฀be฀affected฀even฀when฀[RESET]฀is฀done฀from฀the฀menu.

HOST฀NAMEEnter฀the฀hostname฀of฀the฀network฀connected฀to฀the฀projector.฀A฀host฀name฀must฀be฀

15 or less.

DOMAIN฀NAMEEnter฀the฀domain฀name฀of฀the฀network฀connected฀to฀the฀projector.฀A฀domain฀name฀

must฀be฀60฀characters฀or฀less.

•฀ALERT฀MAIL

ALERT฀MAIL฀(English฀

only)

This฀option฀will฀notify฀your฀computer฀of฀lamp฀replace฀time฀or฀error฀messages฀via฀e-mail฀

when฀using฀wireless฀or฀wired฀LAN.฀

Placing฀a฀checkmark฀will฀turn฀on฀the฀Alert฀Mail฀feature.

Clearing฀a฀checkmark฀will฀turn฀off฀the฀Alert฀Mail฀feature.

Sample฀of฀a฀message฀to฀be฀sent฀from฀the฀projector:

The฀lamp฀is฀at฀the฀end฀of฀its฀usable฀life.฀Please฀replace฀the฀lamp.

Projector฀Name:฀NEC฀Projector

Lamp฀Hours฀Used:฀100฀[H]

SENDER’S฀ADDRESSEnter฀sender’s฀address.฀

SMTP฀SERVER฀NAMEEnter฀the฀SMTP฀server฀name฀to฀be฀connected฀to฀the฀projector.

RECIPIENT’S฀ADDRESS฀

1,2,3

Enter฀your฀recipient’s฀address.฀Up฀to฀three฀addresses฀can฀be฀entered.

TEST฀MAIL

Send฀a฀test฀mail฀to฀check฀whether฀your฀settings฀are฀correct฀or฀not

NOTE:

•Ifyouexecuteatest,youmaynotreceiveanAlertmail.Shouldthishappen,checkifnetwork

settingsarecorrect.

•Ifyouenteredanincorrectaddressinatest,youmaynotreceiveanAlertmail.Shouldthis

happen,checkiftheRecipient’sAddressiscorrect.

SAVEClick฀this฀button฀to฀reect฀the฀above฀settings.

•฀NETWORK฀SERVICE

PJLink฀PASSWORDSet฀a฀password฀for฀PJLink*.฀A฀password฀must฀be฀32฀characters฀or฀less.฀Do฀not฀forget฀

your฀password.฀However,฀if฀you฀forget฀your฀password,฀consult฀with฀your฀dealer.

HTTP฀PASSWORDSet฀a฀password฀for฀HTTP฀server.฀A฀password฀must฀be฀10฀characters฀or฀less.

AMX฀BEACONTurn฀on฀or฀off฀for฀detection฀from฀AMX฀Device฀Discovery฀when฀connecting฀to฀the฀network฀

supported฀by฀AMX’s฀NetLinx฀control฀system.

TIP:

WhenusingadevicethatsupportsAMXDeviceDiscovery,allAMXNetLinxcontrolsystemwillrec-

ognizethedeviceanddownloadtheappropriateDeviceDiscoveryModulefromanAMXserver.

PlacingacheckmarkwillenabledetectingtheprojectorfromAMXDeviceDiscovery.

ClearingacheckmarkwilldisabledetectingtheprojectorfromAMXDeviceDiscovery.

Image฀Express฀Utility฀LiteClick฀“DOWNLOAD”฀to฀display฀the฀download฀page฀from฀which฀the฀EXE฀le฀of฀Image฀

Express฀Utility฀Lite฀can฀be฀downloaded฀to฀your฀USB฀memory฀connected฀to฀your฀com-

puter.฀(→฀page฀

60)

SAVE

Click฀this฀button฀to฀reect฀the฀above฀settings.

*฀What฀is฀PJLink?

฀PJLink฀is฀a฀standardization฀of฀protocol฀used฀for฀controlling฀projectors฀of฀different฀manufacturers.฀This฀standard฀protocol฀is฀estab-

lished฀by฀Japan฀Business฀Machine฀and฀Information฀System฀Industries฀Association฀(JBMIA)฀in฀2005.

฀The฀projector฀supports฀all฀the฀commands฀of฀PJLink฀Class฀1.

฀Setting฀of฀PJLink฀will฀not฀be฀affected฀even฀when฀[RESET]฀is฀done฀from฀the฀menu.

3. Convenient Features

CRESTRON฀ROOMVIEW฀compatibility

The฀projector฀supports฀CRESTRON฀ROOMVIEW,฀allowing฀multiple฀devices฀connected฀in฀the฀network฀to฀be฀managed฀

and฀controlled฀from฀a฀computer฀or฀a฀controller.

For฀more฀information,฀visit฀http://www.crestron.com

Access฀to฀the฀HTTP฀server฀function,฀and฀make฀necessary฀settings฀for฀[CRESTRON]฀in฀[NETWORK฀SETTINGS].

•฀ROOMVIEW฀for฀managing฀from฀the฀computer.

DISABLEDisables฀ROOMVIEW.

ENABLEEnables฀ROOMVIEW.

•฀CRESTRON฀CONTROL฀for฀managing฀from฀the฀controller.

DISABLEDisables฀CRESTRON฀CONTROL.

ENABLEEnables฀CRESTRON฀CONTROL.฀

IP฀ADDRESSSet฀your฀IP฀address฀of฀CRESTRON฀SERVER.

IP฀IDSet฀your฀IP฀ID฀of฀CRESTRON฀SERVER.

TIP:TheCRESTRONsettingsarerequiredonlyforusewithCRESTRONROOMVIEW.

Formoreinformation,visithttp://www.crestron.com

•฀INFORMATION

WIRED฀LANDisplay฀a฀list฀of฀settings฀of฀wired฀LAN฀connection.

WIRELESS฀LANDisplay฀a฀list฀of฀settings฀of฀wireless฀LAN฀connection.

UPDATEReect฀settings฀when฀they฀are฀changed.

3. Convenient Features

❿

Controlling the Projector over a LAN (PC Control Utility Pro 4/

Pro 5)

Using฀the฀utility฀software฀“PC฀Control฀Utility฀Pro฀4”฀and฀“PC฀Control฀Utility฀Pro฀5”฀included฀on฀the฀companion฀NEC฀

Projector฀CD-ROM,฀the฀projector฀can฀be฀controlled฀from฀a฀computer฀over฀a฀LAN.

PC฀Control฀Utility฀Pro฀4฀is฀a฀program฀compatible฀with฀Windows.฀(→฀this฀page)

PC฀Control฀Utility฀Pro฀5฀is฀a฀program฀compatible฀with฀Mac฀OS.฀(→฀page฀55)

Control Functions

Power฀On/Off,฀signal฀selection,฀picture฀freeze,฀picture฀mute,฀audio฀mute,฀adjusting,฀error฀message฀notication,฀event฀

schedule.

Screen฀of฀PC฀Control฀Utility฀Pro฀4

This฀section฀provides฀an฀outline฀of฀preparation฀for฀use฀of฀PC฀Control฀Utility฀Pro฀4/Pro฀5.฀For฀information฀on฀how฀to฀use฀

PC฀Control฀Utility฀Pro฀4/Pro฀5,฀see฀Help฀of฀PC฀Control฀Utility฀Pro฀4/Pro฀5.฀(→฀page฀

54, 55)

Step฀1:฀Install฀PC฀Control฀Utility฀Pro฀4/Pro฀5฀on฀the฀computer.

Step฀2:฀Connect฀the฀projector฀to฀a฀LAN.

Step฀3:฀Start฀PC฀Control฀Utility฀Pro฀4/Pro฀5.

•฀To฀run฀PC฀Control฀Utility฀Pro฀4฀on฀Windows฀8฀and฀Windows฀XP,฀“Microsoft฀.NET฀Framework฀Version฀2.0”฀is฀required.฀

The฀Microsoft฀.NET฀Framework฀Version฀2.0,฀3.0฀or฀3.5฀is฀available฀from฀Microsoft’s฀web฀page.฀Download฀and฀install฀

the฀it฀on฀your฀computer.฀

TIP:

•PCControlUtilityPro4canbeusedwithaserialconnection.

Using on Windows

Step 1: Install PC Control Utility Pro 4 on the computer

NOTE:

•Toinstalloruninstalltheprogram,theWindowsuseraccountmusthave[Administrator]privilege(Windows8,Windows7,

WindowsVistaandWindowsXP)

•Exitallrunningprogramsbeforeinstallation.Ifanotherprogramisrunning,theinstallationmaynotbecompleted.

1฀Insert฀the฀accompanying฀NEC฀Projector฀CD-ROM฀into฀your฀CD-ROM฀drive.

The menu window will be displayed.

3. Convenient Features

TIP:

Ifthemenuwindowwillnotbedisplayed,trythefollowingprocedure.

ForWindows7:

1.฀Click฀“start”฀on฀Windows.

2.฀Click฀“All฀Programs”฀→฀“Accessories”฀→฀“Run”.

3.฀Type฀your฀CD-ROM฀drive฀name฀(example:฀“Q:\”)฀and฀“LAUNCHER.EXE”฀in฀“Name”.฀(example:฀Q:\

LAUNCHER.EXE)

4.฀Click฀“OK”.

the menu window will be displayed.

2฀Click฀“PC฀Control฀Utility฀Pro฀4”฀on฀the฀menu฀window.

The installation will start.

When the installation is complete, the Welcome window will be displayed.

3฀Click฀“Next”.

฀“END฀USER฀LICENSE฀AGREEMENT”฀screen฀will฀be฀displayed.

฀Read฀“END฀USER฀LICENSE฀AGREEMENT”฀carefully.

4฀If฀you฀agree,฀click฀“I฀accept฀the฀terms฀in฀the฀license฀agreement”฀and฀then฀click฀“Next”.

•฀Follow฀the฀instructions฀on฀the฀installer฀screens฀to฀complete฀the฀installation.

•฀When฀the฀installation฀is฀complete,฀you฀will฀return฀to฀the฀menu฀window.

TIP:

•UninstallingPCControlUtilityPro4

TouninstallPCControlUtilityPro4,dothesameproceduresstatedasin“UninstallingVirtualRemoteTool”.Read“VirtualRemote

Tool”as“PCControlUtilityPro4”(→page

39)

3. Convenient Features

Step 2: Connect the projector to a LAN.

Connect฀the฀projector฀to฀the฀LAN฀by฀following฀the฀instructions฀in฀“Connecting฀to฀a฀Wired฀LAN”฀(→฀page฀

123),฀“Con-

necting฀to฀a฀Wireless฀LAN฀(Optional:฀NP02LM฀series)”฀(→฀page฀124)฀and฀“9.฀Controlling฀the฀Projector฀by฀Using฀an฀

HTTP฀Browser”฀(→฀page฀45)

Step 3: Start PC Control Utility Pro 4

Click฀“Start”฀→฀“All฀programs”฀or฀“Programs”฀→฀“NEC฀Projector฀User฀Supportware”฀→฀“PC฀Control฀Utility฀Pro฀4”฀→

“PC฀Control฀Utility฀Pro฀4”.

NOTE:

•FortheSchedulefunctionofthePCControlutilityPro4towork,youmusthaveyourcomputerrunningandnotinstandby/

sleepmode.Select“PowerOptions”fromthe“ControlPanel”inWindowsanddisableitsstandby/sleepmodebeforerunningthe

scheduler.

[Example]ForWindows7:

Select“ControlPanel”→“SystemandSecurity”→“PowerOptions”→“Changewhenthecomputersleeps”→“Putthecomputer

tosleep”→“Never”.

NOTE:

•When[NORMAL]isselectedfor[STANDBYMODE]fromthemenu,theprojectorcannotbeturnedonviathenetwork(wiredLAN/

wirelessLAN)connection.

TIP:

Viewing฀the฀Help฀of฀PC฀Control฀Utility฀Pro฀4

•฀Displaying฀the฀Help฀le฀of฀PC฀Control฀Utility฀Pro฀4฀while฀it฀is฀running.

฀Click฀“Help฀(H)”฀→฀“Help฀(H)฀…”฀of฀window฀of฀PC฀Control฀Utility฀Pro฀4฀in฀this฀order.

The pop-up menu will be displayed.

•฀Displaying฀the฀help฀le฀using฀the฀Start฀Menu.

฀Click฀“Start”฀→฀“All฀programs”฀or฀“Programs”฀→฀“NEC฀Projector฀User฀Supportware”฀→฀“PC฀Control฀Utility฀Pro฀4”฀→

“PC฀Control฀Utility฀Pro฀4฀Help”.

The Help screen will be displayed.

3. Convenient Features

Using on Mac OS

Step 1: Install PC Control Utility Pro 5 on the computer

1.฀Insert฀the฀accompanying฀NEC฀Projector฀CD-ROM฀in฀your฀Mac฀CD-ROM฀drive.

฀The฀CD-ROM฀icon฀will฀be฀displayed฀on฀the฀desktop.

2.฀Double-click฀the฀CD-ROM฀icon.

The CD-ROM window will be displayed.

3.฀Double-click฀the฀“Mac฀OS฀X”฀folder.

4.฀Double-click฀“PC฀Control฀Utility.mpkg”.

The installer will start.

5.฀Click฀“Next”.

฀“END฀USER฀LICENSE฀AGREEMENT”฀screen฀will฀be฀displayed.

6.฀Read฀“END฀USER฀LICENSE฀AGREEMENT”฀and฀click฀“Next”.

The conﬁrmation window will be displayed

7.฀Click฀“I฀accept฀the฀terms฀in฀the฀license฀agreement”.

Follow the instructions on the installer screens to complete the installation.

Step 2: Connect the projector to a LAN

Connect฀the฀projector฀to฀the฀LAN฀by฀following฀the฀instructions฀in฀“Connecting฀to฀a฀Wired฀LAN”฀(→฀page฀

123),฀“Con-

necting฀to฀a฀Wireless฀LAN฀(Optional:฀NP02LM฀series)”฀(→฀page฀124)฀and฀“❾฀Controlling฀the฀Projector฀by฀Using฀an฀

HTTP฀Browser”฀(→฀page฀45)

Step 3: Start PC Control Utility Pro 5

1.฀Open฀your฀Applications฀folder฀in฀Mac฀OS.

2.฀Click฀the฀“PC฀Control฀Utility฀Pro฀5”฀folder.

3.฀Click฀the฀“PC฀Control฀Utility฀Pro฀5”฀icon.

PC Control Utility Pro 5 will start.

NOTE:

•FortheSchedulefunctionofthePCControlutilityPro5towork,youmusthaveyourcomputerrunningandnotinsleepmode.

Select“EnergySaver”fromthe“SystemPreferences”inMacanddisableitssleepmodebeforerunningthescheduler.

•When[NORMAL]isselectedfor[STANDBYMODE]fromthemenu,theprojectorcannotbeturnedonviathenetwork(wiredLAN/

wirelessLAN)connection.



TIP:

Viewing฀the฀Help฀of฀PC฀Control฀Utility฀Pro฀5

•฀Displaying฀the฀Help฀le฀of฀PC฀Control฀Utility฀Pro฀5฀while฀it฀is฀running.฀

•฀From฀the฀menu฀bar,฀click฀“Help”฀→฀“Help”฀in฀this฀order.฀

The Help screen will be displayed.

•฀Displaying฀the฀Help฀using฀the฀Dock฀

1.฀Open฀“Application฀Folder”฀in฀Mac฀OS.

2.฀Click฀the฀“PC฀Control฀Utility฀Pro฀5”฀folder.

3.฀Click฀the฀“PC฀Control฀Utility฀Pro฀5฀Help”฀icon.

The Help screen will be displayed.



3. Convenient Features

⓫ Projecting Your Computer’s Screen Image from the

Projector over a LAN (Image Express Utility Lite)

Using฀Image฀Express฀Utility฀Lite฀contained฀on฀the฀supplied฀NEC฀Projector฀CD-ROM฀allows฀you฀to฀send฀the฀computer’s฀

screen฀image฀and฀sound฀to฀the฀projector฀over฀a฀USB฀cable฀or฀a฀wired฀or฀wireless฀LAN.

Image฀Express฀Utility฀Lite฀is฀a฀program฀compatible฀with฀Windows.

Image฀Express฀Utility฀Lite฀for฀Mac฀OS฀is฀a฀program฀compatible฀with฀Mac฀OS.฀(→฀page฀

61)

This฀section฀will฀show฀you฀an฀outline฀about฀how฀to฀connect฀the฀projector฀to฀a฀LAN฀and฀to฀use฀Image฀Express฀Utility฀

Lite.฀For฀the฀operation฀of฀Image฀Express฀Utility฀Lite,฀see฀the฀help฀of฀Image฀Express฀Utility฀Lite.

Step฀1:฀install฀Image฀Express฀Utility฀Lite฀on฀the฀computer.฀

Step฀2:฀Connect฀the฀projector฀to฀a฀LAN.

Step฀3:฀Start฀Image฀Express฀Utility฀Lite.

TIP:

•ImageExpressUtilityLite(forWindows)canbestartedfrommostcommerciallyavailableremovablemediasuchasUSBmemory

devicesorSDcardswithouttheneedtoinstallonyourcomputer.(→page59)

What You can Do with Image Express Utility Lite

•฀Image฀transmission฀(for฀Windows฀and฀Mac฀OS)

•฀The฀screen฀of฀your฀computer฀can฀be฀sent฀to฀the฀projector฀via฀a฀wired฀or฀wireless฀network฀without฀a฀computer฀cable฀

(VGA).

•฀By฀using฀“EASY฀CONNECTION”฀function,฀the฀complicated฀network฀settings฀can฀be฀simplied฀and฀the฀computer฀

will฀automatically฀connect฀to฀the฀projector.

•฀The฀screen฀of฀your฀computer฀can฀be฀sent฀to฀up฀to฀four฀projectors฀at฀the฀same฀time.

•฀Audio฀transfer฀capability฀(for฀Windows฀only)

•฀Image฀Express฀Utility฀Lite฀allows฀you฀to฀send฀the฀computer’s฀screen฀image฀and฀audio฀to฀the฀projector฀over฀wired/

wireless฀LAN฀or฀USB฀connection.

•฀Audio฀transfer฀capability฀is฀available฀only฀when฀the฀computer฀connects฀with฀the฀projector฀in฀peer-to-peer฀net-

work.

•฀USB฀Display฀(for฀Windows฀only)

•฀Computer’s฀screen฀image฀and฀audio฀can฀be฀projected฀via฀a฀USB฀cable,฀without฀connecting฀a฀computer฀cable฀

(VGA).

•฀Just฀connecting฀the฀computer฀and฀the฀projector฀over฀a฀USB฀cable฀will฀make฀the฀USB฀Display฀function฀available฀

(Plug฀&฀Play)฀even฀without฀installing฀Image฀Express฀Utility฀Lite฀on฀the฀computer.฀(→฀page฀

43)

•฀Geometric฀Correction฀Tool฀[GCT]฀(for฀Windows฀only)

See฀“⓬฀Projecting฀an฀Image฀from฀an฀Angle฀(Geometric฀Correction฀Tool฀in฀Image฀Express฀Utility฀Lite)”.

3. Convenient Features

Using on Windows

Step 1: install Image Express Utility Lite on the computer.

NOTE:

•Toinstalloruninstalltheprogram,theWindowsuseraccountmusthave“Administrator”privilege(Windows8,Windows7,

WindowsVistaandWindowsXP).

•Exitallrunningprogramsbeforeinstallation.Ifanotherprogramisrunning,theinstallationmaynotbecompleted.

•ImageExpressUtilityLitewillbeinstalledtothesystemdriveofyourcomputer.

Ifthemessage“Thereisnotenoughfreespaceondestination”isdisplayed,freeupenoughspace(about100MB)toinstallthe

program.

1.฀Insert฀the฀accompanying฀NEC฀Projector฀CD-ROM฀into฀your฀CD-ROM฀drive.

The menu window will be displayed.

TIP:

Ifthemenuwindowwillnotbedisplayed,trythefollowingprocedure.

ForWindows7:

1.฀Click฀“start”฀on฀Windows.

2.฀Click฀“All฀Programs”฀→฀“Accessories”฀→฀“Run”.

3.฀Type฀your฀CD-ROM฀drive฀name฀(example:฀“Q:\”)฀and฀“LAUNCHER.EXE”฀฀in฀“Name”.฀(example:฀Q:\

LAUNCHER.EXE)

4.฀Click฀“OK”.

The menu window will be displayed.

2.฀Click฀“Installing฀Image฀Express฀Utility฀Lite”฀on฀the฀menu฀window.

The installation will start.

฀“END฀USER฀LICENSE฀AGREEMENT”฀screen฀will฀be฀displayed.฀

฀Read฀“END฀USER฀LICENSE฀AGREEMENT”฀carefully฀

3.฀If฀you฀agree,฀click฀“I฀agree.”฀and฀then฀click฀“Next”.฀

•฀Follow฀the฀instructions฀on฀the฀installer฀screens฀to฀complete฀the฀installation.฀

•฀When฀the฀installation฀is฀complete,฀you฀will฀return฀to฀the฀menu฀window.

When the installation is complete, a completion message will be displayed.

4.฀Click฀“OK”.

This completes the installation.

TIP:

•UninstallingImageExpressUtilityLite

TouninstallImageExpressUtilityLite,dothesameproceduresstatedasin“UninstallingVirtualRemoteTool”.Read“VirtualRemote

Tool”as“ImageExpressUtilityLite”(→page39)

Step 2: Connect the projector to a LAN.

Connect฀the฀projector฀to฀the฀LAN฀by฀following฀the฀instructions฀in฀“Connecting฀to฀a฀Wired฀LAN”฀(→฀page฀

123),฀“Con-

necting฀to฀a฀Wireless฀LAN฀(Optional:฀NP02LM฀series)”฀(→฀page฀124)฀and฀“9.฀Controlling฀the฀Projector฀by฀Using฀an฀

HTTP฀Browser”฀(→฀page฀45)

3. Convenient Features

Step 3: Start Image Express Utility Lite.

1.฀On฀Windows,฀click฀“Start”฀→฀“All฀programs”฀→฀“NEC฀Projector฀UserSupportware”฀→฀“Image฀Express฀Utility฀

Lite”฀→฀“Image฀Express฀Utility฀Lite”.

฀Image฀Express฀Utility฀Lite฀will฀start.

฀The฀select฀window฀for฀network฀connection฀will฀be฀displayed

2.฀Select฀Network฀and฀click฀“OK”.

The select window for destination will show a list of connectable projectors.

•฀When฀connecting฀the฀computer฀directly฀to฀the฀projector฀by฀one-to-one,฀“Easy฀Connection”฀is฀recommended.

•฀When฀one฀or฀more฀networks฀for฀“EASY฀CONNECTION”฀are฀found,฀the฀“Easy฀Connection฀Selection฀Screen”฀

window฀will฀be฀displayed.

•฀To฀check฀for฀the฀network฀available฀for฀connected฀projectors,฀from฀the฀menu,฀select฀[INFO.]฀→฀[WIRELESS฀

LAN]฀→฀[SSID].

3.฀Select฀the฀network฀you฀wish฀to฀connect,฀and฀click฀“Select”.

The target selection window will be displayed.

4.฀Place฀a฀check฀mark฀for฀projectors฀to฀be฀connected,฀and฀then฀click฀“Connect”.

•฀When฀one฀or฀more฀projectors฀are฀displayed,฀from฀the฀menu฀on฀the฀projector,฀select฀[INFO.]฀→฀[WIRELESS฀LAN]฀

→฀[IP฀ADDRESS].

When connecting with the projector is established, you can operate the control window to control the projector. (→

page 44)

NOTE:

•When[NORMAL]isselectedfor[STANDBYMODE]fromthemenu,theprojectorthatisturnedoffwillnotbedisplayedinthe

selectwindowfordestination

TIP:

Viewing฀the฀“Help”฀le฀of฀Image฀Express฀Utility฀Lite

•฀Displaying฀the฀Help฀le฀of฀Image฀Express฀Utility฀Lite฀while฀it฀is฀running.

฀Click฀the฀[?]฀(help)฀icon฀on฀the฀control฀window.

The Help screen will be displayed.

•฀Displaying฀the฀Help฀le฀of฀GCT฀while฀it฀is฀running.

฀Click฀“Help”฀→฀“Help”฀on฀the฀edit฀window.

The Help screen will be displayed.

•฀Displaying฀the฀help฀le฀using฀the฀Start฀Menu.

฀Click฀“Start”฀→฀“All฀programs”฀or฀“Programs”฀→฀“NEC฀Projector฀User฀Supportware”฀→฀“Image฀Express฀Utility฀Lite”฀

→฀“Image฀Express฀Utility฀Lite฀Help”.

The Help screen will be displayed.

3. Convenient Features

Starting Image Express Utility Lite from a USB Memory or SD Card

Image฀Express฀Utility฀Lite฀can฀be฀started฀from฀commercially฀available฀removable฀media฀such฀USB฀memory฀or฀SD฀cards฀

if฀it฀is฀copied฀beforehand.฀This฀will฀eliminate฀the฀trouble฀of฀installing฀Image฀Express฀Utility฀Lite฀to฀your฀computer.

1.฀Copy฀Image฀Express฀Utility฀Lite฀to฀removable฀media.

฀Copy฀all฀the฀folders฀and฀les฀(total฀size฀approx.฀6MB)฀from฀the฀“IEU_Lite฀(removable-media)”฀folder฀in฀the฀supplied฀

NEC Projector CD-ROM to the root directory of your removable media.

2.฀Insert฀your฀removable฀media฀into฀your฀computer.

฀The฀“AutoPlay”฀screen฀will฀be฀displayed฀on฀your฀computer.

TIP:

•Ifthe“AutoPlay”screenisnotdisplayed,openthefolderfrom“Computer”(“MyComputer”forWindowsXP).

3.฀Click฀“Open฀folder฀to฀view฀les”

฀The฀IEU_Lite.exe,฀other฀folder,฀and฀les฀will฀be฀displayed.

4.฀Double-click฀the฀“IEU_Lite.exe”฀(฀

) icon.

฀Image฀Express฀Utility฀Lite฀will฀start.

NOTE:

•The“EASYCONNECTION”functionisnotsupportedwhenImageExpressUtilityLiteisstartedfromremovablemedia.

3. Convenient Features

Downloading Image Express Utility Lite via the HTTP server

Downloading฀procedure฀when฀the฀projector฀is฀connected฀to฀the฀Internet.

1.฀Access฀the฀HTTP฀server.฀(→฀page฀

45)

2.฀Select฀the฀“NETWORK฀SETTINGS”฀tab฀and฀then฀the฀“NETWORK฀SERVICE”฀tab.

3.฀Click฀“DOWNLOAD”฀for฀“Image฀Express฀Utility฀Lite”.

The download page will be displayed.

4.฀Place฀a฀checkmark฀for฀IEU_Lite฀(removable-media).zip฀and/or฀gct.ngm.

5.฀Click฀“DOWNLOAD”.

6.฀Choose฀a฀folder฀where฀you฀want฀to฀download฀the฀le฀and฀click฀“SAVE”.฀

(A folder in your computer is recommeded.)

The downloading will start.

฀After฀the฀downloading฀is฀completed,฀make฀sure฀that฀the฀le฀is฀placed฀in฀the฀destination฀folder.

Supported OS:

•฀Windows฀8฀(32-bit/64-bit)

•฀Windows฀8฀Pro฀(32-bit/64-bit)

•฀Windows฀8฀Enterprise฀(32-bit/64-bit)

•฀Windows฀7฀Home฀Basic฀(32-bit/64-bit)

•฀Windows฀7฀Home฀Premium฀(32-bit/64-bit)

•฀Windows฀7฀Professional฀(32-bit/64-bit)

•฀Windows฀7฀Ultimate฀(32-bit/64-bit)

•฀Windows฀7฀Enterprise฀(32-bit/64-bit)

•฀Windows฀Vista฀Home฀Basic฀(32-bit/64-bit)

•฀Windows฀Vista฀Home฀Premium฀(32-bit/64-bit)

•฀Windows฀Vista฀Business฀(32-bit/64-bit)

•฀Windows฀Vista฀Ultimate฀(32-bit/64-bit)

•฀Windows฀Vista฀Enterprise฀(32-bit/64-bit)

•฀Windows฀XP฀Home฀Edition฀Service฀Pack฀3฀or฀later฀(32-bit)

•฀Windows฀XP฀Professional฀Service฀Pack฀3฀or฀later฀(32-bit)

Starting฀IEU฀Lite฀(removable-media).zip฀and฀gct.ngm

1.฀Extract฀the฀downloaded฀IEU฀Lite฀(removable-media)฀zip฀le฀into฀your฀removable฀media.

2.฀Double-click฀the฀IEU฀Lite.exe฀icon฀in฀the฀IEU฀Lite฀(removable-media)฀folder.

•฀If฀you฀downloaded฀gct.ngm฀too,฀move฀gct.ngm฀to฀the฀same฀folder฀where฀IEU_Lite_GCT.exe฀is฀placed.

•฀To฀use฀the฀Geometric฀Correction฀Tool฀function฀(GCT)฀of฀Image฀Express฀Utility฀lite฀together฀with฀a฀video฀cable,฀

double-click฀the฀“IEU_Lite_GCT.exe”฀icon.฀When฀GCT฀correction฀data฀(*.ngm)฀is฀saved฀in฀the฀same฀folder฀where฀

IEU_Lite_GCT.exe฀is฀placed,฀the฀data฀will฀be฀automatically฀used฀without฀the฀need฀of฀LAN฀connection.

NOTE:

The“EASYCONNECTION”functionisnotsupportedwhenImageExpressUtilityLiteisstartedfromremovablemedia.

3. Convenient Features

Using on Mac OS

Step 1: Install Image Express Utility Lite for Mac OS on the computer

1.฀Insert฀the฀accompanying฀NEC฀Projector฀CD-ROM฀in฀your฀Mac฀CD-ROM฀drive.

฀The฀CD-ROM฀icon฀will฀be฀displayed฀on฀the฀desktop.

2.฀Double-click฀the฀CD-ROM฀icon.

The CD-ROM window will be displayed.

3.฀Double-click฀the฀“Mac฀OS฀X”฀folder.

4.฀Double-click฀“Image฀Express฀Utility฀Lite.dmg”.

฀The฀“Image฀Express฀Utility฀Lite”฀window฀will฀be฀displayed.

5.฀Drag฀and฀drop฀the฀“Image฀Express฀Utility฀Lite”฀folder฀to฀your฀Applications฀folder฀in฀Mac฀OS.

Step 2: Connect the projector to a LAN

Connect฀the฀projector฀to฀the฀LAN฀by฀following฀the฀instructions฀in฀“Connecting฀to฀a฀Wired฀LAN”฀(→฀page฀

123),฀“Con-

necting฀to฀a฀Wireless฀LAN฀(Optional:฀NP02LM฀series)”฀(→฀page฀124)฀and฀“❾฀Controlling฀the฀Projector฀by฀Using฀an฀

HTTP฀Browser”฀(→฀page฀45)

Step 3: Start Image Express Utility Lite for Mac OS

1.฀Open฀your฀Applications฀folder฀in฀Mac฀OS.

2.฀Double-click฀the฀“Image฀Express฀Utility฀Lite”฀folder.

3.฀Double-click฀the฀“Image฀Express฀Utility฀Lite”฀icon.

฀When฀Image฀Express฀Utility฀Lite฀for฀Mac฀OS฀starts,฀the฀select฀window฀for฀destination฀will฀be฀displayed.

•฀At฀the฀rst฀time฀of฀startup,฀“END฀USER฀LICENSE฀AGREEMENT”฀screen฀will฀be฀displayed฀before฀the฀select฀

window for destination is displayed.

฀Read฀“END฀USER฀LICENSE฀AGREEMENT”฀and฀select฀“I฀accept฀the฀terms฀in฀the฀license฀agreement”,฀and฀click฀

“OK”.

4.฀Select฀a฀projector฀to฀be฀connected,฀and฀then฀click฀“Connect”.

฀Your฀desktop฀screen฀will฀be฀displayed฀on฀the฀projector.

3. Convenient Features

TIP:

ViewingtheHelpofImageExpressUtilityLiteforMacOS

•฀From฀the฀menu฀bar,฀click฀“Help”฀→฀“Image฀Express฀Utility฀Lite฀Help”฀while฀Image฀Express฀Utility฀is฀run-

ning.฀

The Help screen will be displayed



3. Convenient Features

⓬ Projecting an Image from an Angle (Geometric Correction

Tool in Image Express Utility Lite)

The฀Geometric฀Correction฀Tool฀(GCT)฀function฀allows฀you฀to฀correct฀distortion฀of฀images฀projected฀even฀from฀an฀

angle.฀

What you can do with GCT

•฀The฀GCT฀feature฀includes฀the฀following฀three฀functions

•฀4-point฀Correction:฀You฀can฀t฀a฀projected฀image฀within฀the฀border฀of฀the฀screen฀easily฀by฀align฀the฀four฀corners฀

of฀an฀image฀to฀the฀ones฀of฀the฀screen.

•฀Multi-point฀Correction:฀You฀can฀correct฀a฀distorted฀image฀on฀the฀corner฀of฀a฀wall฀or฀irregular฀shaped฀screen฀

by฀using฀many฀separated฀screens฀to฀correct฀the฀image฀as฀well฀as฀4-point฀Correction.

•฀Parameters Correction:฀You฀can฀correct฀a฀distorted฀image฀by฀using฀a฀combination฀of฀transformational฀rules฀

prepared฀in฀advance.

This฀section฀will฀show฀an฀example฀for฀use฀with฀4-point฀Correction.

For฀information฀about฀“Multi-point฀Correction”฀and฀“Parameters฀Correction”,฀see฀the฀help฀le฀of฀Image฀Express฀

Utility฀Lite.฀(→฀page฀

58)฀

•฀Your฀correction฀data฀can฀be฀stored฀in฀the฀projector฀or฀your฀computer฀which฀can฀be฀restored฀when฀necessary.

•฀The฀GCT฀function฀is฀available฀with฀a฀USB฀cable,฀wired฀or฀wireless฀LAN฀connection,฀and฀video฀cable.฀

Projecting an Image from an Angle (GCT)

This฀section฀will฀show฀an฀example฀for฀use฀with฀USB฀Display฀(using฀a฀USB฀cable฀to฀connect฀a฀computer฀and฀the฀pro-

jector).

•฀The฀USB฀Display฀function฀will฀automatically฀display฀the฀control฀window฀

•฀For฀a฀video฀cable฀or฀LAN฀connection,฀install฀and฀start฀Image฀Express฀Utility฀Lite฀in฀your฀computer฀beforehand.฀(→

page฀

56)

Preparation:฀Adjust฀the฀projector฀position฀or฀the฀zoom฀so฀that฀the฀projected฀image฀can฀cover฀the฀whole฀screen฀area.

1.฀Click฀the฀“฀

฀”฀(Picture)฀icon฀and฀then฀the฀“฀฀”฀button.

฀The฀“4-point฀Correction”฀window฀will฀be฀displayed.

2.฀Click฀the฀“Start฀Correction”฀button฀and฀then฀“Start฀4-point฀Correction”฀button.

A green frame and a mouse pointer ( ) will be displayed.

•฀Four฀[฀•฀]฀marks฀will฀be฀appeared฀at฀four฀corners฀of฀the฀green฀frame

3. Convenient Features

3.฀Use฀the฀mouse฀to฀click฀the฀[฀•฀]฀mark฀of฀which฀corner฀you฀wish฀to฀move.

The currently selected [ •฀]฀mark฀will฀turn฀red.

(In฀the฀above฀example,฀Windows฀screens฀are฀omitted฀for฀clarication.)

4.฀Drag฀the฀selected฀[฀•฀]฀mark฀to฀the฀point฀you฀wish฀to฀correct฀and฀drop฀it.

•฀When฀you฀click฀somewhere฀within฀the฀project฀image฀area,฀the฀nearest฀[฀•฀]฀mark฀will฀go฀to฀the฀position฀where฀

the mouse cursor is.

5.฀Repeat฀Step฀3฀and฀4฀to฀correct฀the฀distortion฀of฀the฀projected฀image.

6.฀After฀completing,฀right-click฀the฀mouse.

The green frame and the mouse pointer will disappear from the projected image area. This will complete the cor-

rection.

7.฀Click฀the฀“X”฀(close)฀button฀on฀the฀“4-point฀Correction”฀window.

฀The฀“4-point฀Correction”฀window฀will฀disappear฀and฀the฀4-point฀correction฀will฀take฀effect.

8.฀Click฀the฀“฀

฀”฀button฀on฀the฀control฀window฀to฀exit฀the฀GCT.

TIP:

•Afterperformingthe4-pointcorrection,youcansavethe4-pointcorrectiondatatotheprojectorbyclicking“File”→“Exportto

theprojector…”onthe“4-pointCorrection”window.

•SeetheHelpofImageExpressUtilityLiteforoperating“4-pointCorrection”windowandotherfunctionsthanGCT.(→page

58)

3. Convenient Features

⓭ Viewing 3D Images

The฀projector฀provides฀3D฀images฀to฀a฀user฀wearing฀commercially฀available฀LCD฀shutter฀eyeglasses.

CAUTION

Health precautions

Before฀viewing,฀be฀sure฀to฀read฀health฀care฀precautions฀that฀may฀be฀found฀in฀the฀user’s฀manual฀included฀with฀your฀LCD฀

shutter฀eyeglasses฀or฀your฀3D฀compatible฀content฀such฀as฀DVDs,฀video฀games,฀computer’s฀video฀les฀and฀the฀like.

To฀avoid฀any฀adverse฀symptoms,฀heed฀the฀following:

•฀Do฀not฀use฀LCD฀shutter฀eyeglasses฀for฀viewing฀any฀material฀other฀than฀3D฀images.

•฀Allow฀a฀distance฀of฀2฀m/7฀feet฀or฀greater฀between฀the฀screen฀and฀a฀user.฀Viewing฀3D฀images฀from฀too฀close฀a฀

distance฀can฀strain฀your฀eyes.

•฀Avoid฀viewing฀3D฀images฀for฀a฀prolonged฀period฀of฀time.฀Take฀a฀break฀of฀15฀minutes฀or฀longer฀after฀every฀hour฀

of฀viewing.

•฀If฀you฀or฀any฀member฀of฀your฀family฀has฀a฀history฀of฀light-sensitive฀seizures,฀consult฀a฀doctor฀before฀viewing฀3D฀

images.

•฀While฀viewing฀3D฀images,฀if฀you฀get฀sick฀such฀as฀nausea,฀dizziness,฀queasiness,฀headache,฀eyestrain,฀blurry฀

vision,฀convulsions,฀and฀numbness,฀stop฀viewing฀them.฀If฀symptoms฀still฀persist,฀consult฀a฀doctor.฀

•View3Dimagesfromthefrontofthescreen.Viewingfromananglemaycausefatigueoreyestrain.

LCD฀shutter฀eyeglasses฀(recommended)

•฀DLP฀Link฀compatible฀3D฀eyeglasses฀manufactured฀by฀XPAND฀is฀recommended.

You฀can฀also฀use฀commercially฀available฀DLP

฀Link฀or฀other฀method฀compatible฀LCD฀shutter฀eyeglasses.

Steps฀for฀viewing฀3D฀images฀on฀the฀projector

1.฀Connect฀the฀projector฀to฀your฀video฀equipment.฀

2.฀Turn฀on฀the฀projector,฀display฀the฀on-screen฀menu,฀and฀then฀select฀[ON]฀for฀the฀3D฀mode.

฀For฀the฀operating฀procedure฀to฀turn฀on฀the฀3D฀mode,฀refer฀to฀“On-screen฀menu฀for฀3D฀images”฀on฀the฀following฀

page.

3.฀Play฀your฀3D฀compatible฀content฀and฀use฀the฀projector฀to฀display฀the฀image.

4.฀Put฀on฀your฀LCD฀shutter฀eyeglasses฀to฀view฀3D฀images.

Also refer to the user’s manual accompanied with your LCD shutter eyeglasses for more information.

3. Convenient Features

On-screen฀menu฀for฀3D฀images

Follow฀the฀steps฀to฀display฀the฀3D฀menu.

1. Press the MENU button.

The on-screen menu will be displayed.

2. Press the

▷฀button฀twice.

The [SETUP] menu will be displayed.

3. Press the ▽฀button฀once,฀and฀then฀press฀the฀▷ button ﬁve times.

The [3D] menu will be displayed

4. Press the ▽฀button฀to฀select฀a฀signal฀and฀press฀the฀ENTER฀button.

฀The฀3D฀(DETAIL฀SETTINGS)฀screen฀will฀be฀displayed.

5. Press the ▽฀button฀to฀select฀[3D]฀and฀press฀the฀ENTER฀button.

6. Press the ▽฀button฀to฀select฀[ON].

The selected signal will be displayed in 3D.

7. Press the

▽฀button฀to฀[GLASSES]฀and฀press฀the฀ENTER฀button.

The [GLASSES] setting screen will be displayed.

3. Convenient Features

8. Press the ▽฀button฀to฀select฀a฀compatible฀eyeglass฀method฀and฀press฀the฀ENTER฀button.

฀Set฀other฀3D-related฀menu฀options฀such฀as฀[FORMAT]฀and฀[L/R฀INVERT]฀as฀necessary.฀

9. Press the MENU button once.

The menu will disappear.

Selecting฀input฀connected฀to฀a฀source฀of฀3D฀images฀[COMPUTER/HDMI1/HDMI2/VIDEO]

This฀function฀switches฀the฀3D฀mode฀between฀ON฀and฀OFF฀for฀each฀input.

NOTE:

Toconrmthatthesupported3Dsignalisaccepted,useeitherwayofthefollowing:

•Makesurethat[3D]isdisplayedinthetoprightofthescreenafterthesourceisselected.

•Display[INFO.]→[SOURCE]→[3DSIGNAL]andmakesurethat“SUPPORTED”isdisplayed.

To฀view฀3D฀images,฀see฀page฀65.

Select฀[COMPUTER],฀[HDMI1],฀[HDMI2],฀or฀[VIDEO].

NOTE:

•Themaximumdistanceforviewing3Dimagesis10m/394inchesfromthescreensurfaceunderthefollowingrestrictions:

-Brightnessontheprojector:2000lumensorgreater

-Screengain:1

-Viewingposition:Facingstraighttowardsthescreencenter

-Outsidelight:None

-LCDshuttereyeglasses:Usingtheoptional3DGoggles(NP02GL)

•If3DcontentisplayedbackonyourcomputerandtheperformanceispooritmaybecausedbytheCPUorgraphicschip.Inthis

caseyoumayhavedifcultyseeingthe3Dimagesastheywereintended.Checktoseeifyourcomputermeetstherequirements

providedinyouruser’smanualincludedwithyour3Dcontent.

•TheDLP

LinkcompatibleLCDshuttereyeglassesallowyoutoview3Dimagesbyreceivingsynchsignals,whichareincluded

inlefteyeandrighteyeimages,reectedfromthescreen.Dependingonenvironmentsorconditionssuchastheambientbright-

ness,screensizeorviewingdistance,theLCDshuttereyeglassesmayfailtoreceivesynchsignals,causingpoor3Dimages.

•Whenthe3Dmodeisenabled,theKeystonecorrectionrangewillbenarrower.

•Whenthe3Dmodeisenabled,thefollowingsettingsareinvalid.

[WALLCOLOR],[PRESET],[REFERENCE],[COLORTEMPERATURE]

•Refertothe[SOURCE]screenunderthe[INFO.]menuforinformationonwhethertheinputsignalis3Dcompatible.

•Signalsotherthanthoselistedin“CompatibleInputSignalList”onpage138willbeoutofrangeorwillbedisplayedin2D.

3. Convenient Features

Troubleshooting฀on฀viewing฀3D฀images

If฀images฀will฀not฀be฀displayed฀in฀3D฀or฀3D฀images฀appear฀as฀2D,฀check฀the฀following฀table.฀Also฀refer฀to฀the฀user’s฀

manual฀accompanied฀with฀your฀3D฀content฀or฀LCD฀shutter฀eyeglasses.

Possible฀causesSolutions

•฀The฀content฀you฀are฀playing฀back฀is฀not฀compatible฀with฀3D.•฀Play฀back฀a฀content฀compatible฀with฀3D.

•฀The฀3D฀mode฀was฀turned฀off฀for฀the฀selected฀source.

•฀Use฀the฀projector’s฀menu฀to฀turn฀on฀3D฀mode฀for฀the฀selected฀

source.฀(→฀page฀

104)

•฀You฀are฀not฀using฀our฀recommended฀LCD฀shutter฀eyeglasses.•฀Use฀our฀recommended฀LCD฀shutter฀eyeglasses.฀(→฀page฀

65)

•฀If฀the฀shutter฀of฀your฀LCD฀shutter฀eyeglasses฀cannot฀synchronize฀

with฀the฀currently฀projected฀source,฀the฀following฀are฀possible฀

causes:

-฀Your฀LCD฀shutter฀eyeglasses฀are฀not฀switched฀on.•฀Switch฀on฀your฀LCD฀shutter฀eyeglasses.

-฀The฀battery฀in฀the฀LCD฀shutter฀eyeglasses฀ran฀down.•฀Recharge฀the฀battery฀or฀replace฀it.

-฀The฀correct฀eyeglass฀method฀is฀not฀selected.฀

•฀Change฀the฀eyeglass฀method฀for฀3D฀by฀using฀the฀menu..฀(→

page฀

104)

-฀The฀viewing฀distance฀between฀the฀viewer฀and฀the฀screen฀is฀

too฀far.

•฀Move฀closer฀to฀the฀screen฀until฀the฀viewer฀gets฀3D฀images.฀

•฀Or฀use฀the฀projector’s฀menu฀to฀select฀[NON-INVERT]฀for฀[L/R฀

INVERT].฀

-฀There฀are฀bright฀light฀sources฀or฀other฀projectors฀near฀the฀

viewer.

•฀Keep฀light฀sources฀or฀other฀projectors฀away฀from฀the฀viewer.

•฀Do฀not฀look฀toward฀a฀bright฀light฀source.

•฀Or฀use฀the฀projector’s฀menu฀to฀select฀[NON-INVERT]฀for฀[L/R฀

INVERT].฀

•฀If฀your฀computer฀is฀not฀set฀for฀3D฀viewing,฀the฀following฀are฀

possible฀causes:

-฀Your฀computer฀does฀not฀meet฀the฀requirements฀for฀3D฀view-

ing.

•฀Check฀to฀see฀if฀your฀computer฀meets฀the฀requirements฀provided฀

in฀your฀user’s฀manual฀included฀with฀your฀3D฀content.

-฀Your฀computer฀is฀not฀set฀for฀3D฀output.•฀Set฀your฀computer฀for฀3D฀output.

-฀The฀resolution฀of฀output฀signal฀is฀out฀of฀range.•฀Select฀the฀resolution฀of฀output฀signal฀supporting฀3D.฀

-฀The฀refresh฀rate฀of฀output฀signal฀is฀out฀of฀range.•฀Change฀the฀refresh฀rate฀to฀60Hz฀or฀120Hz.฀

3. Convenient Features

⓮ Connecting Your Microphone

Connecting฀a฀commercially฀available฀dynamic฀or฀condenser฀microphone฀to฀the฀MIC฀input฀jack฀allows฀you฀to฀output฀

your฀mic฀sound฀from฀the฀built-in฀speaker.

Sound฀from฀COMPUTER,฀HDMI฀1,฀HDMI฀2,฀and฀VIDEO฀audio฀inputs฀or฀sound฀of฀USB-A/LAN฀input฀will฀be฀heard฀from฀

the฀speaker฀with฀your฀microphone฀voice.฀

Type฀of฀microphone฀can฀be฀selected.฀From฀the฀menu,฀select฀[SETUP]฀→฀[INSTALLATION]฀→฀[MIC฀SELECT]฀(→฀page฀

99)

Microphone฀sensitivity฀can฀be฀adjusted.฀From฀the฀menu,฀select฀[SETUP]฀→฀[INSTALLATION]฀→฀[MIC฀GAIN].฀(→฀page฀

99)

NOTE:

•TheMICinputjackdoesnotsupportpluginpowermicrophones.

•IfthereisnosignalwheneitherHDMIinputisselected,soundoutputmaynotwork.

MIC

4. Using the Viewer

❶ What you can do with the Viewer

The฀Viewer฀has฀the฀following฀features.

•฀When฀a฀commercially฀available฀USB฀memory฀that฀stores฀image฀les฀is฀inserted฀into฀the฀USB฀port฀(Type฀A)฀of฀the฀

projector,฀the฀Viewer฀allows฀you฀to฀view฀the฀image฀les฀on฀the฀USB฀memory.

฀Even฀if฀no฀computer฀is฀available,฀presentations฀can฀be฀conducted฀simply฀with฀the฀projector.฀

•฀Supported฀graphic฀format฀is฀JPEG.

•฀The฀Viewer฀displays฀the฀thumbnail฀screen฀(JPEG฀Exif฀only)฀on฀which฀you฀can฀jump฀to฀any฀specic฀image฀you฀wish฀

to฀project.

•฀There฀are฀two฀ways฀of฀playback฀for฀slideshow:฀manual฀playback฀and฀auto฀playback.฀The฀interval฀time฀can฀be฀

changed฀in฀auto฀playback.

•฀The฀order฀of฀displaying฀images฀can฀be฀set฀by฀name,฀date฀or฀size.฀Ascending฀or฀descending฀order฀can฀be฀se-

lected.

•฀Images฀can฀be฀rotated฀by฀90฀degrees฀during฀playback.

4. Using the Viewer

NOTE

•TheUSBportoftheprojectordoesnotsupportUSBhub.

•ThefollowingoperationsbyusingthebuttonsontheprojectorarenotpossiblewhentheVIEWERscreensuchastheslidescreen

andthethumbnailscreenisdisplayed.

-Keystonecorrectionbyusingthe▲/▼button

-AutoAdjustmentbyusingtheAUTOADJ.button

-Volumecontrolwiththe◀or▶button

ToperformKeystonecorrectionorSourceselectionduringdisplayoftheViewer,presstheMENUbuttontwicetodisplaythe

menuandoperateViewerfromthemenu.

•FreezingpicturebyusingtheFREEZEbuttonontheremotecontrolisnotpossiblewhentheVIEWERscreensuchastheslide

screenandthethumbnailscreenisdisplayed.

•Executing[RESET]→[ALLDATA]fromthemenuwillreturnthesettingsfortheViewertoolbartothefactorydefault.

•USBmemory

-BesuretouseaUSBmemorydeviceformattedwiththeFAT32orFAT16lesystem.

TheprojectordoesnotsupportNTFSformattedUSBmemory.

IftheprojectordoesnotrecognizeyourUSBmemory,checkiftheformatissupported.

ToformatyourUSBmemoryinyourcomputer,refertothedocumentorhelplethatcomeswithyourWindows.

-WedonotwarrantthattheUSBportoftheprojectorwillsupportallUSBmemoriesinthemarket.

•Supportedimages

-SupportedleformatforViewerareasfollows.

WedonotwarrantalltheimagesaresupportedforViewer.

Imagesotherthanmentionedinthetablemaynotbesupported.

Image฀typeExtensionDescription

JPEGJPG/JPEG

Baseline/Exif฀are฀supported

-Slideshow,effect,andsoundeffectsetwithPowerPointcannotbeplayedback.

-Imagecanbedisplayedataresolutionupto10000×10000pixels.

-Evenifimagesaremetbytheaboveconditions,theremaybesomeimageswhichcannotbeplayedback.

-Morethan200icons(totalnumberofimageleiconsandfoldericons)cannotbedisplayedinathumbnailscreen.

-Longle/foldernamewillbelimitedtothespeciedlength.Thiscanbeshownbybracketadded.

-Ifonefolderhasmanyles,ittakessometimetoplayback.

•Ifasinglefoldercontainstoomanyles,switchingimageswilltaketime.Toshortenswitchingtime,reducethenumberofimages

containedinasinglefolder.

TIP:Exchangeableimageleformat(Exif)isastandardimageleformatusedbydigitalcameraswiththeadditionofspecic

shootingdata.

4. Using the Viewer

❷ Projecting images stored in a USB memory device

This฀section฀explains฀the฀basic฀operation฀of฀the฀Viewer.฀

The฀explanation฀provides฀the฀operational฀procedure฀when฀the฀Viewer฀toolbar฀(→฀page฀76)฀is฀set฀to฀the฀factory฀de-

fault.

•฀Starting฀the฀Viewer .......................................................................below

•฀Removing฀the฀USB฀memory฀from฀the฀projector ....................... page฀74

•฀Exiting฀the฀Viewer .................................................................... page฀74

Preparation:฀Before฀starting฀the฀Viewer,฀store฀images฀to฀the฀USB฀memory฀using฀your฀computer.

Starting the Viewer

1. Turn on the projector. (→฀page฀17)

2.฀Insert฀the฀USB฀memory฀into฀the฀USB฀port฀of฀the฀projec-

tor.

•฀Do฀not฀remove฀the฀USB฀memory฀from฀the฀projector฀while฀

it’s LED ﬂashes. Doing so may corrupt the data.

3.฀Press฀the฀SOURCE฀button฀on฀the฀projector฀cabinet.

The Viewer start screen will be displayed.

•฀Press฀the฀USB-A฀button฀on฀the฀remote฀control.

4. Using the Viewer

4. Press the ENTER button.

The thumbnail screen will be displayed. (

→ page 75)

5. Use the

▲▼◀ or ▶ button to select an icon.

•฀The฀→ (arrow) symbol on the right indicates there are more

pages. pressing the PAGE ▽ (page down) button will show

the next page: pressing the PAGE △ (page up) will show

the previous page.

6. Press the ENTER button.

The selected slide will be displayed.

•฀When฀a฀folder฀icon฀is฀selected,฀icons฀contained฀in฀the฀folder฀

will be displayed.

7. Press the

▶฀button฀to฀select฀the฀next฀slide.

The slide on the right will be displayed.

•฀The฀◀ or ▶ button can be used to select the next (right)

slide or the previous (left) slide in the thumbnail screen.

•฀Pressing฀the฀MENU฀button฀during฀display฀of฀the฀thumbnail฀

screen, the slide screen, or the slideshow screen will display

the toolbar. The toolbar is used to select or rotate an slide.

(→ page 76)

8.฀Press฀the฀EXIT฀button฀when฀the฀toolbar฀is฀not฀dis-

played.

฀The฀thumbnail฀screen฀will฀be฀displayed.

•฀Another฀way฀to฀display฀the฀thumbnail฀screen฀is฀to฀press฀the฀

ENTER button.

•฀To฀close฀the฀toolbar,฀press฀the฀MENU฀button฀to฀return฀to฀the฀

SOURCE list, and press the MENU button again to close

the SOURCE list.

4. Using the Viewer

Removing the USB memory from the projector

1.฀Select฀the฀VIEWER฀start฀screen.

฀Press฀the฀EXIT฀button฀with฀no฀menu฀displayed.

2.฀Remove฀the฀USB฀memory฀from฀the฀projector.

฀Make฀sure฀that฀the฀LED฀on฀the฀USB฀memory฀is฀not฀ashing฀

before removing the USB memory.

NOTE:IfyouremovetheUSBmemoryfromtheprojectorwithaslide

displayed,theprojectormaynotoperatecorrectly.Ifthishappens,

turnofftheprojectorandunplugthepowercord.Wait3minutes,then

connectthepowercord,andturnontheprojector.

Exiting the Viewer

1.฀Press฀the฀MENU฀button฀with฀the฀slide฀screen฀or฀the฀

thumbnail฀screen฀displayed.

The control bar or the pop-up menu will be displayed.

2.฀฀Press฀the฀MENU฀button฀again.

The on-screen menu will be displayed.

3.฀Select฀a฀source฀other฀than฀[USB-A]฀and฀press฀the฀EN-

TER button.

The Viewer will be exited.

TIP:

ToexittheViewerusingtheremotecontrol,selectasourceother

than[USB-A].

4. Using the Viewer

Parts of each screen

The฀Viewer฀has฀four฀screens.

(1) Viewer start screen (3) Thumbnail screen (9) Slide screen/

(11) Slideshow screen

Name Description

(1)฀Viewer฀start฀screenThis฀screen฀will฀be฀displayed฀rst฀when฀you฀select฀the฀Viewer.

(2)฀USB฀iconThis฀icon฀indicates฀that฀the฀USB฀memory฀is฀inserted฀into฀the฀projector.

(3)฀Thumbnail฀screenThis฀screen฀will฀show฀a฀list฀of฀folders฀and฀image฀les฀stored฀in฀the฀USB฀memory.฀The฀

JPEG฀Exif฀les฀will฀be฀displayed฀in฀thumbnail฀screen฀only.

•฀The฀maximum฀number฀of฀image฀les฀or฀folders฀within฀one฀page฀is฀different฀depending฀

on the model.

฀M332XS฀are฀5฀by฀4

฀M352WS/M302WS฀are฀6฀by฀4

(4)฀CursorThe฀cursor฀is฀used฀to฀select฀(highlight)฀the฀folder฀or฀image฀le฀by฀using฀▲▼◀▶ but-

ton.

(5)฀Back฀iconThis฀icon฀is฀used฀to฀return฀to฀the฀upper฀(parent)฀folder.

(6)฀Folder฀iconThis฀icon฀shows฀that฀the฀USB฀memory฀has฀folders.

(7)฀฀Page฀up฀(Page฀down)฀

icon

This฀icon฀shows฀further฀folders฀or฀image฀les฀are฀available฀in฀the฀next฀(previous)฀page.฀

Use฀the฀▶฀button฀to฀go฀to฀the฀next฀(previous)฀row.฀The฀PAGE฀▽฀or฀PAGE฀△ on the

remote฀control฀is฀used฀to฀go฀to฀the฀next฀or฀previous฀page฀directly.

(8)฀Thumbnail฀toolbarThis฀toolbar฀is฀used฀in฀the฀thumbnail฀screen.฀Pressing฀the฀MENU฀button฀will฀display฀

this฀toolbar.฀(→฀page฀

76)

(9)฀Slide฀screenThis฀screen฀is฀used฀for฀manual฀playback.฀The฀selected฀image฀will฀be฀displayed฀in฀full฀

screen.

(10)฀Slide฀toolbarThis฀toolbar฀is฀used฀in฀the฀slide฀screen.฀Pressing฀the฀MENU฀button฀will฀display฀this฀

toolbar.฀(→฀page฀

77)

(11)฀Slideshow฀screenThis฀screen฀is฀used฀for฀auto฀playback.฀The฀slides฀will฀be฀changed฀automatically.

(12)฀Slideshow฀toolbarThis฀toolbar฀is฀used฀in฀the฀slideshow฀screen.฀Pressing฀the฀MENU฀button฀will฀display฀

this฀toolbar.฀(→฀page฀

77)

(5) (6) (4) (7)

(8)(2) (10) (12)

4. Using the Viewer

Using the toolbar

1. Press the MENU button.

The toolbar will be displayed.

The SOURCE screen will be displayed as Viewer connection screen.

2. Use the

◀ or ▶฀button฀to฀select฀an฀item฀and฀use฀the฀▲ or ▼ button to select its available option.

When the cursor is placed, the selected item will be changed to yellow.

The

▲ or ▼ shows more available choices.

3. Press the ENTER button.

The selected item will be displayed.

4.฀Press฀the฀MENU฀button฀two฀times.

The toolbar will be closed and the SOURCE list will be displayed. Press the MENU button again to close the

SOURCE list.

Thumbnail฀toolbar

Menu OptionsDescription

(1)฀Back฀

— Goes฀back฀to฀the฀previous฀image.฀When฀the฀cursor฀reaches฀the฀top฀left฀of฀

the฀screen,฀it฀will฀go฀to฀the฀previous฀page.

(2)฀Forward฀

— Goes฀to฀the฀next฀image.฀When฀the฀cursor฀reaches฀the฀bottom฀right฀of฀the฀

screen,฀it฀will฀go฀to฀the฀next฀page.

(3)฀Display

Closes฀the฀menu฀and฀returns฀to฀the฀thumbnail฀screen.

Closes฀the฀menu฀and฀starts฀the฀slideshow฀from฀the฀highlighted฀item.

Closes฀the฀menu฀and฀displays฀the฀slide฀screen.

(4)฀Order

Displays฀the฀icons฀alphabetically฀by฀name.฀(number฀before฀alphabet)

Displays฀the฀icons฀in฀descending฀order฀of฀le฀size.

Displays฀the฀icons฀in฀the฀order฀of฀creation฀date

(1) (2) (3) (4)

4. Using the Viewer

Slide฀toolbar

Menu OptionsDescription

(1)฀Display

Closes฀the฀menu฀and฀switches฀to฀the฀slide฀screen.

Closes฀the฀menu฀and฀displays฀the฀thumbnail฀screen.

Closes฀the฀menu฀and฀starts฀the฀slideshow฀from฀the฀highlighted฀item.

(2)฀฀Image฀

display

Closes฀the฀menu฀and฀displays฀the฀image฀in฀its฀actual฀size.

Closes฀the฀menu฀and฀displays฀the฀image฀in฀the฀projector’s฀maximum฀reso-

lution.

(3)฀฀Clockwise฀

rotation

— Close฀the฀menu฀and฀rotate฀the฀image฀90°clockwise

(4)฀฀Counter-

clockwise฀

rotation

— Close฀the฀menu฀and฀rotate฀the฀image฀90°counter฀clockwise

Slideshow฀toolbar

Menu OptionsDescription

(1)฀Stop

— Closes฀the฀menu฀and฀changes฀to฀the฀slide฀screen.

(2)฀Back

— Goes฀back฀to฀the฀previous฀image.

(3)฀Forward

— Goes฀to฀the฀next฀image.

(4)฀Interval

Species฀interval฀time฀when฀playing฀back฀the฀slides.

(5)฀Repeat

Repeats฀to฀play฀back฀the฀images฀in฀the฀folder.

Returns฀to฀the฀thumbnail฀screen.

TIP:

•Apictureiconatthecenterofthescreenshowsthatthelecannotbedisplayedintheslidescreenorthumbnailscreen.

•Slidetoolbarsettingforrotationwillbecancelledifthefolderismovedfromoneplacetoanother.

(1) (2) (3) (4)

(1) (2) (3) (4) (5)

5. Using On-Screen Menu

❶ Using the Menus

NOTE:Theon-screenmenumaynotbedisplayedcorrectlywhileinterlacedmotionvideoimageisprojected.

1.฀Press฀the฀MENU฀button฀on฀the฀remote฀control฀or฀the฀projector฀cabinet฀to฀display฀the฀menu.

NOTE:ThecommandssuchasENTER,EXIT,▲▼,◀▶inthebottomshowavailablebuttonsforyouroperation.

2. Press the ◀▶฀buttons฀on฀the฀remote฀control฀or฀the฀projector฀cabinet฀to฀display฀the฀submenu.

3.฀Press฀the฀ENTER฀button฀on฀the฀remote฀control฀or฀the฀projector฀cabinet฀to฀highlight฀the฀top฀item฀or฀the฀rst฀

tab.

4. Use the

▲▼฀buttons฀on฀the฀remote฀control฀or฀the฀projector฀cabinet฀to฀select฀the฀item฀you฀want฀to฀adjust฀or฀

set.

You can use the

◀▶฀buttons฀on฀the฀remote฀control฀or฀the฀projector฀cabinet฀to฀select฀the฀tab฀you฀want.

5.฀Press฀the฀ENTER฀button฀on฀the฀remote฀control฀or฀the฀projector฀cabinet฀to฀display฀the฀submenu฀window.

6.฀Adjust฀the฀level฀or฀turn฀the฀selected฀item฀on฀or฀off฀by฀using฀the฀▲▼◀▶

buttons on the remote control or

the projector cabinet.

Changes฀are฀stored฀until฀adjusted฀again.

7.฀Repeat฀steps฀2฀-6฀to฀adjust฀an฀additional฀item,฀or฀press฀the฀EXIT฀button฀on฀the฀remote฀control฀or฀the฀projec

tor฀cabinet฀to฀quit฀the฀menu฀display.

NOTE:Whenamenuormessageisdisplayed,severallinesofinformationmaybelost,dependingonthesignalorsettings.

8. Press the MENU button to close the menu.

฀To฀return฀to฀the฀previous฀menu,฀press฀the฀EXIT฀button.

5. Using On-Screen Menu

❷

Menu Elements

Slide bar

Solid triangle

Tab

Radio button

High Altitude symbol

ECO mode symbol

Wireless symbol

Menu฀windows฀or฀dialog฀boxes฀typically฀have฀the฀following฀elements:

Highlight .............................Indicates the selected menu or item.

Solid triangle ......................Indicates further choices are available. A highlighted triangle indicates the item is active.

Tab ......................................Indicates a group of features in a dialog box. Selecting on any tab brings its page to the front.

Radio button .......................Use this round button to select an option in a dialog box.

Source ................................Indicates the currently selected source.

Off Timer remaining time ....Indicates the remaining countdown time when the [OFF TIMER] is preset.

Slide bar .............................Indicates settings or the direction of adjustment.

ECO mode symbol ..............Indicates ECO MODE is set.

Key Lock symbol ................Indicates the [CONTROL PANEL LOCK] is enabled.

Thermometer symbol .........Indicates the [ECO MODE] is forcibly set to [ON] mode because the internal temperature is too

high.

High Altitude symbol ..........Indicates the [FAN MODE] is set to [HIGH ALTITUDE] mode.

Wireless symbol .................Indicate the wireless LAN connection is enabled.

Source

Available buttons

Thermometer symbol

Key฀Lock฀symbol

Off Timer remaining

time

Highlight

5. Using On-Screen Menu

❸ List of Menu Items

Some฀menu฀items฀are฀not฀available฀depending฀on฀the฀input฀source.

Menu฀ItemDefaultOptions

SOURCE

COMPUTER*

HDMI1*

HDMI2*

VIDEO*

USB-A*

LAN*

USB-B*

ADJUST


PRESET*1–7

DETAIL฀

SETTINGS

REFERENCE*

HIGH-BRIGHT,฀PRESENTATION,฀VIDEO,฀MOVIE,฀GRAPHIC,฀

sRGB,฀DICOM฀SIM.

GAMMA฀

CORRECTION*

DYNAMIC,฀NATURAL,฀BLACK฀DETAIL

SCREEN฀SIZE*

*LARGE,฀MEDIUM,฀SMALL

COLOR฀

TEMPERATURE

5000,฀6500,฀7800,฀9300

COLOR฀

ENHANCEMENT

*OFF,฀LOW,฀MEDIUM,฀HIGH

DYNAMIC฀

CONTRAST

OFF,฀ON

CONTRAST64

BRIGHTNESS64

SHARPNESS8

COLOR64

HUE32

RESET

IMAGE฀

OPTIONS

CLOCK*

PHASE*

HORIZONTAL*

VERTICAL*

OVERSCANAUTO

AUTO,฀OFF,฀ON

ASPECT฀RATIO

*M332XS:฀AUTO,฀4:3,฀16:9,฀15:9,฀16:10,฀WIDE฀ZOOM,฀NATIVE

M352WS/M302WS:฀AUTO,฀4:3,฀16:9,฀15:9,฀16:10,฀

LETTERBOX,฀NATIVE

POSITION฀(Not฀available฀on฀M352WS/

M302WS)

0 −16฀to฀16

NOISE฀REDUCTIONOFFOFF,฀LOW,฀MEDIUM,฀HIGH

TELECINE2-2/2-3฀AUTOOFF,฀2-2/2-3฀AUTO,฀2-2฀ON,฀2-3฀ON

SETUPGENERAL

DIGITAL฀ZOOM100 80 to 100

AUTO฀KEYSTONEONOFF,฀ON

KEYSTONE0 −30฀to฀30

KEYSTONE฀SAVEOFFOFF,฀ON

WALL฀COLOROFF

OFF,฀WHITEBOARD,฀BLACKBOARD,฀BLACKBOARD฀

(GRAY),฀LIGHT฀YELLOW,฀LIGHT฀BLUE,฀LIGHT฀ROSE

ECO฀SETTINGS

ECO฀MODEAUTO฀ECOOFF,฀AUTO฀ECO,฀NORMAL,฀ECO

AUTO฀ECO฀

OPTIONS

AUTO฀DIMOFFOFF,฀0:01,฀0:03,฀0:10,฀0:20

ROOM฀LIGHT฀

SENSING

OFFOFF,฀ON

NORMAL฀OPTION

CONSTANT฀

BRIGHTNESS

OFFOFF,฀ON

ECO฀OPTION

CONSTANT฀

BRIGHTNESS

OFFOFF,฀ON

CLOSED฀CAPTIONOFF

OFF,฀CAPTION1,฀CAPTION2,฀CAPTION3,฀CAPTION4,฀

TEXT1,฀TEXT2,฀TEXT3,฀TEXT4

OFF฀TIMEROFFOFF,฀0:30,฀1:00,฀2:00,฀4:00,฀8:00,฀12:00,฀16:00

LANGUAGEENGLISH

ENGLISH, DEUTSCH, FRANÇAIS, ITALIANO, ESPAÑOL,

SVENSKA, 日本語

DANSK, PORTUGUÊS, ČEŠTINA, MAGYAR, POLSKI,

NEDERLANDS, SUOMI

NORSK, TÜRKÇE, РУССКИЙ,

, Ελληνικά, 中文, 한국어

ROMÂNĂ, HRVATSKI, БЪЛГАРСКИ, INDONESIA, ,

ไทย,

, 繁體中文

*฀The฀asterisk฀(*)฀indicates฀that฀the฀default฀setting฀varies฀depending฀on฀the฀signal.

*1฀The฀[GAMMA฀CORRECTION]฀item฀is฀available฀when฀an฀item฀other฀than฀[DICOM฀SIM.]฀is฀selected฀for฀[REFERENCE].

*2฀The฀[SCREEN฀SIZE]฀item฀is฀available฀when฀[DICOM฀SIM.]฀is฀selected฀for฀[REFERENCE].

5. Using On-Screen Menu

Menu฀ItemDefaultOptions

SETUP

COLOR฀SELECTCOLORCOLOR,฀MONOCHROME

SOURCE฀DISPLAYONOFF,฀ON

ID฀DISPLAYONOFF,฀ON

ECO฀MESSAGEOFFOFF,฀ON

DISPLAY฀TIMEAUTO฀45฀SECMANUAL,฀AUTO฀5฀SEC,฀AUTO฀15฀SEC,฀AUTO฀45฀SEC

BACKGROUNDBLUEBLUE,฀BLACK,฀LOGO

INSTALLATION

ORIENTATION

DESKTOP฀

FRONT

DESKTOP฀FRONT,฀CEILING฀REAR,฀DESKTOP฀REAR,฀

CEILING฀FRONT

CONTROL฀PANEL฀LOCKOFFOFF,฀ON

SECURITYOFFOFF,฀ON

COMMUNICATION฀SPEED38400bps4800bps,฀9600bps,฀19200bps,฀38400bps

CONTROL฀ID

CONTROL฀ID฀

NUMBER

1 1฀to฀254

CONTROL฀IDOFFOFF,฀ON

TEST฀PATTERNCROSS฀HATCH

MIC฀SELECTDYNAMIC฀MICDYNAMIC฀MIC,฀CONDENSER฀MIC

MIC฀GAIN2 0 to 15

OPTIONS(1)

FAN฀MODEAUTOAUTO,฀HIGH,฀HIGH฀ALTITUDE

COLOR฀SYSTEMVIDEOAUTO

AUTO,฀NTSC3.58,฀NTSC4.43,฀PAL,฀PAL-M,฀PAL-N,฀PAL60,฀

SECAM

WXGA฀MODE

M332XS:฀OFF฀

M352WS/

M302WS:฀ON

OFF,฀ON

HDMI฀SETTINGS

HDMI1

VIDEO฀LEVELNORMALAUTO,฀NORMAL,฀ENHANCED

HDMI2

VIDEO฀LEVELNORMALAUTO,฀NORMAL,฀ENHANCED

AUDIO฀SELECT

HDMI1HDMI1HDMI1,฀COMPUTER

HDMI2HDMI2HDMI2,฀COMPUTER

LANLANLAN,฀COMPUTER

USB฀BUSB฀BUSB฀B,฀COMPUTER

BEEPONOFF,฀ON

OPTIONS(2)

STANDBY฀MODENORMALNORMAL,฀NETWORK฀STANDBY

DIRECT฀POWER฀ONOFFOFF,฀ON

AUTO฀POWER฀ON(COMP.)OFFOFF,฀ON

AUTO฀POWER฀OFF*1:00OFF,฀0:05,฀0:10,฀0:15,฀0:20,฀0:30,฀1:00

DEFAULT฀SOURCE฀SELECTLAST

LAST,฀AUTO,฀COMPUTER,฀HDMI1,฀HDMI2,฀VIDEO,฀USB-A,฀

LAN,฀USB-B

CARBON฀CONVERT0.505

CURRENCY$ $, €

,฀JP¥,฀RMB¥

CURRENCY฀CONVERT

COMPUTER

3DOFF

OFF,฀ON

GLASSESDLP

฀LinkDLP

฀Link,฀OTHERS

FORMATSIDE฀BY฀SIDESIDE฀BY฀SIDE,฀TOP฀AND฀BOTTOM,฀FRAME฀SEQUENTIAL

L/R฀INVERTNON-INVERTNON-INVERT,฀INVERT

HDMI1

3DOFF

OFF,฀ON

GLASSESDLP

฀LinkDLP

฀Link,฀OTHERS

FORMATAUTO

AUTO,฀FRAME฀PACKING,฀SIDE฀BY฀SIDE,฀TOP฀AND฀

BOTTOM

L/R฀INVERTNON-INVERTNON-INVERT,฀INVERT

HDMI2

3DOFF

OFF,฀ON

GLASSESDLP

฀LinkDLP

฀Link,฀OTHERS

FORMATAUTO

AUTO,฀FRAME฀PACKING,฀SIDE฀BY฀SIDE,฀TOP฀AND฀

BOTTOM

L/R฀INVERTNON-INVERTNON-INVERT,฀INVERT

VIDEO

3DOFF

OFF,฀ON

GLASSESDLP

฀LinkDLP

฀Link,฀OTHERS

L/R฀INVERTNON-INVERTNON-INVERT,฀INVERT

WIRED฀LAN

WIRED฀LANENABLEDISABLE,฀ENABLE

SETTINGS

DHCP:฀ON

AUTO฀DNS:฀OFF

DHCP,฀IP฀ADDRESS,฀SUBNET฀MASK,฀GATEWAY,฀

AUTO฀DNS,฀DNS

RECONNECT

WIRELESS฀LAN

PROFILEDISABLE

DISABLE,฀EASY฀CONNECTION,฀SIMPLE฀ACCESS฀POINT,฀

PROFILE1,฀PROFILE2

RECONNECT

*AUTO฀POWER฀OFF:฀This฀item฀can฀be฀selected฀only฀when฀[NORMAL]฀is฀selected฀for฀[STANDBY฀MODE].

5. Using On-Screen Menu

Menu฀ItemDefaultOptions

INFO.

USAGE฀TIME

LAMP฀LIFE฀REMAINING

LAMP฀HOURS฀USED

TOTAL฀CARBON฀SAVINGS

TOTAL฀COST฀SAVINGS

SOURCE(1)

RESOLUTION

HORIZONTAL฀FREQUENCY

VERTICAL฀FREQUENCY

SYNC฀TYPE

SYNC฀POLARITY

SCAN฀TYPE

SOURCE(2)

SIGNAL฀TYPE

VIDEO฀TYPE

BIT฀DEPTH

VIDEO฀LEVEL

3D฀SIGNAL

WIRED฀LAN

IP฀ADDRESS

SUBNET฀MASK

GATEWAY

MAC฀ADDRESS

WIRELESS฀LAN

IP฀ADDRESS

SUBNET฀MASK

GATEWAY

MAC฀ADDRESS

SSID

NETWORK฀TYPE

WEP/WPA

CHANNEL

SIGNAL฀LEVEL

VERSION(1)

FIRMWARE

DATA

VERSION(2)FIRMWARE2

OTHERS

PROJECTOR฀NAME

MODEL฀NO.

SERIAL฀NUMBER

LAN฀UNIT฀TYPE

CONTROL฀ID฀(when฀[CONTROL฀ID]฀

is฀set)

RESET

CURRENT฀SIGNAL

ALL฀DATA

CLEAR฀LAMP฀HOURS

5. Using On-Screen Menu

❹ Menu Descriptions & Functions [SOURCE]

COMPUTER

Selects฀the฀computer฀connected฀to฀your฀COMPUTER฀input฀connector฀signal.

NOTE:WhenthecomponentinputsignalisconnectedtotheCOMPUTERINconnector,select[COMPUTER]respectively.



HDMI1 and 2

Selects฀the฀HDMI฀compatible฀equipment฀connected฀to฀your฀HDMI฀1฀or฀HDMI฀2฀IN฀connector.

VIDEO

Selects฀what฀is฀connected฀to฀your฀VIDEO฀input-VCR,฀DVD฀player฀or฀document฀camera.

USB-A (Viewer)

This฀feature฀enables฀you฀to฀make฀presentations฀using฀a฀USB฀memory฀that฀contains฀slides.

(→฀page฀

70฀“4.฀Using฀the฀Viewer”)

LAN

Selects฀a฀signal฀from฀the฀LAN฀port฀(RJ-45)฀or฀the฀installed฀USB฀wireless฀LAN฀unit฀(optional).

USB-B (USB Display)

Selects฀the฀computer฀connected฀to฀the฀USB-B฀port฀(type฀B)฀by฀using฀a฀commercially฀available฀USB฀cable.฀

(→฀page฀

43)

5. Using On-Screen Menu

❺ Menu Descriptions & Functions [ADJUST]

[PICTURE]

[PRESET]

This฀function฀allows฀you฀to฀select฀optimized฀settings฀for฀your฀projected฀image.

You฀can฀adjust฀neutral฀tint฀for฀yellow,฀cyan฀or฀magenta.฀

There฀are฀seven฀factory฀presets฀optimized฀for฀various฀types฀of฀images.฀You฀can฀also฀use฀[DETAIL฀SETTINGS]฀to฀set฀

user฀adjustable฀settings฀to฀customize฀each฀gamma฀or฀color.

Your฀settings฀can฀be฀stored฀in฀[PRESET฀1]฀to฀[PRESET฀7].

HIGH-BRIGHT ........ Recommended for use in a brightly lit room.

PRESENTATION ..... Recommended for making a presentation using a PowerPoint ﬁle.

VIDEO .................... Recommended for typical TV program viewing.

MOVIE ................... Recommended for movies.

GRAPHIC ............... Recommended for graphics.

sRGB ..................... Standard color values

DICOM SIM. .......... Recommended for DICOM simulation format.

NOTE:

•The[DICOMSIM.]optionisfortraining/referenceonlyandshouldnotbeusedforactualdiagnosis.

•DICOMstandsforDigitalImagingandCommunicationsinMedicine.ItisastandarddevelopedbytheAmericanCollegeofRadiol-

ogy(ACR)andtheNationalElectricalManufacturersAssociation(NEMA).

Thestandardspecieshowdigitalimagedatacanbemovedfromsystemtosystem.

[DETAIL SETTINGS]

5. Using On-Screen Menu

Storing฀Your฀Customized฀Settings฀[REFERENCE]

This฀function฀allows฀you฀to฀store฀your฀customized฀settings฀in฀[PRESET฀1]฀to฀[PRESET฀7].

First,฀select฀a฀base฀preset฀mode฀from฀[REFERENCE],฀then฀set฀[GAMMA฀CORRECTION],฀[SCREEN฀SIZE],฀[COLOR฀

TEMPERATURE],฀[COLOR฀ENHANCEMENT],฀and฀[DYNAMIC฀CONTRAST].฀

HIGH-BRIGHT ........ Recommended for use in a brightly lit room.

PRESENTATION ..... Recommended for making a presentation using a PowerPoint ﬁle.

VIDEO .................... Recommended for typical TV program viewing.

MOVIE ................... Recommended for movies.

GRAPHIC ............... Recommended for graphics.

sRGB ..................... Standard color values.

DICOM SIM. .......... Recommended for DICOM simulation format.

Selecting Gamma Correction Mode [GAMMA CORRECTION]

Each฀mode฀is฀recommended฀for:

DYNAMIC .............. Creates a high-contrast picture.

NATURAL ............... Natural reproduction of the picture.

BLACK DETAIL ....... Emphasizes detail in dark areas of the picture.

NOTE:Thisfunctionisnotavailablewhen[DICOMSIM.]isselectedfor[DETAILSETTINGS].

Selecting฀Screen฀Size฀for฀DICOM฀SIM฀[SCREEN฀SIZE]

This฀function฀will฀perform฀gamma฀correction฀appropriate฀for฀the฀screen฀size.

LARGE ................... For screen size of 150"

MEDIUM ................ For screen size of 100"

SMALL ................... For screen size of 50"

NOTE:Thisfunctionisavailableonlywhen[DICOMSIM.]isselectedfor[DETAILSETTINGS].

Adjusting฀Color฀Temperature฀[COLOR฀TEMPERATURE]

This฀option฀allows฀you฀to฀select฀the฀color฀temperature฀of฀your฀choice.

NOTE:When[PRESENTATION]or[HIGH-BRIGHT]isselectedin[REFERENCE],thisfunctionisnotavailable.

Enhancing the Color [COLOR ENHANCEMENT]

This฀function฀allows฀you฀to฀adjust฀the฀color฀density฀of฀the฀image.

The฀color฀of฀the฀image฀will฀become฀deeper฀in฀the฀order฀of฀“LOW”,฀“MEDIUM”฀and฀“HIGH”฀as฀the฀image฀will฀become฀

darker.

With฀[OFF]฀selected,฀the฀COLOR฀ENHANCEMENT฀function฀will฀not฀work.

Adjusting฀Brightness฀and฀Contrast฀[DYNAMIC฀CONTRAST]

This฀function฀allows฀you฀to฀adjust฀the฀contrast฀ratio฀optically฀using฀the฀built-in฀iris.

To฀increase฀the฀contrast฀ratio,฀select฀[ON].

NOTE:

•The[DYNMICCONTRAST]itemcannotbeselectedinthefollowingcases:

-When[CONSTANTBRIGHTNESS]isenabledwith[ON]selectedfor[ECOMODE]from[ECOSETTINGS].

-When[ON]isselectedfor[3D]whileimagesareprojected.

5. Using On-Screen Menu

[CONTRAST]

Adjusts฀the฀intensity฀of฀the฀image฀according฀to฀the฀incoming฀signal.

[BRIGHTNESS]

Adjusts฀the฀brightness฀level฀or฀the฀back฀raster฀intensity.

[SHARPNESS]

Controls฀the฀detail฀of฀the฀image.

[COLOR]

Increases฀or฀decreases฀the฀color฀saturation฀level.

[HUE]

Varies฀the฀color฀level฀from฀+/−฀green฀to฀+/−฀blue.฀The฀red฀level฀is฀used฀as฀reference.

Input฀signalCONTRASTBRIGHTNESSSHARPNESSCOLORHUE

COMPUTER/HDMI฀(RGB)YesYesYesNo No

COMPUTER/HDMI฀(COMPONENT)YesYesYesYesYes

VIDEO/COMPONENTYesYesYesYesYes

USB-A/LAN/USB-BYesYesYesNo No

Yes฀=฀Adjustable,฀No฀=฀Not฀adjustable

[RESET]

The฀settings฀and฀adjustments฀for฀[PICTURE]฀will฀be฀returned฀to฀the฀factory฀settings฀with฀the฀exception฀of฀the฀following;฀

Preset฀numbers฀and฀[REFERENCE]฀within฀the฀[PRESET]฀screen.

The฀settings฀and฀adjustments฀under฀[DETAIL฀SETTINGS]฀within฀the฀[PRESET]฀screen฀that฀are฀not฀currently฀selected฀

will฀not฀be฀reset.

5. Using On-Screen Menu

[IMAGE OPTIONS]

Adjusting฀Clock฀and฀Phase฀[CLOCK/PHASE]

This฀allows฀you฀to฀manually฀adjust฀CLOCK฀and฀PHASE.

CLOCK ................... Use this item to ﬁne tune the computer image or to remove any vertical banding that might appear. This

function adjusts the clock frequencies that eliminate the horizontal banding in the image.

This adjustment may be necessary when you connect your computer for the ﬁrst time.

PHASE ................... Use this item to adjust the clock phase or to reduce video noise, dot interference or cross talk. (This is

evident when part of your image appears to be shimmering.)

Use [PHASE] only after the [CLOCK] is complete.

NOTE:The[CLOCK]and[PHASE]itemsareavailableforRGBsignalsonly.

5. Using On-Screen Menu

Adjusting฀Horizontal/Vertical฀Position฀[HORIZONTAL/VERTICAL]

Adjusts฀the฀image฀location฀horizontally฀and฀vertically.

NOTE:The[HORIZONTAL]and[VERTICAL]itemsarenotavailableforVIDEO,HDMI1,HDMI2,USB-A,LAN,andUSB-B.

-฀An฀image฀can฀be฀distorted฀during฀the฀adjustment฀of฀[CLOCK]฀and฀[PHASE].฀This฀is฀not฀malfunction.

-฀The฀adjustments฀for฀[CLOCK],฀[PHASE],฀[HORIZONTAL],฀and฀[VERTICAL]฀will฀be฀stored฀in฀memory฀for฀the฀

current฀signal.฀The฀next฀time฀you฀project฀the฀signal฀with฀the฀same฀resolution,฀horizontal฀and฀vertical฀frequency,฀

its฀adjustments฀will฀be฀called฀up฀and฀applied.

฀To฀delete฀adjustments฀stored฀in฀memory,฀from฀the฀menu,฀you฀select฀[RESET]฀→฀[CURRENT฀SIGNAL]฀or฀[ALL฀

DATA]฀and฀reset฀the฀adjustments.

Selecting฀Overscan฀Percentage฀[OVERSCAN]

This฀allows฀you฀to฀set฀the฀appropriate฀overscan฀for฀an฀incoming฀signal.

AUTO ..................... Display an appropriately overscanned image (factory setting).

OFF ........................ Does not overscan the image.

ON ......................... Overscans the image.

NOTE:

•The[OVERSCAN]itemcannotbeselectedwhenVIDEOsignalsareusedorwhen[NATIVE]isselectedfor[ASPECTRATIO].

5. Using On-Screen Menu

Selecting Aspect Ratio [ASPECT RATIO]

The฀term฀“aspect฀ratio”฀refers฀to฀the฀ratio฀of฀width฀to฀height฀of฀a฀projected฀image.

The฀projector฀automatically฀determines฀the฀incoming฀signal฀and฀displays฀it฀in฀its฀appropriate฀aspect฀ratio.

•฀This฀table฀shows฀typical฀resolutions฀and฀aspect฀ratios฀that฀most฀computers฀support.

ResolutionAspect฀Ratio

VGA640฀×฀4804:3

SVGA800฀×฀6004:3

XGA1024฀×฀7684:3

WXGA1280฀×฀76815:9

WXGA1280฀×฀80016:10

WXGA+

1440฀×฀90016:10

SXGA1280฀×฀10245:4

SXGA+

1400฀×฀10504:3

UXGA1600฀×฀12004:3

WUXGA1920฀×฀120016:10

OptionsFunction

AUTO

The฀projector฀will฀automatically฀determine฀the฀incoming฀signal฀and฀display฀it฀in฀its฀aspect฀

ratio.฀(→

next฀page)

The฀projector฀may฀erroneously฀determine฀the฀aspect฀ratio฀depending฀on฀its฀signal.฀If฀this฀

occurs,฀select฀the฀appropriate฀aspect฀ratio฀from฀the฀following.

4:3The฀image฀is฀displayed฀in฀4:3฀aspect฀ratio.

16:9The฀image฀is฀displayed฀in฀16:9฀aspect฀ratio.

15:9The฀image฀is฀displayed฀in฀15:9฀aspect฀ratio.

16:10The฀image฀is฀displayed฀in฀16:10฀aspect฀ratio.

WIDE฀ZOOM

(M332XS)

The฀image฀is฀stretched฀left฀and฀right.฀

Parts฀of฀the฀displayed฀image฀are฀cropped฀at฀the฀left฀and฀right฀edges฀and฀therefore฀not฀

visible.

LETTERBOX

(M352WS/M302WS)

The฀image฀of฀a฀letterbox฀signal฀is฀stretched฀equally฀in฀the฀horizontal฀and฀vertical฀direc-

tions฀to฀t฀the฀screen.฀Parts฀of฀the฀displayed฀image฀are฀cropped฀at฀the฀top฀and฀bottom฀

edges฀and฀therefore฀not฀visible.

NATIVEThe฀projector฀displays฀the฀current฀image฀in฀its฀true฀resolution฀when฀the฀incoming฀computer฀

signal฀has฀a฀lower฀resolution฀than฀the฀projector’s฀native฀resolution.

[Example 1]฀When฀the฀incoming฀

signal฀with฀the฀resolution฀of฀800฀×฀

600฀is฀displayed฀on฀the฀M332XS:

[Example 2]฀When฀the฀incoming฀

signal฀with฀the฀resolution฀of฀800฀×฀

600฀is฀displayed฀on฀the฀M352WS/

M302WS:

NOTE:

•Whenanon-computersignalisdisplayed,the[NATIVE]isnotavailable.

•Whenasignalwithahigherresolutionthantheprojector’snativeresolutionisdisplayed,[NA-

TIVE]isnotavailable.



5. Using On-Screen Menu

Sample฀image฀when฀the฀appropriate฀aspect฀ratio฀is฀automatically฀determined

M332XS

[Computer฀signal]

Aspect฀ratio฀of฀incoming฀signal4:35:416:915:916:10

Sample฀image฀when฀the฀appro-

priate฀aspect฀ratio฀is฀automati-

cally฀determined

[Video฀signal]

Aspect฀ratio฀of฀incoming฀signal4:3LetterboxSqueeze

Sample฀image฀when฀the฀as-

pect฀ratio฀is฀automatically฀de-

termined

NOTE:Todisplayasqueezedsignalprop-

erly,select[16:9]or[WIDEZOOM].

M352WS/M302WS

[Computer฀signal]

Aspect฀ratio฀of฀incoming฀signal4:35:416:915:916:10

Sample฀image฀when฀the฀appro-

priate฀aspect฀ratio฀is฀automati-

cally฀determined

[Video฀signal]

Aspect฀ratio฀of฀incoming฀signal4:3LetterboxSqueeze

Sample฀image฀when฀the฀as-

pect฀ratio฀is฀automatically฀de-

termined

NOTE:Todisplayaletterboxsignalprop-

erly,select[LETTERBOX].

NOTE:Todisplayasqueezedsignalprop-

erly,select[16:9].

TIP:

•Imagepositioncanbeadjustedverticallyusing[POSITION]whenthe[16:9],[15:9],or[16:10]aspectratiosareselected.

•Theterm“letterbox”referstoamorelandscape-orientedimagewhencomparedtoa4:3image,whichisthestandardaspect

ratioforavideosource.

Theletterboxsignalhasaspectratioswiththevistasize“1.85:1”orcinemascopesize“2.35:1”formovielm.

•Theterm“squeeze”referstothecompressedimageofwhichaspectratioisconvertedfrom16:9to4:3.

Adjusting฀the฀Vertical฀Position฀of฀Image฀[POSITION]฀(not฀available฀on฀M352WS/M302WS)

(only฀when฀[16:9],฀[15:9],฀or฀[16:10]฀is฀selected฀for฀[ASPECT฀RATIO])

When฀[16:9],฀[15:9],฀or฀[16:10]฀is฀selected฀in฀[ASPECT฀RATIO],฀the฀image฀is฀displayed฀with฀black฀borders฀on฀the฀top฀

and bottom.

You฀can฀adjust฀the฀vertical฀position฀from฀the฀top฀to฀the฀bottom฀of฀the฀black฀area.

5. Using On-Screen Menu

Turning on Noise Reduction [NOISE REDUCTION]

This฀function฀allows฀you฀to฀select฀the฀level฀of฀noise฀reduction.

The฀projector฀is฀set฀to฀the฀optimized฀level฀for฀each฀signal฀at฀the฀factory.

Select฀your฀preference฀item฀for฀your฀signal฀when฀video฀noise฀is฀noticeable.

The฀options฀are฀[OFF],฀[LOW],฀[MEDIUM],฀and฀[HIGH].

NOTE:ThisfeatureisnotavailablefortheRGBsignal.Noisereductionsettooffgivesbestimagequalitybywayofhigherbandwidth.

Noisereductionsettoonsoftenstheimage.

Setting Telecine Mode [TELECINE]

This฀function฀allows฀you฀to฀convert฀motion฀picture฀lm฀images฀into฀video.฀The฀process฀adds฀additional฀frames฀to฀the฀

picture฀in฀order฀to฀increase฀the฀frame฀rate.

NOTE:ThisfeatureisavailableonlywhenanSDTVsignalisselected.

OFF ........................ Turns off the TELECINE mode.

2-2/2-3 AUTO ........ Detects pull-down correction method.

2-2 ON ................... Uses 2-2 pull-down correction method

2-3 ON ................... Uses 2-3 pull-down correction method

5. Using On-Screen Menu

❻ Menu Descriptions & Functions [SETUP]

[GENERAL]

Using Digital Zoom [DIGITAL ZOOM]

This฀feature฀allows฀you฀to฀electronically฀ne฀adjust฀the฀image฀size฀on฀the฀screen.฀Use฀the฀◀ or ▶฀button฀to฀large฀or฀

reduce฀the฀projected฀image.฀

TIP:Toadjusttheprojectedimagesizeroughly,movetheprojectorawayorclosertothescreen.Toneadjustthezoom,usethe

[DIGITALZOOM]function.(→page

22)

Enabling฀Auto฀Keystone฀[AUTO฀KEYSTONE]

This฀feature฀allows฀the฀projector฀to฀detect฀its฀tilt฀and฀correct฀vertical฀distortion฀automatically.

To฀turn฀on฀the฀AUTO฀KEYSTONE฀feature,฀select฀[ON].฀To฀adjust฀the฀KEYSTONE฀feature฀manually,฀select฀[OFF].

Correcting฀Vertical฀Keystone฀Distortion฀Manually฀[KEYSTONE]

You฀can฀correct฀vertical฀distortion฀manually.฀(→฀page฀

24)

TIP:Whenthisoptionishighlighted,pressingtheENTERbuttonwilldisplayitsslidebarforadjustment.

Saving฀Vertical฀Keystone฀Correction฀[KEYSTONE฀SAVE]

This฀option฀enables฀you฀to฀save฀your฀current฀keystone฀settings.

OFF ........................ Does not save current keystone correction settings. It will return your keystone correction settings to

“zero”.

ON ......................... Saves current keystone correction settings

Saving฀your฀change฀once฀affects฀all฀sources.฀The฀changes฀are฀saved฀when฀the฀projector฀is฀turned฀off.

NOTE:When[AUTOKEYSTONE]issetto[ON],[KEYSTONESAVE]isnotavailable.Nexttimeyouturnonthepower,theAUTO

KEYSTONEfunctionwillworkandthedatastoredwith[KEYSTONESAVE]willbeinvalid.

5. Using On-Screen Menu

Using the Wall Color Correction [WALL COLOR]

This฀function฀allows฀for฀quick฀adaptive฀color฀correction฀in฀applications฀where฀the฀screen฀material฀is฀not฀white.

NOTE:

•Selecting[WHITEBOARD]reduceslampbrightness.

•The[WALLCOLOR]itemcannotbeselectedwhen[ON]isselectedfor[3D]whileimagesareprojected.

Setting฀various฀items฀related฀to฀lamp฀brightness฀[ECO฀SETTINGS]

This฀option฀allows฀you฀to฀decrease฀the฀power฀consumption฀or฀to฀prolong฀the฀lamp฀life฀by฀controlling฀the฀lamp฀bright-

ness.

ECO MODE

The฀ECO฀MODE฀increases฀lamp฀life,฀while฀lowering฀power฀consumption฀and฀cutting฀down฀on฀CO2฀emissions.฀Four฀

brightness฀modes฀of฀the฀lamp฀can฀be฀selected:฀[OFF],฀[AUTO฀ECO],฀[NORMAL]฀and฀[ECO]฀modes.฀(→฀page฀

31)

NOTE:The[OFF]itemisautomaticallyselectedfor[ECOMODE]when[ON]isselected[3D]whileimagesareprojected.

AUTO ECO OPTIONS

Set฀options฀when฀[AUTO฀ECO]฀is฀selected฀for฀[ECO฀MODE].

AUTO฀DIMOFFThe฀AUTO฀DIM฀feature฀will฀not฀work.

0:01,฀0:03,฀0:10,฀0:20฀

(min.)

This฀option฀will฀automatically฀dim฀the฀lamp฀light฀when฀

no฀input฀signal฀is฀present฀for฀a฀certain฀period฀time:฀0:01,฀

0:03,฀0:10,฀and฀0:20฀(minutes).฀When฀it฀reaches฀the฀pre-

set฀time,฀the฀lamp฀brightness฀will฀decrease฀to฀about฀30%฀

immediately฀after฀the฀screen฀becomes฀dim฀for฀a฀moment.฀

Changing฀images฀will฀return฀to฀its฀original฀brightness.

ROOM฀LIGHT฀SENSINGOFFThe฀sensor฀will฀not฀work.

The฀sensor฀will฀detect฀ambient฀brightness฀and฀control฀the฀

lamp฀brightness.฀If฀the฀projector฀is฀placed฀in฀a฀dark฀room,฀

the฀lamp฀brightness฀will฀automatically฀decrease.

NOTE:Thebrightnesscannotbechangedwhen[CEILINGREAR]

or[CEILINGFRONT]isselectedfor[ORIENTATION].

NORMAL OPTION

Set฀the฀option฀when฀[NORMAL]฀is฀selected฀for฀[ECO฀MODE].

CONSTANT฀BRIGHTNESS:฀

OFF ........................ The CONSTANT BRIGHTNESS feature will not work. The lamp brightness will gradually decrease over long

periods of time.

ON ......................... The lamp brightness will increase according to the lamp use of time and will be kept at the lamp brightness

equivalent to the brightness at NORMAL. After the lamp brightness reaches the maximum, the lamp bright-

ness will gradually decrease over long periods of time.

5. Using On-Screen Menu

ECO OPTION

Set฀the฀option฀when฀[ECO]฀is฀selected฀for฀[ECO฀MODE].

CONSTANT฀BRIGHTNESS:

OFF ........................ The CONSTANT BRIGHTNESS feature will not work. The lamp brightness will gradually decrease over long

periods of time.

ON ......................... The lamp brightness will increase according to the lamp use of time and will be kept at the lamp brightness

equivalent to the brightness at ECO. After the lamp brightness reaches the maximum, the lamp brightness will

gradually decrease over long periods of time. The lamp brightness will be kept longer than at NORMAL.

Setting Closed Caption [CLOSED CAPTION]

This฀option฀sets฀several฀closed฀caption฀modes฀that฀allow฀text฀to฀be฀superimposed฀on฀the฀projected฀image฀of฀Video.

OFF ........................ This exits the closed caption mode.

CAPTION 1-4 ......... Text is superimposed.

TEXT 1-4 ................ Text is displayed.

NOTE:

•Theclosedcaptionisnotavailableunderthefollowingconditions:

-whenmessagesormenusaredisplayed.

-whenanimageismagnied,frozen,ormuted.

•Portionsofsuperimposedtextorclosedcaptionmaybetruncated.Ifthathappens,trytoplacethesuperimposedtextor

closedcaptionwithinthescreen.

Using Off Timer [OFF TIMER]

1.฀Select฀your฀desired฀time฀between฀30฀minutes฀and฀16฀hours:฀OFF,฀0:30,฀1:00,฀2:00,฀4:00,฀8:00,฀12:00,฀16:00.

2. Press the ENTER button on the remote control.

3.฀The฀remaining฀time฀starts฀counting฀down.

4.฀The฀projector฀will฀turn฀off฀after฀the฀countdown฀is฀complete.

NOTE:

•Tocancelthepresettime,set[OFF]forthepresettimeorturnoffthepower.

•Whentheremainingtimereaches3minutesbeforetheprojectoristurnedoff,the[THEPROJECTORWILLTURNOFFWITHIN3

MINUTES]messagewillbedisplayedonthebottomofthescreen.

Selecting Menu Language [LANGUAGE]

You฀can฀choose฀one฀of฀29฀languages฀for฀on-screen฀instructions.

NOTE:Yoursettingwillnotbeaffectedevenwhen[RESET]isdonefromthemenu.

5. Using On-Screen Menu

[MENU]

Selecting Menu Color [COLOR SELECT]

You฀can฀choose฀between฀two฀options฀for฀menu฀color:฀COLOR฀and฀MONOCHROME.

Turning฀On฀/฀Off฀Source฀Display฀[SOURCE฀DISPLAY]

This฀option฀turns฀on฀or฀off฀input฀name฀display฀such฀as฀COMPUTER,฀HDMI1,฀HDMI2,฀VIDEO,฀USB-A,฀LAN,฀USB-B,฀

to฀be฀displayed฀on฀the฀top฀right฀of฀the฀screen.

When฀no฀input฀signal฀is฀present,฀the฀no-signal฀guidance฀prompting฀you฀to฀check฀for฀an฀available฀input฀will฀be฀displayed฀

at฀the฀center฀of฀the฀screen.฀When฀the฀[USB-A]฀or฀[LAN]฀item฀is฀selected฀for฀[SOURCE],฀the฀no-signal฀guidance฀will฀

not฀be฀displayed.

Turning฀ON/OFF฀Control฀ID฀[ID฀DISPLAY]

ID DISPLAY ........... This option turns on or off the ID number which is displayed when the ID SET button on the remote control

is pressed.

Turning฀On฀/฀Off฀Eco฀Message฀[ECO฀MESSAGE]

This฀option฀turns฀on฀or฀off฀the฀following฀messages฀when฀the฀projector฀is฀turned฀on.฀

The฀Eco฀Message฀prompts฀the฀user฀to฀save฀energy.฀When฀[OFF]฀is฀selected฀for฀[ECO฀MODE],฀you฀will฀get฀a฀message฀

to฀prompt฀you฀to฀select฀[AUTO฀ECO],฀[NORMAL],฀or฀[ECO]฀for฀[ECO฀MODE].

When฀[AUTO฀ECO],฀[NORMAL],฀or฀[ECO]฀is฀selected฀for฀[ECO฀MODE]

To฀close฀the฀message,฀press฀any฀one฀of฀the฀buttons.฀The฀message฀will฀disappear฀if฀no฀button฀operation฀is฀done฀for฀

30 seconds.

When฀[OFF]฀is฀selected฀for฀[ECO฀MODE]

Pressing฀the฀ENTER฀button฀will฀display฀the฀[ECO฀MODE]฀screen.฀(→฀page฀31)

To฀close฀the฀message,฀press฀the฀EXIT฀button.

5. Using On-Screen Menu

Selecting฀Menu฀Display฀Time฀[DISPLAY฀TIME]

This฀option฀allows฀you฀to฀select฀how฀long฀the฀projector฀waits฀after฀the฀last฀touch฀of฀a฀button฀to฀turn฀off฀the฀menu.฀The฀

preset฀choices฀are฀[MANUAL],฀[AUTO฀5฀SEC],฀[AUTO฀15฀SEC],฀and฀[AUTO฀45฀SEC].฀The฀[AUTO฀45฀SEC]฀is฀the฀fac-

tory฀preset.

Selecting฀a฀Color฀or฀Logo฀for฀Background฀[BACKGROUND]

Use฀this฀feature฀to฀display฀a฀blue/black฀screen฀or฀logo฀when฀no฀signal฀is฀available.฀The฀default฀background฀is฀

[BLUE].

NOTE:

•Ifthe[LOGO]itemisselectedfor[BACKGROUND]withthe[LAN]or[USB-B]sourceselected,the[LOGO]itemwillbeselected

regardlessofitsselection.

•When[SOURCEDISPLAY]isturnedon,theno-signalguidancepromptingyoutocheckforanavailableinputwillbedisplayed

atthecenterofthescreenregardlessofitsselection.

•Yoursettingwillnotbeaffectedevenwhen[RESET]isdonefromthemenu.

5. Using On-Screen Menu

[INSTALLATION]

Selecting฀Projector฀Orientation฀[ORIENTATION]

This฀reorients฀your฀image฀for฀your฀type฀of฀projection.฀The฀options฀are:฀desktop฀front฀projection,฀ceiling฀rear฀projection,฀

desktop฀rear฀projection,฀and฀ceiling฀front฀projection.

DESKTOP฀FRONTCEILING฀REAR

DESKTOP฀REARCEILING฀FRONT

Disabling฀the฀Cabinet฀Buttons฀[CONTROL฀PANEL฀LOCK]

This฀option฀turns฀on฀or฀off฀the฀CONTROL฀PANEL฀LOCK฀function.

NOTE:

•ThisCONTROLPANELLOCKdoesnotaffecttheremotecontrolfunctions.

•Whenthecontrolpanelislocked,pressingandholdingtheSOURCEbuttonontheprojectorcabinetforabout10secondswill

changethesettingto[OFF].

TIP:Whenthe[CONTROLPANELLOCK]isturnedon,akeylockicon[]willbedisplayedatthebottomrightofthemenu.

Enabling฀Security฀[SECURITY]

This฀feature฀turns฀on฀or฀off฀the฀SECURITY฀function.

Unless฀the฀correct฀keyword฀is฀entered,฀the฀projector฀cannot฀project฀an฀image.฀(→฀page฀

33)

NOTE:Yoursettingwillnotbeaffectedevenwhen[RESET]isdonefromthemenu.

5. Using On-Screen Menu

Selecting Communication Speed [COMMUNICATION SPEED]

This฀feature฀sets฀the฀baud฀rate฀of฀the฀PC฀Control฀port฀(D-Sub฀9P).฀It฀supports฀data฀rates฀from฀4800฀to฀38400฀bps.฀The฀

default฀is฀38400฀bps.฀Select฀the฀appropriate฀baud฀rate฀for฀your฀equipment฀to฀be฀connected฀(depending฀on฀the฀equip-

ment,฀a฀lower฀baud฀rate฀may฀be฀recommended฀for฀long฀cable฀runs).

NOTE:Yourselectedcommunicationspeedwillnotbeaffectedevenwhen[RESET]isdonefromthemenu.

Setting฀ID฀to฀the฀Projector฀[CONTROL฀ID]

You฀can฀operate฀multiple฀projectors฀separately฀and฀independently฀with฀the฀single฀remote฀control฀that฀has฀the฀CONTROL฀

ID฀function.฀If฀you฀assign฀the฀same฀ID฀to฀all฀the฀projectors,฀you฀can฀conveniently฀operate฀all฀the฀projectors฀together฀

using฀the฀single฀remote฀control.฀To฀do฀so,฀you฀have฀to฀assign฀an฀ID฀number฀to฀each฀projector.

CONTROL ID NUMBER .......Select a number from 1 to 254 you wish to assign to your projector.

CONTROL ID .......................Select [OFF] to turn off the CONTROL ID setting and select [ON] to turn on the CONTROL ID set-

ting.

NOTE:

•When[ON]isselectedfor[CONTROLID],theprojectorcannotbeoperatedbyusingtheremotecontrolthatdoesnotsupport

theCONTROLIDfunction.(Inthiscasethebuttonsontheprojectorcabinetcanbeused.)

•Yoursettingwillnotbeaffectedevenwhen[RESET]isdonefromthemenu.

•PressingandholdingtheENTERbuttonontheprojectorcabinetfor10secondswilldisplaythemenuforcancelingtheControl

ID.

Assigning or Changing the Control ID

1. Turn on the projector.

2.฀Press฀the฀ID฀SET฀button฀on฀the฀remote฀control.

฀The฀CONTROL฀ID฀screen฀will฀be฀displayed.

฀If฀the฀projector฀can฀be฀operated฀with฀the฀current฀remote฀control฀ID,฀the฀[ACTIVE]฀will฀be฀displayed.฀If฀the฀projector฀

cannot฀be฀operated฀with฀the฀current฀remote฀control฀ID,฀the฀[INACTIVE]฀will฀be฀displayed.฀To฀operate฀the฀inactive฀

projector,฀assign฀the฀control฀ID฀used฀for฀the฀projector฀by฀using฀the฀following฀procedure฀(Step฀3).

3.฀Press฀one฀of฀numeric฀keypad฀buttons฀while฀pressing฀and฀holding฀the฀ID฀SET฀button฀

on the remote control.

Example:

฀To฀assign฀“3”,฀press฀the฀“3”฀button฀on฀the฀remote฀control.

฀No฀ID฀means฀that฀all฀the฀projectors฀can฀be฀operated฀together฀with฀a฀single฀remote฀control.฀

To฀set฀“No฀ID”,฀enter฀“000”฀or฀press฀the฀CLEAR฀button.

TIP:TherangeofIDsisfrom1to254.

4.฀Release฀the฀ID฀SET฀button.

฀The฀updated฀CONTROL฀ID฀screen฀will฀be฀displayed.

NOTE:

•TheIDscanbeclearedinafewdaysafterthebatteriesarerundownorremoved.

•AccidentallypressinganyoneofthebuttonsoftheremotecontrolwillclearcurrentlyspeciedIDwith

batteriesremoved.

5. Using On-Screen Menu

Using Test Pattern [TEST PATTERN]

Displays฀the฀test฀pattern฀to฀check฀for฀image฀distortion฀at฀the฀time฀of฀the฀projector฀setup.฀Press฀the฀ENTER฀button฀to฀

display฀the฀test฀pattern;฀press฀the฀EXIT฀button฀to฀close฀the฀test฀pattern฀and฀return฀to฀the฀menu.฀Menu฀operation฀and฀

keystone฀correction฀are฀not฀possible฀when฀the฀test฀pattern฀is฀displayed.

Selecting฀Microphone฀Type฀[MIC฀SELECT]

This฀feature฀allows฀you฀to฀select฀dynamic฀or฀condenser฀type฀for฀your฀microphone.

Setting MIC Gain [MIC GAIN]

This฀feature฀allows฀you฀to฀adjust฀your฀microphone฀sensitivity฀when฀it฀is฀connected฀to฀the฀MIC฀input฀jack฀of฀the฀projec-

tor.฀Microphone฀volume฀can฀be฀adjusted฀with฀the฀VOL.฀(+)฀or฀(−)฀button฀on฀the฀remote฀control฀or฀the฀◀ or ▶ on the

projector฀cabinet.

[OPTIONS(1)]

Selecting Fan Mode [FAN MODE]

This฀option฀allows฀you฀to฀select฀three฀modes฀for฀fan฀speed:฀Auto฀mode,฀High฀speed฀mode,฀and฀High฀Altitude฀mode.

AUTO ..................... The built-in fans automatically run at a variable speed according to the internal temperature.

HIGH ...................... The built-in fans run at high speed.

HIGH ALTITUDE ..... The built-in fans run at a high speed. Select this option when using the projector at altitudes approximately

5500 feet/1700 meters or higher.

When฀you฀wish฀to฀cool฀down฀the฀temperature฀inside฀the฀projector฀quickly,฀select฀[HIGH].

NOTE:

•ItisrecommendedthatyouselectHighspeedmodeifyouusetheprojectornon-stopforconsecutivedays.

•Set[FANMODE]to[HIGHALTITUDE]whenusingtheprojectorataltitudesapproximately5500feet/1700metersorhigher.

•Usingtheprojectorataltitudesapproximately5500feet/1700metersorhigherwithoutsettingto[HIGHALTITUDE]cancause

theprojectortooverheatandtheprotectorcouldshutdown.Ifthishappens,waitacoupleminutesandturnontheprojector.

•Usingtheprojectorataltitudeslessthanapproximately5500feet/1700metersandsettingto[HIGHALTITUDE]cancausethe

lamptoovercool,causingtheimagetoicker.Switch[FANMODE]to[AUTO].

•Usingtheprojectorataltitudesapproximately5500feet/1700metersorhighercanshortenthelifeofopticalcomponentssuch

asthelamp.

•Yoursettingwillnotbeaffectedevenwhen[RESET]isdonefromthemenu.

100

5. Using On-Screen Menu

Selecting Signal Format [COLOR SYSTEM]

This฀feature฀allows฀you฀to฀select฀video฀standards฀manually.

Normally฀select฀[AUTO].฀Select฀the฀video฀standard฀from฀the฀pulldown฀menu.฀

Enabling฀or฀Disabling฀WXGA฀Mode฀[WXGA฀MODE]

Selecting฀[ON]฀will฀give฀priority฀to฀WXGA฀(1280฀×฀768)/WUXGA฀(1920฀×฀1080)฀signals฀in฀recognizing฀an฀input฀sig-

nal.

When฀[WXGA฀MODE]฀is฀set฀to฀[ON],฀XGA฀(1024฀×฀768)/UXGA฀(1600฀×฀1200)฀signals฀may฀not฀be฀recognized฀on฀

M332XS.฀In฀this฀case,฀select฀[OFF].

NOTE:

•The[OFF]isselectedatthetimeofshipmentofM332XS.

•The[ON]isselectedatthetimeofshipmentofM352WS/M302WS.

Setting฀HDMI1/2฀[HDMI฀SETTINGS]

Make฀the฀settings฀for฀each฀video฀level฀when฀connecting฀HDMI฀equipment฀such฀as฀a฀DVD฀player.฀

VIDEO LEVEL ......... Select [AUTO] to automatically detect video level. If automatic detection may not work well, select [NOR-

MAL] to disable the [ENHANCED] feature of your HDMI equipment or select [ENHANCED] to improve image

contrast and increase detail in the dark areas.

NOTE:

•IftheprojectordoesnotreectthesettingsforyourHDMIequipmentsuchasaDVDplayerconnectedtotheHDMI1INorHDMI

2INconnector,selecttheHDMI1orHDMI2inputsourceagainontheprojector.

Setting Audio [AUDIO SELECT]

Make฀the฀settings฀for฀each฀audio฀level฀when฀connecting฀HDMI฀equipment,฀your฀network,฀and฀USB-B฀port.฀Select฀

between฀each฀equipment฀and฀computer.

HDMI ..................... Select [HDMI1] or [HDMI2] to switch the HDMI 1 or HDMI 2 IN digital audio signal or select [COMPUTER]

to switch the COMPUTER input audio signal.

LAN ........................ Select [LAN] or [COMPUTER] to switch the source connected to the network.

USB-B .................... Select [USB-B] or [COMPUTER] to switch the source connected over the USB cable (USB-B).

Enabling฀Key฀Sound฀and฀Error฀Sound฀[BEEP]

This฀feature฀turns฀on฀or฀off฀the฀button฀sound฀or฀alarm฀when฀an฀error฀occurs฀or฀the฀following฀operations฀are฀per-

formed.

-฀Displaying฀the฀main฀menu฀

-฀Switching฀sources

-฀Resetting฀data฀by฀using฀[RESET]

-฀Pressing฀POWER฀ON฀or฀STANDBY฀button

101

5. Using On-Screen Menu

[OPTIONS(2)]

Selecting฀Standby฀condition฀in฀[STANDBY฀MODE]

The฀projector฀has฀two฀standby฀modes:฀[NORMAL]฀and฀[NETWORK฀STANDBY].

The฀[NORMAL]฀mode฀is฀the฀mode฀that฀allows฀you฀to฀put฀the฀projector฀in฀the฀power-saving฀condition฀which฀consumes฀

less฀power฀than฀the฀[NETWORK฀STANDBY]฀mode.฀The฀projector฀is฀preset฀for฀the฀[NORMAL]฀mode฀at฀the฀factory.

NORMAL .............................POWER indicator: Red light/STATUS indicator: Off

When [NORMAL] is selected, only the following buttons and feature will work:

POWER button on the projector cabinet and the remote control, and powering on from PC Control

command.

NETWORK STANDBY ..........POWER indicator: Orange light/STATUS indicator: Off

When [NETWORK STANDBY] is selected, the projector can be turned on over a wired LAN connec-

tion and only the following buttons, port, and features will work:

POWER button on the projector cabinet and the remote control, powering on from PC Control

command, DIRECT POWER ON, AUTO POWER ON(COMP.), LAN port, wireless LAN unit (optional),

Virtual Remote Tool, LAN feature, and Mail Alert feature.

Important:

-When[NETWORKSTANDBY]isselected,[AUTOPOWEROFF]willturngreyincolorandbedisabled,and[0:15]willbeselected

automatically.

NOTE:

•Evenwhen[NORMAL]or[NETWORKSTANDBY]isselectedfor[STANDBYMODE],poweronoroffcanbedonebyusingthePC

CONTROLport.

•ThepowerconsumptioninthestandbymodewillnotbeincludedincalculatingCO

emissionreduction.

•Yoursettingwillnotbeaffectedevenwhen[RESET]isdonefromthemenu.

Enabling฀Direct฀Power฀On฀[DIRECT฀POWER฀ON]

Turns฀the฀projector฀on฀automatically฀when฀the฀power฀cord฀is฀inserted฀into฀an฀active฀power฀outlet.฀This฀eliminates฀the฀

need฀to฀always฀use฀the฀POWER฀button฀on฀the฀remote฀control฀or฀projector฀cabinet.

102

5. Using On-Screen Menu

Turning฀On฀the฀Projector฀By฀Applying฀Computer฀Signal฀[AUTO฀POWER฀ON(COMP.)]

When฀the฀projector฀is฀in฀Standby฀mode,฀applying฀a฀computer฀signal฀from฀a฀computer฀connected฀to฀the฀COMPUTER฀

IN฀input฀will฀power฀on฀the฀projector฀and฀simultaneously฀project฀the฀computer’s฀image.

This฀functionality฀eliminates฀the฀need฀to฀always฀use฀the฀POWER฀button฀on฀the฀remote฀control฀or฀the฀projector฀cabinet฀

to฀power฀on฀the฀projector.

To฀use฀this฀function,฀rst฀connect฀a฀computer฀to฀the฀projector฀and฀the฀projector฀to฀an฀active฀AC฀input.

NOTE:

•Disconnectingacomputersignalfromthecomputerwillnotpowerofftheprojector.Werecommendusingthisfunctionincom-

binationoftheAUTOPOWEROFFfunction.

•Thisfunctionwillnotbeavailableunderthefollowingconditions:

-whenacomponentsignalisappliedtotheCOMPUTERINconnector

-whenaSynconGreenRGBsignalorcompositesyncsignalisapplied

•ToenabletheAUTOPOWERON(COMP.)afterturningofftheprojector,wait3secondsandinputacomputersignal.

Ifacomputersignalisstillpresentwhentheprojectoristurnedoff,theAUTOPOWERON(COMP.)willnotworkandtheprojector

remainsinstandbymode.

Enabling฀Power฀Management฀[AUTO฀POWER฀OFF]

When฀this฀option฀is฀selected฀you฀can฀enable฀the฀projector฀to฀automatically฀turn฀off฀(at฀the฀selected฀time:฀5min.,฀10min.,฀

15min.,฀20min.,฀30min.,฀60min.)฀if฀there฀is฀no฀signal฀received฀by฀any฀input฀or฀if฀no฀operation฀is฀performed.

NOTE:

•Thisitemcanbeselectedonlywhen[NORMAL]isselectedfor[STANDBYMODE].

•When[NETWORKSTANDBY]isselected,[AUTOPOWEROFF]willturngreyincolorandbedisabledand[0:15]willbeselected

automatically.

Selecting Default Source [DEFAULT SOURCE SELECT]

You฀can฀set฀the฀projector฀to฀default฀to฀any฀one฀of฀its฀inputs฀each฀time฀the฀projector฀is฀turned฀on.

LAST ...................... Sets the projector to default to the previous or last active input each time the projector is turned on.

AUTO ..................... Searches for an active source in order of COMPUTER → HDMI1 → HDMI2 → VIDEO → USB-A → USB-B

→ COMPUTER and displays the ﬁrst found source.

COMPUTER ........... Displays the computer signal from the COMPUTER IN connector every time the projector is turned on.

HDMI1 ................... Displays the digital source from the HDMI 1 IN connector every time the projector is turned on.

HDMI2 ................... Displays the digital source from the HDMI 2 IN connector every time the projector is turned on.

VIDEO .................... Displays the Video source from the VIDEO IN connector every time the projector is turned on.

USB-A .................... Displays slides or plays back movie ﬁles from the USB memory device every time the projector is turned

on.

LAN ........................ Displays a signal from LAN port (RJ-45) or the USB Wireless LAN Unit.

USB-B .................... Displays the computer signal from the USB-B port every time the projector is turned on.

103

5. Using On-Screen Menu

Setting฀carbon฀footprint฀factor฀[CARBON฀CONVERT]

Adjusts฀the฀carbon฀footprint฀factor฀in฀the฀carbon฀saving฀calculation.฀The฀initial฀setting฀is฀0.505[kg-CO2/kWh]฀based฀on฀

the฀CO2฀Emissions฀from฀Fuel฀Combustion฀(2008฀Edition)฀published฀by฀OECD.

Selecting฀your฀currency฀[CURRENCY]

Displays฀electricity฀pricing฀(available฀in฀4฀currency฀units).

$ ............................ US Dollar

€ ........................... EU Euro

JP¥ ........................ Japanese Yen

RMB¥ .................... Chinese Yuan

Changing฀currency฀setting฀and฀currency฀convert฀setting฀[CURRENCY฀CONVERT]

Changes฀currency฀setting฀and฀currency฀convert฀setting฀for฀CARBON฀METER.

The฀initial฀setting฀are฀as฀follows:

US Dollar ............... 0.11 [$/kWh]

EU Euro ................. 0.19 [€/kWh]

Japanese Yen ......... 20 [¥/kWh]

Chinese Yuan

......... 0.48 [¥/kWh]

The฀initial฀settings฀for฀US฀dollar,฀EU฀Euro,฀and฀Japanese฀Yen฀are฀based฀on฀“Energy฀Prices฀and฀Taxes฀(second฀quarter฀

2010”฀published฀by฀OECD.

The฀initial฀setting฀for฀Chinese฀Yuan฀is฀based฀on฀“Chinese฀Data฀File฀(2010)”฀published฀by฀JETRO.

104

5. Using On-Screen Menu

[3D]

Selecting฀input฀connected฀to฀a฀source฀of฀3D฀images฀[COMPUTER/HDMI1/HDMI2/VIDEO]

[3D]

This฀function฀switches฀the฀3D฀mode฀between฀ON฀and฀OFF฀for฀each฀input.

ON ......................... Turns on the 3D mode for the selected input.

NOTE:

Toconrmthatthesupported3Dsignalisaccepted,useeitherwayofthefollowing:

•Makesurethat[3D]isdisplayedinthetoprightofthescreenafterthesourceisselected.

•Display[INFO.]→[SOURCE]→[3DSIGNAL]andmakesurethat“SUPPORTED”isdisplayed.

OFF ........................ Turns off the 3D mode for the selected input.

[GLASSES]

Select฀a฀3D฀glass฀method.

DLP

Link .............. For 3D eyeglasses (ones manufactured by XPAND are recommended) or DLP

Link compatible LCD shutter

eyeglasses.

Others .................... For other LCD shutter eyeglasses such as IR or wired LCD shutter types.

[FORMAT]

Sets฀3D฀format.

NOTE:ThisoptionwillnotworkforVIDEOsource.

AUTO ..................................Automatically selects the appropriate format. The supported format is HDMI 3D only.

SIDE BY SIDE .....................Selects this format for the SIDE BY SIDE 3D image. SIDE BY SIDE is a format that stores the left

and right eye images displayed horizontally. Only the half of the horizontal resolution is supported

TOP AND BOTTOM .............Selects this format for the TOP AND BOTTOM 3D image. TOP AND BOTTOM is a format that stores the

left and right eye images displayed vertically. Only the half of the vertical resolution is supported.

FRAME PACKING ................Selects this format for the FRAME PACKING 3D image. FRAM PACKING is a format that stores the

left and right eye images without compression.

FRAME SEQUENTIAL ..........Selects this format for the FRAME SEQUENTIAL 3D image. FRAME SEQUENTIAL is a format that

displays the left and right eye images alternately. This format is available only for COMPUTER

input.

NOTE:

ThisfunctionwillnotworkforVIDEOsource.

Thisoptionisavailableonlywhen[DLP

Link]isselectedfor[GLASSES].

105

5. Using On-Screen Menu

[L/R฀INVERT]

Change฀the฀setting฀if฀you฀have฀difculty฀seeing฀3D฀images.

NON-INVERT ......... Normal setting.

INVERT .................. Changes the order of displaying the images for left eye and right eye.

NOTE:

Thisoptionisavailableonlywhen[DLP

Link]isselectedfor[GLASSES].

106

5. Using On-Screen Menu

Setting up the Projector for a Wired LAN Connection [WIRED LAN]

Important

•฀Consult฀with฀your฀network฀administrator฀about฀these฀settings.

•฀When฀using฀a฀wired฀LAN฀connection,฀connect฀a฀LAN฀cable฀(Ethernet฀cable)฀to฀the฀LAN฀port฀(RJ-45)฀of฀the฀projec-

tor.฀(→฀page฀

123)

TIP:Thenetworksettingsyoumakewillnotbeaffectedevenwhen[RESET]isdonefromthemenu.

[WIRED฀LAN][DISABLE]Wired฀LAN฀connection฀will฀be฀turned฀off.

[ENABLE]Wired฀LAN฀connection฀will฀be฀turned฀on.

[SETTINGS][DHCP]

.......................... IP address, subnet mask, and gateway will

be automatically assigned to the projector

from your DHCP server.

OFF .........................Specify IP address, subnet mask, and gate-

way assigned by your network administra-

tor.

[IP฀ADDRESS]Set฀your฀IP฀address฀of฀the฀network฀connected฀to฀the฀

projector.

[SUBNET฀MASK]Set฀your฀subnet฀mask฀number฀of฀the฀network฀connected฀

to฀the฀projector.

[GATEWAY]Set฀the฀default฀gateway฀of฀the฀network฀connected฀to฀the฀

projector.

[AUTO฀DNS]

ON .......................... DHCP server will automatically assign IP

address of DNS server connected to the

projector.

OFF .........................Set your IP address of DNS server connected

to the projector.

[RECONNECT]Retry฀to฀connect฀the฀projector฀to฀a฀network.

107

5. Using On-Screen Menu

Setting up the Projector for a Wireless LAN Connection (with the optional USB Wireless

LAN Unit equipped) [WIRLESS LAN]

Important

•฀Consult฀with฀your฀network฀administrator฀about฀these฀settings.

•฀When฀using฀a฀wireless฀LAN฀connection,฀attach฀the฀optional฀USB฀Wireless฀LAN฀to฀the฀projector.฀(→฀page฀

124)

[PROFILE][DISABLE]Wireless฀LAN฀connection฀will฀be฀turned฀off

[EASY฀CONNECTION]Select฀[EASY฀CONNECTION]฀to฀execute฀a฀wireless฀LAN฀

easily฀using฀Image฀Express฀Utility฀Lite฀on฀the฀supplied฀

NEC฀Projector฀CD-ROM.

[SIMPLE฀ACCESS฀

POINT]

Set฀the฀projector฀for฀simple฀access฀point.

Selecting฀[SIMPLE฀ACCESS฀POINT]฀will฀allow฀the฀projec-

tor฀to฀create฀an฀infrastructure฀network.฀The฀IP฀address฀of฀

the฀projector฀will฀be฀set฀automatically.฀

Select฀"Obtain฀an฀IP฀Address฀Automatically"฀to฀set฀the฀IP฀

address฀of฀a฀connected฀computer.฀฀

It฀takes฀a฀few฀seconds฀for฀a฀change฀of฀your฀computer's฀IP฀

address฀to฀come฀into฀effect฀in฀Windows฀7/Windows฀Vista฀

while฀it฀takes฀one฀or฀two฀minutes฀in฀Window฀XP.฀

When฀you฀connect฀with฀your฀computer฀to฀save฀your฀prole฀

and฀select฀"Automatically฀connect฀when฀within฀range"฀from฀

the฀Properties฀tab฀of฀Wireless฀Network฀in฀Windows฀for฀your฀

selected฀prole,฀your฀wireless฀LAN฀will฀be฀accessed฀under฀

the฀following฀conditions:

•฀at฀the฀time฀of฀turning฀on฀the฀computer฀or฀the฀projec-

tor

•฀when฀the฀notebook฀type฀is฀within฀the฀range฀of฀the฀

projector's฀wireless฀LAN฀can฀be฀achieved.

Data฀transmission฀between฀wireless฀LAN฀and฀wired฀LAN฀

is฀not฀possible.฀

When฀the฀[SIMPLE฀ACCESS฀POINT]฀mode฀is฀used฀to฀

send฀images,฀it฀is฀recommended฀to฀connect฀to฀only฀one฀

computer.

[PROFILE฀1]Up฀to฀two฀settings฀for฀the฀USB฀wireless฀LAN฀unit฀can฀be฀

stored฀in฀memory฀of฀the฀projector.฀(→฀page฀

48)

To฀recall฀the฀settings฀from฀memory,฀select฀[PROFILE฀1]฀or฀

[PROFILE฀2]฀from฀[PROFILE].

[PROFILE฀2]

[RECONNECT]Retry฀to฀connect฀the฀projector฀to฀a฀network.฀Try฀this฀if฀you฀have฀changed฀[PROFILE].

NOTE:Afterselecting[EASYCONNECTION]from[PROFILE],youcannotmakesettingsto[DHCP],[IPADDRESS],[SUBNETMASK],

[GATEWAY],and[AUTODNS]except[CHANNEL].

108

5. Using On-Screen Menu

Hints on How to Set Up LAN Connection

To฀set฀up฀the฀projector฀for฀a฀LAN฀connection:

Access฀the฀HTTP฀server฀function฀to฀display฀the฀web฀browser฀(→฀page฀45)฀and฀select฀[NETWORK฀SETTINGS]฀→

[SETTINGS]฀→฀[WIRELESS฀LAN]฀→฀[PROFILE฀1]฀or฀[PROFILE฀2].

Two฀settings฀can฀be฀set฀for฀the฀USB฀Wireless฀LAN฀Unit.

Next฀select฀[SETTINGS]฀for฀your฀selected฀prole,฀and฀set฀[ENABLE]฀or฀[DISABLE]฀for฀[DHCP],฀[IP฀ADDRESS],฀

[SUBNET฀MASK],฀and฀[GATEWAY].฀Last฀click฀[SAVE].฀To฀reect฀changes,฀click฀the฀[SETTING]฀tab฀and฀then฀click฀

[APPLY].฀(→฀page฀48)

To฀recall฀LAN฀settings฀stored฀in฀the฀prole฀number:

To฀use฀[PROFILE฀1]฀or฀[PROFILE฀2]฀set฀on฀the฀HTTP฀server,฀from฀the฀projector’฀menu,฀select฀[SETUP]฀→฀[WIRE-

LESS฀LAN]฀→฀[PROFILE]฀→฀[PROFILE฀1]฀or฀[PROFILE฀2].฀Last฀select฀[YES]฀and฀press฀the฀ENTER฀button.฀(→

page฀

107)

To connect a DHCP server:

From฀the฀projector฀menu,฀select฀[SETUP]฀→฀[WIRED฀LAN]฀→฀[SETTINGS]฀→฀[DHCP]฀→฀[ON]฀and฀press฀the฀ENTER฀

button.฀To฀specify฀IP฀address฀without฀using฀the฀DHCP฀server,฀use฀the฀HTTP฀server฀function.฀(→฀page฀

45)

To฀set฀only฀for฀wireless฀LAN฀(NETWORK฀TYPE฀and฀WEP/WPA):

Access฀the฀HTTP฀server฀function฀to฀display฀the฀web฀browser฀(→฀page฀

45)฀and฀select฀[NETWORK฀SETTINGS]฀→

[SETTINGS]฀→฀[WIRELESS฀LAN]฀→฀[PROFILE฀1]฀or฀[PROFILE฀2].

Make฀necessary฀settings฀for฀[SETTINGS]฀and฀click฀[SAVE].

From฀the฀projector฀menu,฀select฀[SETUP]฀→฀[WIRELESS฀LAN]฀→฀[PROFILE]฀→฀[PROFILE฀1]฀or฀[PROFILE฀2].฀

To select an SSID:

Access฀the฀HTTP฀server฀function฀to฀display฀the฀web฀browser฀(→฀page฀

45)฀and฀select฀[NETWORK฀SETTINGS]฀→

[SETTINGS]฀→฀[WIRELESS฀LAN]฀→฀[CONNECTION]฀→฀[SITE฀SURVEY]฀and฀select฀the฀ID.

If฀you฀do฀not฀use฀[SITE฀SURVEY],฀type฀the฀SSID฀in฀[CONNECTION]฀and฀select฀[INFRASTRUCTURE]฀or฀[AD฀HOC].฀

(→฀page฀48)

To฀receive฀lamp฀replacement฀time฀or฀error฀messages฀via฀e-mail:

Access฀the฀HTTP฀server฀function฀to฀display฀the฀web฀browser฀(→฀page฀

45)฀and฀select฀[NETWORK฀SETTINGS]฀→

[ALERT฀MAIL],฀and฀set฀[SENDER’S฀ADDRESS],฀[SMTP฀SERVER฀NAME],฀and฀[RECIPIENT’S฀ADDRESS].฀Last,฀

click฀[SAVE].฀(→฀page฀50)

To฀execute฀[EASY฀CONNECTION]฀using฀Image฀Express฀Utility฀Lite:

The฀[EASY฀CONNECTION]฀is฀a฀mode฀that฀can฀abbreviate฀the฀troublesome฀LAN฀settings฀when฀using฀the฀Image฀

Express฀Utility฀Lite฀and฀connecting฀the฀PC฀and฀projector฀via฀a฀wireless฀LAN.

The฀Image฀Express฀Utility฀Lite฀is฀contained฀on฀the฀supplied฀NEC฀Projector฀CD-ROM.฀

To฀use฀[EASY฀CONNECTION],฀access฀the฀HTTP฀server฀function฀to฀display฀the฀web฀browser฀(→฀page฀

45)฀and฀select฀

[NETWORK฀SETTINGS]฀→฀[SETTINGS]฀→฀[WIRELESS฀LAN]฀→฀[EASY฀CONNECTION].฀Next฀select฀[SETTINGS]฀

→฀[CHANNEL].฀Last฀click฀[SAVE].

From฀the฀projector฀menu,฀select฀[SETUP]฀→฀[WIRELESS฀LAN]฀→฀[PROFILE]฀→฀[EASY฀CONNECTION].฀

109

5. Using On-Screen Menu

❼ Menu Descriptions & Functions [INFO.]

Displays฀the฀status฀of฀the฀current฀signal฀and฀lamp฀usage.฀This฀item฀has฀six฀pages.฀The฀information฀included฀is฀as฀

follows:

TIP:PressingtheHELPbuttonontheremotecontrolwillshowthe[INFO.]menuitems.

[USAGE TIME]

[LAMP฀LIFE฀REMAINING]฀(%)*

[LAMP฀HOURS฀USED]฀(H)

[TOTAL฀CARBON฀SAVINGS]฀(kg-CO2)

[TOTAL฀COST฀SAVINGS]($)

*฀The฀progress฀indicator฀shows฀the฀percentage฀of฀remaining฀bulb฀life.

฀The฀value฀informs฀you฀of฀the฀amount฀of฀lamp฀usage.฀When฀the฀remaining฀lamp฀time฀reaches฀0,฀the฀LAMP฀LIFE฀

REMAINING฀bar฀indicator฀changes฀from฀0%฀to฀100฀Hours฀and฀starts฀counting฀down.

฀If฀the฀remaining฀lamp฀time฀reaches฀0฀hours,฀the฀projector฀will฀not฀turn฀on.

•฀The฀message฀to฀the฀effect฀that฀the฀lamp฀should฀be฀replaced฀will฀be฀displayed฀for฀one฀minute฀when฀the฀projec-

tor฀is฀turned฀on฀and฀when฀the฀POWER฀button฀on฀the฀projector฀or฀the฀STANDBY฀button฀on฀the฀remote฀control฀is฀

pressed.

฀To฀dismiss฀this฀message,฀press฀any฀button฀on฀the฀projector฀or฀the฀remote฀control.

Lamp฀life฀(H)Brightness฀by฀mode

OFF AUTO ECO NORMAL ECO OFF AUTO ECO NORMAL ECO

M352WS

3500H

3500H฀to฀

6000H

5000H

8000H100%

OFF฀thru฀

ECO

Approx.฀81%

Approx.฀60%

M332XS

M302WS

3500H฀to฀

7000H

5500HApprox.฀76%

•฀[TOTAL฀CARBON฀SAVINGS]

฀This฀displays฀the฀estimated฀carbon฀saving฀information฀in฀kg.฀The฀carbon฀footprint฀factor฀in฀the฀carbon฀saving฀cal-

culation฀is฀based฀on฀the฀OECD฀(2008฀Edition).฀(→฀page฀32)

110

5. Using On-Screen Menu

[SOURCE(1)]

[RESOLUTION]฀[HORIZONTAL฀FREQUENCY]

[VERTICAL฀FREQUENCY]฀[SYNC฀TYPE]

[SYNC฀POLARITY]฀[SCAN฀TYPE]

[SOURCE(2)]

[SIGNAL฀TYPE]฀[VIDEO฀TYPE]

[BIT฀DEPTH]฀[VIDEO฀LEVEL]

[3D฀SIGNAL]

[WIRED LAN]

[IP฀ADDRESS]฀[SUBNET฀MASK]

[GATEWAY]฀[MAC฀ADDRESS]

111

5. Using On-Screen Menu

[WIRELESS LAN]

[IP฀ADDRESS]฀[SUBNET฀MASK]

[GATEWAY]฀[MAC฀ADDRESS]

[SSID]฀[NETWORK฀TYPE]

[WEP/WPA]฀[CHANNEL]

[SIGNAL฀LEVEL]

[VERSION(1)]

[FIRMWARE]฀Version

[DATA]฀Version

[VERSION(2)]

[FIRMWARE2]฀Version

112

5. Using On-Screen Menu

[OTHERS]

[PROJECTOR฀NAME]

[MODEL฀NO.]

[SERIAL฀NUMBER]

[LAN฀UNIT฀TYPE]

[CONTROL฀ID]฀(when฀[CONTROL฀ID]฀is฀set)

113

5. Using On-Screen Menu

❽ Menu Descriptions & Functions [RESET]

Returning to Factory Default [RESET]

The฀RESET฀feature฀allows฀you฀to฀change฀adjustments฀and฀settings฀to฀the฀factory฀preset฀for฀a฀(all)฀source฀(s)฀except฀

the฀following:

[CURRENT฀SIGNAL]

Resets฀the฀adjustments฀for฀the฀current฀signal฀to฀the฀factory฀preset฀levels.฀

The฀items฀that฀can฀be฀reset฀are:฀[PRESET],฀[CONTRAST],฀[BRIGHTNESS],฀[COLOR],฀[HUE],฀[SHARPNESS],฀

[ASPECT฀RATIO],฀[HORIZONTAL],฀[VERTICAL],฀[CLOCK],฀[PHASE],฀[OVERSCAN],฀[NOISE฀REDUCTION],฀and฀

[TELECINE]..

[ALL฀DATA]

Reset฀all฀the฀adjustments฀and฀settings฀for฀all฀the฀signals฀to฀the฀factory฀preset.

All items can be reset EXCEPT฀[LANGUAGE],฀[BACKGROUND],฀[SECURITY],฀[COMMUNICATION฀SPEED],฀

[CONTROL฀ID],฀[STANDBY฀MODE],฀[FAN฀MODE],฀[CARBON฀CONVERT],฀[CURRENCY],฀[CURRENCY฀CON-

VERT],฀[LAMP฀LIFE฀REMAINING],฀[LAMP฀HOURS฀USED],฀[TOTAL฀CARBON฀SAVINGS],฀[WIRED฀LAN],฀and฀

[WIRELESS฀LAN].

To฀reset฀the฀lamp฀usage฀time,฀see฀“Clearing฀Lamp฀Hour฀Meter฀[CLEAR฀LAMP฀HOURS]”฀below.

Clearing Lamp Hour Meter [CLEAR LAMP HOURS]

Resets฀the฀lamp฀clock฀back฀to฀zero.฀Selecting฀this฀option฀displays฀submenu฀for฀a฀conrmation.฀Select฀[YES]฀and฀press฀

the฀ENTER฀button.

NOTE:Elapsedtimeofthelampusewillnotbeaffectedevenwhen[RESET]isdonefromthemenu.

NOTE:Theprojectorwillturnoffandgointostandbymodewhenyoucontinuetousetheprojectorforanother100hoursafterthe

lamphasreachedtheendofitslife.Inthisconditionyoucannotclearthelamphourmeteronthemenu.Ifthishappens,pressthe

HELPbuttonontheremotecontrolfor10secondstoresetthelampclockbacktozero.Dothisonlyafterreplacingthelamp.

114

6. Installation and Connections

This฀section฀describes฀how฀to฀set฀up฀your฀projector฀and฀how฀to฀connect฀video฀and฀audio฀sources.

Your฀projector฀is฀simple฀to฀set฀up฀and฀use.฀But฀before฀you฀get฀started,฀you฀must฀rst:

①฀Set฀up฀a฀screen฀and฀the฀projector.

②฀Connect฀your฀computer฀or฀video฀equip-

ment฀to฀the฀projector.

฀(→฀page฀117, 119, 120, 121, 122,

123)

③

฀Connect฀the฀supplied฀power฀cord.

(→฀page฀

16)

NOTE:Ensurethatthepowercordandanyother

cablesaredisconnectedbeforemovingthepro-

jector.Whenmovingtheprojectororwhenitis

notinuse,coverthelenswiththeslidinglens

cover.

❶ Setting Up the Screen and the Projector

Selecting a Location

[M332XS]

The฀further฀your฀projector฀is฀from฀the฀screen฀or฀wall,฀the฀larger฀the฀image.฀The฀minimum฀size฀the฀image฀can฀be฀is฀ap-

proximately฀60"฀(1.52฀m)฀measured฀diagonally฀when฀the฀projector฀is฀roughly฀27฀inches฀(0.68฀m)฀from฀the฀wall฀or฀screen.฀

The฀largest฀the฀image฀can฀be฀is฀150"฀(3.8฀m)฀when฀the฀projector฀is฀about฀69฀inches฀(1.8฀m)฀from฀the฀wall฀or฀screen.

150"

120"

Distance

(Unit: m/inch)

Lens center

Screen Size

1.4/55"

1.8/69.2"

1.2/45.5"

0.9/36"

0.7/26.6"

203.2(W)�152.4(H) / 80(W)�60(H)

162.6(W)�121.9(H) / 64(W)�48(H)

121.9(W)�91.4(H) / 48(W)�36(H)

Screen Size (Unit: cm/inch)

304.8(W)�228.6(H) / 120(W)�90(H)

243.8(W)�182.9(H) / 96(W)�72(H)

100"

80"

60"

TIP:

•DigitalZoomcanresultinablurryimageduetotheelectroniczoom.

•Formoredetailsonthrowdistance,seepage116.

To the wall outlet.

115

6. Installation and Connections

[M352WS/M302WS]

The฀further฀your฀projector฀is฀from฀the฀screen฀or฀wall,฀the฀larger฀the฀image.฀The฀minimum฀size฀the฀image฀can฀be฀is฀ap-

proximately฀60"฀(1.52฀m)฀measured฀diagonally฀when฀the฀projector฀is฀roughly฀22฀inches฀(0.6฀m)฀from฀the฀wall฀or฀screen.฀

The฀largest฀the฀image฀can฀be฀is฀150"฀(3.8฀m)฀when฀the฀projector฀is฀about฀58฀inches฀(1.5฀m)฀from฀the฀wall฀or฀screen.

150"

120"

Distance

(Unit: m/inch)

Lens center

Screen Size

1.2/46.3"

1.5/58.3"

1/38.3"

0.8/30.3"

0.6/22.2"

Screen Size (Unit: cm/inch)

323.1(W)�201.9(H) / 127(W)�79(H)

258.5(W)�161.5(H) / 102(W)�64(H)

100"

80"

60"

215.4(W)�134.6(H) / 85(W)�53(H)

172.3(W)�107.7(H) / 68(W)�42(H)

129.2(W)�80.8(H) / 51(W)�32(H)

TIP:

•DigitalZoomcanresultinablurryimageduetotheelectroniczoom.

•Formoredetailsonthrowdistance,seepage116.

116

6. Installation and Connections

Throw Distance and Screen Size

The฀following฀shows฀the฀proper฀relative฀positions฀of฀the฀projector฀and฀screen.฀Refer฀to฀the฀table฀to฀determine฀the฀

position฀of฀installation.

Distance Chart

B฀=฀Vertical฀distance฀between฀lens฀center฀and฀

screen center

C฀=฀Throw฀distance

D฀=฀Vertical฀distance฀between฀lens฀center฀and฀

screen฀bottom฀(top฀of฀screen฀for฀ceiling฀ap-

plication)

α฀=฀Throw฀angle

NOTE:Thevaluesinthetablesaredesignvaluesand

mayvary.

[M332XS]

Screen Size

Diagonal Width Height wide wide

inch mm inch mm inch mm inch mm inch mm inch mm degree

60 1524 48 1219 36 914 24 617 27 675 6 160

40.8

80 2032 64 1626 48 1219 32 823 36 915 8 214 40.8

100 2540 80 2032 60 1524 41 1029 46 1156 11 267 40.7

120 3048 96 2438 72 1829 49 1235 55 1396 13 320 40.7

150 3810 120 3048 90 2286 61 1543 69 1757 16 400 40.7

[M352WS/M302WS]

Screen Size

Diagonal Width Height wide wide

inch mm inch mm inch mm inch mm inch mm inch mm degree

60 1524 51 1292 32 808 21 524 22 565 5 120

40.9

80 2032 68 1723 42 1077 27 698 30 769 6 160 40.8

100 2540 85 2154 53 1346 34 873 38 973 8 199 40.8

120 3048 102 2585 64 1615 41 1047 46 1177 9 239 40.7

150 3810 127 3231 79 2019 52 1309 58 1482 12 299 40.7

WARNING

*฀Installing฀your฀projector฀on฀the฀ceiling฀must฀be฀done฀by฀a฀qualied฀technician.฀Contact฀your฀NEC฀dealer฀for฀more฀

information.

*฀Do฀not฀attempt฀to฀install฀the฀projector฀yourself.

•฀Only฀use฀your฀projector฀on฀a฀solid,฀level฀surface.฀If฀the฀projector฀falls฀to฀the฀ground,฀you฀can฀be฀injured฀and฀the฀

projector฀severely฀damaged.

•฀Do฀not฀use฀the฀projector฀where฀temperatures฀vary฀greatly.฀The฀projector฀must฀be฀used฀at฀temperatures฀between฀

41°F฀(5°C)฀and฀104°F฀(40°C)฀(Eco฀mode฀selected฀automatically฀at฀95°F฀to฀104°F/35°C฀to฀40°C).

•฀Do฀not฀expose฀the฀projector฀to฀moisture,฀dust,฀or฀smoke.฀This฀will฀harm฀the฀screen฀image.

•฀Ensure฀that฀you฀have฀adequate฀ventilation฀around฀your฀projector฀so฀heat฀can฀dissipate.฀Do฀not฀cover฀the฀vents฀on฀

the฀side฀or฀the฀front฀of฀the฀projector.

Reﬂecting the Image

Using฀a฀mirror฀to฀reect฀your฀projector’s฀image฀enables฀you฀to฀enjoy฀a฀much฀larger฀image฀when฀a฀smaller฀space฀is฀

required.฀Contact฀your฀NEC฀dealer฀if฀you฀need฀a฀mirror฀system.฀If฀you’re฀using฀a฀mirror฀system฀and฀your฀image฀is฀

inverted,฀use฀the฀MENU฀and฀▲▼◀▶฀buttons฀on฀your฀projector฀cabinet฀or฀your฀remote฀control฀to฀correct฀the฀orienta-

tion.฀(→฀page฀

97)

Screen center

Lens center

Screen bottom

117

6. Installation and Connections

HDMI 2 IN

HDMI 1 IN

COMPUTER IN

USB-B

AUDIO IN

Computer cable (VGA) (supplied)

To mini D-Sub 15-pin connector

on฀the฀projector.฀It฀is฀recommend-

ed that you use a commercially

available distribution ampliﬁer if

connecting a signal cable longer

than the cable supplied.

NOTE:ForMac,useacommercially

availablepinadapter(notsup-

plied)toconnecttoyourMac’s

videoport.

A commercially available USB cable

(compatible with USB 2.0 speciﬁcations)

Stereo mini-plug audio

cable (not supplied)

❷ Making Connections

NOTE:WhenusingwithanotebookPC,besuretoconnecttheprojectorandnotebookPCwhiletheprojectorisinstandbymode

andbeforeturningonthepowertothenotebookPC.

InmostcasestheoutputsignalfromthenotebookPCisnotturnedonunlessconnectedtotheprojectorbeforebeingpoweredup.

*Ifthescreengoesblankwhileusingyourremotecontrol,itmaybetheresultofthecomputer’sscreen-saverorpowermanage-

mentsoftware.

Enabling the computer’s external display

Displaying฀an฀image฀on฀the฀notebook฀PC’s฀screen฀does฀not฀necessarily฀mean฀it฀outputs฀a฀signal฀to฀the฀projector.

When฀using฀a฀PC฀compatible฀laptop,฀a฀combination฀of฀function฀keys฀will฀enable/disable฀the฀external฀display.

Usually,฀the฀combination฀of฀the฀“Fn”฀key฀along฀with฀one฀of฀the฀12฀function฀keys฀gets฀the฀external฀display฀to฀come฀on฀

or฀off.฀For฀example,฀NEC฀laptops฀use฀Fn฀+฀F3,฀while฀Dell฀laptops฀use฀Fn฀+฀F8฀key฀combinations฀to฀toggle฀through฀

external฀display฀selections.

Connecting Your Computer

NOTE:SignalssupportedbyPlug&Play(DDC2)

INPUT

COMPUTER IN HDMI 1 IN HDMI 2 IN

analog digital digital

Yes Yes Yes

HDMI฀cable฀(not฀supplied)

Use฀High฀Speed฀HDMI

Cable.

118

6. Installation and Connections

•฀Select฀the฀source฀name฀for฀its฀appropriate฀input฀connector฀after฀turning฀on฀the฀projector.

Input฀connector

SOURCE฀button฀on฀the฀projector฀

cabinet

Button฀on฀the฀remote฀control

COMPUTER฀IN

฀COMPUTER(COMP1)

HDMI฀1฀IN

฀HDMI1HDMI1

HDMI฀2฀IN

฀HDMI2HDMI2

USB-B

฀USB-B(USB-B)

NOTE:TheprojectorisnotcompatiblewithvideodecodedoutputsoftheNECISS-6020switcher.

NOTE:AnimagemaynotbedisplayedcorrectlywhenaVideosourceisplayedbackviaacommerciallyavailablescanconverter.

Thisisbecausetheprojectorwillprocessavideosignalasacomputersignalatthedefaultsetting.Inthatcase,dothefollowing.

*Whenanimageisdisplayedwiththelowerandupperblackportionofthescreenoradarkimageisnotdisplayedcorrectly:

ProjectanimagetollthescreenandthenpresstheAUTOADJ.buttonontheremotecontrolortheprojectorcabinet.

119

6. Installation and Connections

Connecting an External Monitor

You฀can฀connect฀a฀separate,฀external฀monitor฀to฀your฀projector฀to฀simultaneously฀view฀on฀a฀monitor฀the฀computer฀

analog฀image฀you’re฀projecting.

NOTE:

•Daisychainconnectionisnotpossible.

•Whenaudioequipmentisconnected,theprojectorspeakerisdisabled.

Monitor฀out฀and฀sleep฀mode:

•฀The฀MONITOR฀OUT฀(COMP.)฀connector฀will฀not฀work฀when฀[NORMAL]฀is฀selected฀for฀[STANDBY฀MODE].

฀The฀MONITOR฀OUT฀(COMP.)฀connector฀will฀work฀only฀in฀the฀sleep฀mode.

฀Applying฀a฀signal฀from฀the฀COMPUTER฀IN฀connector฀will฀put฀the฀projector฀in฀the฀sleep฀mode,฀which฀allows฀you฀to฀

use฀the฀MONITOR฀OUT(COMP.)฀connector฀and฀the฀AUDIO฀OUT฀mini฀jack.฀Sound฀from฀the฀MIC฀input฀jack฀will฀be฀

output฀to฀the฀AUDIO฀OUT฀mini฀jack.

฀The฀sleep฀mode฀is฀one฀of฀the฀standby฀modes.฀The฀sleep฀mode฀cannot฀be฀selected฀from฀the฀menu.

•฀In฀the฀network฀standby฀mode,฀฀sound฀for฀the฀last฀viewed฀computer฀or฀video฀source฀will฀be฀heard.

฀฀BNC-to-฀D-SUB฀converted฀signal฀will฀not฀be฀output฀in฀the฀standby฀mode฀and฀sleep฀mode.

MONITOR OUT(COMP.)

AUDIO OUT

Computer cable (VGA) (supplied)

Stereo mini-plug audio cable (not supplied)

Computer cable (VGA)

(not supplied)

120

6. Installation and Connections

Connecting Your DVD Player or Other AV Equipment

Connecting฀Video฀Input

•฀Select฀the฀source฀name฀for฀its฀appropriate฀input฀connector฀after฀turning฀on฀the฀projector.

Input฀connector

SOURCE฀button฀on฀the฀projector฀

cabinet

Button฀on฀the฀remote฀control

VIDEO฀IN

฀VIDEO

(VIDEO)

NOTE:TheAUDIOINLandRjacks(RCA)aresharedbetweentheVideoinputs.

NOTE:RefertoyourVCRowner’smanualformoreinformationaboutyourequipment’svideooutputrequirements.

NOTE:AnimagemaynotbedisplayedcorrectlywhenaVideosourceisplayedbackinfast-forwardorfast-rewindviaascan

converter.

VIDEO IN

AUDIO IN

Audio cable (not supplied)

Video cable (not supplied)

Audio equipment

Audio cable (not supplied)

121

6. Installation and Connections

Connecting Component Input

•฀Select฀the฀source฀name฀for฀its฀appropriate฀input฀connector฀after฀turning฀on฀the฀projector.

Input฀connector

SOURCE฀button฀on฀the฀projector฀

cabinet

Button฀on฀the฀remote฀control

COMPUTER฀IN

฀COMPUTER(COMP1)

NOTE:RefertoyourDVDplayer’sowner’smanualformoreinformationaboutyourDVDplayer’svideooutputrequirements.

COMPUTER IN

AUDIO IN

Audio cable (not supplied)

15-pin - to - RCA (fe-

male) × 3 cable adapter

(ADP-CV1E)

Stereo mini plug - to - RCA audio

cable (not supplied)

Component video RCA × 3

cable (not supplied)

DVD player

Audio Equipment

122

6. Installation and Connections

HDMI 2 IN

HDMI 1 IN

Connecting HDMI Input

You฀can฀connect฀the฀HDMI฀output฀of฀your฀DVD฀player,฀hard฀disk฀player,฀Blu-ray฀player,฀or฀notebook฀type฀PC฀to฀the฀

HDMI฀IN฀connector฀of฀your฀projector.

NOTE:TheHDMIINconnectorsupportsPlug&Play(DDC2B).

Audio cable (not supplied)

HDMI฀cable฀(not฀supplied)

Use฀High฀Speed฀HDMI

Cable.

Input฀connector

SOURCE฀button฀on฀the฀projector฀

cabinet

Button฀on฀the฀remote฀control

HDMI฀1฀IN

฀HDMI1HDMI1

HDMI฀2฀IN

฀HDMI2HDMI2

TIP:ForusersofaudiovideoequipmentwithanHDMIconnector:

Select“Enhanced”ratherthan“Normal”ifHDMIoutputisswitchablebetween“Enhanced”and“Normal”.

Thiswillprovideimprovedimagecontrastandmoredetaileddarkareas.

Formoreinformationonsettings,refertotheinstructionmanualoftheaudiovideoequipmenttobeconnected.

•฀When฀connecting฀the฀HDMI฀IN฀connector฀of฀the฀projector฀to฀the฀DVD฀player,฀the฀projector’s฀video฀level฀can฀be฀

made฀settings฀in฀accordance฀with฀the฀DVD฀player’s฀video฀level.฀In฀the฀menu฀select฀[HDMI฀SETTINGS]฀→฀[VIDEO฀

LEVEL]฀and฀make฀necessary฀settings.

•฀If฀the฀HDMI฀input฀sound฀cannot฀be฀heard,฀in฀the฀menu฀select฀[HDMI฀SETTINGS]฀→฀[AUDIO฀SELECT]฀→฀[HDMI1]฀

or฀[HDMI2].฀

Audio Equipment

123

6. Installation and Connections

Connecting to a Wired LAN

The฀projector฀comes฀standard฀with฀a฀LAN฀port฀(RJ-45)฀which฀provides฀a฀LAN฀connection฀using฀a฀LAN฀cable.฀

To฀use฀a฀LAN฀connection,฀you฀are฀required฀to฀set฀the฀LAN฀on฀the฀projector฀menu.฀฀Select฀[SETUP]฀→฀[WIRED฀LAN].฀

(→฀page฀

106).

Example of LAN connection

Example฀of฀wired฀LAN฀connection

Server

Hub

LAN cable (not supplied)

NOTE:UseaCategory5orhigher

LANcable.

124

6. Installation and Connections

Connecting to a Wireless LAN (Optional: NP02LM series)

The฀USB฀Wireless฀LAN฀Unit฀also฀provides฀a฀wireless฀LAN฀connection.฀To฀use฀a฀wireless฀LAN฀connection,฀you฀are฀

required฀to฀assign฀an฀IP฀address฀to฀the฀projector.

Important:

•฀If฀you฀use฀the฀projector฀with฀the฀USB฀Wireless฀LAN฀Unit฀in฀the฀area฀where฀the฀use฀of฀wireless฀LAN฀equipment฀is฀

prohibited,฀remove฀the฀USB฀Wireless฀LAN฀Unit฀from฀the฀projector.

•฀Buy฀the฀appropriate฀USB฀Wireless฀LAN฀Unit฀for฀your฀country฀or฀area.

NOTE:

•WhentheprojectoristurnedonwiththeoptionalwirelessLANunitinserted,theindicatorwilllightupblueandthegreenLED

ontheUSBWirelessLANUnitashestoshowthattheUSBWirelessLANUnitisworking.

•Yourcomputer’swirelessLANadapter(orunit)mustbecompliedwithWi-Fi(IEEE802.11b/g/n)standard.

Flow of Setting Wireless LAN

Step 1: Attach the USB Wireless LAN Unit to the projector.

Step 2:

฀Connect฀the฀computer฀to฀the฀projector฀via฀wired฀LAN.฀(→฀page฀123)

฀Use฀the฀computer’s฀browser฀to฀display฀the฀projector’s฀HTTP฀server.฀(→฀page฀45)

Step 3:

฀Use฀an฀HTTP฀server฀to฀set฀the฀wireless฀LAN.฀(→฀page฀48)

฀Access฀the฀HTTP฀server฀function฀to฀set฀[NETWORK฀SETTINGS]฀→฀[SETTINGS]฀→฀[WIRELESS]฀→

[EASY฀CONNECTION],฀[SIMPLE฀ACCESS฀POINT],฀[PROFILE1]฀or฀[PROFILE2].

NOTE:

•TousetheHTTPserverfunction,theprojectormustbeconnectedtoanetwork.

FirstusethewiredLANtoconnecttheprojectortoanetworkandthenusetheHTTPservertosetthewirelessLAN.

•AftersettingthewirelessLANbyusingtheHTTPserver,set[NETWORKSETTINGS]→[SETTINGS]→[WIRED]→[DISABLE]

When฀switching฀to฀set฀on฀the฀projector฀after฀connecting฀to฀the฀wireless฀LAN:

Use฀the฀menu฀to฀set฀the฀wireless฀LAN฀connection฀for฀the฀projector.฀

(→฀page฀

107)

Select฀[DISABLE],฀[EASY฀CONNECTION]฀,฀[PROFILE1]฀or฀[PROFILE2]฀you฀set฀from฀the฀HTTP฀server.

Attaching the USB Wireless LAN Unit

NOTE:

•TheUSBWirelessLANUnitmustbeinsertedintotheUSBWirelessLANUnitportinthecorrectdirection.Itcannotbeinserted

inthereversedirection.IftheUSBWirelessLANUnitisinsertedinthereversedirectionwithexcessiveforceapplied,theUSB

portmaybreak.

•BeforetouchingtheUSBWirelessLANUnit,touchametallicobject(suchasadoorknoboraluminumwindowframe)todischarge

thestaticelectricityfromyourbody.

•AlwaysinsertorremovetheUSBWirelessLANunitwhenthemainpoweristurnedoff.Failuretodosomaycauseprojector

malfunctionordamagetotheUSBwirelessLANunit.Iftheprojectorwillnotworkcorrectly,turnofftheprojector,disconnect

thepowercord,andthenconnectitagain.

•DonotinsertotherUSBdevicesintotheUSBWirelessLANunitport.DonotinserttheUSBWirelessLANunitintotheUSB-B

port(TypeB).

125

6. Installation and Connections

Prepare฀a฀Phillips฀screw฀driver฀beforehand.

1.฀Press฀the฀POWER฀button฀to฀turn฀off฀the฀projector฀and฀set฀it฀

into฀standby฀condition,฀and฀disconnect฀the฀power฀cord.

2. Remove the USB (LAN) port cover.

Loosen the screw securing the port cover.

฀•฀The฀screw฀is฀not฀removable.฀

3.฀Slowly฀insert฀the฀USB฀Wireless฀LAN฀Unit฀into฀the฀USB฀(LAN)฀

port.

Remove the cap from the USB Wireless LAN Unit, and then insert

it with the surface (side of indicator) facing outward. Keep the cap

for later use.

NOTE:DonotforcetoinserttheUSBWirelessLANUnit.

4.฀Put฀the฀USB฀(LAN)฀port฀cover฀back฀into฀place.

฀Insert฀the฀catch฀of฀the฀USB฀(LAN)฀port฀cover฀into฀the฀groove฀of฀the฀

projector cabinet, and then tighten the screw to secure the port

cover.

To฀remove฀the฀USB฀Wireless฀LAN฀Unit,฀disconnect฀the฀power฀cord฀

and฀use฀the฀above฀procedure.

NOTE:

•ThegreenLEDontheUSBWirelessLANUnitashestoshowthatWireless

LANUnitisworking.IftheUSBWirelessLANUnitisincorrectlyattached,

theblueLEDwillnotash.

•DonotpressthebuttonontheUSBWirelessLANUnit.Thebuttonwillnot

workwiththismodel.

126

6. Installation and Connections

Example฀of฀wireless฀LAN฀connection

(Network฀Type฀→฀Infrastructure)

PC with wireless

LAN card inserted

PC with built-in wireless

LAN function

Wired LAN

Wireless access point

USB Wireless LAN Unit

To฀enable฀direct฀communication฀(i.e.,฀peer-to-peer)฀between฀personal฀computers฀and฀projectors,฀you฀need฀to฀

select฀the฀Ad฀Hoc฀mode.

Use฀the฀HTTP฀server฀function฀to฀make฀the฀settings.฀(→฀page฀45)

PC with wireless

LAN card inserted

PC with built-in wireless

LAN function

Use฀the฀HTTP฀server฀function฀to฀make฀the฀settings.฀(→฀page฀45)

Example฀of฀wireless฀LAN฀connection฀(Network฀Type฀→฀Ad฀Hoc)

USB Wireless LAN Unit

127

This฀section฀describes฀the฀simple฀maintenance฀procedures฀you฀should฀follow฀to฀clean฀the฀lens,฀the฀cabinet,฀and฀to฀

replace฀the฀lamp.

❶ Cleaning the Lens

•฀Turn฀off฀the฀projector฀before฀cleaning.

•฀The฀projector฀has฀a฀plastic฀lens.฀Use฀a฀commercially฀available฀plastic฀lens฀cleaner.

•฀Do฀not฀scratch฀or฀mar฀the฀lens฀surface฀as฀a฀plastic฀lens฀is฀easily฀scratched.

•฀Never฀use฀alcohol฀or฀glass฀lens฀cleaner฀as฀doing฀so฀will฀cause฀damage฀to฀the฀plastic฀lens฀surface.

❷ Cleaning the Cabinet

Turn฀off฀the฀projector,฀and฀unplug฀the฀projector฀before฀cleaning.

•฀Use฀a฀dry฀soft฀cloth฀to฀wipe฀dust฀off฀the฀cabinet.

฀If฀heavily฀soiled,฀use฀a฀mild฀detergent.฀

•฀Never฀use฀strong฀detergents฀or฀solvents฀such฀as฀alcohol฀or฀thinner.฀

•฀When฀cleaning฀the฀vents฀or฀the฀speaker฀using฀a฀vacuum฀cleaner,฀do฀not฀force฀the฀brush฀of฀the฀vacuum฀cleaner฀

into฀the฀slits฀of฀the฀cabinet.

Vacuum the dust off the vents.

•฀Clogged฀vents฀may฀cause฀a฀rise฀in฀฀the฀internal฀temperature฀of฀the฀projector,฀resulting฀in฀malfunction.

•฀Do฀not฀scratch฀or฀hit฀the฀cabinet฀with฀your฀ngers฀or฀any฀hard฀objects

•฀Contact฀your฀dealer฀for฀cleaning฀the฀inside฀of฀the฀projector.

NOTE:Donotapplyvolatileagentsuchasinsecticideonthecabinet,thelens,orthescreen.Donotleavearubberorvinylproduct

inprolongedcontactwithit.Otherwisethesurfacenishwillbedeterioratedorthecoatingmaybestrippedoff.

7. Maintenance

128

7. Maintenance

❸ Replacing the Lamp

When฀the฀lamp฀reaches฀the฀end฀of฀its฀life,฀the฀LAMP฀indicator฀in฀the฀cabinet฀will฀blink฀red฀and฀the฀message฀“THE฀LAMP฀

HAS฀REACHED฀THE฀END฀OF฀ITS฀USABLE฀LIFE.฀PLEASE฀฀REPLACE฀THE฀LAMP.”฀will฀appear฀(*).฀Even฀though฀the฀

lamp฀may฀still฀be฀working,฀replace฀the฀lamp฀to฀maintain฀the฀optimal฀projector฀performance.฀After฀replacing฀the฀lamp,฀

be฀sure฀to฀clear฀the฀lamp฀hour฀meter.฀(→฀page฀

113)

WARNING

•฀Do฀not฀spray฀ammable฀gas฀to฀get฀rid฀of฀dust฀and฀dirt฀that฀accumulate฀in฀the฀lens.฀Doing฀so฀could฀cause฀a฀

re.

CAUTION

•฀DO฀NOT฀TOUCH฀THE฀LAMP฀immediately฀after฀it฀has฀been฀used.฀It฀will฀be฀extremely฀hot.฀Turn฀the฀projector฀

off฀and฀then฀disconnect฀the฀power฀cord.฀Allow฀at฀least฀one฀hour฀for฀the฀lamp฀to฀cool฀before฀handling.

•฀Use฀the฀specied฀lamp฀for฀safety฀and฀performance.฀

฀To฀order฀the฀replacement฀lamp,฀specify฀your฀lamp฀type.

฀Replacement฀lamp:

฀NP30LP:฀M352WS/M332XS

฀NP28LP:฀M302WS

•฀DO฀NOT฀REMOVE฀ANY฀SCREWS฀except฀one฀lamp฀cover฀screw฀and฀three฀lamp฀housing฀screws.฀You฀could฀receive฀

an฀electric฀shock.

•฀Do฀not฀break฀the฀glass฀on฀the฀lamp฀housing.

฀Keep฀nger฀prints฀off฀the฀glass฀surface฀on฀the฀lamp฀housing.฀Leaving฀nger฀prints฀on฀the฀glass฀surface฀might฀cause฀

an฀unwanted฀shadow฀and฀poor฀picture฀quality.

•฀The฀projector฀will฀turn฀off฀and฀go฀into฀standby฀mode฀when฀you฀continue฀to฀use฀the฀projector฀for฀another฀100฀hours฀

after฀the฀lamp฀has฀reached฀the฀end฀of฀its฀life.฀If฀this฀happens,฀be฀sure฀to฀replace฀the฀lamp.฀If฀you฀continue฀to฀use฀

the฀lamp฀after฀the฀lamp฀reaches฀the฀end฀of฀its฀life,฀the฀lamp฀bulb฀may฀shatter,฀and฀pieces฀of฀glass฀may฀be฀scattered฀

in฀the฀lamp฀case.฀Do฀not฀touch฀them฀as฀the฀pieces฀of฀glass฀may฀cause฀injury.฀If฀this฀happens,฀contact฀your฀NEC฀

dealer฀for฀lamp฀replacement.

*NOTE:Thismessagewillbedisplayedunderthefollowingconditions:

•foroneminuteaftertheprojectorhasbeenpoweredon

•whenthe

(POWER)buttonontheprojectorcabinetortheSTANDBYbuttonontheremotecontrolispressed

Toturnoffthemessage,pressanybuttonontheprojectorcabinetortheremotecontrol.

Optional฀lamp฀and฀tools฀needed฀for฀replacement:

•฀Phillips฀screwdriver฀(plus-head)

•฀Replacement฀lamp

Flow of Replacing the Lamp

Step 1. Replace the lamp

Step 2.

฀Clear฀the฀lamp฀usage฀hours฀(→฀page฀113)

129

7. Maintenance

2.฀Remove฀the฀lamp฀housing.

(1)฀Loosen฀the฀three฀screws฀securing฀the฀lamp฀housing฀until฀the฀phillips฀screwdriver฀goes฀into฀a฀freewheeling฀condi-

tion.

฀•฀The฀three฀screws฀are฀not฀removable.

฀•฀฀There฀is฀an฀interlock฀on฀this฀case฀to฀prevent฀the฀risk฀of฀electrical฀shock.฀Do฀not฀attempt฀to฀circumvent฀this฀

interlock.

(2)฀Remove฀the฀lamp฀housing฀by฀holding฀it.

CAUTION:

Make฀sure฀that฀the฀lamp฀housing฀is฀cool฀enough฀to฀before฀removing฀it.

Interlock

To replace the lamp:

1. Remove the lamp cover.

(1)฀Loosen฀the฀lamp฀cover฀screw

฀•฀The฀lamp฀cover฀screw฀is฀not฀removable.

(2)฀Push฀and฀slide฀the฀lamp฀cover฀off.

130

7. Maintenance

This completes the lamp replacement.

Go on to the clearing lamp hour meters.

NOTE:Whenyoucontinuetousetheprojectorforanother100hoursafterthelamphasreachedtheendofitslife,theprojector

cannotturnonandthemenuisnotdisplayed.

Ifthishappens,presstheHELPbuttonontheremotecontrolfor10secondstoresetthelampclockbacktozero.

Whenthelamptimeclockisresettozero,theLAMPindicatorgoesout.



To clear the lamp usage hours:

1.฀Place฀the฀projector฀where฀you฀use฀it.

2.฀Plug฀the฀power฀cord฀into฀the฀wall฀outlet,฀and฀then฀turn฀on฀the฀projector.

3.฀Clear฀the฀lamp฀usage฀hours.

From the menu, select [RESET] → [CLEAR LAMP HOURS] and reset the lamp usage hours.

4. Reattach the lamp cover.

(1)฀Slide฀the฀lamp฀cover฀back฀until฀it฀snaps฀into฀place.

(2)฀Tighten฀the฀screw฀to฀secure฀the฀lamp฀cover.

฀•฀Be฀sure฀to฀tighten฀the฀screw.

3.฀Install฀a฀new฀lamp฀housing.

(1)฀Insert฀a฀new฀lamp฀housing฀until฀the฀lamp฀housing฀is฀plugged฀into฀the฀socket.฀

(2)฀Push฀the฀top฀center฀of฀the฀lamp฀housing฀to฀secure฀it.

(3)฀Secure฀it฀in฀place฀with฀the฀three฀screws.

฀•฀Be฀sure฀to฀tighten฀the฀screws.

131

8. Appendix

❶ Troubleshooting

This฀section฀helps฀you฀resolve฀problems฀you฀may฀encounter฀while฀setting฀up฀or฀using฀the฀projector.

Indicator Messages

Power Indicator

Indicator Condition Projector฀ConditionNote

Off The main power is off –

Blinking light Blue

0.5 sec On,

0.5 sec Off

The projector is getting ready to turn on. Wait for a moment.

2.5 sec On,

0.5 sec Off

Off Timer is enabled. –

Steady light Blue The projector is turned on. –

Orange

The projector is [NETWORK STANDBY] mode or

sleep mode*.

–

Red [NORMAL] is selected for [STANDBY MODE] –

Status Indicator

Indicator Condition Projector฀ConditionNote

Off

Power on or Standby ([NORMAL] or [NETWORK

STANDBY] for [STANDBY MODE])

–

Blinking light Red

1 cycle (0.5 sec

On, 2.5 sec Off)

Lamp cover error or lamp housing error Replace the lamp cover or lamp housing correctly.

2 cycle (0.5 sec

On, 0.5 sec Off)

Temperature error The projector is overheated. Move the projector to

a cooler location.

3 cycle (0.5 sec

On, 0.5 sec Off)

Power error Power unit is not working properly. Contact your

dealer.

4 cycle (0.5 sec

On, 0.5 sec Off)

Fan error Fans will not work correctly.

6 cycle (0.5 sec

On, 0.5 sec Off)

Lamp error Lamp fails to light. Wait a full minute and then turn

on again.

Orange 1 cycle (0.5 sec

On, 2.5 sec Off)

Network conﬂict

Both the built-in wired LAN and the wireless LAN cannot

be connected to the same network at the same time.

To use both built-in wired LAN and wireless LAN at the

same time, connect them to different networks.

Green Re-firing the lamp (The projector is cooling

down.)

The projector is re-ﬁring.

Wait for a moment.

Steady฀light

Green

The projector is in [NORMAL] mode or sleep

mode.

–

Orange

CONTROL PANEL LOCK is on. You have pressed cabinet button when Control

Panel Lock is on.

CONTROL ID error Remote control ID and projector ID are not

matched.

Lamp Indicator

Indicator Condition Projector฀ConditionNote

Off Normal –

Blinking light Red

Lamp has reached its end of life. Lamp replace-

ment message will be displayed.

Replace the lamp.

Steady light Red Lamp has been used beyond its limit. The projector

will not turn on until the lamp is replaced.

Replace the lamp.

Green

[ECO MODE] is set to [AUTO ECO], [NORMAL]

or [ECO]

–

*฀For฀more฀information฀on฀"sleep฀mode",฀see฀page฀

119.

Over-Temperature฀Protection

If฀the฀temperature฀inside฀the฀projector฀rises฀too฀high,฀the฀over-temperature฀protector฀will฀automatically฀turn฀off฀the฀lamp฀

with฀the฀STATUS฀indicator฀blinking฀(2-cycle฀On฀and฀Off.)

Should฀this฀happen,฀do฀the฀following:

•฀Unplug฀the฀power฀cord฀after฀the฀cooling฀fans฀stop.

•฀Move฀the฀projector฀to฀a฀cooler฀location฀if฀the฀room฀where฀you฀are฀presenting฀is฀particularly฀too฀warm.

•฀Clean฀the฀vents฀if฀they฀are฀clogged฀with฀dust.

•฀Wait฀about฀60฀minutes฀until฀the฀inside฀of฀the฀projector฀becomes฀cool฀enough.

132

8. Appendix

Common Problems & Solutions

(→฀“Power/Status/Lamp฀Indicator”฀on฀page฀

131.)

ProblemCheck฀These฀Items

Does not turn on

or shut down

•Checkthatthepowercordispluggedinandthatthepowerbuttonontheprojectorcabinetortheremotecontrol

is on. (→ pages

16, 17)

•Ensurethatthelampcoverisinstalledcorrectly.(→ page 130)

•Checktoseeiftheprojectorhasoverheated.Ifthereisinsufcientventilationaroundtheprojectororiftheroom

where you are presenting is particularly warm, move the projector to a cooler location.

•Checktoseeifyoucontinuetousetheprojectorforanother100hoursafterthelamphasreachedtheendofits

life. If so, replace the lamp. After replacing the lamp, reset the lamp hours used. (→ page 113)

•Thelampmayfailtolight.Waitafullminuteandthenturnonthepoweragain.

•Set[FANMODE]to[HIGHALTITUDE]whenusingtheprojectorataltitudesapproximately5500feet/1700meters

or higher. Using the projector at altitudes approximately 5500 feet/1700 meters or higher without setting to [HIGH

ALTITUDE] can cause the projector to overheat and the projector could shut down. If this happens, wait a couple

minutes and turn on the projector. (→ page

99)

If you turn on the projector immediately after the lamp is turned off, the fans run without displaying an image for

some time and then the projector will display the image. Wait for a moment.

Will turn off

•Ensurethatthe[OFFTIMER]or[AUTOPOWEROFF]isoff.(→ page

94, 102)

No picture

•Usetheinputselectbuttonontheremotecontroltoselectyoursource(COMPUTER,HDMI1,HDMI2,VIDEO,

USB-A, LAN, or USB-B). (→ page

19) If there is still no picture, press the button again.

•Ensureyourcablesareconnectedproperly.

•Usemenustoadjustthebrightnessandcontrast.(→ page 86)

•Ensurethatthelenscapisremoved.(→ page 5,17)

•Resetthesettingsoradjustmentstofactorypresetlevelsusingthe[RESET]intheMenu.(→ page 113)

•EnteryourregisteredkeywordiftheSecurityfunctionisenabled.(→ page 33)

•BesuretoconnecttheprojectorandnotebookPCwhiletheprojectorisinstandbymodeandbeforeturningon

the power to the notebook PC.

In most cases the output signal from the notebook PC is not turned on unless connected to the projector before

being powered up.

* If the screen goes blank while using your remote control, it may be the result of the computer’s screen-saver

or power management software.

•Seealsothenext page.

Picture suddenly be-

comes dark

•CheckiftheprojectorisintheForcedECOmodebecauseoftoohighambienttemperature.Ifthisisthecase,

lower the internal temperature of the projector by selecting [HIGH] for [FAN MODE]. (→ page

99)

Color tone or hue is un-

usual

•Checkifanappropriatecolorisselectedin[WALLCOLOR].Ifso,selectanappropriateoption.(→ page

93)

•Adjust[HUE]in[PICTURE].(→ page 86)

Image isn’t square to the

screen

•Repositiontheprojectortoimproveitsangletothescreen.(→ page

20)

•UsetheKeystonecorrectionfunctiontocorrectthetrapezoiddistortion.(→ page 24)

Picture is blurred

•Adjustthefocus.(→ page

23)

•Repositiontheprojectortoimproveitsangletothescreen.(→ page 20)

•Ensurethatthedistancebetweentheprojectorandscreeniswithintheadjustmentrangeofthelens.

(→ page 114)

•Condensationmayformonthelensiftheprojectoriscold,broughtintoawarmplaceandisthenturnedon.

Should this happen, let the projector stand until there is no condensation on the lens.

Fl ic ke r ap pe ar s on

screen

•

Set [FAN MODE] to other than [HIGH ALTITUDE] mode when using the projector at altitudes approximately 5500 feet/1700

meters or lower. Using the projector at altitudes less than approximately 5500 feet/1700 meters and setting to [HIGH ALTI-

TUDE] can cause the lamp to overcool, causing the image to ﬂicker. Switch [FAN MODE] to [AUTO]. (→ page

99)

Image is scrolling ver-

tically, horizontally or

both

•Checkthecomputer’sresolutionandfrequency.Makesurethattheresolutionyouaretryingtodisplayissupported

by the projector. (→ page

138)

•AdjustthecomputerimagemanuallywiththeHorizontal/Verticalinthe[IMAGEOPTIONS].(→ page 88)

Remote control does

not work

•Installnewbatteries.(→ page

11)

•Makesuretherearenoobstaclesbetweenyouandtheprojector.

•Standwithin22feet(7m)oftheprojector.(→ page

11)

Indicator is lit or blink-

ing

•SeethePOWER/STATUS/LAMPIndicator.(→ page

131)

Cross color in RGB

mode

•PresstheAUTOADJ.buttonontheprojectorcabinetortheremotecontrol.(→ page

26)

•Adjustthecomputerimagemanuallywith[CLOCK]/[PHASE]in[IMAGEOPTIONS]inthemenu.(→ page 87)

For฀more฀information฀contact฀your฀dealer.

133

8. Appendix

If there is no picture, or the picture is not displayed correctly.

•฀Power฀on฀process฀for฀the฀projector฀and฀the฀PC.

฀Be฀sure฀to฀connect฀the฀projector฀and฀notebook฀PC฀while฀the฀projector฀is฀in฀standby฀mode฀and฀before฀turning฀on฀

the฀power฀to฀the฀notebook฀PC.

฀In฀most฀cases฀the฀output฀signal฀from฀the฀notebook฀PC฀is฀not฀turned฀on฀unless฀connected฀to฀the฀projector฀before฀

being฀powered฀up.

NOTE:Youcancheckthehorizontalfrequencyofthecurrentsignalintheprojector’smenuunderInformation.Ifitreads“0kHz”,

thismeansthereisnosignalbeingoutputfromthecomputer.(→page

110orgotonextstep)

•฀Enabling฀the฀computer’s฀external฀display.

฀Displaying฀an฀image฀on฀the฀notebook฀PC’s฀screen฀does฀not฀necessarily฀mean฀it฀outputs฀a฀signal฀to฀the฀projector.฀

When฀using฀a฀PC฀compatible฀laptop,฀a฀combination฀of฀function฀keys฀will฀enable/disable฀the฀external฀display.฀Usu-

ally,฀the฀combination฀of฀the฀“Fn”฀key฀along฀with฀one฀of฀the฀12฀function฀keys฀gets฀the฀external฀display฀to฀come฀on฀

or฀off.฀For฀example,฀NEC฀laptops฀use฀Fn฀+฀F3,฀while฀Dell฀laptops฀use฀Fn฀+฀F8฀key฀combinations฀to฀toggle฀through฀

external฀display฀selections.

•฀Non-standard฀signal฀output฀from฀the฀computer

฀If฀the฀output฀signal฀from฀a฀notebook฀PC฀is฀not฀an฀industry฀standard,฀the฀projected฀image฀may฀not฀be฀displayed฀

correctly.฀Should฀this฀happen,฀deactivate฀the฀notebook฀PC’s฀LCD฀screen฀when฀the฀projector฀display฀is฀in฀use.฀Each฀

notebook฀PC฀has฀a฀different฀way฀of฀deactivate/reactivate฀the฀local฀LCD฀screens฀as฀described฀in฀the฀previous฀step.฀

Refer฀to฀your฀computer’s฀documentation฀for฀detailed฀information.

•฀Image฀displayed฀is฀incorrect฀when฀using฀a฀Mac

฀When฀using฀a฀Mac฀with฀the฀projector,฀set฀the฀DIPswitch฀of฀the฀Mac฀adapter฀(not฀supplied฀with฀the฀projector)฀ac-

cording฀to฀your฀resolution.฀After฀setting,฀restart฀your฀Mac฀for฀the฀changes฀to฀take฀affect.

฀For฀setting฀display฀modes฀other฀than฀those฀supported฀by฀your฀Mac฀and฀the฀projector,฀changing฀the฀DIP฀switch฀on฀

a฀Mac฀adapter฀may฀bounce฀an฀image฀slightly฀or฀may฀display฀nothing.฀Should฀this฀happen,฀set฀the฀DIP฀switch฀to฀

the฀13"฀xed฀mode฀and฀then฀restart฀your฀Mac.฀After฀that,฀restore฀the฀DIP฀switches฀to฀a฀displayable฀mode฀and฀then฀

restart฀the฀Mac฀again.

NOTE:AVideoAdaptercablemanufacturedbyAppleInc.isneededforaMacBookwhichdoesnothaveaminiD-Sub15-pin

connector.

•฀Mirroring฀on฀a฀MacBook

*฀When฀using฀the฀projector฀with฀a฀MacBook,฀output฀may฀not฀be฀set฀to฀1024฀×฀768฀unless฀“mirroring”฀is฀off฀on฀your฀

MacBook.฀Refer฀to฀owner’s฀manual฀supplied฀with฀your฀Mac฀computer฀for฀mirroring.

•฀Folders฀or฀icons฀are฀hidden฀on฀the฀Mac฀screen

฀Folders฀or฀icons฀may฀not฀be฀seen฀on฀the฀screen.฀Should฀this฀happen,฀select฀[View]฀→฀[Arrange]฀from฀the฀Apple฀

menu฀and฀arrange฀icons.

134

8. Appendix

❷ Speciﬁcations

This฀section฀provides฀technical฀information฀about฀projector’s฀performance.

[M352WS/M302WS/M332XS]

Optical

Model฀NumberNP-M352WSNP-M302WSNP-M332XS

Projection฀SystemSingle฀DLP®฀chip฀(0.65",฀aspect฀16:10)Single฀DLP®฀chip฀(0.55",฀aspect฀

4:3)

Resolution*

1280฀×฀800฀pixels฀(WXGA)1024฀×฀768฀pixels฀(XGA)

LensDigital฀zoom฀and฀manual฀focus

Digital฀Zoom฀Ratio฀=฀1.2

F2.4/฀f=6.5฀mm

Lamp270฀W฀AC฀

(219฀W฀in฀NORMAL)

(162฀W฀in฀ECO)

225฀W฀AC฀

(171฀W฀in฀NORMAL)

(135฀W฀in฀ECO)

270฀W฀AC฀

(219฀W฀in฀NORMAL)

(162฀W฀in฀ECO)

Light฀Output*

3500 lumens 3000 lumens 3300 lumens

NORMAL:฀81%NORMAL:฀76%NORMAL:฀81%

ECO:฀60%*

Contrast฀Ratio*

(full฀white:฀full฀black)

10000:1฀with฀DYNAMIC฀CONTRAST฀ON

Image฀Size฀(Diagonal)60–150฀inches/1.52฀m–3.81฀m฀(16:10)60–150฀inches/1.52฀m–3.81฀m฀

(4:3)

Projection฀Distance

(Min.–Max.)

22.2–58.3฀inches/0.57–1.48฀m26.6–69.2฀inches/0.68–1.76฀m฀

Projection฀Angle40.7°–40.9°40.7°–40.8°

*1฀Effective฀pixels฀are฀more฀than฀99.99%.

*2฀This฀is฀the฀light฀output฀value฀(lumens)฀when฀the฀[PRESET]฀mode฀is฀set฀to฀[HIGH-BRIGHT].฀If฀any฀other฀mode฀is฀selected฀as฀the฀

[PRESET]฀mode,฀the฀light฀output฀value฀may฀drop฀slightly.

*3฀Compliance฀with฀ISO21118-2005

*4฀The฀maximum฀power฀becomes฀equivalent฀to฀power฀in฀ECO฀(ECO฀MODE).

Electrical

Model฀NumberNP-M352WSNP-M302WSNP-M332XS

Inputs

1฀×฀RGB/Component฀(D-Sub฀15฀P),฀2฀×฀HDMI฀Type฀A฀(19P,฀HDMI

฀Connector)฀HDCP฀supported*

1฀×฀Video฀(RCA),฀1฀×฀(L/R)฀RCA฀Audio,฀1฀×฀Stereo฀Mini฀Audio

Outputs1฀×฀RGB฀(D-Sub฀15P),฀1฀×฀Stereo฀Mini฀Audio

PC฀Control1฀×฀PC฀Control฀Port฀(D-Sub฀9P)

Wired฀LAN฀Port1฀×฀RJ-45฀(10BASE-T/100BASE-TX)

Wireless฀LAN฀Port฀

(Optional)

IEEE฀802.11฀b/g/n฀(optional฀USB฀Wireless฀LAN฀Unit฀฀required)

USB฀Port1฀×฀Type฀A,฀1฀×฀Type฀B

MIC฀Input1฀×฀Monaural฀Mini฀Audio

Color฀Reproduction10-bit฀signal฀processing฀(1.07฀billion฀colors)฀(USB-A,฀LAN:฀16.7฀million฀colors)

*5฀HDMI

฀(Deep฀Color,฀Lip฀Sync)฀with฀HDCP

฀What฀is฀HDCP/HDCP฀technology?

฀HDCP฀is฀an฀acronym฀for฀High-bandwidth฀Digital฀Content฀Protection.฀High฀bandwidth฀Digital฀Content฀Protection฀(HDCP)฀is฀a฀system฀

for฀preventing฀illegal฀copying฀of฀video฀data฀sent฀over฀a฀High-Denition฀Multimedia฀Interface฀(HDMI).

฀If฀you฀are฀unable฀to฀view฀material฀via฀the฀HDMI฀input,฀this฀does฀not฀necessarily฀mean฀the฀projector฀is฀not฀functioning฀properly.฀With฀

the฀implementation฀of฀HDCP,฀there฀may฀be฀cases฀in฀which฀certain฀content฀is฀protected฀with฀HDCP฀and฀might฀not฀be฀displayed฀

due฀to฀the฀decision/intention฀of฀the฀HDCP฀community฀(Digital฀Content฀Protection,฀LLC).

฀Video:฀Deep฀Color;฀8/10/12-bit,฀LipSync

฀Audio:฀LPCM;฀up฀to฀2฀ch,฀sample฀rate฀32/44.1/48฀KHz,฀sample฀bit;฀16/20/24-bit

*6฀An฀image฀with฀higher฀or฀lower฀resolution฀than฀the฀projector’s฀native฀resolution฀(M332XS:฀1024฀×฀768฀/฀M352WS/M302WS:฀1280฀

×฀800)฀will฀be฀displayed฀with฀Advanced฀AccuBlend.

135

8. Appendix

Model฀NumberNP-M352WSNP-M302WSNP-M332XS

Compatible฀Signals*

Analog:฀VGA/SVGA/XGA/WXGA/Quad-VGA/SXGA/SXGA+/WXGA+/WXGA++/UXGA/WSXGA+/HD/

Full฀HD/WUXGA/Mac13"/Mac16"/Mac฀19"/Mac฀21"/Mac฀23"฀

Component:฀480i/480p/720p/1080i฀(60Hz),฀576i/576p/1080i฀(50Hz),฀DVD฀Progressive฀(50/60Hz)

Digital:฀VGA/SVGA/XGA/WXGA/Quad-VGA/SXGA/SXGA+/WXGA+/WXGA++/WSXGA+/HDTV฀(1080p)/

HDTV฀(1080i)/HDTV฀(720p)/HDTV฀(480p)

3D:฀For฀PC฀XGA/1280฀×฀720/WXGA,฀For฀Video฀SDTV฀(480i),฀For฀HDMI-1.4a฀720p฀(Frame฀Packing)/

1080p฀(Frame฀Packing)/1080i฀(Side฀by฀Side฀(Half))/720p฀(Top฀and฀Bottom)/1080p฀(Top฀and฀Bottom)

Horizontal฀Resolution540฀TV฀lines:฀NTSC/NTSC4.43/PAL/PAL-M/PAL-N/PAL60

300฀TV฀lines:฀SECAM

Scan฀RateHorizontal:฀15฀kHz฀to฀100฀kHz฀(RGB:฀24฀kHz฀or฀over)

Vertical:฀50฀Hz฀to฀120฀Hz฀(HDMI:฀50฀Hz฀to฀85฀Hz)

Sync฀CompatibilitySeparate฀Sync

Built-in฀Speaker20฀W฀(monaural)

Power฀Requirement100–240V฀AC,฀50/60Hz

Input฀Current3.9-1.6A3.3-1.4A3.9-1.6A

Power฀

Consump-

tion

(Typical฀

value)

ECO฀

MODE฀

OFF

354W฀(100-130V)

335W฀(200-240V)

300W฀(100-130V)

286W฀(200-240V)

354W฀(100-130V)

335W฀(200-240V)

NORMAL292W฀(100-130V)

278W฀(200-240V)

233W฀(100-130V)

224W฀(200-240V)

292W฀(100-130V)

278W฀(200-240V)

ECO258W฀(100-130V)

246W฀(200-240V)

210W฀(100-130V)

202W฀(200-240V)

258W฀(100-130V)

246W฀(200-240V)

STANDBY฀

(

NETWORK฀

STANDBY

)

2.5฀W(100-130V)

2.9฀W฀(200-240V)

STANDBY฀

(NORMAL)

0.2W฀(100-130V)

0.38W฀(200-130V)

Mechanical

Model฀NumberNP-M352WSNP-M302WSNP-M332XS

Installation

Orientation

Desktop/Front,฀Desktop/Rear,฀Ceiling/Front,฀Ceiling/Rear

Dimensions14.5"฀(W)฀×฀5.3"฀(H)฀×฀11.5"฀(D)฀/368฀mm฀(W)฀×฀134฀mm฀(H)฀×฀291฀mm฀(D)

14.5"฀(W)฀×฀3.9"฀(H)฀×฀11.3"฀(D)฀/368฀mm฀(W)฀×฀98฀mm฀(H)฀×฀286฀mm฀(D)฀(not฀including฀protrusions)

WeightM352W/M332XS:฀8.2฀lbs/3.7฀kg

M302WS:฀8.0฀lbs/3.6฀kg

Environmental฀

Considerations

Operational฀Temperatures฀:฀41°฀to฀104°F฀(5°฀to฀40°C),฀

(ECO฀mode฀selected฀automatically฀at฀95°F฀to฀104°F/35°C฀to฀40°C)฀

20%฀to฀80%฀humidity฀(non-condensing)฀

Storage฀Temperatures฀:฀14°฀to฀122°F฀(-10°฀to฀50°C),฀

20%฀to฀80%฀humidity฀(non-condensing)

Operating฀altitude:฀0฀to฀2400m/8000฀feet฀(Set฀[FAN฀MODE]฀to฀[HIGH฀ALUTITUDE]฀when฀using฀the฀pro-

jector฀at฀altitudes฀approximately฀1700฀meters฀/5500฀feet)

RegulationsUL/C-UL฀Approved฀(UL฀60950-1,฀CSA฀60950-1)

Meets฀DOC฀Canada฀Class฀B฀requirements

Meets฀FCC฀Class฀B฀requirements

Meets฀AS/NZS฀CISPR.22฀Class฀B

Meets฀EMC฀Directive฀(EN55022,฀EN55024,฀EN61000-3-2,฀EN61000-3-3)

Meets฀Low฀Voltage฀Directive฀(EN60950-1,฀TÜV฀GS฀Approved)

For฀additional฀information฀visit:

US฀:฀http://www.necdisplay.com/

Europe฀:฀http://www.nec-display-solutions.com/

Global฀:฀http://www.nec-display.com/global/index.html

For฀information฀on฀our฀optional฀accessories,฀visit฀our฀website฀or฀see฀our฀brochure.

The฀specications฀are฀subject฀to฀change฀without฀notice.

136

8. Appendix

368 (14.5)

286(11.3)

134 (5.3)

130 (5.2)

150 (5.9)

200 (7.9)

175 (6.9)

98 (3.9)

80 (3.2)

108 (4.3)

291 (11.5)

❸ Cabinet Dimensions

[M352WS/M302WS/M332XS]

Lens center

Holes for ceiling mount

Unit:฀mm฀(inch)

137

8. Appendix

Attaching the Optional Cable Cover (NP05CV)

An฀optional฀cable฀cover฀(NP05CV)฀is฀available฀for฀hiding฀cables.

CAUTION:

•฀Be฀sure฀to฀tighten฀the฀screws฀after฀attaching฀the฀cable฀cover.฀Failure฀to฀do฀so฀may฀cause฀the฀cable฀cover฀to฀come฀

off฀and฀fall,฀resulting฀in฀injury฀or฀damage฀to฀the฀cable฀cover.

•฀Do฀not฀put฀bundled฀cables฀in฀the฀cable฀cover.฀Failure฀to฀do฀so฀may฀damage฀the฀power฀cord,฀resulting฀a฀re.

•฀Do฀not฀force฀excessive฀pressure฀to฀the฀cable฀cover.฀Doing฀so฀may฀cause฀damage฀to฀the฀cable฀cover,฀resulting฀

in฀injury.

Attaching฀the฀cable฀cover

Attach฀the฀cable฀cover฀after฀installing฀the฀projector฀on฀the฀ceiling฀and฀connecting฀cables.

Tool฀needed฀for฀attaching:

•฀Phillips฀screwdriver฀(plus-head)

1.฀Align฀two฀tabs฀on฀the฀outside฀of฀the฀cable฀cover฀with฀grooves฀of฀the฀projector฀and฀push฀the฀top฀end.

•฀At฀the฀same฀time฀two฀tabs฀on฀the฀inside฀of฀the฀cable฀cover฀will฀be฀engaged฀in฀the฀responding฀grooves฀of฀the฀

projector.

NOTE:

•Becarefulnottogetcablescaughtinbetweenthecablecoverandtheprojector.

2.฀Tighten฀the฀cable฀cover฀screws.

•฀Be฀sure฀to฀tighten฀the฀screws.

Removing฀the฀cable฀cover

1.฀Loosen฀the฀cable฀cover฀screws฀until฀the฀Phillips฀screwdriver฀goes฀into฀a฀freewheeling฀condition

2. Remove the cable cover.

Push up the cable cover slightly and rotate it to release.

138

8. Appendix

❹ Pin Assignments of D-Sub COMPUTER Input Connector

Mini D-Sub 15 Pin Connector

Signal฀Level

Video฀signal฀:฀0.7Vp-p฀(Analog)

Sync฀signal฀:฀TTL฀level

51423

11 12 13 14 15

6978

Pin No. RGB฀Signal฀(Analog)YCbCr฀Signal

1 RedCr

2 Green฀or฀Sync฀on฀GreenY

3 BlueCb

4Ground

5 Ground

Red฀GroundCr฀Ground

7Green฀GroundY฀Ground

8 Blue฀GroundCb฀Ground

9Hot฀plug

10 Sync฀Signal฀Ground

11 No฀Connection

12 Bi-directional฀DATA฀(SDA)

13 Horizontal฀Sync฀or฀Composite฀

Sync

14Vertical฀Sync

15 Data฀Clock

COMPUTER IN

NOTE:PinNos.12and15arerequiredforDDC/CI.



139

8. Appendix

❺ Compatible Input Signal List

Analog RGB

Signal

Resolution

(฀dots฀)

Aspect฀Ratio

Refresh฀Rate

(฀Hz฀)

VGA640 ×4804:360/72/75/85

SVGA800 ×6004:356/60/72/75/85

XGA1024 ×768*

4:360/70/75/85

WXGA1280 ×768*

15:960

1280 ×800 *

16:1060

1360×768*

16:960

1366×768*

16:960

Quad-VGA1280 ×9604:360/75

SXGA1280 ×10245:460/75

SXGA+1400× 1050 4:360

WXGA+1440 ×90016:1060

WXGA++1600×900*

16:960

UXGA1600× 1200 *

4:360

WSXGA+1680 ×1050 16:1060

HD1280 ×72016:960

Full฀HD1920 ×1080 16:960

WUXGA1920× 1200 *

16:1060

MAC฀13"640 ×4804:367

MAC฀16"832 ×6244:375

MAC฀19"1024×7684:375

MAC฀21"1152 ×8704:375

MAC฀23"1280 × 10245:465

Component

SignalFormatAspect฀Ratio

Refresh฀Rate

(฀Hz฀)

HDTV฀(1080p)1920×1080 16:950/60

HDTV฀(1080i)1920×1080 16:950/60

HDTV฀(720p)1280 ×72016:950/60

SDTV฀(480p)720×4804:3/16:960

SDTV฀(576p)720×5764:3/16:950

SDTV฀(480i)720×4804:3/16:960

SDTV฀(576i)720×5764:3/16:950

Composite฀Video

SignalAspect฀Ratio

Refresh฀Rate

(฀Hz฀)

NTSC4:360

PAL4:350

PAL604:360

SECAM4:350

NOTE:

•Animagewithhigherorlowerresolutionthantheprojector’snativeresolution(M332XS:1024×768/M352WS/M302WS:1280

×800)willbedisplayedwithAdvancedAccuBlend.

•SynconGreenandCompositesyncsignalsarenotsupported.

•Signalsotherthanthosespeciedinthetableabovemaynotbedisplayedcorrectly.Ifthisshouldhappen,changetherefresh

rateorresolutiononyourPC.RefertoDisplayPropertieshelpsectionofyourPCforprocedures.

HDMI

Signal

Resolution

(฀dots฀)

Aspect฀Ratio

Refresh฀Rate

(฀Hz฀)

VGA640 ×4804:360

SVGA800 ×6004:360

XGA1024 ×768*

4:360

WXGA1280 ×768*

15:960

1280 ×800 *

16:1060

1366×76816:960

Quad-VGA1280 ×9604:360

SXGA1280 ×10245:460

SXGA+1400× 1050 4:360

WXGA+1440 ×90016:1060

WXGA++1600×90016:960

WSXGA+1680 ×1050 16:1060

HDTV฀(1080p)1920 ×1080 16:950/60

HDTV฀(1080i)1920× 1080 16:950/60

HDTV฀(720p)1280 ×72016:950/60

SDTV฀(480p)720 ×4804:3/16:960

SDTV฀(576p)720 ×5764:3/16:950

SDTV฀(480i)720฀

(1440)

×4804:3/16:960

SDTV฀(576i)720฀

(1440)

×5764:3/16:950

Signal

Resolution

(฀dots฀)

Aspect฀Ratio

Refresh฀Rate

(฀Hz฀)

For฀PC฀Signal

XGA1024 ×7684:360/120

HD1280 ×72016:960/120

WXGA1280 ×800 16:1060/120

HDTV฀(1080p)1920 ×1080 16:960

For฀Video฀Signal

SDTV฀(480i)720 ×4804:3/16:960

HDMI 3D

Signal

Resolution

(฀dots฀)

Aspect฀Ratio

Refresh฀Rate

(฀Hz฀)

Structure:฀Frame฀Packing

1080p1920×1080 16:923.98/24

720p1280 ×72016:950/59.94/60

Structure:฀Side฀by฀Side฀(Half)

1080i 1920× 1080 16:950/59.94/60

Structure:฀Top฀and฀Bottom

1080p1920×1080 16:923.98/24

720p1280 ×72016:950/59.94/60

*1฀Native฀resolution฀on฀XGA฀model฀(M332XS)฀

*2฀Native฀resolution฀on฀WXGA฀model฀(M352WS/M302WS)

*3฀The฀projector฀may฀fail฀to฀display฀these฀signals฀correctly฀when฀[AUTO]฀is฀selected฀for฀[ASPECT฀RATIO]฀in฀the฀on-screen฀menu.

฀The฀factory฀default฀is฀[AUTO]฀for฀[ASPECT฀RATIO].฀To฀display฀these฀signals,฀select฀[16:9]฀for฀[ASPECT฀RATIO].

*4฀WXGA฀MODE:฀OFF

*5฀WXGA฀MODE:฀ON

140

8. Appendix

❻ PC Control Codes and Cable Connection

PC Control Codes

Function Code Data

POWER ON 02H 00H 00H 00H 00H 02H

POWER OFF 02H 01H 00H 00H 00H 03H

INPUT SELECT COMPUTER 02H 03H 00H 00H 02H 01H 01H 09H

INPUT SELECT HDMI 1 02H 03H 00H 00H 02H 01H A1H A9H

INPUT SELECT HDMI 2 02H 03H 00H 00H 02H 01H A2H AAH

INPUT SELECT VIDEO 02H 03H 00H 00H 02H 01H 06H 0EH

INPUT SELECT USB-A 02H 03H 00H 00H 02H 01H 1FH 27H

INPUT SELECT LAN 02H 03H 00H 00H 02H 01H 20H 28H

INPUT SELECT USB-B 02H 03H 00H 00H 02H 01H 22H 2AH

PICTURE MUTE ON 02H 10H 00H 00H 00H 12H

PICTURE MUTE OFF 02H 11H 00H 00H 00H 13H

SOUND MUTE ON 02H 12H 00H 00H 00H 14H

SOUND MUTE OFF 02H 13H 00H 00H 00H 15H

NOTE:ContactyourlocaldealerforafulllistofthePCControlCodesifneeded.

Cable Connection

Communication฀Protocol

Baud rate .........................................38400 bps

Data length ......................................8 bits

Parity ...............................................No parity

Stop bit ............................................One bit

X on/off ............................................None

Communications procedure .............Full duplex

NOTE:Dependingontheequipment,alowerbaudratemayberecommendedforlongcableruns.

PC Control Connector (D-SUB 9P)

NOTE1:Pins1,4,6and9arenoused.

NOTE2:Jumper“RequesttoSend”and“CleartoSend”togetheronbothendsofthecabletosimplifycableconnection.

NOTE3:Forlongcablerunsitisrecommendedtosetcommunicationspeedwithinprojectormenusto9600bps.

15243

67 98

To GND of PC

To RxD of PC

To TxD of PC

To RTS of PC

To CTS of PC

141

8. Appendix

No image is displayed from your PC or video equipment to the

projector.

Still no image even though you connect the projector to the PC

ﬁrst, then start the PC.

Enabling your notebook PC’s signal output to the projector.

•Acombinationoffunctionkeyswillenable/disabletheexter-

naldisplay.Usually,thecombinationofthe“Fn”keyalong

withoneofthe12functionkeysturnstheexternaldisplay

onoroff.

No image (blue or black background, no display).

Still no image even though you press the AUTO ADJUST

button.

Still no image even though you carry out [RESET] in the

projector’s menu.

Signal cable’s plug is fully inserted into the input connector

A message appears on the screen.

( _____________________________________________ )

The source connected to the projector is active and available.

Still no image even though you adjust the brightness and/or

the contrast.

Input source’s resolution and frequency are supported by the

projector.

❼ Troubleshooting Check List

Before฀contacting฀your฀dealer฀or฀service฀personnel,฀check฀the฀following฀list฀to฀be฀sure฀repairs฀are฀needed฀also฀by฀

referring฀to฀the฀“Troubleshooting”฀section฀in฀your฀user’s฀manual.฀This฀checklist฀below฀will฀help฀us฀solve฀your฀problem฀

more฀efciently.

*฀Print฀this฀page฀and฀the฀next฀page฀for฀your฀check.

Frequency of occurrence  always  sometimes (How often?_____________________)  other (__________________)

Power

No power (POWER indicator does not light blue) See also “Status

Indicator (STATUS)”.

Power cord’s plug is fully inserted into the wall outlet.

Lamp cover is installed correctly.

Lamp Hours Used (lamp operation hours) was cleared after

lamp replacement.

No power even though you press and hold the POWER but-

ton.

Shut down during operation.

Power cord’s plug is fully inserted into the wall outlet.

Lamp cover is installed correctly .

[AUTO POWER OFF] is turned off (only models with the [AUTO

POWER OFF] function).

[OFF TIMER] is turned off (only models with the [OFF TIMER]

function).

Video and Audio

Image is too dark.

Remains unchanged even though you adjust the brightness

and/or the contrast.

Image is distorted.

Image appears to be trapezoidal (unchanged even though you

carry out the [KEYSTONE] adjustment).

Parts of the image are lost.

Still unchanged even though you press the AUTO ADJUST

button.

Still unchanged even though you carry out [RESET] in the

projector’s menu.

Image is shifted in the vertical or horizontal direction.

Horizontal and vertical positions are correctly adjusted on a

computer signal.

Input source’s resolution and frequency are supported by the

projector.

Some pixels are lost.

Image is ﬂickering.

Still unchanged even though you press the AUTO ADJUST

button.

Still unchanged even though you carry out [RESET] in the

projector’s menu.

Image shows ﬂickering or color drift on a computer signal.

Still unchanged even though you change [FAN MODE] from

[HIGH ALTITUDE] to [AUTO].

Image appears blurry or out of focus.

Still unchanged even though you checked the signal’s resolution

on PC and changed it to projector’s native resolution.

Still unchanged even though you adjusted the focus.

No sound.

Audio cable is correctly connected to the audio input of the

projector.

Still unchanged even though you adjusted the volume level.

AUDIO OUT is connected to your audio equipment (only models

with the AUDIO OUT connector).

Other

Remote control does not work.

No obstacles between the sensor of the projector and the

remote control.

Projector is placed near a ﬂuorescent light that can disturb the

infrared remote controls.

Batteries are new and are not reversed in installation.

Buttons on the projector cabinet do not work (only models with the

[CONTROL PANEL LOCK] function)

[CONTROL PANEL LOCK] is not turned on or is disabled in

the menu.

Still unchanged even though you press and hold the EXIT button

for a minimum of 10 seconds.

142

8. Appendix

In the space below please describe your problem in detail.

Information on application and environment where your projector is used

Projector

Model number:

Serial No.:

Date of purchase:

Lamp operating time (hours):

Eco Mode:  OFF  AUTO ECO

 NORMAL  ECO

Information on input signal:

Horizontal synch frequency [ ] kHz

Vertical synch frequency [ ] Hz

Synch polarity H  (+)  (−)

V  (+)  (−)

Synch type  Separate  Composite

 Sync on Green

STATUS Indicator:

Steady light  Orange  Green

Flashing light [ ]] cycles

Remote control model number:

Signal฀cable

NEC standard or other manufacturer’s cable?

Model number: Length: inch/m

Distribution ampliﬁer

Model number:

Switcher

Model number:

Adapter

Model number:

Installation environment

Screen size: inch

Screen type:  White matte  Beads  Polarization

 Wide angle  High contrast

Throw distance: feet/inch/m

Orientation:  Ceiling mount  Desktop

Power outlet connection:



Connected directly to wall outlet

 Connected to power cord extender or other (the

number of connected equipment______________)



Connected to a power cord reel or other (the number

of connected equipment______________)

Computer

Manufacturer:

Model number:

Notebook PC  / Desktop 

Native resolution:

Refresh rate:

Video adapter:

Other:

Video฀equipment

VCR, DVD player, Video camera, Video game or other

Manufacturer:

Model number:

Projector

DVD player

143

8. Appendix

❽ TCO Certiﬁcation

Some฀models฀in฀this฀product฀family฀are฀TCO฀certied.฀All฀TCO฀certied฀models฀have฀the฀TCO฀mark฀on฀the฀marking฀

plate฀(on฀the฀bottom฀of฀the฀product).฀To฀see฀a฀list฀of฀our฀TCO฀certied฀projectors฀and฀their฀TCO฀Certication฀(in฀English฀

only),฀visit฀our฀website฀at฀

http://www.nec-display.com/ap/en_projector/tco/index.html

The฀TCO฀certication,฀designed฀by฀TCO฀Development,฀is฀an฀international฀environmental฀and฀ergonomics฀standard฀

for฀IT฀equipment.฀

In฀some฀cases฀we฀may฀post฀a฀list฀of฀TCO฀certied฀models฀on฀our฀website฀before฀the฀TCO฀mark฀is฀placed฀on฀the฀prod-

uct.฀This฀difference฀in฀timing฀is฀related฀to฀the฀date฀certication฀is฀received฀compared฀with฀the฀projectors฀manufacturing฀

date.

144

8. Appendix

❾ REGISTER YOUR PROJECTOR! (for residents in the United

States, Canada, and Mexico)

Please฀take฀time฀to฀register฀your฀new฀projector.฀This฀will฀activate฀your฀limited฀parts฀and฀labor฀warranty฀and฀InstaCare฀

service฀program.

Visit฀our฀web฀site฀at฀www.necdisplay.com,฀click฀on฀support฀center/register฀product฀and฀submit฀your฀completed฀form฀

online.

Upon฀receipt,฀we฀will฀send฀a฀conrmation฀letter฀with฀all฀the฀details฀you฀will฀need฀to฀take฀advantage฀of฀fast,฀reliable฀

warranty฀and฀service฀programs฀from฀the฀industry฀leader,฀NEC฀Display฀Solutions฀of฀America,฀Inc.

NEC NP-M352WS REPLACED BY NP-M353WS 3500-Lumen Portable Projector

Product's Documents

User Manual

Specifications

NEC NP-M352WS REPLACED BY NP-M353WS Questions and Answers
