Decorator Panel mensions an Installation.
A
mi
= B
D
B
C
Suggested Panel Assembly Methods
A
B
C
D
Thickness
B17-3/4"
(451mm)
44-1/8"
(1121mm)
24"
(610mm)
35-3/4"
(908mm)
3/4" max
(19mm)
16-3/4"
(425mm)
43-3/16"
(1097mm)
23"
(584mm)
34-3/4"
(883mm)
1/16"
(2mm)
17-3/8"
(441mm)
43-13/16"
(1113mm)
23-9/16"
(599mm)
35-5/16"
(897mm)
1/4"
(6mm)
* For ease of installation cut backer panel corners at
45o_ 1,,x 1,,
1" (25.4mm)
Typ.
I I
WEIGHT REQUIREMENTS FOR PANEL INSERTS
• individualrefrigerator door panels should not exceed 15 Ibs. (7 kg).
• Freezer drawer panel should not exceed 15 Ibs. (7 kg).
Three Panel Method
Trim Frame
Surrounding Door
Refrigerator Door
Front Panel ( 3/4" Max.)
Spacer Panel (1/16")
Backing Panel (1/4")
Routed Raised Panel Method
Trim Frame
Surrounding Door
Routed Area
Front Panel ( 3/4" Max.)
i ]
+Backing Panel (1/4")
12884405 06/08
