Tripp Lite SV120KL SmartOnline SV Series 120kVA Large-Frame Modular Scalable 3-Phase On-Line Double-Conversion 208/120V 50/60 Hz UPS System

Owner's Manual

For SV120KL. Series: SV Series

PDF File Manual, 112 pages, Read Online | Download pdf file

Owner’s Manual

SmartOnline

208V SV-Series

3-Phase Modular UPS Systems

(Series Number: AG-0172) (Series Number: AG-0173) (Series Number: AG-0174)

Input: 120/127V (Ph-N), 208/220V (Ph-Ph)

(Not suitable for mobile applications)

Español 38 • Français 75

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Loading ...

File type: PDF

File name: 1615519_sv120kl.pdf

File size: 614.57 KB

File Language: English, French, Spanish

Pages: 112

Author: Tripp Lite

File created: 2022-04-22

Published: 2023-11-27

Updated: 2023-12-12

Download File

Specifications

Brand: Tripp Lite

Model: SV120KL

Category: Tools - Home Improvement

Nominal Input Voltage(s) Supported: 120/208V 3-PH Wye; 127/220V 3-PH Wye

Input Frequency: 40 to 70Hz (online mode); 50/60Hz Auto-selectable

Power Factor (Input): 0.99 (full load)

Power Factor: 0.9

Frequency Compatibility Details: Auto-selectable, user adjustable

Output AC Waveform (Battery Mode): Pure Sine wave

Nominal Output Voltage(s) Supported: 120/208V 3-PH Wye; 127/220V 3-PH Wye

DC System Voltage (VDC): ±120VDC

Battery Replacement Description: Hot-swappable, replaceable batteries

Voltage Regulation Description: Online, double-conversion power conditioning

UPS Power Module Dimensions (hwd, in.): 79.13 x 23.62 x 43.3

UPS Power Module Weight (kg): 479.90

UPS Power Module Weight (lbs.): 1058

UPS Input Connection Type: Hardwire

Product Compliance: RoHS; FCC Part 15 Class A (USA)

Output Capacity (VA): 120000

Output Capacity (kVA): 120

Output Capacity (Watts): 108000

Output Capacity (kW): 108

Primary UPS Depth (mm): 1,100

Primary UPS Height (mm): 2,010

Primary UPS Width (mm): 600

Shipping Dimensions (hwd / in.): 75.00 x 29.00 x 48.00

Shipping Weight (lbs.): 1055.00

Unit Weight (lbs.): 438.7

Expandable Runtime: Yes

EMI / RFI AC Noise Suppression: Yes

AC Suppression Response Time: Instantaneous

Storage Temperature Range: 5° to 140°F (-15° to 60°C)

Relative Humidity: 0 to 95%, non-condensing

AC Economy Mode Efficiency Rating (100% Load): 99%

Audible Noise: Less than 73 DBA front-side, 1m

UPS Housing Material: Steel

View in the file: Full Specifications
