TouchMaster 6-Outlet Under-Monitor Surge
Protector, 6 ft. (1.83 m) Cord, 1440 Joules,
Tel/Modem Protection
MODEL NUMBER: TMC-6
Description
The TOUCHMASTER COMPACT surge suppressor offers complete AC and phone line surge
suppression for comprehensive protection of workstations, desktop PCs, telecom systems and other
sensitive electronics. Heavy-grade AC surge suppression shields connected equipment from damage and
performance problems due to transient surges. RJ11 telephone line suppression jacks protect dialup and
DSL modem lines, fax machines, cordless phones and more. TOUCHMASTER COMPACT offers six total
outlets, six-foot (1.8-meter) cord and LEDs to warn of power and wiring problems. Heavy-grade AC
suppression rated at 1440 joules shields equipment from surges and line noise. Attractive, slim design is
perfect for use under desktop computer monitors or notebook computers. Individual switches offer power
control over connected equipment.
Features
6 outlets
●
6-ft. (1.83 m) cord with space-saving right-angle plug
●
Built-in RJ11 jacks prevent surges from damaging your modem/fax equipment; 6-ft. (1.83 m) telephone
cord included
●
Surge suppression rating: 1440 joules
●
EMI/RFI noise filtering
●
15 amp resettable circuit breaker
●
Diagnostic LEDs confirm suppressor "protection present" (green), "grounded" (red) status and "power
on" (green)
●
Always-on outlet provides power for equipment you always need on, even when the "master" switch is
off
●
Includes full normal mode (H-N) and common mode (N-G/H-G) line surge suppression
●
Allows for the computer to be controlled by the "master" switch and other outlets to be controlled either
the "master" switch or corresponding switch on the front panel
●
$50,000 Ultimate Lifetime Insurance (U.S., Canada, and Puerto Rico only) covers connected equipment
●
Automatic shutoff permanently cuts power to outlets if protection circuit is incapacitated, preventing
equipment damage and indicating replacement is required
●
Highlights
6 outlets / 6-ft. cord
●
1440 joule rating
●
Tel/modem surge protection
●
Individual switches
●
Package Includes
TOUCHMASTER COMPACT
surge suppressor
●
6-ft. (1.83 m) phone cord
●
Instruction manual and warranty
information
●
1 / 4
Specifications
1000 Eaton Boulevard
Cleveland, OH 44122
United States
OVERVIEW
UPC Code 037332119117
INPUT
Nominal Input Voltage(s) Supported 120V AC
Recommended Electrical Service 120V (110-125V)
Input Plug Features Right Angle
Input Cord Gauge Type 14 gauge; SJT
Input Cord Gauge (AWG) 14
Voltage Compatibility (VAC) 120
Maximum Surge Amps 84000
Input Plug Type NEMA 5-15P
Input Cord Details SJT
Input Cord Length (ft.) 6
Right-Angle Plug Yes
Input Cord Length (m) 1.83
Integrated Cord Clip No
OUTPUT
Frequency Compatibility 50 / 60 Hz
Output Receptacles (6) 5-15R
Circuit Breaker (amps) 15
Transformer Accommodation (3) Yes
Right-Angle Outlets No
USER INTERFACE, ALERTS & CONTROLS
Diagnostic LED(s) Yes
Switches Includes 5 front panel AC power switches. 4 switches control individual outlets and 1 serves as a main power switch
that controls all but the one marked "unswitched" on the back panel
Diagnostic LED Details Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
SURGE / NOISE SUPPRESSION
AC Suppression Joule Rating 1440
AC Suppression Response Time < 1 ns
2 / 4
1000 Eaton Boulevard
Cleveland, OH 44122
United States
Protection Modes Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
UL1449 Let Through Rating 400V - UL Verified
EMI / RFI Filtering Yes
Automatic Shut-Off Yes
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection Details 1 line
Cable (Coax) Protection No
Network (Ethernet) Protection No
Telephone/DSL Protection Yes
PHYSICAL
Material of Construction Plastic
Power Cord Color Black
Form Factors Supported Supports under monitor placement as a power control center for an entire PC system with peripherals
Housing Color Black
Mounting Holes or Slots No
Receptacle Color Black
Shipping Dimensions (hwd / in.) 2.00 x 12.30 x 13.30
Shipping Dimensions (hwd / cm) 5.08 x 31.24 x 33.78
Shipping Weight (lbs.) 3.30
Shipping Weight (kg) 1.50
Unit Dimensions (hwd / in.) 1.750 x 11.500 x 12.000
Unit Dimensions (hwd / cm) 4.45 x 29.21 x 30.48
Unit Weight (lbs.) 2.8
Unit Weight (kg) 1.27
Input Cord Color Black
FEATURES & SPECIFICATIONS
Rotatable Outlets No
Antimicrobial No
STANDARDS & COMPLIANCE
Product Certifications NOM (Mexico); UL 1449; UL 497A; UL 1363
Product Compliance RoHS
WARRANTY & SUPPORT
3 / 4
1000 Eaton Boulevard
Cleveland, OH 44122
United States
Product Warranty Period
(Worldwide)
Lifetime limited warranty
Connected Equipment Insurance
(U.S., Canada & Puerto Rico)
$50,000 <a class="insuranceLink" href="//tripplite.eaton.com/support/insurance-policy">Ultimate Lifetime
Insurance</a>
