SD42350/01-15
Danze, Inc., 2500 Internationale Parkway, Woodridge, IL 60517, USA danze.com
Contractor: Contact #:
Job Name: Location:
Submittal Information:
D423507
SPECIFICATIONS
Warranty
Description
DID-U-WAVE™ KITCHEN PULL-DOWN FAUCET
Finishes Available
Model
D423507 (AC/Plug-In)
Standards
Flow Rate
• NSF/ANSI 372
• ASME A112.18.1M/A112.18.1
D423507
• Ceramic disc cartridge for drip free performance
• Dual function spray head; spray/aerated stream
•
S
napBack™ retraction with Grip Lock™ Weight
• 17 3/8" high swivel spout, 8 1/8" spout length
• 300° swivel spout
• 70" spray hose length
• Features Dual Operation: Hands free with the
wave of the hand or manual
• LED task-lighting
• 1.75gpm (6.6L/min) maximum flow rate @60psi
17 3/8"
(441mm)
8°
9 1/8"
(231mm)
8 1/8"
(207mm)
24 3/8"
(617mm)
1/8~2 1/2"
(1~64mm)
3 1/2"
(87mm)
3 5/8"
(90mm)
45°
45°
9 1/2"
(239mm)
1 1/4"-18UNEF
9/16"-24UNEF
3/8" Compression
17"
(432mm)
• 8" deck plate DA665051 sold separately for
single hole mounting
1/4"
(6mm)
2 1/2"
(62mm)
10 1/4"
(261mm)
Ø 1 3/8"
(Ø34mm)
R
7/8"
(R 20mm)
PSI
GPM
0.5
1
1.5
2.2
20 40 60 80
1.75
• Chrome & Stainless Steel
A manufacturer's limited "lifetime" warranty covers all
non-electronic parts of Danze faucets for manufacturing
defects and a manufacturer's five (5) year warranty covers
all electronic parts of the Danze faucet for manufacturing defects.
8" Deck Plate DA665051 Sold Separately
NSF/ANSI 372
Water Efficiency
•
ADA Accessibility Guidelines for
Buildings and Facilities -
309.4 Operation and Operable Parts
