Instructions for 10ft Hammock Stand
(12 Parts, Not Including Hardware)
CONTENTS*
“U” Bracket • QTY = 2
“L” Bracket • QTY = 4
Frame Tube • QTY = 6
Double-ended Hex Wrench • QTY = 1
Hex Nut • QTY = 2Z-Hook • QTY = 2
Washer • QTY = 2
Hardware Parts
*Not to scale
CAUTION
If you are not familiar with hardware or the use of tools, please use a qualified general contractor to install. Improper installation may cause
injury. Safety First: Before using the hammock stand, inspect all parts and hardware as well as installation points and objects supporting your
hammock for wear or weakness. Be sure all parts are properly secure, including the hardware. The Z-hooks, Hex Nuts, & Washers should all
be tight and secure. Make sure there is no excessive rust or twisting in the any of the hardware and parts. The hammock stand is not a
playground or toy. Rough play may result in falls and may wear out your hammock stand and hardware prematurely. Small children should not
play unsupervised in your hammock stand. Carefully, follow the directions of your hammock stand & hammock (sold separately).
Hex Nut
Z-Hook
Washer
»»»»
“U” Bracket
The Z-hooks should be inserted entirely through the top hole of the
“U” Bracket. Use the Double-ended Hex Wrench to tighten the
Washer & Hex Nut to the Z-Hook. Do not over tighten.
At the end of each Frame Tube has (2) Spring-Pins
built-in their interior. Make sure you securely insert
them into the eyelets of the parts: “U” Brackets & “L”
Brackets. You should hear a ‘click’ sound and see the
head of the Spring-Pin through the eyelets of those
parts.
After assembling the stand, to check if they are
secure: pull & push each part to make sure they are
not loose or can separately. Once all parts are secure,
you may install your hammock (sold separately).
Spring Pin
End of a
Frame Tube
®
BY SUNJOE
Made in China
Max Weight Capacity: 265 LBS (120.2 KGS)
©Bliss Hammocks is a Registered Trademark of Snow Joe, LLC
