Dishwasher
User’s Manual
15 7738 0100_AA_BEKO_B6B_EN/ 30-03-23.(16:01)
BDFB1410W
BDFB1410X
Explanation of symbols
Throughout this User Manual the following symbols are used:
C
Important information or useful
hints about usage.
A
Warning for hazardous
situations with regard to life and
property.
B
Warning for electric shock.
Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations.
Do not dispose of the packaging materials together with the domestic or other
wastes. Take them to the packaging material collection points designated by the local
authorities.
Please read this user manual first!
Dear Customer,
We hope that you get the best results from your product which has been manufactured
with high quality and state-of-the-art technology. Therefore, please read this entire
user manual and all other accompanying documents carefully before using the product
and keep it as a reference for future use. If you handover the product to someone else,
give the user manual as well. Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models. Differences
between models will be identified in the manual.
This product was manufactured using the latest technology in environmentally friendly conditions.
CONTENTS
1 INSTRUCTIONS FOR SAFETY
AND ENVIRONMENT 4
General safety .......................................4
Intended use ..........................................4
Children’s safety ....................................5
Disposing of packaging material ........5
Transportation of the product ............5
Compliance with WEEE Directive and
Disposing of the Waste Product .........6
Compliance with RoHS Directive ........6
Package information ............................6
2 DISHWASHER 7
Overview ................................................7
Fan drying system .................................8
Technical specications .......................8
3 INSTALLATION 9
Appropriate installation location .......9
Connecting water supply .....................9
Connection to the drain .................... 10
Adjusting the feet .............................. 10
Aquasafe+ ........................................... 11
Electrical connection ..........................11
Initial use ..............................................12
4 PREPARATION 13
Tips for energy saving ........................13
Detergent .............................................13
Tablet detergents ...............................14
Rinse aid ...............................................15
Items not suitable for washing in the
dishwasher ...........................................15
Placing the dishes into the
dishwasher ...........................................16
Cutlery basket .................................... 18
Cutlery basket .................................... 18
Collapsible lower basket tines ......... 19
Collapsible lower basket tines ......... 19
Upper basket multi-function service
rack ....................................................... 20
Lower basket multipurpose / height
adjustable service rack ......................21
Lower basket bottle wire .................. 22
Upper basket height adjustable
rack ....................................................... 22
Upper basket multipurpose service
rack ....................................................... 22
Adjusting the height of the upper
basket .................................................. 23
Collapsible upper basket wires ........ 24
Height setting with empty basket .. 24
Ceiling cutlery basket ........................ 25
Ceiling cutlery basket ........................ 25
5 OPERATION OF THE PRODUCT
26
Keys .......................................................27
Preparing the machine.......................27
Program Selection ..............................27
Auxiliary functions ............................ 29
Scheduling the washing time .......... 30
Starting the programme ................... 30
Cancelling the programme ................31
Salt indicator (
) ...............................31
Rinse Aid indicator ( ) ......................31
Adjusting the amount of rinse aid ....31
End of programme ............................. 32
Water cut-o warning ....................... 32
Overowing warning ......................... 32
6 MAINTENANCE AND
CLEANING 33
Cleaning the outer surface of the
product ................................................ 33
Cleaning the interior of the machine 33
Cleaning the lters ............................ 33
Cleaning the hose lter ..................... 34
Cleaning the impellers ...................... 35
Lower impeller .................................... 35
Upper impeller ................................... 35
7 TROUBLESHOOTING 36
CONTENTS
Mandatory Warnings
Dishwashers
•
The appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervised or
instruction concerning use of the appliance by a responsible person for
their safely.
•
Young children should be supervised to ensure that they do not play
with the appliance.
•
If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a
hazard.
•
Capacity standard place settings
•
Please do not leave the door open as this will cause a tripping hazard
•
The dishwasher must always be connected to the water system using
new hose sets.
•
Water Supply Min: 0.03 MPa - Max: 1.0 MPa
•
If the appliance is installed on a carpet floor, take care that the openings
in its base are not obstructed
•
WARNING - Knives and other utensils with sharps points must be
loaded in the basket with the points down or placed in a horizontal
position.
•
WARNING: SOME DISHWASHER DETERGENTS ARE STRONGLY
ALKALINE. THEY CAN BE EXTREMELY DANGEROUS IF SWALLOWED.
AVOID CONTACT WITH SKIN AND EYES AND KEEP CHILDREN AWAY
FROM THE DISHWASHER WHEN THE DOOR IS OPEN.
•
This appliance is intended to be used in household and similar
applications such as:
-
Staff kitchen areas in shops, offices and other working environments;
-
Farm houses;
-
By clients in hotels, motels and other residential type environments;
-
Bed and Breakfast type environments
16
4 / /40 EN
instructions for safety and environment
1
This section contains safety
instructions that will help to get
protected from risk of personal
injury or property damage. Failure
to follow these instructions shall
void all warranties.
General safety
• Never place the product
on a carpet-covered floor;
otherwise, lack of airflow
beneath the product will
cause electrical parts to
overheat. This will cause
problems with your product.
• Do not operate the product
if the power cable / plug is
damaged! Call the
• Connect the product to a
grounded outlet protected
by a fuse complying with
the values in the “Technical
specifications” table. Do
not neglect to have the
grounding installation made
by a qualified electrician. The
manufacturer shall not be
liable for any damages that
will arise when the product
is used without grounding
in accordance with the local
regulations.
• The water supply and
draining hoses must be
securely fastened and remain
undamaged.
• Unplug the product when not
in use.
• Never wash the product by
spreading or pouring water
onto it! There is the risk of
electric shock!
• Never touch the plug with
wet hands! Never unplug by
pulling on the cable, always
pull out by grabbing the plug.
• The product must be
unplugged during installation,
maintenance, cleaning and
repairing procedures.
• Always have the installation
and repairing procedures
carried out by the Authorised
Service Agent. Manufacturer
shall not be held liable for
damages that may arise from
procedures carried out by
unauthorised persons.
• Never use chemical solvents
in the product. They bring
forth the risk of explosion.
• When you pull the upper and
lower baskets out completely,
the door of the product will
bear all the weight of the
baskets. Do not put other
loads on the door; otherwise,
the product may tilt.
• Never leave the door of
the product open apart
from loading and unloading
procedures.
• Do not to open the door
of the product when it is
running unless necessary.
Be careful for the rush of hot
steam when you open the
door.
Intended use
• This product has been
designed for domestic use.
• It must be used to do the
domestic type dishes only.
• This appliance is intended
/
5 / 40
EN
instructions for safety and environment
to be used in household and
similar applications such as:
- Staff kitchen areas in shops,
offices and other working
environments;
- Farm houses;
- By clients in hotels, motels
and other residential type
environments;
- Bed and breakfast type
environments
• Only dishwasher safe
detergents, rinse aids and
additives must be used.
• The manufacturer waives
any responsibility arisen
from incorrect usage or
transportation.
• The service life of your
product is 10 years. During
this period, original spare
parts will be available to
operate the product properly.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical,sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the
appliance. Cleaning and user
maintenance shall not be
made by children without
supervision.
Chldren’s safety
• Electrical products are
dangerous for the children.
Keep children away from the
product when it is in use. Do
not let them to tamper with
the product.
• Do not forget to close the
door of the product when
leaving the room where it is
located.
• Store all detergents and
additives in a safe place
away from the reach of the
children.
Dsposng of
packagng materal
Packaging materials are
dangerous to children. Keep
packaging materials in a safe
place away from reach of the
children.
Packaging materials of the
product are manufactured from
recyclable materials. Dispose
of them properly and sort in
accordance with recycled waste
instructions. Do not dispose
of them with normal domestic
waste.
Transportaton of the
product
A
If you need to move the
product, do it in upright
position and hold from
the rear side. Slanting
the product onto its
front side may cause the
electronic parts in it get
wet and damaged.
6 / /40 EN
instructions for safety and environment
1. Unplug the product before
transporting it.
2. Remove water drainage and
water supply connections.
3. Drain the remaining water in
the product completely.
Complance wth
WEEE Drectve and
Dsposng of the
Waste Product
This product complies with
EU WEEE Directive
(2012/19/EU). This product
bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality
parts and materials which can be
reused and are suitable for
recycling. Do not dispose of the
waste product with normal
domestic and other wastes at the
end of its service life. Take it to
the collection center for the
recycling of electrical and
electronic equipment. Please
consult your local authorities to
learn about these collection
centers.
Complance wth RoHS
Drectve
The product you have purchased
complies with EU RoHS Directive
(2011/65/EU). It does not contain
harmful and prohibited materials
specified in the Directive.
Package nformaton
Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do
not dispose of the packaging
materials together with the
domestic or other wastes. Take
them to the packaging material
collection points designated by
the local authorities.
/
7 / 40
EN
Dishwasher
2
Overvew
1. Upper basket
2. Upper impeller
3. Lower impeller
4. Silverware basket (depends on model)
5. Door
6. Rating Label
7. Control panel
8. Detergent dispenser
9. Lower basket
10. Filters
11. Salt reservoir lid (depends on model)
12. Upper basket rail
13. Upper cutlery basket (depends on model)
14. Tabletop (depends on model)
15. Fan drying system (depends on model)
15
15
8 / /40 EN
Dishwasher
Techncal specfcatons
Compliance to standards and test data / EC declaration of conformity
This product complies with the following EU directives;
Development, production and sales stages of this product comply with the safety
rules included in all pertaining European Community regulations.
2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242
Power input 220-240 V, 50 Hz (see rating label)
Total power consumption 1800-2100 W (see rating label)
Heater power consumption 1800 W (see rating label)
Total current (depends on the model) 10 A (see rating label)
Drain pump power consumption 30 W (see rating label)
Water pressure 0.3 –10 bar (= 3 – 100 N/cm² = 0.03-1.0
Mpa)
C
Technical specifications may be changed without prior notice to improve the
quality of the product.
C
Figures in this manual are schematic and may not match the product exactly.
C
Values stated on the markings of the product or in the printed documents
accompanying the product are obtained in the laboratory on basis of the
relevant standards. Depending on operational and environmental conditions of
the product, these values may vary.
Note for test institutions:
Data required for performance tests shall be provided upon request. Requests can be
e-mailed to the following address:
dishw[email protected]
Do not forget to provide the code, stock and serial numbers of the product to be tested in
your request e-mail along with your contact information. Code, stock and serial numbers of
the product may be found on the type label attached to the side wall of the door.
Fan dryng system
(depends on model)
Fan drying system ensures efficient drying of your dishes.
It is normal to hear a different sound than that of washing cycle during fan operation.
/
9 / 40
EN
3
Installation
Refer to the nearest Authorised Service
Agent for installation of your product. To
make the product ready for use, make sure
that the electricity, tap water supply and
water drainage systems are appropriate
before calling the Authorised Service Agent.
If they are not, call a qualified technician
and plumber to have any necessary
arrangements carried out.
C
Preparation of the location and
electrical, tap water and waste
water installations at the place
of installation is the customer's
responsibility.
B
Installation and electrical
connections must be carried
out by the Authorised Service
Agent. Manufacturer shall
not be held responsible
for damages arising from
processes carried out by
unauthorised persons.
A
Prior to installation, visually
check if the product has any
defects on it. If so, do not have
it installed. Damaged products
cause risks for your safety.
C
Make sure that the water inlet
and discharge hoses are not
folded, pinched or crushed
while pushing the product into
its place after installation or
cleaning procedures.
When placing the product, pay attention
not to damage the floor, walls, piping, etc.
Do not hold the product by its door or panel
to move it.
Approprate nstallaton
locaton
• Place the product on a solid and flat
floor that has sufficient load carrying
capacity! The product must be
installed on a flat surface in order for
the door to be closed comfortably and
securely.
• Do not install the product at places
where temperature may fall below 0ºC.
• Place the product at least 1 cm away
from the edges of other furniture.
• Place the product on a rigid floor. Do
not place it on a long pile rug or similar
surfaces.
B
Do not place the product on the
power cable.
• Make sure that you select a location
that will allow you to load and unload
the dishes in a fast and comfortable
manner.
• Install the product in a place close to
the tap and the drain hole. Select the
installation location by considering
that it will not be changed after the
connections are made.
Connectng water supply
C
We recommend attaching a
filter on the house/apartment
supply water inlet to protect
the machine from damages
that may arise from impurities
(sand, dirt, rust, etc.) coming
from the urban water supply
system or from your own water
system as well as to prevent
complaints such as yellowing or
sludge accumulation at the end
of washing.
10 / /40 EN
Installation
Permitted water temperature:
up to 25°C ( 60°C for products
equipped with Aquasafe+; please
refer toAquasafe+ section )
The dishwasher may not be connected to
open warm water devices or flow-through
water heaters.
• Do not use old or used water inlet
hose on the new product. Use the new
water inlet hose supplied with the
product.
• Connect the water inlet hose directly
to the water tap. Pressure coming
from the tap should be minimum 0.3
and maximum 10 bars. If the water
pressure exceeds 10 bars, a pressure
relief valve should be installed in
between.
• Open the taps completely after making
the connections to check for water
leaks.
C
Use a screw-on hose connector
to connect the water inlet hose
to a water tap with a ¾ inch
external thread. If required, use
a filter insert to filter deposits
from the pipes.
A
For your safety, close the water
inlet tap completely after the
washing programme is over.
Connecton to the dran
Water discharge hose can directly be
connected to the drain hole or sink’s
drainage. The length of this connection
must be min. 50 cm and max. 100 cm from
the floor. A discharge hose longer than 4
meters causes dirty washing.
Attach the water discharge hose to the
drainpipe without bending it. Tightly fix
the water discharge hose to the drainpipe
in order to prevent any dislocation of the
water discharge hose during operation of
the product.
min
300*
min
120*
max 1000 *
min 500 *
* mm
C
Drainpipe must be connected
to the sewage system and it
should not be connected to any
surface water.
Adjustng the feet
If the door of the product cannot be closed
properly or if the product swings when you
push it slightly, then you need to adjust
the feet of the product. Adjust the feet of
the product as illustrated in the installation
manual supplied with the product.
/
11 / 40
EN
Installation
accordance with the local regulations.
• Connection must comply with national
regulations.
• Power cable plug must be within easy
reach after installation.
B
Unplug the product after the
washing programme is over.
• The voltage and allowed fuse or breaker
protection are specified in the “Technical
specifications” section. If the current
value of the fuse or breaker in the house
is less than 16 Amps, have a qualified
electrician install a 16 Amp fuse.
• The specified voltage must be equal to
your mains voltage.
• Do not make connections via extension
cables or multi-plugs.
B
Damaged power cables must
be replaced by the Authorised
Service Agent.
B
If your dishwasher is equipped
with internal illumination, lamp
should only be replaced by the
Authorised Service Agent in
case of failures that may occur
on the lamp.
B
If the product has a failure, it
should not be operated unless
it is repaired by the Authorised
Service Agent! There is the risk
of electric shock!
Aquasafe+
(depends on model)
The Aquasafe+ system protects against
water leaks that may occur at the hose
inlet.Water contact with the valve box of
the system must be avoided to prevent
damage to the electrical system. If the
Aquasafe+ system is damaged, unplug the
product and call the Authorised Service
Agent.
A
As the hose set contains
electrical connections and
assemblies, never shorten
or lengthen the hose with
extension hoses.
A
Dishwashers door must be
aligned properly otherwise hot
steam can escape! Danger of
serious burns, other injury or
may damage furniture.
Electrcal connecton
Connect the product to a grounded outlet
protected by a fuse complying with the
values in the “Technical specifications”
table. The manufacturer shall not be liable
for any damages that will arise when the
product is used without grounding in
12 / /40 EN
Installation
Intal use
Before starting to use the product, make
sure that all preparations are made in
accordance with the instructions in
sections “Important safety instructions”
and “Installation”.
• To prepare the product to do the
dishes, perform first operation in the
shortest programme with detergent
while the machine is empty. During the
initial use, fill the salt reservoir with 1
litre of water prior to filling it with salt.
A
There might be a small amount
of water left in the product
after factory quality control
tests. This has no harm on the
product.
/
13 / 40
EN
Preparation
4
Tps for energy savng
Following information will help you use
the product in an ecological and energy-
efficient manner.
Wipe away any coarse food remnants on
the dishes before putting them in the
product.
Operate the product after filling it
completely.
When selecting a programme, consider
the table of “Programme data and average
consumption values”.
Do not put more detergent than suggested
on the detergent package.
Detergent
You can use powder, liquid/gel or tablet
detergents in the machine.
A
Only use in the machine
the detergents produced
particularly for use with
dishwashers. We recommend
you not use detergents that
contain chlorine and phosphate
as they are harmful for the
environment.
Adding detergent
C
Pay attention to the warnings
on the detergent packaging
to get better washing and
drying results. Contact the
manufacturer of the detergent
for further questions.
A
Do not put solvents into the
detergent dispenser. There is
the risk of explosion!
Put the detergent into the detergent
dispenser just before operating the
machine as illustrated below.
1. Push the latch to right to open the
detergent dispenser lid (A).
2. Put suggested amount of powder,
liquid/gel or tablet detergent in the
reservoir.
C
Inside the detergent dispenser
there are level markings that
help you use appropriate
amount of powder detergent.
When brimful, detergent
dispenser will contain 45 cm³
of detergent. Fill detergent up
to 15 cm³ or 25 cm³ level marks
in the detergent dispenser
according to fullness of the
machine and/or soiling degree
of the dishes. One tablet
is enough if you are using
detergent tablets.
3. Push the lid of the detergent dispenser
to close it. A “click” will be heard when
the lid is closed.
14 / /40 EN
Preparation
C
The best washing performance
in dishwashers is obtained by
using detergent, rinse aid and
water softening salt individually.
C
Observe the instructions of the
detergent manufacturer on
the package when using tablet
detergents.
C
Contact the detergent
manufacturer if your dishes
are wet and/or if you notice
limescale spots particularly on
your glasses after the washing
programme is over when using
a tablet detergent.
When you switch to powder
detergent from tablet detergent:
1. Make sure that salt and rinse aid
reservoirs are full.
2. Set the water hardness to the highest
level and perform an empty run.
3. After the empty washing cycle, review
the user manual and readjust the water
hardness level so as to suit the water
supply.
4. Make the appropriate rinse aid settings.
1
2
3
C
Use powder or liquid/gel
detergent in short programmes
without prewash since the
solubility of the tablet detergent
changes depending on the
temperature and time.
Tablet detergents
In addition to the conventional tablet
detergents, there are also commercially
available detergent tablets that show water
softening salt and/or rinse aid effect. Some
types of these detergents contain special-
purpose components such as glass and
stainless steel protectors. These tablets
show their effects up to a certain water
hardness level (21°dH). Water softening
salt and rinse aid must also be used
together with the detergent if the water
hardness level is above the mentioned level.
/
15 / 40
EN
Preparation
4. If there are stains on tableware items
after washing, level must be increased
and if there is a blue trace after wiping
them by hand, it must be decreased.
This is set to position 3 as factory
default.
C
The rinse aid adjustment is
described under "Adjusting
the amount of rinse aid" in
the section for operating the
machine.
C
Wipe clean any spilled rinse
aid outside the reservoir. Rinse
aid that spilled accidentally
will cause foaming and it will
eventually decrease washing
performance.
Items not sutable for
washng n the dshwasher
• Never wash dishes soiled by cigarette
ash, candle remnants, polish, dyestuff,
chemicals, etc. in your dishwasher.
• Do not wash silverware and cutlery
with wooden or bone stems, glued
pieces, or pieces that are not resistant
to heat, as well as copper and tin-
plated containers in the dishwasher.
Rnse ad
C
The rinse aid used in
dishwashers is a special
combination that aims to
increase drying efficiency and
prevent water or lime stains
on the washed items. For this
reason, care must be paid
to have rinse aid in the rinse
aid reservoir and to use rinse
aids produced specially for
dishwashers only.
1. Open the lid of the rinse aid reservoir
with the help of the latch.
2. Fill the reservoir until “MAX” level.
3. Slightly press the point (B) of the
reservoir lid to close it.
16 / /40 EN
Preparation
C
Decorative prints of chinaware
as well as aluminium and silver
items may get discoloured or
tarnished after washing in the
dishwasher just as it happens
in handwashing as well. Some
delicate glass types and crystals
may become dull in time. We
strongly recommend you to
check if the tableware you are
going to purchase is suitable
for washing especially in the
dishwasher.
Placng the dshes nto the
dshwasher
You can use your dishwasher in the
optimum way with respect to energy
consumption and washing and drying
performance only if you place the dishes in
an orderly way.
• Wipe away any coarse food remnants
(bones, seeds, etc.) on the dishes
before placing them in the dishwasher.
• Place thin, narrow pieces in the middle
sections of baskets if possible.
• Place the heavily soiled and bigger
items in the lower basket and smaller,
delicate and light items in the upper
basket.
• Place the hollowed dishes such as
bowls, glasses and pans upside down
in the dishwasher. Thus, accumulation
of water in deep hollows is prevented.
A
To prevent possible injuries,
always place the sharp and
pointed dishes such as service
fork, bread knife, etc. upside
down so as their pointed ends
will face down or they will lie
horizontally in the dish basket.
Unload dishes in the lower basket first and
then the dishes in the upper basket.
/
17 / 40
EN
Preparation
Suggestions for loading the dishwasher
Lower basket
Upper basket
Improper Loading Of Dishware
Improper Loading Of Dishware
18 / /40 EN
Preparation
Cutlery basket
(depends on model)
Cutlery basket is designed to wash your
dishes such as knife, fork, spoon, etc. in an
efficient manner.
Since the cutlery basket can be moved (A,
B), you can create more space while placing
your dishes in the lower basket and free up
space for your dishes of different sizes.
Cutlery basket
(depends on model)
Cutlery basket is designed to wash your
dishes such as knife, fork, spoon, etc. in an
efficient manner.
Since the cutlery basket can be moved (A,
B), you can create more space while placing
your dishes in the lower basket and free up
space for your dishes of different sizes..
/
19 / 40
EN
Preparation
Collapsble lower basket
tnes
(depends on model)
There are foldable tines (A) located at the
lower basket of the machine are designed
for an easier placement of large pieces such
as pans, bowls, etc. You can create larger
spaces by folding each tines individually or
all of them at once.
To bring the collapsible tines into horizontal
position, grab the tines from mid position
and push them in the directions of arrows
(B). To bring the tines back to vertical
position, just lift them up. Collapsible tines
will click into the latch again (C).
C
Bringing the tines to the
horizontal position by holding
them from the tips may cause
them to bend. Therefore, it
will be appropriate to bring the
tines in the middle to horizontal
or vertical position by holding
them from their stems and
pushing in the direction of
arrow.
Collapsble lower basket
tnes
(depends on model)
There are foldable tines (A) located at the
lower basket of the machine are designed
for an easier placement of large pieces such
as pans, bowls, etc. You can create larger
spaces by folding each tines individually or
all of them at once.
To bring the collapsible tines into horizontal
position, grab the tines from mid position
and push them in the directions of arrows
(B). To bring the tines back to vertical
position, just lift them up. Collapsible tines
will click into the latch again (C).
20 / /40 EN
Preparation
C
Bringing the tines to the
horizontal position by holding
them from the tips may cause
them to bend. Therefore, it
will be appropriate to bring the
tines in the middle to horizontal
or vertical position by holding
them from their stems and
pushing in the direction of
arrow.
Upper basket mult-
functon servce rack
(depends on model)
Thanks to the upper basket multi-function
service rack on the upper basket of your
appliance, you may load and wash long
service-ware and kitchen-ware easily. Also,
the wineglass securing compartments
available on the front side of this accessory
allows easier placing of the stemware with
proper sizes on the upper basket.
You may remove the upper basket multi-
function service rack by lifting it upwards
when you do not want to use it.
You may reinstall the upper basket multi-
function service rack on the side of your
upper basket easily to use it again.
/
21 / 40
EN
Preparation
Lower basket multpurpose
/ heght adjustable servce
rack
(depends on model)
This accessory located at the lower basket
of your machine allows you to easily wash
pieces such as extra glasses, long ladles
and bread knives.
C
You may use the racks as
required by moving them to
lower or upper position, or close
them to create a wider space in
your lower basket.
A
Make sure that the impeller
does not touch the dishes you
placed on the racks.
To close the racks:
1. Fold the rack (A).
2. Slide the rack up (B).
3. Put the rack in vertical position (C).
4. Slide the rack down and lock it by the
tabs (D).
C
You may open the racks in the
same process in reverse order.
To adjust the height of the racks:
1. Fold the rack (E).
2. Slide the rack up (F).
3. Open the rack at the desired level (G).
22 / /40 EN
Preparation
You can lift up the upper basket
multipurpose service rack to remove it if
you do not want to use it.
If you want to use the upper basket
multipurpose service rack again, you can
easily attach it to the side section of your
upper basket.
Upper basket heght
adjustable rack
(depends on model)
Use the lower and upper parts of the height
adjustable racks in the upper basket of
the machine by sliding them down or up
according to the heights of the glasses,
cups or etc. (A, B, C).
Lower basket bottle wre
(depends on model)
The bottle wire is designed for easier
washing of long pieces with wide mouths.
You may take out the bottle wire from the
basket when not in use by pulling it out
from both sides (H).
Upper basket multpurpose
servce rack
(depends on model)
This accessory located at the upper basket
of your machine allows you to easily wash
pieces such as extra long ladles and bread
knives.
/
23 / 40
EN
Preparation
1. To raise the basket, hold the wires of
the basket and pull the basket upwards
with both hands while the basket is at
the lowermost position (B)
2. Release the basket when it catches on
to the next upper position with a “Click”
that may be heard from the right and
left mechanisms.
Repeat the same operation if the height is
not adequate.
1
2
3
C
The movement mechanism may
not work properly when the
upper basket is overloaded or
when the load is unbalanced.
And it may fall to the next lower
position in heavier conditions.
C
Ensure that the adjustment
mechanisms on the right and
left of the upper basket are
aligned.
Adjustng the heght of the
upper basket
(depends on model)
Upper basket height adjustment
mechanism is designed so that you can
create wide spaces on the upper or lower
compartment of the machine by adjusting
the basket upwards or downwards either
while it is empty or full.
Thanks to this mechanism, you may use
your basket in three different positions,
namely lower, center or upper positions.
To lower the basket, perform the following
while the basket is at uppermost position;
1. Hold the wires of the upper basket and
raise the handle of the mechanism
upwards as shown in the figure (A).
2. Lower the basket to the next lower
position.
3. Release the basket when it catches on
to the next lower position.
Repeat the same operation if the height is
not adequate.
1
2
3
24 / /40 EN
Preparation
Pull the basket out completely.
Place the basket back into the tracks at the
desired height.
Push the latches back into the correct
position.
Collapsble upper basket
wres
(depends on model)
You can use collapsible wires when you
need a larger space for your dishes in the
upper basket of your machine.
To bring the collapsible wires into horizontal
position, grab the wire from the middle
position and push them in the direction of
arrow in the figure. Place your larger dishes
into the area created. To bring the wires
back to vertical position, just lift them up.
C
Bringing the wires to the
horizontal position by holding
them from the tips may cause
them to bend. Therefore, hold
the wires from their stems while
bringing them to the horizontal
or vertical positions.
Heght settng wth empty
basket
(depends on model)
In this model, the height setting of the
upper basket may be changed using the
wheels which are mounted at two different
heights.
Release the latches on both the right and
left tracks of the upper basket by pushing
them outwards.
/
25 / 40
EN
Preparation
Celng cutlery basket
(depends on model)
Ceiling cutlery basket is designed to wash
your cutlery items such as forks, spoons
and etc. by placing them between the bars
on the basket.
Celng cutlery basket
(depends on model)
Ceiling cutlery basket is designed to wash
your cutlery items such as forks, spoons
and etc. by placing them between the bars
on the basket.
1
In models with partial movement feature,
pushing the bar (1) on the handle enables
the central tray of the basket to get to
the lower position and the system gets
unlocked. Thus right and left side trays can
be used as moving parts.
The free space enabled by the side trays
allows long parts to be loaded in the upper
basket.
When the central tray is in the lower
position, you can load long/high items such
as coffee cups, ladles, etc. on the tray. When
the side trays lean on two side walls, the
handle can be pulled to allow the central
tray to rise and the system to be locked.
26 / /40 EN
5
5
Operation of the product
1. On / Off key
2. Display
3. Start / Hold / Cancel key
4. Delay key
5. Function keys
a)
b)
c)
6. Program Selection key
7. Program indicator
8. Program Monitoring indicator
a) Washing indicator
b) Drying indicator
c) Program End Indicator
5
SteamGloss Function
Hygiene Intense function
1 2 3
4
5
6
b
c
a
7 9
10111213
8
b
c
a
Half Load function
9. Start ( ) / Hold indicator
10. Delay indicator
11. Rinse aid (
) indicator
Hygiene Intense
indicator
13.
12. (not in use)
/
27 / 40
EN
Operation of the product
Keys
On / Off key
Used to turn the machine on or off.
When this key is brought to ON, the
machine is started with the economy
program and the number of the economy
program is displayed on the program
indicator. The indicators on the screen go
off.
Start / Hold / Cancel key
Used for starting, holding or cancelling the
selected program.
Program Selection key
Used to select the proper washing program
that you specified from the program
information and average consumption
table.
Delay key
Used for setting the delaying period.
Preparng the machne
1. Open the door of the dishwasher.
2. Load your dishes as described in the
user manual.
3. Ensure that lower and upper propellers
are rotating freely.
4. Add adequate amount of detergent in
the detergent compartment.
5. Inspect whether low salt and low rinse
aid indicators are illuminated; and add
salt and/or rinse aid if required.
6. Close the door of the dishwasher.
Program Selecton
1. Turn your machine on by pressing the
On / Off key.
2. Select the proper washing program for
your dishes considering the program
information and average consumption
values table.
3. Press the Program Selection key until
the number of the program you have
decided is displayed on the Program
indicator
28 / /40 EN
Operation of the product
12345
Intensive Eco Clean&Shine Quick&Shine Mini
70 ºC 45 ºC 65 ºC 60 ºC 35 ºC
Suitable for heavily
soiled dishes, pots
and pans.
Most economical
washing program
for the normally
soiled daily dishes
that are kept
waiting.
Daily washing
programme for
medium soiled
dishes.
Daily washing
program
at which the medium
soiled dishes that
are kept waiting are
cleaned and dried in
the fastest
way.
Suitable for lightly
soiled daily dishes
that are scraped or
pre-cleaned.
High Medium Medium Medium Low
+++ -
+++ +
+++ -
120 125 120 58 30
17,6 15,3 16,2 11,8 11,8
1,65 0,88 1,38 1,2 0,8
Programme Data and Average Consumption Values Table
Loading Capacity: 14
The consumption values shown in the table were determined under standard conditions. Differences may therefore occur under practical conditions.
Programme number
Programme name
Cleaning temperature
Degree of Soiling
Energy (kWh)
Prewash
Wash
Dry
Duration (min)
Water (I)
/
29 / 40
EN
Operation of the product
Auxlary functons
Washing programmes of your dishwasher
are designed to obtain the best cleaning
effect, considering the type of the soiling,
soiling degree and properties of the dishes
to be washed.
Auxiliary functions are provided in order to
enable you to save time, water and energy
and to perform a more comfortable washing
with conditions specific to you.
C
Auxiliary functions may cause
changes in the programme
duration.
C
Auxiliary functions are not
suitable for all washing
programmes. Indicator of the
auxiliary function that is not
compatible with the programme
will not be active.
To add auxiliary function to the
programme:
1. Select the desired washing programme
by pressing the programme selection
key.
2. In the selected washing programme,
if auxiliary function is selected, its
symbol will be displayed on the screen.
If the function key is pressed again, the
symbol will disappear and selection is
cancelled.
Hygiene Intense function
(depends on the model)
Designed to be used when more hygiene
is required for washing the dishes. This
function increases the washing and rinsing
temperatures in the selected cycle and
extends the periods of these steps in the
cycle. Moreover, an additional rinsing cycle
is performed to wash and rinse your dishes
with more hygiene.
SteamGloss Function
(depends on the model)
It provides superior drying performance.
Half Load function
(depends on the model)
It is used to operate the machine without
loading it completely.
1. Load your dishes in the machine as you
like.
2. Turn the machine on with On/Off key.
3. Select the desired programme and
press the Half Load key.
While the function is enabled, the Half Load
indicator will become on in the function
selection indicator and on the display.
4. Start the programme by pressing Start
/ Pause / Cancel key.
C
With the Half Load function you
can save both water and power
while using the lower and upper
baskets of the machine.
Floor illumination
Warning to show that machine is
in washing phase
(depends on the model)
Your machine reflects a light to the floor
during the washing process. This light turns
off after the washing process is complete.
C
Floor illumination is activated
automatically when the
washing programme starts and
remains lit until the end of the
programme.
C
Floor illumination cannot be
cancelled by the user.
30 / /40 EN
Operation of the product
C
To exit time delay mode
without activating the Time
Delay, press the time delay key
until the 3-6-9 hours duration
indicators disappear. Time Delay
mode will be cancelled and the
programme selection mode will
be activated.
Changing the settings while Time
Delay function is active
While the Time Delay function is activated,
you cannot make changes in the washing
programme, auxiliary functions or the
duration of delay time.
To cancel the Time Delay function
1. Press and hold Start/Pause/Cancel key
for 3 seconds. Time delay period and
start/pause icon will start to flash and
Time Delay function will be cancelled.
C
You can select and start a
new programme following the
cancellation of Time Delay
function.
C
Time Delay function cannot be
set after the programme starts.
Startng the programme
To start your machine after selecting the
programme and auxiliary functions, press
Start/Pause/Cancel key.
Schedulng the washng
tme
Time Delay
If an economical electricity tariff is applied
in your region, you can use the Time
Delay function to wash your dishes during
appropriate hours.
You can delay the start of the selected
programme until 3-6-9 hours. Time Delay
cannot be set after the programme starts.
1. Press the Time Delay function key after
selecting the washing programme and
other auxiliary functions.
2. Time Delay selection mode is activated.
3-hours time delay icon will flash on
the display.
4. With a second press on the key,
3-hours time delay icon will disappear
and 6-hours time delay icon will start to
flash. With a third press, 6-hours time
delay icon will disappear and 9-hours
time delay icon will start to flash.
5. Press the Start/Pause key to activate
the time delay.
C
While the Time Delay is active
the relevant delay period and
start icon will be displayed
steadily. For 0-3 hours time
delay the 3-hours time delay
icon will be displayed, for 3-6
hours time delay the 6-hours
time delay icon will be displayed,
and for 6-9 hours time delay the
9-hours time delay icon will be
displayed.
C
If the door is opened while
the Time Delay is active, the
countdown will be paused and
start icon will start to flash.
/
31 / 40
EN
Operation of the product
C
Your machine performs water
softening depending on the
hardness level of the supply
water. Due to water softening
process the programme
duration may change. The
programme duration can also
change while the programme
is running depending on the
ambient temperature where
your machine is installed,
temperature of the supply
water and amount of the dishes.
C
Pay attention not to open the
door of the machine when it is
running. Stop the machine by
pressing Start/Pause/Cancel
key if you have to open the
door. Then, open the door of
the machine. There may be a
rush of vapour when you open
the door of your machine; be
careful. Close the door of your
machine and press Start/Pause/
Cancel key again. Programme
will resume running.
C
The machine will remain silent
in pause mode for some time
in order to remove the water in
the machine and on the dishes
completely and to have the
water softener cleaned, and
then it will resume running in
drying mode.
Cancellng the programme
1. Press Start/Pause/Cancel key for 3
seconds to cancel the programme.
2. Release the key when the programme
indicator starts flashing. For a couple
of minutes the machine will fulfill
the necessary operations required to
cancel the programme.
C
There might be residues of
detergent or rinse aid in the
machine and/or on the pieces
being washed depending on the
step the programme you have
cancelled was in.
Salt ndcator ( )
Please check the salt indicator on the
display to see whether there is adequate
amount of softening salt in the dishwasher
or not. You need to refill the salt reservoir
with salt whenever salt indicator appears
on the display of your machine.
C
Adjusting the water hardness
level is explained in Water
Softening System section.
Rnse Ad ndcator ( )
Please check the rinse aid indicator on the
display to see whether there is adequate
amount of rinse aid in the dishwasher or
not. You need to refill the rinse aid reservoir
with rinse aid whenever rinse aid indicator
appears on the display of your machine.
Adjustng the amount of
rnse ad
1. After turning on the machine, press
and hold Time Delay and P keys
simultaneously for 3 seconds to enter
the settings menu.
2. Press P key until the drying indicator
starts flashing
3. Set to the appropriate level with the
Time Delay key.
4. Press the On/Off key to save.
32 / /40 EN
Operation of the product
Water cut-o warnng
If mains water is cut or water inlet tap is
turned off the machine cannot take water
in and P2 icon will flash on the programme
indicator. As long as the problem continues,
washing programme is paused and the
water inlet is checked regularly by the
machine; when the water is restored P2
icon will disappear after a while and the
washing programme resumes.
Overowng warnng
If the machine intakes too much water or
there is leakage at any of the components
then the machine will detect this and P1
icon will flash on the Programme indicator.
As long as the overflowing continues safety
algorithm will be active and try to discharge
the water. If overflowing stops and safety
is assured, P1 icon will disappear. If P1 does
not disappear, there is a permanent fault. In
this case the authorised service should be
contacted.
End of programme
End of Programme indicator will light up
once the washing programme is over.
1. Press the On/Off key to turn off your
machine.
2. Close the tap.
3. Unplug the machine from the socket.
C
For energy saving, the machine
is automatically turned off
following the completion of the
programme or if the programme
is not started.
C
Leave your dishes in the
machine for about 15 minutes
to allow them cool down after
they are washed. Your dishes
will dry in a shorter time if you
leave the door of your machine
ajar during this period. This
process will increase the drying
effectiveness of your machine.
No rinse aid dispensed in P:1 position
1 dose of rinse aid is dispensed in P:2
position.
2 doses of rinse aid are dispensed in P:3
position.
3 doses of rinse aid are dispensed in P:4
position.
4 doses of rinse aid are dispensed in P:5
position.
/
33 / 40
EN
Maintenance and cleaning
6
Service life of the product extends and
frequently faced problems decrease if it is
cleaned at regular intervals.
A
Unplug the product and turn off
the tap before attempting any
cleaning procedures.
C
Do not use abrasive substances
for cleaning.
C
Clean the filter and impellers
at least once a week in order
for the machine operates
efficiently.
Cleanng the outer surface
of the product
Wipe the outer surface and door gaskets
of the product gently with a mild cleaning
material and damp cloth. Wipe the "Control
panel" only with a slightly damp cloth.
Cleanng the nteror of the
machne
• Clean the interior of the machine and
the tank by running a programme with
or without detergent based on the
degree of soil.
• If water has remained in the machine,
drain the water by performing the
procedures under the topic "Canceling
a programme". If the water cannot
be discharged, remove the filters
as specified in the "Cleaning the
filters" section and check if there
are any leftover deposits that have
accumulated at the bottom of the
machine, blocking the water path.
Clean if necessary.
Cleanng the flters
Clean the filters at least once a week in
order for the machine operates efficiently.
Check if food residues are left on the filters.
If there are food residues on filters, take
them out and clean well under running
water.
1. Turn the micro filter (1) and coarse filter
(2) assembly counter clockwise and pull
it out from its seating.
2. Pull out the metal/plastic filter (3) from
the seating.
3. Press the two pawls on the coarse filter
inwards and separate the coarse filter
from the assembly.
34 / /40 EN
Maintenance and cleaning
4. Clean all three filters under tap water
by means of a brush.
5. Place the metal/plastic filter.
6. Place the coarse filter into the micro
filter. Make sure that it is properly
seated. Turn the coarse filter clockwise
until a "click" sound is heard.
C
Do not use the dishwasher
without filter.
C
Incorrect placement of the filters
will reduce washing efficiency.
Cleanng the hose flter
Damages on the machine that may be
caused by impurities coming from the
urban supply water or your own water
installation (such as sand, dirt, rust, etc.)
can be prevented by means of the filter
attached to the water inlet hose. Check the
filter and the hose regularly and clean them
if necessary.
1. Turn off the tap and remove the hose.
2. After taking out the filter, clean it
under running tap water.
3. Place the cleaned filter back to its seat
in the hose.
4. Install the hose to tap.
(depends on model)
/
35 / 40
EN
Maintenance and cleaning
Cleanng the mpellers
Clean the impellers at least once a week in
order for the machine operates efficiently.
Lower mpeller
Check if the holes on the lower impeller (1)
are clogged. If they are clogged, remove and
clean the impeller. You can pull the lower
impeller up to remove it.
Upper mpeller
Check if the holes on the upper impeller (1)
are clogged. If they are clogged, remove
and clean the impeller. Turn its nut to left to
remove the upper impeller.
Make sure that the nut is tightened well
when installing the upper impeller.
36 / /40 EN
7
Troubleshooting
Machine does not start.
• Power cable is unplugged. >>> Check if the power cable is plugged in.
• Fuse is blown. >>> Check the fuses in your house.
• Water is cut. >>> Make sure that the water inlet tap is open.
• Door of the machine is open. >>> Make sure that you have closed the door of the
machine.
• On / Off button is not pressed. >>> Make sure that you have turned on the machine by
pressing the On / Off button.
Dishes are not washed clean
• Dishes are not placed orderly in the machine. >>> Load the dishes as described in the
user manual.
• Selected programme is unsuitable. >>> Select a programme with a higher temperature
and cycle time.
• Impellers are stuck. >>> Prior to starting the programme, turn the lower and upper
impellers by hand to make sure that they rotate freely.
• Impeller holes are clogged. >>> Lower and upper impeller holes might be clogged with
food remnants such as lemon pips. Clean the impellers regularly as illustrated in section
“Cleaning and Care”.
• Filters are clogged. >>> Check if the filter system is clean. Clean the filter system
regularly as illustrated in section “Cleaning and Care”.
• Filters are installed incorrectly. >>> Check the filter system and make sure that it is
installed correctly.
• Baskets are overloaded. >>> Do not overload the baskets in excess of their capacity.
• Detergent is stored under unsuitable conditions. >>> If you are using powder
detergent, do not store the detergent package in humid places. Keep it in a closed
container if possible. For ease-of-storing, we recommend you to use tablet detergents.
• Detergent is not sufficient. >>> If you are using powder detergent, adjust the amount
of detergent according to the soiling degree of your dishes and/or programme
definitions. We recommend you to use tablet detergents for optimum results.
• Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if
necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the
machine.
• Detergent dispenser lid is left open. >>> Make sure that the detergent dispenser lid is
closed tightly after adding detergent.
Dishes are not dry at the end of cycle
• Dishes are not placed orderly in the machine. >>> Place your dishes in a way that no
water will accumulate in them.
/
37 / 40
EN
Troubleshooting
• Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if
necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the
machine.
• Machine is unloaded right after the programme is over. >>> Do not unload your
machine right after washing process is completed. Slightly open the door and wait
for evacuation of the steam inside for a while. Unload the dishes after the pieces
cool down to a touchable level. Start unloading process from the lower basket. Thus,
dropping of water remained on a piece at upper basket onto the pieces at lower basket
is prevented.
• Selected programme is unsuitable. >>> Since rinsing temperature is low at
programmes with short duration, drying performance will also be low. Select
programmes with longer duration for a higher drying performance.
• Surface quality of the kitchen utensils is deteriorated. >>> Desired washing
performance can not be obtained on kitchen utensils with deteriorated surfaces and it
is not suitable to use such utensils in terms of hygiene as well. Also, water can not flow
easily on deteriorated surfaces. It is not recommended to wash such kitchen utensils in
dishwasher.
C
It is normal that drying complaints can be experienced with Teflon kitchen
utensils. It is associated with the structure of Teflon. Since the surface tensions
of Teflon and water are different, water droplets will remain as beads on the
Teflon surface.
Tea, coffee or lipstick stains remain on dishes.
• Selected programme is unsuitable. >>> Select a programme with a higher temperature
and cycle time.
• Surface quality of the kitchen utensils is deteriorated. >>> Tea and coffee stains
or other dye spots may not be cleaned in dishwasher when they have penetrated in
deteriorated surfaces. Desired washing performance can not be obtained on kitchen
utensils with deteriorated surfaces and it is not suitable to use such utensils in terms
of hygiene as well. It is not recommended to wash such kitchen utensils in dishwasher.
• Detergent is stored under unsuitable conditions. >>> If you are using powder
detergent, do not store the detergent package in humid places. Keep it in a closed
container if possible. For ease-of-storing, we recommend you to use tablet detergents.
Lime traces remain on dishes and glassware gains a misty appearance
• Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if
necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the
machine.
• Water hardness setting is low or salt level is insufficient >>> Measure the hardness of
the supply water appropriately and check the water hardness setting.
• Salt leakage exists. >>> Pay attention not to spill salt around the salt filling hole
while adding salt. Make sure that the salt reservoir lid is tightly closed after finishing
38 / /40 EN
Troubleshooting
the filling process. Run the prewash programme to remove the salt that spilled inside
the machine. Since the salt granules that will remain under the lid will dissolve during
prewash, causing the lid loosen, check the lid once again at the end of the programme.
There is a different odour in the machine
C
A new machine has a peculiar odour. It will fade out after a couple of washes.
• Filters are clogged. >>> Check if the filter system is clean. Clean the filter system
regularly as illustrated in section “Cleaning and Care”.
• Dirty dishes are kept in dishwasher for 2-3 days. >>> If you are not going to start the
machine right after you have put the dishes into it, remove the remnants on the dishes
and run the Prewash programme without detergent every 2 days. In such cases, do not
close the door of the machine completely in order to avoid odour build up in machine.
You can also use commercially available odour removers or machine cleaners.
Rust, discoloration or surface deterioration occurs on dishes
• Salt leakage exists. >>> Salt may cause deterioration and oxidation on metal surfaces.
Pay attention not to spill salt around the salt filling hole while adding salt. Make sure
that the salt reservoir lid is tightly closed after finishing the filling process. Run the
prewash programme to remove the salt that spilled inside the machine. Since the salt
granules that will remain under the lid will dissolve during prewash, causing the lid
loosen, check the lid once again at the end of the programme.
• Salty food remnants have remained on dishes for a long time. >>> If cutlery soiled
with such foods will be kept waiting in machine, dirt must be removed by prewash or
dishes must be washed without being kept waiting.
• Electric installation is not grounded. >>>Check if your machine is connected to the
actual grounding line. Otherwise, the static electric created in the product causes arcs
on the surfaces of metal items creating pores, removing the protective cover on the
surface and causing discoloration.
• Intensive cleansers such as bleaches are used. >>> Protective cover on metal surfaces
gets damaged and looses its efficiency in time when it gets in contact with cleansers
such as bleach. Do not wash your dishes with bleach.
• Metal items particularly knives are used for purposes other then their intended uses.
>>> Protective cover on the edges of knives may get damaged when they are used for
purposes such as opening cans. Do not use metal kitchen utensils out of their intended
uses.
• Cutlery are made of low quality stainless steel. >>> Corrosion on such items is
inevitable; they should not be washed in dishwashers.
• Kitchen utensils that are already corroded are washed in dishwasher. >>> Rust on a
corroded item can migrate to other stainless steel surfaces and cause corrosion on
those surfaces as well. Such items should not be washed in dishwashers.
/
39 / 40
EN
Troubleshooting
Detergent remains in detergent dispenser.
• Detergent dispenser was damp when adding detergent. >>> Make sure that the
detergent dispenser is dried well prior to filling it with detergent.
• Detergent is added long before the washing process. >>> Pay attention to add
detergent shortly before start-up of the washing.
• Opening of the detergent dispenser lid is prevented during washing. >>> Place the
dishes in a way that will not prevent the detergent dispenser lid from opening and the
water going into the machine from impellers.
• Detergent is stored under unsuitable conditions. >>> If you are using powder
detergent, do not store the detergent package in humid places. Keep it in a closed
container if possible. For ease-of-storing, we recommend you to use tablet detergents.
• Impeller holes are clogged. >>> Lower and upper impeller holes might be clogged with
food remnants such as lemon pips. Clean the impellers regularly as illustrated in section
“Cleaning and Care”.
Decorations and ornaments on kitchen utensils are being erased.
C
Decorated glasses and decorated lustre porcelains are not suitable for washing
in the dishwasher. Manufacturers of some glassware and porcelain tableware
items do not recommend washing such kitchen utensils in the dishwashers
either.
Dishes are scratched.
C
Kitchen utensils that contains or are made of aluminium should not be washed
in dishwasher.
• Salt leakage exists. >>> Pay attention not to spill salt around the salt filling hole while
adding salt. Spilled salt can cause scratches. Make sure that the salt reservoir lid is
tightly closed after finishing the filling process. Run the prewash programme to remove
the salt that spilled inside the machine. Since the salt granules that will remain under
the lid will dissolve during prewash, causing the lid loosen, check the lid once again at
the end of the programme.
• Water hardness setting is low or salt level is insufficient >>> Measure the hardness of
the supply water appropriately and check the water hardness setting.
• Dishes are not placed orderly in the machine. >>> When placing the glasses and other
glassware into the basket lean them not against other dishes but the edges or racks of
the basket or the glass support tines. Striking of the glasses to each other or to other
dishes due to the impact of water during washing can cause breaks, or scratches on
their surfaces.
40 / /40 EN
Troubleshooting
A smear remains on glasses that resembles milk stain which can not be
removed when wiped by hand. A bluish / rainbow appearance occurs when
the glass is pointed to light.
• Excessive rinse aid is used. >>>Lower rinse aid setting. Clean the spilled rinse aid when
adding rinse aid.
• Corrosion has occurred on glass due to soft water. >>> Measure the hardness of the
supply water appropriately and check the water hardness setting. If your supply water
is soft (<5 dH), do not use salt. Choose programmes that wash in higher temperatures
(e.g. 60-65°C). You can also use glass protective detergents that are commercially
available.
Foam forms in the machine.
• Dishes are washed with hand-wash detergent by hand but not rinsed before placing
them into the machine. >>> Hand-wash detergents do not contain antifoam. There is
no need to hand-wash the dishes before placing them into the machine. Removing the
coarse soil on the dishes under tap water, with a tissue paper or fork will be sufficient.
• Rinse aid has spilled into the machine when adding rinse aid. >>> Take care that rinse
aid is not spilled in the machine when you are filling it. Clean any spilled rinse ait with
the help of a tissue paper/towel.
• Lid of the rinse aid reservoir is left open. >>> Make sure that the lid of the rinse aid
reservoir is closed after adding rinse aid.
Kitchen utensils are broken.
• Dishes are not placed orderly in the machine. >>> Load the dishes as described in the
user manual.
• Baskets are overloaded. >>> Do not overload the baskets in excess of their capacity.
Water remains in the dishwasher at the end of the programme.
• Filters are clogged. >>> Check if the filter system is clean. Clean the filter system
regularly as illustrated in section “Cleaning and Care”.
• Discharge hose is clogged/blocked. >>> Check the discharge hose. If necessary,
remove the discharge hose, clear the blockage and insert is as illustrated in the user
manual.
C
If you cannot eliminate the problem although you follow the instructions in this
section, consult your dealer or the Authorised Service Agent. Never try to repair
a nonfunctional product yourself.
