1
Quick Start Guide
High-Density Fiber Cassette Solutions
Modular Fiber Cassette Enclosures*
Models: N482-00U, N482-01U, N482-02U, N482-04U
Fiber Cassettes*
Models: N482-1M24-LC12, N482-2M12-LC12, N482-2M24-6M12, N482-3M8-LC12, N482-3M8L12S,
N482-6M24-6M24, N482-6M12-6M12, N482-12M12-X2
* This Quick Start Guide covers installation of all N482-Series enclosures and cassettes.
Any new models, even if not listed above, will include this Quick Start Guide and can be installed by following its instructions.
Note: The installation diagrams in this manual show the N482-01U.
The installation is the same for the N482-00U, N482-02U and N482-04U, except for the orientation and number of cassettes.
Español 3 • Français 5 • Русский 7 • Deutsch 9
Installing the Cable Management Bracket
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Installing the Panel Shield Bracket
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
