Tripp Lite OMNIVSX850 850VA 480W Line-Interactive UPS with 6 C13 Outlets - AVR, 230V, C14 Inlet, LCD, USB, Tower

Owner's Manual

For OMNIVSX850. Also, The document are for others Tripp Lite models: OMNIVSX850D, OMNIVSX1000, OMNIVSX1000D, OMNIVSX1500, OMNIVSX1500D

PDF File Manual, 56 pages, Read Online | Download pdf file

UPS Systems

Models:

OMNIVSX850, OMNIVSX850D, OMNIVSX1000,

OMNIVSX1000D, OMNIVSX1500, OMNIVSX1500D

(Series Numbers: AG-02FC, AG-02F5, AG-87E4, AG-02FD, AG-87E6, AG-02FE)

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Español 12 • Français 23 • Русский 34 • Deutsch 45

18-07-252-93388F.indb 1 10/3/2018 10:10:23 AM

Loading ...

File type: PDF

File name: 25536094_omnivsx850.pdf

File size: 4.34 MB

File Language: English, French, Spanish, German, Russian

Pages: 56

Author: Tripp Lite

File created: 2018-10-03

Published: 2023-11-24

Updated: 2023-12-11

Download File

Specifications

Brand: Tripp Lite

Model: OMNIVSX850

Category: Computing

Nominal Input Voltage(s) Supported: 230V AC

Nominal Voltage Details: 230V nominal output in battery mode

Frequency Compatibility: 50 / 60 Hz

Frequency Compatibility Details: Automatic frequency selection

Output Voltage Regulation (Battery Mode): ±10%

Output AC Waveform (Battery Mode): PWM sine wave

Nominal Output Voltage(s) Supported: 220V; 230V; 240V

Battery Type: Valve Regulated Lead Acid (VRLA)

DC System Voltage (VDC): 12

Battery Recharge Rate (Included Batteries): Less than 8 hours from 10% to 90%

Internal UPS Replacement Battery Cartridge: RBC51

Battery Replacement Description: See manual for battery replacement information

UPS Power Module Dimensions (hwd, in.): 6.3 x 4.8 x 13.6

UPS Power Module Weight (kg): 5.99

UPS Power Module Weight (lbs.): 13.2

Low Voltage Transfer to Battery Power (Setpoint): 170V

High Voltage Transfer to Battery Power (Setpoint): 280V

UPS Input Connection Type: C14 inlet

Output Capacity (VA): 850

Output Capacity (kVA): 0.85

Output Capacity (Watts): 480

Output Capacity (kW): 0.48

Primary UPS Depth (mm): 345

Primary UPS Height (mm): 160

Primary UPS Width (mm): 122

Shipping Dimensions (hwd / in.): 9.80 x 14.20 x 23.60

Unit Weight (lbs.): 13.200

Runtime Full Load (min.): 1 min. (480W)

Runtime Half Load (min.): 5 min. (240W)

UPS AC Suppression Response Time: Instantaneous

EMI / RFI AC Noise Suppression: Yes

Operating Temperature Range: 32° to 104°F (0° to 40°C)

Storage Temperature Range: 5° to 122°F (-15° to 50°C)

Relative Humidity: Up to 90%, non-condensing

AC Mode Efficiency Rating (100% Load): >95%

Audible Noise: Less than 40dB front side 1m

Transfer Time: 6 milliseconds

Green Energy-Saving Features: Greater than 95% efficiency - GREEN UPS

UPS Housing Material: ABS
