TOUCH CODE TRANSMITTER MODEL 139.53776
OWNERS MANUAL
FCC. rules prohibit adfustments to or modification of receiver and transmitter circuitry except for changing the code setting
and replacing the transmitter battery. THERE ARE NO OTHER USER SERVICEABLE PARTS.
Manufactured under" 1 _ m_e of the following U S. patents: RE29,.525; 4,037",201; 4,750,118; 4,806,930
FEATURES OF THE TOUCH CODE TRANSMITTER
Personalized Code: Upto 10,000 possible combinations,
Code can easily be changed if desired.
Operation: Opener activates when programmed code is
keyed into transmitter and ENTER button is pressed,
The user has 10 seconds to key in the 4-digit code and
press the ENTER button.
tf wrong numbers are accidentally pressed, correction can
be made immediately. The ENTER key will transmit only
the last four digits°
This transmitter can be used with any 5B000SR Series
garage door opener and/or Light Control.
Keypad will Illuminate for 10 seconds at the first push of
ANY number key,
Keypad will remain illuminated for 20 seconds after code
is transmitted° During that time you can STOP or
REVERSE door travel just by pressing the ENTER key.
Power Supply: 12Volt battery.
Installation: Simple to install, Fastening screws and plug
are provided_
All 53000SR Sedes Receivers have two memory channels;
one for the Touch Code Transmitter and the other for all
portable transmitters used to operate an opener or to turn
on lights.
INSTALL TRANSMITTER
Open the transmitter cover and remove the battery compartment screw. Set cover aside and remove battery. NOTE BATTERY
POLARITY AS MARKED ON COMPARTMENT Follow the mounting instructions which apply to your type of door as
described below.
NOTE: If you want the transmitter' in a location different from the one illustrated, it is recommended that you program
the code into the receiver and test the operation of the transmitter before mounting it. A metal door, foil-backed insula-
lion or aluminum siding will lessen transmission range.
SECTIONAL DOOR INSTALLATION: Center the trans-
mitter on garage jamb face at eye level as shown (Figure 1).
Hold the transmitter firmly against jamb with cover half open
so both top and bottom mounting holes are visible_ Use a
punch to mark each hole.Drill two 1/8" pilot holes, Fasten
transmitter securely with screws provided.
insert the plug provided into top hoTe to cover the fastening
screw. Wl'len installing the battery, be sure to observe
polarity (refer to illustration), Re-fasten compartment
cover.
ON_=-PIECE DOOR INSTALLATION: Install the
transmitter on exterior front wall of a FRAME garage. Be sure
to position it away from the door opening to avoid injury as
door swings out and up (Figure 2). NOTE: If the garage is
constructed of material other than wood (brick, stone or
aluminum siding), install transmitter on door jamb with
this important exception: LOCATE TRANSMITTER ON
OUTSIDE EDGE OF DOOR JAMB TO AVOID INJURY AS
DOOR SWINGS OUT AND UP.
Mark fastening holes, drilt and install the transmitter as
instructed for sectional door_ NOTE BATTERY POLARITY.
Keyboard
FIGURE t
b
FIGURE 2
Garage
!
Side 1
