1
Description: ROBINHOOD WORKSTATION SUPERTUB SPLASH BACK
Model Number: SB1200
751152
Issue: A
All dimensions in mm
Model may vary slightly from images pictured
2
Overview
Contents of packaging:
1 x splash back
1 x stainless steel handle
2 x chrome baskets
1 x installation kit
Installation
1. Fix handle using fixing screws and washers supplied.
Typical equipment required:
o electric drill
o screwdriver
o tape measure
o spirit level
3
Installation - continued
2. Fix mounting screws and cup washers to the wall using the dimensions given below. Mounting to a stud is recommended.
However, if fitted to other wall linings (plasterboard, concrete etc) suitable wall fixings will be required.
A Distance from the bench top to the lower fixing screw
100mm flush fit between the bottom surface of the splash back and the bench top
103mm allows a 3mm gap between the splash back and bench top if sealing is required
3. Hang splash back from the cup washers.
Cleaning and maintenance
Powder coated surfaces must not be cleaned with abrasive or chemical cleaners. To keep the splash back looking
its best, wipe regularly with a damp soft cloth. A mild soap and water solution may be used to remove stubborn
dirt. Under no circumstances should harsh detergents (including chemical cleaners) such as bleaches, scourers or
any abrasive cleaner be used as these products may irreparably damage the surface finishes of the splash back.
NB. Their use will render the warranty void.
For any other problems please call help line on NZ 0800 760 667 or AUS 1800 648 556
4
Warranty Certificate (New Zealand)
The benefits conferred hereunder are in addition to all other rights and remedies in respect of the product which the purchaser has by virtue of the Consumer Guarantee
Act and similar legislation, and nothing contained in this Certificate shall in any way limit the purchaser's rights under such legislation.
Terms and Conditions
The following conditions apply in respect of the warranty given in this certificate:
1. Robinhood warrants this product against manufacturing defects and faulty materials for a period of:
2. Rangehood – 24 months from date of original purchase.
3. Supertub – Lifetime on stainless bowl, 5 years on single lever unit, 1 year on other components from date of original purchase.
4. Ironing Centre – 12 months from date of original purchase.
5. Uniduct – 12 months from date of original purchase. For commercial use 3 months from date of original purchase.
6. This warranty is limited to the repair or replacement free of charge within the warranty period of any component part which Robinhood at its discretion determines to
be faulty. Such warranty is subject to terms and conditions set out below.
7. The warranty applies within New Zealand.
8. The customer must produce the original invoice or other purchase documentation as proof of the purchase date.
9. To abide by the guarantee please complete the details below and keep it with your purchase invoices.
10. In the event that service is required, contact the source from whom the product was purchased. It will be the responsibility of that sales agent to direct the purchaser
to an authorised service centre or replace the defective parts. All costs of labour performed outside an authorised Service Centre will not be the responsibility of
Robinhood. Alternatively contact Robinhood.
Warranty exclusions
1. The warranty does not apply for the following:
If defect is caused by misuse, wear and tear, dirt, fire or accidental damage.
If the product has been repaired or serviced by an unauthorised person.
If installed contrary to Robinhood instructions.
Products purchased overseas or not designed for use in New Zealand.
Normal user adjustments or customer instruction on the product’s operation.
Abnormal product performance as a result of incorrect installation or deviation from specified instructions.
All costs incurred on installation or removal.
If the product is used outdoors.
2. A charge shall be made if the service person finds the product is functioning correctly.
3. Paint finishes and the colours in plastics are fully covered by this warranty for 12 months from date of purchase.
Should service be required please contact the store where you purchased your Robinhood product. If you require any further advice or information on Robinhood product
feel free to contact:
Robinhood
Free Phone: 0800 760 667
Free Fax: 0800 276 246
Email: [email protected]
Website: www.robinhood.co.nz
Name of purchaser
Address
Date of purchase Model number Serial No/Date stamp
Name of supplier
Address
Invoice number
Complete these details and keep it with your purchase invoice.
DO NOT POST
5
Warranty Certificate (Australia)
The benefits conferred hereunder are in addition to all other rights and remedies in respect of the product which the purchaser has by virtue of the Trade Practices Act
1974 and similar State and Territory legislation and nothing contained in this Certificate shall in any way limit the purchaser's rights under such legislation.
Terms and Conditions
The following conditions apply in respect of the warranty given in this certificate:
1. Robinhood warrants this product against manufacturing defects and faulty materials for a period of:
2. Rangehood – 24 months from date of original purchase.
3. Supertub – Lifetime on stainless bowl, 5 years on single lever unit, 1 year on other components from date of original purchase.
4. Ironing Centre – 12 months from date of original purchase.
5. Uniduct – 12 months from date of original purchase. For commercial use 3 months from date of original purchase.
6. This warranty is limited to the repair or replacement free of charge within the warranty period of any component part which Robinhood at its discretion determines to
be faulty. Such warranty is subject to terms and conditions set out below.
7. The warranty applies within the Commonwealth of Australia.
8. The customer must produce the original invoice or other purchase documentation as proof of the purchase date.
9. To abide by the guarantee please complete the details below and keep it with your purchase invoices.
10. In the event that service is required, contact the source from whom the product was purchased. It will be the responsibility of that sales agent to direct the purchaser
to an authorised service centre or replace the defective parts. All costs of labour performed outside an authorised Service Centre will not be the responsibility of
Robinhood. Alternatively contact Robinhood or your nearest Service Agent as listed below.
Warranty exclusions
1. The warranty does not apply for the following:
If defect is caused by misuse, wear and tear, dirt, fire or accidental damage.
If the product has been repaired or serviced by an unauthorised person.
If installed contrary to Robinhood instructions.
Products purchased overseas or not designed for use in New Zealand.
Normal user adjustments or customer instruction on the product’s operation.
Abnormal product performance as a result of incorrect installation or deviation from specified instructions.
All costs incurred on installation or removal.
If the product is used outdoors.
2. For warranty service outside of Capital City metropolitan area or 30 km from nearest authorised service agent the purchaser shall be liable for travelling expenses and
cost of transport of the product or parts to and from the Service Agent
3. Paint finishes and the colours in plastics are fully covered by this warranty for 12 months from date of purchase.
4. A charge shall be made if the service person finds the product is functioning correctly.
Should service be required please contact the store where you purchased your Robinhood product. If you require any further advice or information on Robinhood product
feel free to contact:
Robinhood
Free Phone: 1800 648 556
Free Fax: 1800 628 577
Email: [email protected]
Website: www.robinhood.com.au
Area Service agents Contact details
Victoria J.A. Appliances Tel: (03) 8371 9100 Fax: (03) 9355 8644
Email: [email protected]
New South Wales (Sydney, North Coast) All General White Goods Services Tel: (02) 8788 8666 Fax: (02) 9756 1091
Email: [email protected]
New South Wales (Country, Wagga Wagga) K J Wardens Tel: (02) 6922 8600 Fax: (02)6922 8611
ACT K J Wardens Tel: (02) 6280 5736 Fax: (02) 6280 5376
Tasmania BSH Electrical Pty Ltd Tel: (03) 6231 0255 Fax: (03) 6334 1044
South Australia Ivesons Electrical Tel: (08) 8297 2033 Fax: (08) 8297 7881
Western Australia J.H. Wilberforce Tel: (08) 9340 6222 Fax: (08) 9340 6262
Queensland Terry Hayes Agencies Tel: 1800 6485561 Fax: (07) 3262 1217
Email: [email protected]
Name of purchaser
Address
Date of purchase Model number Serial No/Date stamp
Name of supplier
Address
Invoice number
Complete these details and keep it with your purchase invoice.
DO NOT POST
