Your remote control can be programmed to operate upto two devices, such as a garage door opener, gate
operator, or commercial door operator andhas a SMART/ LEARN button. Eachbutton on the remote control
works independently of the other andmust be programmed separately. The images throughout this manualare for
reference only andyour product may look different.
STOP
Read instructions thoroughly BEFORE beginning. If you are using this product with residential door
openers, this product must be used only withdoor openers manufactured starting January 1, 1993
that use photoelectric sensors located near the bottom of the door track.
WARNING: This product can expose you to chemicals including lead, which are known to the State of California
to cause cancer or birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov
To prevent possible SERIOUS INJURY or DEATH:
• NEVER allow smallchildren near batteries.
• If battery is swallowed, immediately notify doctor.
To reduce risk of fire, explosionor chemical burn:
• Replace ONLY with 3V CR2032 coin batteries.
• DO NOT recharge, disassemble, heat above 212°F (100°C) or incinerate.
PROGRAMMING
PROGRAM TO GARAGE DOOR OPENERS WITH A YELLOW LEARN BUTTON
If your remote was previously programmed to another type of opener, see PROGRAM TO COMPATIBLE GARAGE DOOR
OPENERS AND OPERATORS to reprogram to a yellow LEARN button.
1. Start withthe garage door closed.
2. Press andimmediately release the yellow LEARN button. The Learn LED glows steady for 30seconds.
Within30 seconds...
3. Press andhold the button onthe remote controlyouwish to use.
4. Release the button when the garage door opener lights blink or two clicks are heard.
5. Test by pressing the button youjust programmed. The opener activates.
To program the remote to Chamberlainaccessories, refer to the manual provided withthe accessory.
Yellow
LEARN
Button
PROGRAM TO COMPATIBLE GARAGE DOOR OPENERS AND OPERATORS
1. Start withyour garage door, gate, or commercial door closed.
2. Remove the remote control cover. Press and holdthe program button untilthe LED turns on.
3. Press andrelease the SMART/LEARN button onyour product or matchthe remote control DIP SWITCHES
to the existingreceiver or existing remote control.
4. Select a buttontoprogram onthe remote control. Press and release the buttonthe specified number of
times accordingtothe following list. NOTE: Make sure the LED stops flashing between each press of the
button. The garage door opener will respond by clicking, blinking or activating.
... 8 times Chamberlain
®
* Yellow Button 2011-Current
... 3 times Chamberlain
®
* Purple Button 2005-Current
... 2 times Chamberlain
®
* Orange Button 1997-2005
... 4 times Chamberlain
®
* Green Button1993-1996
... 6 times Genie OverheadDoor
®
Intellicode 1995-Current
... 5 times Genie OverheadDoor
®
** Intellicode 2005-Current
... 1 time Linear
®
Mega-Code 1997-Current
... 7 times Stanely
®
Security Code 1998
... 9 times Wayne Dalton
®
Rolling Code 372.5 MHz 1999-Current
... 14 times Linear Multicode
®
10 Position Dip Switch
... 16 times Stanley Multicode
®
10 Position Dip Switch
... 18 times Linear
®
8 Position Dip Switch
... 10 times Xtreme Garage
®
, Guardian
®
Black Button 2005-Current
... 11 times Sommer
®
Black Button 1998-Current
* LiftMaster, Do-It, Master Mechanic, Raynor, True Value and Sears Craftsman are
compatible with Chamberlain technology.
** Find Genie Intellicode II instructions at support.chamberlaingroup.com.
5. Press the program buttonon the remote controltosave.
6. Test by pressing the button youjust programmed. The opener activates.
To program the remote to Chamberlainaccessories, refer to the manual provided withthe accessory.
LED
Program
Button
Cover
LEARN
XMITTER
CONTROL BOARD
RADIO
BUTTON
LOGIC BOARD
SMART/LEARN
BUTTON
RECEIVER REMOTEDIP SWITCHES
• The SMART/LEARN buttonor DIP SWITCHES are located either onthe product or inan external receiver on
or near the product. Consult your product owner’s manual to locate the SMART/LEARN buttonor
DIPSWITCHES.
• If youhave a 2 position DIP SWITCH and programming fails, reverse DIP SWITCHES (OFF to ON and
ONtoOFF).
BATTERY
To prevent possible SERIOUS INJURY or DEATH:
• NEVER allow smallchildren near batteries.
• If battery is swallowed, immediately notify doctor.
To reduce risk of fire, explosionor chemical burn:
• Replace ONLY with 3V CR2032 coin batteries.
• DO NOT recharge, disassemble, heat above 212°F (100°C) or incinerate.
Battery
Dispose of old batteries properly.
Replace ONLY with 3V CR2032
coin batteries.
NOTICE: This device complies with part 15 of the FCC rules and Innovation, Science and Economic Development Canada license-exempt
RSSs. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation. Any changes or modifications not
expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules and
Industry Canada ICES standard. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
LiftMaster.com
Chamberlain and LiftMaster are Trademarks of Chamberlain Group. Genie is a Trademark of Overhead Door Corporation. Overhead Door is a Trademark of Overhead Door Corporation. Linear is a Trademark of Linear Corporation. Master Mechanic is a Trademark of TruServ. Sears is a
Trademark of Sears & Roebuck. Stanley is a Trademark of The Stanley Works. Wayne Dalton is a trademark of Wayne Dalton Corporation. Do It is a trademark of Do It Best Corporation. L.L.C. Sommer is a trademark of Sommer Antriebs-und Funktechnik GmbH. Xtreme Garage is a
trademark of Menard, Inc. Guardian is a Trademark of ADH Guardian USA LLC.
© 2020, LiftMaster
All Rights Reserved
114-5463-000B
UNIVERSAL REMOTE CONTROL
Model 380UT
